Chapter 1. Product Overview
The Kaye LTR-150 is the next generation, multi-purpose calibrator designed to address the flexibility and
capacity needs for validation calibrations and verifications. As a multi-purpose calibrator, the LTR-150 can
be easily transformed from a standard dry block to a micro bath or surface temperature calibrator, which are
purchasable options. The LTR-150 offers a broad temperature range from -30°C to 150°C with temperature
stability of ±0.01°C and uniformity of ±0.1°C. Performance of calibration and calibration verification can either
be performed automatically via Remote mode or manual through Standard mode.
The Kaye LTR-150 has been designed to interface directly
with all Kaye products (Validator AVS, Validator 2000, IRTD,
ValProbe, and RF ValProbe). The firmware is backward
compatible with all version of Kaye software without need
for software upgrades. This functionality allows the unit to
be utilized for fully automatic calibrations/verifications of
thermocouples, ValProbes or RF ValProbes utilizing your
existing IRTD and applicable Kaye software.
The Kaye LTR-150 also has the flexibility to calibrate other
process or validation sensors in Standalone mode through
the intuitive 7” touchscreen, and a variety of optional inserts.
To maximum accuracy of the control and measurement
during calibration, the LTR-150 includes an external Control
Reference Probe. This probe is used for feedback to the
calibrator controller.
The calibrator is portable, rugged and can be used in a
variety of environments from 0°C to 50°C and humidity ≤80%
(non-condensing).
Chapter 1. Product Overview

5
M5101-EN Rev. B |
Key Components of the LTR-150
1. Tank (Dry Block, Micro Bath, Surface).
2. Carrying handle.
3. Steel housing.
4. Touch screen for display and operation.
5. Calibrator exhaust ventilation
6. Connection for external reference probe.
7. USB Port for connection to Kaye hardware.
8. Main switch with fuse and mains plug socket.
Calibrator, bottom view:
• Calibrator ventilation
Inlet air for housing cooling
Inlet air for tank / metal block cooling
b
c
Chapter 1. Product Overview
b
c

6| Kaye LTR-150 - Dry Block & Liquid Bath All-in-One Temperature Calibrator
1.1 Dry-Block Function
The LTR-150 comes standard with a dry block insert containing sixteen (16) wells for thermocouples as
well as two (2) wells for IRTD, and one (1) well for the Control Reference Probe. Each of the sixteen (16)
thermocouple wells is included with a sleeve which can accommodate upwards of three (3) thermocouples.
The sleeves are optimized to handle 22AWG thermocouples, which are similar to the ones currently utilized
in existing Kaye dry block models.
Kaye also offers additional dry blocks for calibrating specialty process or validation probes. These blocks are
easily interchangeable utilizing the supplied insert tool.
Thermocouple insert wells
IRTD insert wells
Control Reference Probe well
Chapter 1. Product Overview

7
M5101-EN Rev. B |
1.2 Micro Bath Function
The LTR-150 has the ability to be utilized as a micro bath for calibration/verification of specialty probes or
even ValProbe Loggers. Utilization of the micro bath functionality requires the purchase of the optional Micro
Bath Kit (PN: 425-3061).
The kit includes a micro bath tub as well as one (1) sensor cage, two (2) magnetic stirrers, one (1) magnetic
lifter, one (1) sleeve exchange tool, one (1) work cover, and one (1) transportation cover. Kaye also offers
Silicon Oil (type 200 -10cs) which can cover the complete temperature range of the calibrator and can be
directly poured into the micro bath tub.
The use of calibration liquids offers certain
advantages if temperatures of unusual shape
and/or size require calibration. The sensor cage
can accommodate up to two (2) ValProbe rigid
loggers. The test item is immersed directly into
the desired liquid medium without an insulating
air gap, resulting in direct temperature contact
between the unit and test item(s). The continuous
adjustment of the magnetic stirrer together with
the removable sensor basket agitates the medium
to create a broad and uniform temperature
measuring zone. Furthermore, the sensor basket
guarantees unhindered stirring, protecting the
tank floor.
The sensor cover reduces evaporation of the liquid to a
minimum and cooling of the liquid surface. The cover is
screwed on to the micro bath and has five (5) openings for
sensors under test.
Chapter 1. Product Overview

