2008 Built-In Grill Specifications

Bringing Gourmet Lifestyles Outdoors Since 19062

www.KalamazooGourmet.com 1.800.868.1699 3
No Other Grill Cooks Like a Kalamazoo
No wonder Kalamazoo grills inspire such a loyal following. Over 115 BTUs per square inch of
primary cooking power. The ability to cook with any combination of charcoal, wood and gas.
Real hassle-free cleaning. Custom cooking surfaces. The advantages are unrivaled.
Hybrid Cooking with Charcoal, Wood and Gas Changing fuels is as
easy as opening the hybrid grilling drawer. Our powerful gas burners are
located below the hybrid drawer system. Use the burners alone to cook
with gas, or place wood or charcoal in the drawer. The gas burners can
be used to quickly and conveniently start a wood or charcoal fire, or to
maintain the heat for longer cooking sessions.
Ultimate Versatility Grilling, searing, roasting, smoking, wok cooking,
rotisserie and even baking. The power and versatility of Kalamazoo grills
enable home chefs to passionately pursue every cooking style they de-
sire, on a grill that makes it look effortless.
Custom Cooking Surfaces Homeowners can select their ideal combina-
tion of cooking surface patterns optimized for meat, fish and vegetables.
There is even a solid surface available for teppanyaki-style cooking. For
even further personalization, initials, logos and other artwork can be cut
into the surface. See page 11 for more information.
Easy-to-Use Rotisserie Cradles Forget the spit. Kalamazoo 450 and 900
Series grills come standard with a no-mess rotisserie cradle as part of the
infrared rotisserie system.
Integrated Cabinetry All Kalamazoo built-in and free-standing grills
come standard with integrated cabinetry for storage and access to the
deep hopper cleanout and electronic ignition modules.
Redundant Electronic Ignition The electronic ignition on a Kalamazoo
is a fully-redundant system. There are two independent electronic igniters
wired to each burner for reliable starting.
Hassle-Free Cleaning Any ash, grease and debris funnel down the
deep-hopper design into a cleanout pan that is large enough to hold
everything and deep enough to be easy to handle. There are no shallow
grease trays on a Kalamazoo to slosh all over your patio. Another benefit
of the deep-hopper design is that 99% of flare-ups are eliminated.
“The feature that really puts the Kalamazoo over the top
is that you can easily switch between gas and charcoal or
wood. It is as simple as opening the drawer!”
— Chef Rick Bayless
Wok-ready cooktop cabinets add
convenient storage and expand your
cooking capabilities.
Revolutionary hybrid grilling drawer
system.

Bringing Gourmet Lifestyles Outdoors Since 19064
Kalamazoo Built-In Grills
Kalamazoo 900HB Hybrid Built-In Grill
K900HB
Hybrid grill cooks with charcoal, wood
and gas
122,000 BTUs total cooking power
38.3” Wide
Built-In Grills with Stainless Steel Cabinets
Kalamazoo is the only manufacturer to offer built-in grills that include their
own stainless steel cabinets as a standard feature. Why? The Advanced
Cooking Concept at the core of every grill we make utilizes a deep cook-
box that extends far below the grilling surface for improved heat dynamics
and a broader range of outdoor cooking techniques. And, the hassle-free
cleaning system funnels down to a large and deep pan conveniently ac-
cessed within the cabinet. A Kalamazoo reaches all the way down to the
patio and stands on its own adjustable leveling legs for easy installation.
Each Kalamazoo is built to last and covered by a lifetime warranty. We build
the grills around a fully-welded stainless steel frame, and use much heavier-
guage stainless steel than our rivals, so much, in fact, that a Kalamazoo
900HB weighs-in at over 500 pounds.
Available in gas or hybrid charcoal, wood and gas models
432 square-inch (450 Series) or 864 square-inch (900 Series) primary
grilling area
50,000 main burner BTUs (450 Series) or 100,000 main burner BTUs
(900 Series) in 2 or 4 control zones
Infrared rotisserie cradle systems with 11,000 BTUs (450 Series) or 22,000
BTUs (900 Series) in 1 or 2 control zones
Hassle-free cleanout system
Optional custom laser-cut stainless steel cooking surfaces (see page 43)
Optional wok-ready cooktop (shown) (see page 28)
Available with 22,000 BTU infrared searing burner (K900G models only)
Natural gas standard, liquid propane configuration optional
Hand-built in 304 stainless steel on a fully-welded frame
Toe-kicks available
Kalamazoo 900GB Gas Built-In Grill
K900GB
Gas Grill
144,000 BTUs total cooking power
22,000 BTU infrared searing burner
38.3” Wide
Kalamazoo 450HB Hybrid Built-In Grill
K450HB
Hybrid grill cooks with charcoal, wood
and gas
61,000 BTUs total cooking power
26.9” Wide
Kalamazoo 450GB Gas Built-In Grill
K450GB
Gas grill
61,000 BTUs total cooking power
26.9” Wide

