TK-3301
UHF FM TRANSCEIVER
CONTENTS
GENERAL.....................................................2
REALIGNMENT ...........................................3
DISASSEMBLY FOR REPAIR ......................4
CIRCUIT DESCRIPTION ..............................7
SEMICONDUCTOR DATA.........................10
COMPONENTS DESCRIPTION.................11
TERMINAL FUNCTION .............................11
PARTS LIST ...............................................12
EXPLODED VIEW ......................................18
PACKING....................................................19
ADJUSTMENT ..........................................20
PC BOARD
TX-RX UNIT (X57-7772-70)...................24
SCHEMATIC DIAGRAM ............................28
BLOCK DIAGRAM .....................................32
LEVEL DIAGRAM ......................................34
SPECIFICATIONS ......................................35
Antenna cover
(F07-1882-23)
Button knob (PTT)
(K29-9425-03)
Button knob
(Side1/Side2)
(K29-9426-03)
Knob (Selector)
(K29-9427-03)
Knob (Volume)
(K29-9309-13)
Plastic cabinet assy
(A02-4082-03)

TK-3301
2
Document Copyrights
Copyright 2009 by Kenwood Corporation. All rights re-
served.
No part of this manual may be reproduced, translated,
distributed, or transmitted in any form or by any means,
electronic, mechanical, photocopying, recording, or other-
wise, for any purpose without the prior written permission
of Kenwood.
Disclaimer
While every precaution has been taken in the preparation
of this manual, Kenwood assumes no responsibility for er-
rors or omissions. Neither is any liability assumed for dam-
ages resulting from the use of the information contained
herein. Kenwood reserves the right to make changes to any
products herein at any time for improvement purposes.
GENERAL
INTRODUCTION
SCOPE OF THIS MANUAL
This manual is intended for use by experienced techni-
cians familiar with similar types of commercial grade com-
munications equipment. It contains all required service
information for the equipment and is current as of the pub-
lication date. Changes which may occur after publication
are covered by either Service Bulletins or Manual Revisions.
These are issued as required.
ORDERING REPLACEMENT PARTS
When ordering replacement parts or equipment informa-
tion, the full part identification number should be included.
This applies to all parts : components, kits, or chassis. If the
part number is not known, include the chassis or kit number
of which it is a part, and a sufficient description of the re-
quired component for proper identification.
PERSONAL SAFETY
The following precautions are recommended for personal
safety:
• DO NOT transmit until all RF connectors are verified se-
cure and any open connectors are properly terminated.
• SHUT OFF and DO NOT operate this equipment near
electrical blasting caps or in an explosive atmosphere.
• This equipment should be serviced by a qualified techni-
cian only.
SERVICE
This transceiver is designed for easy servicing. Refer to
the schematic diagrams, printed circuit board views, and
alignment procedures contained within.
Destination Number of CH Channel No. Frequency Signaling RF power output
E,T 16 channel
CH1 446.00625MHz 94.8Hz
0.5W
CH2 446.09375MHz 88.5Hz
CH3 446.03125MHz 103.5Hz
CH4 446.06875MHz 79.7Hz
CH5 446.04375MHz 118.8Hz
CH6 446.01875MHz 123.0Hz
CH7 446.08125MHz 127.3Hz
CH8 446.05625MHz 85.4Hz
CH9 446.00625MHz 107.2Hz
CH10 446.09375MHz 110.9Hz
CH11 446.03125MHz 114.8Hz
CH12 446.06875MHz 82.5Hz
CH13 446.04375MHz D132N
CH14 446.01875MHz D155N
CH15 446.05625MHz D134N
CH16 446.08125MHz D243N

TK-3301
3
REALIGNMENT
1. Modes
User mode
Data programming mode
PC test mode PC tuning mode
PC mode
Mode Function
User mode For normal use.
PC mode Used for communication between the trans-
ceiver and PC.
Data programming
mode
Used to read and write frequency data and
other features to and from the transceiver.
PC test mode Used to check the transceiver using the PC.
This feature is included in the FPU.
2. How to Enter Each Mode
Mode Operation
User mode Power ON
PC mode Received commands from PC
3. PC Mode
3-1. Preface
The transceiver is programmed by using a personal com-
puter, a programming interface (KPG-22/22A, USB adapter
(KCT-53U)) and FPU (programming software).
The programming software can be used with a PC. Figure
1 shows the setup of a PC for programming.
3-2. Connection Procedure
1. Connect the transceiver to the personal computer with
the interface cable and USB adapter (when the interface
cable is KPG-22A, the KCT-53U can be used).
Note:
• You must install the KCT-53U driver in the computer to
use the USB adapter (KCT-53U).
• When using the USB adapter (KCT-53U) for the first time,
plug the KCT-53U into a USB port on the computer with
the computer power ON.
2. When the POWER is switched on, user mode can be en-
tered immediately. When the PC sends a command, the
transceiver enters PC mode.
When data is read from the transceiver, the red LED
lights.
When data is written to the transceiver, the green LED
lights.
Note:
• The data stored in the personal computer must match
Model Name and Model Type when it is written into EE-
PROM.
• Do not press the [PTT] key during data transmission or
reception.
3-3. KPG-22/KPG-22A Description
(PC programming interface cable: Option)
The KPG-22/22A is required to interface the transceiver
with the computer. It has a circuit in its D-sub connector
(KPG-22: 25-pin, KPG-22A: 9-pin) case that converts the RS-
232C logic level to the TTL level.
The KPG-22/22A connects the SP/MIC connector of the
transceiver to the RS-232C serial port of the computer.
3-4. KCT-53U Description (USB adapter: Option)
The KCT-53U is a cable which connects the KPG-22A to a
USB port on a computer.
When using the KCT-53U, install the supplied CD-ROM
(with driver software) in the computer. The KCT-53U driver
runs under Windows 2000, XP or Vista 32-bit.
3-5. FPU (Programming Software) Description
The FPU is the programming software for the transceiver
supplied on a CD-ROM. The software on this disk allows a
user to program the transceiver via Programming interface
cable (KPG-22/22A).
The FPU model refer to “List of FPU for transceiver” be-
low.
3-6. Programming with PC
If data is transferred to the transceiver from a PC with the
FPU, the data for each set can be modified.
Data can be programmed into the EEPROM in RS-232C
format via the SP/MIC jack.
In this mode the PTT line operate as TXD and RXD data
lines respectively.
List of FPU for transceiver
Model Type FPU
TK-3301 E,T KPG-121D

TK-3301
4
REALIGNMENT
DISASSEMBLY FOR REPAIR
1. Removing the Case Assembly from the Chassis
1. Remove the volume knob qand channel knob w.
2. Remove the two screws e.
3. Lift and remove the chassis from the case assembly r.
(Use a flat-blade screwdriver to easily lift the chassis.)
:@
.
;
.
2. Removing the TX-RX unit from the Chassis
1. Detach the solder of speaker wire from the PCB before-
hand.
2. Remove the packing tfrom the SP/MIC jack of the TX-
RX unit.
3. Remove the ten screws yfixing the TX-RX unit.
4. Remove the solder of the antenna terminal with a solder-
ing iron u.
5. Remove the solder of the positive terminal with a solder-
ing iron i.
Note: You can remove the TX-RX unit from the chas-
sis without removing the solder at the positive terminal.
However, in this case, you can not attach the packing
(G53-1605-03) that is on the positive terminal to the chas-
sis in assembling. So, it is advisable to remove the solder
on the positive terminal first.
6. Remove the FPC from the flat cable connector o.
7. Lift and remove the TX-RX unit from the chassis !0.
=
B
B
B
B
B
B
B
2

>
8
PC
KPG-22 or KPG-22A or
KPG-22A+KCT-53U
Illustration is KPG-22
FPU
Tuning cable
(E30-3216-05)
D-SUB
(25-pin)
Transceiver Transceiver Transceiver
KPG-22
PC
Gray
Gray/Black
1.5D-XV Lead wire
1.5D-XV Shield wire
+
–
+
–
SP
MIC
D-SUB
(9-pin)
KPG-22A
PC
USB
KPG-22A
KCT-53U
PC
Fig. 1

