Karman S-Ergo 300G User manual

S
-
Ergo 300 series
S
-
Ergo 300G(KM
-
3020.2)/S
-
Ergo 305(KM
-
3520.2)

i
GENERAL WARNING
DO maintain your chair well, in particular check the tire pressure since this
affects the efficiency of the brakes.
DO make sure both brakes are applied before getting in or out of the chair.
DO make sure both brakes are applied when the chair is not being pushed or
used.
DO take care when climbing curbs or turning on slopes.
DO avoid steep or uneven surfaces that may cause the chair to tip over.
DO avoid soft surfaces because the casters may become bogged down.
DO travel smoothly in all conditions.
DO look well ahead to anticipate hazards such as furniture, doors, potholes,
etc.
DO make sure that both feet are safely on the footrests and that clothing is
safely tucked out of the way so that it cannot get caught in the wheels.
DO take care when traveling up or down or across inclines.
DO keep both hands on the push handles to control the chair, if you are the
attendant.
DO pay attention to keep the chair balanced.
DO check the frame and components regularly and refer to this user guide
during and after the warranty period.
DO tie-up the upholstery or replace which with a new one when it becomes
loose.
DO lubricate bearings regularly.
DO equip with anti-tippers to avoid falling backwards.
DO equip with a seat belt designed for disabled people.
DO equip with "ankle supports" for disabled people.
DO clean both hands after oiling the wheelchair.
DO NOT overload the chair in any circumstance.
DO NOT hang anything heavy on the back of the chair that could cause the
chair to become unstable, particularly when negotiating inclines.
DO NOT allow more than one user at a time.
DO NOT use with an unconscious patient.
DO NOT use other transport to pull the wheelchair.
DO NOT do "wheelies", since you my fall or tip over backwards and suffer a
severe injury.
DO NOT sit in the wheelchair within a moving vehicle unless it has been
affixed the labels of hook mark.
DO NOT go too fast or turn too quickly.
DO NOT stand on the footplates when getting in or out of the chair.
DO NOT go down steps forward, whether solo or with an attendant.
DO NOT attempt to lift the wheelchair by any removable (detachable) parts.
Lifting by means of any removable (detachable) parts of the wheelchair may
result in injury to the user and/or assistant or damage to the wheelchair.
DO NOT use the wheelchair when the back is folded. This alters the centre
of gravity and may cause the wheelchair to tip backwards. The back should
only be folded for storage or transport of the wheelchair.
DO NOT hang anything on the back joint that could cause the backrest
folding suddenly and may cause injury.

ii
YOU AND YOUR KARMA SERVICE PROVIDER
No tools are required for assembly. Your wheelchair should be assembled
by your authorized Karma dealer. Your authorized Karma dealer is also
your service provider. Unauthorized repairs, upgrades and add-ons will
negate your warranty. Anything wheelchair related that requires tools
should be done by your authorized Karma service provider. Your Karma
service provider has the necessary service/maintenance manual for your
wheelchair.
If you have any defective parts or lose any parts, please contact your dealer
for repair and/or replacement. Please only use parts authorized by Karma.
Use of parts that are not authorized by Karma will negate your warranty.
Part numbers are listed on our bill of materials (explosion drawings), which
we give to our authorized dealers and service providers. Customers should
order parts through their dealer as well as all repairs and scheduled
maintenance.
Customers should go to their dealership for all service needs to guarantee
their warranty is not nullified. Always go to an authorized service provider.
Unauthorized repairs will nullify your warranty. Procedures other than those
described in this manual must be performed by a qualified technician. They
also have the service manual with a complete list of maintenance required to
keep your Karma wheelchair in top performance. Check the warranty
section of this manual to find out what Karma guarantees and what
maintenance and parts you will have to pay for.
Karma does not have an official list of service providers at this time. Please
contact your dealer for service. If you cannot contact your dealer, please
contact another authorized Karma dealer for service. If all else fails, contact
Karma directly via our website or give us a call and we can refer you to your
new service provider.

iii
CE MARKING
This wheelchair complies with the requirements of the Medical Devices Directive
93/42/EEC.
CAUTION:
Before purchasing and using Karma wheelchairs, please consult qualified
professionals so as to ensure that you choose suitable products and use them
correctly as well. For safety reasons, if there is any risk due to the user’
s
movement in the wheelchair
or other environmental factors that might cause the
wheelchair to tip or the person on the wheelchair to fall off (ex. Amputee…
),
Karma recommends that you install anti-
tippers, safety belt, or other additional
safety
accessories
.

