Kenmore 110.2706 User manual

Automatic Washers
Use and Care Guide
Lavadoras automáticas
Manual de Uso y Cuidado
Laveuses automatiques
Guide d’utilisation et d’entretien
Models/Modelos/Modèles 110.2706✼, 2707✼, 2708✼, 2709✼
✼ = color number, número de color, numéro de couleur
Sears Roebuck and Co., Hoffman Estates, IL 0179 U.S.A. www.sears.com
8566938 Sears Canada Inc., Toronto, Ontario, Canada M5B 2B8 www.sears.ca
®
Designed to use onl
High Efficienc (HE) detergent
Diseñado para utilizar solamente
detergente de alta eficacia
Conçu pour l'utilisation d'un
détergent haute efficacité
seulement

2
TABLE OF CONTENTS
PROTECTION AGREEMENTS.......................................................2
In the U.S.A...................................................................................2
In Canada .....................................................................................3
WARRANTY.....................................................................................3
WASHER SAFETY...........................................................................4
INSTALLATION REQUIREMENTS ................................................5
Tools and Parts ............................................................................5
Location Requirements ................................................................6
Drain S stem ................................................................................6
Electrical Requirements................................................................7
INSTALLATION INSTRUCTIONS ..................................................8
Before You Start...........................................................................8
Remove Shipping Base and Packing Ring..................................8
Connect Drain Hose .....................................................................8
Connect the Inlet Hoses...............................................................9
Secure the Drain Hose .............................................................. 10
Level the Washer....................................................................... 10
Complete Installation................................................................. 11
BENEFITS AND FEATURES ....................................................... 12
WASHER USE .............................................................................. 13
Starting Your Washer ................................................................ 13
Using the Proper Detergent ...................................................... 13
Pausing or Restarting the Washer ............................................ 14
Stopping the Washer................................................................. 14
Changing C cles, Modifiers and Options ................................. 14
Status Lights.............................................................................. 15
C cles........................................................................................ 15
Modifiers.................................................................................... 17
Options ...................................................................................... 18
Operating Controls .................................................................... 18
Normal Sounds.......................................................................... 18
LAUNDRY TIPS............................................................................ 19
WASHER CARE ........................................................................... 19
Cleaning Your Washer............................................................... 19
Water Inlet Hoses ...................................................................... 20
Vacation, Storage and Moving Care......................................... 20
TROUBLESHOOTING.................................................................. 21
SERVICE NUMBERS ............................................... BAC COVER
PROTECTION AGREEMENTS
In the U.S.A.
Master Protection Agreements
Congratulations on making a smart purchase. Your new
Kenmore® product is designed and manufactured for ears of
dependable operation. But like all products, it ma require
preventive maintenance or repair from time to time. That’s when
having a Master Protection Agreement can save ou mone and
aggravation.
Purchase a Master Protection Agreement now and protect
yourself from unexpected hassle and expense.
The Master Protection Agreement also helps extend the life of
our new product. Here’s what’s included in the Agreement:
✔Expert service b our 12,000 professional repair specialists
✔Unlimited service and no charge for parts and labor on all
covered repairs
✔“No-lemon” guarantee – replacement of our covered
product if four or more product failures occur within twelve
months
✔Product replacement if our covered product can’t be fixed
✔Annual Preventive Maintenance Check at our request – no
extra charge
✔Fast help by phone – phone support from a Sears technician
on products requiring in-home repair, plus convenient repair
scheduling
✔Power surge protection against electrical damage due to
power fluctuations
✔Rental reimbursement if repair of our covered product takes
longer than promised
Once ou purchase the Agreement, a simple phone call is all that
it takes for ou to schedule service. You can call an time da or
night, or schedule a service appointment online.
Sears has over 12,000 professional repair specialists, who have
access to over 4.5 million qualit parts and accessories. That’s
the kind of professionalism ou can count on to help prolong the
life of our new purchase for ears to come. Purchase our
Master Protection Agreement toda !
Some limitations and exclusions apply. For prices and
additional information, call 1-800-827-6655.
Sears Installation Service
For Sears professional installation of home appliances, garage
door openers, water heaters, and other major home items, in the
U.S.A. call 1-800-4-MY-HOME®.