TK-3301
5
3. Removing the Battery Release Lever
from the Case Assembly
1. Press the upper part of the lever toward the inside of the
case assembly. One side of the shaft will be removed q.
2. Lift and remove the battery release lever from the case
assembly w.
@
:
4. Attaching the Battery Release Lever to
the Case Assembly
1. Insert one side of the shaft into the hole at the lever fit-
ting section on the case assembly q.
Caution: The thin spring (G01-4543-14) should be posi-
tioned above the two tabs of the lever.
2. Tilt the battery release lever slightly forward w, so that
the thick spring (G01-4542-04) is positioned below the
case surface.
3. With the thick spring positioned below the case surface,
attach the other side of the shaft to the case assembly
by pressing the battery release lever euntil it snaps into
place r.
Caution: Be careful not to tilt the battery release lever
too forward.
If the battery release lever is pushed in this state where
the two tabs come below the case surface, there is a
possibility of damaging the two tabs.
A thin spring
Shaft
Tow tabs
A thick spring
:@
.
;
5. Assembling the Battery Release Lever
1. Place the lever wonto the stopper q.
2. Place the thick spring eonto the lever.
3. Hook the right and left ends of the thin spring ronto the
tabs of the stopper, then place the thin spring onto the
lever t.
4. Slide the shaft through the hole of the stopper and lever
y.
:
@
.
;
=
B
6. Attaching the Positive Terminal to the Chassis
Always attach the positive terminal to the chassis, using
the following procedures, before mounting the TX-RX unit
onto the chassis.
1. Remove the holder assembly wfrom the packing qof
the positive terminal.
2. Mount the packing of the positive terminal into the chas-
sis hole e.
3. Mount the holder assembly into the packing of the posi-
tive terminal r.
:
.
;
@

TK-3301
6
7. Mounting the Chassis to the Case Assembly
1. Confirm that the waterproof packing attached to the
circumference of the chassis is securely inserted in the
groove of the chassis q.
2. Attach the speaker with waterproof packing to the
speaker recess of the case assembly w. Make sure the
speaker clasp is securely inserted.
3. Tighten the speaker clasp into the case assembly with
the screw.
4. Insert the upper part of the chassis into the case assem-
bly e.
Caution: Take care that the speaker lead wire is not
caught by the microphone element.
5. Press the chassis rand the case assembly together to
attach them.
Caution: If the packing of the SP/MIC does not come
to the correct position after attaching the chassis to the
case assembly, reposition the packing with your fingers.
@
:
Confirm that the
waterproof packing is
securely inserted in the
groove of the chassis.
.
;
;
;
DISASSEMBLY FOR REPAIR
8. The Nuts of the Volume Knob and Channel Knob
Note that the shapes, colors and heights of nuts of the
volume knob and channel knob are different from one
another. (The nut of volume knob is silver, and the nut of
channel knob is gold)
Use the following jig when removing the nuts of the vol-
ume knob and channel knob.
• Jig (Part No.: W05-1012-00)
Volume knob
(Silver)
Channel knob
(Gold)
9. Screw sequence for mounting the TX-
RX unit to the chassis
Attach the TX-RX unit to the chassis using the screws in
the order shown in the drawing below.
TX-RX UNIT
Component side view
@
;=
B>
2
:

8
.

TK-3301
7
1. Frequency Configuration
The receiver utilizes double conversion. The first IF is
38.85MHz and the second IF is 450kHz. The first local oscil-
lator signal is supplied from the PLL circuit.
The PLL circuit in the transmitter generates the neces-
sary frequencies. Fig. 1 shows the frequencies.
ANT
TX/RX : 446.00625~
446.09375MHz
ANT
SW
RF
AMP
TX
AMP
RF
AMP
1st MIX MCF
38.85MHz
CF
450kHz
IF
SYSTEM
AF
AMP
SP
RX:
407.15625~
407.24375
MHz PLL
VCO
MIC
AMP
MIC
TX: 446.00625~
446.09375MHz
38.4MHz
X3
multiply TCXO 12.8MHz
Fig. 1 Frequency configuration
2. Receiver
The receiver is double conversion super-heterodyne, de-
signed to operate in the frequency range 446MHz.
The frequency configuration of the receiver is shown in
Fig. 2.
ANT
ANT
SW
BPF
RF AMP
Q204
MIXER
Q203
IF AMP
Q202
BPF
1st Local
MCF
XF201
IC201
IF, MIX, DET
IC308
AQUA-L
Q2
X3 multiply
X1
TCXO
CF201
2nd Local 12.8MHz
AF VOL
IC309
AF PA SP
Fig. 2 Receiver section
■Front End (RF AMP)
The signal coming from the antenna passes through the
transmit/receive switching diode circuit, (D103, D104 and
D106) passes through a BPF (L213 and L212), and is ampli-
fied by the RF amplifier (Q204).
The resulting signal passes through a BPF (L209, L207
and L206) and goes to the mixer. These BPFs are non-vari-
able type.
CIRCUIT DESCRIPTION
■First Mixer
The signal from the front end is mixed with the first local
oscillator signal generated in the PLL circuit by Q203 to pro-
duce a first IF frequency of 38.85MHz.
The resulting signal passes through the XF201 MCF to
cut the adjacent spurious and provide the opitimun charac-
teristics, such as adjacent frequency selectivity.
■IF Amplifier Circuit
The first IF signal is passed through a four-pole monolithic
crystal filter (XF201) to remove the adjacent channel signal.
The filtered first IF signal is amplified by the first IF ampli-
fier (Q202) and then applied to the lF system IC (IC201).
The IF system IC provides a second mixer, limiting amplifier,
quadrature detector and RSSI (Received Signal Strength In-
dicator). The second mixer mixes the first IF signal with the
38.4MHz of the second local oscillator output (TCXO X1 and
Q2) and produces the second IF signal of 450kHz.
The second IF signal is passed through the ceramic filter
(CF201) to remove the adjacent channel signal. The filtered
second IF signal is amplified by the limiting amplifier and
demodulated by the quadrature detector with the ceramic
discriminator (CD201). The demodulated signal is routed to
the audio circuit.
■Audio Amplifier Circuit
The demodulated signal from IC201 goes to AF amplifier
through IC308.
The signal then goes through an AF volume control , and
is routed to an audio power amplifier (IC309) where it is am-
plified and output to the speaker.
■Squelch
Part of the AF signal from the IC enters the FM IC (IC201)
again, and the noise component is amplified and rectified by
a filter and an amplifier to produce a DC voltage correspond-
ing to the noise level.
The DC signal from the FM IC goes to the analog port
of the MCU (IC306). IC306 determines whether to output
sounds from the speaker by checking whether the input
voltage is higher or lower than the preset value.
To output sounds from the speaker, IC306 sends a high
signal to the AF_CONT line and turns IC309 on through
Q312, Q313, Q314, Q315 and Q316. (See Fig. 4)
IC201: FM IF
IF amp SIGNAL
DTMF IC308
AQUA-L
QT/DQT
BUSY QT/DQT IN
IC306
MCU
AF_CONT
SP
Q315,316
IC309
AF PA
Q312,313,314
CLK, DATA,
STD, LOADN
SW
SW
Fig. 3 AF amplifier and squelch

TK-3301
8
■Receive Signaling
• QT/DQT
The output signal from FM IC (IC201) enters the MCU
(IC306) through IC308. IC306 determines whether the QT or
DQT matches the preset value, and controls the SP MUTE
and the speaker output sounds according to the squelch re-
sults.
3. PLL Frequency Synthesizer
The PLL circuit generates the first local oscillator signal
for reception and the RF signal for transmission.
■PLL
The frequency step of the PLL circuit is 5 or 6.25kHz.
A 12.8MHz reference oscillator signal is divided at IC1 by
a fixed counter to produce an oscillator (VCO) output signal
which is buffer amplified by Q3 then divided in IC1 by a pro-
grammable counter. The divided signal is compared in phase
with the 5 or 6.25kHz reference signal from the phase com-
parator in IC1. The output signal from the phase comparator
is filtered through a low-pass filter and passed to the VCO
to control the oscillator frequency. (See Fig. 5)
■VCO
The operating frequency is generated by Q5 in transmit
mode and receive mode. The oscillator frequency is con-
trolled by applying the VCO control voltage, obtained from
the phase comparator, to the varactor diodes (D4 and D8).
The outputs from Q5 is amplified by Q9 and sent to the
RF amplifiers.
■Unlock Detector
If a pulse signal appears at the LD pin of IC1, an unlock
condition occurs, and the DC voltage obtained from C4 and
Q1 causes the voltage applied to the MCU to go low. When
the MCU detects this condition, the transmitter is disabled,
ignoring the push-to-talk switch input signal.
D4,8
Q5
VCO
Q9
BUFF AMP
Q3
BUFFER
Q11
RF AMP
LPF
LPF
REF OSC
1/M
1/N
Phase
comparator
Charge
pump
5 or 6.25kHz
5 or 6.25kHz
PLL DATA
X1
12.8MHz
IC1
PLL IC
Fig. 4 PLL circuit
4. Transmitter System
■Microphone Amplifier
The signal from the microphone passes through the
IC308. When encoding DTMF, it is turned OFF for muting
the microphone input signal by IC308.
The signal passes through the Audio processor (IC308)
for the maximum deviation adjustment, and goes to the
VCO modulation input.
AGC
LPF
LPF
VCO
LPF TCXO
MIC
DTMF
IC308
AQUA-L
IC306
MCU
QTVCO
QTTCXO
X1
Fig. 5 Microphone amplifier
■Drive and Final Amplifier
The signal from the T/R switch (D10 is on) is amplified by
the pre-drive (Q101 and Q102) and the drive amplifier (Q103).
The output of the drive amplifier is amplified by the RF
power amplifier (Q106) to 0.5W. The output of the RF
power amplifier is then passed through the harmonic filter
(LPF) and antenna switch (D103) and applied to the antenna
terminal.
From
T/R SW
(D10)
Drive
AMP
RF
AMP
Pre-drive
AMP
Q102Q101 Q103
RF power
AMP
Q106
ANT
SW LPF
D103
ANT
VDD
VG
IC101
(1/2)
IC101
(2/2)
R120
R123
R126
+B
PCTV
(IC306)
5T5T
VD VG
Fig. 6 Drive and final amplifier and APC circuit
■APC Circuit
The APC circuit always monitors the current flowing
through the drive amplifier and RF power amplifier (Q103
and Q106) and keeps a constant current.
The voltage drop at R120, R123 and R126 is caused by
the current flowing through the RF power amplifier and
drive amplifier, and this voltage is applied to the differential
amplifier IC101 (1/2).
IC101(2/2) compares the output voltage of IC101 (1/2)
with the reference voltage from IC306. The output of IC101
CIRCUIT DESCRIPTION

