Kenmore 758.15420011 User manual

Use & Care Guide
Manual de Uso y Cuidado
English /Espa_ol
Model 758.15420011
I(enmoreo
÷no÷ .................ous÷ .................u_i_i_ier
14 Gallon Output with Digital Readout
@ I@ @
Hu,m_d_f_cado Para
Producci6n de ]4 ga/ones con lectura digital
P/N 1B72042 07/10
Sears Brands Management Corporation
Hoffman Estates, IL 60179 U.S.A.
www.kenmore.com
www.sea rs.com

r ONE YEAR FULLWARRANTY ON KENMORE HUMIDIFIER
if any part of this humidifier fails due to a defect in material or workmanship within
one year from the date of purchase, or if the humidifier motor fails due to a defect in
material or workmanship during the second year from the date of purchase, RETURN
THE HUMiDiFiER TO THE NEAREST SEARS PARTS & REPAIR CENTER, and it will be
repaired free of charge. This warranty does not include humidifier filters, which are
expendable parts that can wear out from normal use in less than one year. This
warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.
Sears Brands Management Corporation, Ho_man Estates, IL 60179 j
GENERAL SAFETY INSTRUCTIONS
Safety Signal Words
DANGER: means if the safety
information is not followed someone
will be seriously injured or killed.
WARNING: means if the safety
information is not followed someone
could be seriously injured or killed.
CAUTION: means if the safety
information is not followed someone
may be injured.
1. To reduce the risk of fire or shock
hazard, plug humidifier directly into
a 120V A.C. electrical outlet. Do not
use extension cords.
2. Keep the electric cord out of traffic
areas. To reduce the risk of fire
hazard, never put the electric cord
under rugs, near heat registers,
radiators, stoves or heaters.
3. Always unplug the humidifier before
moving it, before cleaning, or
whenever the humidifier is not in
service.
4. Keep the humidifier clean.
5. Do not put foreign objects inside
the humidifier.
6. Do not allow to be used as a toy.
Close attention is necessary when
used by or near children.
7. Never use your humidifier while any
part is missing or damaged in any
manner.
8. To reduce the risk of electrical
hazard or damage to humidifier, do
not tilt, jolt or tip humidifier while
unit is running.
9. To reduce the risk of damage to
humidifier, unplug when not in use.
10. To reduce the risk of accidental
electrical shock, do not touch the
cord or controls with wet hands.
11. To reduce the risk of fire, do not
use near an open flame such as a
candle or other flame source.
12. Note the warning label shown
below.
WARNING: To reduce risk of fire,
electric shock, or injury always
unplug before servicing or cleaning.
Tab/e of Contents
Warranty Information .................................. 2
General Safety Instruction .......................... 2
To Save A Service Call ............................... 3
Know Your Humidifier .................................. 3
How Your Humidifier Works ....................... 4
Assembly ......................................................... 4
Location Instructions .................................... 5
Operating Tips for Best Performance ....... 5
Electrical Hook-Up ................................... 6
Water Fill ............................................... 6-7
Operating Humidifier Controls .......... 8-9
Using Your Humidifier ....................... 9-10
Replacement and Care of Filters ....11-12
Cleaning and Maintenance ............. 12-13
Troubleshooting ................................. 14-15
Repair Parts ........................................ 16-17

To Save A Service Call
Check the following if your humidifier
is not operating.
1. Is power cord attached to outlet?
2. Is there electrical power to outlet?
Know Your Humidifier
Controls -_
Filter
Housing
Filters:
Replacement
Filter 32-14911
3. Is airflow control in operating
position?
4. Is humidity control set high enough?
5. Is the cabinet sitting on a level
surface?
.- Fan Assembly
/Bottles
Pivoting Lid
/
Humidistat
(On Power
Cord)
Casters
Pivoting Lid Removed For Clarity
Description 758.15420010
*Output per 24 hrs 14 gallons
Capacity of Each Bottle 2.375 gallons
*Sq. ft. coverage 2,900
Fan Speeds 3
Auto Fan Speed Yes
Replacement Filter Set of 4(32-14911)
Refill Indicator Yes
Auto Humidistat Yes
Auto Shut Off Yes
Controls Electronic (Push Button)
Casters Yes
ETL Listed Yes
Volts 120 A.C.
Hertz 60
Amps (High Speed) 2.88
Watts (High Speed) 165
* Based on an area with average insulation and an 8 foot
ceiling height
ANSI/AHAM HU-1-t997, SEC. 8.t, results may vary.