www.KalamazooGourmet.com 1.800.868.1699 5
Kalamazoo Built-In Grills (DIMENSIONS)
Kalamazoo 900HB Hybrid Built-In Grill
K900HB
Kalamazoo 900GB Gas Built-In Grill
K900GB
7.86
26.38
38.26
54.00
36.00
42.85
6.51
3.32
16.86
COUNTER
HEIGHT
+/- 1.5”
ADJUSTMENT
+/- 1.5”
ADJUSTMENT
INSTALLATION WIDTH
OVERALL WIDTH
MAX. INSTALLATION DEPTH
25.13
MIN. INSTALLATION DEPTH
+/- 1.5”
ADJUSTMENT
+/- 1.5”
ADJUSTMENT
2.5” REAR CLEARANCE
REQUIRED FOR HOOD
OPENING
2.5” REAR CLEARANCE
REQUIRED FOR HOOD
OPENING
7.86
26.38
3.32
MAX. INSTALLATION DEPTH
MIN. INSTALLATION DEPTH
+/- 1.5”
ADJUSTMENT
6.51
OVERALL WIDTH
38.26
54.00
36.00
42.85
16.86
COUNTER
HEIGHT
+/- 1.5”
ADJUSTMENT
+/- 1.5”
ADJUSTMENT
INSTALLATION WIDTH

Bringing Gourmet Lifestyles Outdoors Since 19066
Kalamazoo Built-In Grills (DIMENSIONS CONTINUED)
Kalamazoo 450HB Hybrid Built-In Grill
K450HB
Kalamazoo 450GB Gas Built-In Grill
K450GB
6” REAR CLEARANCE
REQUIRED FOR HOOD
OPENING
26.82
35.87
+/- 1.5"
ADJUSTMENT
12.75
33.30
49.70
+/- 1.5"
ADJUSTMENT
INSTALLATION WIDTH
COUNTER
HEIGHT
OVERALL WIDTH
MIN. INSTALLATION DEPTH
MAX. INSTALLATION DEPTH
+/- 1.5"
ADJUSTMENT
19.33
20.64
7.90
3.06
5.28
26.82
35.87
+/- 1.5"
ADJUSTMENT
12.75
33.30
49.70
+/- 1.5"
ADJUSTMENT
INSTALLATION WIDTH
6” REAR CLEARANCE
REQUIRED FOR HOOD
OPENING
COUNTER
HEIGHT
OVERALL WIDTH
MIN. INSTALLATION DEPTH
MAX. INSTALLATION DEPTH
+/- 1.5"
ADJUSTMENT
19.33
20.64
7.90
3.06
5.28

www.KalamazooGourmet.com 1.800.868.1699 7
Back Filler Panels for Grills
Filler Panel for Kalamazoo 900 Series Built-In Grills
K-BKFP-900B
Filler Panel for Kalamazoo 450 Series Built-In Grills
K-BKFP-450B
Filler panels are available to bring the back side of a Kalamazoo grill installation flush with the backs of our 30”-deep
kitchen cabinets and to support countertop spans behind the grill.
Filler panels connect to, and are suspended between, Kalamazoo Outdoor Kitchen Cabinets on either side. Counter over-
hang brackets are available.
Filler panels are ideal for island kitchen installations. Your expert Kalamazoo Outdoor Kitchen Consultant can advise you
regarding the use of these and other outdoor kitchen system components.
38.56
31.50
2.00 27.13
31.50
2.00

