Kenwood TH-D75E User manual

B5A-4505-00/00 (EN)
USER MANUAL
This User Manual covers detailed operating instructions of the TH-D75A/E
including basic operating instructions described in the User Guide comes
with the product.
TH-D75A
TH-D75E

1–1
1 CONTENTS
1 CONTENTS ................................................................................. 1
2 BEFORE STARTING................................................................. 2-1
3 PREPARATION......................................................................... 3-1
SUPPLIED ACCESSORIES..................................................................3-1
INSTALLING THE ANTENNA ...............................................................3-1
INSTALLING THE BATTERY PACK .......................................................3-1
INSTALLING ALKALINE BATTERIES....................................................3-1
INSTALLING THE BELT CLIP ...............................................................3-1
INSTALLING THE HAND STRAP..........................................................3-2
CHARGING THE BATTERY PACK ........................................................3-2
BATTERY LIFE.....................................................................................3-3
CONNECTING TO A CIGARETTE LIGHTER SOCKET..........................3-3
CONNECTING TO A REGULATED POWER SUPPLY............................3-3
4 GETTING ACQUAINTED .......................................................... 4-1
KEY AND CONTROL KNOB OPERATIONS..........................................4-1
DISPLAY..............................................................................................4-3
5 BASIC OPERATIONS ............................................................... 5-1
SWITCHING THE POWER ON/ OFF.....................................................5-1
ADJUSTING THE INTERNAL CLOCK...................................................5-1
ADJUSTING THE VOLUME ..................................................................5-1
VOLUME BALANCE (BAND A/B)..........................................................5-1
SELECTING DUAL BAND MODE/ SINGLE BAND MODE .....................5-1
SELECTING AN OPERATION BAND....................................................5-2
SELECTING A FREQUENCY BAND .....................................................5-2
SELECTING THE DEMODULATION MODE..........................................5-2
SELECTING A FREQUENCY ...............................................................5-2
ADJUSTING THE SQUELCH................................................................5-3
TRANSMITTING ..................................................................................5-3
MONITOR............................................................................................5-3
FUNCTION SELECT MODE .................................................................5-4
6MENU MODE............................................................................ 6-1
MENU ACCESS ...................................................................................6-1
CHARACTER ENTRY...........................................................................6-1
MENU CONFIGURATION.....................................................................6-2
7 OPERATING THROUGH FM REPEATERS................................ 7-1
REPEATER ACCESS ...........................................................................7-1
TRANSMITTING A 1750 Hz TONE .......................................................7-3
REVERSE FUNCTION .........................................................................7-3
8 MEMORY CHANNEL ................................................................ 8-1
SIMPLEX & REPEATER OR ODD-SPLIT MEMORY CHANNEL?...........8-1
MEMORY CHANNEL LIST ..................................................................8-1
RECALLING A MEMORY CHANNEL ....................................................8-2
EDITING MEMORY CHANNEL.............................................................8-3
CALL CHANNEL MEMORY (SIMPLEX) ................................................8-4
CALL CHANNEL MEMORY (ODD-SPLIT) ............................................ 8-4
CALL CHANNEL LIST ..........................................................................8-4
MEMORY GROUP ...............................................................................8-4
MEMORY SHIFT .................................................................................8-5
9 SCAN ....................................................................................... 9-1
SELECTING A SCAN RESUME METHOD ............................................9-1
BAND SCAN........................................................................................9-1
PROGRAM SCAN................................................................................9-2
MHz SCAN ..........................................................................................9-2
MEMORY SCAN ..................................................................................9-2
GROUP LINK SCAN.............................................................................9-3
PRIORITY SCAN .................................................................................9-4
CALL SCAN.........................................................................................9-4
SCAN AUTO BACKLIGHT ....................................................................9-4
10 CTCSS/DCS/CROSS TONE.................................................. 10-1
CTCSS .............................................................................................. 10-1
DCS...................................................................................................10-2
CROSS TONE....................................................................................10-3
11 DUAL TONE MULTI-FREQUENCY(DTMF) ............................ 11-1
MANUAL DIALING ............................................................................. 11-1
AUTOMATIC DIALER .........................................................................11-1
EchoLink MEMORY............................................................................11-2
12 OTHER OPERATIONS .......................................................... 12-1
FREQUENCY STEP SIZE...................................................................12-1
FINE TUNING ....................................................................................12-1
ATTENUATOR (ATT) .......................................................................... 12-1
PROGRAMMABLE VFO .....................................................................12-2
BEAT SHIFT ...................................................................................... 12-2
AF/ IF/ DETECT OUTPUT MODE ....................................................... 12-2
FM NARROW ....................................................................................12-3
BAR ANTENNA..................................................................................12-3
TX INHIBIT ........................................................................................ 12-3
TIME-OUT TIMER ..............................................................................12-3
MICROPHONE SENSITIVITY............................................................. 12-3
SETTING RECEIVING FILTERS .........................................................12-4
VOX (VOICE-OPERATED TRANSMISSION) .......................................12-4
PITCH FREQUENCY..........................................................................12-5
CW REVERSE ..................................................................................12-5
LED CONTROL..................................................................................12-6
DISPLAY ILLUMINATION ...................................................................12-6
POWER ON MESSAGE ..................................................................... 12-6
SINGLE BAND DISPLAY .................................................................... 12-7
METER TYPE .................................................................................... 12-7
DISPLAY BACKGROUND COLOR...................................................... 12-7
INFORMATION BACKLIGHT ..............................................................12-8
AUDIO EQUALIZER (TX/RX).............................................................. 12-8
KEY BEEP ......................................................................................... 12-9
BEEP VOLUME .................................................................................12-9
BATTERY SAVER............................................................................... 12-9
AUTO POWER OFF (APO)................................................................. 12-9
BATTERY LEVEL ............................................................................... 12-9
CHARGING .......................................................................................12-9
PROGRAMMABLE FUNCTION KEYS .............................................. 12-10
KEY LOCK....................................................................................... 12-11
VOLUME LOCK ............................................................................... 12-11
DISPLAY UNIT ................................................................................. 12-11
OUTPUT DESTINATION INTERFACE (USB/Bluetooth)..................... 12-12
SELECTING A LANGUAGE.............................................................. 12-13
VERIFYING THE FIRMWARE VERSION........................................... 12-13
TRANSCEIVER RESET.................................................................... 12-14
13 GPS...................................................................................... 13-1
BUILT-IN GPS FUNCTION ON/ OFF ................................................... 13-1
SETTING MY POSITION DATA........................................................... 13-1
MARK FUNCTION .............................................................................13-4
POSITION MEMORY LIST .................................................................13-4
TARGET POINT ................................................................................. 13-6
TRACK LOG ......................................................................................13-6
14 APRS®..............................................................................................................................................14-1
BASIC SETTINGS.............................................................................. 14-1
POSITION COMMENT....................................................................... 14-3
STATUS TEXT.................................................................................... 14-3
STATION LIST.................................................................................... 14-5
APRS MESSAGE FUNCTIONS ..........................................................14-9
PROGRAMMING A PACKET PATH................................................... 14-11
SETTING INTERNAL TNC ............................................................... 14-12
APRS LOCK .................................................................................... 14-13
SETTING TX BEACON..................................................................... 14-13
SETTING BEACON INFORMATION ................................................. 14-14
OBJECT FUNCTIONS...................................................................... 14-15
QSY FUNCTION .............................................................................. 14-16
SETTING SmartBeaconingTM ....................................................................................................... 14-17
SETTING WAY POINT...................................................................... 14-18
SETTING PACKET FILTER............................................................... 14-19
STORING USER PHRASES ............................................................. 14-19
STORING AUTO MESSAGE REPLY ................................................. 14-19
SETTING NOTIFICATION SOUND ................................................... 14-20
SETTING DISPLAY .......................................................................... 14-21
APRS VOICE ................................................................................... 14-21
SETTING DIGIPEATER .................................................................... 14-21
PC OUTPUT .................................................................................... 14-23

