CN39 MIDI Settings Manual
1
MIDI Settings
MIDI Overview
The term MIDI is an acronym for Musical Instrument Digital Interface, an international standard for connecting
musical instruments, computers, and other devices to allow the exchange of performance data.
MIDI Terminals
MIDI terminal Function
MIDI IN Receiving note, program change, and other data.
MIDI OUT Sending note, program change, and other data.
MIDI channels
MIDI uses channels to exchange data back and forth between MIDI devices. There are receive (MIDI IN) and transmit (MIDI OUT)
channels. Most musical instruments or devices with MIDI functions are equipped with both MIDI IN and OUT jacks and are capable of
transmitting and receiving data via MIDI. The receive channels are used to receive data from another MIDI device, and the transmit
channels are used to transmit data to another MIDI device.
The illustration below shows three musical instruments, connected together using MIDI.
Transmitting instrument aReceiving instrument bReceiving instrument c
Transmitting instrument asends transmit channel and keyboard information to receiving instruments b/c.
The information arrives at the receiving instruments b/c.
Receiving instruments b/cwill respond to MIDI data that is sent if their receive channel is the same as the transmit channel of the
transmitting instrument a. If the channels do not match, the receiving instruments b/cwill not respond to any data that is sent.
For both receiving and transmitting, channels 1-16 can be used.
Recording/playing with a sequencer
When connected to a sequencer (or a computer running MIDI
sequencing software), the CN39 digital piano can be used to
record and playback multi-track songs, with separate sounds
playing simultaneously on each channel.
Sequencer
CN39 MIDI Settings Manual
2
MIDI Settings
MIDI Functions
The CN39 digital piano supports the following MIDI functions:
Transmit/receive note information
Transmit/receive note information to/from a MIDI-connected
musical instrument or device.
Transmit/receive program change information
Transmit/receive program change data to/from a MIDI-
connected musical instrument or device.
Transmit/receive channel settings
Specify transmit/receive channels within the range of 1 to 16.
Transmit/receive pedal data
Transmit/receive sustain, sostenuto, and soft pedal data to/
from a MIDI-connected musical instrument or device.
Transmit/receive exclusive data
Transmit/receive front panel or menu function settings as
exclusive data.
Receive volume data
Receive MIDI volume data sent from a MIDI-connected
musical instrument or device.
Multi-timbral mode setting
Receive multiple channel MIDI data from a MIDI-connected
musical instrument or device.
* Please refer to the ‘MIDI Implementation Chart’ on page 19 for further
information regarding the MIDI capabilities of the CN39 digital piano.
MIDI Settings
No. Setting Description Default setting
1MIDI Channel Specify the channel that is used to transmit/receive MIDI information. 1
2 Send PGM Change # Send a MIDI program change number from 1 to 128. 1
3 Local Control Specify whether internal sounds will be heard when the keyboard is pressed. On
4Trans. PGM Change Specify whether program change data is sent when sounds are changed. On
5Multi-timbral Mode Specify whether the instrument can receive Multi-timbral MIDI information. O
6Channel Mute Specify which channels (1-16) are activated to receive MIDI information. Play All
* Default settings will be shown in the rst LCD display illustration (i.e. Step 1) for each setting explanation below.
Entering the MIDI Settings menu
While the normal playing mode screen is shown in the LCD display:
Press the FUNCTION button (MENU).
The Function menus will be shown in the LCD display.
Press the or buttons to select the MIDI Settings menu.
Press the FUNCTION button (ENTER) again to enter the MIDI
Settings menu.
Selecting and adjusting the desired setting
After entering the MIDI Settings menu:
Press the or buttons to move the selection cursor over the
desired setting.
Press the or buttons to adjust the selected setting.
* To reset the current setting to the default value, press the and
buttons simultaneously.
CN39 MIDI Settings Manual
3
MIDI Settings
1
MIDI Channel
The MIDI Channel setting allows the transmit/receive channel to be specied. The selected channel will function as
both the transmit and receive channel (separate transmit/receive channels cannot be specied).
1. Selecting the MIDI Channel setting
After entering the MIDI Settings menu (page 2):
Press the or buttons to select the MIDI Channel setting.
