Kendall howard Esdc-7836-1000 User manual

Page | 1

Save This Manual for Future Reference

The Answer is Yes! What’s the Question?™

Owner’s Manual

Part Number ESDC-7836-1000 & ESDC-7836-2000

For Your Safety

Read and understand the entire manual before use

ESD CABINET

Page | 2

Save This Manual for Future Reference

TABLE OF CONTENTS

Contents

SUPPORT..............................................................................................................................................................2

DISCLAIMER ..........................................................................................................................................................2

DIMENSIONAL DRAWING ......................................................................................................................................3

SPECIFICATIONS.....................................................................................................................................................3

INDIVIDUAL REPLACEMENT COMPONENTS ...........................................................................................................3

COMPONENT IDENTIFICATION...............................................................................................................................4

INSTALLATION AND SETUP ....................................................................................................................................5

CABINET USE..........................................................................................................................................................6

CARE AND CLEANING.............................................................................................................................................7

TROUBLESHOOTING...............................................................................................................................................8

WARRANTY............................................................................................................................................................9

Support

Support is available through the following methods:

By Phone from 8:00 AM to 5:00 PM CST. 651.213.1333

By Email c[email protected]

By Mail 10152 Liberty Lane, Chisago City, MN 55013

By Web www.kendallhoward.com

Disclaimer

DISCLAIMER: Kendall Howard LLC. endeavors to make this manual accurate and complete. However, Kendall

Howard LLC makes no representations or warranties of any kind, expressed or implied, about whether the use of

products contained herein would infringe any rights or the correctness, accuracy or reliability of the information

contained herein or that said information covers all details, conditions, or variations. The information herein does

not provide for every possible contingency in connection with the installation or use of the product(s). The

information contained in this document is subject to change without notice or obligation. Kendall Howard LLC

assumes no responsibility for the accuracy, completeness or reliability of the information contained in this

document. Any reliance placed on the information is therefore strictly at your own risk.

Page | 3

Save This Manual for Future Reference

Dimensional Drawing

Specifications

Dimensions

Height 78” x Width 36” x Depth 18”

Weight (ESDC-7836-1000)

270 lbs (122 kg)

Weight (ESDC-7836-2000)

341 Lbs (155 kg)

Color

Gloss Black Powder Coat

Individual Replacement Components

Description

Part Number

Cabinet Top ESD Mat

A-2523

Leg Leveler

CP-1549

Grounding Boot

A-2543

Right Locking Door

A-2533

Left Non-Locking Door

A-2531

Page | 4

Save This Manual for Future Reference

Component Identification

What’s included (ESDC-7836-1000)?

ESD Cabinet

Part Number ESDC-7836-1000

What’s included (ESDC-7836-2000)?

Drawer Assembly (2) ESD Shelf (2)

Part Number ESDC-7836-1200 Part Number ESDC-7836-1204

23” x 32” Pegboard (1)

Part Number ESDC-7836-1201

Page | 5

Save This Manual for Future Reference

Installation and Setup

Step 1:

Cut and remove the two plastic banding and any shrink wrap material. Remove the cardboard

packaging. Remove accessories boxes from cabinet. Lift the Cabinet out of the packaging.

Step 2:

Place the Cabinet on the preinstalled leg levelers. Adjust the levelers so they are level to the mounting

surface, both vertically and horizontally. Note that the leg levelers can be adjusted from inside the

cabinet using a ¼” hex wrench. Maximum leveler height is 1.15”. If the leg levelers exceed 1.15”, the

floor anchor kit cannot be installed. Install the front kick plate with the two provided 8-32 pan head

screws.

Step 3:

Locate the top ESD mat. Ensure the top is clean and clear of any debris. Remove adhesive backer and

attach the ESD mat to the top of the cabinet. Apply slight pressure to ensure adhesion.

Step 4:

Determine a grounding method. The cabinet is designed to establish a ground through the rear leg

levelers which are equipped with grounding boots. This grounding method assumes that the cabinet is

installed on static-dissipative of ESD safe flooring. If this is not the case a secondary method can be used.

This involves connecting the 10’equipment ground (supplied) cable and to one of the ESD boots

mounted to the leg levelers. The other end will connect to a suitable grounding point.

Step 5:

Mount the Cabinet to the floor or the wall using the provided anchor kit. Level the cabinet to the floor.

Note that the distance from the wall must be .50” to 1.75” in order to use the wall anchoring kit. Note

that the distance from the base of the cabinet base must be .85” to 1.50” in order to use the floor

anchoring kit.

Page | 6

Save This Manual for Future Reference

Cabinet Use

ESD Control

The ESD 2-layer vinyl mats are required for proper ESD protection when using this ESD Cabinet.

