K2L MOST150 C-O Converter V1.0 Revision 1.0 (06-17-13)
K2L - USER MANUAL
MOST150 C-O Converter - Simplex Variant

MOST150 C-O Converter
Revision 1.0 (06-17-13) 2 K2L MOST150 C-O Converter V1.0
K2L - USER MANUAL
Table of Contents
Chapter 1 Preface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Scope of Delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3 Restrictions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4 Definitions of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Chapter 2 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Feature Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 3 Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Coaxial Electrical Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Optical Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Chapter 4 Pin Assignment of the Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1 MOST150 Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.2 Coaxial Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.3 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Chapter 5 Typical Use Case - Connection Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Chapter 6 Technical Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Chapter 7 Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

MOST150 C-O Converter
K2L MOST150 C-O Converter V1.0 3 Revision 1.0 (06-17-13)
K2L - USER MANUAL
List of Figures
Figure 2.1 Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Figure 3.1 Coaxial Electrical Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Figure 3.2 Optical Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Figure 4.1 Pin Assignment of the Power Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Figure 5.1 Typical Use Case: Connection Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

MOST150 C-O Converter
Revision 1.0 (06-17-13) 4 K2L MOST150 C-O Converter V1.0
K2L - USER MANUAL
List of Tables
Table 1.1 Definitions of Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Table 3.1 Interfaces on the Coaxial Electrical Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Table 3.2 Interfaces on the Optical Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Table 4.1 Pinning of the Power Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Table 6.1 Mechanical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Table 6.2 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Table 7.1 Customer Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

MOST150 C-O Converter
K2L MOST150 C-O Converter V1.0 5 Revision 1.0 (06-17-13)
K2L - USER MANUAL
Chapter 1 Preface
1.1 Intended Use
The K2L MOST150 C-O Converter is intended to be used for connecting optical tools or
devices to a MOST150 system basing on a coax electrical physical layer (cPHY).
1.2 Scope of Delivery
The delivery covers the following:
MOST150 C-O Converter
Very short optical MOST cable
Coaxial cable
Power adapter cable for use together with OptoLyzer OL3150o / OptoLyzer MOCCA compact V3.1
Power supply (optional)
Check your shipment for completeness. If you have any complaints direct them to
[email protected]. Providing the delivery note number eases the handling.
1.3 Restrictions
The MOST150 C-O Converter does not contain any kind of PLL or signal recovery. As a
consequence this tool does not completely pass all MOST physical layer compliance tests.
The MOST150 C-O Converter cannot be used for physical layer tests.
The MOST150 C-O Converter can only be used for system test setups and demo setups.
The MOST150 C-O Converter and an optical tool have to be connected using a specific very short
optical cable without couplers. The very short optical cable is part of the shipment.

MOST150 C-O Converter
Revision 1.0 (06-17-13) 6 K2L MOST150 C-O Converter V1.0
K2L - USER MANUAL
1.4 Definitions of Terms
For better understanding of the following chapters, this section provides explanation to
special terms, used in the description of the MOST150 C-O Converter user manual.
Table 1.1 Definitions of Terms
TERM / ABBREVIATION DESCRIPTION
C-O Coaxial - Optical
cPHY coax electrical physical layer
DDepth
H Height
MOST®Media Oriented Systems Transport
PLL Phase-locked loop
VHDL VHSIC hardware description
VHSIC Very-high-speed integrated circuits
WWidth

MOST150 C-O Converter
K2L MOST150 C-O Converter V1.0 7 Revision 1.0 (06-17-13)
K2L - USER MANUAL
Chapter 2 Introduction
The MOST150 C-O Converter is a small, compact device designated for connecting optical tools or
devices to a MOST150 system basing on cPHY. As it has no firmware or VHDL inside and there are
no additional control elements the MOST150 C-O Converter is easy to apply.
MOST150 networks can be built up as optical or as coaxial systems. In order to use the features of
existing optical-based MOST150 devices also in coaxial systems the MOST150 C-O Converter can be
integrated in coaxial systems by just connecting the MOST150 network to the coaxial interfaces of the
MOST150 C-O Converter. The optical MOST150 devices can be connected to the optical interface of
the MOST150 C-O Converter using the delivered optical MOST cable. Afterwards the MOST150
devices can be used for developing, testing, or analyzing coaxial MOST150 based multimedia products
and systems. The MOST150 C-O Converter indicates both ‘power is connected’ and ‘MOST signal is
detected’.
2.1 Feature Summary
The following list covers the key features of the MOST150 C-O Converter:
Compact housing
Easy usage
Multiple hardware variants available (see homepage: http://www.K2L.de)
Combined power supply possible for MOST150 C-O Converter and OptoLyzer OL3150o or
MOST150 C-O Converter and OptoLyzer MOCCA compact
No firmware or VHDL inside
Indication of power detection for both connectors (optical and coaxial)
Indication of MOST signal detection for both connectors (optical and coaxial)

