Kenwood TK-3312 User manual

SERVICE MANUAL
This product complies with the RoHS directive for the European market. This product uses Lead Free solder.
© 2010-11 PRINTED IN JAPAN
B51-8943-00 (Y)684
UHF FM TRANSCEIVER
TK-3312/3317
CONTENTS
GENERAL....................................................2
SYSTEM SET-UP.........................................3
REALIGNMENT...........................................3
DISASSEMBLY FOR REPAIR.....................9
CIRCUIT DESCRIPTION ...........................12
SEMICONDUCTOR DATA .........................17
COMPONENTS DESCRIPTION................18
PARTS LIST...............................................19
EXPLODEDVIEW......................................26
PACKING ...................................................27
ADJUSTMENT...........................................29
PC BOARD
TX-RX UNIT (X57-7890-21)....................34
SCHEMATIC DIAGRAM ............................38
BLOCK DIAGRAM.....................................44
LEVEL DIAGRAM......................................46
OPTIONAL ACCESSORIES
KNB-29N (Ni-MH Battery Pack)............47
KNB-45L (Li-ion Battery Pack).............47
KNB-53N (Ni-MH Battery Pack)............47
KMC-48GPS (GPS Speaker Microphone) ..47
SPECIFICATIONS..................BACK COVER
Whip antenna
(T90-1039-25) Knob (Selector) (K29-9427-03)
Knob (Volume)
(K29-9309-13)
Plastic cabinet assy
(A02-4095-23)
Button knob
(SIDE1/SIDE2)
(K29-9426-03)
Button knob (PTT)
(K29-9425-03)
Key top (7key)
(K29-9463-12)
K, M Versions

TK-3312/3317
2
Document Copyrights
Copyright 2010 by Kenwood Corporation. All rights re-
served.
No part of this manual may be reproduced, translated,
distributed, or transmitted in any form or by any means, elec-
tronic, mechanical, photocopying, recording, or otherwise,
for any purpose without the prior written permission of Ken-
wood.
Disclaimer
While every precaution has been taken in the prepara-
tion of this manual, Kenwood assumes no responsibility
for errors or omissions. Neither is any liability assumed for
damages resulting from the use of the information contained
herein. Kenwood reserves the right to make changes to any
products herein at any time for improvement purposes.
Firmware Copyrights
The title to and ownership of copyrights for firmware
embedded in Kenwood product memories are reserved for
Kenwood Corporation. Any modifying, reverse engineering,
copy, reproducing or disclosing on an Internet website of the
firmware is strictly prohibited without prior written consent of
Kenwood Corporation. Furthermore, any reselling, assigning
or transferring of the firmware is also strictly prohibited with-
out embedding the firmware in Kenwood product memories.
GENERAL
INTRODUCTION
SCOPE OFTHIS MANUAL
This manual is intended for use by experienced techni-
cians familiar with similar types of commercial grade com-
munications equipment. It contains all required service
information for the equipment and is current as of the pub-
lication date. Changes which may occur after publication
are covered by either Service Bulletins or Manual Revisions.
These are issued as required.
ORDERING REPLACEMENT PARTS
When ordering replacement parts or equipment informa-
tion, the full part identification number should be included.
This applies to all parts : components, kits, or chassis. If the
part number is not known, include the chassis or kit number
of which it is a part, and a sufficient description of the re-
quired component for proper identification.
PERSONAL SAFETY
The following precautions are recommended for personal
safety:
• DONOTtransmituntilallRFconnectorsareveriedse-
cure and any open connectors are properly terminated.
• SHUT OFF and DO NOT operate this equipment near
electrical blasting caps or in an explosive atmosphere.
• Thisequipmentshouldbeservicedbyaqualiedtechni-
cian only.
SERVICE
This transceiver is designed for easy servicing. Refer
to the schematic diagrams, printed circuit board views, and
alignment procedures contained within.
Model Type TX-RX unit Frequency
range Remarks
TK-3312
K, M
X57-7890-21 450~520MHz IF1: 49.95MHz
LOC:50.4MHz
TK-3317 M

TK-3312/3317
3
SYSTEM SET-UP
REALIGNMENT
1. Modes
Mode Function
User mode For normal use.
PC mode Used for communication between the trans-
ceiver and PC.
Mode Function
Data programming
mode Used to read and write frequency data and other features to and from the transceiver.
PC test mode Used to check the transceiver using the PC.
This feature is included in the FPU.
Wireless clone
mode Used to transfer programming data from one transceiver to another.
Firmware version
information mode Used to confirm the internal firmware version.
Self-programming
mode You can program the frequency signaling and other function using only the transceiver.
2. How to Enter Each Mode
Mode Operation
User mode PowerON
PC mode Received commands from PC
Wireless clone mode [<B]+PowerON(Twoseconds)
Firmware version
information mode [Side1]+[Side2]+PowerON(Two seconds)
Self-programming mode [S]+PowerON(Twoseconds)
Choose the type of transceiver
Transceiver programming
Delivery
Merchandise received
Are you using the speaker microphone?
A personal computer, programming interface (KPG-22/22A),
and FPU (programming software) are required for programming.
(The frequency, TX power HI/LOW, and signaling data are
programmed for the transceiver.)
YES
NO
KMC-21, KMC-45 or KMC-48GPS
Speaker microphone
(Option)
Are you using the optional antenna? YES
NO
KRA-23 or KRA-27
Optional antenna
TX/RX 450~520 5.0W TK-3312 K,M
Frequency range (MHz) RF power Type
TX/RX 450~520 5.0W TK-3317 M
User mode
Data programming mode
PC test mode PC tuning mode
PC mode
Wireless clone mode
Firmware version information mode
Self-programming mode

TK-3312/3317
4
3. PC Mode
3-1. Preface
The transceiver is programmed by using a personal com-
puter, a programming interface (KPG-22/22A, USB adapter
(KCT-53U)) and FPU (programming software).
The programming software can be used with a PC. Fig-
ure 1 shows the setup of a PC for programming.
3-2. Connection Procedure
1. Connect the transceiver to the personal computer with
the interface cable and USB adapter (when the interface
cable is KPG-22A, the KCT-53U can be used).
Note:
• You must install the KCT-53U driver in the computer to
use the USB adapter (KCT-53U).
• WhenusingtheUSBadapter(KCT-53U)forthersttime,
plug the KCT-53U into a USB port on the computer with
thecomputerpowerON.
2. WhenthePOWERisswitchedon,usermodecanbeen-
tered immediately. When the PC sends a command, the
transceiver enters PC mode.
When data is read from the transceiver, the red LED
lights.
When data is written to by the transceiver, the green LED
lights.
Note:
• The data stored in the personal computer must match
Model Name and Model Type when it is written into EE-
PROM.
• Do not press the [PTT] key during data transmission or
reception.
3-3. KPG-22/KPG-22A Description
(PC programming interface cable: Option)
The KPG-22/22A is required to interface the transceiver
with the computer. It has a circuit in its D-sub connector
(KPG-22: 25-pin, KPG-22A: 9-pin) case that converts the
RS-232C logic level to the TTL level.
The KPG-22/22A connects the SP/MIC connector of the
transceiver to the RS-232C serial port of the computer.
3-4. KCT-53U Description (USB adapter: Option)
The KCT-53U is a cable which connects the KPG-22A to
a USB port on a computer.
When using the KCT-53U, install the supplied CD-ROM
(with driver software) in the computer. The KCT-53U driver
runs under Windows 2000, XP or Vista (32-bit).
3-5. FPU (Programming Software) Description
The FPU is the programming software for the transceiver
suppliedonaCD-ROM.Thissoftwarerunsunder windows
XP, Vista or 7 on a PC. The software on this disk allows a
user to program the transceiver transceivers via Program-
ming interface cable (KPG-22/22A).
3-6. Programming with PC
If data is transferred to the transceiver from a PC with the
FPU, the data for each set can be modified.
DatacanbeprogrammedintotheEEPROMinRS-232C
format via the SP/MIC jack.
In this mode the PTT line operate as TXD and RXD data
lines respectively.
List of FPU for transceiver
Model Type FPU
TK-3312 K KPG-134D (K)
TK-3312 M KPG-134D (M)
TK-3317 M
Fig. 1
REALIGNMENT
D-SUB
(25-pin)
Transceiver Transceiver Transceiver
KPG-22
PC D-SUB
(9-pin)
KPG-22A
PC
USB
KPG-22A
KCT-53U
PC
PC KPG-22 or KPG-22A or
KPG-22A+KCT-53U
Illustration is KPG-22.
FPU
(KPG-134D)
Tuning cable
(E30-3216-05)
Gray
Gray/Black
1.5D-XV Lead wire
1.5D-XV Shield wire
+
–
+
–
SP
MIC