TK-3301
9
(2/2) controls the VG of the RF power amplifier and drive
amplifier to make both voltages the same.
The change of power high/low is carried out by the
change of the reference voltage.
■Encode Signaling
• QT/DQT
QT/DQT data of the QTTCXO Line is output from pin 14
of the MCU. The signal passes through a low-pass CR filter
and goes to the TCXO (X1).
The QT/DQT data of the QTVCO Line is output from pin
15 of the MCU. The signal passes through a low pass CR fil-
ter, mixes with the audio signal, and goes to the VCO modu-
lation input. TX deviation is adjusted by the MCU.
5. Power Supply
There are four 5V power supplies in the transceiver: 5M,
5C, 5R, and 5T. 5M for MCU is always output while the
power is on. 5M is always output, but turns off when the
power is turned off to prevent malfunction of the MCU.
5C is a common 5V and is output when SAVE is not set
to OFF.
5R is 5V for reception and output during reception.
5T is 5V for transmission and output during transmission.
6. Control Circuit
The control circuit consists of a MCU (IC306) and its
peripheral circuits. It controls the TX-RX unit. IC306 mainly
performs the following:
1) Switching between transmission and reception by the
PTT signal input.
2) Reading system, group, frequency, and program data
from the memory circuit.
3) Sending frequency program data to the PLL.
4) Controlling squelch on/off by the DC voltage from the
squelch circuit.
5) Controlling the audio mute circuit by the decode data in-
put.
6) Transmitting tone and encode data.
■Frequency Shift Circuit
The MCU (IC306) operates at a clock of 14.746 MHz. This
oscillator has a circuit that shifts the frequency by BEAT
SHIFT SW (Q305, Q306).
A beat sound may be able to be evaded from generation
if “Beat Shift” is set to ON when it is generated in the inter-
nal spurious transmission modulated sound of a transceiver.
X301
XOUT XIN
BSHIFT
Q305 Q306
IC306
MCU
Hi: ON
Low: OFF
Fig. 7 Frequency shift circuit
CIRCUIT DESCRIPTION
■Memory Circuit
Memory circuit consists of the MCU (IC306) and an EE-
PROM (IC305). An EEPROM has a capacity of 16k bits that
contains the transceiver control program for the MCU and
data such as transceiver channels and operating features.
MCU EEPROM
IC306 IC305
Fig. 8 Memory circuit
■Low Battery Warning
The battery voltage is checked using by the MCU. The
transceiver generates a warning tone when it falls below
the warning voltage shown in the table.
1) The red LED blinks when the battery voltage falls below
the voltage (1) shown in the table during transmission.
Note: The transceiver checks the battery voltage during
reception even when, in the FPU, the Battery Warning
status function is set to “On TX” (default setting).
However, the LED does not blink during reception. Dur-
ing transmission, the LED blinks to generate the warning
tone of a low battery voltage.
2) The transceiver immediately stops transmission when
the battery voltage falls below the voltage (2) shown in
the table. A message tone beeps while the PTT switch is
released.
Ni-Cd Battery Ni-MH Battery Li-ion Battery
(1) 6.2V 6.2V 6.2V
(2) 5.9V 5.9V 5.9V
66 IC306
MCU
R301
SB
R305
Fig. 9 Low battery warning
7. Control System
Keys and channel selector circuit. The signal from the
keys and channel selector are directly input to the MCU, as
shown in Fig. 10.
EN1
62
55
56
57
Channel
selector
61
60
59
58
EN2
EN3
EN4
EN5
IC306
MCU
SIDE1
PTT PTT
SW
SW1
SW2
SIDE2
Fig. 10 Control system

TK-3301
10
MCU: R5F212CCKCMD (TX-RX unit IC306)
Pin No. Signal Name I/O Function
1 5T_C O 5T control
2 PLL_STB O PLL strobe
3 5C_C O 5C control
4 5R_C O 5R control
5 W/N O No function
6 MODE I No function
7 AF_CONT O Speaker mute
8 BSHIFT O Beat shift control
9 RESET I MCU reset
10 XOUT O MCU clock (14.746MHz)
11 VSS - GND
12 XIN I MCU clock (14.746MHz)
13 VCC I Power supply input
14 QTTCXO O QT/DQT output
15 QTVCO O QT/DQT output
16~21 AUX6~AUX1 I/O No function
22 MIC_MUTE O MIC mute
23 AF_MUTE O No function
24~32 N.C O No function
33 RXDATA I No function
34 TXDATA O No function
35 OPTDET I Headset detect
36 TX_SW O No function
37 RX_SW O No function
38 LEDRX O Green LED control
39 LEDTX O Red LED control
40 APC_SW O APC switch
41 DC_SW O No function
42 STD I Baseband IC data input
43 1/2 OSC O Baseband IC clock (3.6864MHz)
44 INT I No function
45 TXD O Serial data output
SEMICONDUCTOR DATA
Pin No. Signal Name I/O Function
46 RXD I Serial data input
47 DIR O Baseband IC data output
48 DI/O I/O Baseband IC data input / output
49 DTRLOADN O Baseband IC data output
50 TDATA/DTRCLK O Baseband IC data output
51 SCLK O Serial clock for baseband IC
52 TCLK/DTRDO I Baseband IC data input
53 RDF/FD I Baseband IC data input
54 MDSW I No function
55 PTT I PTT switch input
56 SIDE1 I Side1 key input
57 SIDE2 I Side2 key input
58~62 EN5~EN1 I Channel selector input
63 DEST1 I No function
64 DEST2 I No function
65 PLL_UL I PLL unlock signal input
66 BATT I Battery voltage detect
67 RSSI I RSSI input
68 BUSY I Busy signal input
69 VOX I VOX signal detect
70 QT/DQT_IN I QT/DQT signal input
71 EEPCLK O EEPROM clock
72 EEPDAT I/O EEPROM data input / output
73 TH_DET I Temperature detect
74 DTMF I DTMF/BEEP output
75 AVSS - GND
76 PCTV I APC control voltage
77 VREF I Reference voltage input
78 AVCC I Power supply input
79 PLL_DAT O PLL data output
80 PLL_CLK O PLL clock output

TK-3301
11
TX-RX unit (X57-7772-70)
Ref. No. Part Name Description
IC1 IC PLL system IC
IC101 IC APC
IC201 IC FM system IC
IC301 IC Voltage detector/ Reset
IC303,304 IC Voltage regulator/ 5V
IC305 IC EEPROM
IC306 IC MCU
IC308 IC Audio processor
IC309 IC Audio amplifier
Q1 Transistor Rectification
Q2 Transistor Tripler
Q3 Transistor RF amplifier
Q5 FET VCO
Q6 Transistor Rectification
Q9 Transistor RF amplifier
Q10 Transistor Ripple filter
Q11 Transistor RF amplifier
Q101,102 Transistor RF amplifier
Q103 FET TX drive amplifier
Q106 FET TX final amplifier
Q107 Transistor DC switch
Q108 FET DC switch
Q109 Transistor DC switch
Q202 Transistor IF amplifier
Q203 FET Mixer
COMPONENTS DESCRIPTION
Ref. No. Part Name Description
Q204 FET Low noise amplifier
Q301 Transistor DC switch/ Red color LED
Q302 Transistor DC switch/ Green color LED
Q303 Transistor DC switch/ 5R
Q304 Transistor DC switch/ 5T
Q305,306 Transistor Beat shift switch
Q308 Transistor Rectification
Q310,311 Transistor MIC mute
Q312,313 Transistor DC switch
Q314 Transistor Mute switch
Q315,316 FET Mute switch
D2,4,8 Variable Capci-
tance Diode Frequency control/ VCO
D9 Variable Capci-
tance Diode Modulator
D10 Diode TX/RX RF switch
D101 Zener diode Voltage protection
D103,104 Diode ANT switch
D106 Diode ANT switch
D301 Diode Reverse voltage protection
D302 Diode Rectification
D303 LED Red color LED
D304 LED Green color LED
D306 Diode Rectification
D307 Diode Limiter
D308,309 Diode Rectification
TERMINAL FUNCTION
TX-RX unit (X57-7772-70)
Pin No. Name I/O Function
CN301
1 B I B (Battery Voltage)
2 SB O Switched B
3 AFVOL_IN I Audio input
4 AFVOL_OUT O Audio output
5 AFVOL_GND - GND
Pin No. Name I/O Function
6 EN1 I Encoder pulse input
7 EN2 I Encoder pulse input
8 GND - GND
9 EN3 I Encoder pulse input
10 EN4 I Encoder pulse input
11 EN5 I Encoder pulse input