Bringing Gourmet Lifestyles Outdoors Since 19068
Cooktop for Built-In Installations
KKBI
Natural gas standard, liquid propane configuration optional
Custom stainless steel griddle available (see page 11)
Wok-Ready Cooktops
24” Cooktop Cabinet
K-CKTP-24
Kalamazoo weather-tight rain gutter
Includes glide-out bottom tray and utensil tray with hooks ideal for hot
pads and tools
Natural gas standard, liquid propane configuration optional
Left- or right-hinge
Toe-kicks available
Why settle for a run-of-the-mill side burner when you can have a
32,000 BTU wok-ready cooktop in your outdoor kitchen. Our ingenious
design uses four concentric rings of fire. To simmer sauces and glazes
at low temperatures, the two inner rings provide controlled heat. Turn the
burner up to high and all four rings kick in for rapid boiling or other high-
temperature work.
Kalamazoo cooktops are available for built-in installations (photo at left)
or mounted in a convenient storage cabinet.
22.00
16.13
3.50 min
5.00 max
5.43
2.07
16.00
1.68
1.44
GAS INLET
OFF
LOW
HIGH/
IGNITE
SIDEBURNER
(SELF-IGNITION)
OFF
LOW
HIGH/
IGNITE
2.25
24.00
34.75
30.00
33.12
3.25
39.00
12.00
0.93
GAS INLET OPENINGS

www.KalamazooGourmet.com 1.800.868.1699 9
Everything you need for the ultimate outdoor kitchen, including design support, is available
from Kalamazoo Outdoor Gourmet. We work with design professionals and homeowners to
plan the ideal outdoor cooking and entertaining retreat for each home.
Create a Complete Outdoor Kitchen
Call us to speak with an outdoor kitchen design expert and get started designing your outdoor dream kitchen today.
You can also download the 2008 Outdoor Kitchen Design Resource Book from www.KalamazooGourmet.com.
Weather-Tight Outdoor Base Cabinets
More than 20 cabinets are available, each with a seamless rain gutter
surrounding every door and drawer opening. The cabinets are fully-
finished on all sides in hand-rubbed stainless steel.
Stainless steel construction, including all hardware
Full-extension stainless steel drawer glides
Weather-tight design
Fully-finished on all sides
Stainless steel levelling legs
Counter support brackets available
Toe-kicks available
Countertops shown for illustrative purposes only
High-Performance Outdoor Refrigeration
Kalamazoo offers a complete line of outdoor refrigeration with more than
20 models available, including refrigerators and refrigerated drawers,
freezers and freezer drawers, wine chillers, keg tappers, beverage centers
and a clear ice maker. Variable speed compressors, advanced insulation
and forced air cooling add up to the most powerful and energy efficient
outdoor refrigeration available. Check out the chart below comparing
BTUs (a measurement of cooling power) and energy consumption among
the most popular brands:
Kalamazoo U-line
Sub-
Zero Viking Marvel GE
BTU Output 995-1985 300-
700 325 380 461 275
Energy Used
(kWh/year) 311 339 334 N/A N/A 360 48” Outdoor Keg Tapper and Glass-
Door Refrigerator and the Outdoor
Artisan Pizza Oven

Bringing Gourmet Lifestyles Outdoors Since 190610

www.KalamazooGourmet.com 1.800.868.1699 11
Kalamazoo Built-In Grill Accessories
We offer a wide assortment of unique grill accessories that help make outdoor cooking an even
better experience. What else would you expect from the pioneers who invented the hybrid grill?
Custom Cooking Surfaces Laser cut from solid slabs of stainless steel
up to 1/4” thick, Kalamazoo’s custom cooking surfaces combine patterns
specially developed for the best performance with different types of food
and styles of cooking. Create any combination of these patterns and further
customize with initials, logo or other artwork (see the photo at left). The
sheer mass of these robust surfaces helps ensure great grill marks every
time. Solid surface areas are also available for teppanyaki-style cooking.
Cooktop Griddle Specially designed and fabricated for Kalamazoo wok-
ready side burners, this heavy stainless steel griddle is perfect for fajitas
and stir-fry.
Sunbrella Grill Covers A Kalamazoo is built to withstand the elements,
but covering the grill helps it stay clean and always at the ready. And
since a Kalamazoo deserves to be covered by nothing but the best, we
make all our covers from black Sunbrella™ fabric, silk-screened with the
Kalamazoo logo.
Grilling Rubs Kalamazoo has created signature spice blends using all-
natural ingredients that take make it easy to create bold flavors on the
grill. From the earthy coffee flavors of our ZaZa Barbecue Rub to the rich
garlic and herbs of the Kalamazoo Rub, there is a perfect compliment
available for most any food. Check out all five blends at
www.KalamazooGourmet.com.
Grillmaster’s Apron Our logo apron shows you take pride in your grilling
and in your grill. This is a full-length butcher’s apron in heavy black twill
with a stain-resistant finish.
“MEAT” PATTERN “FISH” PATTERN “VEGETABLE” PATTERN
“Your neighbors will shake with fear.”
— Uncrate