TK-3312/3317
5
REALIGNMENT
4.Wireless Clone Mode
4-1. Outline
“Wireless Clone Mode” copies the transceiver data to an-
other transceiver.
The dealer can copy the transceiver data to another
transceiver even without the use of a personal computer.
4-2. Example
The transceiver can copy the programming data to one or
more transceivers via RF communication.
The clone source and clone target/s must be in wireless
clone mode.
4-3. Operation
1. To switch the clone target/s to Clone mode, press and
holdthe[<B]keywhileturningthetransceiverpowerON.
2. Wait for 2 seconds. “CLONE” appears on the LCD, fol-
lowed by “FRQTBL 1”.
3. Select a channel table number using the [Selector] knob.
4. To switch the clone source to Clone mode, press and
holdthe[<B]keywhileturningthetransceiverpowerON.
5. Wait for 2 seconds. “CLONE” appears on the LCD, fol-
lowed by “FRQTBL 1”.
6. Select the same channel table number as the clone tar-
get/s.
7. Press the [S] key on the clone source to begin data trans-
mission.When the clone target starts to receive data, the
green LED will light and“CLONING” will appear on the
LCD.The source unit will display “MASTER”.
8. When the clone source finishes sending data, a “confir-
mation”tonewillsoundand“COMPLETE”willappearon
the LCD. If data transmission failed while cloning, the tar-
getunitwillproducedanerrortoneand“CLONENG”will
appear on the LCD.
9. If the cloning fails, no data will be available in the target
unit when it is returned to User mode.
10.When the cloning is successful, the target unit's “Scan”
and “Key lock” functions will return to their default values
(Scan=OFF,Keylock=OFF).
11.The source will remain in clone mode after cloning. The
target unit will return to user mode after a successful
cloning.
Note:
• Thedealercanclonedatatotwoormoretransceiversby
repeating the above procedures.
• Ifthe transceiverswireless clone Mode isconguredas
“Disabled”, the transceiver cannot enter Clone mode.
• The table shown below will cover the frequency tables
used for wireless cloning.
• Wireless clone mode cannot be entered in battery low
state.
• Aunitcannotbea“SourceUnit”ifitisunprogrammed.If
the [S] key is pressed, an “error” tone will sound.
• Onceaunitissettobethesource,itcannotbeatarget
after the data has been transmitted. This protects the
data in the source unit.
• MSKsignalingisusedincloning.
• Electronic interface may cause a failure in data transfer
during Wireless Clone, such as when waveforms or elec-
tromagnetics are being performed at the workbench.
• Wireless clone mode can be used ONLY by the autho-
rized service personnel.
• The wireless clone mode setting must be congured as
“Disable” before being delivered to the end-user.
• Towirelessclone,replacethe antennafromboththe
source transceiver and the target transceiver with a dum-
my load.
• ThetransmitoutputpowerisautomaticallysettoLowin
Clone mode.
4-4. Adding the Data Password
If the Data password is set to the transceiver, you must
enter the password to activate a clone mode.The maximum
length of the password is 6 digits.
The following describes how to enter the password.
1. Press and hold the [<B] key for 2 seconds while turning
the transceiver power on.
2. “CLN.LOCK.R”(When the Read authorization password
issettothetransceiver.) /“CLN.LOCK.W” (Whenthe
Overwritepasswordissettothetransceiver.)isdisplayed
on the LCD.
3. Ifthe [selector]knob isrotated while“CLN.LOCK.R”/
“CLN.LOCK.W”isdisplayed,thenumber(0to9)ashes
on the LCD.
When you press the [C>] key, the currently selected num-
ber is determined.
If you press the [A] key, the least digit of the password is
deleted.
If you press the [S] key after entering the password in this
procedure, “FRQTBL 1” is displayed if the entered pass-
word is correct.
 Ifthepasswordisincorrect,“CLN.LOCK.R”/“CLN.LOCK.
W” is redisplayed.
• Clone frequency table
No. Operating frequency 450~520 (MHz)
1 450.000
2 452.000
3 454.000
4 456.000
5 458.000
6 460.000
7 462.000
8 464.000
9 466.000
10 468.000
11 470.000
12 472.000
13 474.000
14 476.000
15 478.000
16 480.000
17 482.000
18 484.000
19 486.000
20 488.000

TK-3312/3317
6
REALIGNMENT
5. Self Programming Mode
Write mode for frequency data and signaling, etc. To be
usedONLYbytheauthorizedservicepersonmaintainingthe
user's equipment. After programming, reset the FPU to the
“Self- Programming” disabled mode.Transceivers CANNOT
be delivered to the end-user in the self-programming mode.
5-1. Enter to the Self Programming Mode
Press and hold the [S] key for 2 seconds while turning
the transceiver power on.
When the transceiver enters in the self programming
mode, “1- 1” is displayed 2 seconds after “SELF” is dis-
played.
Note:
This mode (self programming mode) cannot be set when
it has been disabled with the FPU.
5-2. Adding the Data Password
If the Data password is set to the transceiver, you must
enter the password to activate a self programming mode.
The maximum length of the password is 6 digits.
The following describes how to enter the password.
1. Press and hold the [S] key for 2 seconds while turning
the transceiver power on.
2. “SLF.LOCK.R”(WhentheReadauthorizationpasswordis
settothetransceiver.)/“SLF.LOCK.W”(WhentheOver-
write password is set to the transceiver.) is displayed on
the LCD.
3. Ifthe[selector]knobisrotatedwhile“SLF.LOCK.R”/“SLF.
LOCK.W”isdisplayed,thenumber(0to9)ashesonthe
LCD.
When you press the [C>] key, the currently selected num-
ber is determined.
If you press the [A] key, the least digit of the password is
deleted.
If you press the [S] key after entering the password in this
procedure, “SELF” is displayed if the entered password is
correct.
 Ifthepasswordisincorrect,“SLF.LOCK.R”/“SLF.LOCK.W”
is redisplayed.
5-3. Channel Selection Mode
In this mode, the Zone or Channel can be selected.
Press and hold the [S] key for 2 seconds while turning
the transceiver power on to enter self programming mode.
When the transceiver enters in the self programming mode,
the transceiver automatically enters the Channel Selection
mode.
2 seconds after displaying “SELF", “1- 1” appears on the
LCD.
The setup item for channel selection mode is as follows.
Setup item Display Remarks
Select
Zone/Channel *** - ***
*** - *** Zone: 1~128
Channel: 1~128
Key operation
Key Key Function
[Selector] Toggle between Zone selection and Channel selec-
tion
[Side1] No action
[Side2] No action
[S] Enter the Item Setting mode
[A] Return to the Channel Selection mode
[<B] Decrement the blinking Zone/Channel number by 1.
Press and hold to decrement in steps of 10.
[C>] Increment the blinking Zone/Channel number by 1.
Press and hold to decrement in steps of 10.
Note:
If a non-existing Zone-Channel is selected and the mem-
ory for all 128 channels is already filled, an error tone will
sound and “MEM.FULL” will appear on the LCD for 2 sec-
onds.
5-4. Item Selection Mode
In this mode, the following items can be selected.
• RXfrequency
• RXsignaling
• TXfrequency
• TXsignaling
• RFpowerHi/Low
• ScanDel/Add
• Beatshifton/off
• Companderon/off
When the [S] key is pressed in the Channel Selection
mode, the transceiver enters the Item Selection mode.
Key operation
Key Key Function
[Selector] The selected item changes
[Side1] No action
[Side2] No action
[S] Enter the Item Setting mode
[A] Return to the Channel Selection mode
[<B] Error tone sounds
[C>] Error tone sounds