TK-3301
12
PARTS LIST
Chip capacitor
Code L W T
Empty 5.6±0.5 5.0±0.5 Less than 2.0
A 4.5±0.5 3.2±0.4 Less than 2.0
B 4.5±0.5 2.0±0.3 Less than 2.0
C 4.5±0.5 1.25±0.2 Less than 1.25
D 3.2±0.4 2.5±0.3 Less than 1.5
E 3.2±0.2 1.6±0.2 Less than 1.25
F 2.0±0.3 1.25±0.2 Less than 1.25
G 1.6±0.2 0.8±0.2 Less than 1.0
H 1.0±0.05 0.5±0.05 0.5±0.05
Chip resistor
Code L W T
E 3.2±0.2 1.6±0.2 1.0
F 2.0±0.3 1.25±0.2 1.0
G 1.6±0.2 0.8±0.2 0.5±0.1
H 1.0±0.05 0.5±0.05 0.35±0.05
• Rating wattage
Code Wattage Code Wattage Code Wattage
1J 1/16W 2C 1/6W 3A 1W
2A 1/10W 2E 1/4W 3D 2W
2B 1/8W 2H 1/2W
(Less than 10pF)
Code B C D F G
(pF) ±0.1 ±0.25 ±0.5 ±1 ±2
CAPACITORS
C C 4 5 T H 1 H 2 2 0 J
1 2 3 4 5 6
1 = Type ... ceramic, electrolytic, etc. 4 = Voltage rating
2 = Shape ... round, square, etc. 5 = Value
3 = Temp. coefficient 6 = Tolerance
• Temperature coefficient
1st Word C L P R S T U
Color* Black Red Orange Yellow Green Blue Violet
ppm/°C 0 –80 –150 –220 –330 –470 –750
• Tolerance (More than 10pF)
Code C D G J K M X Z P No code
(%) ±0.25 ±0.5 ±2 ±5 ±10 ±20 +40 +80 +100 More than 10μF : –10~+50
–20 –20 –0 Less than 4.7μF : –10~+75
• Voltage rating
2nd word A B C D E F G H J K V
1st word
0 1.0 1.25 1.6 2.0 2.5 3.15 4.0 5.0 6.3 8.0 –
1 10 12.5 16 20 25 31.5 40 50 63 80 35
2 100 125 160 200 250 315 400 500 630 800 –
3 1000 1250 1600 2000 2500 2150 4000 5000 6300 8000 –
• Chip capacitors
(EX) C C 7 3 F S L 1 H 0 0 0 J Refer to the table above.
1 2 3 4 5 6 7 1 = Type
(Chip) (CH, RH, UJ, SL) 2 = Shape
3 = Dimension
(EX) C K 7 3 F F 1 H 0 0 0 Z 4 = Temp. coefficient
1 2 3 4 5 6 7 5 = Voltage rating
(Chip) (B, F) 6 = Value
7 = Tolerance
RESISTORS
• Chip resistor (Carbon)
(EX) R D 7 3 E B 2 B 0 0 0 J
1 2 3 4 5 6 7
(Chip) (B, F)
• Carbon resistor (Normal type)
(EX) R D 1 4 B B 2 C 0 0 0 J
1 2 3 4 5 6 7
1 = Type 5 = Rating wattage
2 = Shape 6 = Value
3 = Dimension 7 = Tolerance
4 = Temp. coefficient
CC45 Color*
2nd Word G H J K L
ppm/°C ±30 ±60 ±120 ±250 ±500
Example : CC45TH = –470±60ppm/°C
• Capacitor value
010 = 1pF 2 2 0 = 22pF
100 = 10pF
101 = 100pF Multiplier
102 = 1000pF = 0.001μF 2nd number
103 = 0.01μF 1st number
L
W
T
• Dimension

TK-3301
✽New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L: Scandinavia K: USA P: Canada
Y: PX (Far East, Hawaii) T: England E: Europe
Y: AAFES (Europe) X: Australia M: Other Areas
13
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
PARTS LIST
1 1A
✽A02-4082-03 PLASTIC CABINET ASSY
2 3A A10-4124-11 CHASSIS
5 2C B09-0725-03 CAP ACCESSORY
6 1C
✽B62-2154-00 INSTRUCTION MANUAL
8 1A D10-0649-03 LEVER
9 1A D21-0863-04 SHAFT
10 1A D32-0441-13 STOPPER
12 3A E23-1253-04 TERMINAL
13 2A E23-1254-04 TERMINAL
14 1B
✽E37-1463-05 SPEAKER WIRE LEAD (RED)
15 1B
✽E37-1464-05 SPEAKER WIRE LEAD (BLACK)
17 2B F07-1882-23 ANTENNA COVER
18 3A F20-3353-14 INSULATING SHEET (CHASSIS-BATT+)
20 1A G01-4542-04 COIL SPRING (LEVER)
21 1A G01-4543-14 COIL SPRING (STOPPER)
22 2A G10-1330-04 FIBROUS SHEET (AUDIO IC)
23 2A G11-4465-04 RUBBER SHEET (FINAL FET)
24 3A G13-2009-04 CUSHION (CHASSIS)
25 3A G13-2033-04 CUSHION (BATT-)
26 3A G13-2034-14 CUSHION (CHASSIS-)
27 3A G13-2038-24 CUSHION (CHASSIS-CERMIC FILTER)
28 2A G13-2039-14 CUSHION (PCB-CERMIC FILTER)
29 3A G53-1604-03 PACKING (CHASSIS)
30 2A G53-1605-03 PACKING (BATT+)
31 2A G53-1609-14 PACKING (ECM)
32 1A G53-1611-04 PACKING (ANT)
33 2B G53-1799-03 PACKING (VOLUME/SELECTOR)
34 1B G53-1800-03 PACKING (SP/MIC)
35 1B G53-1801-03 PACKING (SPEAKER)
37 2A J19-5463-03 HOLDER (BATT+)
38 2A J19-5473-03 HOLDER ASSY (BATT+)
39 2C J19-5521-03 HOLDER
40 1B J19-5522-03 SPEAKER CLASP
41 1C J29-0734-05 BELT HOOK ACCESSORY
42 2A J82-0121-05 FPC
43 1A J99-0737-04 ADHESIVE SHEET (PTT)
45 1B K29-9309-13 KNOB (VOLUME)
46 1A K29-9425-03 BUTTON KNOB (PTT)
47 1A K29-9426-03 BUTTON KNOB (MON/PF)
48 1B K29-9427-03 KNOB (SELECTOR)
A 3B N14-0848-05 CIRCULAR NUT (SELECTOR)
B 3B N14-0849-05 CIRCULAR NUT (VOLUME)
C 3A N30-2606-48 PAN HEAD MACHINE SCREW
D
2A,3A,1B N83-2005-48 PAN HEAD TAPTITE SCREW
50 2C N99-2046-05 SCREW SET ACCESSORY
52 2A R31-0670-15 VARIABLE RESISTOR
54 2A S60-0440-05 ROTARY SWITCH
56 1B T07-0369-15 SPEAKER
57 2A T90-1043-15 ANTENNA ELEMENT
59 1D W08-0988-05 CHARGER
60 1D W08-0992-05 AC ADAPTER E
61 1D W08-0993-05 AC ADAPTER T
D303 B30-2315-05 LED (RED/2P/8)
D304 B30-2314-05 LED (GREEN/2P/8)
C1 CK73HB1H332K CHIP C 3300PF K
C2 CK73HB1C682K CHIP C 6800PF K
C3 CK73GB1A105K CHIP C 1.0UF K
C4 CK73HB1A104K CHIP C 0.10UF K
C5 CK73HB1H471K CHIP C 470PF K
C6 CK73HB1E103K CHIP C 0.010UF K
C7 CC73HCH1H100D CHIP C 10PF D
C8-10 CC73HCH1H101J CHIP C 100PF J
C11 CK73FB0J106K CHIP C 10UF K
C12 CK73HB1H471K CHIP C 470PF K
C13 CC73HCH1H100D CHIP C 10PF D
C14,15 CK73HB1E103K CHIP C 0.010UF K
C16 CC73HCH1H470J CHIP C 47PF J
C17 CK73HB1E103K CHIP C 0.010UF K
C18 CC73HCH1H180J CHIP C 18PF J
C21 CK73HB1E103K CHIP C 0.010UF K
C22 CK73FB0J106K CHIP C 10UF K
C23 CK73HB1E103K CHIP C 0.010UF K
C25 CC73HCH1H300J CHIP C 30PF J
C26 CC73HCH1H020B CHIP C 2.0PF B
C27 CS77AA1VR33M CHIP TNTL 0.33UF 35WV
C29 CC73HCH1H270J CHIP C 27PF J
C30 CK73HB1H471K CHIP C 470PF K
C31 CK73HB1E103K CHIP C 0.010UF K
C32 CS77CA1C3R3M CHIP TNTL 3.3UF 16WV
C33 CK73HB1H471K CHIP C 470PF K
C35 CS77CA1V0R1M CHIP TNTL 0.1UF 35WV
C36 CK73HB1H332K CHIP C 3300PF K
C37 CS77CA1V0R1M CHIP TNTL 0.1UF 35WV
C39 CK73HB1C682K CHIP C 6800PF K
C40 CC73HCH1H050B CHIP C 5.0PF B
C41 CC73HCH1H030B CHIP C 3.0PF B
C42 CC73HCH1H050B CHIP C 5.0PF B
C44,45 CK73GB1A105K CHIP C 1.0UF K
C47 CC73HCH1H100C CHIP C 10PF C
C50 CK73HB1H471K CHIP C 470PF K
C51 CC73HCH1H100D CHIP C 10PF D
C53 CC73HCH1H080B CHIP C 8.0PF B
C56 CC73HCH1H3R5B CHIP C 3.5PF B
C58 CC73HCH1HR75B CHIP C 0.75PF B
C59 CC73HCH1H010B CHIP C 1.0PF B
C61 CC73HCH1H2R5B CHIP C 2.5PF B
C62 CK73HB1H471K CHIP C 470PF K
C64 CC73HCH1H050B CHIP C 5.0PF B
TK-3301
TX-RX UNIT (X57-7772-70)
TK-3301
TX-RX UNIT (X57-7772-70)

