Karel MS26S User manual

MS
26 S
MS
26 S
11/2003
USER'S GUIDE
TELEPHONE EXCHANGE

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
MS26S KK - REVAAA 21/11/2003
KAREL may modify the content of this guide because of any improvement or addition
without any notice. The products may have some differences from the functionality
written in this guide according to the hardware revision or software version.
II

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
CONTENTS
SYSTEM FEATURES:..............................................................................................................1
DEFINITION:............................................................................................1
STRUCTURE OF THE SYSTEMS:........................................................................................1
DIAL TONES AND HOOK FLASH:.......................................................................................2
DEFINITIONS:..................................................................................................................3
SERVICE EXPLANATIONS:...................................................................................................3
ABBREVIATIONS:.................................................................................................................3
SERVICES RELATED TO THE USERS:..........................................................................4
CALL INITIATION SERVICES:..............................................................................................5
Internal Call:....................................................................................................................5
Calling Operator:.............................................................................................................5
Line Call (9):........................................................................................................................6
Selective Line Access(7):.................................................................................................7
Last Number Redial (70):.................................................................................................7
Last Number Auto-Dial (770):.........................................................................................8
Private Pool Entry (84):....................................................................................................9
Calling From Private Pool (6):........................................................................................9
Calling From Common Pool (5):.................................................................................10
Doorphone Call:.............................................................................................................10
Conference:........................................................................................................11
CALL ANSWERING SERVICES:........................................................................................12
Answering An Incoming Call:.....................................................................................12
Selective Call Pick Up (82):..........................................................................................12
OTHER SERVICES RELATED TO CALLS:........................................................................13
Call Hold:........................................................................................................................13
Call Transfer:.................................................................................................................13
Line Call Park (#4):.........................................................................................................15
Retrieving A Call Parked Through Ones Own Phone (4):............................................15
Retrieving A Parked Line (4):......................................................................................16
Line - Line Connection (#6):..........................................................................................16
Call Back (8):...................................................................................................................17
Intrusion (0):....................................................................................................................17
III IV
: Authorized Ext.; : Programming required; : Operator Only; : Extra Hardware required
PREFACE
This guide covers all the facilities presented by MS26S Telephone System to you.
All the features in this guide can be used easily through any telephone set. Additionally,
if you have a Karel Feature Phone (LT26S or LT26S-H), can reach the user features just
by one key touch.
We recommend you to read this guide thoroughly in order to be familiar all the features
of your PABX.
We hope you will enjoy using your PABX,
Karel Electronics

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
CALL FORWARDING SERVICES:..................................................................................18
Follow Me (85):..............................................................................................................18
PASSWORD SERVICES:................................................................................................19
Password Define (836):.................................................................................................19
Changing Password (836):.................................................................................................19
Telephone Lock (837):...................................................................................................20
OTHER USER SERVICES:................................................................................................21
Do Not Disturb (831):.....................................................................................................21
Reminder Service (838):...................................................................................................22
Listening to Music (857):...................................................................................................23
Door Opener (23):...........................................................................................................23
SERVICES RELATED TO THE OPERATOR:........................................................................24
Date Setting (833):............................................................................................................24
Time Setting (88):...........................................................................................................24
Common Pool Entry (834):.............................................................................................24
Group Call Park (#4):.....................................................................................................25
Music On Hold (832):......................................................................................................25
Putting Lines Into Service Automatically (827) :..........................................................26
Night Mode (879):..........................................................................................................27
Line Forwarding (795):...................................................................................................28
Re-Loading The System Parameters (824):...............................................................29
SERVICES RELATED TO REPORTING:...................................................................................30
Call Record Listing (8767):..............................................................................................30
Common Pool Listing (8764):........................................................................................30
Time and Date Information Listing (8765):...............................................................31
KY16 Page Feed (8763):...................................................................................................31
KY16 Line Feed (8762):.................................................................................................31
KY16 On Line (8761):....................................................................................................31
KY16 Off Line (8760):......................................................................................................32
SAMPLES TO REPORTS TAKEN:........................................................................................33
Call record listing sample:..............................................................................................33
Common Pool sample:..................................................................................................34
Time and Date Listing:...................................................................................................34
V1
SYSTEM FEATURES
DEFINITION
The MS26S exchange has been designed so as to meet customer demands for small-
scale exchanges, thanks to its flexible structure, software and hardware features.
Structure of the Systems:
The MS26S electronic telephone branch exchange consists of backplane, EPROM, cabi-
net and power adaptor. Its capacity is:
• 2 lines and 6 extensions.
MS26S has been designed to be used with any kind of standard telephone set, as well
as the ones that have been specially produced to be used with it. The KAREL feature
telephone sets (such as LT26S, LT26S-H), which provide ease of use and easy access
to several features for the MS26S exchange, have been developed. The extensions
who use KAREL feature telephone sets can perform operations which could not be
done by standard telephones, as well as they can access several exchange features
through single key. Such features have been explained in the guide of the related feature
telephone set.
Moreover, it is possible to connect to your MS26S telephone exchange peripheral units
such as answering machine, wireless telephone, fax, data terminal and modem. Call
your authorized reseller for more information related to the issue.
: Authorized Ext.; : Programming required; : Operator Only; : Extra Hardware required

