KAM SF Series User manual

Kam SF speaker series
Full range active PA speakers
Due to continuous product development, please ensure that you have downloaded
the latest instruction manual for this product from the Kam website at www.kam.co.uk
MANUAL VERSION 1.0
07.08.15
For the latest instruction manual updates and information on the entire Kam range visit:
www.kam.co.uk
Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ
Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: [e-mail] • Web: www.lambaplc.com
Made in China. Due to continuous product development, specifications and appearance are subject to change. © Copyright Lamba plc. E&OE.

Thank you for purchasing this Kam product, we are sure that it will serve you for many years to come.
To optimise its performance, please read these operating instructions carefully to familiarise yourself with the basic operations of this
unit. Please retain them for future reference. This unit has been tested at the factory before being shipped to you.
To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture. To prevent a fire hazard, do not
expose the unit to any naked flame sources. Unplug this apparatus during lightning storms or if it is unlikely to be used for long
periods of time. When installing the unit, please ensure you leave enough space around the unit for ventilation. Slots and openings in
the unit are provided for ventilation to ensure reliable operation of the product and to protect it from overheating. To prevent fire
hazard, the openings should never be blocked or covered.
The unit is powered by mains electricity, always handle the power cable by the plug. Never pull out the plug by pulling on the cable.
Never touch the power cable when your hands are wet as this could cause an electric shock. Do not tie a knot in the cable. The
power cable should be placed such that it is not likely to be stepped on. A damaged power cable can cause a fire or give you an
electrical shock. Check the power cord periodicaly, if you ever find that it is damaged, replace it before using the unit again. Contact
your retailer for a replacement. The voltage of the available power supply differs according to country or region. Be sure that the
power supply voltage of the area where this unit is to be used meets the required written on the unit.
The lightning flash symbol inside a triangle is to alert the user to the presence high voltage within the unit’s enclosure that
may be of sufficient power to constitute a risk of electrical shock to persons. Caution: to prevent the risk of electric shock,
do not attempt to open the unit. No user-serviceable parts inside. Refer all servicing to qualified service personnel. The
exclamation mark inside a triangle is intended to alert the user to the presence of important operating and maintenance
instructions in the literature accompanying the unit.
Select the installation location of your unit carefully. Avoid placing it in direct sunlight or locations subject to vibration and excessive
dust. Do not use the unit where there are extremes in temperature (below 41ºF / 5ºC or exceeding 95ºF / 35ºC).
Unpacking and safety Please unpack your new product carefully. Your new product should reach you in perfect condition. Please
check that no damage has occurred during transit. If any damage is found, do not operate your unit. Please contact the retailer you
purchased it from immediately. If there is any damage to the mains cable do not use the device. Always disconnect the unit from the
mains supply when carrying out any cleaning of the unit.
Manufacturer declarations
In compliance with the following requirements: RoHS Directive (2002/95/EU) and WEEE Directive (2002/96/EU).
If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal.
CE declaration of conformity
R&TTE Directive (1999/5/EU), EMC Directive (2004/108/EU), Low Voltage Directive (2006/95/EU).
The declarations are available on application from certificati[email protected]
Before putting the devices into operation, please observe the respective country-specific regulations.

Kam SF series speaker rear panel controls
1. Mic level: volume control of microphone input (10 & 11)
2. Line level: volume control of line input (9)
3. Master: volume control of speaker output
4. EQ bass: bass frequency equalisation
5. Clip LED: lights when the speaker is overloaded
6. Power LED: lights when the unit is powered on
7. EQ treble: treble frequency equalisation
8. AUX in: auxiliary audio input connection
9. Line in: stereo audio line input connection
10. Mic in: 6.35mm jack audio input for microphone
11. Mic in: XLR audio input for microphone
12. Line in: XLR audio line input connection
13. Line out/link: line level speaker output
14. Power in: IEC mains power input (AC 115-240V)
15. Power: mains power switch to turn speaker on or off

Features and specifications
Kam SF12A
Low frequency driver 12 inch / 60oz 4ohm
High frequency driver 1.75 inch Ti. Diap. 8ohm
Impedance 4ohm
Frequency response 40Hz-18KHz
Max calculated SPL 102db
Sensitivity 96db ±3db
RMS power 400W+100W
Frequency range (-10dB) (-10dB) 40Hz-18KHz
Hi pass frequency 3.5KHz-18KHz
LF transducer Class D
HF transducer Class A/B
AC input 115V~240V
Coverage Horizontal: 45° / Vertical: 40°
Audio inputs 1.2V
Audio outputs Low: 34V/4Ω/ Hi: 13V/4Ω
Pole mountYes
Dimensions (WxDxH) 306 x 388 x 594mm
Net weight 12.8Kg
Kam SF15A
Low frequency driver 15 inch / 60oz 4ohm
High frequency driver 1.75 inch Ti. Diap. 8ohm
Impedance 4ohm
Frequency response 40Hz-18KHz
Max calculated SPL 110db
Sensitivity 105db ±3db
RMS power 400W+100W
Frequency range (-10dB) 40Hz-18KHz
Hi pass frequency 2.5KHz-18KHz
LF transducer Class D
HF transducer Class A/B
AC input 115V~240V
Coverage Horizontal: 60° / Vertical: 50°
Audio inputs 1.2V
Audio outputs Low: 34V/4Ω/ Hi: 13V/4Ω
Pole mount Yes
Dimensions (WxDxH) 347 x 450 x 692mm
Net weight 17Kg
Due to continuous product development, specifications and appearance are subject to change. © Copyright Lamba plc. E&OE.