MOST150 C-O Converter
Revision 1.0 (06-17-13) 8 K2L MOST150 C-O Converter V1.0
K2L - USER MANUAL
2.2 Block Diagram
Figure 2.1 shows the features available for the MOST150 C-O Converter.
Figure 2.1 Block Diagram
The electrical MOST signal received via the Rx coaxial cable (1) is converted inside the MOST150
C-O Converter (2) and sent to a MOST150 device (oPHY) via the FOT (3). This MOST150 device
(e.g., an OptoLyzer OL3150o or an OptoLyzer MOCCA compact V3.1) (4) processes the optical MOST
signal and sends it back to the MOST150 C-O Converter where it is received via the FOT (5). Inside
the MOST150 C-O Converter the optical MOST signal is converted to an electrical MOST signal (6)
and sent via the Tx coaxial cable (7) back into the MOST150 system basing on cPHY.
The LEDs (8) inform whether the MOST150 C-O Converter is connected to power or about the
detection of a MOST signal (either optical or electrical).
Power In
MOST
Signal
Optical
Coaxial
MOST
Signal
MOST150 C-O Converter
FOT
LED
LED
Coax
Coax
(1)
(2) (3)
(7)
(6) (5)
(4)
(8)
(8)

MOST150 C-O Converter
K2L MOST150 C-O Converter V1.0 9 Revision 1.0 (06-17-13)
K2L - USER MANUAL
Chapter 3 Hardware Description
3.1 Coaxial Electrical Panel
Figure 3.1 depicts the coaxial electrical panel of the MOST150 C-O Converter.
Figure 3.1 Coaxial Electrical Panel
All components of the coaxial electrical panel are described in Ta ble 3.1 from left to right.
How the MOST150 C-O Converter can be connected is described in Chapter 5, "Typical Use Case -
Connection Diagram," on page 12.
Table 3.1 Interfaces on the Coaxial Electrical Panel
INTERFACE COLOR DESCRIPTION
LED Red MOST150 C-O Converter is powered.
Green If the MOST150 C-O Converter is powered and a MOST signal has
been detected in the MOST150 system basing on cPHY, the LED
switches to green.
Coaxial out - Coaxial Tx interface to be connected to the MOST150 system basing
on cPHY. For details refer to Section 4.2, "Coaxial Connector," on
page 11.
Coaxial in - Coaxial Rx interface to be connected to the MOST150 system basing
on cPHY. For details refer to Section 4.2, "Coaxial Connector," on
page 11.
LED Coaxial out Coaxial in

MOST150 C-O Converter
Revision 1.0 (06-17-13) 10 K2L MOST150 C-O Converter V1.0
K2L - USER MANUAL
3.2 Optical Panel
Figure 3.2 depicts the optical panel of the MOST150 C-O Converter.
Figure 3.2 Optical Panel
All components of the optical panel are described in Ta b le 3.2 from left to right.
How the MOST150 C-O Converter can be connected is described in Chapter 5, "Typical Use Case -
Connection Diagram," on page 12.
Table 3.2 Interfaces on the Optical Panel
INTERFACE COLOR DESCRIPTION
FOT - Optical connector. For details refer to Section 4.1, "MOST150
Connector," on page 11.
LED Red MOST150 C-O Converter is powered.
Green If the MOST150 C-O Converter is powered and a MOST signal has
been detected in the MOST150 optical system, the LED switches to
green.
Power - 12 V power supply. For details refer to Section 4.3, "Power," on
page 11.
FOT PowerLED

