Keith CleenSweep Manual User manual

CleenSweep®- Manual (CSM)
WALKING FLOOR®International
www.WalkingFloorService.ca
Canada
Brantford, ON
Toll-Free: 800-514-6085
Phone: [phone]
KEITH Manufacturing Co.
www.KeithWalkingFloor.com
World Headquarters
Madras, OR
Toll-Free: 800-547-6161
Phone: [phone]
INSTALLATION / OWNER’S MANUAL
& PARTS CATALOG
Original Instructions
©2022 KEITH Manufacturing Co. All Rights Reserved. KEITH, KEITH logo and WALKING FLOOR are registered trademarks of KEITH
Manufacturing Co. Equipment manufactured by KEITH Manufacturing Co. is protected by numerous patents both domestic and foreign.
DOC06950 Rev. AReleased: 2022-12-12

i DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
Table of Contents
Introduction iii
CleenSweep®Tarp System Limited Warranty iv
Warranty Registration Card v
1.0 Safety 1
1.1 General Safety 1
1.1.1 Intended Function and Expected Use: 1
1.1.2 Improper Use 1
1.1.3 Training 1
1.1.4 Personal Protective Equipment 1
1.2 Design / Installation Safety 1
1.2.1 Controls 1
1.3 Marking of Machinery 2
1.3.1 Safety Decals 2
2.0 Specications 3
2.1 System 3
2.2 Component Identication 4
3.0 Installation 5
3.1 Strap Roller Mounting Position Options 5
3.2 Winch & Strap Roller Installation 6
3.2.1 Winch Installation Below Slope Shield 6
3.2.2 Strap Roller Assembly Installation Near Top of Front Wall 8
3.2.3 Strap Roller Assembly Installation Under Front Tarp Header 9
3.2.4 Option for High Density or High Flow Materials 10
3.3 Tarp Assembly, Installation & Adjustment 11
3.4 Tarp Modications for Bullnose Trailer 15
3.5 Tarp Modications for V-Floor Trailers 16
3.6 Optional - Tarp Catch Hooks 16
4.0 Step by Step Instructions 17
5.0 Winch Brake Adjustment - Wedge Brake 29
6.0 Operation 30
7.0 Troubleshooting 32
7.1 Check List 32
7.2 Problem / Solution - Troubleshooting 32
8.0 Parts Catalog 33
Winch Assembly 33
Strap Roller Assembly 36
Tarp & Misc Components 37

ii DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
9.0 Technical Support 38
10.0 Contact Information - KEITH Manufacturing Co. 38
11.0 Crank Handle Mounting Plate Template 39

iii DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
Introduction
This manual explains procedures for installing and operating the KEITH®Manual CleenSweep®Tarp System.
Many variables a󰀨ect the installation, but the general process remains constant. Details of the installation vary,
according to trailer features and installer preferences.
An e󰀩cient installation requires appropriate tools and accessible materials that are not supplied with this kit.
It is strongly recommended that the installers and operators read this entire manual before beginning
the installation or operating of the system.
Please direct any questions to KEITH Manufacturing Co., one of our international o󰀩ces listed in the contact
information section of this manual, or on our website.
WARNING: Always disconnect hydraulic and electric power to the trailer and follow lock out/tag
out safety procedures before entering the trailer or working on the CleenSweep®Tarp System
components. Failure to do so may result in serious injury or death.
IMPORTANT: Installing the CleenSweep®Tarp System requires some alterations to your trailer. Changes
made without the approval of the trailer manufacturer may void the trailer’s warranty.