8| Kaye LTR-150 - Dry Block & Liquid Bath All-in-One Temperature Calibrator
1.3 Surface Temperature Function
The LTR-150 can also be used for surface temperature calibrations
by utilizing the optional surface temperature insert (PN: 412-3054).
The surface insert is hollow from the bottom and longer than the
adapter sleeve enabling fast and easy calibrations.
The surface temperature insert has a bored hole where the
control reference probe can be inserted which is directly beneath
the contact surface of the insert. This enables very accurate
measurement of the surface temperature. The insert is designed
for optimized homogeneity of the contact surface’s center while
enabling solid thermal contact.
The surface temperature insert is ideal for calibrating / verifying Flat Surface
ValProbes in the temperature range from -25°C to 150°C.
1.4 Calibration Modes
The LTR-150 was designed to offer flexibility and ease of use. To
accommodate these needs Kaye implemented two main modes or menu’s Remote Control mode and
Standalone mode.
Remote Control mode is intended for
Automatic Calibration utilizing Kaye
Validator equipment (Validator 2000,
Validator AVS, ValProbe and RF ValProbe).
In this mode, control of the LTR-150 and
the touchscreen interface is automatically
driven by the appropriate Kaye software.
In the Kaye software, the user configures
the set points, the stability criteria, and
deviation criteria. The user simply starts
the calibration from the Kaye software
and the control of the calibration is
automated. No additional interaction with
the touchscreen is required. The LTR-150
when powered on automatically boots
into the Remote Control screen.
The Standalone mode is intended again
to offer flexibility by allowing fully manual
configuration of the LTR-150 to define all
different kinds of parameters from different
types of sensors, ramp and soaks setups /
profiles to address other calibration needs.
For Standalone mode, refer to Chapter 7.
Manual Calibration and Chapter 8. Controls
for details the options and screen flows to
manually configure the LTR-150.
Chapter 1. Product Overview

9
M5101-EN Rev. B |
1.5 Contact Kaye Customer Service
You may contact our North American customer service team at (814) 834-9140 (FAX: (814) 781-7969). You
may also call our European headquarters in Germany at +49 (0) 7231-14335 0.
1.6 Calibration and Repair Information
To schedule and send the LTR-150 to Kaye for calibration or repair:
1. Contact the Kaye Service Center in your area to schedule the calibration or repair.
2. Utilize original packing box and carefully pack and secure the LTR-150.
3. Send the LTR-150 to the Service Center.
Chapter 1. Product Overview

10 | Kaye LTR-150 - Dry Block & Liquid Bath All-in-One Temperature Calibrator
Chapter 2. Safety Information
WARNING! A Warning identifies conditions and procedures that are dangerous to the user.
CAUTION! A Caution identifies conditions and procedures that can cause damage to the product or
equipment under test.
See Table 1 below for list of symbols used in this manual and on the LTR-150.
Table 1: Hazard Signs and Symbols
Before you install the LTR-150, read through this operating manual carefully. If the instructions
contained within it are not followed, the safety guidelines, this could result in danger for people,
the environment, and the device and the system it is connected to.
To guarantee that the device operates safely, the operator must act competently and be conscious of safety
issues.
General safety instructions:
In all work, the existing national regulations for accident prevention and safety in the workplace must be complied
with. Any internal regulations of the operator must also be complied with, even if these are not mentioned in this
manual.
Ensure that the complete operating instructions are always available in excellent condition at the calibrator installation
site.
Degree of protection per EN 60529: Ensure that the ambient conditions at the site of use does not exceed the
requirements for the stated protection rating.
Structural safety in accordance with EN 61010-1: The calibrator must be installed in such a way that the
requirements for structural safety are met.
Only use the LTR-150 if it is in perfect condition. Damaged or faulty devices must be checked without delay and, if
necessary, replaced. If problems cannot be cleared, immediately shut down the calibrator and ensure that it
cannot be started up accidentally.
Chapter 2. Safety Information

