Kenwood KDW60X10 User manual

Freestanding Dishwasher
KDW60X10
KDW60W10
installation / instructions manual
KDW60X10_60W10_IB_final110317.indd 1 17/03/2011 10:18 AM

contents
unpacking............................................................................................................................ 4
installation........................................................................................................................... 5
location ............................................................................................................................ 5
product overview................................................................................................................ 9
front view ......................................................................................................................... 9
rear view.......................................................................................................................... 9
upper basket.................................................................................................................. 10
lower basket .................................................................................................................. 10
internal view .................................................................................................................. 10
control panel...................................................................................................................11
display screen ................................................................................................................11
wash cycle table ............................................................................................................... 12
before operating ............................................................................................................... 13
to open the door ............................................................................................................ 13
to close the door............................................................................................................ 13
items not suitable for use in the dishwasher ................................................................. 13
adding detergent or detergent tablet.............................................................................. 14
adding rinse aid................................................................................................................ 15
adjusting the rinse aid reservoir .................................................................................... 15
adding salt ..................................................................................................................... 16
adjusting salt consumption ............................................................................................ 17
loading the dishwasher.................................................................................................... 18
before loading the dishwasher ...................................................................................... 18
upper basket.................................................................................................................. 19
- adjusting the upper basket ...................................................................................... 19
- loading the upper basket for 12 place settings........................................................ 19
- hinged cup rack....................................................................................................... 20
lower basket .................................................................................................................. 20
- hinged spikes .......................................................................................................... 20
- loading the lower basket ......................................................................................... 21
cutlery basket ................................................................................................................ 21
- loading the cutlery basket ....................................................................................... 21
starting a wash cycle ....................................................................................................... 22
changing a programme.................................................................................................... 22
at the end of a programme .............................................................................................. 22
switching off the unit ....................................................................................................... 23
unloading the dishwasher ............................................................................................... 23
delay start.......................................................................................................................... 23
half load............................................................................................................................. 23
KDW60X10_60W10_IB_final110317.indd 2 17/03/2011 10:18 AM

cleaning after use............................................................................................................. 24
external care.................................................................................................................. 24
- the door and the door seal ...................................................................................... 24
- the control panel...................................................................................................... 24
internal care................................................................................................................... 24
- ltering system ........................................................................................................ 24
spray arms..................................................................................................................... 25
frost precaution ................................................................................................................ 25
moving the dishwasher.................................................................................................... 25
maintenance after a prolonged period of non-operation.............................................. 25
hints and tips .................................................................................................................... 26
fault code....................................................................................................................... 26
technical problems ........................................................................................................ 26
disposal of the dishwasher ............................................................................................. 28
disposal of packing material ........................................................................................... 28
specications.................................................................................................................... 29
safety warnings ................................................................................................................ 30
KDW60X10_60W10_IB_final110317.indd 3 17/03/2011 10:18 AM

4
unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Thank you for purchasing your new Kenwood Freestanding Dishwasher.
These operating instructions will help you use it properly and safely.
We recommend that you spend some time reading this installation/instruction
manual in order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this installation/
instruction manual for future reference.
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
The Main Unit
Detergent Measuring Spoon x 1
1 full spoon = 20g (approx.)
P.N.: 673002200079
Instruction Manual X 1
P.N.: KDW60X-W10-002
U-shape Hose Holder X 1
P.N.: 673006200003
Salt Funnel X 1
P.N.: 673002200043
Condensation Strip X 1
P.N.: 675001300715
Measuring Cup X 1
60ml (approx)
P.N.: 673006200004
Normal Supply Hose X 1
P.N.: 673000900060
Cutlery Basket
P.N.: 673002200019
and 673002200024
KDW60X10_60W10_IB_final110317.indd 4 17/03/2011 10:18 AM

5
installation
1. Please ensure the dishwasher is installed
by a qualified technician. Refer to the tools
required.
location
When selecting a position for your
freestanding dishwasher you should make
sure the installation surface is flat and
firm, and the room is well ventilated. Avoid
locating your dishwasher near a heat source,
eg. cooker, boiler or radiator. Extreme cold
ambient temperatures may also cause the
appliance not to perform properly. This
dishwasher is not designed for use in a garage
or outdoor installation.
Do not drape the dishwasher with any
covering. When installing, ensure that free
space is left at the sides.
2. Ensure there is clearance each side of the
unit to allow slight sideways movement for
servicing when required. Good levelling is
essential for correct closure and sealing
of the door. When the unit is correctly
levelled, the door should not catch the
inner liner on either side of the cabinet.
The adjustable feet may be loosened or
tightened in order to obtain the optimum
levelling of the unit.
All parts removed must be saved to
do the reinstallation in the future.
Ensure the dishwasher is unplugged
and empty. We recommend that 2
people handle the dishwasher during
installation.
600
600
unit in mm
850
30
850
600
620
min.100
80
level level
level
level
installation
KDW60X10_60W10_IB_final110317.indd 5 17/03/2011 10:18 AM