2. Changing the MIDI Channel value
Press the or buttons to increase or decrease the value of
the MIDI Channel setting.
* The MIDI Channel value can be adjusted within the range of 1~16.
* To reset the MIDI Channel setting to the default value, press the
and buttons simultaneously.
* Any changes made to the MIDI Channel setting will remain until the
power is turned o.
* Preferred MIDI Channel settings can be stored to a Registration
Memory for convenient recall, or to the Startup Setting memory for
automatic selection when the instrument is turned on. Please refer to
CN39 Owner’s Manual pages 35 and 79 for more information.
3. Exiting the MIDI Channel setting
Press the FUNCTION button (BACK) to exit the MIDI Channel
setting and return to the Function Menus screen.
Omni mode
When the CN39 digital piano is turned on, the instrument is automatically set to ‘omni mode on’, allowing MIDI information to be
received on all MIDI channels (1~16). When the MIDI Channel setting is used to specify a transmit/receive channel, the instrument
will be set to ‘omni mode o’.
Multi-timbral mode and Split/Dual modes
Using Split mode with Multi-timbral mode enabled
Notes played in the lower section of the keyboard will be
transmitted on the channel that is 1 channel higher than the
specied channel. For example, if the MIDI channel is set to
3, notes played in the lower section of the keyboard will be
transmitted on channel 4.
Using Dual mode with Multi-timbral mode enabled
Notes played will be transmitted on two channels: the
specied channel and the channel that is 1 channel higher.
For example, if the MIDI channel is set to 3, notes played on
the keyboard will be transmitted on channels 3 and 4.
* If the specied MIDI channel is 16, the lower section / layered part will be transmitted on channel 1.
CN39 MIDI Settings Manual
4
MIDI Settings
2
Send Program Change Number
The Send Program Change Number function is used to send a Program Change Number (1-128) to the connected
MIDI device.
1. Selecting the Send Program Change Number function
After entering the MIDI Settings menu (page 2):
Press the or buttons to select the Send Program Change
Number function.
2. Specifying and transmitting a Program Change Number
Press the or buttons to decrease or increase the Program
Change Number.
* The program change number can be set within the range of 1~128.
Press the FUNCTION button (SEND) to send the specied
Program Change Number.
3. Exiting the Send Program Change Number function
Press the FUNCTION button (BACK) to exit the Send Program
Change Number function and return to the Function Menus
screen.
CN39 MIDI Settings Manual
5
MIDI Settings
3
Local Control
The Local Control setting determines whether the instrument will play an internal sound when the keys are pressed.
This setting may be useful when using the CN39 digital piano to control an external MIDI device that is connected
to the instrument’s amplier/speakers.
Local Control setting
Local Control Description
O The instrument will transmit information to an external MIDI device only.
On (default) The instrument will play an internal sound and transmit information to an external MIDI device.
1. Selecting the Local Control setting
After entering the MIDI Settings menu (page 2):
Press the or buttons to select the Local Control setting.
2. Changing the Local Control setting
Press the or buttons to turn the Local Control setting on
or o.
* To reset the Local Control setting to the default setting, press the
and buttons simultaneously.
* Any changes made to the Local Control setting will remain until the
power is turned o.
* Preferred Local Control settings can be stored to a Registration
Memory for convenient recall, or to the Startup Setting memory for
automatic selection when the instrument is turned on. Please refer to
CN39 Owner’s Manual pages 35 and 79 for more information.
3. Exiting the Local Control setting
Press the FUNCTION button (BACK) to exit the Local Control
setting and return to the Function Menus screen.
CN39 MIDI Settings Manual
6
MIDI Settings
4
Transmit Program Change Numbers
The Transmit Program Change Numbers setting determines whether the CN39 digital piano will transmit program
change information via MIDI when the instrument’s panel buttons are pressed.
Transmit Program Change Numbers setting
Transmit PGM# Multi-timbral setting Eect of pressing panel buttons
On (default) O, On1 SOUND buttons will send PGM# shown in the left column*.
On On2 SOUND buttons will send PGM# shown in the right column*.
