Kasda KW5862 User manual

KW5862 WIFI ADSL Gateway
User Manual

WLAN ADSL Gateway User Manual
NOTICE
This document contains proprietary information protected by copyright, and this Manual
and all the accompanying hardware, software, and documentation are copyrighted. All
rights are reserved. No part of this document may be photocopied or reproduced by
mechanical, electronic, or other means in any form.
The manufacturer does not warrant that the hardware will work properly in all
environments and applications, and makes no warranty or representation, either
expressed or implied, with respect to the quality, performance, merchantability, or
fitness for a particular purpose of the software or documentation. The manufacturer
reserves the right to make changes to the hardware, software, and documentation
without obligation to notify any person or organization of the revision or change.
All brand and product names are the trademarks of their respective owners.
© Copyright 2014
All rights reserved.

Content
1 OVERVIEW..............................................................................................................................1
1.1 FEATURES .........................................................................................................................1
1.1.1 Data rate..................................................................................................................1
1.1.2 ADSL Compliance...................................................................................................1
1.1.3 Wireless...................................................................................................................1
1.1.4 Network Protocol & Features.................................................................................2
1.1.5 ATM Capabilities.....................................................................................................2
1.1.6 VoIP..........................................................................................................................2
1.1.7 FIREWALL...............................................................................................................3
1.1.8 Management Support.............................................................................................3
1.1.9 Operating System Support.....................................................................................3
1.1.10 Environmental.........................................................................................................4
1.2 PACKET CONTENTS..........................................................................................................4
1.3 SYSTEM REQUIREMENTS..................................................................................................4
1.4 FACTORY DEFAULTS ........................................................................................................4
1.5 WARNINGS AND CAUTIONS...............................................................................................5
2HARDWARE DESCRIPTION.................................................................................................6
3HARDWARE INSTALLATION...............................................................................................8
4PC CONFIGURATION GUIDE.............................................................................................9
4.1 LOCAL PC CONFIGURATION IN WINDOWS 95, 98, ME, XP...................................................9
4.2 LOCAL PC CONFIGURATION IN WINDOWS 2000...................................................................9
5 WEB-BASED MANAGEMENT GUIDE..................................................................................10
5.1 LANSETTING PAGE .........................................................................................................10
5.2 INTERNET ACCESS CONFIGURATION................................................................................11
5.2.1 ADSL Mode Setup.....................................................................................................11
5.2.2 Router Mode Setup................................................................................................... 16
5.2.3 LAN Settings..............................................................................................................22
5.2.3.1 IPv4 LAN Settings.................................................................................................. 22
5.2.3.2 IPv6 LAN Settings.................................................................................................. 24
5.3 WIRELESS SETTING ......................................................................................................... 26
5.3.1 Basic...........................................................................................................................26
5.3.2 Advanced Settings......................................................................................................27
5.3.3 Security........................................................................................................................ 29
5.4 VOIPCONFIGURATION..................................................................................................... 33
5.4.1 SIP Basic Setting.......................................................................................................33
5.4.2 SIP Advanced Setting...............................................................................................35
5.5PRINTER SERVER INSTALLATIONS ......................................................................................36
APPENDIX: FREQUENT ASKED QUESTIONS......................................................................38

WLAN ADSL Gateway User Manual
1
1 Overview
Thank you for choosing our product. The KW5862 is a Wireless ADSL router
combining an ADSL modem, an 802.11n wireless router, a 4-port switch, two FXS
ports and a USB host port in one unit, bringing high-speed wireless Internet
connection to a home or office.
1.1 Features
1.1.1 Data rate
Downstream data rate up to 24 Mbps
Upstream data rate up to 1Mbps
1.1.2 ADSL Compliance
ITU G.992.1 (G.DMT)
ITU G.992.2 (G.Lite)
ITU G.994.1 (G.hs)
ITU G.992.3 (G.DMT.BIS)
ITU G.992.4 (G.lite.bis)
ITU G.992.5
Compatible with all T1.413 issue 2 (full rate DMT over analog
POTS), and CO DSLAM equipment
1.1.3 Wireless
Fully IEEE 802.11b & IEEE 802.11g compatible
IEEE 802.11n draft 2 compatible
Wireless data rate up to 300 Mbps
Fully IEEE 802.11b & IEEE 802.11g compatible.
Wireless data rate up to 54Mbps
Operating in the unlicensed 2.4 GHz ISM band
Multi-SSID
Supports 64/128 bits WEP security and user authentication