MOST150 C-O Converter
K2L MOST150 C-O Converter V1.0 11 Revision 1.0 (06-17-13)
K2L - USER MANUAL
Chapter 4 Pin Assignment of the Connectors
4.1 MOST150 Connector
Connector type: Tyco Micro Pigtail FOT (2+0).
The orientation of the Rx and Tx path is printed on the top.
The MOST150 connector is designated for a 2+0 optical header cable. The direction is visible on the
cable:
Tx: Optical output for MOST network
Rx: Optical input for MOST network
4.2 Coaxial Connector
Connector type: 59S20X-40ML5-Z FAKRA
4.3 Power
Figure 4.1 shows the pin assignment as it is visible on the rear panel.
Figure 4.1 Pin Assignment of the Power Connector
Table 4.1 Pinning of the Power Connector
PIN NO. SIGNAL DESCRIPTION
1 12 V Power supply
2 Reserved -
3 GND System ground

MOST150 C-O Converter
Revision 1.0 (06-17-13) 12 K2L MOST150 C-O Converter V1.0
K2L - USER MANUAL
Chapter 5 Typical Use Case - Connection Diagram
The Figure 5.1 below shows the connection diagram for a typical use case.
Figure 5.1 Typical Use Case: Connection Diagram
The instructions below describe how the MOST150 C-O Converter can be connected:
1. Power off all devices.
2. Connect the coaxial electrical panel of the MOST150 C-O Converter to a MOST150 system using
the delivered coaxial cable (1).
3. Connect an optical MOST150 device (e.g., an OptoLyzer OL3150o or OptoLyzer MOCCA compact
V3.1) to the optical panel of the MOST150 C-O Converter using the delivered, very short MOST
cable (2).
4. In case an OptoLyzer OL3150o (or OptoLyzer MOCCA compact V3.1) is used as optical MOST150
device, connect the delivered power adapter cable with the power supply pack (3) of the OptoLyzer
OL3150o (or OptoLyzer MOCCA compact V3.1) as shown in Figure 5.1.
Alternatively if neither an OptoLyzer OL3150o nor an OptoLyzer MOCCA compact V3.1 is used,
connect a power supply pack that has to be ordered separately (not part of shipment). Proceed
with step 6.
5. Connect both OptoLyzer OL3150o (or OptoLyzer MOCCA compact V3.1) (4) and the MOST150
C-O Converter (4) with the delivered power adapter cable as shown in Figure 5.1.
6. Power the devices.
MOST150 System (cPHY)
MOST150
System
oPHY
OptoLyzer OL3150o (e.g.)
MOST150 Device
MOST150 Device
MOST150 Device
MOST150
C-O Converter
Short MOST Cable
(Part of Shipment)
12 V Power
(e.g., Power Supply of
the OptoLyzer OL3150o)
Power Adapter Cable
(Part of Shipment)
(1)
(2)(3)
(4)
(4)

MOST150 C-O Converter
K2L MOST150 C-O Converter V1.0 13 Revision 1.0 (06-17-13)
K2L - USER MANUAL
Chapter 6 Technical Specification
The table below covers mechanical characteristics of the MOST150 C-O Converter.
The table below covers electrical characteristics of the MOST150 C-O Converter.
Table 6.1 Mechanical Characteristics
PARAMETER VALUE UNIT
Dimensions (H x W x D) 110 x 80 x 35 mm
Weight 180 g
Ambient Temperature Range -40..+60 °C
Table 6.2 Electrical Characteristics
PARAMETER MIN TYP MAX UNIT
Operating Voltage Range 8 12 30 V
Current Consumption (operation) 100 mA

MOST150 C-O Converter
Revision 1.0 (06-17-13) 14 K2L MOST150 C-O Converter V1.0
K2L - USER MANUAL
Chapter 7 Revision History
Table 7.1 Customer Revision History
REVISION LEVEL &
DATE
SECTION/FIGURE/
ENTRY CORRECTION
Rev. 1.0
(06-17-13)
Initial Version

Further Information
For more information on K2L automotive products, software, and MOST®development tools and
modules, visit our web site: http://www.K2L.de. Direct contact information is available at:
http://www.K2L.de/contact.
K2L GmbH
Bannwaldallee 48
D-76185 Karlsruhe
Germany
Technical Support
Contact information for technical support is available at: [email protected]
MOST150 C-O Converter
K2L MOST150 C-O Converter V1.0 15 Revision 1.0 (06-17-13)
K2L - USER MANUAL
