INSTALLATION MANUAL KKL CABLE CONNECTORS

93/11-2020-MOJ
Full life-cycle manual available: katko.com/terms-conditions/
Product Datasheet:
Type Un In (Al)
(A)
In (Cu)
(A) Al mm² Cu mm² Torque Al/Cu (Nm) T Stripping length L Allen key Mounting EAN code Weight
(V) mm size 6419410… kg
KKL 1X16 690 63 63 1,5-16 1,5-16 2,2 (1,5-16mm²) 15 Hex 3 Direct ...378496 0,01
KKL 1x50T.1 690 125 125 16-50 2,5-50 5 (2,5-16mm²) / 10 (25-50mm²) 19 Hex 5 Direct ...378717 0,019
KKL 1X50T.2 690 125 125 16-50 2,5-50 5 (2,5-16mm²) / 10 (25-50mm²) 19 Hex 5 Direct ...378502 0,019
KKL 1x50T.3 690 125 125 16-50 2,5-50 5 (2,5-16mm²) / 10 (25-50mm²) 19 Hex 5 Direct ...378724 0,019
KKL 1X50M 690 125 125 16-50 2,5-50 5 (2,5-16mm²) / 10 (25-50mm²) 19 Hex 5 Direct ...378519 0,017
KKL 1X50N 690 125 125 16-50 2,5-50 5 (2,5-16mm²) / 10 (25-50mm²) 19 Hex 5 Direct ...378670 0,014
KKL 1X50 690 160 160 16-50 2,5-50 5 (2,5-16mm²) / 10 (25-50mm²) 19 Hex 5 Bolt ...378571 0,011
KKL 2X50 690 200 320 16-50 16-50 5 (2,5-16mm²) / 10 (25-50mm²) 19 Hex 5 Bolt M8 ...378588 0,023
KKL 2X50M 690 200 320 16-50 16-50 5 (2,5-16mm²) / 10 (25-50mm²) 19 Hex 5 Bolt M8 ...378663 0,023
KKL 1X95 690 200 245 25-95 25-95 12 (16-50 mm2) / 22 (70-95 mm2) 22 Hex 6 Bolt M8 ...378595 0,03
KKL1x95M 690 200 245 25-95 25-95 12 (16-50 mm2) / 22 (70-95 mm2) 22 Hex 6 Bolt M8 ...378953 0,03
KKL 2X95 690 400 490 25-95 25-95 12 (16-50 mm2) / 22 (70-95 mm2) 22 Hex 6 Bolt M10 ...378601 0,061
KKL 1X120T.1 690 200 245 16-120 16-120 12 (16-50 mm2) / 22 (70-120 mm2) 22 Hex 6 Direct ...378526 0,037
KKL 1X120T.2 690 200 245 16-120 16-120 12 (16-50 mm2) / 22 (70-120 mm2) 22 Hex 6 Direct ...378533 0,037
KKL 1X120T.3 690 200 245 16-120 16-120 12 (16-50 mm2) / 22 (70-120 mm2) 22 Hex 6 Direct ...378540 0,037
KKL 1X120T 690 200 245 16-120 16-120 12 (16-50 mm2) / 22 (70-120 mm2) 22 Hex 6 Direct …378700 0,037
KKL 1X120TM 690 200 245 16-120 16-120 12 (16-50 mm2) / 22 (70-120 mm2) 22 Hex 6 Direct ...378557 0,037
KKL 1X120RS 690 200 245 16-120 16-120 12 (16-50 mm2) / 22 (70-120 mm2) 22 Hex 6 Bolt M8 ...378687 0,044
KKL 1X120RSY 690 200 245 16-120 16-120 12 (16-50 mm2) / 22 (70-120 mm2) 22 Hex 6 Bolt M8 ...378694 0,044
KKL 1X150 690 250 320 25-150 25-150 12 (25-50 mm2) / 22 (70-95 mm2) / 38 (120-150 mm2) 29 Hex 6 Bolt M10 …378618 0,073
KKL1x150T2 690 250 320 25-150 25-150 12 (25-50 mm2) / 22 (70-95 mm2) / 38 (120-150 mm2) 29 Hex 6 Bolt M10 ...378748 0,073
KKL 2X150 690 500 640 25-150 25-150 12 (25-50 mm2) / 22 (70-95 mm2) / 38 (120-150 mm2) 29 Hex 6 Bolt M12 …378625 0,15