1–2
INDEMNITIES
• JVCKENWOOD Corporation takes all appropriate
measures to ensure all descriptions in this manual
are accurate; however, this manual may still contain
typographical errors (“typos”) and expressions that are
misleading. JVCKENWOOD Corporation is entirely
free from any responsibilities arising from any losses or
damages caused by such typos or expressions.
• JVCKENWOOD Corporation has the right to change or
improve the product specications, etc., described in this
manual without prior notice. JVCKENWOOD Corporation
is entirely free from any responsibilities for any losses or
damages caused by such changes and improvements.
• JVCKENWOOD Corporation is entirely free from any
responsibilities for any failures, damages or losses arising
from, or in connection with, use of the transceiver with or
connected to any external equipment.
• JVCKENWOOD Corporation does not warrant that the
quality and functions described in this manual comply with
your purpose of use and, unless specically described in
this manual, JVCKENWOOD Corporation shall be free
from any responsibilities for any defects and indemnities
for any damages or losses. Selection and installation of
any external equipment shall be done at your own risk.
You are fully responsible for the use and eects of external
equipment.
• JVCKENWOOD Corporation shall be free from any
responsibilities for any incidental losses or damages, such
as missing communications or call opportunities caused
by a failure or performance error of the transceiver.
Note:
¡Display examples in this manual may not match the actual
operations.
NETWORK ...................................................................................... 14-23
VOICE ALERT.................................................................................. 14-24
PROGRAMMING MESSAGE GROUP CODE.................................... 14-24
15 BUILT-IN KISS TNC .............................................................. 15-1
KISS MODE OPERATION ..................................................................15-1
16 D-STAR................................................................................. 16-1
DV MODE/ DR (D-STAR REPEATER) MODE ...................................... 16-1
MY CALLSIGN................................................................................... 16-1
DIGITAL FUNCTION MENU ...............................................................16-2
SIMPLEX CALL..................................................................................16-2
LOCAL AREA CALL ........................................................................... 16-3
GATEWAY CALL ................................................................................16-4
REPLY TO THE GATEWAY CALL........................................................16-4
CALLSIGN DESIGNATION.................................................................16-4
CALLSIGN LIST.................................................................................16-4
DIRECT REPLY..................................................................................16-5
AUTO REPLY FUNCTION...................................................................16-5
RX HISTORY .....................................................................................16-5
TX MESSAGES.................................................................................. 16-6
TX HISTORY...................................................................................... 16-6
CALL WITHIN ZONE ..........................................................................16-6
SETTING THE ACCESS REPEATER (FROM)..................................... 16-7
SETTING THE ROUTE REPEATER (ROUTE) ..................................... 16-7
SETTING THE DESTINATION (TO) .................................................... 16-7
CHECKING THE CALLSIGN SETTING............................................... 16-8
DISPLAYING THE REPEATER DETAILS............................................. 16-9
FAST DATA COMMUNICATION .......................................................... 16-9
EMR COMMUNICATION .................................................................... 16-9
RX AFC ........................................................................................... 16-10
FM AUTO DETECTION ON DV......................................................... 16-10
DATA FRAME OUTPUT.................................................................... 16-10
BK (BREAK) CALL........................................................................... 16-10
CALLSIGN SQUELCH/ CODE SQUELCH......................................... 16-11
GPS DATA TX MODE ....................................................................... 16-11
RX BREAK-IN DISPLAY ................................................................... 16-12
CALLSIGN ANNOUNCE .................................................................. 16-12
STANDBY BEEP .............................................................................. 16-13
DV GATEWAY MODE ....................................................................... 16-13
DR SCAN......................................................................................... 16-14
REPEATER SCAN LOCKOUT .......................................................... 16-14
REPEATER LIST.............................................................................. 16-15
HOTSPOT LIST................................................................................ 16-16
17 USB...................................................................................... 17-1
CONNECTING WITH A PC................................................................. 17-1
OPERATION SETTING ...................................................................... 17-1
SETTING USB AUDIO OUTPUT LEVEL ............................................17-1
18 Bluetooth®..................................................................................................................................18-1
TURNING ON/ OFF THE Bluetooth FUNCTION.................................. 18-1
CONNECTING BY THE PAIRED DEVICE LIST.................................... 18-2
CONNECTING TO A PC VIA Bluetooth ............................................... 18-3
19 microSD MEMORY CARD .................................................... 19-1
INSERTING/ REMOVING A microSD MEMORY CARD ....................... 19-1
FORMATTING A microSD MEMORY CARD........................................ 19-2
HOW TO USE A microSD MEMORY CARD ........................................ 19-2
LOADING MEMORY DATA ................................................................. 19-2
CLEARING THE SAVED FILE............................................................. 19-3
COMMUNICATION HISTORY(QSO LOG)...........................................19-3
DISPLAYING THE microSD MEMORY CARD INFORMATION ............. 19-4
20 RECORDING ........................................................................ 20-1
RECORDING AUDIO FILES ............................................................... 20-1
OPERATION OF THE AUDIO FILE ..................................................... 20-1
21 FM RADIO ............................................................................ 21-1
TURNING ON FM RADIO MODE........................................................ 21-1
EDITING THE FM RADIO MEMORY CHANNEL LIST ......................... 21-1
22 VOICE MESSAGE MEMORY................................................. 22-1
RECORDING VOICE MESSAGES ......................................................22-1
SENDING VOICE MESSAGES ...........................................................22-2
Firmware Copyrights
The title to and ownership of copyrights for rmware embedded in
KENWOOD product memories are reserved for JVCKENWOOD
Corporation.
VOICE MESSAGE MEMORY NAMES................................................. 22-2
CLEARING VOICE MESSAGES ......................................................... 22-3
TX MONITORING OF VOICE MESSAGE ...........................................22-3
23 VOICE GUIDANCE ............................................................... 23-1
SETTING VOICE GUIDANCE MODE .................................................. 23-1
24 WEATHER ALERT (TH-D75A ONLY).................................... 24-1
WEATHER ALERT ON/ OFF............................................................... 24-1
WEATHER CHANNEL SCAN ............................................................. 24-1
25 WIRELESS CONTROL (TH-D75A ONLY) ............................. 25-1
PREPARATION ..................................................................................25-1
CONTROL OPERATION.....................................................................25-1
26 OPTIONS.............................................................................. 26-1
27 MAINTENANCE.................................................................... 27-1
GENERAL INFORMATION ................................................................. 27-1
SERVICE ........................................................................................... 27-1
SERVICE NOTE.................................................................................27-1
CLEANING ........................................................................................27-1
TROUBLESHOOTING........................................................................ 27-2
28 SPECIFICATIONS ................................................................ 28-1

2-1
2 BEFORE STARTING
Thank You
We are grateful you decided to purchase this KENWOOD
Digital transceiver.
The models listed below are covered by this manual.
TH-D75A: 144/220/430MHz Tribander (The Americas)
TH-D75E: 144/430MHz Dual Bander (E type: Europe/ T type:
UK)
Firmware Version 1.00 or later.(The rmware version can be
veried in Menu No.991.)
Features
This transceiver has the following main features:
• Includes a program for dealing with data formats
supported by Automatic Packet Reporting System
(APRS®).
─ Compliant with a APRS®Digital Peter function.
• Compliant with voice/digital mode D-STAR digital amateur
radio networks.
─ Supports with D-STAR 2-wave simultaneous reception.
─ Supports Reector Terminal mode.
• Built-in GPS receiver unit.
• Transective color TFT Display.
• Weatherproof toughness to IP 54/55 standard.
• Wide-band and multi-mode reception.
• Two-wave simultaneous reception.
(VxU, UxV, UxU (TH-D75A/ TH-D75E), Vx220M, 220MxV,
Ux220M (TH-D75A)
• Equipped with IF lter for comfortable reception (SSB/
CW).
• High-performance DSP-based voice processing.
• Built-in Bluetooth (SPP, HSP)
• microSD memory card (2 GB to 32 GB)
• Compliant with the battery charge as well as data
transmission and reception by USB Type-CTM.
• 1000 memory channels, 1500 repeater lists and 30
hodspot lists.
• Transmit power 4-step switching (5/ 2/ 0.5/ 0.05 W)
Writing Conventions Followed in this Manual
The writing conventions described below have been followed
to simplify instructions and avoid unnecessary repetition.
Instruction Action
Press [KEY]. Momentarily press KEY.
Press and hold [KEY] .Press KEY until actived.
Press [KEY1], [KEY2]. Press KEY1 momentarily, release
KEY1, then press KEY2.
Press [F], [KEY].
Press the F key to enter Function
mode, then press KEY to access
its secondary function.
Press [KEY] + Power
ON.
With the transceiver power OFF,
press and hold KEY while turning
the transceiver power ON.

