Kenwood TK-2180 User manual

B62-2508-10 (E)
TK-2180/ TK-3180
VHF FM TRANSCEIVER/
UHF FM TRANSCEIVER
INSTRUCTION MANUAL
ÉMETTEUR-RÉCEPTEUR FM VHF/
ÉMETTEUR-RÉCEPTEUR FM UHF
MODE D’EMPLOI
TRANSCEPTOR DE FM VHF/
TRANSCEPTOR DE FM UHF
MANUAL DE INSTRUCCIONES
RICETRASMETTITORE FM VHF/
RICETRASMETTITORE FM UHF
MANUALE DI ISTRUZIONI
VHF-FM-TRANSCEIVER/
UHF-FM-TRANSCEIVER
BEDIENUNGSANLEITUNG
VHF FM ZENDONTVANGER/
UHF FM ZENDONTVANGER
GEBRUIKSAANWIJZING

Importeur
Amsterdamseweg 37, 1422 AC Uithoorn, Nederland
Importer
12 Priestley Way, London NW2 7BA, United Kingdom
Importeur
Konrad-Adenauer-Allee 1-11, 61118 Bad Vilbel, Deutschland
Importador
Carretera de Rubi, 88 Planta 1A, 08174 Sant Cugat del Vallès Barcelona, España
Importateur
7 Allee des Barbanniers 92230 Gennevilliers, France
Importatore
Via G. Sirtori 7/9, 20129 Milano, Italia
Importeur
Leuvensesteenweg 248J, 1800 Vilvoorde, België
Authorised Representative in Europe
Amsterdamseweg 37, 1422 AC Uithoorn, THE NETHERLANDS
Manufacturer
3-12, Moriyacho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, JAPAN

VHF FM TRANSCEIVER/
UHF FM TRANSCEIVER
TK-2180/ TK-3180
INSTRUCTION MANUAL
ENGLISH
NOTIFICATION
This equipment complies with the essential
requirements of Directive 2014/53/EU.
This equipment requires a licence and is intended
for use in the countries as below.
AT BE DK FI FR DE GR IS IE
IT LI LU NL NO PT ES SE CH
GB CY CZ EE HU LV LT MT PL
SK SI BG RO HR TR
ISO3166

THANK YOU
We are grateful you chose KENWOOD for your land mobile radio
applications. We believe this easy-to-use transceiver will provide
dependable communications to keep personnel operating at peak
efficiency.
KENWOOD transceivers incorporate the latest in advanced technology.
As a result, we feel strongly that you will be pleased
with the quality and features of this product.
MODELS COVERED BY THIS MANUAL
• TK-2180: VHF FM Transceiver
• TK-3180: UHF FM Transceiver
NOTICES TO THE USER
◆Government law prohibits the operation of unlicensed radio
transmitters within the territories under government control.
◆Illegal operation is punishable by fine and/or imprisonment.
◆Refer service to qualified technicians only.
SAFETY: It is important that the operator is aware of and understands
hazards common to the operation of any transceiver.
Information on Disposal of Old Electrical and Electronic Equipment and Batteries
(applicable for countries that have adopted separate waste collection systems)
Products and batteries with the symbol (crossed-out wheeled bin) cannot
be disposed as household waste.
Old electrical and electronic equipment and batteries should be recycled at
a facility capable of handling these items and their waste byproducts.
Contact your local authority for details in locating a recycle facility nearest to
you.
Proper recycling and waste disposal will help conserve resources whilst
preventing detrimental effects on our health and the environment.
Notice: The sign "Pb" below the symbol for batteries indicates that this
battery contains lead.
Firmware Copyrights
The title to and ownership of copyrights for firmware embedded in
KENWOOD product memories are reserved for JVC KENWOOD
Corporation.

i
PRECAUTIONS
• Do not charge the transceiver and battery pack when they are wet.
• Ensure that there are no metallic items located between the
transceiver and the battery pack.
• Do not use options not specified by KENWOOD.
• If the die-cast chassis or other transceiver part is damaged, do not
touch the damaged parts.
• If a headset or headphone is connected to the transceiver, reduce
the transceiver volume. Pay attention to the volume level when
turning the squelch off.
• Do not place the microphone cable around your neck while near
machinery that may catch the cable.
• Do not place the transceiver on unstable surfaces.
• Ensure that the end of the antenna does not touch your eyes.
• When the transceiver is used for transmission for many hours, the
radiator and chassis will become hot. Do not touch these locations
when replacing the battery pack.
• Do not immerse the transceiver in water.
Turn the transceiver power off in the following locations:
• In explosive atmospheres (inflammable gas, dust particles,
metallic powders, grain powders, etc.).
• While taking on fuel or while parked at gasoline service stations.
• Near explosives or blasting sites.
• In aircrafts. (Any use of the transceiver must follow the
instructions and regulations provided by the airline crew.)
• Where restrictions or warnings are posted regarding the use of
radio devices, including but not limited to medical facilities.
• Near persons using pacemakers.