TABLE OF CONTENTS
1. PREFACE.............................................................................................1
2. SAFETY................................................................................................2
3. INTENDED USE & PARTS ...................................................................6
4. OPERATION.........................................................................................8
5. INSPECTION AND MAINTENANCE...................................................20
6. OPTIONS AND ACCESSORIES.........................................................22
7. TROUBLESHOOTING........................................................................24
8. SPECIFICATIONS ..............................................................................25
9. CLEANING & RECYCLING ................................................................26
10. WARRANTY .....................................................................................26

1
1. PREFACE
Please carefully read this owner's manual before using the wheelchair. Improper use
of the wheelchair could result in harm or injury. Therefore, for safe and enjoyable
use of the wheelchair, please read this owner's manual.
This owner's manual includes operation instructions for the aspects of the
wheelchair, unfolding/folding instructions and instructions on how to deal with
possible accidents.
This owner's manual is written for Karma wheelchair: S-Ergo 300 series.
The symbols used in this manual are explained below. Pay special attention to
the parts marked with these symbols.
WARNING: Improper use could lead to serious injury or death.
CAUTION:
Improper use could lead to serious injury and/or
damage to your wheelchair.
SUGGESTION:
Follow these instructions to keep the wheelchair in
good condition.
This manual includes the repair and maintenance chart as well as the warranty.
If someone else uses the wheelchair, make sure that you give him or her this
owner's manual for his or her reference.
As designs change, some illustrations and pictures in this manual may not
correspond to the wheelchair that you purchased. We reserve the right to make
design modifications without further notice.

2
2. SAFETY
2.1 Doorways
The safest way to operate the chair is on level floors that are free of obstacles.
Whenever possible use a ramp to enter or exit a facility. Keeping your hands on
the push rims will allow you to maintain maximum balance. Do not try to force
yourself over an obstruction by propulsion and never use the sides of a doorway to
pull yourself through a passageway.
2.2 Leaning
Do not lean over the side of your wheelchair since such an action may cause you to
lose balance and fall. (See Figure 2.1)
2.3 Navigating Inclines
Never turn on a hill due to the danger of tipping.
When assisting, go straight up a slope. If user needs to go down midway, walk
backwards until user is on level ground. (See Figures 2.2 and 2.3)
Avoid stopping on an incline; it can potentially cause you to lose control of the
chair.
Do not use the brakes to slow down or stop the wheelchair; this could cause it to
seize up, causing you to lose control or fall out of the chair.
Whenever possible, utilize help from an assistant/attendant while navigating
inclines.
2.4 Curbs
Whenever possible get help from an assistant/attendant (if you have assistance
make sure that your chair is equipped with push handles).
Avoid hard impacts when descending a curb. A hard impact could adversely
affect the chair.
Never try to scale or descend curbs that exceed a normal height (30-50mm).
Always be careful when climbing curbs and never move up or down a curb in
reverse without an assistant.
2.5 Stairs
Always use two or more assistants. Tilt the wheelchair to its point of equilibrium.
One assistant (at the back) holds the wheelchair up against the first step,
gripping the handles firmly to lift. The second assistant, holding firmly a fixed
part of the front frame, lifts the wheelchair above the stairs and holds it while the
first attendant places one foot on the following step and repeat the operation
(See Figure2.6)
Never go down steps forwards.
Never use an escalator for transport, use an elevator.

