Kambrook RF3399 User manual

After Sales Support Web: www.winplus.com.auAfter Sales Support Web: www.winplus.com.au
Power Point Controller
Instruction Manual
Model Number RF3399
N14410 Meets Australian standard AS/NZS 3197 - 2005
Approval number: SGSEA/90387
On
Indicator
RF3399
Power Point
Controller
max load: 2400W
WARNIING!
Total load not exceed
maximum rating of device
Build an Automated living system with these additional items.
Kambrook Power Point Controller / Kambrook Power Point Controller Kit.
Expand on your automated living options by adding additional Power Point
Controllers. Four individual Power Point Controllers or four groups of Power Point
Controllers can be used per Compact Remote Control.
Kambrook Compact Remote Control.
Expand on your automated living options by adding additional Compact Remote
Controls. Each additional Compact Remote Control increases the total number of
Power Point Controllers that can be operated individually in your system.
Note: A Power Point Controller may only be paired to one individual Compact Remote
Control, not multiple Compact Remote Controls.
Kambrook Outdoor Power Point Controller.
Control your outdoor appliances as well as indoor with the Outdoor Power Point
Controller using your existing Compact Remote Control.
Technical Information.
Working Voltage: 230 - 240V~/50Hz Max. Load power: 10A or 2400W
Warranty
The product is guaranteed to be fit for purpose and free from defects for a period of 12 months from the date
of purchase. Defects that occur within this warranty period will be repaired or replaced under Australian
consumer law. Proof of Purchase - This warranty is valid for the original purchase only and is not
transferable. Please keep your purchase docket or receipt as proof of purchase and as proof of the date on
which the purchase was made. The purchase docket or receipt must be presented with the product when
making a claim under this warranty. Service during the warranty period - If being returned, please
ensure the product is properly packaged so as to ensure thatno damage occurs to theproduct during transit.
Also make sure that you have included an explanation of the fault. The consumer is responsible for costs to
return the product when claiming warranty. Extent of Warranty - This warranty does not cover manuals,
packaging, filters, bags, seals or other accessories. This warranty does not cover batteries or any other
consumable item. Warranty Procedure - Return the faulty product with proof of purchase to the original
place of purchase or contact Winplus Australia via www.winplus.com.au. Normal Wear and Tear - This
warranty does not cover normal wear and tear of the product or parts. Exclusions - This warranty does not
cover: - Any defect caused by lack of reasonable care, unauthorised modification or attempted repair by an
unauthorisedperson. - Any product that has not been installed, operated or maintained in accordance with
the instructions provided with the product. - Any product that has been used for purposes other than
domesticuse. - If theproductislocatedoutsideAustraliaorNewZealand.
For further support on thisproduct please visit www.winplus.com.au or contact us during businesshours on
1300663 907.

After Sales Support Web: www.winplus.com.au After Sales Support Web: www.winplus.com.au
Power Point Controller - Kambrook
Welcome - Thank you for choosing this Kambrook Automated Living product.
All Kambrook Automated Living products are manufactured to the highest standards of
performance and safety, and, as part of our philosophy of customer service and
satisfaction, are backed by our comprehensive 1 Year Warranty. We hope you will enjoy
your purchase for many years to come.
General Information and Safety Instructions
Please read this manual and safety information carefully and follow all instructions.
Internal manipulation, modification or attempt to open this product will void all
warranties and is deemed unsafe.
Please note that the RF3399 Power Point Controller is for indoor use only and is
not suitable for outdoor use. For outdoor use please use the RF3405 Outdoor
Power Point Controller.
Warning:
Not for outdoor use.
Do not exceed maximum power rating 10A or 2400W.
Children and infirm persons should use this device only under the
supervision of a responsible adult to ensure that they can use this device to
control appliances safely.
Young children should be supervised to ensure that they do not play with this
device.
Parts List
1 x Power Point Controller. 1 x Instruction Manual.
Features
Low energy consumption - Less than 1W power consumption when in standby
state.
Safety - If a power failure occurs, the Power Point Controller automatically switches
to the off position to ensure a safe environment and reduce power wastage.
Manual control or remote control - Power Point Controllers have a manual ON
switch so devices can be controlled manually as well as by the Compact Remote
Control.
No interference - Each Power Point Controller button has its own code set, which
means no interference and stable performance.
Use with other Kambrook Automated living products to increase
features
Individual control - The Compact Remote Control (sold separately) can control up
to 4 individual Power Point Controllers using its 4 numbered buttons.
Group control - The Compact Remote Control (sold separately) can control up to 10
Power Point Controllers as a group per numbered button. Each Power Point Controller
assigned to a group can only be operated by the Compact Remote Control as a
group. All on or all off.
Room to room control - The Compact Remote Control (sold separately) works
through walls and ceilings.
Instructions
How to program a Kambrook Compact Remote Control (sold separately) to the Kambrook
Automated Living Power Point Controller.
1. Unplug the device you wish to control with the Power Point Controller from the power
point.
2. Ensure that the power point is switched on.
3. Plug in the Power Point Controller.
4. Plug the device you wish to control into the front of the Power Point Controller.
5. Ensure the device is switched to on (if applicable).
6. Pair the Power Point Controller with the Compact Remote Control.
a. Press and hold the manual ON button on the Power Point Controller for 5 seconds,
the blue LED light marked “Indicator” on the Power Point Controller will begin to
flash.
b. Release the On button. Select the desired numbered button on the Compact Remote
Control (sold separately) that you wish to assign to this particular Power Point
Controller to.
c. The LED indicator light on the Power Point Controller will then stop flashing,
indicating that the Power Point Controller has been paired successfully with the
Compact Remote Control. You can then control the Power Point Controller by pressing
the corresponding numbered button to switch on or off any device or appliance
plugged to this Power Point Controller.