How Your Humidifier Works
Your new Kenmore humidifier is
designed to satisfy home humidity
requirements through the principle of
evaporation of water into the air.
After water is added to the bottle, the
filters begin to soak up the water and
become totally saturated in
approximately 30 minutes. Air is drawn
in from the rear of the humidifier and
through the filters by means of
circulation fans. As air passes through
the filters, moisture is absorbed into the
air and then released in the form of
vapor. No water droplets will enter the
home. All evaporation into the air takes
place in the humidifier, which means
that the residue left by evaporating
water is not passed into the home, but
remains in the filter.
Dry Air
Enters
Through
the Rear
Humidified Air is Then
Released Through the Top
!
CAUTION =To reduce the risk of
injury, fire or damage to
humidifier, use only cleaners
specifically recommended for
humidifiers. Never use flammable,
combustible or poisonous
materials to clean your humidifier.
To reduce the risk of scalds and
damage to humidifier, never put
hot water in humidifier.
Assembly
Your new Kenmore humidifier is
completely assembled for you to use.
Remove the bag pack containing two
plastic caster pads from top of
humidifier and retain for future use if
required. See the following Step 1 for
instructions.
Remove the packaging material from
inside your humidifier and follow the
instructions of this operator's manual for
proper usage. The packaging material is
located under the fan assembly. Remove
the packaging material and discard.
4

Location Instructions
WARNING: For your own safety,
do not use humidifier if any parts are
damaged or missing.
Step 1,
Place humidifier on a flat level surface
in an area of your house where humidity
is needed most, or in an area which
would likely result in moist air being
circulated throughout the house, such as
near a cold air return. Placing the unit
level is very important if the humidifier is
located on carpeting.
NOTE; The 14 gallon humidifier contains
water bottles. The weight of the bottles
in the front of the cabinet may cause
the front casters to sink deeper into the
carpet. If this happens, the water level
will be higher towards the front of the
humidifier, and lower towards the back.
The water level float (located at the
rear of the cabinet) may not sense the
water so the flashing "F" will be
displayed and the unit will not energize.
If this happens, the unit will need to be
leveled in order for the humidifier to be
energized. To level the humidifier when
located on carpet, place the included
caster pads under the front two casters
of the humidifier only.
NOTE: Due to release of cool, moist air
from humidifier, it is best to direct air
away from home thermostat and hot air
registers. It is best to position humidifier
next to an inside wall. Hot air registers
and cold air from outside walls can
affect the efficiencies of the controls.
Unit should not be placed where warm
air from a hot air register blows directly
on unit.
Moist air (humidity) produced will
disperse into the whole house, but area
closest to the unit will have the highest
humidity. If the unit is positioned close to
a window, condensation may form on
the window pane. If this is not
appropriate the unit should be
repositioned in another location.
Step 2:
The humidifier should be positioned with
the back (cord exit side), at least 2
inches away from the wall. Air needs to
enter through the louvers in the rear
panel in order for the humidifier to
operate at peak efficiency.
At Least2 in. From Wall Front of
-_ _ _._............Cabinet
_ Front
....... Caster
..........Caster Pad
r/77777T/_ ..........Carpet
Surface
NOTE: Ifpositioning on
__ /carpet, placecaster pads
./under thecastersonly if
they are requiredto level
the unit.
Operoting Tips for Best Performonce
1. Position the humidifier at least 2
inches from any wall and away from
any heat registers.
2. Do not restrict airflow from entering
or exiting the humidifier.
3. Use Sears recommended bacteriostat
to retard bacteria growth that may
cause odors and may be harmful to
your health.
4. Perform regular cleaning as instructed
in "Cleaning and Maintenance" section
of this manual.
5. Replace the evaporative wicking
filters at least once per humidification
season or more depending on water
conditions in your area.