iv DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
CleenSweep®Tarp System Limited Warranty
This CleenSweep®Tarp System is warranted to the original purchaser to be free from defects in material and
workmanship under normal use for a period of one year from the date of purchase. During the warranty period,
and upon proof of purchase, the CleenSweep®Tarp System will be repaired or replaced with the same or similar
model.
IT IS EXPRESSLY AGREED THAT THIS SHALL BE THE SOLE AND EXCLUSIVE REMEDY OF
THE BUYER. UNDER NO CIRCUMSTANCES SHALL KEITH MANUFACTURING CO. BE LIABLE
FOR ANY COSTS, LOSS, EXPENSE, DAMAGE, SPECIAL DAMAGES, INCIDENTAL DAMAGES,
OR CONSEQUENTIAL DAMAGES ARISING DIRECTLY OR INDIRECTLY FROM THE USE OF THE
CLEENSWEEP®TARP SYSTEM. WHETHER BASED UPON WARRANTY, CONTRACT NEGLIGENCE
OR STRICT LIABILITY.
THE WARRANTY AND LIMITS OF LIABILITY CONTAINED HEREIN ARE IN PLACE OF ALL OTHER
WARRANTIES AND LIABILITIES, EXPRESSED OR IMPLIED. ALL IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY DISCLAIMED
BY KEITH MANUFACTURING CO. AND EXCLUDED FROM THIS WARRANTY. FURTHER, KEITH
MANUFACTURING CO. DOES NOT WARRANT THAT THE CLEENSWEEP®TARP SYSTEM
COMPLIES WITH LOCAL, MUNICIPAL, STATE OR FEDERAL CODES, IF ANY AND THE BUYER
ALONE IS RESPONSIBLE FOR ANY KNOWLEDGE OF ANY COMPLIANCE WITH ANY SUCH
CODES.
This warranty shall not apply to any parts that; (a) have been repaired or altered outside of the CleenSweep®
Tarp System; (b) have been subjected to misuse, negligence or accident; or (c) have been used or installed in a
manner contrary to CleenSweep®Tarp System instructions.
In certain circumstances some states do not allow the exclusion or limitation of incidental damages, some or all
of the above limitations or exclusions may not apply to you. This warranty gives you specic legal rights and you
may have other rights that vary from state to state.
If this warranty violates law: To the extent any provision of this warranty contravenes the law of any jurisdiction,
that provision shall be inapplicable in such jurisdiction and the remainder of the warranty shall not be a󰀨ected
thereby.
Notice: To validate all warranties, a warranty registration card must be completed and returned to KEITH
Manufacturing Co. within ten days of purchase. If you did not receive a warranty registration card, contact
your dealer immediately.

v DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
Warranty Registration Card
Note: To validate the warranty, the registration information must be lled out completely and returned to KEITH
within ten (10) days of purchase and/or installation.
Please ll out the Warranty Registration form on our website at www.KeithWalkingFloor.com or ll out the
Warranty Registration Card below and mail or email it to:
KEITH Manufacturing Co.
P.O. Box 1
Madras, OR 97741-0001
[e-mail]
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
This warranty registration card must be completed and on le at KEITH in order for the warranty period to
begin on the purchase date. If no purchase date is registered, the beginning of the warranty will automatically
revert to the manufacture date.
Name / Company Name: ___________________________________________________________________
Address: ________________________________________________________________________________
City, State / Prov.: _____________________________________________ Postal Code: ________________
Country:________________________________________________________________________________
Phone: _________________________________________________________________________________
E-Mail: _________________________________________________________________________________
SYSTEM DATA:
Date of Purchase: ________________________________________________________________________
Model / Serial Number: ____________________________________________________________________
Purchased From: ________________________________________________________________________
Type of Material Loaded/Unloaded: __________________________________________________________
I have fully read the KEITH Manufacturing Co. warranty information and fully understand and agree to the
terms of the warranty.
Name: _______________________________ Date: __________ Signature: __________________________