ii
• Do not disassemble or modify the transceiver for any reason.
• Do not place the transceiver on or near airbag equipment while
the vehicle is running. When the airbag inflates, the transceiver
may be ejected and strike the driver or passengers.
• Do not transmit while touching the antenna terminal or if
any metallic parts are exposed from the antenna covering.
Transmitting at such a time may result in a high-frequency burn.
• If an abnormal odor or smoke is detected coming from the
transceiver, switch the transceiver power off immediately,
remove the battery pack from the transceiver, and contact your
KENWOOD dealer.
• Use of the transceiver while you are driving may be against
traffic laws. Please check and observe the vehicle regulations
in your area.
• Do not expose the transceiver to extremely hot or cold
conditions.
• Do not carry the battery pack (or battery case) with metal
objects, as they may short the battery terminals.
• The orange seal on the reverse side of the transceiver is
important with respect to the waterproof efficiency of the
transceiver. Do not place stickers or other materials on or
around the seal shown in the figure, or on the reverse side of
the battery pack. Doing so will impair the waterproof efficiency
of the transceiver and may cause it to break down. Additionally,
in order to prevent damage to the seal, do not allow it to come
in contact with foreign materials.

iii
CONTENTS
UNPACKING AND CHECKING EQUIPMENT .............................. 1
SUPPLIED ACCESSORIES....................................................... 1
PREPARATION .............................................................. 2
BATTERY PACK PRECAUTIONS.................................................. 2
INSTALLING/ REMOVING THE (OPTIONAL) BATTERY PACK ........................ 7
INSTALLING THE (OPTIONAL) ANTENNA ......................................... 8
INSTALLING THE BELT CLIP .................................................... 8
INSTALLING THE CAP OVER THE UNIVERSAL CONNECTOR ........................ 9
INSTALLING THE (OPTIONAL) SPEAKER/ MICROPHONE OR HEADSET.............. 9
GETTING ACQUAINTED ...................................................10
DISPLAY ....................................................................12
PROGRAMMABLE FUNCTIONS...........................................14
BASIC OPERATIONS .......................................................16
OVERVIEW...................................................................16
SWITCHING POWER ON/ OFF ...............................................16
ADJUSTING THE VOLUME .....................................................17
SELECTING AZONE AND CHANNEL.............................................17
TRANSMITTING...............................................................18
RECEIVING...................................................................18
CONVENTIONAL SCAN ....................................................19
ADD TO SCAN/ DELETE FROM SCAN ..........................................19
SCAN REVERT ...............................................................20
PRIORITY SCAN..............................................................20
QUIET TALK (QT)/ DIGITAL QUIET TALK (DQT) ........................21
OPERATOR SELECTABLE TONE (OST).........................................21
5-TONE SIGNALING........................................................22
MAKING ASELCALL (SELECTIVE CALL)........................................22
TRANSMITTING ASTATUS MESSAGE...........................................23
RECEIVING SELCALLS AND STATUS MESSAGES .................................24
REVIEWING MESSAGES IN THE QUEUE MEMORY ...............................25

iv
FleetSync: ALPHANUMERIC 2-WAY PAGING FUNCTION ............26
SELCALL (SELECTIVE CALLING)...............................................26
STATUS MESSAGE ...........................................................27
SHORT MESSAGES...........................................................29
LONG MESSAGES ............................................................29
DTMF (DUAL TONE MULTI FREQUENCY) CALLS ......................30
MANUAL DIALING............................................................30
AUTODIAL ...................................................................30
REDIAL......................................................................30
CONNECT/ DISCONNECT IDS..................................................31
DTMF SIGNALING ..........................................................31
STUN .......................................................................31
VOICE OPERATED TRANSMISSION (VOX)..............................32
EMERGENCY CALLS .......................................................34
ADVANCED OPERATIONS .................................................35
SELECTING ATRANSMIT POWER ..............................................35
TALK AROUND...............................................................35
MONITOR/ SQUELCH OFF ....................................................36
KEY LOCK...................................................................37
SCRAMBLER .................................................................37
CLOCK ......................................................................38
TRANSCEIVER BACKLIGHT.....................................................38
BACKGROUND OPERATIONS .............................................39
TIME-OUT TIMER (TOT).....................................................39
BUSY CHANNEL LOCKOUT (BCL).............................................39
BATTERY SAVER .............................................................39
BATTERY POWER INDICATOR ..................................................40
SIGNAL STRENGTH INDICATOR ................................................40
BEGINNING/ END OF TRANSMIT SIGNAL .......................................40
VGS-1 OPTIONAL VOICE GUIDE & STORAGE UNIT ...................41
VOICE RECORDER............................................................41
VOICE GUIDE ................................................................43