Electrical Hook-Up
Locate nearest 120V A.C. wall socket in
the location desired, preferably on
inside wall. With the humidifier in the
desired location, route the electrical cord
safely so no one will trip or upset the
humidifier. Plug in the electrical cord.
WARNING: To reduce the risk of
fire or shock hazard, humidifier
should be plugged into a 120V A.C.
outlet. Do not use extension cords.
If the plug does not fit fully in the outlet,
reverse plug. If it still does not fit,
contact a qualified electrician to install
the proper outlet. Do not change the
plug in any way.
To reduce the risk of electrical shock,
this humidifier has a polarized plug (one
blade is wider than the other). This plug
will fit in a polarized outlet only one
way.
Water Fill
WARNING: To reduce the risk of
shock, always unplug humidifier
before cleaning or servicing.
This humidifier is designed for use with
the two water bottles that are located
under the pivoting lid.
Open the pivoting lid of the humidifier.
Remove the water bottles by lifting them
straight up and out of the cabinet.
Notice the water bottles are designed as
right and left hand units. Position them
in the correct location so the humidifier
can function properly. The water bottles
should rest in the front of the cabinet.
Each "E-Z-Fill Side-Cap" must be facing
the rear of the unit.
Each water bottle is designed with an
"E-Z-Fill Side-Cap" that is easily
removable. Remove the "E-Z-Fill Side-
Cap" on the side of the water bottle by
twisting counterclockwise.
/Fan Assembly
Pivoting
Lid
Left
"Side=Fill Cap" Should
A|ways Face Rear
6

Water Fill (continued)
Place the opening of the water bottle
under a water faucet (the bottle should
fit under a four-inch clearance faucet).
Fill with recommended mixture of cold
water and an EPA approved
bacteriostat (if necessary) only.
CAUTION" Use only EPA
(Environmental Protection
Agency) approved Bacteriostat
available from Sears Retail
stores. Under no circumstances
should you use water treatment
products designed for Roto belt
or Ultrasonic humidifiers.
Solid debris could make the valve leak.
Install the "E-Z-Fill Side-Cap" by
twisting clock- wise. Hand tighten only.
Check for possible leaks by
performing the following:
1. Grasp bottle handle and hold the
bottle upright over a sink.
2. Press up on the valve cap plunger for
about one second to let out a little
water.
3. Release the plunger.
4. Listen for air bubbles Look for leaks
around the "E-Z-Fill Side-Cap'.
5. If you hear air bubbles or see leaks_
retighten the "E-Z-Fill Side-Cap" and
repeat Steps 1-4.
Wipe off excess water from the bottle.
Position the water bottle back into the
unit by grasping the water bottle handle
and lower it into the cabinet until the
bottle sits on pads at bottom of cabinet.
The "E-Z-Fill Side-Cap" must be facing
the rear of the cabinet. When
positioned properly, the plunger will
open and water will flow into the
cabinet. The water level will
automatically remain at approximately
1/2" until the bottles are empty.
Allow the filter to saturate for 30
minutes before operation.
Turn Counterclockwise
to Remove Cap
J
J
Valve Cap _
Plunger
Pivoting Lid Removed for Clarity
7

Operating the Controls
Where you set your desired humidity
levels depends on your personal comfort
level, outside temperature and inside
temperature. A starting set point of
30% - 40% ROOM humidity is
recommended, but there may be
conditions that require a different
setting.
IMPORTANT" Water damage may
result if condensation starts to form on
windows or walls. Humidity SET point
should be lowered until condensation no
longer forms. We recommend room
humidity levels do not exceed 50%.
When Outdoor Recommended Indoor
Temperature is; Relative Humidity is:
-IO°F -24°C 20%
2°F -18°C 25%
10°F -12°C 30%
20°F * -6°C * 35%
_and above
To Operate the Controls
Digital Display
Press the power/speed button once to
turn the unit on _ ._::_ Initially there is a
slight delay while the electronics
calibrate. Two bars (- -) appear during
this time. Once calibration is complete a
ROOM humidity reading between
20% - 95% will be displayed. A flashing
20 display indicates that the room
humidity is less than 20%.
NOTE: The default settings at initial
startup are (WHISPER) F1 fan speed and
65% SET humidity. After desired settings
are selected by the user, they remain as
long as the unit remains plugged in and
there is no power interruption. If the unit
is unplugged the original default settings
are employed.
Humidifier fan should operate at initial start
up. If it does not, refer to, "Fan not operating
(digital display is illuminated)" in the
"Troubleshooting" section on pages 14-t5.
8
FunctionButtons
I
"Digital Display
Speed Button _)
This humidifier is equipped with a 3-
speed fan control. Initially depressing
the speed button will display the current
speed setting. Each push of the speed
button advances the mode through the
settings of (HIGH) F3, (MEDIUM) F2,
(WHISPER) F1 and (AUTO) A.
The selected setting is displayed on the
digital readout. The higher the setting,
the faster water is evaporated and
released into the air. F1 (WHISPER) is
the quietest setting and is provided for
conditions that do not require a rapid
evaporation rate.
When (AUTO) A is selected the
humidifier will determine the required
fan speed needed to bring the actual
room humidity up to the set humidity.
Speed Button \
Humidity Control 0
This button allows you to adjust the
humidity to suit your needs. This
humidifier will automatically cycle on
and off as required to maintain the
selected setting.
The readout displays both actual
(ROOM) and desired (SET) humidity
percentage (%) settings when humidity
control button is pressed. The ROOM
readout has a range of 20% to 95%. If
the room humidity level is equal to or
less than 20% the display will show a
flashing 20.