This unit provides a RTT value of < 1 X 10⁹ohms for each shelf. This unit provides a RTG value

of 1 X 10⁵ < 1X 10⁹ ohms from each drawer, pegboard, conductive bins, or Cabinet top to the

grounding boots.

The Electrical circuit for ESD protection is as follows:

ESD Cabinet

The cabinet is insulated from any residual grounding. The rear leg levelers connect to an

internal common ground point. This connection contains a 1MEG ohm resistor providing the

ESD protection. The common ground is wired to each louvered panel or grounding backplane.

This establishes the grounding to the accessories. A separate wire runs from the common

ground to the cabinet top.

ESD Shelf

The ESD Shelf is connected to the Cabinet using the louvered panels and two support screws.

The shelf is then grounded through the louvered panel and to the common ground point.

ESD Pegboard

The ESD Pegboard is locked into place using slots in the louvered panels. The Pegboard is then

grounded through the louvered panel and to the common ground point.

ESD Drawer

The ESD Drawer is connected to the Cabinet using the louvered panels and six support screws.

The Drawer is then grounded through the louvered panel and to the common ground point.

Page | 7

Save This Manual for Future Reference

Care and Cleaning

Painted Surfaces

All painted surfaces can be cleaned with a non-abrasive, non-ammonia or non-bleached based

cleaner. Do not use soap or detergents on exposed metal surfaces of the sliding drawer, fixed

shelf, or pegboard. The soap may leave a residue that will insulate the mat from ESD

grounding. Wipe down all cleaned surfaces with a lint free soft cloth.

ESD Mats

Clean only with approved cleaners. Wipe down all cleaned surfaces with a lint free soft cloth.

Leg Levelers

The front leg levelers are adjustable and non-conductive. The rear leg levelers are adjustable

and have pre-installed ground boots. They can be cleaned with any non-ammonia or bleached

based cleaner.

Approved cleaning solutions for ESD surfaces

•Desco 10446 Reztore Surface & Mat Cleaner

•3M 8001 Antistatic Mat & Table Top Cleaner

NOTE: Do not use petroleum-based solvents or alcohol to clean any surfaces on this ESD

Cabinet.

Page | 8

Save This Manual for Future Reference

Troubleshooting

ESD non-compliant on Shelves, Drawers and Mats

•Verify that the flooring has a RTT value of 10⁵<10⁹. If not use the provided equipment

ground wire and connect from one of the grounding boots to define a ground.

•Verify that the ESD mat has a RTT value of 10⁵<10⁹. If it does not, clean mat and repeat

test. If it still does not pass then the mat will need to be replaced.

•Verify that that the resistance from the mat to each conductive leg leveler with

grounding boot has a RTG value of 10⁵<10⁹ ohms. If this RTG value fails proceed to the

next step.

•Remove the ESD mat. Check the RTG value of 10⁵<10⁹ from the metal surface to each

conductive leg leveler ground boot. If this test passes, replace the ESD mat. If this RTG

value fails proceed to the next step.

ESD non-compliant on Louvered panels

•Check ground wire connection from the common ground to the leg leveler grounding

boot (this is visible on the internal bottom shelf). Replace if damaged. Retest the RTG

value. Note that this wire will have a 1MEG ohm resistor installed, if not ESD protection

will not be available.

•None of the accessories is reading an acceptable ground value. Check common ground

wiring to each louvered panel (ground plane). Replace if damaged. Retest the RTG value.

•Top of Cabinet is not reading an acceptable ground value. Check common ground wire

from common ground to Cabinet top. Replace if damaged. Retest the RTG value.

Glossary:

•RTT = Resistance point to point

•RTG = Resistance to ground

Page | 9

Save This Manual for Future Reference

Warranty

GENERAL: Kendall Howard offers all users of our products the following Limited Warranty against defects in material and workmanship. Please read your Warranty

carefully. This Warranty sets forth our responsibilities in the unlikely event of defect and tells you how to obtain resolution.

TERMS OF WARRANTY: Kendall Howard products are warranted to be free of defects in material and workmanship. If any part or portion of the Kendall Howard

product fails to conform to the Warranty, Kendall Howard, at its option, will furnish new or factory remanufactured products for repair or replacement of that part.

WARRANTY EXTENDS TO FIRST PURCHASER FOR USE, NON-TRANSFERABLE: This Warranty is extended to the first person, firm, association, or corporation for whom

the Kendall Howard product specified herein is originally sold for use in the United States (the "User"). This Warranty is not transferable or assignable without the

prior written permission of Kendall Howard.

ASSIGNMENT OF WARRANTIES: Kendall Howard assigns to User any warranties which are made by manufacturers and suppliers of components of the Kendall

Howard product and which are assignable, but Kendall Howard makes NO REPRESENTATIONS as to the effectiveness or extent of such warranties, assumes NO

RESPONSIBILITY for any matters which may be warranted by such manufacturers or suppliers and extends no coverage under this Warranty to such components.