KKL2x150LR 690 500 640 25-150 25-150 12 (25-50 mm2) / 22 (70-95 mm2) / 38 (120-150 mm2) 29 Hex 6 Bolt M12 ...300459 0,15
KKL 1X240 690 315 425 35-240 35-240 25 (35-120 mm2) / 55 (150-240 mm2) 35 Hex 8 Bolt M12 ...378632 0,113
KKL 2X240 690 630 850 35-240 35-240 25 (35-120 mm2) / 55 (150-240 mm2) 35 Hex 8 Bolt M12 ...378649 0,245
KKL 1X240TM 690 400 425 35-240 35-240 25 (35-120 mm2) / 40 (150-240 mm2) 30 Hex 8 Bolt M8 ...378656 0,113
KKL 1X240TE 690 400 400 35-240 35-240 25 (35-120 mm2) / 40 (150-240 mm2) 30 Hex 8 Bolt M8 ...378731 0,113
KKL2x240LR 690 630 850 35-240 35-240 25 (35-120 mm2) / 55 (150-240 mm2) 35 Hex 8 Bolt M12 ...378755 0,245
KKL1x300 690 400 520 95-300 95-300 45 (95-120 mm2) / 75 (150-300 mm2) 42 Hex 12 Bolt M12 ...484289 0,262
KKL2x300 690 800 1040 95-300 95-300 45 (95-120 mm2) / 75 (150-300 mm2) 42 Hex 12 Bolt M12 ...484296 0,501
KKL2x150VB 690 500 640 25-150 25-150 12 (25-50 mm2) / 22 (70-95 mm2) / 38 (120-150 mm2) 31/62 Hex 6 Bolt M12 ...484319 0,18
KKL2x150VM 690 500 640 25-150 25-150 12 (25-50 mm2) / 22 (70-95 mm2) / 38 (120-150 mm2) 31/62 Hex 6 Bolt M12 ...484302 0,18
KKL2x240VB 690 630 850 35-240 35-240 25 (35-120 mm2) / 40 (150-240 mm2) 37/75 Hex 8 Bolt M12 ...484333 0,339
KKL2x240VM 690 630 850 35-240 35-240 25 (35-120 mm2) / 40 (150-240 mm2) 37/75 Hex 8 Bolt M12 ...484326 0,339
KKL2x300VB 690 800 1040 95-300 95-300 45 (95-120 mm2) / 75 (150-300 mm2) 42/82 Hex 12 Bolt M12 ...484357 0,572
KKL2x300VM 690 800 1040 95-300 95-300 45 (95-120 mm2) / 75 (150-300 mm2) 42/82 Hex 12 Bolt M12 ...484340 0,572
Table 1

93/11-2020-MOJ
Full life-cycle manual available: katko.com/terms-conditions/
Installation:
Connection:
Stripping length L:L
Nut - DIN 934
Spring washer - DIN 127
Washer - DIN 125
Bolt - DIN 933
Conductor:
Mounting: Bolt Mounting: Direct
Torque T
Ref. Table 2
Mounting: DirectMounting: Bolt

93/11-2020-MOJ
Full life-cycle manual available: katko.com/terms-conditions/
Cross section (mm²)/ number of conductors simultaneously connectable to the terminal
KKL
Type In [A] Torque [Nm] 1,5 2,5 4 6 10 16 25 35 50 70 95 120 150 185 240 300
1x16 63 2,2Nm (1,5-16mm²) Al
Cu
111111----------
3 3 3 2 1** 1
1x50 160 5Nm (2,5-16mm²) Al
Cu -- - - - 1 1 1 1 -------
10Nm (25-50mm²) 3 3 3 3 2 1 1** 1
1x50N 125 5Nm (2,5-16mm²) Al
Cu -- - - - 1 1 1 1 -------
10Nm (25-50mm²) 3 3 3 3 2 1 1** 1
1x50M 125 5Nm (2,5-16mm²) Al
Cu -- - - - 1 1 1 1 -------
10Nm (25-50mm²) 3 3 3 3 2 1 1** 1
1x50T.1 125 5Nm (2,5-16mm²) Al
Cu -- - - - 1 1 1 1 -------
10Nm (25-50mm²) 3 3 3 3 2 1 1** 1
1x50T.2 125 5Nm (2,5-16mm²) Al
Cu -- - - - 1 1 1 1 -------
10Nm (25-50mm²) 3 3 3 3 2 1 1** 1