TK-3301
14
Ref. No. Address Parts No. Description Desti-
nation
New
parts
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-7772-70)
C202 CK73FB0J106K CHIP C 10UF K
C203 CK73HB1E103K CHIP C 0.010UF K
C204 CK73HB1H102K CHIP C 1000PF K
C205 CK73HB1H182K CHIP C 1800PF K
C206,207 CK73HB1H102K CHIP C 1000PF K
C208 CK73HB1A104K CHIP C 0.10UF K
C209 CC73HCH1H680J CHIP C 68PF J
C210-213 CK73HB1A104K CHIP C 0.10UF K
C214 CC73HCH1H020B CHIP C 2.0PF B
C215,216 CK73HB1E103K CHIP C 0.010UF K
C219 CC73HCH1H010B CHIP C 1.0PF B
C220 CC73HCH1H100C CHIP C 10PF C
C222 CK73HB1H471K CHIP C 470PF K
C223 CK73HB1E103K CHIP C 0.010UF K
C224 CK73HB1A104K CHIP C 0.10UF K
C225 CK73HB1E103K CHIP C 0.010UF K
C226 CK73HB1H471K CHIP C 470PF K
C227 CC73HCH1H180J CHIP C 18PF J
C228 CK73HB1H471K CHIP C 470PF K
C230 CK73HB1E103K CHIP C 0.010UF K
C231 CK73HB1H471K CHIP C 470PF K
C232 CC73HCH1H2R5B CHIP C 2.5PF B
C233 CC73HCH1H060B CHIP C 6.0PF B
C234 CK73HB1H471K CHIP C 470PF K
C241 CK73FB0J106K CHIP C 10UF K
C242 CC73HCH1H120J CHIP C 12PF J
C243 CK73HB1H471K CHIP C 470PF K
C245 CC73HCH1H010B CHIP C 1.0PF B
C247 CC73HCH1H010B CHIP C 1.0PF B
C249 CC73GCH1H130J CHIP C 13PF J
C250 CK73HB1H471K CHIP C 470PF K
C252-254 CK73HB1H471K CHIP C 470PF K
C256 CK73HB1H471K CHIP C 470PF K
C257 CC73HCH1H080B CHIP C 8.0PF B
C259 CC73HCH1H2R5B CHIP C 2.5PF B
C261 CC73HCH1H4R5B CHIP C 4.5PF B
C263 CC73HCH1H050B CHIP C 5.0PF B
C264,265 CC73HCH1H3R5B CHIP C 3.5PF B
C266 CC73HCH1H050B CHIP C 5.0PF B
C290 CC73HCH1H020B CHIP C 2.0PF B
C291 CC73HCH1H060B CHIP C 6.0PF B
C303 CC73HCH1H101J CHIP C 100PF J
C304 CK73HB1A104K CHIP C 0.10UF K
C305 CC73HCH1H101J CHIP C 100PF J
C306 CK73GB1A105K CHIP C 1.0UF K
C307 CC73HCH1H101J CHIP C 100PF J
C310 CK73GB1A105K CHIP C 1.0UF K
C311 CC73HCH1H101J CHIP C 100PF J
C312 CK73HB1H471K CHIP C 470PF K
C313 CC73HCH1H101J CHIP C 100PF J
C315 CC73HCH1H101J CHIP C 100PF J
C316 CK73HB1H471K CHIP C 470PF K
C318 CK73HB1E103K CHIP C 0.010UF K
C319 CK73HB1H102K CHIP C 1000PF K
C320 CC73HCH1H101J CHIP C 100PF J
C321 CK73GB1A105K CHIP C 1.0UF K
C322 CC73HCH1H101J CHIP C 100PF J
C323 CK73GB1A105K CHIP C 1.0UF K
C325 CC73HCH1H101J CHIP C 100PF J
C327 CK73HB1H471K CHIP C 470PF K
C66 CK73HB1H471K CHIP C 470PF K
C67 CC73HCH1H050B CHIP C 5.0PF B
C69 CK73HB1H471K CHIP C 470PF K
C71 CC73HCH1H0R3B CHIP C 0.3PF B
C72 CK73HB1A104K CHIP C 0.10UF K
C74,75 CK73HB1H471K CHIP C 470PF K
C76 CS77CP0J100M CHIP TNTL 10UF 6.3WV
C77 CK73HB1H471K CHIP C 470PF K
C78 CC73HCH1H330J CHIP C 33PF J
C80 CK73HB1H471K CHIP C 470PF K
C81 CC73HCH1H150J CHIP C 15PF J
C83-85 CK73HB1H471K CHIP C 470PF K
C86 CC73HCH1H100B CHIP C 10PF B
C101,102 CK73HB1H471K CHIP C 470PF K
C103 CC73HCH1H300J CHIP C 30PF J
C104 CC73HCH1H040B CHIP C 4.0PF B
C106 CK73GB1A105K CHIP C 1.0UF K
C107 CK73HB1H471K CHIP C 470PF K
C108 CK73GB1A105K CHIP C 1.0UF K
C109 CC73HCH1H060B CHIP C 6.0PF B
C111 CK73GB1A105K CHIP C 1.0UF K
C112,113 CK73HB1H471K CHIP C 470PF K
C114 CK73HB1A104K CHIP C 0.10UF K
C115 CC73HCH1H060B CHIP C 6.0PF B
C117 CC73HCH1H080B CHIP C 8.0PF B
C120 CK73HB1H471K CHIP C 470PF K
C124 CK73HB1H471K CHIP C 470PF K
C125 CC73HCH1H100B CHIP C 10PF B
C126 CC73HCH1H120J CHIP C 12PF J
C127 CC73HCH1H220J CHIP C 22PF J
C128,129 CK73HB1H471K CHIP C 470PF K
C130 CK73GB1A105K CHIP C 1.0UF K
C131 CK73HB1E103K CHIP C 0.010UF K
C133 CK73GB1A105K CHIP C 1.0UF K
C135,136 CK73HB1H471K CHIP C 470PF K
C137 CC73HCH1H101J CHIP C 100PF J
C138 CC73GCH1H010B CHIP C 1.0PF B
C140 CK73HB1H471K CHIP C 470PF K
C141 CK73HB1A104K CHIP C 0.10UF K
C142 CC73GCH1H330J CHIP C 33PF J
C144 CK73HB1H471K CHIP C 470PF K
C146 CC73GCH1H120J CHIP C 12PF J
C154 CK73HB1H471K CHIP C 470PF K
C155 CC73GCH1H3R5B CHIP C 3.5PF B
C161 CC73GCH1H010B CHIP C 1.0PF B
C162 CC73GCH1H020B CHIP C 2.0PF B
C164 CC73GCH1H3R5B CHIP C 3.5PF B
C166 CC73GCH1H060B CHIP C 6.0PF B
C167 CK73HB1H471K CHIP C 470PF K
C168 CC73GCH1H040B CHIP C 4.0PF B
C169 CC73GCH1H2R5B CHIP C 2.5PF B
C170 CC73GCH1H101J CHIP C 100PF J
C172 CC73GCH1H050B CHIP C 5.0PF B
C173 CC73GCH1H0R5B CHIP C 0.5PF B
C174 CC73GCH1H060B CHIP C 6.0PF B
C175 CC73GCH1H020B CHIP C 2.0PF B
C176 CC73GCH1H060B CHIP C 6.0PF B
C177 CC73GCH1H2R5B CHIP C 2.5PF B
C178 CC73GCH1H040B CHIP C 4.0PF B
C201 CK73GB1C224K CHIP C 0.22UF K