6
installation
4. The condensation strip must be fitted
to the underside of the worktop above
your dishwasher to protect it against any
moisture. Its purpose is to protect your
worktop’s underside from steam rising from
the dishwasher.
• Ensure the surface is clean prior to
sticking the condensation strip to the
underside of the worktop.
• Remove the backing paper from the
condensation strip.
3. If required, the worktop of the dishwasher
can be removed. The height without
the worktop is 820 mm, the minimum
dimensions required to accommodate the
dishwasher within fitted kitchen furniture
units.
Do not connect the unit to the mains socket
before installation. Ensure you are not
installing the unit right in front of the mains
socket. This is to avoid potential damage to
the back of the unit.
• Stick the condensation strip to the
underside of the worktop.
5. The worktop can be removed by removing
the fixing screws located at the front of the
dishwasher. After removing the screws,
push the cover forward, then lift it away
from the dishwasher.
Failure to attach the condensation
strip could result in damage to the
underside of your worktop!
Stick the Condensation Strip
under the worktop, where you
want to install the dishwasher.
Leave some space
Unscrew
Push forward
Remove the worktop
Step 1
Step 2
KDW60X10_60W10_IB_final110317.indd 6 17/03/2011 10:18 AM

7
installation
7. Make sure your plumbing is suitable for
use with the dishwasher. If in doubt contact
a qualified plumber. This unit MUST BE
connected to COLD WATER MAINS using
the new water inlet hose. OLD HOSE
SETS MUST NOT BE RE-USED. The
water pressure from the water mains
needs to be at a minimum of 0.04 MPa and
a maximum of 1.00MPa.
• Connect one end of the safety water
supply hose to your dishwasher, and
then connect the other end of the hose
to your water mains. Please ensure the
black rubber seal is in place.
• After connecting the hose, turn on your
water mains and check for leaks.
• Connect the dishwasher to the mains
socket.
• Do not bend your drain hose.
6. Position the dishwasher next to a water
tap and a drain. Ensure the water inlet and
drain hoses are not kinked or squashed.
The unit must not stand on the mains
cable.
You may use a Y-adaptor (not included)
for an additional water feed for another
appliance, for example a washing
machine. This is only applicable for
cold water mains. A Y-adaptor is
available from most DIY stores.
water mains
safety water supply hose
Y-Adaptor
(not included)
Connect to
another
appliance
if required.
KDW60X10_60W10_IB_final110317.indd 7 17/03/2011 10:18 AM

8
installation
ST4 screws
water drain hose
U-shaped drain hose
holder
• You may use the U-shaped drain hose
holder to secure your drain hose and to
avoid bending it.
• Secure the water drain hose to the
waste pipe to avoid it coming off during
the washing process.
The waste pipe must only be connected
to the foul drains and not the surface
water drainage system. The water drain
hose should be placed between 40 cm
and 100 cm from the floor level and
must not be extended, otherwise the
unit may not be able to expel the waste
water properly.
KDW60X10_60W10_IB_final110317.indd 8 17/03/2011 10:19 AM

9
product overview
front view
rear view
1. control panel
2. door handle
3. display screen
4. drain hose
5. water inlet
(connect to supply hose)
6. mains cable
(connect to electrical mains outlet)
2
4
3
6
5
1
KDW60X10_60W10_IB_final110317.indd 9 17/03/2011 10:19 AM

10
upper basket
internal view
lower basket
7. cup racks 8. spikes
9. spray arms (1 - under upper basket and
1 - under lower basket)
10. salt reservoir
11. detergent dispenser (dual compartment)
12. cutlery basket
13. filtering system
14. rinse aid dispenser
7
8
7
8
12
13
14
9
10
11
KDW60X10_60W10_IB_final110317.indd 10 17/03/2011 10:19 AM