O O Program Change information will not be transmitted via MIDI.
* Please refer to the ‘Program Change Number List’ on page 9.
1. Selecting the Transmit Program Change Numbers setting
After entering the MIDI Settings menu (page 2):
Press the or buttons to select the Transmit Program Change
Numbers setting.
2. Changing the Transmit Program Change Numbers setting
Press the or buttons to turn the Transmit Program Change
Numbers setting on or o.
* To reset the Transmit Program Change Numbers setting to the default
setting, press the and buttons simultaneously.
* Any changes made to the Transmit Program Change Numbers setting
will remain until the power is turned o.
* Preferred Transmit Program Change Numbers settings can be stored
to a Registration Memory for convenient recall, or to the Startup
Setting memory for automatic selection when the instrument is
turned on. Please refer to CN39 Owner’s Manual pages 35 and
79 for more information.
3. Exiting the Transmit Program Change Numbers setting
Press the FUNCTION button (BACK) to exit the Transmit
Program Change Numbers setting and return to the Function
Menus screen.
Omni mode
Program change numbers will also be transmitted when
Multi-timbral mode is set to On1 or On2.
When using Dual or Split mode, On/O information and
sound type settings for are transmitted as exclusive data,
however program change numbers will not be transmitted.
CN39 MIDI Settings Manual
7
MIDI Settings
5
Multi-timbral Mode
The Multi-timbral Mode setting determines whether or not the CN39 digital piano is able to receive MIDI information
on more than one MIDI channel simultaneously. This allows the instrument to play back multi-track, multi-timbral
performance data sent from an external MIDI device.
Multi-timbral Mode setting
Multi-timbral Mode Selected sound
O (default) The sound shown in the left column is selected*.
On1 The sound shown in the left column is selected*.
On2 The sound shown in the right column is selected*.
* Please refer to the ‘Program Change Number List’ on page 9.
1. Selecting the Multi-timbral Mode setting
After entering the MIDI Settings menu (page 2):
Press the or buttons to select the Multi-timbral Mode
setting.
2. Changing the Multi-timbral Mode setting
Press the or buttons to change turn the Multi-timbral
Mode setting.
* To reset the Multi-timbral Mode setting to the default setting, press
the and buttons simultaneously.
* Any changes made to the Multi-timbral Mode setting will remain until
the power is turned o.
* Preferred Multi-timbral Mode settings can be stored to a Registration
Memory for convenient recall, or to the Startup Setting memory for
automatic selection when the instrument is turned on. Please refer to
CN39 Owner’s Manual pages 35 and 79 for more information.
3. Exiting the Multi-timbral Mode setting
Press the FUNCTION button (BACK) to exit the Multi-timbral
Mode setting and return to the Function Menus screen.
CN39 MIDI Settings Manual
8
MIDI Settings
6
Channel Mute
The Channel Mute setting determines which MIDI channels (1-16) are activated to receive MIDI information when
Multi-timbral mode is enabled.
* This setting is only available when the Multi-timbral Mode setting is set to ‘On1’ or ‘On2’.
1. Selecting the Channel Mute setting
After entering the MIDI Settings menu (page 2):
Press the or buttons to select the Channel Mute setting.
Press the FUNCTION button (EDIT).
The Channel Mute selection screen will be shown in the LCD
display.
2. Selecting and playing/muting channels
Press the or buttons to select the desired MIDI channel.
Press the or buttons to alternate between ‘Play’ and ‘Mute’
states.
* To reset the Channel Mute setting to the default value, press the
and buttons simultaneously.
* Any changes made to the Channel Mute setting will remain until the
power is turned o.
* Preferred Channel Mute settings can be stored to a Registration
Memory for convenient recall, or to the Startup Setting memory for
automatic selection when the instrument is turned on. Please refer to
CN39 Owner’s Manual pages 35 and 79 for more information.
3. Exiting the Channel Mute function
Press the FUNCTION button (BACK) to exit the Channel Mute
adjustment screen and return to the MIDI Settings menu.