1
UNPACKING AND CHECKING EQUIPMENT
Note: The following unpacking instructions are for use by your
KENWOOD dealer, an authorized KENWOOD service facility, or
the factory.
Carefully unpack the transceiver. We recommend that you
identify the items listed in the following table before discarding
the packing material. If any items are missing or have
been damaged during shipment, file a claim with the carrier
immediately.
SUPPLIED ACCESSORIES
Item Quantity
Belt clip 1
Screw for belt clip 2
Univeral connector cap 1
Screw for connector cap 1
Instruction manual 1
Belt clip + screws Universal connector
cap + screw

2
PREPARATION
BATTERY PACK PRECAUTIONS
Do not use battery packs or battery chargers not recommended
by KENWOOD.
◆Do not recharge the battery pack if it is already fully charged.
Doing so may cause the life of the battery pack to shorten or the
battery pack may be damaged.
◆After charging the battery pack, disconnect it from the charger.
If the charger power is reset (turned ON after being turned
OFF), recharging will start again and the battery pack will
become overcharged.
◆Do not use the transceiver while charging the battery pack.
We recommend you switch the transceiver power OFF while
charging is taking place.
◆Do not charge the battery pack when the battery pack or
transceiver is wet, to avoid the risk of fire or damage. Wipe
the water from thebattery pack or transceiver using a dry cloth
before charging.
◆Do not short the battery terminals or dispose of the battery by
fire.
◆Never attempt to remove the casing from the battery pack.
■CHARGING THE BATTERY PACK
For charging procedures, refer to the battery charger
Instruction Manual.

3
Information concerning the (optional) Li-ion battery pack:
The battery pack includes flammable objects such as organic solvent.
Mishandling may cause the battery to rupture producing flames or
extreme heat, deteriorate, or cause other forms of damage to the
battery. Please observe the following prohibitive matters.
• Do not disassemble or reconstruct battery!
The battery pack has a safety function and protection circuit to
avoid danger. If they suffer serious damage, the battery may
generate heat or smoke, rupture, or burst into flame.
• Do not short-circuit the battery!
Do not join the + and – terminals using any form of metal (such
as a paper clip or wire). Do not carry or store the battery pack in
containers holding metal objects (such as wires, chain-necklace
or hairpins). If the battery pack is short-circuited, excessive
current will flow and the battery may generate heat or smoke,
rupture, or burst into flame. It will also cause metal objects to
heat up.
• Do not incinerate or apply heat to the battery!
If the insulator is melted, the gas release vent or safety function
is damaged, or the electrolyte is ignited, the battery may
generate heat or smoke, rupture, or burst into flame.
• Do not use or leave the battery near fires, stoves, or other
heat generators (areas reaching over 80°C)!
If the polymer separator is melted due to high temperature,
an internal short-circuit may occur in the individual cells and
the battery may generate heat or smoke, rupture, or burst into
flame.
• Do not immerse the battery in water or get it wet by other
means!
If the battery’s protection circuit is damaged, the battery
may charge at extreme current (or voltage) and an abnormal
chemical reaction may occur. The battery may generate heat or
smoke, rupture, or burst into flame.
DANGER