11
1. half load indicator light
• illuminates when the half load
washing cycle is selected.
• only the upper spray arms will be
in function.
• load the soiled dishes in the
upper basket.
rinse aid refill warning light
• illuminates when the rinse aid
dispenser needs refilling.
salt refill warning light
• illuminates when the salt reservoir
needs refilling.
2. display window
• displays selected program time, delay
start time and fault codes etc.
control panel
1 2 3 4 5 6
1. exterior display window
• displays programme selected, programme
time, delay start time and fault codes etc.
2. salt refill warning light
• illuminates when the salt reservoir needs
refilling.
3. 3 in 1 washing cycle light
• illuminates when the 3 in 1 washing cycle
is selected.
display screen
3. delay start button
• to preset the wash timer and delay the
starting time by up to 24 hours.
• each press of this button increases the
delay start time by 1 hour intervals.
4. half load washing button
• press this button to select the half load
washing cycle.
5. programme button
• press this button to select the washing
programme.
6. on/off button
• to turn the dishwasher on and off.
• the LED light illuminates when the
dishwasher is on.
5
3
4
2
1
4. rinse aid refill warning light
• illuminates when the rinse aid dispenser
needs refilling.
5. half load indicator light
• illuminates when the half load washing
cycle is selected.
• only the upper spray arms will be in
function.
• load the soiled dishes in the upper
basket.
KDW60X10_60W10_IB_final110317.indd 11 17/03/2011 10:19 AM

12
wash cycle table
Programme Cycle
Cycle
Selection
Information
Process
Detergent
Amount
(Pre-wash/ Main
wash)
Running
Time
(min.)
Energy
Consumption
(Kwh)
Water
Consumption
(I)
Rinse
Aid
3 in 1 • Pots,
utensils and
cutlery.
• Highly
soiled.
• pre-wash
(50°C)
• wash (50°C)
• rinse (70°C)
• drying
• 3 in 1 155 1.2 16
intensive • Pots, pans,
casserole
dishes.
Dishes that
have been
sitting with
dried food
on them for
a while.
• pre-wash
(50°C)
• pre-wash
• wash (65°C)
• rinse
• (55°C)
• drying
• pre-wash
(5g)
• main wash
(25g)
130 1.4 22
normal • Pots, plates,
glasses and
lightly soiled
pans.
• Normally
soiled.
• pre-wash
(50°C)
• wash (50°C)
• rinse (65°C)
• drying
• pre-wash
(5g)
• main wash
(25g)
160 1.2 16
economy*
(EN50242)
• Plates,
glasses,
bowls.
• Lightly
soiled.
• pre-wash
• wash (55°C)
• rinse (65°C)
• drying
• pre-wash
(5g)
• main wash
(25g)
155 1.05 13
rinse • For dishes
that need
to be rinsed
and dried
only.
• wash (40°C)
• rinse (70°C)
• drying
• n/a 80 0.8 8
glass • Glasses,
crystal and
fine china.
• A shorter
wash for
lightly soiled
loads.
• pre-wash
• wash (40°C)
• rinse
• (60°C)
• drying
• main wash
(20g)
95 0.8 15
rapid • A shorter
wash for
lightly soiled
loads that
do not need
drying.
• wash (40°C)
• rinse (45°C)
• main wash
(20g)
30 0.45 12
* To comply with Standards of Performance, i.e. EN50242, please ensure to use economy washing
cycle for the test.
Condensing dry technology
• Energy is saved by drying the dishes using the remaining heat after the last rinse cycle.
• Wash cycle times are extended due to this drying method.
• Some wash programmes do not have a drying function, please refer to the Wash Cycle
Table for more details.
KDW60X10_60W10_IB_final110317.indd 12 17/03/2011 10:19 AM