CN39 MIDI Settings Manual
9
Program Change Number List
Sound Name Multi-timbral mode = o/on1 Multi-timbral mode = on2
Bank LSB Program Number Bank MSB Bank LSB Program Number
PIANO1
SK ConcertGrand 0 1 121 0 1
EX ConcertGrand 0 2 95 27 1
SK-5 GrandPiano 0 3 95 30 1
Studio Grand 0 4 121 1 1
Studio Grand 2 0 5 95 28 1
Mellow Grand 0 6 121 2 1
Mellow Grand 2 0 7 95 29 1
PIANO2
Upright Piano 0 8 95 25 1
Standard Grand 0 9 95 16 1
Pop Grand 010 95 31 1
Upright Piano 2 0 11 95 26 1
Modern Piano 012 121 0 2
Upright Piano 3 0 13 95 34 1
Honky Tonk 014 121 0 4
E.PIANO
Classic E.Piano 015 121 0 5
6 0 ’s E . P. 016 121 3 5
M o d er n E . P. 017 121 0 6
Electric Grand 018 121 0 3
Classic E.P. 2 0 19 95 3 5
Classic E.P. 3 0 20 95 5 5
Modern E.P. 2 0 21 95 6 6
ORGAN
Jazz Organ 022 121 018
Blues Organ 023 121 017
Ballad Organ 024 95 517
Gospel Organ 025 95 317
Church Organ 026 121 020
Mellow Flutes 027 95 48 20
Medium Ensemble 028 95 42 20
Loud Ensemble 029 95 43 20
HARPSI & MALLETS
Harpsichord 0 30 95 6 7
Vibraphone 031 121 012
Clavi 032 121 0 8
Marimba 033 121 013
Celesta 034 121 0 9
Music Box OctUP 0 35 95 311
STRINGS & CHOIR
Slow Strings 0 36 95 145
String Pad 037 95 849
Warm Strings 0 38 95 149
CN39 MIDI Settings Manual
10
Program Change Number List
Sound Name Multi-timbral mode = o/on1 Multi-timbral mode = on2
Bank LSB Program Number Bank MSB Bank LSB Program Number
String Ensemble 039 121 049
Choir 040 121 053
Choir 2 041 95 53 54
New Age 042 121 089
Atmosphere 043 121 0100
BASS
Wood Bass 044 121 033
Electric Bass 045 121 034
Fretless Bass 046 121 0 36
W. Bass & Ride 0 47 95 133
OTHERS : PIANO
Jazz Grand 048 95 8 1
Studio Grand 3 049 95 17 1
Mellow Grand 3 050 95 18 1
Rock Piano 051 121 1 2
New Age Piano 0 52 95 9 1
New Age Piano 2 0 53 95 10 1
New Age Piano 3 0 54 95 11 1
Piano Octaves 055 95 1 1
Wide Honky Tonk 0 56 121 1 4
OTHERS : E.PIANO
Electric Grand2 057 121 1 3
D o l ce E . P. 058 95 2 5
C r y s t al E . P. 059 95 1 6
Tremolo E.P. 060 95 1 5
Classic E.P. 4 0 61 121 1 5
Classic E.P. 5 0 62 121 2 5
New Age E.P. 0 63 95 2 6
Modern E.P. 3 0 64 121 1 6
Modern E.P. 4 0 65 121 2 6
Legend E.P. 066 121 3 6
P ha s e E . P. 067 121 4 6
OTHERS : HARPSI & MALLETS
Harpsichord wTC 068 121 0 7
Harpsichord 2 069 121 3 7
Harpsichord Oct 070 121 1 7
WideHarpsichord 071 121 2 7
Synth Clavi 072 121 1 8
Glockenspiel 073 121 010
Music Box 074 121 011
Toy Piano 075 95 111
Wide Vibraphone 076 121 112
Wide Marimba 077 121 113
Xylophone 078 121 014
CN39 MIDI Settings Manual
11
Program Change Number List
Sound Name Multi-timbral mode = o/on1 Multi-timbral mode = on2
Bank LSB Program Number Bank MSB Bank LSB Program Number
Handbells 079 95 115
Tubular Bells 080 121 015
Church Bells 081 121 115
Carillon 082 121 215
Dulcimer 083 121 016
OTHERS : DRAWBAR
Drawbar Organ 084 95 117
Drawbar Organ 2 085 95 217
