SERVICE MANUAL
UHF FM TRANSCEIVER
© 2008-8 PRINTED IN JAPAN
B51-8842-00 (N)554
TK-3102G
GENERAL.....................................................2
SYSTEM SET-UP.........................................2
REALIGNMENT ...........................................3
DISASSEMBLY FOR REPAIR ......................5
CIRCUIT DESCRIPTION ..............................6
SEMICONDUCTOR DATA.........................10
COMPONENTS DESCRIPTION.................11
PARTS LIST ...............................................12
EXPLODED VIEW ......................................19
PACKING....................................................20
ADJUSTMENT ..........................................21
CONTENTS
PC BOARD
TX-RX UNIT (X57-6030-XX) ................26
SCHEMATIC DIAGRAM ............................30
BLOCK DIAGRAM .....................................34
LEVEL DIAGRAM ......................................36
OPTIONAL ACCESSORIES
KNB-14 (Ni-Cd BATTERY)....................37
KNB-15A (Ni-Cd BATTERY) .................37
KNB-20N (Ni-MH BATTERY) ...............37
SPECIFICATIONS ...................BACK COVER
Knob (CH)
(K29-5278-03)
Knob (VOL)
(K29-5255-03)
Whip antenna
(T90-1039-25)
Plastic cabinet assy
(A02-4049-03)

TK-3102G
2
License and frequency allocated by FCC
Choose the type of transceiver
Merchandise received
Transceiver programming
Are you using the speaker microphone?
A personal computer (IBM PC or compatible), programming
interface (KPG-22/22A), USB adapter (KCT-53U), and programming
software (KPG-55D ver.4.00 or later) are required for programming.
(The frequency, and signaling data are programmed for the transceiver.)
Frequency range (MHz) RF power Type
TX/RX 450~470
TX/RX 470~490
4.0W
4.0W
TK-3102G K,M
TK-3102G K2,M2
NO
(Option)
YES KMC-17 or KMC-21
Speaker microphone
Delivery
SYSTEM SET-UP
INTRODUCTION
SCOPE OF THIS MANUAL
This manual is intended for use by experienced techni-
cians familiar with similar types of commercial grade com-
munications equipment. It contains all required service
information for the equipment and is current as of the pub-
lication date. Changes which may occur after publication
are covered by either Service Bulletins or Manual Revisions.
These are issued as required.
ORDERING REPLACEMENT PARTS
When ordering replacement parts or equipment informa-
tion, the full part identification number should be included.
This applies to all parts : components, kits, or chassis. If the
part number is not known, include the chassis or kit number
of which it is a part, and a sufficient description of the re-
quired component for proper identification.
GENERAL
PERSONAL SAFETY
The following precautions are recommended for personal
safety:
• DO NOT transmit until all RF connectors are verified se-
cure and any open connectors are properly terminated.
• SHUT OFF and DO NOT operate this equipment near
electrical blasting caps or in an explosive atmosphere.
• This equipment should be serviced by a qualified techni-
cian only.
SERVICE
This transceiver is designed for easy servicing. Refer to
the schematic diagrams, printed circuit board views, and
alignment procedures contained within.
NOTE
You must use KPG-55D version 4.00 or later for this
transceiver. KPG-55D versions earlier than version 4.00 will
not work properly.
Document Copyrights
Copyright 2008 by Kenwood Corporation. All rights re-
served.
No part of this manual may be reproduced, translated,
distributed, or transmitted in any form or by any means,
electronic, mechanical, photocopying, recording, or other-
wise, for any purpose without the prior written permission
of Kenwood.
Disclaimer
While every precaution has been taken in the preparation
of this manual, Kenwood assumes no responsibility for er-
rors or omissions. Neither is any liability assumed for dam-
ages resulting from the use of the information contained
herein. Kenwood reserves the right to make changes to any
products herein at any time for improvement purposes.

TK-3102G
3
REALIGNMENT
1. Modes
User mode
PC mode
PC test mode PC tuning mode
Data programming mode
Mode Function
User mode For normal use.
PC mode Used for communication between the trans-
ceiver and PC.
Data programming
mode
Used to read and write frequency data and
other features to and from the transceiver.
PC test mode Used to check the transceiver using the PC.
This feature is included in the FPU.
2. How to Enter Each Mode
Mode Operation
User mode Power ON
PC mode Received commands from PC
3. Getting Acquainted
4. PC Mode
4-1. Preface
The transceiver is programmed by using a personal com-
puter, a programming interface (KPG-22/22A), USB adapter
(KCT-53U) and programming software (KPG-55D (ver.4.00 or
later)).
The programming software can be used with a PC. Fig-
ure 1 shows the setup of a PC for programming.
4-2. Connection Procedure
1. Connect the transceiver to the personal computer with
the interface cable and USB adapter (when the interface
cable is KPG-22A, the KCT-53U can be used.).
Notes:
• You must install the KCT-53U driver in the computer to
use the USB adapter (KCT-53U).
• When using the USB adapter (KCT-53U) for the first time,
plug the KCT-53U into a USB port on the computer with
the computer power ON.
2. When the POWER is switched on, user mode can be en-
tered immediately. When the PC sends a command, the
transceiver enters PC mode.
When data is transmitting from the transceiver, the red
LED lights.
When data is received by the transceiver, the green LED
lights.
Notes :
• The data stored in the personal computer must match
the Model Name when it is written into the EEPROM.
• Do not press the [PTT] key during data transmission or
reception.
• Change the transceiver to PC mode, then attach the in-
terface cable.
4-3. KPG-22/KPG-22A Description
(PC programming interface cable : Option)
The KPG-22/22A is required to interface the transceiver
with the computer. It has a circuit in its D-sub connector
(KPG-22: 25-pin, KPG-22A: 9-pin) case that converts the RS-
232C logic level to the TTL level.
The KPG-22/22A connects the SP/MIC connector of the
transceiver to the RS-232C serial port of the computer.
4-4. KCT-53U Description (USB adapter : Option)
The KCT-53U is a cable which connects the KPG-22A to
a USB port on a computer.
When using the KCT-53U, install the supplied CD-ROM
(with driver software) in the computer. The KCT-53U driver
runs under Windows 2000 or XP.
Speaker
Speaker/
microphone
jacks
Microphone
Antenna
PTT (Push-To-
Talk) switch
Press, then
speak into the
microphone to
call a station.
Release to
receive.
Monitor key
Press and hold to
turn the squelch
OFF. You will
hear background
noise. Release
to turn the
squelch back ON.
LED indicator
Lights red while
transmitting.
Lights green while
receiving a signal.
Flashes red when
the battery voltage
is low while
transmitting.
Power switch/
Volume control
Turn clockwise
to switch ON the
transceiver. To
switch OFF the
transceiver, turn
counterclockwise
until a click
sounds. Rotate
to adjust the
volume level.
Channel
selector
Rotate to select
channels1 ~ 16.
Battery pack
(KNB-15A)