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
Definitions:
Extension (Internal line): :
Owner of each telephone that has been connected to the exchange.
Extension number (Internal line number):
The inner-exchange phone number that should be dialed in order to call another phone
that has been connected to the exchange. The extension numbers are in the range 11-16.
Operator:
Owner of the first telephone that is connected to the exchange. The operator (the
extension with number 11) can perform some special operations, in addition to the entire
operations that can be done by other extensions.
External number:
The number to be dialed upon access to the lines of the exchange when external calls
are to be made, which has been taken from the local telephone operator.
Line number:
When one attempts to make an external call, it is the number of a line of exchange to be
dialed, if one wishes to select one of the lines. Line numbers are 1 and 2.
Service Explanations:
Within this guide, the services are both described by symbolic pictures and the things to
be done have been explained in text, item by item. As can be seen, the last item of some
services has been given as “Hear the internal dial tone.” At that point, the extension that
receives the internal dial tone can either hang up or can start to use another service.
In case one of the items listed in the explanations is skipped or incomplete, the service
may not work as desired. If the service is not working as desired, even though the entire
items have been executed one by one, then source of the problem may be searched in
the notes section in explanations. Apply your authorized reseller, if the solution is not in
the notes section.
Moreover, for the services that ends with the statement “g Replace the handset.”, if the
extension has the authorization to use the key “*” (Apply to your system supervisor for
that authorization.), then s/he can carry out the same operation by pressing the key “*”,
instead of replacing the handset. Besides, the extension will directly receive internal dial
tone and will be able to make use of any other service s/he wishes.
Abbreviations:
: Service that can be used with authority level.
: Service that requires specific programming.
: Operator only service.
: Service that requires special hardware.
Dial Tones and Hook Flash:
Information about the tones systems have and their structures are as follows.
Internal dial tone:
It is the tone received when the extension lifts the handset. This tone indicates that a
number can be dialed for any action. The tone is discontinuous by default, but it can be
made continuous through programming.
Ring back tone:
The ring back tone is different for internal and external calls.
For internal calls, it is the tone received when an extension calls another extension and
the called extension is not busy at the moment. It is in the form of 2 short ringing.
On the other hand, for external calls, the ring back tone transmitted by the CO is received.
Busy tone:
The busy tone, which is in the form of short ringing, is the one that shows the called
extension is busy, or if an extension attempts to access a line, then it is the tone which
shows that line or lines are busy at the moment.
Special dial tone :
The special dial tone is a tone that is short, periodic and lower compared to the dial tone
and it indicates that the extension is keeping an extension or line on hold at the moment.
In order to receive special dial tone, one should make hook flash while conversing with
an extension or a line. The extension who receives that tone can resume conversation by
making hook flash again or s/he can make use of features, such as getting information,
which can be used upon receiving the special dial tone. Following the action taken
after the special dial tone has been received, the extension can resume the previous
conversation by making hook flash.
Error tone :
This tone is in the form of three short tones and a long tone and it should not be confused with
the busy tone. This tone indicates that an erroneous action has been taken by the extension.
C.O. dial tone:
It is the tone received upon access to C.O. line. A line number can be dialed upon
receiving this tone.
Hook Flash operation:
It is used for putting a line, over which a conversation is going on, on hold. It is a
quite frequent action taken during use of the exchange. In order to make hook flash,
you should press the on/off latch of your phone for 100-600 milliseconds (this can be
changed through programming.) and then release it. The keys “Flash” or “R” on some
phones can be employed for hook flash operation. Besides, some extensions with tone
dialing phones can be given the authorization to employ the key “#” on their telephones
for hook flash, through programming. These extensions can also carry out hook flash
action by pressing the key “#” of their telephones.
23