13



the following items are not suitable
small plastic items
(milk bottle nipple)
plastic items that
are not dishwasher safe
crystal glasses
silverware
valuable vases
copper pots and pans
cast iron pans
cracked / chipped china
scratched non-stick cookware
towels and sponges
before operating
to open the door
• Pull the door handle.
• If the door is opened during operation all functions are automatically interrupted.
to close the door
• After loading the dishes, push the baskets fully into the dishwasher.
• Lift the door upwards and push until it clicks into position.
• Do not slam the dishwasher door.
items not suitable for use in the dishwasher
When purchasing new crockery and cutlery, please make sure they are dishwasher-proof. Some
items are not suitable for dishwashers.
• Wooden cutlery and crockery or items with wooden parts may discolour and fade. The glue used
in these items is not dishwasher-proof and wooden handles may come loose after being washed
in a dishwasher.
• Craft items, antiques, valuable vases and decorative glassware are also not suitable for
dishwashers.
• Plastic items (e.g. tupperware) which are not heat resistant may melt or loose shape due to the
high temperature in the dishwasher.
• Copper, brass, tin and aluminium items may discolour or become matt.
• Clouding may occur on glasses and delicate glassware after frequent washing. Do not wash
delicate glassware, or glassware containing lead crystal in a dishwasher. Wash delicate
glassware by hand instead.
• Silver and aluminium parts have a tendency to discolour during washing. Residues like egg
white, egg yolk and mustard often cause discolouring and staining on silver. Therefore, please
clean the residues from silver immediately after use.
KDW60X10_60W10_IB_final110317.indd 13 17/03/2011 10:19 AM

14
adding detergent or detergent tablet
Only use detergents specifically designed for use in dishwashers. To be more environmentally
friendly, please use no more than the correct amount of detergent.
Please follow the steps below to fill the detergent dispenser.
1. Push the button on the lid of the detergent
dispenser in the direction of the arrow until the
flap springs open.
2. Fill the detergent dispenser with detergent
powder or insert the detergent tablet. The
marking indicates the filling level.
Bleach and
Countertop detergent
push up from the right side
Irritant
pre-wash detergent chamber
main wash detergent chamber
or
3. Close the lid firmly so that it clicks into place.
Keep out of the reach of children
• Irritating to eyes.
• Avoid contact with eyes. In case of contact with eyes, rinse
immediately with plenty of water and seek medical advice.
• If swallowed, seek medical advice immediately.
You can choose to add a detergent
tablet alone or to add detergent powder
to both the main wash detergent
chamber and the pre-wash detergent
chamber for your selected wash cycle.
All programmes with pre-wash need an
additional detergent dosage that must
be placed in the pre-wash detergent
chamber (please refer to the wash cycle
table). This detergent will take effect
during the pre-wash phase.
KDW60X10_60W10_IB_final110317.indd 14 17/03/2011 10:19 AM

15
adding rinse aid
Rinse aid helps to ensure water does not cling and leave marks on crockery during the drying phase
and helps crockery dry faster after it has been washed. Only pour rinse aid that is for domestic
dishwashers into the reservoir. This model is designed to use liquid rinse aids only.
Please follow the steps below to pour the rinse aid into the storage reservoir, and the amount will
dispense automatically.
1. Turn the cap and open as indicated.
2. When the cap open marking is aligned, you
may lift the cap up.
3. Pour the rinse aid in until the level indicator
turns completely black in colour and close
the cap.
4. Be careful not to overfill the reservoir. Wipe
up any spills. The approximate volume of
the rinse aid reservoir is 110ml.
open
rinse aid indicator
Rinse aid warning light will illuminate when the reservoir
is running out of rinse aid and requires refilling.
rinse aid warning light
Alternatively, you can judge the amount of rinse aid by checking the rinse aid indicator right next
to the reservoir’s cap. When the indicator is black, it means it is full. When it is clear, it means it is
almost empty.
adjusting the rinse aid reservoir
The rinse aid reservoir has six settings. Both the recommended
setting and the factory setting is “4.” If the dishes are not drying
properly or are spotted, adjust the dial to the next higher number
until your dishes are spot-free.
If the water hardness in your area is soft, you
may not need rinse aid as it may cause white
film to develop on your dishes.
KDW60X10_60W10_IB_final110317.indd 15 17/03/2011 10:19 AM

16
adding salt
If the water in your area is hard, deposits will form on your dishes
and utensils. This appliance contains a salt reservoir for you to
reduce the hardness of the water.
Please follow the steps below to pour the salt into the salt reservoir
and it must be set to correspond to the water hardness level in your
area.
1. Remove the lower basket and unscrew the reservoir cap.
2. Fill the reservoir with approximately 500ml of water (first use
only).
3. Place the funnel provided over the salt reservoir.
4. Pour in approximately 1.2kg of dishwasher salt depending on the
brand used.
5. Clean any excess salt from around the reservoir opening and
then screw the cap on again firmly.
6. Run the “rapid” wash programme immediately (without any
crockery in the dishwasher) to remove any traces of salt from the
compartment.
The salt warning light will illuminate when the reservoir is
running out of salt and requires re-filling.
The salt warning light will cease to illuminate within a few
days depending on how quickly the salt dissolves.
OPEN
Open
Open
Open
salt warning light
KDW60X10_60W10_IB_final110317.indd 16 17/03/2011 10:19 AM