TK-3102G
4
REALIGNMENT
PC
KPG-22 or KPG-22A or
KPG-22A+KCT-53U
Illustration is KPG-22
KPG-55D
(ver.4.00 or later)
Tuning cable
(E30-3216-05)
D-SUB
(25-pin)
Transceiver
KPG-22
PC
Gray
Gray/Black
1.5D-XV Lead wire
1.5D-XV Shield wire
+
–
+
–
SP
MIC
D-SUB
(9-pin)
Transceiver
KPG-22A
PC
USB
Transceiver
KPG-22A
KCT-53U
PC
Fig. 1
4-5. Programming Software Description
The KPG-55D (ver.4.00 or later) is the programming
software for the transceiver supplied on a CD-ROM. This
software runs under Windows 2000, XP or Vista (32-bit) on
a PC.
4-6. Programming with PC
If data is transferred to the transceiver from a PC with
the KPG-55D (ver.4.00 or later), the data for each set can be
modified.
Data can be programmed into the EEPROM in RS-232C
format via the SP/MIC jack.
In this mode the PTT line operate as RXD data line.

TK-3102G
5
DISASSEMBLY FOR REPAIR
■Removing the case assembly from the chassis
1. Remove the two knobs q, cushion w and three round
nuts e.
2. Remove the two screws r.
3. Expand the right and left sides of the bottom of the case
assembly, then Iift and remove the chassis from the case
assembly t.
:
@
.
.
.
:
;
;
=
4. Taking care not to cut the speaker lead y, open the
chassis and case assembly.
B
■Removing the TX-RX unit from the chassis
1. Remove the eleven screws u.
2. Remove the VOL/CH FPC from the TX-RX unit connector
(CN400) i.
3. Remove the solder from the antenna terminal using a
soldering iron, then lift the unit off o.
4. Remove the waterproof packing !0 and cushion !1 from
the antenna connector.
Note: The cushion cannot be reused. Affix a new cush-
ion when you remove the cushion.
5. Remove the two screws !2 and remove the antenna con-
nector.
Note: When reassembling the unit in the chassis, be
sure to solder the antenna terminal.
CN400
Antenna
terminal
>
>
>>
>>
>
2
8




>>
■Removing the lever
1. Press down the lever on the lower case !3, insert a small
flat-head screwdriver into the space between the case
and lever, open the case carefully !4 and lift the lever off.
Note: Do not force to remove the lever from the case.
Case assembly
Lever knob



TK-3102G
6
CIRCUIT DESCRIPTION
1. Frequency Configuration
The receiver utilizes double conversion. The first IF is
38.85MHz and the second IF is 450kHz. The first local oscil-
lator signal is supplied from the PLL circuit.
The PLL circuit in the transmitter generates the neces-
sary frequencies. Fig. 1 shows the frequencies.
2. Receiver
The receiver is double conversion superheterodyne, de-
signed to operate in the frequency range of 450 to 470MHz
(K, M), 470 to 490MHz (K2, M2).
The frequency configuration is shown in Fig. 1.
1) Front-end RF Amplifier
An incoming signal from the antenna is applied to an RF
amplifier (Q203) after passing through a transmit/receive
switch circuit (D102 and D103 are off) and a 3-pole LC filter.
After the signal is amplified (Q203), the signal is filtered by
a band pass filter (a 3-pole LC filter) to eliminate unwanted
signals before it is passed to the first mixer.
The voltage of these diodes are controlled by to track the
MPU (IC403) center frequency of the band pass filter. (See
Fig. 2)
2) First Mixer
The signal from the RF amplifier is heterodyned with the
first local oscillator signal from the PLL frequency synthe-
sizer circuit at the first mixer (Q202) to create a 38.85MHz
first intermediate frequency (1st IF) signal. The first IF signal
is then fed through two monolithic crystal filters (MCFs :
XF201) to further remove spurious signals.
3) IF Amplifier
The first IF signal is amplified by Q201, and then enters
IC200 (FM processing IC). The signal is heterodyned again
with a second local oscillator signal within IC200 to create
a 450kHz second IF signal. The second IF signal is then fed
through a 450kHz ceramic filter (CF200) to further eliminate
unwanted signals before it is amplified and FM detected in
IC200.
4) AF Amplifier
The recovered AF signal obtained from IC200 is ampli-
fied by IC300 (1/4), filtered by the IC300 low-pass filter (2/4)
and IC300 high-pass filter (3/4) and (4/4), and de-emphasized
by R303 and C306. The AF signal is then passed through a
WIDE/NARROW switch (Q303). The processed AF signal
passes through an AF volume control and is amplified to a
sufficient level to drive a loud speaker by an AF power am-
plifier (IC302).
Fig. 1 Frequency configuration
Fig. 2 Receiver section configuration
ANT
ANT SW RF
AMP
MCF
CF
IF SYSTEM AF
AMP
RX
TX
PA
AMP
TX
AMP
PLL
VCO
MIC
AMP
TCXO
X3
multiply
38.85MHz
450kHz
38.4MHz
12.8MHz
SP
MIC
ANT
D102, D103
BPF
L208~L211
RF AMP
Q203
BPF
L214, L203, L204
MIXER
Q202
MCF
XF201
IF AMP
Q201
CF200
IF, MIX, DET
IC200
AF AMP
LPF, HPF
IC300
AF PA AMP
IC302
SP
X3
multiply
Q1
TCXO
1st Local OSC
(PLL)
ANT SW
WIDE/NARROW SW
Q303
APC
TUNE
IC403
MPU