Drawbar Organ 3 086 121 218
Drawbar Organ 4 087 121 317
Drawbar Organ 5 088 121 117
Jazzer 089 95 118
Soft Solo 090 95 817
ElectronicOrgan 091 95 917
60’s Organ 092 121 217
Perc. Organ 093 121 118
Tibia Bass 094 95 14 18
Rock Organ 095 121 019
OTHERS : CHURCHORGAN
Principal Oct. 096 95 24 20
Soft Diapason 097 95 45 20
Soft Strings 098 95 41 20
Bright Ensemble 099 95 47 20
Full Organ 0100 95 44 20
Reed Ensemble 0101 95 46 20
Diapason 0102 95 720
Full Ensemble 0103 95 121
Diapason Oct. 0104 95 620
Theater Organ 0 105 95 120
8’ Celeste 0106 95 520
Small Ensemble 0107 95 820
Reeds 0108 95 10 20
Chiy Tibia 0109 95 17 20
Principal Pipe 0110 95 22 20
Church Organ 2 0 111 121 120
Church Organ 3 0 112 121 220
Reed Organ 0113 121 021
Pu Organ 0114 121 121
OTHERS : ACCORDION
FrenchAccordion 0115 121 022
Fr. Accordion 2 0116 95 122
Accordion 0117 121 122
Accordion 2 0118 95 222
Blues Harmonica 0119 95 223
CN39 MIDI Settings Manual
12
Program Change Number List
Sound Name Multi-timbral mode = o/on1 Multi-timbral mode = on2
Bank LSB Program Number Bank MSB Bank LSB Program Number
Harmonica 0120 121 023
Tango Accordion 0121 121 024
OTHERS : GUITAR
FingerNylon Gtr 0122 95 425
Nylon Acoustic 0123 121 025
Nylon Acoustic2 0124 121 225
Nylon Acoustic3 0125 121 325
Ukulele 0126 121 125
Ballad Guitar 0127 95 626
Steel Guitar 0128 121 026
Steel Guitar 2 1 1 121 326
12 String 1 2 121 126
Mandolin 1 3 121 226
Jazz Guitar 1 4 121 027
Pedal Steel 1 5 121 127
Rhythm Guitar 1 6 121 228
Electric Guitar 1 7 121 028
E. Guitar 2 1 8 121 128
E. Guitar 3 1 9 121 229
Muted Electric 110 121 029
Cutting Guitar 111 121 129
Country Lead 112 121 329
OverdriveGuitar 113 121 0 30
Dynmic Ov.drive 114 121 1 30
Distortion 115 121 031
Dist Feedback 116 121 131
Dist Rhythm 117 121 231
E.Gtr Harmonics 118 121 032
Guitar Feedback 119 121 132
OTHERS : BASS
Wood Bass 2 1 20 95 233
Wood Bass 3 1 21 95 433
Wood Bass 4 1 22 95 533
Electric Bass 2 1 23 95 534
Electric Bass 3 1 24 95 634
FingerSlap Bass 125 121 134
Pick Bass 126 121 035
Slap Bass 127 121 037
Slap Bass 2 128 121 0 38
Synth Bass 129 121 039
Synth Bass 2 1 30 121 040
Synth Bass 3 1 31 121 239
Synth Bass 4 1 32 121 140
Warm Synth Bass 1 33 121 139
CN39 MIDI Settings Manual
13
Program Change Number List
Sound Name Multi-timbral mode = o/on1 Multi-timbral mode = on2
Bank LSB Program Number Bank MSB Bank LSB Program Number
Clavi Bass 134 121 339
Hammer Bass 135 121 439
Rubber Bass 1 36 121 240
Attack Bass 137 121 340
OTHERS:STRINGS&ORCHINST
Violin 1 38 121 041
Slow Violin 139 121 141
Viola 140 121 042
Cello 141 121 043
Contrabass 142 121 044
Tremolo Strings 143 121 045
Strings & Brass 1 44 121 149
60’s Strings 145 121 249
Strings sf. 146 95 949
StringEnsemble2 147 121 050
Synth Strings 148 121 051
Synth Strings 2 1 49 121 052
Synth Strings 3 1 50 121 151