TK-3301
15
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-7772-70)
C331 CK73HB1A104K CHIP C 0.10UF K
C332 CC73HCH1H050B CHIP C 5.0PF B
C334 CK73HB1E103K CHIP C 0.010UF K
C335 CK73FB0J106K CHIP C 10UF K
C337 CC73HCH1H050B CHIP C 5.0PF B
C353-355 CK73HB1E103K CHIP C 0.010UF K
C356 CK73HB1H102K CHIP C 1000PF K
C358 CK73GB1C224K CHIP C 0.22UF K
C359 CK73FB0J106K CHIP C 10UF K
C360 CK73HB1A104K CHIP C 0.10UF K
C361 CK73GB1A105K CHIP C 1.0UF K
C362 CK73HB1H471K CHIP C 470PF K
C363 CC73HCH1H820J CHIP C 82PF J
C364 CC73HCH1H120J CHIP C 12PF J
C365 CC73HCH1H820J CHIP C 82PF J
C366 CK73HB1A104K CHIP C 0.10UF K
C367 CK73GB1A105K CHIP C 1.0UF K
C368 CK73HB1H271K CHIP C 270PF K
C369,370 CK73HB1A104K CHIP C 0.10UF K
C371 CK73FB0J106K CHIP C 10UF K
C372 CK73HB1H471K CHIP C 470PF K
C373 CC73HCH1H121J CHIP C 120PF J
C374 CK73HB1H102K CHIP C 1000PF K
C375,376 CK73HB1H471K CHIP C 470PF K
C377 CK73HB1A683K CHIP C 0.068UF K
C378 CC73HCH1H820J CHIP C 82PF J
C379,380 CK73GB1A105K CHIP C 1.0UF K
C381 CK73HB1H391K CHIP C 390PF K
C382 CK73HB1C153K CHIP C 0.015UF K
C383-385 CK73HB1A104K CHIP C 0.10UF K
C386 CK73HB1E103K CHIP C 0.010UF K
C388,389 CK73HB1H471K CHIP C 470PF K
C390,391 CK73GB1A105K CHIP C 1.0UF K
C392 CK73HB1A473K CHIP C 0.047UF K
C393 CK73FB0J106K CHIP C 10UF K
C395 CC73HCH1H221J CHIP C 220PF J
C396 CK73HB1A104K CHIP C 0.10UF K
C397 CK73GB1C474K CHIP C 0.47UF K
C399 CC73HCH1H101J CHIP C 100PF J
C400 CK73FB0J106K CHIP C 10UF K
C402 CK73HB1A104K CHIP C 0.10UF K
C403 CK73HB1A473J CHIP C 0.047UF J
C404 CS77CC0J101M CHIP TNTL 100UF 6.3WV
C405 CC73HCH1H221J CHIP C 220PF J
C408,409 CK73HB1H471K CHIP C 470PF K
C411 CK73HB1H471K CHIP C 470PF K
C413-415 CK73HB1H471K CHIP C 470PF K
TC2 C05-0384-05 CERAMIC TRIMMER CAPACITOR (10P)
CN2,3 E23-1278-05 TERMINAL
CN301 E40-6573-05 FLAT CABLE CONNECTOR
J301 E11-0703-05 PHONE JACK (2.5/3.5)
F301 ✽F53-0321-05 FUSE
101 2A J30-1282-14 SPACER
CD201 L79-1866-05 TUNING COIL
CF201 2A L72-0959-05 CERAMIC FILTER
L1 L92-0138-05 CHIP FERRITE
L2 L40-4791-86 SMALL FIXED INDUCTOR (4.7UH)
L4 L40-5681-86 SMALL FIXED INDUCTOR (0.56UH)
L6 L40-5681-86 SMALL FIXED INDUCTOR (0.56UH)
L7 L92-0138-05 CHIP FERRITE
L8 L40-1875-71 SMALL FIXED INDUCTOR (18NH)
L9 L92-0470-05 CHIP FERRITE
L10 L40-1885-92 SMALL FIXED INDUCTOR (180NH)
L12 L40-1875-71 SMALL FIXED INDUCTOR (18NH)
L14 L40-1885-92 SMALL FIXED INDUCTOR (180NH)
L16 L40-2778-67 SMALL FIXED INDUCTOR (27NH)
L17 L41-2785-45 SMALL FIXED INDUCTOR (270NH)
L20 L40-1885-92 SMALL FIXED INDUCTOR (180NH)
L21 L92-0138-05 CHIP FERRITE
L22,23 L40-2275-71 SMALL FIXED INDUCTOR (22NH)
L101 L40-1875-71 SMALL FIXED INDUCTOR (18NH)
L102 L40-3375-71 SMALL FIXED INDUCTOR (33NH)
L103 L40-1575-71 SMALL FIXED INDUCTOR (15NH)
L104 L40-1068-71 SMALL FIXED INDUCTOR (1.0NH)
L105 L41-2278-45 SMALL FIXED INDUCTOR (22NH)
L106 L92-0472-05 CHIP FERRITE
L107 L40-2763-92 SMALL FIXED INDUCTOR (2.7NH)
L108 L34-4603-15 AIR-CORE COIL
L109 L92-0472-05 CHIP FERRITE
L111 L41-2785-45 SMALL FIXED INDUCTOR (270NH)
L112 L34-4572-05 AIR-CORE COIL
L113-115 L34-4564-05 AIR-CORE COIL
L116 L41-1092-44 SMALL FIXED INDUCTOR (1UH)
L201 L40-1091-86 SMALL FIXED INDUCTOR (1.0UH)
L202 L92-0138-05 CHIP FERRITE
L203 L41-5685-39 SMALL FIXED INDUCTOR (0.56UH)
L204 L40-1885-92 SMALL FIXED INDUCTOR (180NH)
L205 L40-2775-71 SMALL FIXED INDUCTOR (27NH)
L207 L41-6868-14 SMALL FIXED INDUCTOR (6.8NH)
L208 L92-0138-05 CHIP FERRITE
L209 L41-6868-14 SMALL FIXED INDUCTOR (6.8NH)
L210 L41-2785-45 SMALL FIXED INDUCTOR (270NH)
L212,213 L41-8268-14 SMALL FIXED INDUCTOR (8.2NH)
L214 L41-4775-45 SMALL FIXED INDUCTOR (47NH)
L250 L40-1875-71 SMALL FIXED INDUCTOR (18NH)
L301 L92-0472-05 CHIP FERRITE
L302-304 L92-0138-05 CHIP FERRITE
L305 L92-0140-05 CHIP FERRITE
X1 L77-3042-05 TCXO (12.8MHZ)
X301 L78-1433-05 RESONATOR (14.746MHZ)
XF201 L71-0549-15 MCF (38.85MHZ)
CP1 RK75HA1J101J CHIP-COM 100 J 1/16W
CP201 RK75HA1J104J CHIP-COM 100K J 1/16W
CP203 RK75HA1J104J CHIP-COM 100K J 1/16W
CP301,302 RK75HA1J473J CHIP-COM 47K J 1/16W
CP303,304 RK75HA1J102J CHIP-COM 1.0K J 1/16W
R1 RK73HB1J183J CHIP R 18K J 1/16W
R2 RK73HB1J123J CHIP R 12K J 1/16W
R3 RK73HB1J184J CHIP R 180K J 1/16W
R4 RK73HB1J563J CHIP R 56K J 1/16W
R5 RK73HB1J104J CHIP R 100K J 1/16W
R7 RK73HB1J000J CHIP R 0.0 J 1/16W
R8 RK73HB1J101J CHIP R 100 J 1/16W
R9 RK73HB1J222J CHIP R 2.2K J 1/16W
R10 RK73HB1J000J CHIP R 0.0 J 1/16W
R11 RK73HB1J274J CHIP R 270K J 1/16W
R12 RK73HB1J221J CHIP R 220 J 1/16W
If a part reference number is listed in a shaded box, that part does not come with the PCB.