TK-3102G
7
CIRCUIT DESCRIPTION
XF201:L71-0522-05
Item Rating
Nominal center frequency 38.850MHz
Pass band width ±5.0kHz or more at 3dB
40dB stop band width ±20.0kHz or less
Ripple 1.0dB or less
Insertion loss 4.0dB or less
Guaranteed attenuation 80dB or more at fo -910kHz
Terminal impedance 610Ω/ 3PF
CF200:L72-0958-05
Item Rating
Nominal center frequency 450kHz
6dB band width ±6.0kHz or more
50dB band width ±12.5kHz or less
Ripple 2.0dB or less at fo ±4kHz
Insertion loss 6.0dB or less
Guaranteed attenuation 35.0dB or more at fo ±100kHz
Terminal impedance 2.0 kΩ
5) Squelch
Part of the AF signal from the IC enters the FM IC again,
and the noise component is amplified and rectified by a filter
and an amplifier to produce a DC voltage corresponding to
the noise level.
The DC signal from the FM IC goes to the analog port of
6) Receive Signaling
QT/DQT
300 Hz and higher audio frequencies of the output signal
from IF IC are cut by a low-pass filter (IC301). The resulting
signal enters the microprocessor (IC403). IC403 determines
whether the QT or DQT matches the preset value,
and controls the MUTE and AFCO and the speaker output
sounds according to the squelch results.
3. PLL Frequency Synthesizer
The PLL circuit generates the first local oscillator signal
for reception and the RF signal for transmission.
1) PLL
The frequency step of the PLL circuit is 5 or 6.25kHz.
A 12.8MHz reference oscillator signal is divided at IC1 by
a fixed counter to produce the 5 or 6.25kHz reference fre-
quency. The voltage controlled oscillator (VCO) output signal
is buffer amplified by Q6, then divided in IC1 by a dual-mod-
ule programmable counter . The divided signal is compared
in phase with the 5 or 6.25kHz reference signal in the phase
comparator in IC1. The output signal from the phase com-
parator is filtered through a low-pass filter and passed to the
VCO to control the oscillator frequency. (See Fig.4)
the microprocessor (IC403). IC403 determines whether to
output sounds from the speaker by checking whether the
input voltage is higher or lower than the preset value.
To output sounds from the speaker, IC403 sends a high
signal to the MUTE and AFCO Iines and turns IC302 on
through Q302, Q304, Q305, Q306 and Q307.(See Fig. 3)
Fig. 3 AF amplifier and squelch
FM IF IC IC200
IF AMP DET
DET HPF
AMP
LPF
IC301
QT/DQT
Q303
W/N SW
IC403
MPU
BUSY
MUTE
AFCO
TI
6 5 67 62
AF AMP
IC300
LPF HPF
Q302
SW
IC302
AF PA AMP Q307
SW
SW
SP
Q304, 305, 306

TK-3102G
8
CIRCUIT DESCRIPTION
Fig. 4 PLL circuit
Fig. 6 Transmit audio and QT/DQT encoder
3) Unlock Detector
If a pulse signal appears at the LD pin of IC1, an unlock
condition occurs, and the DC voltage obtained from D7, R6,
and C1 causes the voltage applied to the UL pin of the mi-
croprocessor to go low. When the microprocessor detects
this condition, the transmitter is disabled, ignoring the push-
totalk switch input signal. (See Fig. 5)
4. Transmitter
1) Transmit Audio
The modulation signal from the microphone is amplified
by IC500 (1/2), passes through a pre-emphasis circuit, and
amplified by the other IC500 (1/2) to perform IDC operation.
The signal then passes through a low-pass filter (splatter
fiIter) (Q501 and Q502) and cuts 3kHz and higher frequen-
cies. The resulting signal goes to the VCO through the VCO
modulation terminal for direct FM modulation. (See Fig. 6)
Fig. 5 Unlock detector circuit
2) VCO
The operating frequency is generated by Q4 in transmit
mode and Q3 in receive mode. The oscillator frequency is
controlled by applying the VCO control voltage, obtained
from the phase comparator, to the varactor diodes (D2 and
D4 in transmit mode and D1 and D3 in receive mode). The
T/R pin is set high in receive mode causing Q5 and Q7 to
turn Q4 off, and turn Q3 on . The T/R pin is set low in trans-
mit mode. The outputs from Q3 and Q4 are amplified by Q6
and sent to the buffer amplifiers.
2) QT/DQT Encoder
A necessary signal for QT/DQT encoding is generated by
IC403 and FM-modulated to the PLL reference signal. Since
the reference OSC does not modulate the loop characteris-
tic frequency or higher, modulation is performed at the VCO
side by adjusting the balance. (See Fig. 6)
PLL DATA
12.8MHz
REF OSC
I/M
I/N
PLL IC IC1
PHASE
COMPARATOR
CHARGE
PUMP
LPF
5kHz/6.25kHz
D2, 4
D1, 3
Q4
TX VCO
Q3
RX VCO
Q6
BUFF AMP
Q2
RF AMP
Q5, 7
T/R SW
5kHz/6.25kHz
MUTE
VR501
MAX
DEV
VR500
BALANCE
X1, IC1
D5, Q4
VCO
REFERENCE
OSC
(TCXO)
MIC
IC500 (1/2)
MIC
AMP
IC500 (1/2)
IDC
Q503
SW
PRE-EMPHASIS
Q501, 502
LPF
(SPLATTER FILTER)
IC403
TO QT/DQT
IC1
LD
PLL IC
D7
C1
R6
5C
IC403
UL
MPU

