Kalor Lara 12D User manual

USER MANUAL
Lara 12D / Michela 12D
Ductable Air Stoves
Instructions for the correct use and maintenance of
your Kalor wood pellet air (dry) stove
Distribution and warranty in Ireland by:

A note from the distributor:
Congratulations and thank you for choosing a Kalor wood pellet stove. Kalor is a leading
wood pellet stove brand worldwide, offering leading combustion efficiencies and superior
reliability. You have chosen well!
Kalor stoves are distributed in Ireland by Wood Pellet Stoves.ie, through a network of
Authorised Dealers. We are a company, totally dedicated to wood pellet stoves and boilers
and our priorities are quality, not just of product but also of the installation and
maintenance.
We also support a nationwide network of Authorised Technicians who are specially trained
on Kalor wood pellet stoves and boilers. This ensures that your stove can be correctly
installed, commissioned, maintained and repaired by competent personnel and that you
receive the best possible service, all the way from purchasing your stove to the end of its
life-cycle.
Please refer to the notes on the inner back cover of this manual for further details
regarding the installation, commissioning and warranty for your stove/boiler.
We wish you all the best with your new Kalor stove/boiler and hope it serves you well for
many, many years.
Yours sincerely,
_____________________________
Fergus Mc Manamon
General Manager
Wood Pellet Stoves.ie