TK-3312/3317
7
REALIGNMENT
5-5. Item Setting Mode
In this mode, the selected item in the Item Selection
mode can be programmed.
When the [S] key is pressed in the Item Selection mode,
the transceiver enters the Item Setting mode.
The setup items for item setting mode are as follows
Setup item Display Remarks
1. RX frequency 1. RX FREQ
→
***.*****
Receive frequency
450.00000~520.00000MHz
2. RX signaling
2. RX SIG
TONEOFF/
QT ***.*/
DQT ***N/
DQT ***I
Receive QT/DQT
3.TX frequency 3.TX FREQ →
***.***** Transmit frequency
450.00000~520.00000MHz
4.TX signaling
4.TX SIG →
TONEOFF/
QT ***.*/
DQT***N/
DQT***I
Transmit QT/DQT
5. RF power Hi/Low 5. PWR *** HI/LOW
6. Scan Del/Add 6. SCN *** DEL/ADD
7. Beat shift on/off 7. SFT *** ON/OFF
8. Compander on/off 8. CMP *** ON/OFF
Key operation
Key Key Function
[Selector] Changing the selection item (RX/TX frequency and
RX/TX signaling only)
[Side1] No action
[Side2] No action
[S]
•StorethecurrentsettingsandreturntotheItem
Selection mode without backup.
•AMHzdigitofthefrequencyblinks.(RX/TXfre-
quency only)
•Theiconofthecurrentsignalingconguration
blinks. (RX/TX signaling only)
[A] Abort the current settings and return to the Item
Selection mode without backup.
[<B] Toggle/Decrease the blinking value.
[C>] Toggle/Increase the blinking value.
5-6. Self Programming Mode flow chart
■ Channel selection mode flow chart
■Item selection mode flow chart
Data password
[S]+Power ON SLF.LOCK.R
or
Display
SLF.LOCK.W
SELF I - I
Zone Channel
Self programming mode
[S]
[S][A]
Channel selection mode
[S][A] Zone selection
Channel selection
Item setting mode
[S]
Read authorization password /
Overwrite password entry (6 digits)
When the Read
authorization password is
set to the transceiver.
When the Overwrite
authorization password is
set to the transceiver.
[Selector]
[<B] : Zone/Channel number decrement
[C>] : Zone/Channel number increment
Channel selection mode
[S]
[S][A] 1. RX frequency
[Selector]
[S][A] 2. RX signaling
[Selector]
[S][A] 3. TX frequency
[Selector]
[S][A] 4. TX signaling
[Selector]
[S][A] 5. RF power Hi / Low
[Selector]
[S][A] 6. Scan Del / Add
[Selector]
[S][A] 7. Beat shift on / off
[Selector]
[S][A] 8. Compander on / off
Item setting mode
[Selector]

TK-3312/3317
8
■Item setting mode flow chart 6. Firmware Version Information Mode
TurnthetransceiverONwiththe[Side1]and[Side2]keys
held down.Then, the version is displayed during holding the
[Side1] and [Side2] keys.
REALIGNMENT
[Selector]
[1. RX frequency] or
[3.TX frequency]
[S]
[A] MHz setting
490. 00000
Display
490. 00000
490. 00000
STP 5.00K
--------
--------
[Selector]
[A] kHz setting
[Selector]
[A] Channel step
[Selector]
[<B] / [C>]
[<B] / [C>]
[<B] / [C>]
[S]
[S]
[S]
[S] : Cleared
[A] Frequency clear
[Selector]
[2. RX signaling] or
[4.TX signaling]
[S]
[A] OFF
[2. RX signaling] or
[4.TX signaling]
OFF
DQT I
Display
TONE OFF
QT 67.0
DQT 023N
DQT 023 I
[Selector]
[A] QT
[Selector]
[A] DQT N
[Selector]
[S] :Tone off
[<B] / [C>]
[<B] / [C>]
[S]
[S]
[S][<B] / [C>]
[A] DQT I
5. RF power Hi / Low
[S]
Hi / Low selection Hi Low
[S] : Stored
[A]:
Not
stored
Display
5.PWR HI
[<B] / [C>]
6. Scan Del / Add
[S]
Del / Add selection Del Add
[S] : Stored
[A]:
Not
stored
Display
6.SCN ADD
[<B] / [C>]
[7. Beat shift on/off] or
[8. Compander on/off]
[S]
on / off selection on off
[S] : Stored
[A]:
Not
stored
Display
7.SFT ON or
8.CMP ON
[<B] / [C>]
Current
setting value
Value is not set

TK-3312/3317
9
DISASSEMBLY FOR REPAIR
1. Removing the Case Assembly from the
Chassis
1. Remove the selector knob aand volume knob b.
2. Remove the two screws c.
3. Lift and remove the chassis from the case assembly d.
(Useaat-bladescrewdrivertoeasilyliftthechassis.)
2. Removing the Holder Assembly from
the Chassis
1. Remove the holder from the chassis.
Note: Taking care not to cut the speaker and microphone
lead.
2. Detach the solder of speaker and microphone lead from
the PCB beforehand.
3. Remove the packing efrom the SP/MIC jack of the TX-
RX unit.
3. Removing theTX-RX unit from the
Chassis
1. Remove the eleven screws ffixing the TX-RX unit.
2. Remove the solder of the antenna terminal with a solder-
ing iron g.
3. Remove the solder of the positive terminal with a solder-
ing iron h.
Note: You can remove the TX-RX unit from the chassis
without removing the solder at the positive terminal.
However, in this case, you can not attach the packing
(G53-1605-03) that is on the positive terminal to the
chassis in assembling. So, it is advisable to remove the
solder on the positive terminal first.
4. RemovetheFPCfromtheatcableconnectori.
5. Lift and remove the TX-RX unit from the chassis j.
4. Removing the Battery Release Lever
from the Case Assembly
1. Press the upper part of the lever toward the inside of the
caseassembly.Onesideoftheshaftwillberemoveda.
2. Lift and remove the battery release lever from the case
assembly b.
Note: Scratch and widen the glue hole if there is difficulty
in removing the other end of the shaft.
No glue is required when you reassemble the battery re-
lease lever.
b
a
c
c
d
BLU
YEL
RED
BLK
S+
S-
M+
M-
Note: To remove the Holder Assy from
the Chassis,useaflat-head screwdriver
and insert to this hole.
e
fx2
fx2fx2
g
i
j
h
f
f
f
f
f
b
a