1 DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
1.0 Safety
1.1 General Safety
1.1.1 Intended Function and Expected Use:
1.1.1.1. The KEITH®CleenSweep®system is a winch system primarily intended to restage clean
out systems used in live oor trailers. The system is supplied as a kit primarily intended for
installation into mobile trailers or truck bodies. It is manually operated.
1.1.2 Improper Use
1.1.2.1. This equipment has been manufactured utilizing state-of-the-art technology in accordance
with acknowledged safety regulations. Nevertheless, dangerous situations could arise
from improper use, which could endanger life and limbs of personnel and cause damage
to the equipment and other assets. This equipment may only be used for its intended
purpose. It may only be operated in impeccable technical condition and in accordance
with the proper use and this user manual. Problems, which could a󰀨ect safety, must be
resolved immediately. The manufacturer is not liable for any damage caused by improper
use or arbitrary modications. The installation, commissioning, operation, and maintenance
instructions must be followed as outlined in this manual.
1.1.2.2. Personnel must not enter the danger zone(s) when the system is enabled. Specically,
nobody should be inside, under, or behind the trailer in the unloading zone during operation.
Additionally, no one should be in a full or lling trailer. Lock-out and tag-out procedures must
be followed before accessing the drive area.
1.1.2.3. Safeguards must not be altered or bypassed.
1.1.2.4. The user and system designer must understand the characteristics and safe handling
requirements of the material that is being conveyed.
1.1.2.5. Bulk materials are by nature unstable and owable. Avoid burial by avoiding contact with the
material.
1.1.3 Training
1.1.3.1. Operators must read and understand this manual before operating or maintaining the
machine. Only qualied, trained personnel may execute commissioning, operation, and
maintenance of the system.
1.1.4 Personal Protective Equipment
1.1.4.1. Always wear protective equipment appropriate for risks associated with each phase of
the system’s life, including transportation, installation, assembly, operation, inspection,
maintenance, and dismantling, disabling, and scrapping. As a minimum, this includes the
following personal protective equipment:
• Safety Glasses • Protective/Traction Shoes
• Gloves • Welding/Grinding Protection
• Helmets • Thermal Protection (i.e. Coats)
• Hearing Protection
1.2 Design / Installation Safety
1.2.1 Controls
1.2.1.1. The control panel must be located such that it is easily accessible for all sizes and capacities
of people, and allows the operator to move freely (whenever applicable).
1.2.1.2. Control devices must be located outside of danger zones, such that any exposed persons in
danger zones are visible from the control station.
1.2.1.3. An acceptable means must be provided to monitor the status and movement of the load.

2 DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
1.3 Marking of Machinery
1.3.1 Safety Decals
KEITH Manufacturing Co. www.KeithWalkingFloor.com Rev B

3 DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
Worded
Old - 2019
Wordless
2020 - Future Description
Rotating parts and shaft can cut or entangle
causing serious injury. Stay clear when in
operation. Lockout/tagout before servicing.
KEITH CleenSweep Tarp System
Remove handle when not in use and store in
secure compartment when traveling.
* Some or all of these safety decals may apply and be adhered to this system.
2.0 Specications
2.1 System
Manual CleenSweep®
Dimensions 7.25”W x 10.5”H x 9.25”D [184 mm x 267 mm x 235 mm]
Weight 25 lbs [11 kg]

4 DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
2.2 Component Identication
Strap Roller
Tarp Pipe
Tarp Header Not shown
Front Bulkhead Wall
of Trailer
Winch Assembly
Front Slope Shield
Floor Slats
Tarp Assembly
Removable
Crank Handle

5 DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
3.0 Installation
3.1 Strap Roller Mounting Position Options
Guide Rails/Skis - short
Tarp Header
Strap Roller - attached
to tarp header
Strap Roller - attached
to top of front wall
Winch - under slope shield
High Front Wall Mount
Cap Plate Mount with Guide Rails/Skis
Winch - under slope shield

6 DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
WARNING: Always disconnect hydraulic and electric power to the trailer and follow lock out/tag
out safety procedures before entering the trailer or working on the CleenSweep®Tarp System
components. Failure to do so may result in serious injury or death.
3.2 Winch & Strap Roller Installation
Winch mounted on front wall below front slope shield and strap roller mounted near top of front wall.
3.2.1 Winch Installation Below Slope Shield
NOTE: Front wall of trailer may need to be reinforced to withstand the forces created by the winch.
1. Locate and mark a centerline up the front wall of the trailer. NOTE: It is crucial that strap roller
and the roll of strap on the winch is mounted in the absolute center of the trailer. If the winch is
not mounted square, it will put uneven pressure on the tarp strap and the system will not function
properly.