3-1
3 PREPARATION
SUPPLIED ACCESSORIES
After carefully unpacking the transceiver, identify the items
listed in the table below. We recommend you keep the box and
packaging for shipping.
Item Comments
Quantity
TH-
D75A
TH-D75E
E T
Antenna 1 1 1
Li-ion battery pack KNB-75LA:
1820 mAh 1 1 1
Charger
(AC Voltages: 100 - 240 V,
50/60 Hz)
W0H-0160-XX 1 – –
W0H-0161-XX – 1 –
W0H-0162-XX – – 1
Belt clip 2 screws supplied 1 1 1
Warranty card 1 1 1
User guide
English/ French/
Spanish 1 1 1
Italian/ German/
Dutch – 1 –
INSTALLING THE ANTENNA
Hold the supplied antenna by its base, then screw it into the
connector on the top panel of the transceiver until secure.
INSTALLING THE BATTERY PACK
Note:
¡Because the battery pack is provided uncharged, you must
charge the battery pack before using it with the transceiver.
¡When removing the battery pack, be careful not to drop the
transceiver and the battery pack.
¡When installing/removing the battery pack, be careful not to
damage your nails or ngers.
Match the guides of the battery pack with the corresponding
grooves on the upper rear of the transceiver, then rmly press
the battery case to lock it in place.
To remove the battery pack, lift the release lever to unlock the
battery pack. Lift the battery pack away from the transceiver.
INSTALLING ALKALINE BATTERIES
1To open the optional KBP-9 battery case lid, press the
release lever on the top of the battery case, then pull the
cover up.
ab
c
2Insert (or remove) six AAA (LR03) Alkaline batteries.
• When removing the Alkaline batteries from the battery
case, pull up on the batteries from the positive (+)
terminal.
• Be sure to match the battery polarities with those
marked in the bottom of the battery case.
3Align the two tabs at the bottom of battery case, then close
the cover until the locking tabs on top click.
4To install the battery case onto (or remove it from) the
transceiver, follow “INSTALLING THE BATTERY PACK”.
Note:
¡Do not use Manganese batteries or Rechargeable batteries in
place of Alkaline batteries.
¡Remove all batteries from the case when it is not expected to be
in use for several months.
¡To lift the battery pack safety catch, use a piece of hardened
plastic or metal, such as a screwdriver, that is no more than
6 mm wide and 1 mm thick. It is imperative that you place the
implement under only the lip of the safety catch so that you do
not damage the release latch.
INSTALLING THE BELT CLIP
If desired, you can install the supplied belt clip to the
transceiver.
Attach the belt clip rmly using the two supplied M3 x 6 mm
binding screws.
Belt clip
Screws
Note：
¡Be careful not to pinch your ngers into the belt clip.
¡Check occasionally to see if the screws are loose.
CAUTION
• Do not use glue which is designed to prevent screw
loosening when installing the belt clip, as it may cause
damage to the transceiver. Acrylic ester, which is
contained in these glues, may crack the transceiver’s
back panel.

3-2
INSTALLING THE HAND STRAP
If desired, you can install the commercially available strap with
sucient strength using the holes of the transceiver.
Note：
¡If the strap is thick and does not pass through the holes, install
the strap using the holes of the supplied belt clip.
CHARGING THE BATTERY PACK
For charging the battery pack with the supplied
battery charger
The battery pack can be charged after it has been installed
onto the transceiver. (The battery pack is provided uncharged
for safety purposes.)
1Plug the charger into an AC wall outlet.
2Insert the charger plug into the DC IN jack of the
transceiver while the transceiver power is OFF.
Polarity of DC power
connector
DC IN jack
• Charging starts and < > indicator appears on the
display when the transceiver power is OFF. < >
indicator disappears when charging is completed.
• The backlight is ON when pressing any key while
charging.
• "Charging" does not appear when charging with the
optional rapid battery charger.
3It takes approximately 3.5 hours to charge an empty KNB-
75LA Li-ion battery pack (charging when the transceiver
power is OFF). After 3.5 hours, remove the charger plug
from the transceiver DC IN jack.
• Charging when the transceiver power is ON takes a
longer time than charging when the transceiver power
is OFF.
4Unplug the charger from the AC wall outlet.
Note:
¡Never leave the battery pack in direct sunlight.
¡The transceiver becomes warm while charging the battery pack.
¡While the battery pack is charged, the ambient temperature
must be within 0°C ~ 40°C (32°F ~ 104°F). Otherwise, charging
does not start. If the transceiver senses that the temperature is
more than 60°C (140° F) during charging, the transceiver stops
charging.
¡Before recharging the battery pack, use the battery pack until
the transceiver stops receiving.
¡Do not plug the charger into the DC IN jack for more than 24 hours.
¡Do not expose the charger to dripping or splashing conditions.
No objects lled with liquids, such as vases, shall be placed on
the AC adapter or charger.
¡Do not place the charger into the liquids.
¡Unplug the charger as soon as possible after the charging
period is over.
¡The charger plug for an AC wall outlet should be used to
disconnect an AC adapter from an AC outlet, and the charger
plug must remain readily operable.
¡After the battery pack is charged, do not unplug and plug the
charger into the AC outlet again. Unpluging the charger will reset
the charging timer and the battery pack will be charged again.
This could result in over-charging.
¡If the battery pack is not used for a long time, the battery pack
capacity temporarily decreases. In this case, charge the battery
and use the battery pack until the transceiver stops receiving.
Repeat this procedure several times. The battery pack should
recover its capacity.
¡Exceeding the specied charge period shortens the useful life of
the KNB-75LA battery pack.
¡The provided charger is designed to charge only the KNB-75LA
battery pack. Charging other models of battery packs may
damage the charger and battery pack.
¡Do not transmit while charging.
¡When not in use, store the battery pack in a cool and dry place.
¡Before charging the battery pack, ensure that the release lever is
rmly closed.
¡Attention should be drawn to the environmental aspects of
battery disposal.
¡It takes approximately 3 hours to charge the KNB-75LA with the
optional rapid battery charger.
¡Charging through the DC IN jack and USB connector when the
transceiver is turned ON can be prevented. Access Menu No. 923.
For charging the battery pack with the USB cable
(USB Type-CTM)
1Plug the USB cable into an AC adapter, etc.
2Attach the battery pack to the transceiver, and plug the
USB plug into the USB connector while the transceiver
power is OFF.
USB Type-CTM
USB connector
Note：
¡To avoid a failure or abnormal heat generation, be sure to use a
USB converter AC adapter (sold separately) with a 5 V output
voltage and a current of 2 A or higher.
¡Do not use a USB cable exceeding 3 m (9.8 feet).
¡Charging from the USB cable is not guaranteed to work with all
USB cables or AC adapters.
¡Charging time with the USB connector may be longer than with
the supplied charger.
¡If the DC IN cable and USB cable are both connected, you
cannot charge from the USB cable. The DC IN route has priority.
¡Charging through the DC IN jack and USB connector when the
transceiver is turned ON can be prevented. Access Menu No. 923.
For charging the battery pack with the optional rapid
battery charger
Note:
¡Insert the battery pack only in the rapid battery charger to
charge a battery pack that has been in storage for a long time.
¡If the battery pack is completely depleted while using the
transceiver, remove the battery pack from the transceiver and
insert the battery pack in the rapid battery charger.
¡When the battery is installed on the transceiver and you are
using an optional rapid battery charger, do not charge the
battery from the DC IN jack/ USB connector. Charging the
battery from the DC IN jack/ USB connector may result in
overcharging the battery which can result in the shortening of
the battery life cycle.