Operating the Controls (continued)
The SET readout has a range of 25% to
65% and is adjusted in increments of
5%. Initially depressing the humidity
button will display the current humidity
setting.
Each additional press of the button
increases the setting by 5%. ASET point
of 65% operates the humidifier
continuously regardless of the ROOM
reading. The humidistat that senses the
readings is located on the power cord.
Insure that this humidistat is free from
obstruction.
Humidity Button\
Using Your Humidifier
Refill Display and Auto Dry Out
Function
For maximum run time both bottles
should be filled. When both bottles are
empty the display alternates the room
humidity reading and "F" (FILL),
indicating additional water is required;
Also at this time the unit will auto-
matically switch into AUTO DRY OUT
MODE and continue to run on the
lowest speed until the filter is dry.
Refil!/Auto Dry Out
Mode Display
NOTE= During this time the room
humidity level will continue to be
monitored and the humidifier will cycle
the fan on and off until the filter is
completely dry. The fan will shut off
leaving you with a dry humidifier that is
less prone to mold and mildew growth.
If AUTO DRY OUT MODE is not desired,
refill the humidifier with water and the
fan will return to the set speed.
9
NOTE= Fan automatically switches to
lowest speed during AUTO DRY OUT
MODE.
Manual Dry Out
At the end of the humidification season
or if you do not plan to run the
humidifier for one week or more, a
manual dry out mechanism is provided
to completely dry out the humidifier
cabinet.
To do this, simply slide the float retainer
located at the back of the humidifier
cabinet to the top position of the slot it
is located in. This will hold the float in
an upward position and the fan will run
until you turn the power off.
NOTE= Be sure to position float retainer
to the normal operating mode (lowest
position in slot) for normal humidifier
operation.
Below is a diagram of the slot the float
retainer is located in, at the back of the
cabinet.
Back of Cabinet Top Position
is for Manual
Dryout
Bottom Position
is for Normal
Operation Mode
Float
Retainer
Slot

Using Your Humidfier (continued)
Check Filter Indicator Control Lock Out
The ability of any humidifier to
efficiently supply humidity output relies
heavily on the condition of the filter. As
the filter loads with impurities it
gradually loses its wicking capability.
When this happens, moisture output is
reduced and the humidifier has to work
longer to satisfy the selected setting.
This humidifier has a check filter
reminder timed to appear after 720
hours of motor operation. When the
display shows an alternating "CF" and
"room humidity" setting at 5second
intervals it is a reminder to check the
filter condition.
NOTE =Some areas have high water
mineral content causing the need for
more frequent filter changes.
Refer to "Replacement and Care of
Filter" on page 11.If a build-up of
deposits or severe discoloration is
evident replace the filter to restore
maximum efficiency.
To avoid unwanted tampering with the
humidifier settings the controls can be
locked.
Activation Procedure
After the humidifier functions have been
set up, press and hold the power button
down for 5seconds. The display will
show "CL" for 5seconds; release the
power button and the control will
resume the display of the room
humidity. The humidifier will continue to
function with the locked in settings. If
buttons are operated while "CL" is
active, the "CL" is displayed and
settings are unaffected.
Deactivation Procedure
To deactivate the "CL" function simply
press and hold the power button for 5
seconds. "CL" will flash and then resume
the display of room humidity.
/
Check Filter Display
Humidistat
The humidistat located on the power
cord senses the percentage of humidity
in the air. It causes the humidifier to
cycle on and off to maintain the
selected humidity SET point. The fan will
turn on if the "ROOM" reading falls 3%
below the SET point and will continue to
run the humidifier until a reading of 1%
above the SET point is achieved. The fan
will turn off until the ROOM reading
falls 3% below the SET point again.
NOTE =Be sure humidistat, which is
located on the power cord, is free from
obstructions and is away from any hot
air source.
10