4
• Do not charge the battery near fires or under direct
sunlight!
If the battery’s protection circuit is damaged, the battery
may charge at extreme current (or voltage) and an abnormal
chemical reaction may occur. The battery may generate heat or
smoke, rupture, or burst into flame.
• Use only the specified charger and observe charging
requirements!
If the battery is charged in unspecified conditions (under high
temperature over the regulated value, excessive high voltage or
current over regulated value, or with a remodelled charger), it
may overcharge or an abnormal chemical reaction may occur.
The battery may generate heat or smoke, rupture, or burst into
flame.
• Do not pierce the battery with any object, strike it with an
instrument, or step on it!
This may break or deform the battery, causing a short-circuited.
The battery may generate heat or smoke, rupture, or burst into
flame.
• Do not jar or throw the battery!
An impact may cause the battery to leak, generate heat
or smoke, rupture, and/or burst into flame. If the battery’
s protection circuit is damaged, the battery may charge at
an abnormal current (or voltage), and an abnormal chemical
reaction may occur. The battery may generate heat or smoke,
rupture, or burst into flame.
• Do not use the battery pack if it is damaged in any way!
The battery may generate heat or smoke, rupture, or burst into
flame.
• Do not solder directly onto the battery!
If the insulator is melted or the gas release vent or safety
function is damaged, the battery may generate heat or smoke,
rupture, or burst into flame.
• Do not reverse the battery polarity (and terminals)!
When charging a reversed battery, an abnormal chemical
reaction may occur. In some cases, an unexpected large
amount of current may flow upon discharging. The battery may
generate heat or smoke, rupture, or burst into flame.

5
• Do not charge the battery for longer than the specified
time!
If the battery pack has not finished charging even after the
regulated time has passed, stop it. The battery may generate
heat or smoke, rupture, or burst into flame.
• Do not place the battery pack into a microwave or high
pressure container!
The battery may generate heat or smoke, rupture, or burst into
flame.
• Keep ruptured and leaking battery packs away from fire!
If the battery pack is leaking (or the battery emits a bad odor),
immediately remove it from flammable areas. Electrolyte
leaking from battery can easily catch on fire and may cause the
battery to generate smoke or burst into flame.
• Do not use an abnormal battery!
If the battery pack emits a bad odor, appears to have different
coloring, is deformed, or seems abnormal for any other reason,
remove it from the charger or operating equipment and do not
use it. The battery may generate heat or smoke, rupture, or
burst into flame.
• Do not reverse-charge or reverse-connect the battery!
The battery pack has positive and negative poles. If the battery
pack does not smoothly connect with a charger or operating
equipment, do not force it; check the polarity of the battery. If
the battery pack is reverse-connected to the charger, it will be
reverse-charged and an abnormal chemical reaction may occur.
The battery may generate heat or smoke, rupture, or burst into
flame.
• Do not touch a ruptured and leaking battery!
If the electrolyte liquid from the battery gets into your eyes,
wash your eyes out with fresh water as soon as possible,
without rubbing your eyes. Go to the hospital immediately. If
left untreated, it may cause eye-problems.

6
■USING THE LI-ION BATTERY PACK
• Charge the battery pack before using it.
• To keep the battery discharge at a minimum, remove the
battery pack from the equipment when it is not in use. Store
the battery pack in a cool and dry location.
• When storing the battery pack for a long period:
1Remove the battery pack from the equipment.
2Discharge the battery pack, if possible.
3Store the battery pack in a cool (below 25°C) and dry
location.
■CHARACTERISTICS OF THE LI-ION BATTERY PACK
• As the battery pack is charged and discharged repeatedly, the
battery capacity decreases.
• Even if the battery pack is unused, the battery pack degrades.
• It takes a longer time to charge the battery pack in cooler
areas.
• The life of battery pack is shortened when it is charged and
discharged in hotter areas. When the battery pack is stored in
a hot location, the battery pack degrades quicker. Do not leave
the battery pack in vehicles or near heating appliances.
• When the battery pack operating time becomes short, even
if it is fully charged, replace the battery pack. Continuing to
charge and discharge the battery pack may result in electrolyte
leakage.

7
INSTALLING/ REMOVING THE (OPTIONAL) BATTERY PACK
1Match the guides of the battery
pack with the corresponding
grooves on the upper rear of
the transceiver, then firmly
press the battery pack to lock it
in place.
2Lock the safety catch to
prevent accidentally pressing
the release latch and removing
the battery pack.
3To remove the battery pack,
lift the safety catch, press the
release latch, then pull the
battery pack away from the
transceiver.
Note:
◆To lift the battery pack safety catch, use a piece of hardened
plastic or metal, such as a screwdriver, that is no more than
6 mm wide and 1 mm thick. It is imperative that you place the
implement under only the lip of the safety catch so that you do
not damage the release latch.
◆Before charging a battery pack that is attached to the
transceiver, ensure that the safety catch is firmly closed.
◆While operating the transceiver using a Li-ion or Ni-MH battery
pack in areas with an ambient temperature of –10°C and lower,
operating time may be shortened.