3-3
Charger Error
• While charging, if a problem is detected in the battery,
“Charge Error !!” appears on the display.
•The following condition create charging error:
Overvoltage in the battery is detected.
• When a charge error occurs, no key other than [ ] will
function.
BATTERY LIFE
Before you operate the transceiver outside using a battery
pack, it is important to know how long the battery pack will
last.
If the battery saver setting is 1.0 sec and the GPS setting is
O in the single band operation, the operating times listed in
the table below are the referential values under the following
cyclic conditions:TX: 6 seconds, RX: 6 seconds, Stand-by: 48
seconds
We recommend you carry extra battery packs with you, in
case the battery pack becomes depleted.
Battery Type Output Power Operating Time/
Hours (Approx.)
KNB-75LA
Li-ion battery pack
H 6
M 8
L 12
EL 15
KBP-9
Battery case
H -
M-
L 3.5
EL -
CONNECTING TO A CIGARETTE LIGHTER SOCKET
To connect the transceiver to the cigarette lighter socket in
your vehicle, use an optional PG-3J Cigarette Lighter cable.
When the PG-3J is connected to the cigarette lighter plug,
the transceiver automatically starts charging the battery pack.
While you operate the transceiver, it charges the battery pack
in the background.
Note:
¡To connect with an external 24 V power source via a DC-DC
converter, only use the optional PG-3J Cigarette Lighter cable.
¡Using the PG-2W DC cable in this situation may cause a re.
PG-2W
24V
12V
24VPG-3J
12V
12V
24VPG-3J
DC-DC Converter
DC-DC Converter
Socket
Note:
¡Do not use the PG-2W to connect directly to a vehicle battery
(12 V). Extensive voltage could result in damaging the
transceiver.
¡If the input voltage exceeds approximately 17.5 V, the
transceiver automatically turns OFF.
CONNECTING TO A REGULATED POWER SUPPLY
To connect the transceiver to an appropriate regulated DC
power supply, use an optional PG-2W DC cable.
1 Conrm that the power of both the transceiver and the DC
power supply is OFF.
2Connect the optional PG-2W DC cable to the DC power
supply; the red lead to the positive (+) terminal, and the
black lead to the negative (–) terminal.
Fuses (3 A)
3Connect the barrel plug on the DC cable to the DC IN jack
of the transceiver.
• While a DC power supply is connected with the DC IN
jack, the transceiver automatically initiates charging the
battery pack.
Caution:
¡Install a lithium-ion battery pack or battery case when a DC
Power Supply is used. Failure to do so may result in burns.
Note:
¡The supply voltage must be between 11 V and 15.9 V to
prevent damaging the transceiver. If the input voltage exceeds
approximately 17.5 V, the transceiver automatically turns OFF.

4-1
4 GETTING ACQUAINTED
[ ]
Press and hold [ ] to turn the transceiver power ON and
OFF.
Press [ ] to turn the backlight ON and OFF when the
transceiver power is ON.
The backlight turns OFF when the backlight timer elapses.
When the voice guidance function is not set to OFF, the
voice announces the operating states of the transceiver.
When pressing [ ] while announcing, the voice stops.
[MONI]
Press and hold [MONI] to unmute the speaker in order to
monitor signals.
Release [MONI] to return to normal operation.
Press [F], [MONI] to enter squelch threshold level
adjustment mode.
[PTT]
Press and hold [PTT], then speak into the microphone to
transmit.
ENC Control
Rotate the ENC control to select an operating frequency,
Memory channel, Menu item, setting value and change the
scan direction, etc.
VOL Control
Rotate the VOL control to adjust the speaker volume.
Multi-Scroll Key
[ ], [ ]
Press [ ] or [ ] to select an operating frequency,
Memory channel, Menu item, setting value or to change the
scan direction, etc.
Press and hold [ ] or [ ] to change an operating
frequency, Memory channel, Menu item, setting value, etc.
continuously.
[ ]
Press and hold [ ] to select a frequency band in VFO
mode.
Press [ ] to move to the next step in various setting
modes.
[ ]
Press and hold [ ] to select a frequency band in VFO
mode.
Press [ ] to move back to the previous step in various
setting modes.
[ENT]
Press [ENT] to enter frequency direct entry mode in VFO
mode.
Press [ENT] to complete the setting value and move to the
next step in Menu mode or various setting modes.
[MODE]
Press [MODE] to select the mode.
Press [F], [MODE] in DV mode or DR mode to enter Digital
Function menu mode.
This key operates the function displayed in the lower left
side.
[MENU]
Press [MENU] to enter Menu mode.
Press [F], [MENU] to cycle the transmit output power.
[A/B]
Press [A/B] to select operation band A or B.
Press [F], [A/B] to switch the Single band mode and Dual
band mode.
This key operates the function displayed in the lower right
side.
[F]
Press [F] to enter Function select mode.
Press and hold [F] to turn the transceiver Key lock function
ON and OFF.
12 Keypad
[VFO] (1)
Press [VFO] to enter VFO mode. In Memory channel
or CALL channel, press [F], [VFO] to copy the current
Memory channel or Call channel to the VFO (memory shift).
KEY AND CONTROL KNOB OPERATIONS
Speaker
Microphone
LCD Display
SP/MIC Jacks
microSD memory card slot
USB Connector (USB Type-CTM)
DC IN (External power supply) Jack

4-2
[MR] (2)
Press [MR] to enter Memory Channel mode.
Press [F], [MR] to move to the Memory channel store
screen.
[CALL] (3)
Press [CALL] to select the Call channel.
Press [F], [CALL] to store the displayed operating
frequency to the Call channel.
[MSG] (4)
Press [MSG] to display the APRS Message list.
Press [F], [MSG] to enter the New Message input mode.
[LIST] (5)
Press [LIST] to display the APRS Station list.
• Each time you press [F], [LIST], the mode cycles
through the following: APRS mode ON KISS mode
ON OFF.
[BCN] (6)
Press [BCN] to transmit the beacon when APRS mode is
ON.
Press [F], [BCN] to transmit the Object.
[REV] (7)
Press [REV] to turn the Reverse function ON or OFF.
Press [F], [REV] to select the Shift direction.
[TONE] (8)
Press [TONE] to turn the Tone function ON.
• Each time you press [TONE], the function cycles
through the following: Tone ON CTCSS ON DCS
ON Cross Tone ON OFF.
Press [F], [TONE] to enter the Tone frequency, CTCSS
frequency, DCS code, or Cross Tone setup mode.
Press [F], press and hold [TONE] to start the Tone
frequency, CTCSS frequency, or DCS code scan.
[PF1] (9)
Press [PF1] to activate its programmed function.
Press [F], [PF1] to turn the Attenuator function ON or OFF.
[MARK] (0)
Press [MARK] to display the Position memory list.
Press and hold [MARK] to enter the Mark Way point
registration mode.
Press [F], [MARK] display your “My position”.
[MHz] ( )
Press [MHz] to enter the MHz mode.
Press and hold [MHz] to start the MHz scan.
Press [F], [MHz] to enter Fine tuning function mode.
[PF2] (#)
Press [PF2] to activate its programmed function.
Press [F], [PF2] to enter Frequency step setup mode or
Fine step frequency setup mode.
ON AIR/ Busy Indicator
The indicator lights red in transmitting, and lights green in
receiving.
The indicator lights blue in transmitting in the reector
terminal mode.