Replacement and Care of Filters
WARNING: To reduce the risk of
shock or iniury from moving parts,
always unplug humidifier before
removing or replacing any parts.
Lid
Fan Assembly
/
/
Humidifier
CAUTION: To help retard bacteria
growth and keep maximum
efficiency, the filter should be
replaced at least once per season,
or more often under hard water
conditions. Use Kenmore 32-14911
recommended replacement filter.
The filters may be rinsed periodically in
clear water only. Take care not to
damage paper. To replace evaporative
wicking filters in your humidifier, follow
these instructions.
1. Unplug humidifier before removing
the filters. We recommend moving the
humidifier to an area where floor
coverings are not susceptible to water
damage, i.e. kitchen or bath areas.
2. Open the pivoting lid and remove
water bottles and set aside. Grasp
the fan assembly front center and
rear center. Lift off and set aside on a
clean flat surface. The filter housings
are now accessible.
3. Lift filter housing out of cabinet and
place where you may work on them
comfortably. With a soft, absorbent
cloth remove any remaining water or
loose mineral deposits not trapped in
the filter from the humidifier cabinet.
4. To open filter housing for easy access
to filters:
a. Deflect the two spring tabs on top of
filter housing. Lift top cover off of the
filter housing and set aside.
b. Remove the two filters and dispose of
properly. Clean internal parts of
humidifier per the "Cleaning and
Maintenance" section (page 12) of
your operator's manual.
Spring
_ilter
Housing
J
Spring
Tabs
Fixed Tabs
Front of
Humidifier
c. Install new filters in the filter housing
track with the glue beads of the
wicking pad to the inside of the filter
housing.
d. Return the top cover of the filter
housing by installing cover over the
fixed tabs on the rear of the lower
filter housing and pivoting the cover
down over the top of the filters. Snap
the cover over the two spring tabs.
11

Replacement and Care of Filters (cont'cl.)
e. Replace the filter housing in the
cabinet.
NOTE: There is a front and back
orientation. To position the filter housings
correctly:
•Be sure that the spring tabs of filter
housings are towards front of cabinet.
• Align the lower portion of the filter
assembly over the six ribs located at
the bottom rear of the humidifier
cabinet.
f. Position fan assembly onto the
cabinet. Make sure the fan venture
(lowest cylinder section below the fan)
is placed inside the filter housing.
g. Replace water bottles.
h. Close the pivoting lid.
i. The unit is ready for use or to be
stored away for next season.
Top
/Cover
/
Y
Spring
Tabs
Flat Portion of Filter Housing
Towards Back of Cabinet
Spring Tabs Towards Front of Cabinet
Step 4e
Cleaning and Maintenance
WARNING: To reduce the risk of injury,
fire or damage to humidifier, use only
cleaners specifically recommended for
humidifiers. Never use flammable,
combustible or poisonous materials to
clean your humidifier. To reduce the risk
of scalds and damage to humidifier,
never put hot water in humidifier.
CAUTION= Local water purity varies from
area to area and under certain conditions
water impurities and airborne bacteria
may promote the growth of
microorganisms in the reservoir of the
humidifier.
To retard bacteria growth that may cause
odors and be harmful to your health, use
only Kenmore replacement filters. We
also recommend using an EPA approved
bacteriostat and humidifier cleaner, 32-
14713, available at your local Sears store.
NOTE: If it is necessary to use
approved bacteriostat, follow directions
correctly.The bottles of the whole house
humidifier will hold 2-3/8 gallons of
water each.
Step 1:
To make cleaning easier, the humidifier
cabinet should be empty and
completely dried out. To accomplish
this, use the following method:
a. On the back side of the humidifier
cabinet, find the float retainer. In
normal operating mode, the retainer
will be positioned in the bottom of the
slot in the cabinet. Push the retainer
up to the top slot position in the
cabinet until it locks in place. (See
"Manual Dryout" section on page 9.)
b. Allow the humidifier to run until there
is no water left in the cabinet.
c. Unplug humidifier.
12