TK-3312/3317
10
DISASSEMBLY FOR REPAIR
5. Attaching the Battery Release Lever to
the Case Assembly
1. Insert one side of the shaft into the hole at the lever fitting
section on the case assembly a.
Caution: The thin spring (G01-4543-14) should be posi-
tioned above the two tabs of the lever.
2. Tilt the battery release lever slightly forward b, so that
the thick spring (G01-4542-04) is positioned below the
case surface.
3. With the thick spring positioned below the case surface,
attach the other side of the shaft to the case assembly
by pressing the battery release lever cuntil it snaps into
place d.
Caution: Be careful not to tilt the battery release lever
too forward.
If the battery release lever is pushed in this state where
the two tabs come below the case surface, there is a
possibility of damaging the two tabs.
6. Assembling the Battery Release Lever
1. Place the lever bonto the stopper a.
2. Place the thick spring conto the lever.
3. Hook the right and left ends of the thin spring donto the
tabs of the stopper, then place the thin spring onto the
lever e.
4. Slide the shaft through the hole of the stopper and lever f.
7. Attaching the PositiveTerminal to the
Chassis
Always attach the positive terminal to the chassis, using
the following procedures, before mounting the TX-RX unit
onto the chassis.
1. Remove the holder assembly bfrom the packing aof
the positive terminal.
2. Mount the packing of the positive terminal into the chas-
sis hole c.
3. Mount the holder assembly into the packing of the posi-
tive terminal d.
A thin spring
Shaft
Tow tabs
A thick spring
ab
c
d
a
b
c
d
e
f
a
c
d
b

TK-3312/3317
11
DISASSEMBLY FOR REPAIR
8. Mounting the Chassis to the Case
Assembly
1. Confirm that the waterproof packing attached to the
circumference of the chassis is securely inserted in the
groove of the chassis a.
2. Insert the upper part of the chassis into the case assem-
bly b.
3. Press the chassis cand the case assembly together to
attach them.
Caution: If the packing of the SP/MIC does not come
to the correct position after attaching the chassis to the
case assembly, reposition the packing with your fingers.
9. Attaching the Antenna Receptacle to
the Chassis
Screw the antenna receptacle to the chassis in the or-
der shown in the drawing so that the antenna receptacle
comes to the center of the case hole.
10.The Nuts of theVolume Knob and
Channel Knob
Note that the shapes, colors and heights of nuts of the
volume knob and channel knob are different from one
another. (The nut of volume knob is silver, and the nut of
channel knob is gold.)
Use the following jig when removing the nuts of the vol-
ume knob and channel knob.
 •Jig(PartNo.:W05-1012-00)
11. Screw sequence for mounting theTX-
RX unit to the chassis
Attach the TX-RX unit to the chassis using the screws in
the order shown in the drawing below.
a
b
Tighten this screw second.
Tighten this screw first.
for Volume knob
(Long) for Selector knob (Short)
TX-RX UNIT
Conponent side view
gh
i
jk
d
eb
fc
a

TK-3312/3317
12
1. Frequency Configuration
The receiver utilizes double conversion. The first IF is
49.95MHz and the second IF is 450kHz. The first Local os-
cillator is supplied from the PLL circuit.
The PLL circuit in the transmitter generates the neces-
sary frequencies.
CIRCUIT DESCRIPTION
2. Receiver System
The receiver system is shown in Figure 2.
Fig. 1 Frequency configuration
Fig. 2 Receiver system
2-1. Front End (RF Amplifier) Circuit
The signal coming from the antenna passes through the
transmit / receive switching diode circuit (D201, D202, D203
and D204) and a BPF (L418 and L419), and is then ampli-
fied by the RF amplifier (Q407).
The resulting signal passes through a BPF (L419, L418,
L491, L414 and L413) and goes to the mixer. These BPFs
are adjusted by variable capacitance diodes (D408, D407,
D405, D404 and D403).The input voltage to the variable ca-
pacitance diodes is a regulated voltage output from the DC
amplifier (IC811).
2-2. First Mixer
The signal from the front end is mixed with the first local
oscillator signal generated in the PLL circuit by Q406 to pro-
duce a first IF frequency of 49.95MHz.
The resulting signal passes through the XF401 MCF to
cut the adjacent spurious and provide the optimum charac-
teristics, such as adjacent frequency selectivity.
TX/RX: 450~520MHz
400.05~
470.05MHz
450~520MHz
1st MIX MCF SP
MIC
CF
450kHz
ANT
ANT
SW RF AMP IF System
X3
multiply
PLL
VCO
49.95MHz 50.4MHz
TX
AMP RF AMP
AF
AMP
MIC
AMP
AF
baseband
TCXO 16.8MHz
SP
ANT
IC401
IF,MIX,DET
Q406
1st MIX
ANT
SW
Q403
X3 multiply
2nd Local
X1
TCXO
16.8MHz
AF
baseband
IC812
BPF1
BPF Q407 RF AMP XF401
MCF
Q405
IF AMP IC815 AF PA
BPF1 1st Local
BPF
CF402 CF401

TK-3312/3317
13
2-3. IF Amplifier Circuit
The first IF signal is passed through a four-pole mono-
lithic crystal filter (XF401) to remove the adjacent channel
signal. The filtered first IF signal is amplified by the first IF
amplifier (Q405) and is then applied to the IF system IC
(IC401).
The IF system IC provides a second mixer, limiting
amplifier, quadrature detector and RSSI (Received Signal
Strength Indicator). The second mixer mixes the first IF sig-
nal with the 50.4MHz signal of the second local oscillator
output (Q403) and produces the second IF signal of 450kHz.
The second IF signal is passed through the ceramic fil-
ter (Wide: CF402, Narrow: CF401) to remove the adjacent
channel signal. The filtered second IF signal is amplified by
the limiting amplifier and demodulated by the quadrature de-
tector with the ceramic discriminator (CD401). The demodu-
lated signal is routed to the audio circuit.
2-4.Wide/Narrow Switching Circuit
Wide and narrow settings can be made for each channel
by switching the ceramic filters CF401 (narrow).
The second IF signal always passes the ceramic filters
CF402 (Wide).
The wide and narrow switching data is output from the
MCU (IC820).
D401 and D402 are switched to ceramic filters when a
narrow mode is selected.
Q404 turns on/off with the Narrow and the IC401 detector
output level is changed to maintain a constant output level
during wide or narrow signals.
Fig. 3 Wide/Narrow switching circuit
2-5. Audio Amplifier Circuit
The demodulated signal from IC401 is sent to an AF am-
plifier through baseband IC (IC812), and is routed to an au-
dio power amplifier (IC815) where it is amplified and output
to the speaker.
2-6. Squelch Circuit
Part of the AF signal from the IC401 enters the FM sys-
tem IC (IC401) again, and the noise component is amplified
and rectified by a filter and an amplifier to produce a DC
voltage corresponding to the noise level.
The DC signal from the FM IC goes to the analog port of
the MCU (IC820). IC820 determines whether or not to output
sounds from the speaker by checking if the input voltage is
higher or lower than the preset value.
To output sounds from the speaker, IC820 sends a high
signal to theAF_CONTlineandturnsIC815onthrough
Q813, Q814, Q818 and Q819.
3.Transmitter System
3-1. Microphone Amplifier Circuit
The signal from the microphone is limited by the AGC
circuit, which is composed of D807, D808, Q810, Q811 and
the mute switch (Q809). IC812 is composed of a high-pass
filter, low-pass filter and pre-emphasis/IDC circuit.
The signal from the microphone and the low speed data
from the MCU (IC820) enter the baseband IC (IC812) and
pass through each path and are mixed inside the IC.
TheoutputsignalfromthebasebandICgoestotheVCO
modulationinput.TheotheroutputsignalgoestotheTCXO
modulation input.
Fig. 4 Microphone amplifier circuit
CIRCUIT DESCRIPTION
IC401
WID/NAR
D401
IFOUT
MXO IFI QUAD
AFOUT
C404
R406
C402
C414
R408
R411
R415
D402
CF401
CF402
C424
R423 R424
Q401
R426 50C
AFOUT
CD401
Q404
R409
IC402
+ -
R471
AGC
SW
D807,808
Q810,811
MIC_MT
X1
TCXO
VCO
LSD
OUT
IC812
Q809
MIC
Baseband
IC