WLAN ADSL Gateway User Manual
2
1.1.4 Network Protocol & Features
Ethernet to ADSL Self-Learning Transparent Bridging
Internet Control Message Protocol (ICMP)
IP Static Routing
Routing Information Protocol (RIP, RIPv2)
Network Address Translation (NAT)
Virtual Server, Port Forwarding
Dynamic Host Configuration Protocol (DHCP)
DNS Relay, DDNS
IGMP Proxy
Simple Network Time Protocol (SNTP)
VPN pass-through (IPSec/PPTP/L2TP)
Parent control
1.1.5 ATM Capabilities
RFC 1483 Multi-protocol over ATM “Bridged Ethernet” compliant
RFC 2364 PPP over ATM compliant
RFC 2516 PPP over Ethernet compliant
ATM Forum UNI3.1/4.0 PVC - Up to 8 PVCs
VPI Range: 0-255
VCI Range: 32-65535
UNI 3.0 & 3.1 Signaling
ATM AAL5 (Adaption Layer type 5)
OAM F4/F5
1.1.6 VoIP
SIP

WLAN ADSL Gateway User Manual
3
Voice codecs: G.711A/µ, G.723, G.726, G.729
Call waiting
Call forwarding
1.1.7 FIREWALL
Built-in NAT
MAC Filtering
Packet Filtering
Stateful Packet Inspection (SPI)
Denial of Service Prevention (DoS)
DMZ
1.1.8 Management Support
Web Based GUI
Upgrade or update via FTP/HTTP
Command Line Interface via Telnet
Diagnostic Test
Firmware upgrade-able for future feature enhancement
1.1.9 Operating System Support
WINDOWS 98
WINDOWS 98 SE
WINDOWS ME
WINDOWS 2000
WINDOWS XP
WINDOWS VISTA
Macintosh
LINUX

WLAN ADSL Gateway User Manual
4
1.1.10 Environmental
Operating humidity: 10%-90% non-condensing
Non-operating storage humidity: 5%-95% non-condensing
1.2 Packet Contents
The packet contents are as the following:
ADSL ROUTER x 1
External Splitter x 1
Power Adapter x 1
Telephone Line x 1
Ethernet Cable x 1
Antenna x 2
CD x 1
1.3 System Requirements
Before using this ROUTER, verify that you meet the following requirements:
Subscription for ADSL service. Your ADSL service provider should
provide you with at least one valid IP address (static assignment or
dynamic assignment via dial-up connection).
One or more computers, each contains an Ethernet 10/100M Base-T
network interface card (NIC).
A hub or switch, if you are connecting the device to more than one
computer.
For system configuration using the supplied web-based program: A web
browser such as Internet Explorer v5.0 or later, or Netscape v4.7 or
later.
1.4 Factory Defaults
The device is configured with the following factory defaults:
IP Address: 192.168.1.1
Subnet Mask: 255.255.255.0
Encapsulation: RFC 2516 LLC
VPI/VCI: According to local information

WLAN ADSL Gateway User Manual
5
1.5 Warnings and Cautions
Never install telephone wiring during storm. Avoid using a telephone
during an electrical storm. There might be a risk of electric shock from
lightening.
Do not install telephone jacks in wet locations and never use the product
near water.
To prevent dangerous overloading of the power circuit, be careful about
the designed maximum power load ratings. Not to follow the rating
guideline could result in a dangerous situation.
Please note that telephone line on modem must adopt the primary line
that directly outputs from junction box. Do not connect Router to
extension phone. In addition, if your house developer divides a
telephone line to multi sockets inside the wall of house, please only use
the telephone that has connected with the splitter of ADSL Router when
you access the Internet. Under the above condition, if you also install
telephone with anti-cheat-dial device, please pull out this kind of
telephone, otherwise ADSL Router may occur frequently off-line.

WLAN ADSL Gateway User Manual
6
2 Hardware Description
Front Panel
LED
Color
Function
POWER
Green
On: Power
Off: No power
ETH1,2,3,4
Green
On: LAN link established and active via LAN port
Blinking: ADSL data activity occurs
Off: No LAN link via LAN port
WLAN
Green
On: The wireless module is ready and idle.
Off: The wireless is not installed.
Blinking: Data transmitting or receiving over WLAN
DSL
Green
Red
On: ADSL link established and active
Blinking: ADSL is trying to establish a connect
No ADSL Line connection
INET
Green
Blinking: ADSL data activity occurs.
Off: No ADSL data is being sent or received.
WPS
Green
On: WPS connection is established
Blinking: Trying to establish a WPS connection
Off: WPS function is off or no WPS connection
VOIP
Green
On:VOIP connection established
Blinking: VOIP data activity occurs
Off: No VOIP connection.

WLAN ADSL Gateway User Manual
7
Rear panel
Port
Function
DSL
Connect the device to an ADSL telephone jack or splitter
using a RJ-11 telephone cable
FXS1
Connect the deviceto your normal phone
RESET
System reset or reset to factory defaults.
USB
Connect the deviceto your printer
ETH1,2,3,4
Connect the device to your PC's Ethernet port, or to the
uplink port on your hub/switch, using a RJ-45 cable
ON/OFF
Switch it on or off
POWER
Connect to the supplied power adapter