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
4
SERVICES RELATED TO THE USERS
The entire user services of the MS26S exchange have been explained in this guide in
detail in order to meet the user needs in the highest level possible.
In this chapter, the features related to use of your MS26S system have been explained.
Read this chapter surely in order to use your exchange effectively.
The features below are the ones that can be used by an extension with any standard
telephone set.
As can be seen in the later sections of the guide, several features have been presented
in order to provide the users with ease in meeting their communication needs. Most of
these features can be employed by dialing their corresponding codes by phone. However,
Karel feature telephone sets (LT26S, LT26S-H) have been developed to access these
features much more easily. Extensions who use Karel feature telephone sets can access
most of these features by a single key or by the menu messages.
CALL INITIATION SERVICES
Internal Call:
In order to make a phone call with an extension:
H Lift the handset and hear the internal dial tone.
B Dial the number of the extension you want to converse with.
F Hear the ring back tone.
E Make your conversation when the extension you have called picks up the phone.
G Terminate the conversation when it is over by replacing the handset.
Notes:
• In the “Hear the ring back tone.” step, if you receive busy tone, then when you wait
without hanging up, you will begin to receive ring back tone as soon as the busyness
of the extension you have called is over and you will be able to make the conversation
when the other party picks up the phone.
• In the “Hear the ring back tone.” step, if you receive busy tone, then you can make use
of the call back service by dialing 8 before hanging up. When the busyness of the other
extension is over and hangs up, your phone will start to ring and when you pick up the
phone, the telephone of the other extension will start to ring. The conversation will
take place when the other extension picks up the phone.
• If the extension does not answer while you receive the ring back tone, then you can
make use of the call back service by dialing 8 before hanging up. In that case, when
the other extension lifts and replaces the handset for some reason, your phone will
ring, and when you pick up the phone, the telephone of the opposite extension will
start to ring. The conversation will take place when the other extension picks up the phone.
• While receiving the busy or ring back tone, if you want to call another extension,
then you can simply dial the other extension’s number without hanging up.
Calling Operator:
In order to make a phone call with the Operator:
H Lift the handset and hear the internal dial tone.
0 Dial 0.
F Hear the ring back tone.
E Make your conversation when the operator picks up the phone.
G Terminate the conversation when it is over by replacing the handset.
Notes:
• In the “Hear the ring back tone.” step, if you receive busy tone, then when you wait
without hanging up, you will begin to receive ring back tone as soon as the busyness
of the extension you have called is over and you will be able to make the conversation
5
0

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
6
when the other party picks up the phone.
• In the “Hear the ring back tone.” step, if you receive busy tone, then you can make use
of the call back service by dialing 8 before hanging up. When the busyness of the other
extension is over and hangs up, your phone will start to ring and when you pick up the
phone, the telephone of the other extension will start to ring. The conversation will
take place when the other extension picks up the phone.
Line Call (9):
When you use this feature of your exchange, the first vacant line, starting from line 2,
will be connected to you. By accessing a vacant line by this way, you can call the external
number you want.
In order to make a line call:
H Lift the handset and hear the internal dial tone.
9 Dial 9.
F Hear the line dial tone.
B Dial the external number you want to converse with.
E Make the conversation when the opposite party picks up the phone.
G Terminate the conversation when it is over by replacing the handset.
Notes:
• In the “Hear the line dial tone.” step, if you receive busy tone, then you can make use
of the call back service by dialing 8 before hanging up.
9
Selective Line Access:
If you want to dial an external number over a specific line you will select, instead of any
line, then you can make use of this feature.
In order to make an external call over a specific line:
H Lift the handset and hear the internal dial tone.
7B Dial 7, then the number of the line you would like to access.
F Hear the line dial tone.
B Dial the external number you want to converse with.
E Make the conversation when the opposite telephone is picked up.
G Terminate the conversation when it is over by replacing the handset.
Notes:
• If you receive busy tone, then you can wait for that line to be vacant without hanging
up, or again, without hanging up, you can make use of the call back service by dialing
8. Moreover, when you wait without hanging up, the line will be connected to you as
soon as it becomes vacant.
• If you receive error tone, then either the line you try to access is out of service, or
you do not have the authorization to access that line.
Last Number Redial:
In order to call the external number you have most recently called:
H When you receive busy tone upon a line call, replace and then lift the
handset and hear the internal dial tone.
70 Dial 70.
C Wait for the exchange to call the number you have dialed.
E Make the conversation.
7
7
70