TK-3102G
9
CIRCUIT DESCRIPTION
3) VCO and RF Amplifier
The transmit signal obtained from the VCO buffer ampli-
fier Q100, is amplified by Q101 and Q102. This amplified
signal is passed to the power amplifier, Q105 and Q107,
which consists of a 2-stage FET amplifier and is capable of
producing up to 4W of RF power. (See Fig. 7)
4) ANT Switch and LPF
The RF amplifier output signal is passed through a low-
pass filter network and a transmit/receive switching circuit
before it is passed to the antenna terminal. The transmit/
receive switching circuit is comprised of D101, D102 and
D103. D102 and D103 are turned on (conductive) in transmit
mode and off (isolated) in receive mode.
5) APC
The automatic power control (APC) circuit stabilizes the
transmitter output power at a predetermined level by sens-
ing the drain current of the final amplifier Field Effect Tran-
sistor (FET) . The voltage comparator, IC100 (2/2), compares
the voltage obtained from the above drain current with a
reference voltage which is set using the microprocessor.
An APC voltage proportional to the difference between the
sensed voltage and the reference voltage appears at the
output of IC100 (1/2). This output voltage controls the gate
of the FET power amplifier, which keeps the transmitter
output power constant. The transmitter output power can
be varied by the microprocessor which in turn changes the
reference voltage and hence, the output power.
6) Thermal Protection Circuit
When the thermistor (TH102) reaches about 80°C, the
protection circuit turns on Q110 to protect transmitting final
amplifier (Q107) from the over heating.
5. Power Supply
A 5V reference power supply [5M] for the control circuit
is derived from an internal battery. This reference is used
to provide a 5V supply in transmit mode [5T], a 5V supply in
receive mode [5R], and a 5V supply common in both modes
[5C] based on the control signal sent from the microproces-
sor.
6. Control System
The IC403 MPU operates at 7.37MHz . This oscillator has
a circuit that shifts the frequency according to the EEPROM
data.
Fig. 7 APC system
AMP
Q101, Q102
DRIVE AMP
Q105
5T
B
Q103,104
B SW
DET
IC100
APC
5T
Q109
SW
Q106
SW
APC
5T
Q108
SW
RX
D102,103
ANT SW
FINAL AMP
Q107
ANT SW
D101
LPF
ANT
5T
SW
Q110
TH102

TK-3102G
10
SEMICONDUCTOR DATA
Microprocessor: 38268MCA060GU (TX-RX unit IC403)
Pin No. Port Name I/O Function
1,2 VC1,VC2 O NC
3NC INC
4 TIBI I QT/DQT external circuit center point
input
5 TI I QT/DQT signal input
6 BUSY I Busy input
7 BATT l Battery voltage detection
8NC lNC
9 VCCN O Frequency regulation output
10 APC O TX : Auto power control D/A output
RX : BPF tuning D/A output
11~14 NC I NC
15 BEEP O Beep output
16 TO O QT/DQT output
17 NC l NC
18 PTT I [PTT] key input connected to RXD
19 TXD O RS-232C output connected to SP/
MIC test (REM)
20 RXD I RS-232C input connected to [PTT]
line
21 NC l NC
22 SELF l Self program L : disable
23 MONl I [MONl] key input
24~27 NC I NC
28~31 ENC3~ENC0 l Encode input (channel select)
32 INT0 l Power detection control
33 RST I Reset input
34 NC I NC
35 NC O NC
36 XIN l 7.3728MHz oscillator
37 XOUT O 7.3728MHz oscillator
38 VSS I GND
39 SHIFT O Beat shift H : shift on
40 PABC O Final supply H : on
41 WNRC O
Audio reference sensitivity L : narrow
42 WNTC O MAX Dev. control Narrow: H
43~46 NC l NC
47 SDA l/O EEPROM data line
48 SCL O EEPROM clock line
49 UL I PLL unlock detection pin L : unlock
50~54 NC l NC
55 DT O Common data output
56 CK O Common clock output
57 NC O NC
58 LE O PLL IC enable H : latches
59,60 NC O NC
Pin No. Port Name I/O Function
61 5MC O
Control of power supply (5M) for
everything except the
microprocessor and EEPROM
L : Power supply ON
62 AFCO O AF amp power suppIy H : ON
63 RX O TX/RX VCO select H : RX
64 GLED O Green LED control H : Lit
65 RLED O Red LED control H : Lit
66 SAVE O Save control H : Save off
67 MUTE O Mute control
H : MIC mute, L : AF mute
68 5RC O Reception power suppIy control
L : on
69 5TC O Transmission power suppIy control
H : on
70~88 NC O NC
89 VCC l
Microprocessor power supply,5V input
90 VREF l A/D conversion reference voltage ;
connected to Vcc
91 AVSS l A/D converter power supply ; con-
nected to Vss
92~95 NC O NC
96~100 NC I NC
FET : 2SK2596-E (Q105)
FET : 2SK2595-E (Q107)
Absolute Maximum Ratings (Ta=25°C)
Item VDSS VGSS IDPch* Tch Tstg
Rating 17V ±10V 0.4A 3W 150°C -45~+150°C
*Tc=25°C
Absolute Maximum Ratings (Ta=25°C)
Item VDSS VGSS IDPch* Tch Tstg
Rating 17V ±10V 1.1A 20W 150°C -45~+150°C
*Tc=25°C