TK-3312/3317
14
3-2. Driver and Final Amplifier Circuit
The signal from the T/R switch (D18 is on) is amplified by
the RF AMP (Q201) and pre-drive amplifier (Q203) to 50mW.
The output of the pre-drive amplifier is amplified by the
drive amplifier (Q204) and the RF final amplifier (Q205) to
5.0W (1W when the power is low).
The drive amplifier and the RF final amplifier consist of
twoMOSFETstages.
The output of the RF final amplifier is then passed
through the harmonic filter (LPF) and antenna switch (D201
and D202) and is applied to the antenna terminal.
3-3. APC Circuit
The APC circuit always monitors the current flowing
through the drive amplifier (Q204) and the RF power ampli-
fier (Q205) and keeps a constant current. The voltage drop
at R307, R309 and R310 is caused by the current owing
through the RF final amplifier. This voltage is applied to the
differential amplifier IC301 (1/2).
IC301 (2/2) compares the output voltage of IC301 (1/2)
with the reference voltage from IC811. The output of IC301
(2/2) controls the VG of the RF power amplifier and the drive
amplifier to make both voltages the same.
The change of power high/low is carried out by the
change of the reference voltage.
CIRCUIT DESCRIPTION
Fig. 5 Driver and final amplifier and APC circuit
4. Frequency Synthesizer Unit
4-1. Frequency synthesizer
The frequency synthesizer consists of theTCXO (X1),
VCO,PLL-IC(IC1),andbufferampliers.
TheTCXOgenerates16.8MHz.Thefrequencystabilityis
1.5ppm within the temperature range of –30°C to +60°C.The
frequency tuning and modulation of theTCXO are done to
applyvoltagetopin1oftheTCXO.TheoutputoftheTCXO
is applied to pin 10 of PLL-IC.
TheVCOconsistsof2VCOandcoversadual
range of 400.05~470.05MHz and 450~520MHz or
350.05~420.05MHzand 400~470MHz.TheVCOgenerates
400.05~470.05MHz or 350.05~420.05MHz for providing the
first local signal for reception. The operating frequency is
generated by Q5 in transmitting mode and Q4 in receiving
mode. The oscillation frequency is controlled by applying
theVCOcontrolvoltage,obtainedfromthephasecompara-
tor (IC1) to the variable capacitance diodes (D6 and D9 in
transmitting mode and D10 and D12 in receiving mode).
The TX pin of IC820 goes “high” in transmitting mode,
causing Q7 and Q4 to turn off, and Q5 turn on. The TX pin
goes “low” in receiving mode.
The output from Q4 and Q5 are amplified by a buffer am-
plifier (Q8) and Q2, and then sent to the PLL-IC.
The PLL-ICconsists of a prescaler, reference divider,
phase comparator, and charge pump. The input signal from
pin 10 and 17 of the PLL-IC is divided down and compared
at the phase comparator. The pulsed output signal of the
phase comparator is applied to the charge pump and trans-
formed into a DC signal in the loop filter (LPF). The DC sig-
nalisappliedtotheCVoftheVCOandlockedtokeepthe
VCOfrequencyconstant.
PLL data is output from PL_STB (pin 20), PL_CLK (pin 8),
and PL_DAT (pin 21) of the MCU (IC820). The data is input
to the PLL-IC when the channel is changed or transmission
is changed to reception and vice versa.PLL lock condition is
always monitored by pin 18 (PL_UL) of the MCU. When the
PLL is unlocked, PL_UL goes low.
ANT
RF FINAL
AMP ANT SW LPF
From
T/R SW
(D18)
D201,202
+B
PC/BPF2
(IC811)
RF
AMP
Q201 Q205
DRIVE
AMP
Q204
VDD VG
Pre-DRIVE
AMP
Q203
IC301
(1/2) IC301 (2/2)
R307
R309
R310

TK-3312/3317
15
CIRCUIT DESCRIPTION
Fig. 6 PLL block diagram
5. Control Circuit
The control consists of the MCU (IC820) and its peripher-
al circuits. It controls the TX-RX unit. IC820 mainly performs
the following;
1) Switching between transmission and reception by PTT
signal input.
2) Reading channel information, frequency, and program
data from the memory circuit.
3) Sending frequency program data to the PLL.
4) Controlling squelch on/off via the DC voltage from the
squelch circuit.
5) Controlling the audio mute circuit via the decode data in-
put.
6) Transmitting tone and encode data.
5-1. Frequency Shift Circuit
The MCU (IC820) and baseband IC (IC812) operates at
a clock frequency of 19.2MHz. The oscillator circuit has the
baseband IC. This oscillator has a circuit that shifts the fre-
quency via Beat shift switch (Q807).
A beat sound may be able to be evaded if “Beat Shift“ is
settoONwhenitisgeneratedintheinternalspurioustrans-
mission modulated sound of the transceiver.
Fig. 7 Frequency shift circuit
5-2. Memory Circuit
The Memory circuit consists of the MCU (IC820) and
EEPROM(IC810).TheEEPROMhasacapacityof512kbits
and stores the channel information, the last channel data,
the scan on status, and other parameters.
■ EEPROM
Note:
 TheEEPROMstorestuning data(Deviation, Squelch,
etc.).
 RealignthetransceiverafterreplacingtheEEPROM.
Fig. 8 Memory circuit
5-3. Low BatteryWarning
The battery voltage is monitored by the MCU (IC820 pin
63: BATT). When the battery voltage falls below the voltage
set by the Low Battery Warning adjustment, the red LED
blinks, notifying the operator that it is time to replace the bat-
tery (when the always option (default setting) under the Bat-
tery Warning function in the FPU is selected). If the battery
voltage falls bellow 5.9V, the transceiver does not transmit
and the warning tone beeps while the PTT switch is pressed.
Low battery warning Battery status
The red LED blinks during
transmission. The battery voltage is low but the transceiver is still usable.
The red LED blinks and the
warning tone beeps while the
PTT switch is pressed.
The battery voltage is lowand
the transceiver cannotbe used
to make calls.
Fig. 9 Low battery warning
RF
AMP
Baseband
IC
VCO
PLL
MCU
IC820 PL_STB,PL_CLK,PL_DAT
IC1
PL_UL
17
10
21
7
BUFF
SWLPF
To mixer
VC
Q9
BUFF
Q8
TCXO
X1 IC812
SW To
RF AMP
TX
(TX: High)
D18
D17Q2
CV
IC812
Baseband IC
H: OFF
L: ON
MCU
XIN
X802
39 40
XOUT XIN
Q807
C854 R857
MCU
BSHIFT
MCU EEPROM
IC820 IC810
63
IC820
MCU
BATT
R824
SB
R829

