KENT Wizard
Cyclonic Vacuum Cleaner
Instruction Manual
8 906019 941216
Imported & Marketed by:
KENT RO SYSTEMS LTD.
4-B, Toy City, Ecotech III, Greater Noida (W). U.P.–201306
Ph.: [phone]
E-mail: [e-mail] | Website: www.kent.co.in.
For customer complaints, contact our Customer Care Officer at:
E-6, 7 & 8, Sector-59, Noida, U.P. -201 309, India. Call: 092-789-12345
E-mail: [e-mail] or visit us at www.kent.co.in Cleans with lower dust discharge
using FOAM filter

Table of Contents
1. Introdruction........................................................................................................................ 1
2. Features of KENT Wizard Cyclonic Vacuum Cleaner.......................................................... 1
3. Know your Product .............................................................................................................. 1
4. Items in the Box................................................................................................................... 2
5. Assembling KENT Wizard Cyclonic Vacuum Cleaner......................................................... 2
6. Using the Appliance............................................................................................................. 3
7. Use of Accessories .............................................................................................................. 3
8. Important Instructions ........................................................................................................ 4
9. Cleaning and Maintenance .................................................................................................. 4
10. Important Safety Instructions ............................................................................................. 6
11. Troubleshooting................................................................................................................... 7
12. Technical Specifications ...................................................................................................... 7
Vacuum Cleaners
Cyclonic
Dear Customer,
At the outset, allow us to thank you for your trust in KENT Wizard
Cyclonic Vacuum Cleaner. At KENT, we take pride in our reputation for
product quality and industry proven performance. We are certain that
your decision to own KENT Wizard Cyclonic Vacuum Cleaner will go a
long way towards keeping you and your family in good health. We are
confident that you will be more than satisfied with its performance
and that it will serve your need for safer and cleaner living without any
compromise.
This guide would help you in getting the best out of your KENT Wizard
Cyclonic Vacuum Cleaner. Please go through the booklet to
familiarise yourself with its operation and maintenance.
With this appliance, you can look forward to years of trouble-free
service. To ensure that the warranty of your KENT Wizard Cyclonic
Vacuum Cleaner is effective, it is important that you fill up the
enclosed warranty card and mail it to us within 15 days of purchase.
In case you require any further information, please contact your
nearest KENT dealer/branch.
Happy Cleaning,


1. Advanced Cyclonic Technology (bagless)
for dust collection.
2. High efficiency motor with strong suction
force for efficient cleaning.
3. Auto power cord retractor.
4. Lightweight.
5. Compact and contemporary design.
Introduction
We at KENT have always believed that a clean and healthy life is a right of every
individual. This ethos is what made us embark on this journey to develop innovative
solutions for cleaning water, vegetable and air. With the use of an innovative
technology and support by a competent service network, we have been able to
create a brand which has become synonymous with well-being and health.
Continuing the tradition, we now present the KENT Wizard Cyclonic Vacuum
Cleaner, with futuristic and state-of-the-art Cyclonic technology and FOAM filters
to provide clean, dust-free and spotless surroundings.
KENT Wizard Cyclonic Vacuum Cleaner does not use filtration bags, as found in
traditional vacuum cleaners available in the market. Instead, air and dust are
sucked at high speed creating a fast-spinning vortex and the dust is separated in
a detachable cylindrical collection vessel or bin. The Cyclonic technology and
FOAM filter in KENT Wizard Cyclonic Vacuum Cleaner also reduces air pollution
with lower dust discharge.
Features of KENT Wizard Cyclonic Vacuum Cleaner
Know Your Product
1 2
Align the
two mark
Fill the cover
into the cup
1. Turbo Brush
2. Metal Telescopic Tube
3. Handle
4. Flexible Hose
5. Carrying Handle
6. Power Cord
7. Cord Retractor Button
8. Wheel
9. Dust Cup
10. On/Off Button
1
2
4
3
56
8
10
7
9
Items in the Box
1. KENT Wizard Cyclonic Vacuum Cleaner : 01 No.
2. Flexible Hose : 01 No.
3. Aluminium Telescopic Tube : 01 No.
4. Floor & Carpet Brush : 01 No.
5. Widemouth Brush : 01 No.
6. Crevice Tool : 01 No.
7. Handle : 01 No.
8. User Guide : 01 No.
Assembling: KENT Wizard Cyclonic Vacuum Cleaner
1. Unpack the unit completely and remove any stickers that can prevent
unit operation.
2. Check the unit for damages. Do not use it in case of any damages.
3. Before switching the unit on, make sure that your home’s main voltage
corresponds to the unit’s operating voltage.
Attaching/Detaching Dust Container
to Vacuum Cleaner’s Body
a. Attaching
Place the bin on the motor unit
as shown in the figure.
b. Detaching
To remove the bin, lift in the direction of arrow.
Attaching/Detaching of the Flexible Hose
a. Attaching
Insert flexible hose into the air intake duct on top of the
appliance. Press until it settles with a click.
b. Detaching
To remove the hose, unplug the appliance and gently pull
the hose attached to the air intake duct.
1. Align the mark
2. Make sure the
contact in surface are
matching completely
3. Adjust the top cover
in the indicating
direction