TK-3102G
11
COMPONENTS DESCRIPTION
Ref. No. Part Name Description
IC1 IC Phase locked loop system
IC100 IC Automatic power control
IC200 IC IF system
IC300 IC Audio amp active filter
IC301 IC Active filter
IC302 IC Audio power AMP
IC400 IC Reset switch
IC401 IC EEPROM
IC402 IC Voltage detect
IC403 IC Microprocessor
IC404 IC Voltage regulator
IC500 IC MIC AMP/Limiter
Q1 Transistor Tripler
Q2 Transistor RF AMP
Q3 FET VCO RX
Q4 Transistor VCO TX
Q5 FET DC switch
Q6 Transistor RF buffer AMP
Q7 Transistor DC switch
Q8 Transistor Ripple filter
Q100 Transistor RF AMP
Q101 Transistor TX pre-drive
Q102 Transistor TX drive
Q103 FET DC switch
Q104 Transistor DC switch
Q105 FET TX drive
Q106 FET DC switch
Q107 FET TX final
Q108,109 Transistor DC switch
Q110 Transistor Temperature protection
switch
Q200 Transistor DC switch
Q201 Transistor IF AMP
Q202 FET Mixer
Q203 FET Mixer RF AMP
Q300 Transistor Active filter
Q302 FET Audio mute switch
Q303~306 Transistor DC switch
Q307 FET Audio mute switch
Q400~402 Transistor DC switch
Q403 Transistor Beat shift switch
Q404 Transistor DC switch
Q405 FET DC switch
Q406~408 Transistor DC switch
Q500 FET DC switch
Ref. No. Part Name Description
Q501,502 Transistor Active filter
Q503 Transistor MIC mute/ AGC
Q504 Transistor DC switch
D1~4 Variable capacitance
diode Frequency control
D5 Variable capacitance
diode TX modulation
D6 Diode Current steering
D7 Diode Unlock detect
D100 Diode RF switch
D101~103 Diode Antenna switch
D200 Diode RF switch
D201~204 Variable capacitance
diode BPF tuning
D300 Diode Limiter
D400 LED TX
D401 LED Busy
D500 Diode AGC detect
D501 Diode MIC mute/AGC switch
D502 Diode Reverse protection
TX-RX unit (X57-6030-XX)

TK-3102G
12
Chip capacitor
Code L W T
Empty 5.6±0.5 5.0±0.5 Less than 2.0
A 4.5±0.5 3.2±0.4 Less than 2.0
B 4.5±0.5 2.0±0.3 Less than 2.0
C 4.5±0.5 1.25±0.2 Less than 1.25
D 3.2±0.4 2.5±0.3 Less than 1.5
E 3.2±0.2 1.6±0.2 Less than 1.25
F 2.0±0.3 1.25±0.2 Less than 1.25
G 1.6±0.2 0.8±0.2 Less than 1.0
H 1.0±0.05 0.5±0.05 0.5±0.05
Chip resistor
Code L W T
E 3.2±0.2 1.6±0.2 1.0
F 2.0±0.3 1.25±0.2 1.0
G 1.6±0.2 0.8±0.2 0.5±0.1
H 1.0±0.05 0.5±0.05 0.35±0.05
s2ATINGWATTAGE
Code Wattage Code Wattage Code Wattage
1J 1/16W 2C 1/6W 3A 1W
2A 1/10W 2E 1/4W 3D 2W
2B 1/8W 2H 1/2W
,ESSTHANP&
Code B C D F G
(pF) ±0.1 ±0.25 ±0.5 ±1 ±2
#!0!#)4/23
C C 4 5 T H 1 H 2 2 0 J
1 2 3 4 5 6
1 = Type ... ceramic, electrolytic, etc. 4 = Voltage rating
2 = Shape ... round, square, etc. 5 = Value
3 = Temp. coefficient 6 = Tolerance
s4EMPERATURECOEFFICIENT
1st Word C L P R S T U
Color* Black Red Orange Yellow Green Blue Violet
ppm/°C 0 –80 –150 –220 –330 –470 –750
s4OLERANCE-ORETHANP&
Code C D G J K M X Z P No code
(%) ±0.25 ±0.5 ±2 ±5 ±10 ±20 +40 +80 +100 More than 10μF : –10~+50
–20 –20 –0 Less than 4.7μF : –10~+75
s6OLTAGERATING
2nd word A B C D E F G H J K V
1st word
0 1.0 1.25 1.6 2.0 2.5 3.15 4.0 5.0 6.3 8.0 –
1 10 12.5 16 20 25 31.5 40 50 63 80 35
2 100 125 160 200 250 315 400 500 630 800 –
3 1000 1250 1600 2000 2500 2150 4000 5000 6300 8000 –
s#HIPCAPACITORS
(EX) C C 7 3 F S L 1 H 0 0 0 J Refer to the table above.
1 2 3 4 5 6 7 1 = Type
(Chip) (CH, RH, UJ, SL) 2 = Shape
3 = Dimension
(EX) C K 7 3 F F 1 H 0 0 0 Z 4 = Temp. coefficient
1 2 3 4 5 6 7 5 = Voltage rating
(Chip) (B, F) 6 = Value
7 = Tolerance
2%3)34/23
s#HIPRESISTOR#ARBON
(EX) R D 7 3 E B 2 B 0 0 0 J
1 2 3 4 5 6 7
(Chip) (B, F)
s#ARBONRESISTOR.ORMALTYPE
(EX) R D 1 4 B B 2 C 0 0 0 J
1 2 3 4 5 6 7
1 = Type 5 = Rating wattage
2 = Shape 6 = Value
3 = Dimension 7 = Tolerance
4 = Temp. coefficient
CC45 Color*
2nd Word G H J K L
ppm/°C ±30 ±60 ±120 ±250 ±500
Example : CC45TH = –470±60ppm/°C
s#APACITORVALUE
010 = 1pF 2 2 0 = 22pF
100 = 10pF
101 = 100pF Multiplier
102 = 1000pF = 0.001μF 2nd number
103 = 0.01μF 1st number
L
W
T
s$IMENSION
PARTS LIST