TK-3301
16
Ref. No. Address Parts No. Description Desti-
nation
New
parts
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-7772-70)
R13 RK73HB1J101J CHIP R 100 J 1/16W
R14 RK73HB1J100J CHIP R 10 J 1/16W
R15 RK73HB1J561J CHIP R 560 J 1/16W
R16 RK73HB1J181J CHIP R 180 J 1/16W
R17 RK73HB1J122J CHIP R 1.2K J 1/16W
R18 RK73HB1J681J CHIP R 680 J 1/16W
R19 RK73HB1J273J CHIP R 27K J 1/16W
R20 RK73HB1J152J CHIP R 1.5K J 1/16W
R21 RK73HB1J123J CHIP R 12K J 1/16W
R22 RK73HB1J103J CHIP R 10K J 1/16W
R26 RK73HB1J333J CHIP R 33K J 1/16W
R27 RK73HB1J684J CHIP R 680K J 1/16W
R28 RK73HB1J102J CHIP R 1.0K J 1/16W
R29 RK73HB1J154J CHIP R 150K J 1/16W
R30 RK73HB1J273J CHIP R 27K J 1/16W
R31 RK73HB1J274J CHIP R 270K J 1/16W
R32 RK73HB1J474J CHIP R 470K J 1/16W
R33 RK73HB1J101J CHIP R 100 J 1/16W
R35 RK73HB1J820J CHIP R 82 J 1/16W
R37 RK73HB1J472J CHIP R 4.7K J 1/16W
R38 RK73HB1J154J CHIP R 150K J 1/16W
R39 RK73HB1J101J CHIP R 100 J 1/16W
R41 RK73HB1J562J CHIP R 5.6K J 1/16W
R42 RK73HB1J220J CHIP R 22 J 1/16W
R43 RK73HB1J471J CHIP R 470 J 1/16W
R45 RK73HB1J562J CHIP R 5.6K J 1/16W
R50 RK73HB1J000J CHIP R 0.0 J 1/16W
R101 RK73HB1J332J CHIP R 3.3K J 1/16W
R102 RK73HB1J273J CHIP R 27K J 1/16W
R103 RK73HB1J331J CHIP R 330 J 1/16W
R104 RK73HB1J560J CHIP R 56 J 1/16W
R105 RK73HB1J333J CHIP R 33K J 1/16W
R106 RK73HB1J331J CHIP R 330 J 1/16W
R107 RK73HB1J680J CHIP R 68 J 1/16W
R109 RK73HB1J000J CHIP R 0.0 J 1/16W
R111 RK73HB1J184J CHIP R 180K J 1/16W
R112 RK73HB1J220J CHIP R 22 J 1/16W
R113 RK73HB1J104J CHIP R 100K J 1/16W
R114 RK73HB1J822J CHIP R 8.2K J 1/16W
R116 RK73HB1J331J CHIP R 330 J 1/16W
R119 RK73GB2A100J CHIP R 10 J 1/10W
R120 RK73EB2ER39K CHIP R 0.39 K 1/4W
R121 RK73HB1J123J CHIP R 12K J 1/16W
R122 RK73HB1J273J CHIP R 27K J 1/16W
R123 RK73EB2ER39K CHIP R 0.39 K 1/4W
R124 RK73HB1J220J CHIP R 22 J 1/16W
R125 RK73HB1J683J CHIP R 68K J 1/16W
R126 RK73EB2ER39K CHIP R 0.39 K 1/4W
R127,128 RK73GH2A154D CHIP R 150K D 1/10W
R129,130 RK73GH2A334D CHIP R 330K D 1/10W
R131 RK73HB1J105J CHIP R 1.0M J 1/16W
R132 RK73HB1J473J CHIP R 47K J 1/16W
R133 RK73HB1J000J CHIP R 0.0 J 1/16W
R134 RK73HB1J563J CHIP R 56K J 1/16W
R135 RK73HB1J104J CHIP R 100K J 1/16W
R136 RK73HB1J474J CHIP R 470K J 1/16W
R137 RK73FB2B000J CHIP R 0.0 J 1/8W
R138 RK73GB2A151J CHIP R 150 J 1/10W
R140 RK73GB2A000J CHIP R 0.0 J 1/10W
R141 RK73HB1J000J CHIP R 0.0 J 1/16W
R201 RK73HB1J823J CHIP R 82K J 1/16W
R203 RK73HB1J472J CHIP R 4.7K J 1/16W
R204 RK73HB1J100J CHIP R 10 J 1/16W
R205 RK73HB1J823J CHIP R 82K J 1/16W
R206 RK73HB1J272J CHIP R 2.7K J 1/16W
R207 RK73HB1J332J CHIP R 3.3K J 1/16W
R208 RK73HB1J823J CHIP R 82K J 1/16W
R210 RK73HB1J392J CHIP R 3.9K J 1/16W
R211 RK73HB1J101J CHIP R 100 J 1/16W
R212 RK73HB1J224J CHIP R 220K J 1/16W
R213 RK73HB1J561J CHIP R 560 J 1/16W
R214 RK73HB1J101J CHIP R 100 J 1/16W
R215 RK73HB1J821J CHIP R 820 J 1/16W
R216 RK73HB1J680J CHIP R 68 J 1/16W
R217 RK73HB1J332J CHIP R 3.3K J 1/16W
R218,219 RK73HB1J563J CHIP R 56K J 1/16W
R220 RK73HB1J000J CHIP R 0.0 J 1/16W
R222 RK73HB1J121J CHIP R 120 J 1/16W
R223 RK73HB1J151J CHIP R 150 J 1/16W
R225 RK73HB1J563J CHIP R 56K J 1/16W
R226 RK73HB1J000J CHIP R 0.0 J 1/16W
R227 RK73FB2B000J CHIP R 0.0 J 1/8W
R228 RK73HB1J102J CHIP R 1.0K J 1/16W
R230,231 RK73HB1J000J CHIP R 0.0 J 1/16W
R301 RK73HH1J474D CHIP R 470K D 1/16W
R302 RK73GB2A000J CHIP R 0.0 J 1/10W
R303 RK73HB1J101J CHIP R 100 J 1/16W
R304 RK73HB1J334J CHIP R 330K J 1/16W
R305 RK73HH1J474D CHIP R 470K D 1/16W
R306 RK73HB1J184J CHIP R 180K J 1/16W
R307 RK73GB2A271J CHIP R 270 J 1/10W
R308 RK73GB2A221J CHIP R 220 J 1/10W
R309,310 RK73GB2A000J CHIP R 0.0 J 1/10W
R313 RK73HB1J102J CHIP R 1.0K J 1/16W
R314,315 RK73HB1J103J CHIP R 10K J 1/16W
R316 RK73HB1J222J CHIP R 2.2K J 1/16W
R317 RK73HB1J472J CHIP R 4.7K J 1/16W
R318 RK73HB1J182J CHIP R 1.8K J 1/16W
R319 RK73HB1J000J CHIP R 0.0 J 1/16W
R320 RK73HB1J123J CHIP R 12K J 1/16W
R321 RK73HB1J103J CHIP R 10K J 1/16W
R322,323 RK73HB1J102J CHIP R 1.0K J 1/16W
R324 RK73HB1J472J CHIP R 4.7K J 1/16W
R340-342 RK73HB1J103J CHIP R 10K J 1/16W
R344 RK73HB1J474J CHIP R 470K J 1/16W
R345 RK73HB1J273J CHIP R 27K J 1/16W
R347 RK73GB2A000J CHIP R 0.0 J 1/10W
R348 RK73HB1J102J CHIP R 1.0K J 1/16W
R349 RK73HB1J105J CHIP R 1.0M J 1/16W
R350 RK73HB1J124J CHIP R 120K J 1/16W
R351 RK73HB1J334J CHIP R 330K J 1/16W
R352 RK73HB1J154J CHIP R 150K J 1/16W
R353 RK73HB1J123J CHIP R 12K J 1/16W
R354 RK73HB1J334J CHIP R 330K J 1/16W
R355 RK73HB1J124J CHIP R 120K J 1/16W
R356 RK73HB1J472J CHIP R 4.7K J 1/16W
R357 RK73HB1J563J CHIP R 56K J 1/16W
R358 RK73HB1J474J CHIP R 470K J 1/16W
R359 RK73HB1J473J CHIP R 47K J 1/16W
R360 RK73HB1J562J CHIP R 5.6K J 1/16W