4-3
Various function indicator
Indicator Description Page
Performs as the S meter when
receiving a signal. 12-7
Displays the selected power level
while transmitting. 5-3
Indicates the transmission band. 5-2
Appears while using Economic low
output power. 5-3
Appears while using Low output
power. 5-3
Appears while using Medium output
power. 5-3
Appears while using High output
power. 5-3
Appears while in FM mode. 5-2
Appears while in Narrow FM mode. 12-3
Appears while in Wide FM mode. 21-1
Appears while in AM mode. 5-2
Appears while in LSB mode. 5-2
Appears while in USB mode. 5-2
Appears while in CW mode. 5-2
Appears while in Digital Repeater
mode. 16-1
Appears while in Digital Voice mode. 16-1
Appears when Voice Alert is set to
“ON”. 14-24
Appears when Voice Alert is set to
“RX Only”. 14-24
Appears when the Tone function is
ON. 7-2
Appears when the CTCSS function
is ON. 10-1
Appears when the DCS function is
ON. 10-2
DISPLAY
Indicator Description Page
Appears when the Cross tone
function is “TONE/CTCSS”. 10-3
Appears when the Cross tone
function is “DCS/CTCSS”. 10-3
Appears when the Cross tone
function is “TONE/DCS”. 10-3
Appears when the Cross tone
function is “DCS/OFF”. 10-3
Appears when the Shift function is
set to plus. 7-3
Appears when the Shift function is
set to minus. 7-3
Appears when the Shift function is
set to -7.6 MHz. (TH-D75E only) 7-3
Appears when the Reverse function
is ON. 7-3
Appears when the Attenuator
function is ON. 12-1
Appears when the packet
communication speed in APRS mode
is set to 1200 bps.
14-12
Appears when the packet
communication speed in APRS mode
is set to 9600 bps.
14-12
Appears when the packet
communication speed in KISS mode
is set to 1200 bps.
15-1
Appears when the packet
communication speed in KISS mode
is set to 9600 bps.
15-1
Appears while in Stand-by (Packet
mode). 15-1
Appears when the Beacon function
is ON. 14-13
Appears when the Object function
is ON. 14-15
Appears when the built-in GPS
function is ON and positioning. 13-1
Appears when the built-in GPS
function is ON and not positioning. 13-1
Common icon Display Area
Band A Display Area
Band B Display Area
Frequency Display

4-4
Indicator Description Page
Appears when the GPS Track Log
function is ON and the built-in GPS
function is positioning.
13-6
Appears when the GPS Track Log
function is ON and the built-in GPS
function is not positioning or in Save
mode.
13-6
Appears when a message is
received. 14-9
Appears when recording
communication. 20-1
Appears when recording a voice
message is paused. 20-1
Appears when the Priority Scan
function is ON. 9-4
Appears when FM radio mode is ON. 21-1
The Bluetooth®function is ON. 18-1
Connected to a Bluetooth®device. 18-1
Appears when a microSD memory
card is recognized. Blinks when a
microSD memory card is mounting.
19-1
Appears when Weather Alert is ON.
Blinks when Weather Alert is
detected.
(TH-D75A only.)
24-1
Appears when the key lock is ON. 12-11
Indicates the battery level. 12-9
Appears during charging of the
battery. 3-2
Indicates the memory group number. 8-4
Indicates the Weather Channel. (TH-
D75A only.) 24-1
Indicator Description Page
Appears when the Memory Channel
Lockout function is ON. 9-3
Appears when the Repeater Lockout
function is ON. 16-14
Appears when Callsign squelch is
ON. 16-11
Appears when Code squelch is ON. 16-11
TX: Appears in interrupt
communication.
RX: Blinks while receiving interrupt
communication.
16-10
Appears when the auto reply function
is ON. 16-5
Appears in GPS transmission. 16-11
Appears while in data communication
mode.
Blinks while receiving fast data.
16-9
Appears when a packet loss
happens. 27-2
Indicates a repeater for local area
call. 16-3
Indicates a repeater for call within
zone. 16-6
Indicates a repeater for gateway call. 16-4
Appears while in the reector
terminal mode. 16-13
KEY GUIDE Display Area
Menu Mode Display D-STAR (DV/DR mode) Display

5-1
5 BASIC OPERATIONS
SWITCHING THE POWER ON/ OFF
Switching the Power ON
Press and hold [ ].
The power on message momentarily appears, and frequency
screen appears.
Switching the Power OFF
Press and hold [ ].
ADJUSTING THE INTERNAL CLOCK
The default setting of the built-in GPS function is [On].
When you turn on the power, the built-in GPS receiver will start
positioning after a while, and "GPS Locked" will be appear on
the display.
After that, the < > indicator will change to < > indicator
and the time and date information will be automatically set.
If the GPS information cannot be received, you can manually
enter the date and time.
1Access Menu No. 950.
Date & Time screen appears by pressing [MENU], [PF1],
[LIST], [MARK].
2Set the date, time, and time zone with [ ]/[ ] or [ENC]
control.
3Press [A/B].
The date, time, and time zone are set.
4Press [MENU] to return to the frequency screen.
Note:
¡"GPS Locked" appears on the display only when you turn on
the power or turn on the GPS function and start positioning for
the rst time.
¡The GPS icon on this transceiver does not ush.
¡If there is no voltage supplied from the battery pack, DC IN jack,
or USB connector, date and time information is retained by the
built-in lithium battery for approximately one week, and then
cleared.
¡If you turn on the power after the date and time information has
been cleared and do not perform acquisition using the built-in
GPS receiver or manual settings, the built-in clock will return to
the default date and time as shown below. (Initial values may
change due to rmware updates.)
Date: 01/01/2024
Time: 00:00
ADJUSTING THE VOLUME
Rotate the VOL control to increase the volume and
counterclockwise to decrease the volume.
When no sound is heard (the squelch is closed), you can
adjust the noise level by rotating the VOL control while
pressing the [MONI].
• To change the volume of the beep that sounds when
you press a key. (refer to page No. 12-9 )
• To change the volume of voice guidance. (refer to page
No. 23-1 )
VOLUME BALANCE (BAND A/B)
This function adjusts the volume balance when using the
transceiver with dual bands.
1Access Menu No. 910.
Volume balance screen appears by pressing [MENU],
[PF1],[VFO], [MARK].
2Change the balance with [ ]/[ ] or [ENC] control.
• Band A and B are set to the same volume level (MAX)
as a default setting. Pressing [MODE] returns to the
previous screen without changing the setting.
When you select [Operation Band Only], the sound of the
operation band is outputted with priority.
Setting examples
When used in combination with APRS:
When using band A for voice calls, use the transceiver with
the sound of band B set to a low volume level or muted.
When simultaneously scanning two waves:
If [Operation Band Only] is set, a voice is output only for
the operation band when the operation and non-operation
band become busy at the same time.
3Press [ENT] to set the volume balance.
4Press [MENU] to return to the frequency screen.
SELECTING DUAL BAND MODE/ SINGLE BAND
MODE
You can switch the transceiver between dual band operation
and single band operation.
1Press [F], [A/B].
• Each time you press [F],[A/B], the transceiver
switches between Single band and Dual band mode.
Dual Band mode Single Band mode

