Kärcher T 15/1 eco!efficiency User manual

English 5.906-447.0 Rev. 00 (03/08) 1
T 15/1
Service Manual

2 English 5.906-447.0 Rev. 00 (03/08)
Contents
1 Preface 3
2 Safety instructions 3
3 Technical Features 3
4 Setup and function 4
5 Basic settings and service procedures 5
6 Troubleshooting 7
7 Technical specifications 7
8 Special tools 7
9 Circuit diagram 8

English 5.906-447.0 Rev. 00 (03/08) 3
Good service work requires extensive and practice-oriented train-
ing as well as well-structured training materials.
Hence we offer regular basic and advanced training programmes
covering the entire product range for all service engineers.
In addition to this, we also prepare service manuals for important
appliances - these can be initially used as instruction guides and
later on as reference guides.
Apart from this, we also regular information about product en-
hancements and their servicing.
If you should require supplements, have corrections or questions
regarding this document, please address these citing the following
subject to:
[email protected]
The responsible product specialist will take care of your issue.
Copying and duplication of texts and diagrams as well as
third-party access to this information is permitted only with
the explicit permission of the company:
Alfred Kärcher GmbH & Co. KG
P O Box 160
D - 71349 Winnenden
www.kaercher.com
Danger
Immediate danger that can cause severe injury or even death.
몇Warning
Possible hazardous situation that could lead to severe injury or
even death.
Caution
Possible hazardous situation that could lead to mild injury to per-
sons or damage to property.
Structure:
– Cable storage on the appliance or on the foldable cable hook.
– Pickup for floor nozzle.
– Storage for accessories.
– In addition to the main filter, a filter bag may be used.
– Installation of HEPA filter H12 prepared (option).
– The appliance switch can be activated by foot.
1 Preface
Subject: Fall 106039
2 Safety instructions
2.1 Hazard levels
3 Technical Features

4 English 5.906-447.0 Rev. 00 (03/08)
1 Suction hose
2 Suction head
3 Fastening screw of the suction head
4 Mains cable hook (foldable)
5 Carrying handle
6Powercord
7 Hose switch
8Locking
9 Impeller
10 Steering roller
11 Dirt receptacle
12 Turbine casing
13 Floor nozzle
14 Suction support
15 Socket
16 Power switch
17 Pickup for floor nozzle
18 Suction pipe
19 Accessories
20 Exhaust filter
21 Mains plug
22 Bender
4 Setup and function

English 5.906-447.0 Rev. 00 (03/08) 5
1 Impeller with plugin axle
2 Fastening screw
ÎLoosen the fastening screw.
ÎPull impeller with plugin axle out to the side.
ÎInstall the new impeller by reversing the installation steps.
1Seal
2 Motor filter
3 Grid of the motor proction filter
ÎPush the grids of the motor protection filter down, turn and re-
move.
ÎRemove the motor protection filter.
ÎInsert the new motor protection filter.
ÎInsert the grid of the motor protection filter and lock it into place.
1 Power cord
2 Fastening screw for mains cable
3 Fastening screw for turbine housing
4 Cable guide
5 Clamping ridge for mains cable
6Spring
7 Power switch
8 Fastening screw for bow
9Bow
10 Turbine casing
ÎRemove spring.
ÎUnscrew the fastening screws for the mains cable.
ÎUnscrew the fastening screws for the bow.
ÎRemove the bow.
1 Opening at suction head
2 Power cord
3 Power switch
4 Capacitor
ÎPull the appliance switch out toward the top.
ÎReplace the mains cable.
Note: Prior to installing the new mains cable, it must be pulled off
through the opening on the suction head.
Note: Wheninstalling themains cable,therouting mustbe correct.
There are cable guides in the turbine housing, along which the ca-
ble must be routed. The cable must be pressed into the clamping
ridge to attach it.
5 Basic settings and service procedures
5.1 Replacing the impeller
5.2 Replace motor protection filter
5.3 Replacing the mains cable

6 English 5.906-447.0 Rev. 00 (03/08)
1 Power switch
2 Cable plug
3 Socket
4 Capacitor
ÎRemove the plugin using a small screwdriver.
ÎPull the plugin out of the shaft and disconnect the cable plug.
1 Bypass filter for engine cooling air
2 Exhaust filter
3 Housing for exhaust filter
4 Nameplate
1 Sound proofing
2 Upper turbine bearing
3 Sound proofing
4 Fastening clips for sound proofing (4 x)
5Powerswitch
Note: The marking arrows (see circles) show the correct installa-
tion position of the upper turbine bearing.
1 Connection plug of the turbine
2 Turbine
3 Upper turbine bearing
ÎRemove the upper turbine bearing from the turbine.
ÎPull the connection plug off the turbine.
ÎReplace the turbine.
Note: When inserting the new turbine, the installation position
must be observed. The turbine must be installed so that the upper
turbine bearing is placed according to the marking arrows (see cir-
cles).
5.4 Remove plugin
5.5 Exhaust filter and bypass filter
5.6 Replace the turbine

English 5.906-447.0 Rev. 00 (03/08) 7
The technical specification sheet and the circuit diagram will be in-
cluded in the next version of the spare parts CD (DISIS) and in the
Intranet.
– Technical specification sheet:
Folder "Central / Service Info Int'l / Technical Specifications"
– Circuit diagram:
Folder "Central / Service Info Int'l / Circuit Diagram"
The operating instructions and the spare parts list can be request-
ed in paper form with the respective part numbers from our spare
parts service department.
Torques:
No data.
There are no special tools necessary.
6 Troubleshooting
Fault Remedy
Motor does not run – Check cables, plugs and socket.
– Check appliance switch (continuity test), replace if required.
– Allow appliance to cool down, the engine protective switch has been triggered due to overheat-
ing.
Suction capacity decreases – Check the suction nozzle, the suction pipe and the suction hose for obstructions, clear if nec-
essary.
– Filter bag/main filter defective/obstructed - replace.
– Close the suction head properly.
Dust comes out during the vacu-
uming Check/correct the correct positioning of the filter bag/main filter.
7 Technical specifications
Appliance type Appliance no.: Circuit diagram Operating in-
structions Spare parts list
T 15/1 EU, 220-240 V, 1~ 50/60 Hz 1.355-201.0 0.088-685.0 5.962-578.0 5.970-840.0
T 15/1 CH, 220-240 V, 1~ 50/60 Hz 1.355-202.0 0.088-685.0 5.962-578.0 5.970-840.0
T 15/1 AU, 220-240 V, 1~ 50/60 Hz 1.355-203.0 0.088-685.0 5.962-578.0 5.970-840.0
T 15/1 GB, 220-240 V, 1~ 50/60 Hz 1.355-204.0 0.088-685.0 5.962-578.0 5.970-840.0
T 15/1 BR, 220-240 V, 1~ 50/60 Hz 1.355-207.0 0.088-685.0 5.962-578.0 5.970-840.0
T 15/1 JP, 100 V, 1~ 50/60 Hz 1.355-206.0 0.088-685.0 5.962-894.0 5.970-941.0
T 15/1 CUL, 120 V, 1~ 60 Hz 1.355-205.0 0.088-685.0 5.962-893.0 5.970-940.0
8 Special tools

8 English 5.906-447.0 Rev. 00 (03/08)
9 Circuit diagram