11
M5101-EN Rev. B |
Never leave the calibrator unattended when it is in operation or in the cooling phase.
Do not remove or obliterate type plates or other markings on the device, as otherwise the warranty is rendered null
and void.
Special Safety Instructions:
Thermal fuse! The calibrator is equipped with a temperature fuse that works independently. If there is an over-temperature
in the inside of the housing, the power supply to the heating system is cut off. The calibrator cannot then be started any
more.
After it has cooled, send the calibrator for inspection to Kaye.
Risk of injury from hazardous gases! When liquids are heated, the evaporation can result in dangerous gases being
formed.
The calibrator may not be used in an explosion-endangered atmosphere (ignitable or explosive atmosphere).
Remove all the easily flammable media from the vicinity of the calibrator.
Ensure that the calibrator cannot encounter easily flammable or explosive media.
Operate the calibrator only in the temperature range permissible for the test sample.
Ensure that the test sample is securely fixed in the calibrator.
Use only suitable adapter sleeves or calibration inserts. When doing so, also ensure that the
structural safety of the calibrator is retained.
IMPORTANT NOTICE!
Always unscrew the transport cover before putting the micro bath into service to avoid excessive
pressure.
Wait until the micro calibration bath has cooled down before screwing on the transport cover.
Further warnings that are specifically relevant to individual operating procedures or activities can be found at the
beginning of the relevant sections of this operating manual.
Micro Bath Calibration Safety Instructions:
Before using calibration liquids, read the entire safety data sheet attentively. Pay attention to the information on the
physical and chemical properties.
Only use calibration liquids that are suitable for the required temperature range and which are not flammable.
Always wear safety goggles for the eyes when handling calibration liquids.
Do not exceed the maximum fill level of the tub insert, which is below the fixture for the sleeve exchange tool.
Silicone oil:
Prevent silicone oil from meeting your eyes by always wearing safety googles.
Use only the silicone oil recommended here.
Always read the safety data sheet supplied with the silicone oil before using it.
Always ensure adequate ventilation when working with silicone oil, since hazardous substances can be released.
Spilled or leaked silicon oil results in extreme danger of slipping. Clean the affected area immediately by suitable
methods.
Since silicone oil is hygroscopic, always use the transport cover to close the calibration bath after use.
Chapter 2. Safety Information

12 | Kaye LTR-150 - Dry Block & Liquid Bath All-in-One Temperature Calibrator
Chapter 3. Specifications
Dry Block
Temperature Range* -30°C to 150°C -22°F to 302°F
Stability ±0.010°C ±0.018°F
Uniformity 0.1°C 0.18°F
Accuracy ±0.1°C ±0.18°F
Heating/Cooling time
20°C to -25°C 45 min
20°C to 121°C 30 min
121°C to 20°C
-30°C to 20°C
30 min
20 min
Micro Bath
Temperature Range* -30°C to 150°C -22°F to 302°F
Stability ±0.010°C ±0.018°F
Uniformity 0.15°C 0.27°F
Accuracy ±0.15°C ±0.27°F
Surface
Temperature Range* -25°C to 150°C -13°F to 302°F
Stability ±0.15°C ±0.27°F
Accuracy ±1°C ±1.8°F
Block Dimensions
Diameter 60 millimeters 2.36 inches
Depth 170 millimeters 6.69 inches
Display Unit
Display Unit
Brilliant Color (7”) Touchscreen
Viewing angle range 120° to 140°
Brightness 400 cd/m2
Unit °C/ °F/ °K
Resolution 0.1/ 0.01/ 0.001 °C/ °F/ °K
General Data
Interface
Serial to Validator
Ethernet
3 x USB
Dimensions
Width 210 millimeters 8.27 inches
Height 380 + 50 millimeters 14.96 + 1.97 inches
Depth 300 millimeters 11.81 inches
Weight (approximate) 15 kilograms 33 pounds
Power Supply 100 – 240 VAC, 50/60 Hz
Power Consumption Approximately 375 watts
* at an ambient temperature of 20°C (68°F)
Chapter 3. Specifications