3
In Canada
Maintenance Agreements
Your purchase has added value because ou can depend on
Sears HomeCentral® for service. With over 2,400 Service
Technicians and more than a million parts and accessories, we
have the tools, parts, knowledge and skills to back our pledge:
We Service What We Sell.
Your Kenmore® product is designed, manufactured and tested to
provide ears of dependable operation. But like all products, it
ma require service from time to time. The Sears Maintenance
Agreement offers ou an outstanding service program, affordabl
priced.
The Sears Maintenance Agreement
■Is our wa to bu tomorrow’s service at toda ’s price
■Eliminates repair bills resulting from normal wear and tear
■Provides phone support from a Sears technician on products
requiring in-home repair
■Even if ou don’t need repairs, provides an annual Preventive
Maintenance Check, at our request, to ensure that our
product is in proper running condition.
Some limitations apply. For more information about Sears
Canada Maintenance Agreements, call 1-800-361-6665.
ENMORE ELITE®
APPLIANCE WARRANTY
ONE YEAR LIMITED WARRANTY
When installed, operated and maintained according to all
instructions supplied with the product, if this appliance fails due
to a defect in material or workmanship within one ear from the
date of purchase, call 1-800-4-MY-HOME® to arrange for free
repair.
TEN-YEAR LIMITED WARRANTY ON STAINLESS STEEL
DRUM AND PLASTIC TUB
For ten ears from the date of purchase, when this washer is
installed, operated and maintained according to all instructions
supplied with the product, Sears will replace the stainless steel
drum and/or plastic tub due to defective materials or
workmanship. After the first ear, customer assumes an labor
costs associated with replacement of these parts.
If this appliance is used for other than private famil purposes,
this warrant applies for onl 90 da s from the date of purchase.
THIS WARRANTY COVERS ONLY DEFECTS IN MATERIAL
AND WOR MANSHIP. SEARS WILL NOT PAY FOR:
1. Expendable items that can wear out from normal use,
including but not limited to filters, belts, light bulbs, and bags.
2. A service technician to instruct the user in correct product
installation, operation or maintenance.
3. A service technician to clean or maintain this product.
4. Damage to or failure of this product if it is not installed,
operated or maintained according to all instructions supplied
with the product.
5. Damage to or failure of this product resulting from accident,
abuse, misuse or use for other than its intended purpose.
6. Damage to or failure of this product caused b the use of
detergents, cleaners, chemicals or utensils other than those
recommended in all instructions supplied with the product.
7. Damage to or failure of parts or s stems resulting from
unauthorized modifications made to this product.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF
REMEDIES
Customer’s sole and exclusive remed under this limited
warrant shall be product repair as provided herein. Implied
warranties, including warranties of merchantabilit or fitness for a
particular purpose, are limited to one ear or the shortest period
allowed b law. Sears shall not be liable for incidental or
consequential damages. Some states and provinces do not allow
the exclusion or limitation of incidental or consequential
damages, or limitations on the duration of implied warranties of
merchantabilit or fitness, so these exclusions or limitations ma
not appl to ou.
This warrant applies onl while this appliance is used in the
United States and Canada.
This warrant gives ou specific legal rights, and ou ma also
have other rights which var from state to state.
Sears, Roebuck and Co.
Dept. 817WA, Hoffman Estates, IL 60179
Sears Canada Inc.
Toronto, Ontario, Canada M5B 2B8
PRODUCT RECORD
In the space below, record our complete model number, serial
number, and purchase date. You can find this information on the
model and serial number label located on the product.
Have this information available to help ou obtain assistance or
service more quickl whenever ou contact Sears concerning
our appliance.
Model number __ __ __. __________________________________________
Serial number___________________________________________________
Purchase date __________________________________________________
Save these instructions and your sales receipt for future
reference.