TK-3102G
✽New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L: Scandinavia K: USA P: Canada
Y: PX (Far East, Hawaii) T: England E: Europe
Y: AAFES (Europe) X: Australia M: Other Areas
13
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
PARTS LIST
TK-3102G (Y50-6420-XX)
TX-RX UNIT (X57-6030-XX)
1 1A
✽A02-4049-03 PLASTIC CABINET ASSY
2 3B A82-0034-03 REAR PANEL
4 2D B09-0351-03 CAP (SP/MIC) ACCESSORY
5 1D
✽B62-2103-00 INSTRUCTION MANUAL
7 2B E04-0449-05 RF COAXIAL RECEPTACLE (SMA)
8 3B E23-1183-04 RELAY TERMINAL (BATT-)
9 1A G01-0881-04 COIL SPRING (BATT RELEASE)
10 3B G10-1288-04 FIBROUS SHEET (CHASSIS)
11 - G11-2583-04 SHEET (HOLDER)
12 3B
✽G11-2588-14 RUBBER SHEET (CHASSIS)
13 1B
✽G11-4478-04 SHEET (CH)
15 3B G13-1709-04 CUSHION (VOL)
16 3B G13-1763-04 CUSHION (TERMINAL BATT+)
17 3B G13-1867-14 CUSHION (TERMINAL BATT-)
18 2B G13-1959-04 CUSHION (RECEPTACLE)
19 2A G13-1985-04 CUSHION (X400)
21 2B G13-1986-04 CUSHION (VR501)
22 3B G13-2069-24 CUSHION (HOLDER)
23 2B G53-0791-03 PACKING (SP/MIC)
24 2A G53-0842-13 PACKING (SP)
25 2B G53-0860-04 PACKING (CHASSIS)
27 2B G53-1528-04 PACKING (SMA)
30 1D H25-0085-04 PROTECTION BAG (100/200/0.07)
31 2D H25-2012-04 PROTECTION BAG (75/100/0.08)
33 1A J19-1572-04 HOLDER (BATT RELEASE)
34 2B J19-5344-13 HOLDER (VOL/CH)
35 2D J21-4493-04 SP/MIC HOLDER ACCESSORY
36 2D J29-0734-05 BELT CLIP ACCESSORY
37 1B J69-0345-04 RING (VOL,CH)
39 2B J82-0059-15 FPC
41 1B K29-5255-03 KNOB (VOL)
42 1A K29-5274-03 BUTTON KNOB (MONI)
43 1A K29-5275-23 BUTTON KNOB (PTT)
44 1B K29-5278-03 KNOB (CH)
45 1A K29-5337-03 LEVER KNOB (BATT RELEASE)
A 2B N09-2438-05 BINDING HEAD SCREW (SMA)
B 1B
✽N14-0581-44 CIRCULAR NUT (VOL,CH)
C 1B
✽N14-0804-24 CIRCULAR NUT (SMA)
D 3A N30-2606-48 PAN HEAD MACHINE SCREW
E 3B N79-2030-48 PAN HEAD TAPTITE SCREW
F 2A,2B N83-2005-48 PAN HEAD TAPTITE SCREW
47 2D N99-0396-15 SCREW SET ACCESSORY
49 2B R31-0647-05 VARIABLE RESISTOR
51 2B S60-0424-25 ROTARY SWITCH
53 1A T07-0369-15 SPEAKER
54 2D T90-1039-25 WHIP ANTENNA ACCESSORY
56 1C
✽W08-0479-25 AC ADAPTER (AC 120V) ACCESSORY K,K2
58 1C W08-0558-35 AC ADAPTER (AC 230V) ACCESSORY M,M2
59 1C
✽W08-0598-15 CHARGER ACCESSORY
60 2C W09-0940-25 BATTERY ASSY ACCESSORY
D400 B30-2156-05 LED (RED)
D401 B30-2157-05 LED (YELLOW)
C1 CK73GB1C104K CHIP C 0.10UF K
C2,3 CC73GCH1H101J CHIP C 100PF J
C4 CK73GB1C104K CHIP C 0.10UF K
C5 CS77AA0J4R7M CHIP TNTL 4.7UF 6.3WV
C6 CC73GCH1H101J CHIP C 100PF J
C7 CK73GB1H471K CHIP C 470PF K
C9 CC73GCH1H130J CHIP C 13PF J
C10 CC73GCH1H470J CHIP C 47PF J
C12 CS77CA1V0R1M CHIP TNTL 0.1UF 35WV
C14 CC73GCH1H130J CHIP C 13PF J
C15 CS77CA1C010M CHIP TNTL 1.0UF 16WV
C16 CC73GCH1H680J CHIP C 68PF J
C17 CK73GB1H331K CHIP C 330PF K
C18 CS77CA1V0R1M CHIP TNTL 0.1UF 35WV
C19,20 CK73GB1H103K CHIP C 0.010UF K
C23 CS77AA0J100M CHIP TNTL 10UF 6.3WV
C24 CK73GB1H103K CHIP C 0.010UF K
C25 CK73GB1H471K CHIP C 470PF K
C26 CC73GCH1H121J CHIP C 120PF J
C27 CK73GB1H471K CHIP C 470PF K
C28 CC73GCH1H330J CHIP C 33PF J
C29 CC73GCH1H020C CHIP C 2.0PF C
C30 CK73GB1H102K CHIP C 1000PF K
C31 CC73GCH1H101J CHIP C 100PF J
C34 CC73GCH1H180J CHIP C 18PF J K,M
C34 CC73GCH1H330J CHIP C 33PF J K2,M2
C35 CC73GCH1H060B CHIP C 6.0PF B K2,M2
C35 CC73GCH1H070B CHIP C 7.0PF B K,M
C36 CC73GCH1H080B CHIP C 8.0PF B
C37 CC73GCH1H150J CHIP C 15PF J K2,M2
C37 CC73GCH1H330J CHIP C 33PF J K,M
C38 CC73GCH1H020B CHIP C 2.0PF B K2,M2
C38 CC73GCH1H050C CHIP C 5.0PF C K,M
C39 CC73GCH1H080B CHIP C 8.0PF B K2,M2
C39 CC73GCH1H080D CHIP C 8.0PF D K,M
C40 CC73GCH1H0R5B CHIP C 0.5PF B
C41 CC73GCH1H040B CHIP C 4.0PF B K,M
C41 CC73GCH1H050B CHIP C 5.0PF B K2,M2
C42 CC73GCH1H100D CHIP C 10PF D K,M
C42 CC73GCH1H130J CHIP C 13PF J K2,M2
C43 CK73GB1H102K CHIP C 1000PF K
C44 CC73GCH1H050B CHIP C 5.0PF B K2,M2
C44 CC73GCH1H060B CHIP C 6.0PF B K,M
C45 CC73GCH1H060B CHIP C 6.0PF B K2,M2
C45 CC73GCH1H100C CHIP C 10PF C K,M
C46 CK73GB1H471K CHIP C 470PF K
TK-3102G
TX-RX UNIT (X57-6030-XX) -10 : K,M -11 : K2,M2

