KAF International Indurre IND-600 User manual

User Manual
Leaders in Dehumidification
E-mail : support@kafinternational.in Web. : www.kafinternational.in

DATASHEET
Make : Indurre
DehumidificationCapacity
Dehumidifying capacity (kg/hr)
Air Flow (m3/hr)
Humidity Setting
Working Temperature
Power Supply
Rated Current
Power consumption
Noise Level
Compressor type
Refrigerant
Water Drain
Net Weight
Gross Weight
Product Dimensions (L x W x H)
Quality/ Safety Approval
60 liters/Day (at 30°C, 80%RH)
2.33
550
30-95%
5 - 38 °C
220-240 VAC/50 Hz
3.0A
850 W
Below< 49 DB
Rotary
R22
Drain out Pipe
40 kg
42 kg.
330 x 495 x 673mm(13" x 19.5" x 26.5")
ISO/CE
Make : Indurre
Remove Water 60 Liters Per 24 Hrs
Automatic humidity control
Adjustable.RH20-95%
Display humidity trouble.
High speed humidity control
Washable, activated carbon filter
Humidity Set at will, humidity control
Micro-computer Control system
It can be set to be off from 1hour to 24 hours.
3 minutes delayed for protecting the compressor.
The transducer can examine itself.
Microcomputer automatic defrost system, suitable for low temperature ambience
For more details - www.kafinternational.in
Note:- Power Supply should be proper. Our Risk & responsibility ceases if electricity supply
is not proper as per requirement.
Use stabilizer / UPS for trouble free performance.



V.
Common Troubleshooting
Failure
Cause analysis
Method
Dehumidifier
cannot work
1. Power cut
2. Power switch is not energized
3. Power cord is not connected
4. Fuse is melted
1. Recover the power
2. Energize the power
3. Connect the power cord
4. Replace the fuse
Dehumidification
is not ideal
1.
Dustaccumulated inair
purificationfiltermesh
2.
Object blocking air inlet and outlet
3.
The door or window is open
Refrigerant is leaking
1. Clear the filter mesh
2. Remove the blocking object
3. Close the door and window
4. Contact with distributor or
manufacturer for repair
Water leak
1. The machine is inclined
2. Water pipe is blocked
1. Level the machine
2. Remove the blocking object
Abnormal noise
1. The machine is not placed solidly
2. The filter mesh is blocked
1. Place the machine firmly.
2. Clear the filter mesh.
1.
Where the above troubles cannot be fixed and repair is needed, please contact supplier or distributor.
Do not disassemble without authorization.
2.
When the dehumidifier is in operation or stops, voice of circulating of refrigerating can be heard.
Such phenomenon is normal.
3.
It is normal for the air outlet to drain hot air.
VI.
Instruction on Code of Failure
This dehumidifier is able to automatically judge failure. If there is any failure, there will be failure code
displayed on the humidity display window.
Ind-600, code of failure ?
Failure display
Problem
bt
Temperature sensor
failure
bh
Humidity sensor failure
t-L
Low Temp
t-h
High Temp
wf
Water full