7 DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
2. The winch must not interfere with the operation of the oor slats, and there should be a 1” [25mm]
minimum clearance between the winch and slats. Ensure all moving parts of the winch and oor have
adequate clearance. Measure 4” [102 mm] up from the top of the oor slats to locate the bottom of the
mounting plate.
A. WELD ATTACHMENT: Remove the
winch mounting plate from the winch
assembly, center on the front wall and
weld. Then re-attach winch assembly to
mounting plate using the (4) M10 bolts.
B. BOLT ATTACHMENT: Transfer the winch
mounting plate mounting bolt hole pattern
to the wall and drill (2) 17/32” [13 mm] bolt
clearance holes. Then attach the entire
winch assembly to the trailer wall using
(2) 1/2” grade 8+ [M12 class 10.9+]
locking fasteners (not included).
3. Front shield modication: It is recommended that the front shield be hinged or tted with a door/panel to
gain access to the winch after it is installed to facilitate adjustment, inspection and maintenance.
4. An opening must be cut into the front Slope Shield and a UHMW strap guide installed for the strap to
pass through. The opening must be centered along the path of the strap from the winch to the strap roller
assembly.

8 DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
3.2.2 Strap Roller Assembly Installation Near Top of Front Wall
NOTE: Front wall of the
trailer may need to be
reinforced to withstand
the forces created by the
winch.
1. Locate the centerline at the top of the front wall of the trailer.
2. Measure down a minimum of 1-1/2” [38 mm] from the top to locate the strap roller mounting
bracket.
3. Center the strap roller bracket with the two mounting holes toward the top of the wall and weld
in place or transfer the strap roller bracket bolt pattern to the wall and drill (3) 7/16” [11 mm] bolt
clearance holes.
4. Attach the strap roller to the front wall using (3) 3/8” grade 5+ [M10 class 8.8+] locking fasteners.

9 DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
3.2.3 Strap Roller Assembly Installation Under Front Tarp Header
If the trailer has any obstacles on the front wall, such as broom/shovel hooks, or man door handles/hinges,
then tarp guide rails/skis will need to be fabricated and installed. Guide rails/skis guide the tarp away from
the front wall to avoid contact with these obstacles, thus preventing possible tarp damage. Also, the strap
roller will need to be attached under a Front Tarp Header and in line with the guide rails/skis to allow the
tarp to hang straight down and against the ski/guide rails.
NOTE: Front wall of the trailer
and cap plate may need to
be reinforced to withstand the
forces created by the winch.
1. Locate and mark the centerline of the cap plate.
2. Locate the strap roller bracket far enough out from the front wall so that the tarp will hang straight
down along the outside of the tarp guide rails when it is fully retracted. (See image)
3. Center the strap roller bracket with the two mounting holes toward the rear of the trailer and weld
in place or transfer the strap roller bracket bolt pattern to the wall and drill (3) 7/16” [11 mm] bolt
clearance holes.
4. Attach the strap roller to the cap plate using (3) 3/8” grade 5+ [M10 class 8.8+] locking fasteners.
Metal Cap
Front Trailer
Bulkhead Wall

10 DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
3.2.4 Option for High Density or High Flow Materials
A. High Sided Trailer with Sloped Cap Plate:
• Prevents material from getting behind the tarp while loading and from getting stuck on top of
cap plate.

11 DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
3.3 Tarp Assembly, Installation & Adjustment
Please note that pipes, strips and fasteners are not supplied by KEITH Manufacturing Co. For the
top pocket, located at the top of the tarp when fully retracted and hanging, (1) 2” [50 mm] diameter
lightweight metal conduit pipe is recommended. For all other pockets, use 1-1/2” [40 mm] diameter
lightweight metal conduit pipes or 1/4” x 3” [6 mm x 76 mm] UHMW plastic strips.
1. Cut the pipes/strips approximately 2” [50 mm] shorter than the inside width of the trailer. Take this
measurement just above the trailer oor, at the trailer’s narrowest point.
2. If the tarp is wider than the width of the trailer, cut the tarp to the same width as the inside of the
trailer. Remove half of the material from each side of the tarp.
Note: If you are installing the tarp into a trailer with a V-Floor®system or into a bullnose trailer, the tarp
will need to be wider than the inside of the trailer because the tarp will conform to the ridges on the
oor or the nose of the trailer. See Tarp Modications for V-Floor Trailers for additional instructions.
If using Pipe in lower pockets:
C. With the tarp laying down on the oor of the trailer, center the 2” [50 mm] pipe in the top pocket
of the tarp which has the notch cut out in the center. On the top side of the pipe drill (4) holes
through the tarp and pipe and install rivets (not supplied) to hold the pipe in place.
D. Center the smaller diameter pipes in the lower pockets of the tarp. On the top side of the pipes
drill (4) holes through the tarp and pipes and install rivets (not included) to hold the pipes in
place.
2” [50 mm] light
weight metal
conduit pipe
(2) 1-1/2” [38 mm] light
weight metal conduit pipes
(4) Rivets per pipe
installed from the top
Handles on
top of tarp
Cut half the material
from each side equally!