5-2
SELECTING AN OPERATION BAND
You can select a band A or B as an operation band for
changing the frequency or setting various operations, etc.
1Press [A/B] to select operating band A or B.
Dual Band A Dual Band B
Single Band A Single Band B
SELECTING A FREQUENCY BAND
You can change the frequency bands for bands A and B.
1Press and hold [ ]/[ ].
• Each time you press and hold [ ]/[ ], you cycle to
the next frequency band.
Band A : 144 220 430  144 (MHz).
Band B : 430  UHF(470-524)  LF/MF(AMBC) 
HF 50 FMBC 118 144 
VHF(174-216) 200/300  430 (MHz).
Note:
¡220 MHz band in Band A is used by the TH-D75A only.
Frequency ranges:
• 118 MHz: Band B 108 ~ 136 MHz
• 144 MHz: 136 ~ 174 MHz
• VHF: 174 ~ 216 MHz (TH-D75A)
174 ~ 230 MHz (TH-D75E)
• 220 MHz: 216 ~ 260 MHz (TH-D75A only)
• 200/300 MHz: Band B 216 ~ 410 MHz (TH-D75A)
230 ~ 410 MHz (TH-D75E)
• 430 MHz: 410 ~ 470 MHz
• UHF: 470 ~ 524 MHz
• LF/MF(AMBC): 0.1 ~ 1.71 MHz
• HF: 1.71 ~ 29.7 MHz
• 50: 29.7 ~ 76 MHz
• FMBC: 76 ~ 108 MHz
SELECTING THE DEMODULATION MODE
You can select the demodulation mode.
1Press [A/B] to select an operation band.
2Press [MODE] to select a demodulation mode.
• Each press changes the demodulation mode as
follows.
Band A: FM/NFM  DR (DV)  (Returns to FM/NFM)
Band B: FM/NFM  DR (DV) AM LSB USB CW
 (Returns to FM/NFM)
Note:
¡Switching between the DV and DR modes is not possible with
the [MODE] button. (Refer to “Digital Function Menu”.)
¡Switching between the FM and NFM modes is not possible with
the [MODE] button.
SELECTING A FREQUENCY
There are 3 operating modes available to choose from: VFO
mode, Memory Channel mode, and Call Channel mode.
VFO Mode
VFO mode allows you to manually change the operating
frequency.
1Press [VFO] to enter VFO mode.
2Rotate the [ENC] control to select your desired operating
frequency.
• You can also select a frequency by using the [ ]/[ ]
keys.
• The default step frequency for the [ENC] control varies
according to the model and operating frequency band:
Model 144 MHz 220 MHz 430 MHz
TH-D75A 5 kHz 20 kHz 25 kHz
TH-D75E 12.5 kHz - 25 kHz
Note:
¡220 MHz band is used by the TH-D75A only.
MHz Step
To adjust the frequency by a larger amount, press [MHz] to
enter MHz mode, then rotate the [ENC] control or use the
[ ]/[ ] keys to adjust the frequency in steps of 1 MHz. Press
[MHz] again to exit MHz mode and adjust the frequency using
the normal step frequency.
Frequency Direct Entry
If the desired operating frequency is far from the current
frequency, using the keypad is the quickest way to change the
frequency.
1Press [ENT].
The Direct Frequency Entry display appears.
2Press the numeric keys ([0] ~ [9]) to enter your desired
frequency.
3To set the entered frequency, press 6 digit.
• Pressing [ENT] before entering all of the digits will set
the remaining digits to 0.

5-3
Memory Channel Mode
Memory Channel mode allows you to quickly select a
frequently used frequency and related data which you have
stored in the memory channel.
1Press [MR] to enter Memory Channel mode.
The Memory channel number appears on the display.
2Press [ ]/[ ] or rotate the [ENC] control to select the
memory channel.
Press [ ] or rotate the [ENC] control clockwise to call
up the memory channel with the higher number, and
press [ ] or rotate the [ENC] control counterclockwise
to call up the memory channel with the lower number.
Display the memory channel number you want to recall.
Press [VFO] to return to frequency display (VFO mode).
Call Channel Mode
Call Channel mode allows you to quickly select a preset
channel to allow immediate calls on that frequency. The Call
channel can be conveniently used as an emergency channel
within your group.
1Press [CALL] to enter Call Channel mode.
“C” appears on the display.
2Press [CALL] again, and the transceiver will return to the
previous frequency.
• The default settings are as follows.
TH-D75A
Band (Mode) Call Channel Memory Name
VHF (except DV/DR mode) 146.520 MHz (FM) Call VHF (FM)
VHF(DV/DR mode) 144.000 MHz (DV) Call VHF (DV)
220 MHz(except DV/DR mode) 223.500 MHz (FM) Call 220M (FM)
220 MHz(DV/DR mode) 223.000 MHz (DV) Call 220M (DV)
UHF(except DV/DR mode) 446.000 MHz (FM) Call UHF (FM)
UHF(DV/DR mode) 440.000 MHz (DV) Call UHF (DV)
TH-D75E
Band (Mode) Call Channel Memory Name
VHF (except DV/DR mode) 145.500 MHz (FM) Call VHF (FM)
VHF(DV/DR mode) 144.8125MHz (DV) Call VHF (DV)
UHF(except DV/DR mode) 433.500 MHz (FM) Call UHF (FM)
UHF(DV/DR mode) 433.6125MHz (DV) Call UHF (DV)
ADJUSTING THE SQUELCH
Squelch is used to mute the speaker when no signals are
present. With the squelch level set correctly, you will hear
sound only while actually receiving a signal. The higher the
squelch level selected, the stronger the signals must be in
order to hear them.You can set the squelch level separately
for Bands A and B.
1Press [F], [MONI].
The squelch level appears on the display.
2Press [ ]/[ ] or rotate the [ENC] control of your selected
band, when no signals are present, and select the squelch
level at which the background noise is just eliminated.
3Press [ENT].
The squelch level is set.
TRANSMITTING
1Select your desired band and frequency/channel.
2Press and hold [PTT], and speak into the microphone to
transmit.
Microphone
3 When you nish speaking, release the [PTT].
Selecting an Output Power
Selecting a lower transmit power is the best way to reduce
battery consumption, if communication is still reliable.
Press [F], [MENU] to select high (H), medium (M), low (L), or
economic low (EL) power.
Battery Pack
KNB-75LA
Battery Case
KBP-9
(AAA Alkaline
batteries)
External Power
Supply
HApprox. 5 W
MApprox. 2 W
LApprox. 0.5 W
EL Approx. 0.05 W
Note:
¡You can program dierent power settings for bands A and B.
¡You can not change the output power in transmitting.
¡You can not set the output power in each frequency band.
MONITOR
When you are receiving while the squelch function is ON,
weak signals may become intermittent.
1Press and hold [MONI].
• The speaker is unmuted and you can monitor the
signals.
2Release [MONI] to return to normal operation.

5-4
FUNCTION SELECT MODE
Press [F] to enter Function Select mode. Press [F] again to
return to the previous screen.
Pressing each key in the function select mode performs the
operation of the second function assigned to each key.
The function of each key may dier depending on the mode
when [F] is pressed (refer to the following table).
Key Second function Remarks
[MARK]
(0) My position Built-in GPS is On.
[VFO] (1) Memory shift
Only in Memory
mode or Call
mode
[MR] (2) Memory channel
registration
[CALL]
(3) Call channel registration
[MSG] (4) APRS message creation
[LIST] (5) APRS/ KISS mode
switching
[BCN] (6) Object beacon Only in APRS
mode
[REV] (7) Shift
[TONE]
(8) Tone frequency
[PF1] (9) Attenuator
[MHz] (*) Fine mode
[PF2] (#) Frequency Step
[MODE] Digital function menu Only in DV/DR
mode
[MENU] Transmission power
[A/B] Dual or Single band
switching
[F] Function select mode end
[MONI] Squelch setting
Note:
¡The tone frequency changes to the following setting items
depending on the conditions of this transceiver.
Tone OFF: Invalid
Tone ON: Tone frequency
CTCSS ON: CTCSS frequency
DCS ON: DCS frequency
Cross Tone ON: Cross tone combination

