KCL OSM ATN260071A User manual

Organized Storage Modules

www.kcl.no www.kcl.no
Organized Storage Modules
1. Unpacking:
˙ When unpacking the units, please ensure the unit is at up position.
˙ Please do not use sharp point tools for unpacking
˙ After unpacking unit, inspect carefully for any damage that may have occurred during transit.
Check for loose, missing, or damage parts before assembly.
2. Assembly Tool Request:
You might need following tools to assemble OSM:
˙ 1/4” Dr. T-handle / 1/4” Dr. Ratchet handle /1/4” Dr. Power Impact Wrench
˙ 1/4” Dr. Socket 10mm & 12mm
˙ Combination Wrench 10mm & 24mm
˙ Phillips Screwdriver PH2
˙ Spirit Level
Before Assembly
Exploded Drawing
No. Description
1 Cabinet
2 Worktop
3 Back Panel
4 Support Bracket (Right)
5 Cupboard
6 Support Bracket (Middle)
7 Support Bracket (Left)
8 Bottom Side Panel for Cabinet
9 Bottom Front Panel
10 Bottom Side Panel for Tall Cabinet
10
9
7
4
3
2
1
8
6 5
2 3

www.kcl.no www.kcl.no
Organized Storage Modules
person to walk through for following steps.
1. Apply 6pcs Hex Bolt M6 Screw (a) on back side of the cabinet. Do not tighten the Hex Bolt
M6 Screw (a). Have about 3-5 screw thread left.
May use Spirit Level to adjust the adjustable feet of cabinet to ensure cabinets are at the
same level.
2. Apply the Support Bracket (4, 6, 7) on to it as below diagram. Apply the Support Bracket
onto correct location as marked below. Please note Right/Left Support bracket position.
(a)
Step 1 Step 2
4 6 6 7
4 5

www.kcl.no www.kcl.no
Organized Storage Modules
right position.
1. Apply 2 pcs Phillips M6 Screw (b) on the top of the Support Bracket. Do not tighten the
Screw (b) completely. Have about 3-5 screw thread left.
2. Lift and hook the Cupboard (5) to the Phillips M6 Screw (b) on the Support Bracket.
3. Tighten completely the top screws and apply remaining 2 pcs Phillips M6 Screw (b) from
inside the Cupboard (5) to the Support Bracket to secure the structure.
Step 3 Step 4
(b)
6 7

www.kcl.no www.kcl.no
Organized Storage Modules
Tighten the screw on the cabinet and push whole station to desired location.
This might need 3-4 people to work together.
Use Phillips M6 Screw (b) and Nut to link between the 2 Cupboard and Tall Cabinet.
Step 5 Step 6
8 9

www.kcl.no www.kcl.no
Organized Storage Modules
Apply Bottom Front/Side Panel with screw and washer as below diagram.
Step 7 Step 8
10 11

www.kcl.no www.kcl.no
Organized Storage Modules
Congregations! The workstation is successfully installed!
Step 9
26"/ 34" Cabinet 26"/ 34" Closet
26"/ 34" Cabinet
3 Drawer with Door
I/N SIZE (mm)
KCL ATN260071A W677 x D500 x H954
KCL ATN340071A W861 x D500 x H954
I/N SIZE (mm)
KCL ATN260001 W677 x D500 x H954
KCL ATN340001 W861 x D500 x H954
I/N SIZE (mm)
KCL ATN261031A W677 x D500 x H954
KCL ATN341031A W861 x D500 x H954
26" Roller Cabinet
I/N SIZE (mm)
KCL ATT260071A W677 x D459 x H994
KCL ATT340071A W833 x D459 x H994
Corner Cabinet
I/N SIZE (mm)
KCL
ATN30001A
W883 x D883 x H954
26" Recycle Bin Cabinet
26"/ 34" Wash Tank
Closet
34" Reel Cabinet
I/N SIZE (mm)
KCL ATN260012 W677 x D500 x H954
I/N SIZE (mm)
KCL ATN2600SI1 W677 x D500 x H954
KCL ATN3400SI1 W861 x D500 x H954
I/N SIZE (mm)
KCL ATN3400AGW W861 x D500 x H954
12 13

www.kcl.no www.kcl.no
Organized Storage Modules
I/N Width (mm) Applied for
KCL N005-03 1725 34"+34"
KCL N005-04 1541 26"+34"
KCL N005-07 2404 34"+34"+26"
KCL N005-08 1357 26"+26"
KCL N005-09 2220 26"+26"+34"
KCL N005-11 2588 34"+34"+34"
KCL N005-12 2036 26"+26"+26"
I/N Width (mm) Applied for
KCL S005-03 1725 34"+34"
KCL S005-04 1541 26"+34"
KCL S005-07 2404 34"+34"+26"
KCL S005-08 1357 26"+26"
KCL S005-09 2220 26"+26"+34"
KCL S005-11 2588 34"+34"+34"
KCL S005-12 2036 26"+26"+26"
Wooden Worktop Stainless Worktop
Impact Socket Holder
Impact Wrench Holder
I/N SIZE (mm)
KCL MAA034 W150 x D30 x H50
I/N SIZE (mm)
KCL MAA011A W115 x D91 x H121
L Type Support Bracket
for Worktop
I/N SIZE (mm)
KCL P-SBL-01 W498 x D40 x H40
26"/ 34" Document Shelf 26"/ 34" Box Rack
ITEM NO. SIZE(mm)
KCL N007-1 W644 x D246 x H91
KCL N007-2 W834 x D246 x H91
ITEM NO. SIZE (mm)
KCL N008-1 W676 x D18 x H78
KCL N008-2 W860 x D18 x H78
Bottom Side Panel
for Cabinet
Bottom Side Panel for
Wall Cabinet
I/N SIZE (mm)
P-MST-01 W472 x D10 x H90
I/N SIZE (mm)
P-MST-02 W498 x D10 x H90
Tool Hanger
I/N Lengh
KCL P-TH001 1.5"
KCL P-TH001 4"
Shelf for 24" Wall Cabinet
I/N SIZE(mm)
KCL P-MST-03 W524 x D476 x H13
Shelf for 26" Closet
I/N SIZE (mm)
KCL P-MST-04 W601 x D464 x H13
Shelf for Corner Cabinet
I/N SIZE (mm)
KCL P-MST-05 W372 x D853 x H13
W538 x D853 x H13
26"/ 34" Cupboard
I/N SIZE (mm)
KCL ACN260001A W677 x D300 x H342
KCL ACN340001A W861 x D300 x H342
Wall Tool Panel with
Shutter
I/N SIZE (mm)
KCL AB68001 W1722 x D150 x H1025
26"/ 34" Perforated Panel
I/N SIZE (mm)
KCL N001 W677 x D20 x H342
KCL N002 W861 x D20 x H342
Support Bracket
I/N SIZE (mm)
KCL N003-RL W90 x D30 x H2000
KCL N003-M W146 x D30 x H2000
24"/ 44" Wall Cabinet
I/N SIZE (mm)
KCL ATN240001 W600 x D525 x H1982
KCL ATN440001 W1120 x D525 x H1982
14 15