Cleaning and Maintenance (cont'd.)
WARNING; To reduce the risk of shock,
always unplug humidifier before
cleaning or servicing. If humidifier is not
unplugged, fan could start after housing
is removed.
Step 2:
To Remove Parts
a. Open the pivoting lid and remove water
bottles and set aside. Grasp the fan
assembly front center and rear center.
Lift off and set aside on a clean flat
surface. The filter housings are now
accessible.
b. Before removing the internal parts of
the humidifier cabinet, we recommend
moving the humidifier to an area where
floor covers are not susceptible to water
damage, i.e.; kitchen or bath area. Lift
the filter housing assemblies out of the
cabinet and set to the side.
c. Remove the water level float from the
humidifier cabinet by pinching the float
retainer to release it from the cabinet.
The cabinet should be empty before
cleaning. The cabinet consists of the
lower areas of the humidifier where the
filters are during normal operation time.
d. Empty cabinet of any remaining water.
e. Proceed to "Bi-Weekly Maintenance" or
"End of Season Maintenance".
f. Remove old filters and dispose of
properly as described on pages 11-12.
Step 3:
Install new filters (purchase the correct
evaporative wicking filter pads 32-14911 for
your humidifier) into the location where the
old filters were positioned. Install the filter
housings with the new filters into the correct
location. Reinstall the water level float.
NOTE; Float retainer should be positioned in
normal operating mode. Assure that it is
positioned in the bottom of the slot in the
back of the cabinet (See page £for
diagram of slot).
Position the fan assembly on top of the
cabinet and return the humidifier to the
desired location for use.
Refill humidifier bottles with fresh cool
water and return them to the cabinet.
Plug the unit into a 120 volt A.C. power
outlet and set the controls per the
"Operating Humidifier Controls" section
(page 8) of this manual.
Bi-Weekly Maintenance
Removing Scale
1. Fill the reservoir with water and add
one 8 oz. cup of white vinegar. Let
solution stay for 20 minutes.
2. Clean all interior surfaces with soft
brush. Dampen soft cloth with white
vinegar and wipe out reservoir to
remove scale.
3. Rinse thoroughly with clean warm
water to remove scale and cleaning
solution before disinfecting the
reservoir.
Disinfecting Humidifier
Cabinet and Water Bottles
1. Fill humidifier cabinet with 1 teaspoon
chlorine bleach in 1gallon of water.
Let solution stay for 20 minutes,
carefully swishing every few minutes.
Wet all surfaces normally exposed to
water.
2. Empty humidifier cabinet after 20
minutes. Rinse with water until bleach
smell is gone. Allow unit to dry out
completely.
3. Water bottles should be cleaned in
the same manner.
End of Season Maintenance
1. Follow "Bi-Weekly Maintenance"
instructions at end of humidification
season.
2. Remove and throw away filters.
3. Let humidifier dry completely before
storing. Do not store with water inside
cabinet or water bottles.
4. Store in cool, dry location.
5. Install a new filters in clean
humidifier before next season begins.
6. "Bi-Weekly Maintenance" procedure
is also recommended if you do not
plan to run the humidifier for one
week or more.
13

Troubleshooting
Trouble
Digital display not
illuminated.
Fan not operating
(digital
display is
illuminated).
Fan running
continuously, unit
will not shut off.
Poor evaporation
of water.
Neither bottle
emptying.
Bottles continues to
empty.
Left bottle not
emptying.
Refill display "F" is
on before bottles
are empty
Display blinks or
fan moves slightly
when humidifier is
plugged in.
Probable Cause
•No Power.
• Power button has not
been depressed.
• ROOM humidity level is
not 3% or more below
SET humidity level.
• Reservoir is empty.
• Float is obstructed.
• SET humidity level is
65%.
• ROOM humidity level
has not reached 1% or
more above SET
humidity level.
• Check to see if filter
message "CF" is
flashing.
• Mineral buildup on
filter.
• Bottle cap plunger
missing post in bottom
of cabinet.
• Dirty filters.
• Air is entering water
bottle.
• Right bottle contains
water.
• Unit is not set up on a
level surface. Float will
not sense water at the
front of the cabinet.
• Normal.
Remedy
• Check 120 volt power source.
• Press power button once to turn
on.
• Raise SET humidity level if
desired.
• Increase fan speed.
• Fill humidifier with water.
• Free float from obstruction.
• A SET humidity percentage of
65% operates fan continuously.
Adjust SET level between
25% - 60%.
• Continue to run until desired
humidity level is achieved. This
may take up to 48 hours initially.
• Change to a fresh new filter.
NOTE: Local water purity
varies from area to area.
• Check orientation of bottles.
Reposition so that bottle cap
plunger (stem) is depressed by
post in bottom of cabinet.
• Change to fresh new filters (32-
14911).
• Check "E-Z-Fill Side-Caps" and
valve assembly caps to ensure
tightness.
• Check for leak in water bottle.
• Ensure gaskets for "E-Z-Fill
Side-Caps" are in place.
• The humidifier is designed so
that right bottle empties first.
• Position unit level. Some carpet
padding may allow unit to sit
lower in the front than rear with
the additional weight of water
bottles in the front of the
cabinet. Install caster pads
under front casters; see page 5.
• No action required.
14