13
M5101-EN Rev. B |
Chapter 4. Getting Started
4.1 Unpack and Inspect
All units have been carefully checked for their operational reliability before shipment.
Immediately after receipt, please check the outer packaging for damages or any signs of improper handling.
Report any possible damages to the forwarder and your responsible sales representative. In such a case,
state a description of the defect, the type and the serial number of the device. IMPORTANT NOTE: Report
any in-transit damage immediately. Damage reported later shall not be recognized.
Carefully unpack the unit to prevent any damage.
Check the completeness of the delivery based on the packing slip and/or purchase order.
The X0365 LTR-150 comes with the following components.
Item Description Quantity
1 LTR-150 1
26 ft. (2 meter) Mains Power Cord (US / EU 100 -240 VAC 50/60Hz) 2
3Dry Block Insert (for up to 48 thermocouples, 3 IRTD, & 1 Reference Probes 1
4Thermocouple Fixture 1
5Insert Transport Cover 1
6Insert Exchange Tool 1
7Extruded Sleeves for thermocouples (16) 16
8External Reference Control Probe 1
9USB to Serial Communications cable (connection to Kaye hardware) 1
10 Calibration Certificate 1
11 User Manual 1
Save the packaging!
The LTR-150 is delivered in special protective packaging.
• Save the packaging for returning the instrument safely to the manufacturer for recalibration or repair.
• Use the type plate to check if the delivered unit corresponds to your order request.
4.2 Placement
Ensure that the LTR-150 storage and operation conditions described below are met:
• Only suitable for indoor use, do not use outdoors.
• Operate only in the vertical position on an even surface. The surface must be stable, clean, and dry.
IMPORTANT NOTE: If the operation positions do not conform to what is described then the structural safety
andthespeciedpropertiesoftheLTR-150isnotguaranteed.
• Sufcientclearancearoundthemachine;greaterthan3feet(1meter)inthefrontand1.5feet(0.5meters)onthe
sidesandback.Sufcientheadclearanceandfreespaceabovethemachine.
• Sufcientventilationmustbeensured.
• Donotoperatenearammablematerials.
• The ventilation openings must not be blocked or covered.
• The machine must be installed in a manner so that it can be easily switched off at any time.
• Not suitable for applications with high vibration or possible contamination
Chapter 4. Getting Started

14 | Kaye LTR-150 - Dry Block & Liquid Bath All-in-One Temperature Calibrator
4.3 Connect to Main Power
Ensure the following before powering up the LTR-150:
• Ensure supply voltage is from 100- 240 VAC 50/60 Hz.
• Connect the LTR-150 only to a properly installed and grounded, three-pronged outlet.
• Do not use any extension cables or adapter plugs.
• Use only the original power cables supplied by Kaye or approved, like power cable.
IMPORTANT! “KILL” switch!
The plug of the mains connecting cable serves as a “KILL” switch.
• Ensure that the plug is always easily accessible and easy to reach.
• In an emergency, pull the plug, so that the machine is isolated from the mains.
4.4 LTR-150 Startup
PriortopoweringuptheLTR-150performthefollowingtasks;
• Unscrew the Insert Transport Cover exposing the Dry Block Insert.
• Connect the External Reference Probe to the connector marked “ext Ref” on the front panel
and insert into the dry block using one of the 2 holes sized specifically for the Reference Control
Probe.
Power On the LTR-150 by utilizing the Power Switch on the front panel
Once powered on, the Kaye LTR-150 splash screen will appear for approximately thirty seconds followed
briefly by the model and firmware version before presenting the Remote Control home screen.
Chapter 4. Getting Started