TK-3102G
14
Ref. No. Address Parts No. Description Desti-
nation
New
parts
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-6030-XX)
C47 CC73GCH1H010B CHIP C 1.0PF B
C48 CK73GB1H471K CHIP C 470PF K
C49 CC73GCH1H0R5B CHIP C 0.5PF B
C51 CC73GCH1H680J CHIP C 68PF J
C52 CK73GB1H471K CHIP C 470PF K
C53 CC73GCH1H060D CHIP C 6.0PF D
C54 CC73GCH1H030B CHIP C 3.0PF B
C55 CK73GB1H471K CHIP C 470PF K
C56 CS77AA0J4R7M CHIP TNTL 4.7UF 6.3WV
C100 CC73GCH1H220J CHIP C 22PF J
C101-103 CK73GB1H471K CHIP C 470PF K
C104 CK73GB1C104K CHIP C 0.10UF K
C105 CC73GCH1H060D CHIP C 6.0PF D
C106,107 CK73GB1H471K CHIP C 470PF K
C108 CC73GCH1H070D CHIP C 7.0PF D
C109,110 CK73GB1H471K CHIP C 470PF K
C111 CC73GCH1H060D CHIP C 6.0PF D
C112 CK73GB1H471K CHIP C 470PF K
C113 CK73GB1C104K CHIP C 0.10UF K
C114,115 CK73GB1H471K CHIP C 470PF K
C116 CK73GB1H102K CHIP C 1000PF K
C118 CC73GCH1H270G CHIP C 27PF G K2,M2
C118 CC73GCH1H270J CHIP C 27PF J K,M
C119 CK73GB1H102K CHIP C 1000PF K
C120,121 CK73GB1H471K CHIP C 470PF K
C123 CK73GB1H102K CHIP C 1000PF K
C125 CK73GB1H471K CHIP C 470PF K
C126 CK73FB1A105K CHIP C 1.0UF K
C127 CS77AA1A6R8M CHIP TNTL 6.8UF 10WV
C128 CK73GB1H103K CHIP C 0.010UF K
C129 CK73GB1H471K CHIP C 470PF K
C130 CC73FCH1H220G CHIP C 22PF G
C131 CK73GB1C104K CHIP C 0.10UF K
C132 CK73GB1H471K CHIP C 470PF K
C134 CC73GCH1H101J CHIP C 100PF J
C135 CC73GCH1H010C CHIP C 1.0PF C
C136 CC73GCH1H060B CHIP C 6.0PF B K2,M2
C136 CC73GCH1H070B CHIP C 7.0PF B K,M
C138 CC73GCH1H101J CHIP C 100PF J
C139 CK73GB1H471K CHIP C 470PF K
C141 CK73GB1H471K CHIP C 470PF K
C142 CC73GCH1H030B CHIP C 3.0PF B
C143 CK73GB1H471K CHIP C 470PF K
C144 CC73GCH1H020B CHIP C 2.0PF B
C145 CK73GB1H471K CHIP C 470PF K
C147 CC73GCH1H010B CHIP C 1.0PF B K2,M2
C147-149 CC73GCH1H010B CHIP C 1.0PF B K,M
C149 CC73GCH1H010B CHIP C 1.0PF B K2,M2
C150 CC73GCH1H050B CHIP C 5.0PF B K,M
C150 CC73GCH1H4R5B CHIP C 4.5PF B K2,M2
C151 CC73GCH1H1R5B CHIP C 1.5PF B
C153 CC73GCH1H030B CHIP C 3.0PF B K,M
C153 CC73GCH1H2R5B CHIP C 2.5PF B K2,M2
C154 CC73GCH1H010B CHIP C 1.0PF B
C155 CC73GCH1H1R5B CHIP C 1.5PF B
C156 CK73GB1C104K CHIP C 0.10UF K
C157 CK73GB1H471K CHIP C 470PF K
C165 CK73GB1H471K CHIP C 470PF K
C200 CS77AA0J100M CHIP TNTL 10UF 6.3WV
C201 CK73GB1H103K CHIP C 0.010UF K
C202 CC73GCH1H270J CHIP C 27PF J
C203 CK73GB1H471K CHIP C 470PF K
C204 CK73GB1H472K CHIP C 4700PF K
C205,206 CC73GCH1H331J CHIP C 330PF J
C207 CK73GB1C104K CHIP C 0.10UF K
C208 CC73GCH1H270J CHIP C 27PF J
C209 CK73GB1C104K CHIP C 0.10UF K
C210 CK73GB1H103K CHIP C 0.010UF K
C211 CK73GB1C104K CHIP C 0.10UF K
C212 CC73GCH1H330J CHIP C 33PF J
C213 CK73GB1C104K CHIP C 0.10UF K
C214 CK73GB1H103K CHIP C 0.010UF K
C215 CC73GCH1H130J CHIP C 13PF J
C217 CK73HB1E103K CHIP C 0.010UF K
C218 CK73GB1H103K CHIP C 0.010UF K K2,M2
C218 CK73GB1H471K CHIP C 470PF K K,M
C219 CC73GCH1H150J CHIP C 15PF J
C220 CK73HB1E103K CHIP C 0.010UF K
C222 CC73HCH1H010B CHIP C 1.0PF B K,M
C222 CC73HCH1H030B CHIP C 3.0PF B K2,M2
C223 CC73GCH1H020C CHIP C 2.0PF C
C224 CK73GB1H471K CHIP C 470PF K
C226 CC73GCH1H0R3B CHIP C 0.3PF B
C227 CC73GCH1H070B CHIP C 7.0PF B K2,M2
C227 CC73GCH1H100C CHIP C 10PF C K,M
C228 CC73GCH1H080B CHIP C 8.0PF B K2,M2
C228 CC73GCH1H270J CHIP C 27PF J K,M
C229 CK73GB1H471K CHIP C 470PF K
C231,232 CK73GB1H471K CHIP C 470PF K
C233,234 CC73GCH1H0R3B CHIP C 0.3PF B
C235 CC73GCH1H040B CHIP C 4.0PF B K2,M2
C235 CC73GCH1H3R5B CHIP C 3.5PF B K,M
C236 CC73GCH1H0R3B CHIP C 0.3PF B K,M
C237 CK73GB1H471K CHIP C 470PF K
C238 CC73GCH1H0R3B CHIP C 0.3PF B
C239 CC73GCH1H020B CHIP C 2.0PF B K2,M2
C239 CC73GCH1H040B CHIP C 4.0PF B K,M
C241 CC73GCH1H060B CHIP C 6.0PF B K,M
C241 CC73GCH1H2R5B CHIP C 2.5PF B K2,M2
C252 CC73GCH1H3R5B CHIP C 3.5PF B K2,M2
C252 CC73GCH1H4R5B CHIP C 4.5PF B K,M
C253,254 CK73GB1H471K CHIP C 470PF K
C255 CC73GCH1H3R5B CHIP C 3.5PF B K2,M2
C255 CC73GCH1H4R5B CHIP C 4.5PF B K,M
C256 CK73GB1C104K CHIP C 0.10UF K
C257 CK73GB1H471K CHIP C 470PF K
C258 CK73GB1C104K CHIP C 0.10UF K
C259 CC73GCH1H030B CHIP C 3.0PF B K,M
C259 CC73GCH1H040B CHIP C 4.0PF B K2,M2
C260 CC73GCH1H030B CHIP C 3.0PF B K2,M2
C260 CC73GCH1H2R5B CHIP C 2.5PF B K,M
C261 CK73HB1A104K CHIP C 0.10UF K
C262 CK73GB1C104K CHIP C 0.10UF K
C263,264 CC73HCH1H220J CHIP C 22PF J
C265 CC73HCH1H470J CHIP C 47PF J K2,M2
C265 CK73HB1H471K CHIP C 470PF K K,M
C267 CC73HCH1H470J CHIP C 47PF J
C300 CK73GB1H822K CHIP C 8200PF K
C301 CK73GB1E183K CHIP C 0.018UF K
C302,303 CK73GB1C104K CHIP C 0.10UF K