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
Last Number Auto-Dial:
Auto-dial service is a feature that makes the exchange automatically call the most
recent number you have dialed in a consecutive manner and connect to you in case the
number starts to ring.
In order to employ the auto-dialer for the most recent number you have dialed:
H Lift the handset and hear the internal dial tone.
770 Dial 770.
G Replace the handset.
C Wait for the auto-dialer to connect the number you have dialed when
it is available.
D Your phone will ring when connection is established.
H Lift the handset.
E Make the conversation.
To cancel:
H Lift the handset and hear the internal dial tone.
77 Dial 77.
G Replace the handset.
Notes:
• How many times the auto-dialer will call the number is determined by the local
telecommunication authorities (It is 15 by factory default.)
• If your phone is busy during the connection, you are warned by short beeps
through ear. In such a case you should either terminate your conversation as
soon as possible or put the line your conversing over on hold and answer the line
connected by the auto-dialer.
8
770 Private Pool Entry :
There are 24 memory locations for each extension in your exchange.
In order to store numbers into the Private Pool:
H Lift the handset and hear the internal dial tone.
84 Dial 84.
B Dial the memory number (00-23).
B Dial the external number.
G Replace the handset.
Notes:
• Example: It will be sufficient to dial “84072670240” in order to store the number
2670240 into the private pool memory location 07.
• If the phone is MF or LT26S feature telephone set, then the key “#” can be
employed to form a delay time of one second among digits. Each time the key “#”
is pressed, the delay time is actualized. For delay periods of longer than one second,
it is necessary to press that key as many times as required.
Example: When “84120###3122670240” is dialed, the number “0 312 2670240” is
stored into the memory location 12. When one wishes to make a call through that
memory location, the exchange dials the other numbers three seconds after it dials 0.
Calling From Private Pool :
You can call the external numbers you have stored in the private pool of your exchange
by a short code.
In order to make a call through the private pool:
H Lift the handset and hear the internal dial tone.
6 Dial 6.
B Dial the memory number you want to call (00-23).
C Wait for the exchange to call the number you have dialed.
E Make the conversation.
84
6
9

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
Calling From Common Pool :
There are 100 common pool memory locations in your exchange, which are open to use
of the entire authorized extensions. You can make calls by having the operator store the
numbers you frequently call into these memory locations.
In order to make calls through the common pool:
H Lift the handset and hear the internal dial tone.
5 Dial 5.
B Dial the memory number you want to call (00-99)
C Wait for the exchange to call the number you have dialed.
E Make the conversation.
Notes:
• How to enter numbers to the Common Pool has been explained in the Chapter
“Services Related to the Operator”.
Doorphone Call:
In order to converse over the doorphone that is connected to the exchange:
H Lift the handset and hear the internal dial tone.
10 Dial 10.
E Make the conversation.
Notes:
• If you receive busy tone, then this indicates that another extension is making
conversation over the doorphone.
5
10
10
11
Conference:
If you wish to include another extension or line while already making conversation with
an extension or a line, then you can make use of this feature.
In order to include one more extension in the conversation:
# Make hook flash.
F Hear the special dial tone.
B Dial the number of the extension you want to include in the conference.
E Tell the extension you call that you will admit her/him into the conference.
3 Dial 3 and carry out the conference.
The entire extensions can be included in the conference by this method.
In order to include another line in the conversation while conversing over a line:
# Make hook flash.
F Hear the special dial tone.
4 Dial 4, put the current line you are conversing over on hold.
9
7B Dial 9 or dial 7 and then the external line number.
B Dial the external number you want to include in the conference.
E Tell the extension you call that you will admit her/him into the conference.
#9 Make hook flash and dial 9.
E Carry out the conference.
It is sufficient to hang up to terminate the conference.
Notes:
• If the number you call is busy or not answering, then you can return to the first line
by making hook flash.

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
12
82
CALL ANSWERING SERVICES
Answering An Incoming Call:
In order to answer a call coming to your telephone:
D In case a call request is received, your phone rings.
H Lift the handset.
E Make the conversation.
Selective Call Pick Up:
In order to answer a call that rings at another extension:
H Lift the handset and hear the internal dial tone.
82 Dial 82.
B Dial the number of the telephone that rings.
E Make the conversation.
Notes:
• If you receive error tone, than this indicates that there is no line ringing at the
extension whose number you have dialed.
13
OTHER SERVICES RELATED TO CALLS
Call Hold:
During a conversation with an extension or line, Call Hold is employed for putting that
extension or line on hold. There are several actions that can be taken while an extension
or line is on hold and Call Hold is a preliminary step prior to those actions. If the
telephone is hung up during call hold, then the line is dropped.
In order to put the call on hold:
# Make hook flash.
F Hear the special dial tone.
In order to retrieve the call on hold:
# Make hook flash.
E Go on with the conversation.
Notes:
Operations that can be done during call hold:
• Call Transfer,
• Call Park,
• Making Hook Flash To Lines,
• Connecting Two Lines Together,
• Conference.
Call Transfer:
During a conversation with a line or extension, you can transfer that line to another
extension by calling her/him or you can return to the previous conversation after
receiving information from that extension.
In order to transfer the call by informing the extension:
# Make hook flash.
F Hear the special dial tone.
B Call the extension to whom you want to transfer the call.
E Tell that you will transfer the call.
G Replace the handset to transfer.