6-1
6 MENU MODE
Software Key operation
Software keys ([Back], [OK], etc.) are displayed in the key
guide area of various setting screens and other screens.
To select or operate the displayed functions, press the
corresponding keys.
Example:
[Back] Press [MODE]: Returns to the previous screen
without conrming the displayed setting.
[OK] Press [A/B]: Changes to the next screen.
CHARACTER ENTRY
In the screens that require you to enter text such as the screen
for entering a memory name or power-on message, there
are two methods to enter text. One is to enter text using the
number keys in the same ways as a mobile phone and the
other is to enter text by selecting characters one by one with
the Multi-Scroll Key or [ENC] control.
Keypad Character Entry
1Enter text with [0] to [9], [ ], [#], and [ENT].
• The each press of a key changes the character that can
be entered.
• To enter another character assigned to the same key,
move the cursor to the next position with [ ] ([ ]
moves the cursor to the previous position) and enter the
next character.
• Pressing [A/B] deletes a character. The character at the
cursor position is deleted. The backspace operation is
performed when there is a blank space.
• Pressing [ ]/[ ] moves the cursor.
Example: Entering the power-on message (Menu No.903)
• Pressing [MODE] input the space.
• Pressing [A/B] clears the text.
2Press [ ].
The cursor moves to the right.
3Press [ENT].
The text is conrmed and text input ends.
Many functions on this transceiver are selected or congured
through the Menu instead of physical controls.
MENU ACCESS
Example: Setting the time for [Battery Saver] of Menu No. 920.
1Press [MENU].
The transceiver enters the Menu mode. The icon currently
selected by the cursor is highlighted, and the item name is
displayed at the bottom of the screen. (Example: TX/RX)
Directly Entering a Menu Number (Direct Access)
You can also directly enter a menu number using the number
keys from this screen.
Press [PF1], [MR], [MARK] for Menu No.920. In this case,
you can move to step 4.
2 Select [Conguration] with [ ]/[ ] or [ENC] control and
press [A/B].
3Select [Battery] with [ ]/[ ] or [ENC] control and press
[A/B].
4Select [Battery Saver] with [ ]/[ ] or [ENC] control and
press [A/B].
5Select a setting value with [ ]/[ ] or [ENC] control and
press [A/B] to set the value.
6Press [MENU].
The menu mode ends and the frequency screen appears.
For subsequent menu operations, steps 1 to 4 will be
referred to as “Access Menu No. XXX”.
Note:
¡Pressing [PTT] during each operation ends menu mode without
conrming the setting.
¡Pressing [MODE] during each operation returns to the previous
screen. Also, pressing [MODE] during step 4 discards the new
setting value and returns to the previous operation.
¡Pressing [MENU] in scanning cancels scan.

6-2
Entering Text with the Multi Scroll Key or [ENC]
1Display the character with [ ]/[ ] or [ENC] control.
2Press [ ].
The character or symbol is entered and the cursor moves
to the right.
Pressing [A/B] deletes the character selected by the
cursor. If it is pressed when there is no character selected
by the cursor, the cursor moves to the left.
Auto Cursor Shift
This function provides assistance for entering text using
the number keys. It is convenient to use this function when
consecutively entering characters with the same key because
it automatically moves the cursor to the right after a set time
has passed.
You can set this time until the cursor is moved to the desired
time.
1Access Menu No. 945.
Select [O], [1.0], [1.5], or [2.0] seconds.
2Press [ENT].
MENU CONFIGURATION
No. Display Description Setting Values
TX/RX - RX
100 Programmable VFO Programmable VFO setting (Band A only) Varies with the selected frequency band
101 Beat Shift Beat shift Type 1 - Type 8
102 USB Out Select USB output select AF/ IF/ Detect
103 FM Narrow FM narrow O/ On
104 MW/ SW Antenna MW/ SW Antenna ANT connector / Bar Antenna
105 WX Alert Weather alert O/ On (TH-D75A only)
TX/RX - TX
110 TX Inhibit TX inhibit O/ On
111 Time-out Timer Time-out timer 0.5/ 1.0/ 1.5/ 2.0/ 2.5/ 3.0/ 3.5/ 4.0/ 4.5/ 5.0/ 10.0 [min]
112 Mic. Sensitivity Microphone sensitivity High/ Medium/ Low
TX/RX - RX Filter
120 SSB High Cut SSB high cut frequency 2.2/ 2.4/ 2.6/ 2.8/ 3.0 [kHz]
121 CW Width CW bandwidth 0.3/ 0.5/ 1.0/ 1.5/ 2.0 [kHz]
122 AM High Cut AM high cut frequency 3.0/ 4.5/ 6.0/ 7.5 [kHz]
TX/RX - Scan
130 Resume Resume method Time/ Carrier/ Seek
131 Resume (Digital) Resume method (Digital) Time/ Carrier/ Seek
132 Time Restart Time operate restart time 1 - 5- 10 [sec]
133 Carrier Restart Carrier operate restart time 1 - 2- 10 [sec]
134 Priority Scan Priority scan O/ On
135 Scan Auto Backlight Scan auto backlight O/ On
136 Auto Weather Scan Auto Weather Channel Scan O/ On (TH-D75A only)
TX/RX - Repeater
140 Oset Frequency Oset frequency Varies with the selected frequency band
141 Auto Oset Auto repeater oset O/ On
142 CALL Key CALL key function CALL (TH-D75A)/ 1750Hz (TH-D75E)
143 1750Hz TX Hold 1750 Hz TX hold O/ On
TX/RX - VOX
150 VOX VOX on/ o O/ On
151 Gain VOX gain level 0 - 4- 9
152 Delay VOX delay time 250/ 500/ 750/ 1000/ 1500/ 2000/ 3000 [ms]
153 TX on Busy VOX on busy O/ On
TX/RX - DTMF
160 Encode Speed Encode speed 50/ 100/ 150 [ms]
161 Pause Time Pause time 100/ 250/ 500/ 750/ 1000/ 1500/ 2000 [ms]
162 TX Hold TX hold O/ On
163 DTMF Memory DTMF memory
Up to 10 channels for DTMF memory channel
Up to 16 characters for DTMF memory name
Up to 16 digits for DTMF memory code
164 EchoLink Memory EchoLink memory
Up to 10 channels for EchoLink memory channel
Up to 8 characters for EchoLink memory name
Up to 8 digits for one channel code

6-3
No. Display Description Setting Values
TX/RX - CW
170 Pitch Frequency Pitch frequency 400 - 800 - 1000 [Hz]
171 Reverse Reverse Normal/ Reverse
TX/RX - Others
180 QSO Log QSO log O/ On
181 LED Control LED control RX: Check
FM Radio: Uncheck
Memory - Memory Channel
200 View List Memory channel list -
201 Group Name Memory group name input Up to 16 characters
202 Recall Method Memory channel recall method All Bands/ Current Band
203 Group Link Memory group link registration register up to 30 memory group links
204 CALL Ch List CALL channel list -
Memory - Repeater List
210 View List Repeater list -
Memory - Callsign List
220 View List Callsign list -
Memory - Hotspot List
230 View List Hotspot list -
Audio File - Recording File
300 View List Recording le list -
301 Recording Recording Stop/ Start
302 Recording Band Recording band A Band/ B Band
Audio File - Voice Message
310 View List Voice message list -
311 TX Monitor TX monitor O / On
312 Digital Auto Reply Digital auto reply O/ Voice Message 1 - Voice Message 4
GPS - Basic Settings
400 Built-in GPS Built-in GPS O/ On
401 My Position My position GPS/ My Position 1 - 5
402 Position Ambiguity Position ambiguity mode O/ 1-Digit - 4-Digit
403 Operating Mode Built-in GPS operating mode Normal/ GPS Receiver
404 Battery Saver Battery saver time O/ 1min/ 2min/ 4min/ 8min/ Auto
405 PC Output GPS data output to PC O/ On
406 Sentence Sentence $GPGGA/ $GPGLL/ $GPGSA / $GPGSV/ $GPRMC/
$GPVTG
GPS - Track Log
410 Track Log Track log recording O/ On
411 Clear Track Log Clear track log -
412 Record Method Record method Time/ Distance/ Beacon
413 Interval Interval time 2 - 10 - 1800 [sec]
414 Distance Distance 0.01 - 9.99 [mile, km, nm]
APRS - Basic Settings
500 My Callsign Callsign entry (for APRS) Up to 9 characters
501 Icon Icon Person/ Bicycle/ Motorcycle, etc. (total 68 icons)
502 Position Comment Position comment
O Duty/ Enroute/ In Service/ Returning/ Committed/
Special/ PRIORITY/ CUSTOM0 ~ CUSTOM6/
EMERGENCY!
503 Status Text Status text
Status text: 1- 5
TX Rate: O/ 1/1 - 1/4 - 1/8
Up to 42 characters
504 Packet Path Packet path type
Type: New-N/ Relay/ Region/ Others1-Others3,
WIDE1-1: O/On, RELAY: O/On, ABBR: Up to 5
characters,
Total Hops: 0 - 1- 7, Path: Up to 79 characters
505 Data Speed Data communications speed 1200 bps/ 9600 bps
506 Data Band Internal data band type A Band/ B Band
507 DCD Sense DCD sense type Busy/ Detect Data/ O (Ignore)
508 TX Delay TX delay time 100/ 150/ 200/ 300/ 400/ 500/ 750/ 1000 [ms]
509 APRS Lock APRS lock Frequency/ PTT/ APRS Key: All unchecked