3
Figure 2.6 Figure 2.7
2.6 Streets
Always use extreme caution when crossing streets. Reflective tape on the chair
and/or your clothing will make you more visible to drivers.
Avoid potholes and rough terrain that might cause the casters to become stuck.
(See Figure 2.4)
2.7 General
Always make sure BOTH brakes are applied before getting in or out of the chair.
Never stand on the footplates when getting in or out of the chair.
Never carry more than one passenger. Karma wheelchairs are limited to one
user.
Use caution to assure your clothing doesn't get tangled with the wheels.
2.8 Transport
Do not use other transportation to pull the wheelchair.
Do not get transported on any vehicle while seated in your wheelchair. Karma
doesn't approve of any tie-down systems. Please transfer into seating approved
by the automotive (or other) industry and wear a safety belt.
2.9 Upholstery
When cleaning the upholstery, use warm water and a mild soap.
Upholstery cleaner/foam can also be used, but avoid other cleaning solvents.
2.10 Anti-tippers
Please purchase anti-tippers and always use them to avoid personal injury. The
distance between anti-tipper and wheels is at least 5cm; the height to floor doesn’t
be over 5cm. (See Figure2.7)
2.11 Maximum User Weight Limit
Refer to "Max. User Weight" in section 8. SPECIFICATIONS. Loads exceeding
maximum capacity can damage your wheelchair and cause malfunctions yielding a
safety hazard. The warranty does not cover damage caused by improper
operation of the wheelchair.
2.12 Avoid General Misuse:
Please note that our "Owner's Manual" contains a number of cautions -- any
vehicle can cause injury if misused -- use within our guidelines and with

4
reasonable care and your safety will be increased. Your wheelchair will give
years of safe use if used sensibly and carefully. Be aware that careless use
endangers your own safety as well as that of others. ALWAYS follow the
Highway Code when outdoors and the guidelines written in this manual.
Do not let children stand or play on the wheelchair. (See Figure 2.5)
Figure 2.1 Figure 2.2 Figure 2.3
Figure 2.4 Figure 2.5

5
2.13 Labeling
Please carefully read all the labeling on the wheelchair before driving it. Do not
remove them. Protect them for future reference.

6
3. INTENDED USE & PARTS
3.1 Intended Use
The S-Ergo 300 series is a self-propelled chair. That is, it can either be pushed
by an attendant or by the patients themselves.
These wheelchairs are suitable for users up to 115kg in weight. Hand brakes
are provided for both rear wheels.
It has pneumatic tires for traction and comfort. It also has an extremely durable
aluminum alloy frame with tough accessories and does not suffer in dramatic
extremes of temperature (neither user nor attendant need touch metal parts in
normal use).
The casters have PU tires for greater durability; pneumatic casters are available
on request.
Rear wheels are 24 inches in diameter and solid PU tires are available on
request.
When prescribing wheelchairs for use by full or partial amputees (above or below
knee, single or double) or other conditions that affects the users natural center of
gravity, we suggest contacting your therapist or dealer as well as attaching
anti-tippers.
The S-Ergo system provides pressure relief, stabilization and reduced sliding.
The S-shaped back can be adjusted so as to make the user more comfortable.
(For S-Ergo 300G)
The plastic modular parts of this model reduce weight and are easy to maintain.

7
3.2 Parts Description
1. Push Handle
2. Side Panel
3. Brake
4. Rear Wheel
5. Cross Brace (Cross Bar)
6. Caster
7. Backrest Upholstery
8. Armrest
9. Seat Upholstery
10. Heel Loop
11. Footplate

8
4. OPERATION
4.1 Preparing For Use
4.1.1 Unfolding
Holding the armrests, pull outwards. (See Figure 4.1)
Pointing your fingers inward with the palm of your hand on the frame, push down
until the seat is fully lowered. Make sure the frame is firmly seated in its holder.
(See Figure 4.2)
Connect the hook and loop fabric on the bottom of the backrest upholstery to the
underside of the seat. (See Figure 4.3)
Squeeze the swing-away footrest release handle and insert it into its coupling at
45°on either side. Swing the footrest towards the middle until you hear it click
into place. (See Figure 4.4)
Flip the footplates down. (See Figure 4.5)
Ready for action! (See Figure 4.6)
Alternatively, you can stand at the side of the chair and complete step 1 by pulling
the nearest armrest towards you and pushing the other one away.
Figure 4.1 Figure 4.2 Figure 4.3
Figure 4.4 Figure 4.5 Figure 4.6
CAUTION:
When unfolding, please be sure the seat tube rests in the bracket (see
right
picture below). Do not put your fingers
between the seat tube and the bracket
to avoid injury to yourself and damage to the wheelchair
(see rightmost picture
below)
.