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
14
In order to transfer the call without informing the extension:
# Make hook flash.
F Hear the special dial tone.
B Call the extension to whom you want to transfer the call.
F Hear the ring back or busy tone.
G Replace the handset to transfer.
Notes:
• In case the extension you call is busy or not answering, you can return to the line
you have previously been conversing with by making hook flash, you can make hook
flash twice and call another extension by dialing her/his number, or you can transfer
the line to the extension who is busy or not answering, by replacing the handset.
• If the transferred line is not answered within 40 seconds it returns to the
extension that has done the transfer operation. The extension to whom a line has
been transferred will be warned through ear by short beeps. In such a case the
extension should terminate the conversation as soon as possible or s/he should
answer the transferred line after parking the current line s/he is conversing with.
After starting to converse with the extension you have called for getting information
or for transferring, if you decide not to transfer, then you are supposed to make hook
flash in order to return to the line you have previously been conversing with.
• If you perform any erroneous operation and hang up during the transfer operation,
then the line is parked and returns to you; on the other hand, if it is an extension,
then it is dropped.
Line Call Park :
The telephone may be used for other purposes after a line call is parked. (Such as
answering a call from another line or calling over another line and getting information.)
In order to park a line call:
# Make hook flash while making conversation with a line.
F Wait for the special dial tone.
4 Dial 4 and park the line.
F Hear the internal dial tone.
Notes:
• The operator is supposed to dial “3”, instead of “4”, to while parking.
Retrieving A Call Parked Through One’s Own Phone :
In order to retrieve a call you have parked:
H Lift the handset and hear the internal dial tone.
4 Dial 4.
E Make the conversation.
Notes:
• The parked line gets into hold status and your phone is set completely free. If the
parked calls are not retrieved within 90 seconds (This duration can be programmed.),
then they return to the extension that has parked them.
15
#4
4

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
Retrieving A Parked Line:
In order to retrieve a line that has been parked by another extension:
H Lift the handset and hear the internal dial tone.
44 Dial 44.
B Dial the number of the line that has been parked or number of the
extension that has parked it.
E Carry out the conversation.
Line - Line Connection :
Thanks to this feature, while conversing with a line, that line can be put on hold and one
can start to converse with another line, then the line on hold and the line with which one
is conversing can be connected to each other, if necessary. That means this feature can
be used to connect two lines together.
In order to connect two lines together:
#4 While conversing with a line, make hook flash and dial 4.
9 Dial 9 and then the external number or
7B Dial 7 and number of the line that will be selected and then the external
number.
E Make conversation with the second line.
#6 Make hook flash and dial 6.
G Replace the handset.
Notes:
• The operator is supposed to dial “3”, instead of “4”, to while parking.
• Duration of call for the lines that have been connected in that way is 4 minutes. The
parties hear a warning tone when they enter the last 30 seconds of the conversation.
After this tone has been received, if one of the parties with DTMF (tone dialing) phone
wishes to prolong that duration by 2 minutes, then that can be done by pressing the key
“9” for a quite long period.
44
#6
16
Call Back :
If the extension you call or the line you want to access is busy, or if the extension is not
answering, then, by making use of the call back service, you can make the exchange
notify you of the availability of the line.
In order to call back:
8 When you receive busy tone or when the extension you call is ringing, dial 8.
G Replace the handset.
When the line is vacant or when the extension that has not previously answered uses the
telephone for the first time and hangs up, your phone rings and when you pick up you
automatically hear the line dial tone or the ring back tone of the extension. You can dial
the external number or you can make conversation with the extension when s/he picks up.
To cancel:
H Lift the handset and hear the internal dial tone.
81 Dial 81.
Intrusion:
If the extension you call is conversing with a line, you can intrude into the ongoing
conversation.
In order to intrude:
0 Dial 0 when you hear the busy tone.
When you hang up, the intrusion operation terminates; however, conversation of the
other parties goes on.
Notes:
• After the intrusion operation, both parties hear a short beep and when you are
conversing with the party you call, the party on the line hears you, but you cannot
hear her/him.
• If there is a line on hold when you are intruding, and if you wish to transfer that line
to the extension whose call you intrude in, then you should replace the handset and
if you wish to return to the line without transferring, then you should make hook
flash. It is sufficient to hang up in order to split.
8
17
0