TK-3312/3317
16
CIRCUIT DESCRIPTION
C
B
A
S
KEY1O KEY2O KEY3O KEY4O KEY1I KEY2I KEY3I KEY4I
EN2 EN1
Selector
IC820
MCU
PF2 PF1 PTT
Side1
Side2
PTT
HSDENC
LSDO
IC820
MCU IC812 Baseband IC
TCXO
3
2
21
MIC
23
MOD1
VCO
24
MOD2
18
ALT
5-4. Key Input
Keys and channel selector circuit.
The signal from the keys and channel selector are direct-
ly input to the MCU, as shown in Figure 10.
Fig. 10 Key input
6. Signaling Circuit
6-1. Encode
■Low-speed data (QT, DQT)
Low-speed data is output from pin 2 of the MCU.The sig-
nal passes through the low pass CR filter, and goes to the
baseband IC (IC812).The signal is mixed with the audio sig-
naland goes to theVCO andTCXO(X1) modulation input
after passing through the D/A converter inside the baseband
IC (IC812) for BAL adjustment.
Fig. 11 Encode
■ High-speed data (2-tone)
High-speed data (HSD) is output from pin 3 of the MCU.
HSD deviation made by an adjustment in the MCU is passed
through the low pass CR filter and then applied to the base-
band (IC812).
The signal is mixed with the audio signal and goes to the
VCOandTCXO.
■MSK/DTMF
The MSK/DTMF signal is generated in the baseband IC
(IC812).The signal passes through the D/A converter (inside
theaudioprocessor:IC812)andisroutedtotheVCO.When
encoding the MSK/DTMF, the microphone input signal is
muted.
6-2. Decode
■QT/DQT
The output signal from the IF IC (IC401) enters the MCU
(IC820) through IC812. IC820 determines whether or not
the QT or DQT matches the preset value, and controls the
AFSW and speaker output sounds according to the squelch
results.
■2-tone
Part of the received AF signal output from the IF IC (IC401)
passes through the baseband IC (IC812) goes to the other
AF amplifier IC808, is compared, and then goes to IC820.
IC820 checks whether or not the 2-tone data is necessary. If
it matches, IC820 carries out a specified operation, such as
turning the speaker on.
■MSK (Fleet Sync)
The MSK input signal from the IF IC (IC401) goes to
IC812. The decoded information is then processed by the
MCU.
■DTMF
The DTMF input signal from the IF IC (IC401) goes to
IC812. The decoded information is then processed by the
MCU.
7. Power Supply
There are five 5V power supplies and three 3.3V power
supplies: 50M, 50V, 50C, 50R, 50T, 33M, 33MS and 33B.
50M and 33M are always output while the power is on.
33MS is always output, but turns off when the power is
turned off, to prevent malfunction of the MCU.
50C is a common 5V and is output when SAVE is not set
toON.
50R is 5V for reception and output during reception.
50T is 5V for transmission and output during transmis-
sion.
50V is 5V for the SP/MIC connector.
33B is 3.3V for the baseband IC (IC812).

TK-3312/3317
17
MCU: F363BEDFEKDLB (TX-RX unit: IC820)
Pin No. Signal Name I/O Function
1 BSHIFT OCPU clock frequency shift
2LSDO O QT/DQT output
3 HSDENC O2-Tone/BEEP output
4 EN1 I Encoder detect for direction
5 EN2 I Pull up for P8_4 (EN2)
6MODE I (Using E8a emulator)
7 NC - NC
8 PL_CLK OPLL IC clock output
9 RESET - Hardware reset input
10 XOUT - NC
11 VSS - GND
12 XIN - Main clock input (19.2MHz)
13 VCC - 3.3V
14 EMPTT OEmergency PTT
15 EN2 I Encoder interrupt
16 CM_IRQ I Baseband IC IRQ
17 INT0 I Battery low interrupt (4.5V)
18 PL_UL I PLL IC unlock input
19 PTT I PTT input
20 PL_STB OPLL IC STB output
21 PL_DAT OPLL IC data output
22 NC NC
23 33MSC O33MS control for switched 33M
24 TXD OSerial data (FPU) to PC
25 RXD I Serial data (FPU) from PC
26 EM_CLK OFor E8a emulator
27 APCSW OAPC enable/disable
28 TX/RX OTX/RX switch H:TX, L: RX
29 50VC O5V AVR control for GPS MIC op-
tion/OPTDET
30 5TC O5T control output
31 EP_DTO O EEPROMICdataoutput
32 EP_CLK O EEPROMICclockoutput
33 CM_DTO O Baseband IC data output
34 EMP OFor FDT tool
35 5RC O5R control output
36 EP_WP O EEPROMICwriteprotectoutput
37 EP_DTI I EEPROMICdatainput
38 EP_CS O EEPROMICchipselectoutput
39 CE OFor FDT tool
40 CM_CLK OBaseband IC clock output
SEMICONDUCTOR DATA
Pin No. Signal Name I/O Function
41 CM_DTI I Baseband IC data input
42 CM_CNS OBaseband IC chip select output
43 DC_SW OAPC voltage discharge switch
44 KEY1O O Key matrix output 1
45 KEY2O O Key matrix output 2
46 KEY3O O Key matrix output 3
47 KEY4O O Key matrix output 4
48 KEY1I I Key matrix input 1
49 KEY2I I Key matrix input 2
50 KEY3I I Key matrix input 3
51 KEY4I I Key matrix input 4
52 PF1 l Side key 1 input
53 PF2 l Side key 2 input
54 LCDBL OLCD backlight switch
L:ON,H:OFF
55 LC_INH OLCD driver IC INH output
56 LC_CLK OLCD driver IC clock output
57 LC_DAT OLCD driver IC date output
58 LC_CE OLCD driver IC chip enble output
59 LC_MOD O LCD driver IC mode output
60 HSDDEC I 2-Tone/5-Tone decode input
61 QT/DQT I QT/DQT decode input
62 CVIN I VCOlockvoltagereadingfor
auto alignment
63 BATT I Battery level input
64 VOX IVOXlevelinput
65 BUSY I RX busy input
66 TH_DET I Temperature level input
67 RSSI I RSSI input
68 WID/NAR OWide Narrow switch
H:WID, L: NAR
69 ASSIST OAssist switch
70 AF_MUT OSpeaker mute output
71 MIC_MT OMic mute output
72 MAN_DN I MAN down
73 5CC O5C control output
74 LEDBLU OBlue LED light control
75 AVSS - GND
76 LEDGRN OGreen LED light control
77 VREF - 3.3V for A/D reference
78 AVCC - 3.3V
79 LEDRED ORed LED light control
80 OPTDET IOptiondetectioninput

TK-3312/3317
18
TX-RX unit (X57-7890-21)
Ref. No. Use / Function Operation / Condition
IC1 PLL IC TX/RX 1st local
IC2,301 OPamplier CVIN/CVADJ amplifier
IC401 FM IC RX FM system
IC402 Comparator Narrow filter switching
IC801 5V AVR 50M
IC802 5V AVR 50C
IC803 5V AVR 50V
IC804 3.3V AVR 33M
IC805 Reset IC Low battery lebel detector
IC806 3.3V AVR 33B
IC807 Reset IC MCU reset signal
IC808 OPamplier HSD amplifier
IC810 EEPROM EEPROM
IC811 OPamplier RX BPF tuning
IC812 Baseband IC Audio processor
IC815 AF amplifier Audio power amplifier
IC817 OPamplier VOXsignalamplier
IC820 MCU Microcontroller unit
IC821 LCD driver
Q2 RF buffer PLL-IC input
Q3 Ripple filter TX/RXVCO
Q4 Oscillator RXVCO
Q5 Oscillator TXVCO
Q6 DC switching TXVCOswitching
Q7 DC switching RXVCOswitching
Q8 RF buffer VCOoutput
Q9 RF amplifier VCOoutput
Q11,12 DC switching Assist switching
Q201 RF amplifier TX amplifier
Q203 RF amplifier Pri-drive amplifier
Q204 FET amplifier Drive amplifier
Q205 FET amplifier Final power amplifier
Q301 DC switching TX FET bias
Q303~306 DC switching APC circuit
Q401 DC switching Q404 control
Q403 Tripler 2nd local (16.8MHz x 3)
Q404 DC switching FM-DET level switching
Q405 IF amplifier 1st IF (49.95MHz)
Q406 Mixer 1st mixer
Q407 RF amplifier RX (VHF)
Q801 DC switching Blue LED
Q802 DC Switching 50T from 50M
Q803 DC Switching 50R from 50M
Q804 DC Switching 33MS from 33M
COMPONENTS DESCRIPTION
Ref. No. Use / Function Operation / Condition
Q805 DC switching Green/Red LED
Q807 DC switching MCU clock shift circuit
Q809 DC switching MIC mute
Q810,811 Amplifier AGC control
Q813 DC switching Q814 control
Q814 DC switching AF power mute
Q815 Level converter EXT PTT/RXD
Q816 Level converter EXT TXD
Q817 DC switching Pop noise mute
Q818,819 AF switching AF power mute
Q820 DC switching Q821 control
Q821 DC switching Backlight LED
Q822 DC switching EMG PTT
D6,9 VARICAP TXVCOtune
D10,12 VARICAP RXVCOtune
D13 Speed up Ripple filter
D14 VARICAP TXVCOassisttune
D15 VARICAP RXVCOassisttune
D16 VARICAP Modulation
D17,18 Switching TX-f/RX 1st local
D201~204 Switching TX/RX ANT switching
D301 5.1V Zone Overvoltageprevention
D401,402 Switching Narrow filter on/through
D403~405 VARICAP RX RF BPT tune
D407,408 VARICAP RX RF BPT tune
D801 LED (green) Busy
D803 Protection Power supply
D804 LED (blue) Signal
D805 LED (red) TX
D806 5.1V Zener Overvoltageprevention
D807,808 Detection MIC level
D809,810 Detection VOXlevel
D817 Speed up LCD back light
D818~821 LED (yellow) Backlight
D824 LED (yellow) Backlight
D829 Key input detect Key1I input
D830 Key input detect Key2I input
D831 Key input detect Key3I input
D832 Key input detect Key4I input