9
CAUTION:
When completing step 2,
never put your fingers
around the side
s or under the chair as they can be
trapped between the seat and the frame. (See
Figure 4.7)
Figure 4.7
4.1.2 Folding
Flip up the footplates. (See Figure 4.8)
Squeeze the swing-away footrest release handle and rotate the footrest 45°to
either side and remove it. (See Figure 4.9)
Separate the hook and loop fabric of the seat’s underside from the backrest
upholstery. (See Figure 4.10)
Pull up on the seat upholstery by holding it in the center of its front and back
edge. (See Figure 4.11)
Press the two release levers on the backrest frame (push handle tubes) to fold
the backrest down for compact storage and easy transport. (See Figure
4.12)(For S-Ergo 305)
Folding is now completed.

10
Figure 4.8 Figure 4.9 Figure 4.10
Figure 4.11 Figure 4.12
CAUTION:
Be careful not to get your fingers caught when folding the wheelchair.
4.1.3 Adjustments
4.1.3.1 Armrest
Armrest flips back by pressing the release lever located at the front base of the
armrest. After you press the release lever, you can lift and rotate the armrest
backwards. (See Figures 4.13 and 4.14)
The height adjustable armrest feature is optional. If your model has it, simply
loosen and remove the knob bolt, then adjust the armrest to the desired height and
finally reattach the knob bolt.
Figure 4.13 Figure 4.14

11
4.1.3.2 Rear Wheel
Your wheelchair may be supplied with quick-release wheels. If so, please follow
the instructions below.
4.1.3.2.1 Rear Wheel Removal
Support the weight of the chair with one hand by holding the push handle.
Depress the hub cover and hold down the quick-release mechanism.
Remove the wheel. (See Figure 4.15)
4.1.3.2.2 Rear Wheel Attachment
Pick up the wheel: Hold the center of the rear wheel by grasping two adjacent
spokes with four fingers of one hand, use the thumb to depress and keep
depressed the quick-release. Take the quick-release axle and depress the
button in its center. This retracts the bearings at the opposite end of the axle.
This will allow you to push the axle through the center of the hub of the wheel.
Your wheels are now ready to be assembled to the frame of your wheelchair.
First ensure that the brake is in the OFF position. Take up the assembled wheel
and axle and depress the button in the center of the axle, as above. This
retracts the ball bearings that will allow you to push the axle into the wheel
bracket that is located on the lower rear frame of the wheelchair. When you
remove your thumb from the button on the axle, the ball bearings should be
visible protruding from the axle at the back of the wheel bracket. This will secure
the wheel safely in the frame. (See Figure 4.16)
CAUTION:

You must make sure that the axle is fully located in the wheelchair bracket and
that the ball bearings are fully open and have positively attached the wheel in
the frame.

The rear wheel can be mounted at different positions on the frame to alter the
seat height and overall stability of the chair. Changing the wheel position
should be carried out by your approved repairer or therapist.
Figure 4.15
Figure 4.16

12
4.1.3.2.3 Important DO’s and DON'T’s
DO: Keep axles clean and lubricated with light oil or maintenance spray.
DO: Maintain correct tire pressure if using pneumatic tires.
DO NOT: Try to remove the wheels while the wheelchair is ccupied even when
using anti-tippers.
4.1.3.3 Footrest
Footrests can rotate in or out, which makes transferring in tight spaces easier and
swinging both footrests inward makes it easier to work at a desk. (See Figures
4.17 and 4.18)
4.1.3.4 Footplate Height
To adjust footplate height use the Karma tool provided to loosen the bolt at the
side of the footrest arm.
Adjust to required height and re-tighten the screw and make sure the footplate is
firm. Then tighten the nut as a locknut from outside. (See Figure 4.19)
Figure 4.17 Figure 4.18 Figure 4.19 Figure 4.20
SUGGESTION:
Make sure that the footplate height is adjusted properly according to the
users calf length to reduce pressure on the body.
The footrest height must be more than 5cm. (See Figure 4.20)
4.1.3.5 Seat Height
The following information is for your reference only. It will be utilized by your
authorized service agent and your therapist to customize the wheelchair to your
specific body dimensions.