Attaching/Detaching the Extension Tubes
a. Attaching
Attach the metal telescopic/extension tube to the handle
in the direction of arrow as shown in the figure
b. Detaching
To detach the metal telescopic/extension tube from the
handle, pull gently in the direction of the arrow as shown
in the figure.
Attaching/Detaching of Floor Brush
a. Attaching
To use the turbo brush, attach the other end of the tube to
the brush as shown in the figure.
b. Detaching
To detach the turbo brush, gently pull out.
Always remove the plug from the power socket
before fitting or removing accessories.
Important Instructions
1. Do not operate the vacuum cleaner too close to heaters,
radiators, cigarette butts, etc.
2. Do not plug in the device with wet hands.
3. Before using the vacuum cleaner, remove large or sharp
objects from the floor in order to prevent damage of
paper filter.
4. During unplugging, do not pull electrical cable. Pull out
the plug itself.
 If the suction pipe or telescopic wand stick on pipe is
blocked, switch off vacuum cleaner at once. Clear the blockage
before attempting to start the vacuum cleaner again.
Cleaning and Maintenance
a. Emptying Dust Cup
1. Unplug the appliance.
2. Remove the flexible tube.
4. Take out the dust cup.
5. Press the lock of dust cup's lower cover.
6. Carry away the dust glass cap and throw away the
contents.
7. Replace the dust compartment subassembly until
it is locked.
Using the Appliance
Before using the appliance:
1. Unwind a sufficient length of cable and insert the plug into the
power socket. A yellow mark on the power cable shows the
ideal cable length. Don’t pull the cable beyond the red mark.
2. Press the ON/OFF button to switch the appliance on.
3. To rewind the power cable, press the rewind button with one
hand and guide the cable with the other hand to ensure that it
does not whip, causing any injury or damage.
Use of Accessories
a. Crevice Tool
Ideal for cleaning of radiators, crevices, corners,
baseboards and between cushions.
b. Small Brush
Used for cleaning furniture, venation, blinds, books, lamp
shades, shelves, drapery rods, high shelves and corners.
c. Floor & Carpat Brush
Ideal for daily cleaning of carpets and hard/wooden floors.
3 4
Carpet Hard floor
Extension Tube
Floor Brush
1
2
3

Important Safety Instructions
When using an electrical appliance, basic precaution should always be followed,
including the following:
1. Do not leave the vacuum cleaner on when plugged in. Unplug when not in use
and before servicing.
2. To reduce the risk of electric shock, do not use on wet surfaces.
3. Use the appliance only as described in the manual.
4. Always use manufacturer’s recommended attachments only.
5. Do not use the appliance if cord or plug is damaged or worn out. Replace the
damaged cord or plug immediately.
6. Do not try to service the appliance on your own. Send it to an authorised
service centre.
7. Never use the cord as a handle, close door on the cord, or pull the cord
around sharp edges or corners. Keep the cord away from heated surfaces.
8. Do not unplug the appliance by pulling the cord. Always unplug by pulling the
plug and not the cord.
9. To avoid electric shocks, do not use the appliance with wet hands.
10. Keep hair, loose clothing, fingers and all parts of body away from
moving parts.
11. Turn all controls off before unplugging.
12. Use extra precaution while cleaning stairs.
13. Do not use the appliance to pick any flammable or combustible liquids, such
as gasoline, or use in areas where they may be present.
14. Hold plug when rewinding onto cord reel. Do not allow plug to whip
when rewinding.
15. Unplug before connecting the hose.
16. Do not pick up anything that is burning or leaving smoke, such as cigarettes,
matches or hot ashes.
17. Never use the appliance without filter in place.
18. If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid a hazard.
19. This appliance is suitable for indoor use only.
20. Keep away from children.
5 6
b. Cleaning Filter
1. Filter for air inlet should be cleaned at least twice a year, or when it
becomes visibly solid.
2. Clean FOAM filters whenever you find it filled.
3. Always operate the cleaner with filters and FOAM installed.
Not doing so would result in reduced suction or even motor damage.
4. Disconnect from the electrical outlet before cleaning the filter.
5. Do not use a washing machine to clean filter.
6. Do not use hair drier to dry it.
C. Storage
1. If you do not intend to use the appliance for a long time, store it
carefully.
2. Unplug the appliance.
3. Keep the appliance out of the reach of children.