6-4
No. Display Description Setting Values
APRS - Beacon TX Control
510 Method Method Manual/ PTT/ Auto/ SmartBeaconing
511 Initial Interval Initial Interval timer 0.2/ 0.5/ 1/ 2/ 3/ 5/ 10/ 20/ 30/ 60 [min]
512 Decay Algorithm Decay Algorithm O/ On
513 Prop. Pathing Prop. Pathing O/ On
514 Speed Speed O/ On
515 Altitude Altitude O/ On
516 Object Object name
Name: up to 9 characters, Type: Live Object/ Killed
Object/ Live Item/ Killed Item, Method: O/ Temp./
Auto(15 min)/ Auto(30 min)/ Auto(60 min), N(S): Latitude,
E(W): Longitude, Icon (Total 68 kinds): Eyeball/ Portable
(Tent)/ HAM store, etc., Comment: up to 42 characters
APRS - QSY Information
520 QSY Info. in Status QSY information in status O/ On
521 Tone/Narrow Tone/ Narrow O/ On
522 Shift/Oset Shift/ Oset O/ On
523 QSY Limit Distance QSY limit distance O/ 10/ 20 … 2490/ 2500 [mile, km, nm]
APRS - SmartBeaconing
530 Low/High Speed Low speed/ High speed setting Low Speed: 2 - 5- 30 [mile/h, km/h, knots]
High Speed: 2 - 70 - 90 [mile/h, km/h, knots]
531 Slow Rate Low speed transmission interval time 1- 30 - 100 [min]
532 Fast Rate High speed transmission interval time 10 - 120 - 180 [sec]
533 Turn Angle Driving direction change, minimum value
setting 5 deg - 28 deg - 90 deg
534 Turn Slope Driving direction change, additional value
setting
1 (10deg/speed) - (26 10deg/speed) - 255 (10deg/
speed)
535 Turn Time Minimum time delay between each beacon
transmission 5 - 60 - 180 [sec]
APRS - Waypoint
540 Format Way point format NMEA/ MAGELLAN/ KENWOOD
541 Length Way point name length 6-Char/ 7-Char/ 8-Char/ 9-Char
542 Output Way point output type All/ Local/ Filtered
APRS - Packet Filter
550 Position Limit Position limit O/ 10/ 20 … 2490/ 2500 [mile, km, nm]
551 Filter Type Filter type Weather/ Digipeater/ Mobile/ Object/ NAVITRA/
1-WAY/ Others
APRS - Message
560 User Phrases User phrases Up to 32 characters x 20 phrases
561 Auto Reply Auto message reply O/ On
562 Reply To Reply to Up to 9 characters
563 Reply Delay Time Reply delay time 0/ 10/ 20/ 30/ 60 [sec]
564 Reply Message Text Reply message text input Up to 50 characters
APRS - Notication
570 RX Beep RX beep O/ Message Only/ Mine/ All New/ All
571 TX Beep TX beep O/ On
572 Special Call Special call Up to 9 characters
573 Display Area Display area Entire Always/ Entire Display/ One Line
574 Interrupt Time Interrupt time 3/ 5/ 10/ 20/ 30/ 60/ innite [sec]
575 APRS Voice APRS voice O/ On
APRS - Digipeat
580 Digipeat(MyCall) Digipeat function O/ On
581 Uicheck UI check time 1 - 28 - 250 [sec]
582 Uidigipeat Uidigipeat O/ On
583 UIdigi Aliases UIdigi aliases Up to 9 characters x 4
584 UIood UIood O/ On
585 UIood Alias UIood alias Up to 5 characters
586 UIoodSubstitution UIood substitution First/ ID/ NOID
587 UItrace UItrace O/ On
588 UItrace Alias UItrace alias Up to 5 characters

6-5
No. Display Description Setting Values
APRS - Others
590 PC Output PC output type O/ Raw Packets/ Waypoints
591 Network Network type APRS[APK005]/ Altnet
592 Voice Alert Voice alert type O/ On/ RX Only
593 VA Frequency VA frequency type 67.0 - 100.0 - 254.1 Hz
594 Message Group Code Message group code Up to 9 characters x 6 codes (ALL,QST,CQ,KWD)
595 Bulletin Group Code Bulletin group code Up to 5 characters x 6 codes
Digital - RX History
600 View History View History -
Digital - TX/RX
610 My Callsign Callsign entry (for DV/DR mode) Up to 8 characters + up to 4 characters
611 TX Message TX message O/ 1/ 2/ 3/ 4/ 5
612 Direct Reply Direct reply O/ On
613 Auto Reply Timing Auto reply timing Immediate/ 5/ 10/ 20/ 30/ 60 [sec]
614 Data TX End Timing Data TX end timing O/ 0.5/ 1/ 1.5/ 2 [sec]
615 EMR Volume Level EMR Volume level 1 - 25 - 50
616 RX AFC RX AFC O/ On
617 FM Auto Det. on DV FM auto detector on DV O/ On
618 Data Frame Output Data Frame Output All/ Related to DSQ/ DATA Mode
619 Break Call Break Call O/ On
Digital - Digital Squelch
620 Select Type Select Type O/Code Squelch/ Callsign Squelch
621 Digital Code Digital Code 00 - 99
Digital - GPS Data TX
630 GPS Info. in Frame GPS Information in frame O/ On
631 Sentence Sentence $GPGGA/ $GPGLL/ $GPGSA/ $GPGSV/ $GPRMC/
$GPVTG/ APRS Sentence
632 Auto TX Auto TX O/ 0.2/ 0.5/ 1/ 2/ 3/ 5/ 10/ 20/ 30/ 60 [min]
Digital - RX Notication
640 Display Method Display method O/ All/ Related to DQS/ My Station Only
641 Single Display Size Single display size Half Display/ Entire Display
642 Dual Display Size Dual display size Half Display/ Entire Display
643 Display Hold Time Display hold time 0 / 3/ 5/ 10/ 20/ 30 / 60/ Innite [sec]
644 Callsign Announce Callsign announce O/ Kerchunk/ Except Kerchunk/ My Station Only/ All
645 Standby Beep Standby beep O/ On
Digital - DV Gateway
650 DV Gateway Mode DV Gateway mode setting O/ Reector TERM Mode
651 My Callsign Callsign entry (for DV Gateway mode) Up to 8 character callsign + 6 patterns of up to 4 character
identication code
652 RPT1 RPT1 (for DV Gateway mode) Up to 8 characters
653 RPT2 RPT2 (for DV Gateway mode) Up to 8 characters
654 Device Information Device name Up to 16 characters
FM Broadcasting - Basic Settings
700 FM Radio Mode FM radio mode O/ On
701 Auto Mute RET. Time Auto mute return time 1 - 3- 10 [sec]
FM Broadcasting - Memory
710 FM Radio List FM radio list -
SD Card - Export
800 Cong Data Cong data -
801 Cong Data + V.Msg Cong data and voice message -
802 Repeater List Only Repeater list only -
803 Callsign List Only Callsign list only -
SD Card - Import
810 Cong Data Cong data -
811 Cong Data + V.Msg Cong data and voice message -
812 Repeater List Only Repeater list only -
813 Callsign List Only Callsign list only -