Trouble
Fan operating
slower than speed
registered on
digital display.
Humidifier not
shutting off during
"Dry Out Mode".
Alternating "F"
and room
humidity
displayed.
Alternating "CF"
and room
humidity
displayed.
Probable Cause
•Humidifier is in "Dry
Out Mode."
• Filter not dry.
• Reservoir is empty.
• Filter may be dirty.
Remedy
• Humidifier automatically
switches fan to (WHISPER) F1
when "F" is flashing.
• During "Dry Out Mode"_ the
humidifier will continue to run
on (WHISPER) F1 speed as
required for up to 2 hours.
• Fill humidifier with water.
• Replace filter.
15

Repair Parts
Parts List for I(enmore Humidifier
Model No. 7.58.15420010
13 -\
16

Repair Parts
Parts List for Kenmore Humidifier
Model No. 758.15420010
Always order by part number - Not by key number
Key Part No. Description
No.
1 828741-2 Lid, Stationary
2 828855-1 Lid, Pivoting
3 1B71952 Control Assembly
3A 1B71904 Control Panel Label
4 824690 "E-Z Fill Side-Cap"
5 828192 Bottle, Left (Includes Key Nos. 4 & 7)
6 828726 Bottle, Right (Includes Key Nos. 4 & 7)
7 509229-1 Cap, Valve Assembly
8 828199-9 Cabinet
9 823726 Rail, Kick
10 STD601107 _Screw, Pan Hd. Ty "AB" #10 x 3/4
11 828515 Caster, Twin Wheel
12 830560-1 Support, Filter Lower
13 32-14911 Filter, Evaporative
14 828534 Support, Motor
15 828115-1 Motor
16 822406-1 Fan
17 828197 Support, Upper Filter
18 824101 Retainer, Float
19 828200-3 Float, Water Level
20 828920 Pad, Caster (Two)
NOTE: Any attempt to repair the control assembly or motor may create
a hazard unless repair is done by a qualified service technician.
Repair service is available at your nearest Sears store.
Standard Hardware Item - May be purchased locally.
t Stock item - May be secured through the Hardware Department
of most Sears retail stores.
17