Warranty
Thank you for choosing Indurre dehumidifier. Itwill bring you great convenience on both work and life. Ifthere
is any failure, please contact our repair department or after-sale service center. We will offer you good
consultancyandrepairservice.
We, KAF International (hereafter referred to as the company) Warrants to the original purchaser of this KAF
Dehumidifier (hereafter called product) bearingS.No. That for a Period of36 month commencing fromthedate
of original purchase, the Company or its Authorized dealer/Service Franchisee will repair or replace with the
neworfunctionallyoperativeparts,freeofcharge,anypartor partsoftheDehumidifier.
According to national law, the followings are not covered by warranty and will be charged with cost (charge
standard: repair fee + replacement of part)
1. Failureanddamagecausedbymal-operationofcustomernotfollowingthemanualor instruction.
2. Damagecausedbytransportationor handling.Customerreplaces,disassemblesand changes machine
numberwithoutauthorization.
3. Damagecausedbysuchnaturaldisasteraslightningstrike,waterdisasterandfire.
4. Damage caused by use of power with abnormal voltage or power supplied by non-power-
supplyingdepartment.
5. Temperaturesensoriseasilydamagedandis notcoveredbywarranty.
6. Damagescausedbyuseinadverseenvironmentofbeingacid,alkaline,salty,sticky,dusty a n d
hightemperature(over38?)arenotcoveredbythewarranty.
7. The machine has no explosion-protection. If there are any accidents caused by use in
explosiveandcorrosiveenvironment,ourcompanybearsnoliability.
8. Withinthewarrantyperiod,partstobe replacedmustbeexchanged with oldones fornew ones.
TERMS AND CONDITIONS OF WARRANTY
1. ThisWarrantyis applicabletothe firstpurchaser oftheproduct further, theWarrantyis applicable only if a
defect has been identified to be on account of faulty material or work man ship and not due to improper
usage.
2. TheCompanyoritsAuthorizedDealer/ServiceFranchiseealonecaninstallservice/repairtheproduct.
3. The Company will make every effort to carry out repairs / replacement of part/components under this
Warranty expeditiously. In the event toany delay in service due to lack/ non- availability of spares parts
componenttheCompanyshallnotbeliableforanyconsequentialdamages.
4. The Warranty shall automatically terminate on the expiry of Warranty period specified in the Warranty
card, even ifthe Product may not have been in use for any time during the Warranty period, for any reason
whatsoever.
5. In the event of repairs / replacement of any parts of any parts of the Product, this warranty will there after
continue and remain in force only for the unexpired Period of the Warranty. More over the time taken for
repair / replacement and transit whether under the Warranty or otherwise shall not be excluded from the
WarrantyPeriod.
6. The Warranty will continue to be in force for the terms specified above irrespective of what replacement
may be provided under it and such replacement shall not attract any fresh period of Warranty, beyondthe
periodspecifiedintheWarrantyCard.
7. The Company or its Authorized Dealers/service Franchises reserve their right to retain any spare parts or
componentreplacedonaccountofanydefectnoticedintheProduct,duringtheWarrantyPeriod.
8. This warranty does not cover any excise duty, central or statesales tax and octoi or any other taxes payable
on the spare parts / sealed system parts,/ components which company may supply or repair for free of cost
duringwarranty period.Thewarranty does notcover thecost ofpacking, toand for freight charges, delivery
and transportation charges on the spare parts /components sent to the company's head office at Delhi or to
thelocation oftheauthorizedservicefranchiseeoritsbranches.
9. In no event shall the company or its Authorized Dealer / Service Franchisees be liable for special or
consequentialdamagesorresultingliability,damageor lossarisingdirectlyor indirectlyforanydelayin the
performanceofthiswarranty,duetocausebeyondtheircontrol.

1. Thiswarrantydoesnotcoverairfilter,plasticpartsandaestheticdesignsparts/Components.
2. This warranty shall not in any case extend towards payment of any monetaryconsideration
whatsoever.Onlycompanyreservesitsrighttoextendthewarrantyinspecialcases.
3. TheCompany's employees atbranchlocations or itsAuthorizedDealers/ServiceFranchisees
/Dealers do not have any authority either to extend the Warranty Period and / or to vary the
terms of this warranty.
4. TheWarranty is effected inDelhi and claims if any,shall bemade only before the competent
Courts, having jurisdiction in Delhi. No claims what so ever shall be made against the
company outside Delhi, not with standing that the product may have sold or delivered or any
stipulationor commitmentinrespectthereof mayhavemadeelsewhere.
5. During Warranty Period, Purchaser will have to bring product at collected by purchaser at
purchasers'cost.
THIS WARRANTY IS NOT VALID LIN CASE OF ANY OF THE FOLLOWING
EVENTS
1. The Warranty Card is not completed in all respect including being duly sealed an signed by
theDealer,atthetimeofpurchaseof theproduct.
2. In caseofanyvariation/fluctuationofsupplyvoltagebeyondspecifiedtolerance.
3. OperatingInstructionsgiveninmanualnotfollowed.
4. Damages/Defectsarecausedbyimproper/negligent use.
5. Repair/serviceworkiscarriedoutbypersonsotherthanAuthorizedbytheCompany.
6. Theoriginalserialnumberoftheproductismodifiedor defaced
7. Any alterations are made in the electrical circuit of parts / components either by the way of
adjustments, addition, removal byabnormal voltage, floor, fire, burring objects kept near by
orothernaturalcalamities.
The Warranty is given in lieu of all other conditions expressed or implied by law or byany
persons purporting toact onbehalfof theCompany and excludes every conditions not herein
expresslysetout.
is the Trade mark of KAF International
AN ISO 9001 : 2015 Certified Co.
New Delhi-110031