12 DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
If using UHMW strips in lower pockets:
2” [50 mm] light
weight metal
conduit pipe
(2) 1/4” x 3” [6 mm x 76 mm]
UHMW plastic strips
(4) sets of bolts,
washers & nylock nuts
or rivets & washers per
UHMW strip installed
from the bottom
Handles on
top of tarp
Cut half the material
from each side equally!
Nylock Nuts
Flat Washers
Flanged Button
Head Bolts
OR
Dome Head Bolts
Large Flanged
Dome Head Rivets
Bolts or Rivets
installed from the
bottom so nothing
sharp scrapes or
catches on the
oor!
Flanged Button Head or
Dome Head Bolt
Large Flanged Dome
Head Blind Rivet
(4) Rivets installed
from the top

13 DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
A. With the tarp laying down on the oor of the trailer, center the 2” [50 mm] pipe in the top pocket of the
tarp which has the notch cut out in the center. On the top side of the pipe drill (4) holes through the
tarp and pipe and install rivets (not supplied) to hold the pipe in place.
B. Center the UHMW strips in the lower pockets of the tarp. Drill (4) holes completely through the tarp
and UHMW strips. Use bolts with washers and nylock nuts (not supplied) or use rivets with washers
(not supplied) to keep the UHMW strips in place. Bolts or Rivets should be installed from the bottom
so nothing sharp scrapes or catches on the oor.
3. Find the center of the top pipe when the tarp is in the hanging position. Drill (2) 3/8” [9.5 mm] holes,
evenly spaced, through the top pipe to attach the U-bolt. It must be centered and installed so that when
the tarp is hanging from the winch, the threads of the U-bolt are facing downward. If necessary, you can
make the notch in the tarp wider in the middle to accommodate the U-bolt.
4. Lay the tarp in the rear of the trailer, with the handles on top of the tarp and the 2” [50 mm] top pipe
resting inside of the trailer about 12”-24” [305-610 mm] (depending on type of material being unloaded)
making sure it is not past the ends of the slats when they are retracted to the front. This will be where
the tarp stops during unloading with the rest of the tarp hanging o󰀨 the back of the trailer.
5. Release the winch strap brake and thread the strap through the strap guide on the winch, through the
UHMW strap guide in the front shield and through the strap roller. Pull (unwind) all of the loose strap
completely o󰀨 of the winch, so the attachment screws are visible, and stretch it out past the end of the
trailer, making sure that the strap is not twisted.
6. Cut the strap o󰀨, leaving enough strap to wrap loosely around the top pipe 3 times, pull tight and tighten
the U-bolt to hold the strap securely in place. This will keep the top pipe of the tarp from falling out of
the trailer when the strap is fully extended.
Strap Fully
Extended
U-Bolt
Align centerline of tarp
with centerline of top pipe
Drill (2) 3/8” [9.5 mm]
holes through the top pipe
for mounting the U-bolt
Wrap the end of the strap
around the top pipe (3x)
and secure it to the pipe
using the U-bolt assembly.

14 DOC06950 Rev. A
INSTALLATION / OPERATION & PARTS CATALOG CleenSweep®- Manual (CSM)
7. Retract the tarp assembly completely so that the U-bolt is back to the strap roller. Cut the tarp to length
leaving a minimum of 12”-14” [305-356 mm] of tarp on the oor covering the slats. Too much tarp on
the oor and the tarp will get caught in the unloaded material and be di󰀩cult to remove. Too little tarp
on the oor and it won’t move along with the load and sweep cleanly. Additional tarp on the oor (36”-
48” [914-1219 mm]) may be needed if the material being unloaded is very light weight (low density).
Minimum
12” - 14”
[305 - 356 mm]
Top of Tarp - Retracted