8
Screw the antenna into the
connector on the top of the
transceiver by holding the antenna
at its base and turning it clockwise
until secure.
Note: The antenna is neither a
handle, a key ring retainer, nor a
speaker/ microphone attachment
point. Using the antenna in these
ways may damage the antenna
and degrade your transceiver’s
performance.
INSTALLING THE BELT CLIP
If necessary, attach the belt clip
using the two supplied
3 x 8 mm screws.
Note: If the belt clip is not installed,
its mounting location may get hot
during continuous transmission
or when left sitting in a hot
environment.
INSTALLING THE (OPTIONAL) ANTENNA
Do not use glue which is designed to prevent screw loosening when
installing the belt clip, as it may cause damage to the transceiver.
Acrylic ester, which is contained in these glues, may crack the
transceiver’s back panel.
SABC
1
2
MIC
<>

9
If you are not using an optional
speaker/ microphone or headset,
install the cap over the universal
connector using the supplied
4 x 6 mm screw. Ensure that the
cap fits tightly over the connector.
INSTALLING THE CAP OVER THE UNIVERSAL CONNECTOR
INSTALLING THE (OPTIONAL) SPEAKER/ MICROPHONE OR HEADSET
SABC
12
ABC
5
JKL
8
0
TUV
4
GHI
7
PQRS
3
DEF
6
MNO
MIC
9
#
WXYZ
<>
1 Insert the guide of the
speaker/ microphone
connector into the
groove of the universal
connector.
2Secure the connector in
place using the attached
screw.
Note: When not using
an optional speaker/
microphone or headset,
install the cap over the
universal connector.
SABC
1
2
MIC
<>

10
GETTING ACQUAINTED
SABC
12
ABC
5
JKL
8
0
TUV
4
GHI
7
PQRS
3
DEF
6
MNO
MIC
9
#
WXYZ
<>
Haut-parleurMicrophone
qAntenna connector
Connect an antenna here {page 8}.
wSelector
Rotate to activate its programmable function {page 14}.

11
ePower switch/ Volume control
Turn clockwise to switch ON the transceiver. Rotate to
adjust the volume. Turn counterclockwise fully to switch
OFF the transceiver.
rTransmit/ Busy/ Call indicator
This LED lights red during transmission, green while
receiving a call, and orange when receiving an encoded call
(i.e. 5-tone, DTMF signaling, etc.).
tAuxiliary (orange) key
Press to activate its programmable function {page 14}.
ySafety Catch
Lock this catch to avoid accidentally pressing the release
latch and removing the battery pack {page 7}.
uRelease Latch
Press the release latch to unlock and remove the battery
pack {page 7}.
iSide 1 key
Press to activate its programmable function {page 14}.
oPTT (Push-To-Talk) switch
Press this switch, then speak into the microphone to call a
station.
!0 Side 2 key
Press to activate its programmable function {page 14}.
!1 S, A, <B, and C> keys
Press to activate their programmable functions {page 14}.
!2 DTMF keypad
Press the keys on the keypad to make DTMF calls
{page 30} or to activate their programmable functions {page
14}.
!3 Universal connector
Connect a speaker/ microphone or headset here {page 9}.
Otherwise, keep the supplied cap in place.

12
DISPLAY
rotacidnI noitpircseD
.srebmunlennahcdnaenozehtsyalpsiD
lennahcdnaenozmargorpnacrelaedruoY
ecalpni,sretcarahc21otpuhtiwseman
enot-5deviecersyalpsidoslA.srebmunfo
.segassemcnySteelFdna
.srebmunlennahcdnaenozehtsyalpsiD
rotarepOrofsrebmuntsilsyalpsidoslA
.senoTelbatceleS
.slangisdeviecerfohtgnertsehtsyalpsiD
srabhtgnerts3lladnaannetnanA
annetnaehtelihwslangisgnortsstneserper
kaewstneserper)srabhtgnertson(flestiyb
.slangis
siffOhcleuqSrorotinoMnehwsraeppA
.detavitca
noitcnufdnuorAklaTehtnehwsraeppA
.detavitcaneebsah
roedomnacSgnisuerauoynehwsraeppA
eerFrognitoVasienozdetcelesehtelihw
.enozllaClennahC
.egassemaevieceruoynehwsehsalF
ehtniderotssiegassemanehwsthgiL
.yromemeueuq