Notes/Notas
18

GARANT[A COMPLETA DE UN Al_lO PARA EL HUMIDIFICADOR KENMORE •
Si cualquier pieza de este humidificador falla debido a un defecto de material o de
fabrlcaci6n dentro del plazo de un afio a partir de la fecha de compra, o si el motor del
humidificador falla debido a un defecto de material o de fabricaci6n durante el segundo
afio a partlr de la fecha de compra, DEVUELVA EL HUMIDIFICADOR AL CENTRO DE
PIEZAS Y REPARACi6N DE SEARS M._.S CERCANO ¥ser_ reparado sin ning0n cargo.
Esta garantia no incluye los filtros del humidificador, que son piezas perecederas que se
pueden desgastar por causa del uso normal en menos de un afio. Esta garantia le
confiere a usted derechos legales especiflcos ¥ es posible que usted tambi@n tenga otros
derechos que varian de un estado a otro.
Sears Brands Management Corporation, Hoffman Estates, iL 60179
INSTRUCCIONES GENERALES DE SEGURIDAD
Palabras de serial de seguridad
PELIGRO: Significa que si no se sigue la
informaci6n de seguridad, alguien resultar6
lesionado gravemente o motif6.
ADVERTENCIA: Significa que si no se sigue
la informaci6n de seguridad, alguien podrla
resultar lesionado gravemente o motif.
PRECAUCION: Significa que si no se sigue la
informaci6n de seguridad, alguien pudiera
resultar lesionado.
1. Para reducir el riesgo de peligro de
incendio o descargas et@ctricas, enchufe el
humidificador directamente en un
tomacorriente de 120 V C.A. No use
cordones de extensi6n.
6. No deje que el humidificador se use
coma un juguete. Es necesario prestar
mucha atenci6n cuanda et
humidificador sea usada par niSas a
cerca de elias.
7. No utilice nunca el humidificador
mientras alguna pieza falte a est@
daSada de cualquier manera.
8. Para reducir el riesgo de peligra
el@ctrica a daSas al humidificadar, no
incline, sacuda ni vuelque el
humidificadar mientras la unidad est@
en marcha.
9. Para reducir et riesgo de da_os al
humidificador, desenchOfeto cuando no
est@ en uso.
2. Mantenga el cable el@ctrico alejado de las 10.
zonas de tr6fico. Para reducir el riesga de
petigro de incendia, no panga nunca el
card6n el@ctrica debajo de alfombras ni
cerca de salidas de calar, radiadares de
calor, estufas de cacina o calentadares.
3. Desenchufe siempre el humidiflcadar antes
de trastadarta, antes de limpiarla a
siempre que no est@ en servicia.
4. Mantenga limpio el humidificador.
5. No ponga abjetas extra,as dentra del
humidificadar.
ind/ce
Informaci6n de garantfa ............................... 19
Instrucciones generales de seguridad ......... 19
Para ahorrarse una Ilamada de servicio ... 20
Familiarfcese con el humidificador ............ 20
C6mo funciona el humidificador ................. 21
Ensambtaje ...................................................... 21
Instrucciones de ubicaci6n ............................ 22
Consejos de utilizaci6n para
lagrar el mejar rendimienta .................... 23
Para reducir el riesgo de descargas
el@ctricas accidentales, no toque el
cable de alimentaci6n ni los cantrales
con las manos mojadas.
1t. Para reducir el riesgo de incendio, no use
et humidificador cerca de una llama al
descubierto, como por ejemplo la de
una vela u otra fuente de llamas.
12. Ffjese en la etiqueta de advertencia que
se muestra a continuaci6n.
ADVERTENCIA: Para reducir et riesgo de
incendio, descargas el@ctricas o lesiones,
desenchufe siempre el humidificador
antes de hacerle servicio de ajustes y
reparac ones o mp ar o.
Conexi6n el@ctrica ........................................ 23
Llenado con agua ................................... 24-26
Utilizaci6n de los controles
det humidificador ............................. 26-27
Utitizaci6n del humidificadar ................ 28-29
Reemplaza y cuidada de los filtros ....... 30-3t
Limpieza y mantenimienta .................... 32-33
Resaluci6n de problemas ....................... 34-35
Piezas de repuesta .................................. 36-37
19

Para ahorrarse una Ilamada de servicio
Compruebe Io sicjuiente si el
humidificador no funciona.
1. _Estd el cable de alimentaci6n
conectado aun tomacorriente?
2. _Hay alimentaci6n el6ctrica al
tomacorriente?
3. _Est6 el control del flujo de aire en la
posici6n de funcionamiento?
4. _Est6 el control de humedad ajustado
a un nivel Io suficientemente alto?
5. _Est6 el gabinete ubicado sobre una
superficie nivelada?
Familiaricese con el humidificador
Carcasa
del filtro
Filtro:
No. de repuesto
32-14911
Controles
Conjunto de
ventiladores
Botellas
J
Tapa pivotante
Higrostato /
(sensor en el cable de
alimentaci6n) Ruedecillas
Se ha quitado la tapa pivotante para mayor claridad
Descripci6n
*Producci6n en galones/24 h
Capacidad de las botellas
*Cobertura en pies cuadrados
Velocidades del ventilador
Velocidad del ventilador
autom6tica
Filtros de repuesto
Indicador de Ilenado
Apagado autom6tico
Higrostato autom6tico
Controles
Bloqueo de los controles
Ruedecillas
Catalogado por ETL
Voltaje
Frecuencia
Intensidad
Potencia
758.15420010
14
2-3/8 galones cada una
2900
3
Si
Juego de 4 (32-14911)
Si
Si
Si
Electr6nicos (bot6n pulsador)
Si
Si
Si
120 V C.A
60 Hz
2,88 A
165 W
* Basada en una zona con aislamiento promedio y una altura de habitaci6n de
2,44 m (8 pies).
ANSI/AHAM HU-1-t997, SEC. 8.t, los resultados pueden variar.
2O