DRAWINGS, DESCRIPTIONS: Kendall Howard warrants for the period and on the terms of the Warranty set forth herein that the Kendall Howard product will

conform to the descriptions contained in Kendall Howard final invoices, orders, proposals (as modified) and other Kendall Howard descriptive documents

("Descriptions"). Kendall Howard does not control the use of any Kendall Howard product. Accordingly, it is understood that the Descriptions are NOT WARRANTIES

OF PERFORMANCE and NOT WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE.

WARRANTY CLAIMS PROCEDURE: Within a reasonable time, but in no case to exceed thirty (30) days, after User's discovery of a defect, User shall contact Kendall

Howard. Subject to the limitations specified herein, a Kendall Howard customer service representative will repair or replace the non-conforming Kendall Howard

product warranted hereunder, without charge for materials. User will not be charged for labor if performed within thirty (30) days of product purchase. In all other

instances, User will be charged for labor performed at Kendall Howard’s then current rates. Kendall Howard shall assume shipping costs for replacement products

and return of the defective product to Kendall Howard. Warranty coverage will be extended only after Kendall Howard inspection determines there is a defect as

claimed and shows no signs of treatment or use which would void the coverage of this Warranty.

WARRANTY PERFORMANCE OF COMPONENT MANUFACTURERS: It is Kendall Howard’s practice, consistent with its desire to remedy Warranty defects in the most

prompt and effective manner possible, to cooperate with and utilize the services of component manufacturers and their authorized representatives in the

performance of work to correct defects in Kendall Howard components. Accordingly, Kendall Howard may utilize third parties in the performance of Warranty work,

including repair or replacement hereunder, where, in Kendall Howard’s opinion, such work can be performed in less time, and with less expense.

ITEMS NOT COVERED BY WARRANTY: THIS WARRANTY DOES NOT COVER DAMAGE OR DEFECT CAUSED BY misuse, improper application, wrong or inadequate

electrical current or connection, negligence, inappropriate on site operating conditions, repair by non- Kendall Howard designated personnel, accident in transit,

tampering, alterations, a change in location or operating use, exposure to the elements, Acts of God, theft or installation contrary to Kendall Howard's

recommendations or specifications, or in any event if the Kendall Howard serial number has been altered, defaced, or removed. THIS WARRANTY DOES NOT COVER

installation costs, external circuit breaker resetting or maintenance or service items and further, except as may be specifically provided for herein, does NOT include

labor or shipping costs arising from the repair or replacement of the Kendall Howard product, or any part thereof, or charges to remove same from any premises of

User. THIS WARRANTY IS VOID if User alters the product in any way.

LIMITATIONS: THIS WARRANTY IS IN LIEU OF AND EXCLUDES ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE. USER'S SOLE AND EXCLUSIVE REMEDY IS REPAIR OR REPLACEMENT OF THE KENDALL HOWARD PRODUCT AS SET FORTH HEREIN. IF USER'S

REMEDY IS DEEMED TO FAIL OF ITS ESSENTIAL PURPOSE BY A COURT OF COMPETENT JURISDICTION, KENDALL HOWARD’S RESPONSIBILITY FOR PROPERTY LOSS OR

DAMAGE SHALL NOT EXCEED ONE TIMES THE NET PRODUCT PURCHASE PRICE. IN NO EVENT SHALL KENDALL HOWARD ASSUME ANY LIABILITY FOR INDIRECT,

SPECIAL, INCIDENTAL, EXEMPLARY OR CONSEQUENTIAL DAMAGES OF ANY KIND WHATSOEVER, INCLUDING WITHOUT LIMITATION LOST PROFITS, BUSINESS

INTERRUPTION OR LOSS OF DATA, WHETHER ANY CLAIM IS BASED UPON THEORIES OR CONTRACT, NEGLIGENCE, STRICT LIABILITY, TORT, OR OTHERWISE.

MISCELLANEOUS: NO SALESPERSON, EMPLOYEE OR AGENT OF KENDALL HOWARD IS AUTHORIZED TO ADD TO OR VARY THE TERMS OF THIS WARRANTY. Warranty

terms may be modified, if at all, only in writing signed by a Kendall Howard officer. This Warranty is effective as of the date of Kendall Howard receipt of full

payment and supersedes all previous warranties Kendall Howard reserves the right to supplement or change the terms of this Warranty in any subsequent warranty

offering to User or others. If any provision of this Warranty should be or becomes invalid and/or unenforceable during the warranty period, the remaining terms

and provisions shall continue in full force and effect. User must complete the attached User Information Card and forward it to Kendall Howard within thirty (30)

days of receipt of the Kendall Howard product. This Warranty is given in and performance hereunder is to be construed under the laws of the State of Nebraska.