TK-3312/3317
✽ New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
19
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
PARTS LIST
L: Scandinavia K: USA P: Canada
Y: PX (Far East, Hawaii) T: England E: Europe
C: China X: Australia M :OtherAreas
TK-3312/3317
TX-RX UNIT (X57-7890-21)
PARTS LIST
1 1A
✽A02-4095-23 PLASTIC CABINET ASSY
3 2C,2E  B09-0725-03 CAP(SP/MIC)ACCESSORY 
4 1B  B43-1622-04 BADGE(FRONT)   
5 1B B43-1623-04 BADGE(REAR)
6 1E B62-2237-00
INSTRUCTIONMANUALACCESSORY M1
7 1C B62-2238-00
INSTRUCTIONMANUALACCESSORY K,M
9 1A D10-0649-03 LEVER
10 1A D21-0863-04 SHAFT(LEVER)
11 1A  D32-0441-13 STOPPER(LEVER)   
13 2A  E04-0477-15 RFCOAXIALRECEPTACLE(SMA) 
14 3A  E23-1253-04 TERMINAL(GROUND)  
15 2A E23-1254-04 TERMINAL(+VE)
16 1B E37-1165-15
PROCESSEDLEADWIRE(SP/RD)
17 1B E37-1514-05
PROCESSEDLEADWIRE(SP/BLK)
19 3A F20-3353-14 INSULATING SHEET(+VE)
21 2A  G01-4542-04 COILSPRING   
22 2A  G01-4543-14 COILSPRING   
23 2B  G10-1330-04 FIBROUSSHEET(IC)   
24 2A G11-4465-04 RUBBER SHEET(FET)
25 2B G11-4550-04 SHEET(ANT)
26 3A  G13-2009-04 CUSHION(CHASSIS)   
27 3A  G13-2033-04 CUSHION(-VE)   
28 3A  G13-2034-14 CUSHION(CHASSIS(-))  
29 2B
✽ G13-2038-34 CUSHION(X57)   
30 2B  G13-2088-04 CUSHION(IC820)
31 3B
✽ G13-2340-14 CUSHION(CF401/402) 
34 2B  G13-2346-04 CUSHION(X57)   
35 3A G53-1604-03 PACKING(CHASSIS)
36 2A G53-1605-03 PACKING(+VE)
37 2B G53-1802-04 PACKING(SMA)
39 2B  G53-1845-03 PACKING(VOL/SEL)   
40 1B G53-1846-03 PACKING(SP)
41 1B G53-1847-03 PACKING(SP/MIC)
43 2D H12-4251-05 PACKING FIXTURE K,M
44 3D  H52-2300-13 ITEMCARTONCASE   K,M
46 2A  J19-5463-03 HOLDER(+VE)   
47 2A  J19-5473-03 HOLDERASSY(+VE)   
49 1B  J19-5545-14 HOLDERASSY(SP)
48 2C,2E
✽ J19-5549-03 HOLDER(SP/MIC)ACCESSORY 
50 2C,1E  J29-0734-05 BELTCLIPACCESSORY 
52 2A J82-0127-05 FPC
54 1B  K29-9309-13 KNOB(VOL)   
55 1A  K29-9425-03 BUTTONKNOB(PTT)   
56 1A  K29-9426-03 BUTTONKNOB(SIDE1/2)  
57 1B  K29-9427-03 KNOB(SELECTOR)   
58 1A
✽ K29-9463-12 KEYTOP(7KEY)   
A 2A  N14-0848-05 CIRCULARNUT(SELECTOR)  
B 2B  N14-0849-05 CIRCULARNUT(VOL) 
C 2A N30-2604-48
PAN HEAD MACHINE SCREW(SMA)
D 3A N30-2606-48
PAN HEAD MACHINE SCREW
E 2B,3A N83-2005-48
PAN HEAD TAPTITE SCREW
60 2C,2E  N99-2046-05 SCREWSETACCESSORY 
VR1 2A  R31-0676-05 VARIABLERESISTOR  
62 1B T07-0787-05 SPEAKER
63 2D T90-1039-25
WHIPANTENNA(440-490)ACCESSORY K,M
64 1B T91-0672-05 MIC ELEMENT
W1 2A  W02-3748-05 ENCODER(SELECTOR)  
66 1C  W08-0988-05 CHARGERACCESSORY K,M
67 1D  W08-0989-25 ACADAPTERACCESSORY K
68 1D  W08-0992-05 ACADAPTERACCESSORY M
101 2B  B11-1876-03 ILLUMINATIONGUIDE 
102 2B B11-1877-14 FILTER
103 2B B38-0935-05 LCD
D801 B30-1790-05 LED(BLUE)
D804 B30-2314-05 LED(GREEN)
D805 B30-2315-05 LED(RED)
D818-821   B30-2337-05 LED(YELLOW)   
D824   B30-2337-05 LED(YELLOW)   
C1 CC73HCH1H101J CHIP C 100PF J
C3 CC73HCH1H100B CHIP C 10PF B
C4 CK73HB1H102K CHIP C 1000PF K
C5 CC73HCH1H101J CHIP C 100PF J
C7 CC73HCH1H100B CHIP C 10PF B
C8 CC73HCH1H101J CHIP C 100PF J
C9 CK73HB1E103K CHIP C 0.010UF K
C10 CC73HCH1H101J CHIP C 100PF J
C11 CK73HB1E103K CHIP C 0.010UF K
C12 CC73HCH1H101J CHIP C 100PF J
C14 CK73HB1A473K CHIP C 0.047UF K
C15 CK73HB1A224K CHIP C 0.22UF K
C16 ,17 CC73HCH1H101J CHIP C 100PF J
C18 CK73HB1E103K CHIP C 0.010UF K
C19 CC73HCH1H101J CHIP C 100PF J
C20 CK73HB1H471K CHIP C 470PF K
C21 CK73HB1E103K CHIP C 0.010UF K
C24 C92-0588-05 CHIP TNTL 1.5UF 16WV
C25 CS77CA1V0R1M CHIP TNTL 0.1UF 35WV
C27 CK73HB1A224K CHIP C 0.22UF K
C28 CK73HB1H471K CHIP C 470PF K
C29 CC73HCH1H030B CHIP C 3.0PF B
C30 CC73HCH1H080B CHIP C 8.0PF B
C33 CC73HCH1H080B CHIP C 8.0PF B
C34 CC73HCH1H100B CHIP C 10PF B
TK-3312/3317
TX-RX UNIT (X57-7890-21)
K: TK-3312 K M: TK-3312 M
M1: TK-3317 M