Pizzicato 151 121 046
Harp 152 121 047
Celtic Harp 153 121 147
Timpani 154 121 048
OTHERS : CHOIR & HIT
Choir 3 155 121 153
Voice Oohs 1 56 121 054
Humming 157 121 154
DoReMi # 158 95 51 54
DoReMi b 159 95 52 54
Synth Vocal 160 121 055
Analog Voice 161 121 155
Orchestra Hit 162 121 0 56
Bass Hit Plus 1 63 121 1 56
6th Hit 1 64 121 2 56
Euro Hit 165 121 3 56
OTHERS : BRASS
Trumpet 166 121 057
Solo Trumpet 167 121 157
Flugel Horn 168 95 157
SentimentalBone 169 95 758
Trombone 170 121 058
Trombone 2 171 121 158
Bright Trombone 172 121 258
Tuba 173 121 059
CupMute Trumpet 174 95 160
CN39 MIDI Settings Manual
14
Program Change Number List
Sound Name Multi-timbral mode = o/on1 Multi-timbral mode = on2
Bank LSB Program Number Bank MSB Bank LSB Program Number
CupMuteTrombone 175 95 260
Muted Trumpet 176 121 060
Muted Trumpet 2 1 77 121 160
French Horns 178 121 061
Warm FrenchHorn 179 121 161
Brass Section 180 121 062
Brass Section 2 1 81 121 162
Synth Brass 182 121 063
Synth Brass 2 1 83 121 064
Synth Brass 3 1 84 121 163
Synth Brass 4 1 85 121 164
Jump Brass 186 121 363
Analog Brass 187 121 263
Analog Brass 2 1 88 121 264
OTHERS : REED
Oboe & Strings 1 89 95 569
Soprano Sax 190 121 065
Alto Sax 191 121 066
Soft Tenor Sax 1 92 95 267
Tenor Sax 193 121 067
Baritone Sax 194 121 068
Oboe 195 121 069
English Horn 196 121 070
Bassoon 197 121 071
Clarinet 198 121 072
OTHERS : PIPE
Flute & Strings 1 99 95 874
Piccolo 1100 121 073
Jazz Flute 1101 95 174
Big Band Winds 1 102 95 274
OrchestralWinds 1103 95 374
Flute 1104 121 074
Ballad Flute 1105 95 13 74
Recorder 1106 121 075
Pan Flute 1107 121 076
Blown Bottle 1108 121 077
Shakuhachi 1109 121 078
Whistle 1110 121 079
Ocarina 1111 121 080
OTHERS : SYNTH LEAD
Square 1112 121 081
Square 2 1113 121 181
Sine 1 114 121 281
Classic Synth 1115 121 082
CN39 MIDI Settings Manual
15
Program Change Number List
Sound Name Multi-timbral mode = o/on1 Multi-timbral mode = on2
Bank LSB Program Number Bank MSB Bank LSB Program Number
Classic Synth 2 1116 121 182
Lead 1117 121 282
Classic Synth 3 1118 121 382
SequencedAnalog 1119 121 482
Caliope 1120 121 083
Chi 1121 121 084
Charang 1122 121 085
Wire Lead 1123 121 185
Voice 1124 121 086
Fifth 1125 121 087
Bass & Lead 1 126 121 088
Soft Wire Lead 1 127 121 188
OTHERS : SYNTH PAD
Itopia 1128 121 192
New Age 2 2 1 95 189
New Age 3 2 2 95 289
New Age 4 2 3 95 389
Warm Pad 2 4 121 090
Sine Pad 2 5 121 190
Bright Warm Pad 2 6 95 190
Polysynth 2 7 121 091
Choir Pad 2 8 121 092
Bowed Pad 2 9 121 093
Metallic Pad 210 121 094
Halo Pad 211 121 095
Sweep Pad 2 12 121 096
Multi Sweep 2 13 95 196
OTHERS : SYNTH SFX
Rain Pad 214 121 097
Soundtrack 215 121 098
Crystal 216 121 099
Synth Mallet 217 121 199
Brightness 218 121 0101
Brightness 2 219 95 1101
Goblin 220 121 0102
Echoes 221 121 0103
Echo Bell 222 121 1103