1x50T.3 125 5Nm (2,5-16mm²) Al
Cu -- - - - 1 1 1 1 -------
10Nm (25-50mm²) 3 3 3 3 2 1 1** 1
2x50 200 5Nm (2,5-16mm²) Al
Cu -11111111-------
320 10Nm (25-50mm²) 3 3 3 3 2 1 1** 1
2x50M 200 5Nm (2,5-10mm²) Al
Cu -11111111-------
320 10Nm (16-50mm²) 3 3 3 3 2 1 1** 1
1x95 200 12Nm (16-50mm²) Al
Cu -----111111-----
245 22Nm (70-95mm²) 3 2 2 1 1** 1
1x95M 200 12Nm (16-50mm²) Al
Cu -----111111-----
245 22Nm (70-95mm²) 3 2 2 1 1** 1
2x95 400 12Nm (16-50mm²) Al
Cu -----111111-----
490 22Nm (70-95mm²) 3 2 2 1 1** 1
1x120 200 12Nm (16-50mm²) Al
Cu -----1111111----
245 22Nm (70-120mm²) 3 2 2 1 1** 1 1
1x120RS 200 12Nm (16-50mm²) Al
Cu -----1111111----
245 22Nm (70-120mm²) 3 2 2 1 1** 1 1
1x120RSY 200 12Nm (16-50mm²) Al
Cu -----1111111----
245 22Nm (70-120mm²) 3 2 2 1 1** 1 1
1x120T 200 12Nm (16-50mm²) Al
Cu -----1111111----
245 22Nm (70-120mm²) 3 2 2 1 1** 1 1
1x120T.1 200 12Nm (16-50mm²) Al
Cu -----1111111----
245 22Nm (70-120mm²) 3 2 2 1 1** 1 1
1x120T.2 200 12Nm (16-50mm²) Al
Cu -----1111111----
245 22Nm (70-120mm²) 3 2 2 1 1** 1 1
1x120T.3 200 12Nm (16-50mm²) Al
Cu -----1111111----
245 22Nm (70-120mm²) 3 2 2 1 1** 1 1
1x120TM 200 12Nm (16-50mm²) Al
Cu -----1111111----
245 22Nm (70-120mm²) 3 2 2 1 1** 1 1
1x150 250
320
12Nm (25-50mm²) Al
Cu ------1 3
1
3
1
2
1
1
1
1
1
1**
1
1- - -22Nm (70-95mm²)
38Nm (120-150mm²)
2x150 500
640
12Nm (25-50mm²) Al
Cu ------1 3
1
3
1
2
1
1
1
1
1
1**
1
1- - -22Nm (70-95mm²)
38Nm (120-150mm²)
2x150VB 500
640
12 Nm (25-50 mm²) Al
Cu ------1 3
1
3
1
2
1
1
1
1
1
1**
1
1- - -22 Nm (70-95 mm²)
38 Nm (120-150 mm²)
2x150VB 500
640
12 Nm (25-50 mm²) Al
Cu ------1 3
1
3
1
2
1
1
1
1
1
1**
1
1- - -22 Nm (70-95 mm²)
38 Nm (120-150 mm²)
1x240 315 25Nm (35-120mm²) Al
Cu -------11111111-
425 55Nm (150-240mm²) 3 3 2 1 1 1 1** 1
2x240 630 25Nm (35-120mm²) Al
Cu -------11111111-
850 55Nm (150-240mm²) 3 3 2 1 1 1 1** 1
2x240VB 630 25Nm (35-120mm²) Al
Cu -------11111111-
850 55Nm (150-240mm²) 3 3 2 1 1 1 1** 1
2x240VM 630 25Nm (35-120mm²) Al
Cu -------11111111-
850 55Nm (150-240mm²) 3 3 2 1 1 1 1** 1
1x300 400 45 Nm (95-120 mm2) Al
Cu ----------111111
520 75 Nm (150-300 mm2) 2 2 1 1 1 1
2x300 800 45 Nm (95-120 mm2) Al
Cu ----------111111
1040 75 Nm (150-300 mm2) 2 2 1 1 1 1
2x300VB 800 45 Nm (95-120 mm2) Al
Cu ----------111111
1040 75 Nm (150-300 mm2) 2 2 1 1 1 1
2x300VM 800 45 Nm (95-120 mm2) Al
Cu ----------111111
1040 75 Nm (150-300 mm2) 2 2 1 1 1 1
** Biggest ne-strand conductors
Cu conductors may be solid, multi-strand or ne-strand conductors. With ne strand conductors use of cable end sleeve is recommended but not required.
Table 2