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
18
CALL FORWARDING SERVICES
Follow Me :
Thanks to this feature, you can make the entire calls coming to you ring on another telephone.
In order to forward calls:
H Lift the handset and hear the internal dial tone.
85 Dial 85.
B Dial the number of the extension to whom you want the calls to be for
warded.
F Hear the internal dial tone. If you do not receive the internal dial tone,
then the forwarding will not be actualized.
To cancel:
H Lift the handset and hear the internal dial tone.
85 Dial 85.
G Replace the handset.
Notes:
• Forwarding can be done separately for Night and Day Modes.
• More than one telephone can be forwarded to the same extension.
• If extension A1 has been forwarded to extension A2, and if extension A2 has been
forwarded to extension A3, then extension A2 rings when extension A1 is called.
85
PASSWORD SERVICES
Password Define :
If you want to prevent your telephone to be used by others for external calls without your
information, then you can lock your phone by using your password when you are not at
your place.
In order to define password:
H Lift the handset and hear the internal dial tone.
836 Dial 836.
B Dial the password (001-999.)
F Hear the internal dial tone.
In order to delete the password:
H Lift the handset and hear the internal dial tone.
836 Dial 836.
B Dial your password.
G Replace the handset.
Changing Password :
In order to change the password:
H Lift the handset and hear the internal dial tone.
836 Dial 836.
B Dial your password.
B Dial your new password.
F Hear the internal dial tone.
836
836
19

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
Telephone Lock :
When a line is attempted to be accessed selectively by dialing “9” through a phone that
has been locked by password and when a code is dialed for calling through memory, you
first hear a short tone. Then you are supposed to enter your password after that tone in
order to perform any operation. That could be considered as a security application.
In order to lock the phone:
H Lift the handset and hear the internal dial tone.
837 Dial 837.
B Dial your password.
1 Dial 1.
F Hear the internal dial tone.
In order to unlock telephone:
H Lift the handset and hear the internal dial tone.
837 Dial 837.
B Dial your password.
0 Dial 0.
F Hear the internal dial tone.
Notes:
• If you change or cancel your password through a locked phone, then the phone is
automatically unlocked.
837
20
OTHER USER SERVICES
Do Not Disturb :
Thanks to this feature, if you want, you can make your telephone ring only once when a
call request is received, instead of ringing until it is picked up.
In order to activate the “Do not disturb”:
H Lift the handset and hear the internal dial tone.
831 Dial 831.
F Hear the internal dial tone.
To deactivate:
H Lift the handset and hear the internal dial tone.
830 Dial 830.
F Hear the internal dial tone.
Notes:
• The party calling you still receives ring back tone even if your telephone rings once
and then becomes silent. In that case, if you wish to answer the call, you can do that
by lifting the handset.
21
831

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
22
Reminder Service :
Thanks to this feature, you can use your phone as an alarm clock and make it warn you
by ringing at a specified time.
In order to enter the time of reminder:
H Lift the handset and hear the internal dial tone.
838 Dial 838.
B Dial the current hour (00-23) and minute (00-59), then the time you
wish to be warned in the form of hour (00-23) and minute (00-59) dial.
F Hear the internal dial tone.
To cancel:
H Lift the handset and hear the internal dial tone.
838 Dial 838.
G Replace the handset.
Notes:
• At the time of reminder, the phone rings in a special reminder ringer cadence. The
extension hears a warning tone as “ding-dong”, when s/he picks up the phone. The
phone rings for 2 minutes, if it is not picked up. If the phone is busy at the time of
reminder, then it rings one minute after it is hung up.
838 Listening To Music :
You can listen to the music, which is being broadcasted from an external music source,
through the feature telephone set of model LT26S-H with handsfree feature.
In order to listen to music:
H Lift the handset and hear the internal dial tone.
857 Dial 857.
After a while, your handsfree telephone will be picked up automatically, the dial tone will
be off and the music broadcast will begin.
To deactivate:
H Lift the handset and hear the internal dial tone.
857 Dial 857.
F Hear the internal dial tone.
Notes:
• In case of listening to music, coming calls are automatically connected to your phone.
• Upon a call is received, the music is cut throughout the conversation and it re-starts
after the call is over.
Door Opener :
In case the external control relay in the system is employed for opening door, you can
open a door through your phone.
In order to open door:
H Lift the handset and hear the internal dial tone.
23 Dial 23.
The door will be opened.
857
23
23