Echo Pan 223 121 2103
Sci-Fi 224 121 0104
OTHERS : ETHNIC
Sitar 2 25 121 0105
Sitar 2 2 26 121 1105
Banjo 227 121 0106
Shamisen 228 121 0107
CN39 MIDI Settings Manual
16
Program Change Number List
Sound Name Multi-timbral mode = o/on1 Multi-timbral mode = on2
Bank LSB Program Number Bank MSB Bank LSB Program Number
Koto 229 121 0108
Taisho Koto 2 30 121 1108
Kalimba 231 121 0109
Bag Pipe 232 121 0110
Fiddle 233 121 0111
Shanai 234 121 0112
OTHERS : PERCUSSION
Tinkle Bell 235 121 0113
Agogo 2 36 121 0114
Steel Drums 237 121 0115
Woodblock 2 38 121 0116
Castanet 239 121 1116
Taiko Drums 240 121 0117
Concert BD 241 121 1117
Melodic Toms 242 121 0118
Melodic Toms 2 2 43 121 1118
Synth Drum 244 121 0119
Rhythm Box Tom 2 45 121 1119
Electric Drum 246 121 2119
Reverse Cymbal 247 121 0120
Gtr Fret Noise 2 48 121 0121
GtrCuttingNoise 249 121 1121
CuttingNoise 2 250 95 1121
Ac Bass Slap 251 121 2121
OTHERS : SFX
Breath Noise 2 52 121 0122
Flute Key Click 253 121 1122
Seashore 254 121 0123
Rain 255 121 1123
Thunder 2 56 121 2123
Wind 257 121 3123
Stream 258 121 4123
Bubble 259 121 5123
Bird Tweet 2 60 121 0124
Dog Barking 261 121 1124
Horse Gallop 262 121 2124
Bird Tweet 2 2 63 121 3124
Cat&Dog&Harp 264 95 12 124
Telephone 265 121 0125
Telephone 2 266 121 1125
Door Creak 267 121 2125
Door Slam 268 121 3125
Scratch 269 121 4125
Wind Chime 270 121 5125
CN39 MIDI Settings Manual
17
Program Change Number List
Sound Name Multi-timbral mode = o/on1 Multi-timbral mode = on2
Bank LSB Program Number Bank MSB Bank LSB Program Number
Helicopter 271 121 0126
Car Engine 272 121 1126
Car Stopping 273 121 2126
Car Passing 274 121 3126
Car Crash 275 121 4126
Siren 2 76 121 5126
Train 277 121 6126
Jet Plane 278 121 7126
Starship 279 121 8126
Burst Noise 280 121 9126
Applause 281 121 0127
Laughing 282 121 1127
Screaming 283 121 2127
Punch 284 121 3127
Heartbeat 285 121 4127
Foot Step 286 121 5127
Gunshot 287 121 0128
Machine Gun 288 121 1128
Laser Gun 2 89 121 2128
Explosion 290 121 3128
OTHERS : DRUMKIT
Standard Set 291 120 0 1
Room Set 292 120 0 9
Power Set 2 93 120 017
Electronic Set 294 120 025
Analog Set 295 120 026
Jazz Set 296 120 033
Brush Set 297 120 041
Orchestra Set 298 120 049
SFX Set 299 120 057
CN39 MIDI Settings Manual
18
MIDI Exclusive Data Format
1st byte 2nd byte 3rd byte 4th byte 5th byte 6th byte 7th byte 8th byte 9th byte 10th byte
12345678910
Byte ID Description
1F0 Start code
240 Kawai ID number
3 00 - 0F MIDI channel
410, 30 Function code (30 when setting Multi-timbre On/O)
504 Indicates that the instrument is an electric piano
613 Indicates that the piano is a CN39 model
7data 1
See table below8 data 2
9data 3
10 F7 End code
data 1 data 2 data 3 Function
00 00 -Multi-timbre O
02 00 -Multi-timbre On 1
01 00 -Multi-timbre On 2
0F 15 - 6C - Split Point A0-C8
14 00 - 7F - Dual/Split balance