TK-3301
17
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-7772-70)
Q1 KTC4075E(Y,GR) TRANSISTOR
Q2 2SC4774 TRANSISTOR
Q3 2SC5636 TRANSISTOR
Q5 2SK1875-F(V) FET
Q6 KTC4075E(Y,GR) TRANSISTOR
Q9 2SC5636 TRANSISTOR
Q10 KTC4075E(Y,GR) TRANSISTOR
Q11 2SC5636 TRANSISTOR
Q101 2SC5636 TRANSISTOR
Q102 2SC5455-A TRANSISTOR
Q103 RD01MUS1-T113 FET
Q106 ✽RD02MUS1BT112 FET
Q107 RT1N441U TRANSISTOR
Q108 2SK1824-A FET
Q109 RT1P441U TRANSISTOR
Q202 2SC4774 TRANSISTOR
Q203,204 3SK318 FET
Q301,302 RT1N441U TRANSISTOR
Q303 RT1P141U TRANSISTOR
Q304 DTB723YE DIGITAL TRANSISTOR
Q305,306 2SC4919 TRANSISTOR
Q308 KTC4075E(Y,GR) TRANSISTOR
Q310 2SC4116(GR)F TRANSISTOR
Q311 2SA1586(Y,GR)F TRANSISTOR
Q312 RT1N441U TRANSISTOR
Q313 2SB1694 TRANSISTOR
Q314 RT1N441U TRANSISTOR
Q315,316 2SK3577-A FET
TH101 B57331V2104J THERMISTOR
TH201 B57331V2104J THERMISTOR
R361 RK73GB2A000J CHIP R 0.0 J 1/10W
R362 RK73HB1J184J CHIP R 180K J 1/16W
R363,364 RK73HB1J104J CHIP R 100K J 1/16W
R365 RK73HB1J332J CHIP R 3.3K J 1/16W
R366 RK73HB1J154J CHIP R 150K J 1/16W
R367 RK73HB1J393J CHIP R 39K J 1/16W
R368 RK73GB2A000J CHIP R 0.0 J 1/10W
R369 RK73HB1J823J CHIP R 82K J 1/16W
R370 RK73HB1J102J CHIP R 1.0K J 1/16W
R371 RK73HB1J272J CHIP R 2.7K J 1/16W
R372 RK73HB1J000J CHIP R 0.0 J 1/16W
R373 RK73HB1J224J CHIP R 220K J 1/16W
R374 RK73HB1J153J CHIP R 15K J 1/16W
R375 RK73HB1J182J CHIP R 1.8K J 1/16W
R376 RK73HB1J471J CHIP R 470 J 1/16W
R377 RK73HB1J473J CHIP R 47K J 1/16W
R378 RK73HB1J561J CHIP R 560 J 1/16W
R379 RK73HB1J102J CHIP R 1.0K J 1/16W
R380 RK73HB1J474J CHIP R 470K J 1/16W
R381 RK73HB1J151J CHIP R 150 J 1/16W
R383 RK73HB1J563J CHIP R 56K J 1/16W
R384 RK73HB1J333J CHIP R 33K J 1/16W
R385 RK73GB2A101J CHIP R 100 J 1/10W
R387 RK73HB1J104J CHIP R 100K J 1/16W
R388 RK73HB1J101J CHIP R 100 J 1/16W
R389 RK73HB1J000J CHIP R 0.0 J 1/16W
R390 RK73GB2A000J CHIP R 0.0 J 1/10W
R391 RK73HB1J102J CHIP R 1.0K J 1/16W
R393 RK73GB2A000J CHIP R 0.0 J 1/10W
R394 RK73HB1J473J CHIP R 47K J 1/16W
R398 RK73HB1J000J CHIP R 0.0 J 1/16W
VR1 R32-0736-05 SEMI FIXED VARIABLE RESISTOR
S1-3 S70-0414-05 TACT SWITCH
MIC301 2A T91-0651-15 MIC ELEMENT
D4 1SV325F VARIABLE CAPACITANCE DIODE
D8 1SV325F VARIABLE CAPACITANCE DIODE
D9 KDV214E-P DIODE
D10 MC2858 DIODE
D101 UDZW5.1(B) ZENER DIODE
D103 HSC277 DIODE
D104 HVC131 DIODE
D106 HVC131 DIODE
D301 GN1G DIODE
D302 HRC0203C DIODE
D306 KDR731 DIODE
D307 MC2850 DIODE
D308,309 KDR731 DIODE
IC1 MB15A02PFV2E1 MOS-IC
IC101 BA2904FVM MOS-IC
IC201 TA31136FNG MOS-IC
IC301 BD4840FVE MOS-IC
IC303 XC6209B502PR MOS-IC
IC304 XC6209B502MR MOS-IC
IC305 BR24L16F-W ROM IC
IC306 R5F212CCKCMD MCU
IC308 AQUA-L MOS-IC
IC309 TA7368FG MOS-IC

TK-3301
18
EXPLODED VIEW
3
2
1
BA
48
45
46
43
47
1
10
9
8
21
20
34
56
35
17
15
14
D
TX-RX unit
Dx10
A
B
D
Cx2
701
Model name plate
31 57
MIC301
42
28
CF201
52
54
33
24
23
27
38
30
37 13
2
18 29
26
25 12
A : N14-0848-05
B : N14-0849-05
C M2.6 x 6 : N30-2606-48
D M2 x 5 : N83-2005-48
22
32
101
X57
X57
40
Parts with the exploded numbers larger than 700 are not supplied.
If a part reference number is listed in a box on the exploded view of the PCB, that part does not come with the PCB.
These parts must be ordered separately.

TK-3301
19
Parts with the exploded numbers larger than 700 are not supplied.
PACKING
3
2
1
DC
6 Instruction manual
(B62-2154-00)
703 Protection bag
59 Charger
(W08-0988-05)
60 AC adapter
(W08-0992-05): E
61 AC adapter
(W08-0993-05): T
41 Belt hook
(J29-0734-05)
39 Holder (SP/MIC)
(J29-5521-03)
50 Screw set
(N99-2046-05)
704 Packing fixture
705 Item carton case
706 Battery assy
*1
*1
702 Pamphlet
5 Cap
(B09-0725-03)

TK-3301
20
Test Equipment Required for Alignment
Test Equipment Major Specifications
1. Standard Signal Generator (SSG)
Frequency Range Operational frequency range of the transceiver
Modulation Frequency modulation and external modulation
Output –127dBm/0.1µV to greater than –47dBm/1mV
2. RF Power Meter
Input Impedance 50Ω
Operation Frequency Operational frequency range of the transceiver
Measurement Range Vicinity of 10W
3. Deviation Meter Frequency Range Operational frequency range of the transceiver
4. Digital Volt Meter (DVM) Measuring Range 10mV to 10V DC
Input Impedance High input impedance for minimum circuit loading
5. Oscilloscope DC through 30MHz
6. High Sensitivity
Frequency Counter
Frequency Range 10Hz to 1000MHz
Frequency Stability 0.2ppm or less
7. DC Ammeter 5A
8. AF Volt Meter (AF VTVM) Frequency Range 50Hz to 10kHz
Voltage Range 1mV to 10V
9. Audio Generator (AG) Frequency Range 50Hz to 5kHz or more
Output 0 to 1V
10. Distortion Meter Capability 3% or less at 1kHz
Input Level 50mV to 10Vrms
11. Spectrum Analyzer Measuring Range DC to 1GHz or more
12. Tracking Generator Center frequency 50kHz to 600MHz
Output Voltage 100mV or more
13. 8ΩDummy Load Approx. 8Ω, 3W
14. Regulated Power Supply 5V to 10V, approx. 3A
Useful if ammeter equipped
■Antenna connector adapter
The antenna connector of this transceiver uses an SMA
terminal.
Use an antenna connector adapter [SMA(f) – BNC(f) or
SMA(f) – N(f)] for adjustment. (The adapter is not provided
as an option, so buy a commercially-available one.)
■Repair Jig (Chassis)
Use jig (part No.: A10-4125-03) for repairing the transceiv-
er. Place the TX-RX unit on the jig and fit it with screws.
The jig facilitates the voltage check and protects the final
amplifier FET when the voltage on the flow side of the TX-
RX unit is checked during repairs.
■Battery Jig (W05-1011-00)
Connect the power cable properly between the battery
jig installed in the transceiver and the power supply, and
be sure output voltage and the power supply polarity prior
to switching the power supply ON, otherwise over voltage
and reverse connection may damage the transceiver, or the
power supply or both.
Note: When using the battery jig, you must measure the
voltage at the terminals of the battery jig. Otherwise, a
slight voltage drop may occur within the power cable, be-
tween the power supply and the battery jig, especially while
the transceiver transmits.
+ Terminal (Red)
– Terminal (Black)
S
–
+
C1
100P/25V
C2
470P/25V
C3
100μ/25V
R1
1.8M
+
+Terminal
(Red)
–Terminal
(Black)
Power
supply
Power
cable
Schematic diagram
ADJUSTMENT
