KENT Auto Sanitiser
Ideal for
Factories, Offices, Hospitals, Malls,
Railways, Shops & Homes
INSTRUCTION MANUAL
12L
Tank
High Capacity

Dear Customer,
At the outset, allow us to thank you for your trust in KENT. We take
pride in our reputation for product quality and industry proven
performance. We are certain that your decision to own a KENT Auto
Sanitiser will go a long way towards keeping you and your employees
in good hygiene & health. We are confident that you will be satisfied
with its performance and that it will serve your need for safer premises
without any compromise on hygiene and cleanliness.
This guide will help you in getting the best out of your KENT Auto
Sanitiser. Please go through this booklet to familiarize yourself with its
operation and maintenance.
You can look forward to years of trouble-free service. To ensure that
the warranty of your Auto Sanitiser is effective, it is important that you
fill up the enclosed warranty card and mail us the installation report
within 15 days of purchase. In case you need any further information,
contact your nearest KENT dealer or branch.
Best Wishes,
KENT RO SYSTEMS LTD.
1. KENT Auto Sanitiser 1
2. Features 1
3. Items in the Box 1
4. Installation Instructions 1
5. Starting-up the Sanitiser 2
6. How it Works 2
7. Priming of the Pump 2
8. Cleaning & Maintainance 3
9. Important Safety Instructions 4
10. Technical Specifications 4
TABLE OF CONTENTS

1 2
KENT AUTO SANITISER
KENT Proudly presents KENT Auto Sanitiser, will go a long way towards keeping you
and your employees in good hygiene & health. We are confident that you will be
satisfied with its performance and that it will serve your need for safer premises
without any compromise on hygiene and cleanliness.
FEATURES
• Transparent tank for sanitiser
• High Storage Capacity of 12L
• Removable tank for cleaning and easy refilling
• Fully automatic and Touchless use for hands free operation
• Optimal and Powerful Spray
• Light on the hand along with the spray to display dispensing
• Bulk Sanitiser are economical in longer run
ITEMS IN THE BOX
1. KENT Auto Sanitiser : 1 No.
2. Screws & Plastic Inserts : 2 Nos. each
3. Sticker Center Drill : 1 No.
4. Syringe (50 ml) : 1 No.
5. Warranty Card : 1 No.
INSTALLATION INSTRUCTIONS
KENT Auto Sanitiser is designed to facilitate only wall-mounting usage.
The sanitiser is easy and convenient to install.
Recommended Site Preparations:
• Single Phase 230 V AC
• Installation space as per dimensions of the sanitiser
• Make sure that the sanitiser is mounted on a wall. Avoid installation on
wooden and metallic stands
• The system and installation must comply with state and local laws
and regulations
Installation Procedure:
Slot holes
Wall Hanging Diagram
1. Paste the central drill sticker on wall at (4.5 feet to 5.0 feet from the ground) as
per your convenience.
2. Ensure that sticker is pasted straight on the wall, then drill holes as per the space
provided on sticker.
3. Now, insert the puff up with the help of a hammer.
4. Screw in two 10X50 self-taping screws, 5.57 inches (141.5 mm) apart horizontally.
5. Carefully hang the purifier on the wall with the help of the wall-mounting slot
holes provided on back side of the sanitiser.
Note: If the wall is not straight or the screws are not properly drilled in an even
position, it will damage your sanitiser.
Note: Keep the device away from heat.
Step-2
1. Connect the power supply.
2. Installation is complete.
STARTING-UP THE SANITISER
• Switch on the power supply
• Fill storage tank to the maximum level
• Before using for the first time run the machine until the liquid
sanitiser comes out from the bottom so that pump will be primed (See
priming procedure)
• Sanitiser is ready to use
HOW IT WORKS
• Place your hand below the bottom of the dispenser at the middle
• Required (to be adjusted by technician only) quantity of the sanitiser
gets sprayed
• Dispenser become ready for the next person after 3 seconds
PRIMING OF THE PUMP
During installation as the pump will be used first time, priming needs to be
done to remove the air in the line so that pump can operate.
Step-1
1. Use Syringe and inject sanitizer into the sanitiser suction pipe.
2. Fill it till the sanitiser can be pushed in.
3. Turn on the power and press the switch on the LH lower side
to turn on continuous spray.
4. Keep pushing sanitiser till spray starts coming.
5. Now block the suction pipe with thumb so that the sanitiser inside does not fall
and put it in the tank.
6. Now press the side switch few times till proper spray starts to come. At this point
all the air from the system has been removed.
7. Place hand below the sanitiser to see that it is sensing properly every time.
8. Machine is now ready for use.
Open the top cover & by
using syringe inject
sanitiser into the sanitiser
suction pipe, during this
keep the sensor ON by
keeping hand in front of it.
Fill it till the sanitiser
can be pushed in.
Keep pushing syring
filled with sanitiser till
spray starts coming.

3 4
IMPORTANT SAFETY INSTRUCTIONS
• If the supply cord is damaged, it must be replaced by the original part in order to
avoid hazard
• Children should be supervised to ensure that they do not play with the appliance
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety
Product : KENT AUTO SANITISER
Product Code : 12011
Product Generic Name : Hand Sanitser
Product Colour : White
Mounting : Wall-mounting
Electrical Input : 230 V AC
Capacity of Sanitizer : 12 L
Dispensing Qty. : Adjustable amount (1-1.5 ml)
Working Voltage : 24 V DC-1.5A
Auto Sensing Distance (range required) : 200mm to 250 mm
Sensing Time : 200mS Typical
Between sensing 3 seconds gap is required
Sensor Type : Infrared Sensor
Hands to be used (Single or multi) : Will work with both options
Net Weight : 7.7 kg
Product Dimensions (mm) : 405 (L) X 330 (W) X 470 (H)
Total Power Consumption : 40W
TECHNICAL SPECIFICATIONS
Switch off the
power supply. Open the upper cover. Remove the tank. Place the tank back.
Refill sanitiser
in tank
CLEANING & MAINTENANCE
• Removable tank for refilling and cleaning
• Sanitiser Refill- open the cover to take the tank out. Fill the sanitiser and put the
tank back
Note: Incase spray nozzle that blocked. Please contact your nearest KENT dealer or
branch, Mishandling of the same may lead to discontinue warranty.
1. Use Syringe and inject sanitizer into the sanitiser suction pipe.
2. Fill it till the sanitiser can be pushed in.
3. Turn on the power and press the switch on the LH lower side
to turn on continuous spray.
4. Keep pushing sanitiser till spray starts coming.
5. Now block the suction pipe with thumb so that the sanitiser inside does not fall
and put it in the tank.
6. Now press the side switch few times till proper spray starts to come. At this point
all the air from the system has been removed.
7. Place hand below the sanitiser to see that it is sensing properly every time.
8. Machine is now ready for use.
Now place hand in front
of centre till proper
spray starts to come. At
this point all the air from
the system has been
removed.
Machine is now
ready for use.
Now block the suction
pipe with thumb so that
the sanitiser inside
does not fall and put it
in the tank.
