K-Tech ET901 Operating instructions

Line Specifications:
(See also the Installation Guide)
The K-Tech ET901 works on most phone lines meeting
the following minimum conditions:
1. 24 - 51 V Analog line (on hook)
2. DTMF compatible
3. 20 mA min loop current
4. 18 –22 gauge shielded twisted pair in elevator trav-
eling cable.
Phone number hints:
Check to see if you need to dial the area code or 1 be-
fore the number.
On PBX systems you may have to put a 9 or 8 and a
pause (¾) before the phone number. Also you may
need to set the timer to “02” or “03” for proper shutoff.
Special Conditions:
The K-Tech ET901 has it’s own built in dialer and cannot
be used with an external dialer.
Using the phone on a ringdown circuit may restrict use
of SUREphone features which are related to the dialing
circuit. Program a pause in phone location 1.
All special phone line features, such as call waiting and
call forwarding should be turned off.
QUICK TROUBLESHOOTING K-Tech
ET901
Programming
Guide
Serial Number: ____________________________
Date Installed: ____________________________
Installed by: ____________________________
Phone Line #: ____________________________
Phone line Voltage: 48VDC (POTS or CO line)
24VDC (PBX System)
Other ____________________
Phone Number(s)
Dialing:
1. ___________________________________
2. ___________________________________
3. ___________________________________
4. ___________________________________
5. ___________________________________
Voice message
________________________________________________
________________________________________________
________________________________________________
________________________________________________
SERIAL #
K-Tech International Inc.
Part # PCB045 Rev. ___ 5 _ _ _ _ _
FAQ
Q. Operator cannot hear passenger at beginning of call.
A. If not using voice message announcement—check to
see if it is deleted properly.
Q. Can the phone work only on phone line power?
A. The SUREphone requires AC power in order to
operate.
Q. Passenger cannot hear operator.
A. Check for excessive noise in elevator, such as a bad
fan. On COP mount units check for proper sealing
between COP and phone faceplate
Keep This Booklet for
Reference
Additional information is available at
www.KTechOnline.com
K-Tech International, Inc
BOK057 Printed in USA
56 Ella Grasso Ave
Torrington, CT 06790 USA
Phone [phone]
Sales: 1-800-993-9399
Tech Support: 1-888-883-8399
Fax [phone]
Email: [email protected]
Website: www.KTechOnline.com
THE INFORMATION BELOW IS IMPORTANT.
YOU MUST HAVE THE SERIAL NUMBER
AVAILABLE WHEN CALLING TECH SUPPORT.
1-888-883-8399

1. Enter programming mode.
2. Press ¾then 1.
3. Press # to start recording, # when finished.
4. After recording, phone will play back the
message. If incorrect go to step 2.
To delete message:
1. Enter programming mode.
2. Press ¾, then 1.
3. Press #, #.
4. There will be no message played back, or you
will hear a short tone when erasing remotely.
STEP 3 THE MESSAGE
Multiple phones on a single line must be given a
two digit ID for each phone.
1. Enter programming mode.
2. Press ¾, then 8.
3. Enter 2 digit ID code.
Single phone with dedicated single phone line.
Enter pound twice [# #] as the two digit ID
code in STEP 3.
1. Enter programming mode.
2. Press ¾then 3 wait for prompt.
3. Enter memory address, start with 1.
For multiple numbers use 2 - 5.
4. Enter phone number, then press the # key
(use the ¾key to program a pause).
5. Phone will play back the number.
(If incorrect go to step 2).
6. Repeat steps 2 and 3 for multiple numbers.
On Ringdown, program a single pause ¾into
phone number memory address # 1.
STEP 2 PHONE NUMBER
 ACTIVATION
Press the activating push-button. The LED will
turn on, then dial tone will be heard for 2-3
seconds. The first phone number will dial.
If the call is answered within the programmed
number of rings, the voice announcement will play
to the answering party only. Check for two way
communication. Have them press # to flash a
single LED or activate the second LED. Tell them
the phone ID number.
 FOR MULTIPLE NUMBER DIALING
If the call is not answered within the programmed
number of rings or the number is busy the phone
will hang up and dial the next number until all
numbers in memory have been dialed. It then
returns to the first number for a total of twelve
attempts.
 CALLING THE PHONE
Have the answering party call the elevator back.
For multiple phones on a single line, the phone
will turn on and the following message will be
heard: “ At the tone you will be connected to
all phones, or, for one phone enter phone ID
number now”. Enter ID # or wait for tone. If the
wrong ID is input the phone will hang up. After the
tone check for two way communication.
 ENDING THE CALL
The phone will automatically shut off within 10
seconds after the answering party hangs up, or
by the auto shut off timer.
 Need help, call the K-Tech support line
1-888-883-8399
STEP 5 TESTING
Program Feature Number [Default Setting]
1 - Voice Message #1 [Blank] (Automatic)
2 - Voice Message #2 [Serial number]
3 – Phone Directory -[Blank]
Memory address 1,2,3,4,5 (number must be at
least one digit—max 20 digits)
4 – Auto shut off timer [05 minutes]
5 – Outgoing number of rings [4]
6 – Incoming number of rings [2]
7 – Enter programming mode
8 – ID number [01]
9 – Security code [ 1 2 3 4 ]
0—Volume [5] 1 (soft) —7 (loud)
# - Exit programming mode or shut-off
FEATURE LIST
STEP 4 SINGLE OR MULTIPLE
The phone can be programmed with the keypad
or remotely over the phone line.
To enter programming mode:
1. Press the ¾key followed by the 7 key
2. Wait for the voice to prompt you for a
security code.
3. Enter security code [factory default is 1234].
You are now in programming mode and you
will be prompted with the following message:
“Enter star then program feature number.”
Important: wait for voice prompt to end
before pressing any keys.
Press the ¾key then the number of the
feature you want to program.
To exit programming:
Press the ¾key followed by the # key to exit.
If security code is lost or forgotten, phone must be
returned to K-Tech for reprogramming.
STEP 1 PROGRAMMING MODE
The K-Tech ET901 Series meets FCC 15 and 68
standards, IC and ETL approval
FCC Registration # ERC-USA-32789-TE-T
REN (Ringer Equivalence Number) 0.0