4
WASHER SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word DANGER” or WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
IM ORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
■ Read all instructions before using the washer.
■ Do not wash articles that have been previously cleaned
in, washed in, soaked in, or spotted with gasoline,
dry-cleaning solvents, other flammable, or explosive
substances as they give off vapors that could ignite or
explode.
■ Do not add gasoline, dry-cleaning solvents, or other
flammable, or explosive substances to the wash water.
These substances give off vapors that could ignite or
explode.
■ Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been used
for 2 weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot water system has not been
used for such a period, before using the washing
machine, turn on all hot water faucets and let the water
flow from each for several minutes. This will release
any accumulated hydrogen gas. As the gas is
flammable, do not smoke or use an open flame during
this time.
■ Do not allow children to play on or in the washer. Close
supervision of children is necessary when the washer is used
near children.
■ Before the washer is removed from service or discarded,
remove the door or lid.
■ Do not reach into the washer if the drum, tub or agitator is
moving.
■ Do not install or store the washer where it will be exposed to
the weather.
■ Do not tamper with controls.
■ Do not repair or replace any part of the washer or attempt any
servicing unless specifically recommended in this manual or in
published user-repair instructions that you understand and
have the skills to carry out.
■ See Electrical Requirements” for grounding instructions.
WARNING: To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow basic precautions,
including the following:

5
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting installation.
The parts supplied are in the washer basket.
Tools needed for connecting the drain hose and water
inlet hoses:
Parts supplied:
Tools needed for securing the drain hose and leveling
the washer:
Alternate Parts
Parts listed are available from our local Sears store or Sears
Service Center. For further information, call 1-800-4-MY-HOME®
(1-800-469-4663).
■Pliers that open to 1⁹⁄₁₆"
(3.95 cm)
■Flashlight (optional)
A. Drain hose form
B. Water inlet hoses (2)
. Flat water inlet hose washers (4)
D. Beaded tie strap
■Adjustable or open end
wrench ⁹⁄₁₆" (14 mm)
■Level
■Wood block
■Ruler or measuring tape
AB
C
D
If You Have: You Will Need to Buy:
Laundr tub or
standpipe taller
than 96" (2.4 m)
Sump pump s stem (if not alread
available)
1" (2.5 cm)
diameter
standpipe
2" (5 cm) diameter to 1" (2.5 cm)
diameter standpipe adapter,
Part Number 3363920 and connector kit
Part Number 285835
Overhead sewer Standard 20 gal. (76 L) 39" (99 cm) tall
drain tub or utilit sink, sump pump and
connectors (available from local
plumbing suppliers)
Floor drain Siphon break, Part Number 285834;
additional drain hose,
Part Number 8318155 and connector
kit, Part Number 285835
Water faucets
be ond reach of
fill hoses
2 longer water fill hoses:
6 ft (1.8 m) Part Number 76314,
10 ft (3.0 m) Part Number 350008
Lint clogged drain Drain protector, Part Number 367031

6
Location Requirements
Selecting the proper location for our washer improves
performance and minimizes noise and possible washer “walk.”
Your washer can be installed in a basement, laundr room,
closet, or recessed area. See “Drain S stem.”
IMPORTANT: Do not install or store the washer where it will be
exposed to the weather.
Proper installation is our responsibilit .
You will need:
■A water heater set to deliver 120°F (49°C) water to the
washer.
■A grounded electrical outlet located within 4 ft (1.2 m) of
where the power cord is attached to the back of the washer.
See “Electrical Requirements.”
■Hot and cold water faucets located within 3 ft (90 cm) of the
hot and cold water fill valves, and water pressure of
20-100 psi (138-690 kPa) for best performance.
■A level floor with a maximum slope of 1" (2.5 cm) under entire
washer. Installing the washer on carpeting is not
recommended.
■A sturd floor to support the washer weight (washer, water
and load) of 315 lbs (143 kgs).
Do not store or operate our washer in temperatures at or below
32°F (0°C). Some water can remain in the washer and can cause
damage in low temperatures. See “Washer Care” for winterizing
information.
Installation spacing for recessed area and closet
installations
The following spacing dimensions are recommended for this
washer. This washer has been tested for installation with spacing
of 0" (0 cm) clearance on the sides. Recommended spacing
should be considered for the following reasons:
■Additional spacing should be considered for ease of
installation and servicing.
■Additional spacing should be considered on all sides of the
washer to reduce noise transfer.
■For closet installation with a door, minimum ventilation
openings in the top and bottom of the door are required.
Louvered doors with equivalent ventilation openings are
acceptable.
■Companion appliance spacing should also be considered.
*Required spacing
Drain System
The washer can be installed using the standpipe drain s stem
(floor or wall), the laundr tub drain s stem, or the floor drain
s stem. Select the drain hose installation method ou need. See
“Tools and Parts.”
Standpipe drain system—wall or floor (views A & B)
The standpipe drain requires a minimum diameter standpipe of
2" (5 cm). The minimum carr -awa capacit can be no less than
17 gal. (64 L) per minute. A 2" (5 cm) diameter to 1" (2.5 cm)
diameter standpipe adapter kit is available. See “Tools and
Parts.”
The top of the standpipe must be at least 39" (99 cm) high and no
higher than 96" (244 cm) from the bottom of the washer.
Laundry tub drain system (view C)
The laundr tub needs a minimum 20 gal. (76 L) capacit . The top
of the laundr tub must be at least 39" (99 cm) above the floor
and no higher than 96" (244 cm) from the bottom of the washer.
Floor drain system (view D)
The floor drain s stem requires a siphon break that ma be
purchased separatel . See “Tools and Parts.”
The siphon break must be a minimum of 28" (71 cm) from the
bottom of the washer. Additional hoses might be needed.
A. Front view
B. Side view
. loset door with vents
ABC
17"*
(43.2 cm)
1"
(2.5 cm)
1"
(2.5 cm) 27¹⁄₂"
(69.9 cm) 1"*
(2.5 cm) 27"
(68.6 cm) 5"*
(12.7 cm)
14" * max.
(35.6 cm)
3"*
(7.6 cm)
3"*
(7.6 cm)
24 in. *
(155 cm )
2
2
48 in. *
(310 cm )
2
2
AB
(39")
99 cm
CD
39"
(99 cm)
28"
(71 cm)