TK-3312/3317
20
Ref. No. Address Parts No. Description Desti-
nation
New
parts
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-7890-21)
C35 CK73HB1E103K CHIP C 0.010UF K
C37 ,38 CK73HB1A104K CHIP C 0.10UF K
C39 CK73HB1H471K CHIP C 470PF K
C41 CC73HCH1H101J CHIP C 100PF J
C43 CC73HCH1H101J CHIP C 100PF J
C44 CK73HB1H471K CHIP C 470PF K
C47 CC73HCH1H470J CHIP C 47PF J
C48 CC73HCH1H090B CHIP C 9.0PF B
C49 CK73HB1H471K CHIP C 470PF K
C50 CK73HB1A104K CHIP C 0.10UF K
C51 CC73HCH1H680J CHIP C 68PF J
C53 CC73HCH1H110J CHIP C 11PF J
C55 CK73FB0J106K CHIP C 10UF K
C56 CC73HCH1H040B CHIP C 4.0PF B
C57 CC73HCH1H1R5B CHIP C 1.5PF B
C58 CC73HCH1H020B CHIP C 2.0PF B
C59 CC73HCH1H080B CHIP C 8.0PF B
C60 CC73HCH1H020B CHIP C 2.0PF B
C61 CC73HCH1H040B CHIP C 4.0PF B
C62 ,63 CC73HCH1H101J CHIP C 100PF J
C64 CC73HCH1H080B CHIP C 8.0PF B
C65 CC73HCH1H030B CHIP C 3.0PF B
C66 CC73HCH1H0R3B CHIP C 0.3PF B
C67 CC73HCH1H0R5B CHIP C 0.5PF B
C68 ,69 CC73HCH1H101J CHIP C 100PF J
C70 CK73HB1H471K CHIP C 470PF K
C71 CC73HCH1H330J CHIP C 33PF J
C72 CC73HCH1H100B CHIP C 10PF B
C73 CC73HCH1H150J CHIP C 15PF J
C74 ,75 CK73HB1H471K CHIP C 470PF K
C76 CK73HB1A104K CHIP C 0.10UF K
C77 CC73HCH1H130J CHIP C 13PF J
C78 CK73HB1A105K CHIP C 1.0UF K
C81 CC73HCH1H010B CHIP C 1.0PF B
C85 CC73HCH1H080B CHIP C 8.0PF B
C86 CC73HCH1H050B CHIP C 5.0PF B
C87 CK73HB1H471K CHIP C 470PF K
C88 CC73HCH1H050B CHIP C 5.0PF B
C201 CC73HCH1H330J CHIP C 33PF J
C203 CK73HB1H471K CHIP C 470PF K
C204 CK73HB1A104K CHIP C 0.10UF K
C205 CK73HB1H471K CHIP C 470PF K
C209 CC73HCH1H330J CHIP C 33PF J
C210 CK73GB1A224K CHIP C 0.22UF K
C211 CK73HB1H471K CHIP C 470PF K
C212 CK73HB1A105K CHIP C 1.0UF K
C213 CK73HB1H471K CHIP C 470PF K
C214 CK73HB1A105K CHIP C 1.0UF K
C215 CC73HCH1H110J CHIP C 11PF J
C216 CK73HB1A105K CHIP C 1.0UF K
C217 CC73HCH1H101J CHIP C 100PF J
C218 CC73HCH1H130J CHIP C 13PF J
C219 CK73HB1H471K CHIP C 470PF K
C220 CC73HCH1H150J CHIP C 15PF J
C221 CK73HB1H471K CHIP C 470PF K
C222 CC73HCH1H101J CHIP C 100PF J
C223-225 CK73HB1H471K CHIP C 470PF K
C226 CC73HCH1H300J CHIP C 30PF J
C227 CC73GCH1H240J CHIP C 24PF J
C228 CC73GCH1H0R3B CHIP C 0.3PF B
C229,230 CC73HCH1H151J CHIP C 150PF J
C233 CK73GB1C104K CHIP C 0.10UF K
C234 CK73GB1A105K CHIP C 1.0UF K
C235 CK73HB1E103K CHIP C 0.010UF K
C236 CC73GCH1H0R3B CHIP C 0.3PF B
C240 CC73GCH1H2R5B CHIP C 2.5PF B
C242 CC73GCH1H060B CHIP C 6.0PF B
C243 CC73GCH1H471J CHIP C 470PF J
C244 CK73HB1H471K CHIP C 470PF K
C245 CC73HCH1H090B CHIP C 9.0PF B
C246 CC73GCH1H060B CHIP C 6.0PF B
C247 CC73GCH1H101J CHIP C 100PF J
C248 CC73GCH1HR75B CHIP C 0.75PF B
C249 CC73GCH1H3R5B CHIP C 3.5PF B
C250 CC73GCH1H060B CHIP C 6.0PF B
C253 CC73GCH1H0R3B CHIP C 0.3PF B
C255 CC73GCH1H070B CHIP C 7.0PF B
C256 CC73GCH1H1R5B CHIP C 1.5PF B
C257 CC73GCH1H2R5B CHIP C 2.5PF B
C258 CC73HCH1H050B CHIP C 5.0PF B
C259 CC73GCH1H1R5B CHIP C 1.5PF B
C260 CC73GCH1H150J CHIP C 15PF J
C262,263 CC73GCH1H120J CHIP C 12PF J
C264 CK73HB1H471K CHIP C 470PF K
C265 CC73HCH1H040B CHIP C 4.0PF B
C266 CK73HB1A105K CHIP C 1.0UF K
C301 CK73HB1A104K CHIP C 0.10UF K
C302 CK73HB1H471K CHIP C 470PF K
C303 CK73FB1C105K CHIP C 1.0UF K
C304 CK73HB1H471K CHIP C 470PF K
C305 CC73HCH1H101J CHIP C 100PF J
C307 CC73HCH1H470J CHIP C 47PF J
C308 CC73HCH1H100B CHIP C 10PF B
C309 CK73HB1H471K CHIP C 470PF K
C311 CK73HB1H471K CHIP C 470PF K
C314 CK73HB1H471K CHIP C 470PF K
C315 CK73HB1H102K CHIP C 1000PF K
C402-407 CK73HB1A104K CHIP C 0.10UF K
C408 CC73HCH1H330J CHIP C 33PF J
C409 CK73HB1E103K CHIP C 0.010UF K
C410 CC73HCH1H220J CHIP C 22PF J
C411 CC73HCH1H820J CHIP C 82PF J
C412 CK73HB1H271K CHIP C 270PF K
C414 CK73HB1A104K CHIP C 0.10UF K
C415 CC73HCH1H390J CHIP C 39PF J
C416 CC73HCH1H820J CHIP C 82PF J
C417 CK73HB1H271K CHIP C 270PF K
C418 CK73HB1A104K CHIP C 0.10UF K
C419 CC73HCH1H560J CHIP C 56PF J
C420 CK73HB1H182K CHIP C 1800PF K
C421 CK73HB1H681K CHIP C 680PF K
C422,423 CK73GB0J106K CHIP C 10UF K
C424 CC73HCH1H560J CHIP C 56PF J
C425 CK73HB1E103K CHIP C 0.010UF K
C426 CK73HB1H471K CHIP C 470PF K
C427 CK73HB1A104K CHIP C 0.10UF K
C428 CK73HB1A333K CHIP C 0.033UF K
C429 CC73HCH1H330J CHIP C 33PF J
C431 CK73HB1A104K CHIP C 0.10UF K
C433 CK73HB1E103K CHIP C 0.010UF K
K: TK-3312 K M: TK-3312 M
M1: TK-3317 M