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
24
SERVICES RELATED TO THE OPERATOR
The features below can be employed by the operator only.
Date Setting :
In order to set the system date:
H Lift the handset and hear the internal dial tone.
833 Dial 833.
B Dial the day (01-31), then the month (01-12.)
F Hear the internal dial tone.
Time Setting :
In order to set the system time:
H Lift the handset and hear the internal dial tone.
88 Dial 88.
B Dial the hour (00-23), then the minute (00-59.)
F Hear the internal dial tone.
Notes:
• The time information is used for features related to the call record listing. The
clock stops on power failure and if KY16 or Net-CM call record system has been
connected to your exchange, then it is recommended that the time information would
be entered at certain intervals.
Common Pool Entry :
The Common Pool is a memory field where 100 telephone numbers, which have been
presented to the use of the entire authorized extensions, can be stored.
In order to enter numbers to the Common Pool:
H Lift the handset and hear the internal dial tone.
834 Dial 834.
B Dial the memory number (00-99.)
B Dial the external number (at most 16 digits.)
G Replace the handset.
88
834
833
25
Notes:
• Example: It is sufficient to dial “8340203122670240” in order to enter the number 0
312 2670240 to the common pool memory location.
• If the phone is MF or LT26S feature telephone set, then the key “#” can be employed
for forming one-second delay periods among digits. Each time the key “#” is
pressed, the delay period of one second is actualized. It is required to press the key
“#” as much as necessary to obtain delay periods longer than one second.
Example: When “84120##3122670240” is dialed, the number “0 312 2670240” is
stored into the memory location 12 and when one wants to make a call through that
memory, the exchange dials the other numbers 2 seconds after dialing 0.
Group Call Park :
The operator can park two lines, whereas other extensions can park only one line.
In order to park an external call:
# While conversing with a line, make hook flash.
F Wait for the special dial tone.
4 Dial 4.
F Hear the internal dial tone.
Notes:
• The parked line gets into hold status and your telephone is completely set free. If the
parked calls are not retrieved within 90 seconds (This duration can be programmed.),
then they return to the operator automatically.
Music On Hold :
By this feature, you can select the source of the music that will be emitted to parties that have
been parked or put on hold or to the extensions that have activated the “Listening To Music”
feature.
In order to select internal melody generator:
H Lift the handset and hear the internal dial tone.
8322 Dial 8322.
F Hear the internal dial tone.
In order to select external music source input:
H Lift the handset and hear the internal dial tone.
8321 Dial 8321.
F Hear the internal dial tone.
#4
832

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
26
To cancel:
H Lift the handset and hear the internal dial tone.
8320 Dial 8320.
F Hear the internal dial tone.
Notes:
• If no music source is selected, then the parties that have been parked or put on
hold receive short beeps. Moreover, the extensions cannot activate the “Listening To
Music” feature, either.
• By default, the internal melody generator of the exchange is on line.
Putting Lines Into Service Automatically :
By this feature, the exchange automatically checks the lines, puts them into service in
the appropriate signaling system (DP or MF) and takes the lines that are malfunctioning
out of service.
In order to put lines into service automatically:
H Lift the handset and hear the internal dial tone.
827 Dial 827.
F Hear the internal dial tone.
Notes:
• When this code is dialed, the entire calls being made at the moment are interrupted,
the exchange checks the system within approximately 10 seconds and then goes on
with the normal operation.
827
27
879
Night Mode :
In order to initiate the Night Mode:
H Lift the handset and hear the internal dial tone.
879 Dial 879.
F Hear the internal dial tone.
To deactivate:
H Lift the handset and hear the internal dial tone.
878 Dial 878.
F Hear the internal dial tone.
Notes:
• If you wish to determine line authorization levels, extension groups, call forwardings
and the extensions on which lines will ring, which you want to be valid only during the
Night Mode:
a) Line authorization levels:
- Set the system to the Night Mode, as described above.
- Determine line authorization levels of the extensions.
b) Call forwarding:
- Set the system to the Night Mode, as described above.
- Follow the procedure described in the section “Call Forwarding” for the exten
sions you want.
c) Determining the extension on which the line call will ring:
- Set the system to the Night Mode, as described above.
- Determine the extension numbers on which you want the line calls to ring.
• Unless any change is necessary, it is sufficient to do these operations once. When the
system is taken out of the Night Mode, the day parameters will be valid.