7
Electrical Requirements
■A 120 volt, 60 Hz., AC onl , 15- or 20-amp, fused electrical
suppl is required. A time-dela fuse or circuit breaker is
recommended. It is recommended that a separate circuit
serving onl this appliance be provided.
■This washer is equipped with a power suppl cord having a
3 prong grounding plug.
■To minimize possible shock hazard, the cord must be
plugged into a mating, 3 prong, grounding-t pe outlet,
grounded in accordance with local codes and ordinances. If a
mating outlet is not available, it is the personal responsibilit
and obligation of the customer to have the properl grounded
outlet installed b a qualified electrician.
■If codes permit and a separate ground wire is used, it is
recommended that a qualified electrician determine that the
ground path is adequate.
■Do not ground to a gas pipe.
■Check with a qualified electrician if ou are not sure the
washer is properl grounded.
■Do not have a fuse in the neutral or ground circuit.
Electrical Shock Hazard
lug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
GROUNDING INSTRUCTIONS
For a grounded, cord-connected washer:
This washer must be grounded. In the event of a malfunction
or breakdown, grounding will reduce the risk of electrical
shock by providing a path of least resistance for electric
current. This washer is equipped with a cord having an
equipment-grounding conductor and a grounding plug. The
plug must be plugged into an appropriate outlet that is
properly installed and grounded in accordance with all local
codes and ordinances.
WARNING: Improper connection of the equipment-
grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or serviceman if you are in
doubt as to whether the appliance is properly grounded.
Do not modify the plug provided with the appliance – if it will
not fit the outlet, have a proper outlet installed by a qualified
electrician.
For a permanently connected washer:
This washer must be connected to a grounded metal,
permanent wiring system, or an equipment grounding
conductor must be run with the circuit conductors and
connected to the equipment-grounding terminal or lead on
the appliance.

8
INSTALLATION INSTRUCTIONS
Before You Start
NOTE: To avoid floor damage, set the washer onto cardboard
before moving across floor.
IMPORTANT:
■Be sure the foam shipping base has been removed from the
bottom of the washer as directed in the Unpacking
Instructions.
■If foam shipping base has not been removed, be sure lid is
secured with tape before la ing washer on its back.
■Removing the foam shipping base is necessar for proper
operation.
Remove Shipping Base and Packing Ring
1. Place cardboard supports from shipping carton on floor
behind washer for support.
2. Using 2 or more people, tip the washer onto its back and
place on cardboard supports.
3. Remove foam shipping base.
4. Set washer upright.
5. Remove tape from lid. Open lid and remove foam packing
ring from washer tub. Keep foam packing ring in case ou
need to move the washer in the future.
Connect Drain Hose
Proper connection of the drain hose protects our floors from
damage due to water leakage. Read and follow these
instructions.
The drain hose is connected to our washer and is stored inside
the washer cabinet.
Remove drain hose from washer cabinet
Pull the corrugated drain hose out of the washer b first grabbing
the pull tie. Continue to pull the hose until the end emerges. Do
not force excess drain hose back into the rear of the washer.
WARNING
Excessive Weight Hazard
Use two or more people to move and install washer.
Failure to do so can result in back or other injury.