13
Figure 4.21
CAUTION:
When you change wheel position (whether rear wheels or casters)
the gravity
will change simultaneously. We recommend you contact your
Karma dealer
and therapist, as well as attach anti-tippers.
Seat Height
(mm)
Front Caster
Size (inch)
Front Fork
Position
Wheels Size
(inch)
Wheels Bar
Position
515
8
”
a
24
”
3
495
7
”
a
24
”
2
515 6” b 24” 3
510 6” a 14” 5
510
7
”
a
16
”
4
495
7
”
a
22
”
3
*Seat angle is 1.5 degrees

14
4.1.3.6 Adjusting Back Height (For S-Ergo 300G)
The follow information is about how to adjust back height of S-Ergo 300G so as to
make the user’s back more comfortable and to fit the position of pelvis well as to
reduce sliding. (See Figure 4.22)
Loosen the screws of both back tubes.
Adjust back height to fit the user’s back.
Tighten the screws and it is ready to use.
Figure 4.22 Figure 4.23 Figure 4.24
4.1.3.7 Center of gravity adjustment (For S-Ergo 300G)
The adjustment of center of gravity provides the user with different options to choose
the position of center of gravity. By reducing the distance of caster and rear wheels,
the chair may become more maneuverable to the user. If the distance of caster
and rear wheels is increased, it becomes more stable to the user. (See Figure
4.23.)
CAUTION:
When you change rear wheels’ pos
ition, the position of center of gravity will
change simultaneously. For further information, we recommend
you contact
your
Karma dealer and/or therapist. We also recommend that you install the
anti
-
tipper
s
.
4.1.3.8 Caster angle adjustment (For S-Ergo 300G)
Caster angle adjustment provides good performance to propel. When adjusting
seat height or changing different wheel sizes, do make sure that the caster angle is
vertical to the ground. (See Figure 4.24)
CAUTION:
We recommend that you contact your therapist or Karma’
s authorized dealer
in case you need to change the angle of caster
. Otherwise you might
damage your wheelchair or injury the user.
4.1.4 Transporting and Storing
Make sure the wheelchair is folded when it is stored.
SUGGESTION:
Please store the wheelchair in a location where it is out of direct sunlight, rain,
and dew. For more details, consult your Karma dealer.

15
WARNING:
Do not
put anything on the wheelchair while it is in storage.
Storing goods on a folded wheelchair will cause
damage
and is not covered by warranty. (See picture right.)
4.2 Transferring In and Out
4.2.1 Transferring In
Engage both hand brakes.
Turn the footplates up and swing them to the side.
The user lowers himself/herself into the seat using the armrests for support.
Turn the footplates back down, so that the user can place his feet on them.
Ensure that the heels rest against the heel supports to prevent contact with the
casters.
Release both hand brakes.
CAUTION:
Always ensure that the front casters a
re in line with the rear wheels and pointing
forwards and that the back of the chair is secure either against a wall or firmly held
by an attendant.
4.2.2 Transferring Out
Make sure that the chair is near your final destination.
Back the chair sufficiently to ensure that the casters are pointing forward, i.e. in
line with the rear wheels and usually with the caster forks pointing forward.
Ensure that, where possible, the rear of the chair is against a wall or, if not, it
must be firmly held by an attendant.
Engage both hand brakes.
Turn the footplates up and swing them to the side.
Slide forwards on the seat.
Place one foot firmly on the ground with the knee at a right angle and the other
foot slightly apart and further back.
Place your hands on the front of the armrests and moving your weight forward,
bring your head and shoulders up over your knees as you push yourself up.
CAUTION:
Never stand on the footplates when getting into (or out of) the chair. (See
Figure 4.25)
When getting in and out of the wheelchair please use the hand brakes. The
hand brake is the lever at the side of the wheelchair.
Please ensure that neither the tread on your tires nor the brake block has
become too worn. If pneumatic tires are fitted, please maintain at the
recommended tire pressure for the same reason.

Please ensure that occupant's fingers do not get caught in the
brake.
When transferring in and out of the chair, make sure that the brakes are applied to