Vacuum Cleaners
7
Warranty Card
(For sale through dealer)
Product: KENT WIZARD CYCLONIC VACUUM CLEANER (KSL-153)
Serial No.:.............................
CUSTOMER DETAILS:
Customer’s Name: .........................................................................................................
Customer’s Address: .....................................................................................................
Customer Phone No.:....................................................................................................
WARRANTY DETAILS:
Invoice Date:................................................ Invoice No.: .............................................
FOR SERVICE CONTACT:
Service Provider’s Name: ..............................................................................................
Service Provider’s Address:...........................................................................................
Ph.No.: ..........................................................................................................................
Imported and Marketed by:
KENT RO SYSTEMS LTD.
4-B, Toy City, Ecotech III, Greater Noida (W). U.P.–201306.
Ph.: [phone]
E-mail: [e-mail] | Website: www.kent.co.in
Customer Care: 092-789-12345
The appliance does
not switch on.
1. Power Cord is not firmly plugged
into the socket.
2. No power in the main supply.
1. Filters are blocked.
1. Hose choked or some blockage
on the brush.
1. Plug in the unit firmly.
2. Check the fuse or cutout
switch. Replace the fuse or
reset the switch.
3. Call an authorised service
centre.
1. Switch off the cleaner and
disconnect the cleaner from
the main power supply.
2. Remove the filters and clean
them.
1. Switch off the cleaner and
disconnect the cleaner from
the main power supply.
2. Remove the hose and/or brush
and remove any blockage.
The appliance
has weak suction
power.
The hose or
brush does not
pickup any dust.
Problem Possible Cause Possible Solutions
Troubleshooting
Technical Specifications
Model Name
Model Number
Net Weight
Input Power Supply
Max. Vacuum Pressure
Noise
Airflow
Maximum Power
KENT Wizard Cyclonic Vacuum Cleaner
KSL-153
7.20kg
Single Phase 220 V AC, 50 Hz.
>24 Kpa
<80 dB (A)
26 L/s
1200 W

Terms & Conditions of Warranty
KENT warrants all new products manufactured by it to be free from defects in material and
workmanship under normal usage and service from the date of purchase as under:
1. The Warranty period commences from the
date of purchase by the first end-user.
During this Warranty period of one year,
KENT or its Authorized Service Provider
(ASP) will replace or repair any part of
KENT Vacuum Cleaner, that in the opinion
of KENT or its ASP, would be defective in
operation due to faulty material or
workmanship (i.e. manufacturing defects)
with the exception of consumables such as
Filters.
2. The product's plastic body is not covered
under Warranty and hence, it must be
handled with care to guard against
breakage.
3. The original purchaser of the unit can avail
services under Warranty at the point of
sale, by producing the damaged part(s)
along with the original invoice.
4. This Warranty is void if the unit is not
operated under normal conditions or
according to the instructions given in
the manual.
5. Product returned to KENT or its ASP for
Warranty examination must be shipped
freight prepaid.
6. KENT or its ASP shall not be held liable for
claims exceeding the cost of repair of the
defects in workmanship.
7. This Warranty Agreement shall not be
interpreted to render KENT or its ASP
liable for injuries or damages of any kind -
direct, consequential or contingent to
persons or property.
8. KENT or its ASP shall not be held
responsible by representative or buyer for
failure to abide by any of the obligations of
this Warranty Agreement if such failures
are the result of circumstances of Forces
Majeures: such as, but not limited to,
floods, earthquakes, transportation strikes,
labour disputes with outside suppliers or
any other conditions beyond the control of
KENT or its ASP.
9. KENT or its ASP shall not be held liable
for repair or alterations made without
prior written approval; for products
failures resulting from the lack of
proper maintenance.
10. This Warranty Agreement excludes all
products/component parts or damage to
any part of this Vacuum Cleaner which, in
the opinion of KENT or its ASP, have been
subjected to misuse; misapplication;
negligence; alteration; accident or operation
contrary to our instructions, incompatibility
with accessories not installed by KENT or its
ASP, or that have been repaired with
component parts other than those
manufactured by or obtained from KENT or
its ASP. Damage caused by freezing, flood,
fire or Act of God is not covered by this
Warranty. In all such cases regular
charges will apply. This limited Warranty
does not include service to diagnose a
claimed malfunction in this unit.
12. KENT reserves the right to alter or
improve design and specifications at any
time, without any contingent obligations to
prospective buyers or owners of the
products previously sold.
13. Any disagreements and obligations based
upon the purchase of KENT products and
thereby imposed on KENT or its ASP shall
be governed by and construed according to
the laws of INDIA and subject to the
jurisdiction of Delhi Courts only.
14. KENT or its ASP assumes no Warranty
liability in connection with this Vacuum
Cleaner other than that specified herein.
This Warranty is in lieu of all other
warranties, expressed or implied,
including warranties of fitness for a
particular purpose. KENT or its ASP does
not authorize any person or representative
to assume for them any other obligations
on the sale of this Vacuum Cleaner.
15. Under no circumstances, the liability of
KENT or its ASP shall exceed the value of
the product.
16. Under no circumstances are the terms
mentioned above negotiable and no
employee of KENT or its ASP has the
authority to supersede them.