15
M5101-EN Rev. B |
Since the LTR-150 will predominately be used for automatic calibration with Kaye validation equipment, the
unit will automatically boot into the Remote Control screen with the following default settings:
Refer to the below sections to change the default settings. To access these parameters, click on the cancel
icon in the upper right-hand corner, this will bring up a new screen with the following three options: End
Remote Control, Switch Off, and Cancel. Tap on End Remote Control, which will take you to the Standalone
home screen. Next, tap on the tools icon in the upper left hard corner to bring up the Calibrator Setup
home screen.
•Mode: Remote Control mode
•Function: Dry Block
•Control Temp: External Reference Probe
•Temp. Controller OFF
•Language Selection: English
•Date and Time MM.DD.YYYY and 24th
•Temperature Units: Celsius
•Decimal Places: 0.00
•Cutout Temperatures: -30.0 to 150.0
Chapter 4. Getting Started

16 | Kaye LTR-150 - Dry Block & Liquid Bath All-in-One Temperature Calibrator
4.4.1 Set Screen Brightness
You can modify the screen brightness (100% default) by tapping on the Display Settings
calculator icon then choose Brightness on the Set Display window.
Enter the desired value (1 through 100) for screen brightness on the numeric keyboard.
Confirm selection by touching the check mark icon to save the change and then the
to return to the Calibrator Set Up window.
4.4.2 Set Language Selection
Select Language selection from the Calibrator Set Up window by touching the world
icon. The current language is indicated in the information box on the left while all installed
languages can be seen in the selection list on the right.
Select the desired language by tapping the desired language.
Confirm selection by tapping on the check mark icon in the lower right of the screen,
which will then return you to the Calibrator Set Up window.
4.4 3 Set Date and Time
Select Date and Time from the Calibrator Set Up window. Options are available to change
the date and time format.
By tapping the respective field, a window is opened for the input/change.
Make the necessary adjustment then touch the check mark icon to save the change and
then the to return to the Calibrator Set Up window.
4.4.4 Set Temperature Units
By tapping on the thermometer icon, a temperature unit selection list appears providing you
with the option to choose between Celsius, Fahrenheit, and Kelvin.
Touch the desired temperature unit, which will then be identified by a check mark.
Confirm selection by touching the check mark icon to save the change and return you to
the Calibrator Set Up window.
4.4.5 Set Decimal Resolution
You can define the format of the temperature values in the windows by tapping on the
pencil and ruler icon.
Touch the desired temperature precision, which will then be identified by a check mark.
Confirm selection by touching the check mark icon to save the change and return you
to the Calibrator Set Up window.
Chapter 4. Getting Started

17
M5101-EN Rev. B |
4.4 6 Switching Modes (Remote Control / Standalone)
To switch to Remote Control mode from the Standalone Main mode simply tap the
Validator icon.
To switch to Standalone mode from Remote Control mode, click on the cancel X icon in
the upper right-hand corner. A new window will display with the following three options: End
Remote Control, Switch Off, and Cancel. Tap on End Remote Control, which will take
you to the Standalone home screen.
4.4.7 Powering Off
To power off the unit from Remote Control screen, tap on the cancel X icon in the upper
right-hand corner then Switch Off. A Switch Off Calibrator screen will appear with a
temporary message stating, “system data are saved – please wait” eventually followed by
another message “you can now turn off the calibrator” at which point you can flip the switch
in the front of the unit.
To power off from Standalone screen, tap on the power icon in the upper right-hand corner
and follow prompts as listed above.
Note: If the temperature value is greater than 40°C then a message will appear stating,
“calibrator is reaching safe temperature – please wait.” Once the value drops below
40°C then a new message will appear informing that “you can now turn off the
calibrator.”
Chapter 4. Getting Started