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
28
Line Forwarding :
Thanks to this feature, you can forward a specific call coming from a line to another
external number during the Night Mode.
In order to forward a line:
H Lift the handset and hear the internal dial tone.
83499 Dial 83499.
B Dial the external number to which you want to forward calls
(it will have been entered into the common pool memory
location 99.)
795 Dial 795.
G Replace the handset.
To cancel the service:
H Lift the handset and hear the internal dial tone.
795 Dial 795.
G Dial 795.
In order to delete the number to which forwarding is done:
H Lift the handset and hear the internal dial tone.
83499 Clear the memory location 99 by dialing 83499.
G Replace the handset.
Notes:
• The line forwarding works only while the system is in Night Mode.
• The external number to which forwarding will be done can be of at most 14 digits..
• The key “#” can be employed for inserting one-second delay periods among digits
of the number during external number entry. Each use of the key “#” is also
considered as a digit.
• Duration of a line call have been forwarded by this way is 4 minutes. The parties hear
a warning tone when they enter the last 30 seconds of the conversation. After this
tone has been received, if one of the parties with DTMF (tone dialing) phone wishes
to prolong that duration by 2 minutes, then that can be done by pressing the key “9”
for a quite long period.
795
29
Re-Loading The System Parameters :
If unexpected changes are observed in the operational orderliness of the exchange, and
if they are not related to hardware problems, then by this feature, it is possible to reset
the system parameters and go back to the normal operational order of the exchange.
In order to reset the system parameters:
H Lift the handset and hear the internal dial tone.
824 Dial 724.
GC Replace the handset and wait for the system for about one minute to
re-load its entire parameters.
Notes:
• An important portion of the system programs is stored in the memory. The system
loads these programs each time it is started.
824

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
30
SERVICES RELATED TO REPORTING
The services related to reporting can be used by the operator only.
Call Record Listing :
You can get the detailed listing of the most recent calls made over the lines again,
through Net-CM or a printer.
In order to get the call record listing again:
H Lift the handset and hear the internal dial tone.
8767 Dial 8767.
F Hear the internal dial tone.
In order to stop call record listing:
H Lift the handset and hear the internal dial tone.
8768 Dial 8768.
F Hear the internal dial tone.
Common Pool Listing :
In order to get listing of the common pool numbers from printer:
H Lift the handset and hear the internal dial tone.
8764 Dial 8764.
C The common pool numbers that have been stored in the system will
be listed.
F Hear the internal dial tone.
8767
8764
31
Time and Date Information Listing :
In order to get listing of the common pool numbers from printer:
H Lift the handset and hear the internal dial tone.
8765 Dial 8765.
C The common pool numbers that have been stored in the system will be listed.
F Hear the internal dial tone.
KY16 Page Feed :
In order to feed whole page on KY16 Mini Printer:
H Lift the handset and hear the dial tone.
8763 Dial 8763.
G Replace the handset.
KY16 Line Feed:
In order to feed line on KY16 Mini Printer:
H Lift the handset and hear the dial tone.
8762 Dial 8762.
G Replace the handset.
KY16 On Line :
When KY16 Mini Printer is put on line, the records that have been stored in the memory
of the exchange are automatically listed through KY16 Mini Printer.
In order to put KY16 Mini Printer on line:
H Lift the handset and hear the dial tone.
8761 Dial 8761.
G Replace the handset.
Notlar:
• You can obtain detailed listing of the entire calls made over any line and call record
data related to the extensions through KY16 mini printer. In order for your exchange
to transmit that data to the printer, the “printer on line” code must be entered.
• When the printer is put off line by the program 8760, the system stores the call
details in its memory and transmits that data to the printer when it is put on line.
8765
8763
8762
8761

USER’S GUIDE REV AAA TELEPHONE EXCHANGE
32
KY16 Off Line :
In case KY16 Mini Printer is off line, no listing is taken and relevant records are stored in
the memory of the exchange.
In order to put KY16 Mini Printer off line:
H Lift the handset and hear the dial tone.
8760 Dial 8760.
G Replace the handset.
8760 SAMPLES TO REPORTS TAKEN
Call record listing sample:
#0001 SI
08/12 14:34:17 14:34:38 00:21 11 12 02 0023 0000046 4483219
Explanation:
1st line:
Counter (e.g.: #0001),
Call type (e.g.: LOC)
LOC: Local call
LDIS: Long distance call
INT: International call
2nd line:
Date,
Starting time,
Ending time,
Call duration,
Number of the extension that has started (2 digits),
Number of the extension that has terminated (2 digits),
Number of the line used (D1, D2),
Number of detected pulse prices (4 digits),
Cost (7 digits),
External number dialed.
KY List:
#0001 LOC
08/12 14 : 34 : 17
00 :21 11 12 D2
0023 000046
4483219
33