16 1F - 60 - Tune, 40 : 440 Hz
17 00, 7F - 00 : Program Change O, 7F : Program Change On
18 00 - 07 - 00 : Light, 01 : Normal, 02 : Heavy, 03 : O, 04 : Light +, 05 : Heavy +, 06 : User1, 07 : User2
19 00 - 03 - Lower Octave Shift
20 00 - 7F 00 - 7F Dual, data 2 : Main sound, data 3 : Layer sound
21 00 - 7F 00 - 7F Split, data 2 : Upper sound, data 3 : Lower sound
22 00 - 7F 00 -7F Four Hands, data2 : Right sound, data3 : Left sound
25 00 - 09 00 - 0B
data2 : Temperament
00 : Equal, 01 : Pure Major, 02 : Pythagorean, 03 : Meantone,
04 : Werkmeister, 05 : Kirnberger, 07 : Pure Minor, 09 : User
data3 : Key
26 00, 7F 00 - 0F Multi-timbre, data 2 : 00 (Mute), 7F (Play), data 3 : Channel
27 00 - 02 00 - 02 Dual/Split, Right (Upper)/Left (Lower), sound Bank LSB
CN39 MIDI Settings Manual
19
MIDI Implementation Chart
KPSZ-1074 R100
Kawai CN39 digital piano
Date: February 2019 Version: 1.0
Function Tra nsmit Receive Remarks
Basic channel At power-up 1 1
Settable 1 - 16 1 - 16
Mode
At power-up Mode 3 Mode 1 * The default for the OMNI
mode is On.
Specifying MIDI channels
automatically turns it O.
Message X Mode 1, 3
Alternative ********* X
Note number 9 - 120** 0 - 127 ** The value depends on
the Transpose setting.
Range ********* 0 - 127
Velocity Note on O O
Note o O O
After touch Key specic X X
Channel specic X O
Pitch bend X O
Control change
0, 32
1
5
6, 38
7
10
11
64
65
66
67
69
70
71
72
73
74
75
76
77
78
84
91
93
98, 99
100, 101
O
X
X
X
X
X
X
O(Right pedal)
X
O(Center pedal)
O(Left p edal)
O
X
X
X
X
X
X
X
X
X
X
X
X
X
X
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
Bank Select *1
Modulation
Portament Time
Data Entry
Volu me
Panpot
Expression Pedal
Sustain Pedal
Portament
Sostenuto Pedal
Soft Pedal
Hold 2
Sustain Level
Resonance
Release Time
Attack Time
Cutto
Decay Time
Vibrato Speed
Vibrato Depth
Vibrato Delay
Portament Control
Reverb Send Level
Chorus Send Level
NRPN LSB, MSB
RPN LSB, MSB
Program change O0-127 O*1
True *********
Exclusive O O On/O Selectable
Common
Song position X X
Song selection X X
Tune X X
Real time Clock X X
Commands X X
Other functions
All sound O XO(120)
Reset all controller
XO(121)
Local On / O X O
All notes O XO(123 - 127)
Active sensing X O
Reset X X
*1 Please refer to the Program Change Number List on page 9.
Mode 1: omni mode On, Poly Mode 2: omni mode On, Mono O : Yes
Mode 3: omni mode O, Poly Mode 4: omni mode O, Mono X : No
Other manuals for CN39
1
Table of contents
Other Kawai Musical Instrument manuals
Kawai
Kawai DX200 User manual
Kawai
Kawai PN81 User manual
Kawai
Kawai SR3 User manual
Kawai
Kawai DG30 Manual
Kawai
Kawai Piano Instruction Manual
Kawai
Kawai MP4 User manual
Kawai
Kawai Concert Artist CA99 Manual
Kawai
Kawai CN23 User manual
Kawai
Kawai Digital Electronic Organs SR50 User manual
Kawai
Kawai MR370 User manual