18 | Kaye LTR-150 - Dry Block & Liquid Bath All-in-One Temperature Calibrator
Chapter 5. Preparing for Calibration
5.1 Selecting LTR-150 Function
The LTR-150 is supplied standard with a dry block insert. To utilize the optional micro bath or surface
temperature functions, the inserts must first be changed and the appropriate Function defined via the
touchscreen.
Insert the appropriate insert based on the calibration function required.
Each measuring insert has its own characteristic values, which are defined at the factory. These characteristic
values are influenced by different factors, such as: diameter, type and material of the measuring insert,
number and diameter of the bore holes or the physical properties of the calibration liquid.
CAUTION! Risk of burns!
The calibrator can become very hot when in operation. Touching hot parts can result in serious burn
injuries.
Never touch the metal block, the tank, the adapter sleeve or the test sensors at temperatures above
35 °C or below 10 °C.
Allow the calibrator to cool to ambient before removal or insertion of any insert.
Always power off unit and clean the tank and the desired insert before insertion.
______________________________________________________________________________
Chapter 5. Preparing for Calibration

19
M5101-EN Rev. B |
5.1.1 Dry Block
Removal:
Let the calibrator cool before you remove the dry block insert.
Unscrew the black protective cover by first placing the prongs of the insert exchange tool
into the holes of the cover. Apply pressure against the prongs then turn counterclockwise
to loosen the cover. Once loosened, the insert exchange tool can be removed and you
can unscrew the insert by placing a single finger from both hands against opposite sides of
the insert and pushing counterclockwise. Continue rotating insert until its top can be
securely held by your hand then continue unscrewing with one hand.
If moisture is present on the inside of the well following insert removal, then gently clean with
a dry cloth.
Place the prongs of the insert exchange tool into the holes of the dry well insert. Apply
pressure against the prongs by grasping each side of the insert exchange tool, stretch apart,
and slowly lift upwards.
If moisture is present on the sides of the dry well insert following its removal, then gently
clean with a dry cloth then turn dry well insert upside down to remove any moisture residing
within the wells.
Clean the dry block insert walls as well as the walls of the metal block. This prevents the
inserts from getting stuck in the metal block.
Installation:
Let the calibrator cool before you install the dry block insert.
Insert the dry block insert into the metal block with the help of the insert exchange tool.
Utilize the insert exchange tool, to screw in the black protective cover which sits above the
dry block insert.
Chapter 5. Preparing for Calibration

20| Kaye LTR-150 - Dry Block & Liquid Bath All-in-One Temperature Calibrator
5.1.2 Thermocouple Fixture:
The LTR-150 comes standard with a Thermocouple (TC) Fixture. The Thermocouple Fixture is used
with the dry block to ensure that all thermocouples are securely held at the full immersion depth of the
dry block inserts to ensure accurate calibrations. The Thermocouple Fixture set contains thermocouple
housing with an integrated metal holder, a transparent cover, and three knurled head screws to hold the
cover in place.
1. Transparent cover.
2. Three knurled head screws.
3. Thermocouple housing.
4. Integrated metal holder.
Installation:
LetthecalibratorcoolbeforeinstallingtheTCfixture.
ScrewtheTChousingontothedryblockthread.Pleasedonotovertighten!
Usage:
Place the thermocouple into the dry block,
route it through the accessible notch and
move the metal holder to fix the position.
Move to the next accessible notch until all
thermocouples are fixed.
Place the transparent cover on the fixture and
secure it with the three knurled knob screws.
Place the External Reference sensor and Kaye
IRTD in the dry block using the holes in the
transparent cover.
Removal of Thermocouples:
Remove the IRDT and sensors and the three knurled knob screws.
Remove the transparent cover.
Remove the metal holder by bending it slightly out of its bed in the fixture.
It is now possible to remove all thermocouples at once.
Chapter 5. Preparing for Calibration
Table of contents
Popular Measuring Instrument manuals by other brands

Cinematography Electronics
Cinematography Electronics AIR Mobile2 operating instructions

Galvanic Applied Sciences
Galvanic Applied Sciences 943-TGX-CE Operation manual

Watts
Watts U-M311 user guide

Boumatic
Boumatic TouchPoint OPERATION, SERVICE AND MAINTENANCE INSTRUCTIONS

Agilent Technologies
Agilent Technologies N9010A Configuration guide

Quantronix
Quantronix CubiScan 125 Service manual