9
Laundry tub drain or standpipe drain
Connecting the drain hose form to the corrugated
drain hose
To keep drain water from going back into the washer:
■Do not force excess drain hose into standpipe. Hose should
be secure but loose enough to provide a gap for air.
■Do not la excess hose on the bottom of the laundr tub.
Floor drain
Do not install the drain hose form on to the corrugated drain
hose. You ma need additional parts. See Floor drain under
“Tools and Parts.”
Connect the Inlet Hoses
1. Insert new flat washers (supplied) into each end of the inlet
hoses. Firml seat the washers in the couplings.
Connect the inlet hoses to the water faucets
Make sure the washer basket is empt .
2. Attach the hose labeled hot to the hot water faucet. Screw
on coupling b hand until it is seated on the washer.
3. Attach the hose labeled cold to the cold water faucet. Screw
on coupling b hand until it is seated on the washer.
4. Using pliers, tighten the couplings with an additional
two-thirds turn.
NOTE: Do not overtighten or use tape or sealants on the
valve. Damage to the valves can result.
Clear the water lines
■Run water through both faucets and inlet hoses, into a
laundr tub, drainpipe or bucket, to get rid of particles in the
water lines that might clog the inlet valve screens.
■Check the temperature of the water to make sure that the hot
water hose is connected to the hot water faucet and that the
cold water hose is connected to the cold water faucet.
Connect the inlet hoses to the washer
1. Attach the hot water hose to the inlet valve labeled hot.
2. Attaching one hose coupling first makes it easier to tighten
the connection with pliers.
3. Screw on coupling b hand until it is seated on the washer.
AB
A. Feed end of drain hose into one end of form. Secure the lip of the
form into one of the hose ribs.
B. Bend the hose over the top of the form and feed into the other end
of the form. Secure the lip of form into one of the hose ribs.
A. oupling
B. Washer
AB
Tighten the couplings with an additional two-thirds turn.
A. Hot water inlet valve
B. old water inlet valve
HOT COLD
AB
COLD
HOT

10
4. Using pliers, tighten the coupling with an additional
two-thirds turn.
NOTE: Do not overtighten or use tape or sealants on the
valve. Damage to the valves can result.
5. Attach the cold water hose to the inlet valve labeled cold.
6. Screw on coupling b hand until it is seated on the washer.
7. Using pliers, tighten the coupling with an additional
two-thirds turn.
NOTE: Do not overtighten or use tape or sealants on the
valve. Damage to the valves can result.
Check for leaks
■Turn on the water faucets and check for leaks. A small
amount of water might enter the washer. You will drain this in
a later step.
NOTE: Replace inlet hoses after 5 ears of use to reduce the
risk of hose failure. Record hose installation or replacement
dates for future reference.
■If ou connect onl one water hose, ou must cap off the
remaining water inlet port.
■Periodicall inspect and replace hoses if bulges, kinks,
cuts, wear, or leaks are found.
Secure the Drain Hose
1. Drape the power cord over the console.
2. Remove an cardboard used to move washer.
3. Fasten the drain hose to the laundr tub leg or drain
standpipe with the beaded tie strap. See view A or B.
If the washer faucets and the drain standpipe are recessed,
put the formed end of the drain hose into the standpipe.
Tightl wrap the tie strap around the water inlet hoses and the
drain hose. See view C.
Level the Washer
One washer foot has been installed at a different height on our
new washer. The other three feet were preset at the factor .
Properl leveling our washer will minimize noise and vibration.
1. Slide the washer to its final location.
2. Push on upper front panel to be sure the washer is on its rear
feet.
COLD
HOT
Beaded tie strap
CBA
WARNING
Excessive Weight Hazard
Use two or more people to move and install washer.
Failure to do so can result in back or other injury.
