KAM Moonglow DMX V2 User manual
Moonglow DMX V2
Classic spinning disco effect with DMX
Due to continuous product development, please ensure that you have downloaded
the latest instruction manual for this product from the Kam website at www.kam.co.uk
MANUAL VERSION 1.0
05-11-13
For the latest instruction manual updates and information on the entire Kam range visit:
www.kam.co.uk
Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ
Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: [email protected] • Web: www.lambaplc.com
Made in China. Due to continuous product development, specifications and appearance are subject to change. © Copyright Lamba plc 2014. E&OE.
Thank you for purchasing this Kam product, we are sure that it will serve you for many years to come.
To optimise the performance of this product, please read these operating instructions carefully to familiarise yourself with the basic
operations of this unit. Please retain them for future reference. This unit has been tested at the factory before being shipped to you.
To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture. To prevent a fire hazard, do not
expose the unit to any naked flame sources. Unplug this apparatus during lightning storms or if it is unlikely to be used for long
periods of time.
When installing the unit, please ensure you leave enough space around the unit for ventilation. Slots and openings in the unit are
provided for ventilation to ensure reliable operation of the product and to protect it from overheating. To prevent fire hazard, the
openings should never be blocked or covered.
The unit is powered by mains electricity, always handle the power cable by the plug. Never pull out the plug by pulling on the cable.
Never touch the power cable when your hands are wet as this could cause an electric shock. Do not tie a knot in the cable. The
power cable should be placed such that it is not likely to be stepped on. A damaged power cable can cause a fire or give you an
electrical shock. Check the power cord periodicaly, if you ever find that it is damaged, replace it before using the unit again. Contact
your retailer for a replacement.
The voltage of the available power supply differs according to country or region. Be sure that the power supply voltage of the area
where this unit is to be used meets the required written on the unit.
The lightning flash symbol inside a triangle is to alert the user to the presence high voltage within the unit’s enclosure that
may be of sufficient power to constitute a risk of electrical shock to persons.
Caution: to prevent the risk of electric shock, do not attempt to open the unit. No user-serviceable parts inside. Refer all
servicing to qualified service personnel.
The exclamation mark inside a triangle is intended to alert the user to the presence of important operating and
maintenance instructions in the literature accompanying the appliance.
Select the installation location of your unit carefully. Avoid placing it in direct sunlight or locations subject to vibration and excessive
dust. Do not use the unit where there are extremes in temperature (below 41ºF / 5ºC or exceeding 95ºF / 35ºC).
Unpacking and safety Please unpack your new product carefully. Your new product should reach you in perfect condition. Please
check that no damage has occurred during transit. If any damage is found, do not operate your unit. Please contact the retailer you
purchased it from immediately. If there is any damage to the mains cable do not use the device. Always disconnect the unit from the
mains supply when carrying out any cleaning of the unit.
Manufacturer declarations
In compliance with the following requirements: RoHS Directive (2002/95/EU) and WEEE Directive (2002/96/EU).
If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal.
CE declaration of conformity
R&TTE Directive (1999/5/EU), EMC Directive (2004/108/EU), Low Voltage Directive (2006/95/EU).
Before putting the devices into operation, please observe the respective country-specific regulations.
DMX512 connection / connection between multiple units
XLR-connection:
When using a DMX controller, connect the DMX output of the controller directly to the DMX input of the first unit in the DMX chain.
Building a DMX chain:
Connect the DMX output of the first unit in the DMX chain with the DMX input of the next unit. Always connect one output with the
input of the next unit until all units are connected.
Caution: on the last unit, the DMX cable has to be terminated with a terminator. Solder a 120 resistor between signal (–) and signal
(+) into a 3 pin XLR plug and plug it in the DMX output of the last unit.
Mains power connection
Connect the device to the mains with the supplied power cable.
Operation
1. DMX512 protocol
Addressing
The LED display on the side of the unit allows you to assign the DMX unit address, which is defined as the first channel from which
the unit will respond to the controller. If you set, for example, the address to channel 7, the unit will use the channel 7 to 14 for
control. Please, be sure that you don’t have any overlapping channels in order to control each unit correctly and independently from
any other unit on the DMX data link. If two, three or more units are addressed similarly, they will work similarly. In DMX mode you
can choose the address from 1 to 512. After you connect the unit to the mains, the unit starts running. When the unit finishes
resetting, the letters A-OO1 will flash in the LED display and then you can set the desired DMX address by pressing the UP or
DOWN buttons.
DMX control
After having addressed all units, you can now start operating them via your lighting controller. After switching on, each unit will
automatically detect whether DMX512 data is received or not.
DMX channels
Channel 1 On/Off
Channel 2 Red & amber from low to high brightness
Channel 3 Green & pink from low to high brightness
Channel 4 Blue & white from low to high brightness
Channel 5 Strobe from slow to fast
Channel 6 Adjust motor running speed
Channel 7 Preset shows
2. Sound-to-Light mode
Press the MENU button, until S1 or S2 shows in the LED display, confirm your choice using the ENTER button, the unit will now
respond to the beat of any music playing. The built-in microphone responds best to the bass sounds in a tune.
3. Auto mode
Press the MENU button, the following functions can be achieved using the button ENTER:
A1 Red & amber colour
A2 Green & pink colour
A3 Blue & white colour
A4 Colour changing pattern 1
A5 Colour changing pattern 2
A6 Increasing brightness / then decreasing brightness
A7 Strobe
4. Synchronization & Master/Slave mode
Take one unit and set it to Sound-to-Light mode, or Auto mode as described above, then get other units and press the MENU button
until A001 shows in the LED display, confirm using the ENTER button, then connect the units to the Auto/Sound-to-Light unit already
set using DMX cables. Disconnect all units from the DMX controller, the units will now work simultaneously, the Auto/Sound-to-Light
unit will act as the Master, the others will act as slave units.
Technical specifications
Power supply AC 220-240V / 50/60Hz
Power consumption Max. 20w
Fuse 250V 1.0A
DMX control channels 10
DMX512 connection 3 pin XLR
Number of LEDs6 x high MCD 1W LEDs, red / green / blue / white / amber / pink
Flash-rate Max. 30Hz
Dimensions 160 x 160 x 170mm