17
adjusting salt consumption
Salt consumption must be adjusted to correspond to the water hardness level in your area. If you
don’t know how hard the water in your home is, please ask the company that supplies water in your
area.
It is recommended that adjustments should be made in accordance with the following chart.
WATER HARDNESS Selector
Position
Salt Consumption
(gram/cycle)
Number of
cycle / 1.2 kgs
˚dh ˚fh ˚Clark mmol/l
0-8 0-14 0-10 0-1.4 / 0 /
8-22 14-39 10-28 1.4-3.9 - 20 60
22-45 39-80 28-56 3.9-8 Mid 40 30
>45 >80 >56 >8 + 60 20
turn
To optimise and customise the level of salt consumption, please follow the steps below to adjust the
salt consumption.
1. Remove the lower basket and unscrew the reservoir cap.
2. There is an arrow-shaped indicator in the reservoir, which you can turn. You may turn it to the “-”
or “+” settings based on the water hardness in your area.
1 ˚dh (German degree) = 1.25mmol/l
1 ˚fh (French degree) = 0.178mmol/l
1 ˚Clark (British degree) = 1.78mmol/l
• Do not use everyday table salt or cooking salt as they contain insoluble
substances which could damage the dishwasher.
• Do not pour detergent into the salt container. This will damage the dishwasher.
KDW60X10_60W10_IB_final110317.indd 17 17/03/2011 10:19 AM

18
loading the dishwasher
before loading the dishwasher
Please observe the following notes before loading your cutlery and crockery into the basket.
• Remove lipstick stains and any food residues from crockery and dishes. Rinse if necessary.
• Dishes and cutlery must not lay inside one another, or cover each other.
• Load your cutlery and crockery so that water can access all surfaces.
• Ensure all items are securely positioned.
• Hollow items such as cups, glasses, pans, etc. must be placed upside down in the basket.
• Wide based items should be placed at an angle so that water can run off them freely.
• The spray arms must not be blocked by items which are too tall or hang through the baskets. If
in doubt, test for free movement by manually rotating the spray arms.
• Ensure that small items cannot fall through the holders in the baskets.
Do not wash items soiled with ash, sand, wax, lubricating grease or paint in the dishwasher.
Ash does not dissolve and can distribute in the dishwasher. Wax, sand, lubricating grease
and paint can cause damage to the dishwasher.
KDW60X10_60W10_IB_final110317.indd 18 17/03/2011 10:19 AM

19
Long items such as soup ladles, mixing spoons and long
knives should be placed lying down across the front of
the upper basket.
For safety reasons, do not operate the dishwasher without the upper and lower baskets in
place.
upper basket
Please use the upper basket for small and lightweight
items such as cups, saucers, glasses, dessert bowls, etc.
Shallow pans or casserole dishes can also be placed in
the upper basket.
remove the stop
lift
slide the basket
out from the rail
adjusting the upper basket
More space can be created for large items on the upper or lower baskets by adjusting the height of
the upper basket.
Ensure that the rail stop is placed back properly after the height adjustment.
loading the upper basket for 12 place settings
For loading the upper basket, please refer to the table below.
Number Item
1 Cups
2 Saucers
3 Glasses
4 Small serving bowl
5 Medium serving bowl
6 Large serving bowl
7 Dessert dishes
1
4
1
1
3
2
7
7
5
6
3
33
33
3
IN
KDW60X10_60W10_IB_final110317.indd 19 17/03/2011 10:19 AM

20
lower basket
We recommend that large and the most difficult to clean items
are placed in the lower basket, such as plates, serving platters,
saucepans, serving bowls, pots, pans, lids etc. We recommend
placing serving dishes and lids at the side of the basket to avoid
blocking the rotation of the spray arms.
raise upwards
hinged cup rack
To make room for taller items in the upper basket, raise the cup rack upwards. You can then lean
the tall glasses against it. You can also remove it when it is not required for use.
raise upwards fold backwards
hinged spikes
The spikes are used for holding plates and a platter. They can be lowered to make more room for
large items. Please refer below for the steps to lower the spikes.
To prevent water dripping from the upper basket onto the dishes in the lower basket,
we recommend that you empty the lower basket first and then the upper basket.
KDW60X10_60W10_IB_final110317.indd 20 17/03/2011 10:19 AM