TK-3102G
15
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-6030-XX)
C304 CS77AA0J100M CHIP TNTL 10UF 6.3WV
C305 CK73GB1H103J CHIP C 0.010UF J
C306 CK73GB1C473K CHIP C 0.047UF K
C307 CS77AA0J100M CHIP TNTL 10UF 6.3WV
C308 CK73GB1H562K CHIP C 5600PF K
C309 CK73GB1H103J CHIP C 0.010UF J
C311 CS77AA0J100M CHIP TNTL 10UF 6.3WV
C312 CK73GB1H103J CHIP C 0.010UF J
C313 CK73FB1A105K CHIP C 1.0UF K
C314 CK73GB1H102K CHIP C 1000PF K
C316 CK73GB1H103J CHIP C 0.010UF J
C318 CK73GB1C333J CHIP C 0.033UF J
C319 CK73GB1C473J CHIP C 0.047UF J
C320,321 CK73GB1C333J CHIP C 0.033UF J
C322 CK73FB1E104K CHIP C 0.10UF K
C327 CK73GB1C104K CHIP C 0.10UF K
C330 CC73GCH1H101J CHIP C 100PF J
C331 CK73FB1C474K CHIP C 0.47UF K
C332 CS77AA0J100M CHIP TNTL 10UF 6.3WV
C333 CK73GB1A474K CHIP C 0.47UF K
C334 CC73GCH1H221J CHIP C 220PF J
C335 CK73GB1C473K CHIP C 0.047UF K
C336 CK73GB1H103K CHIP C 0.010UF K
C337 CS77CC0J101M CHIP TNTL 100UF 6.3WV
C338 CC73GCH1H560J CHIP C 56PF J
C400 CK73GB1C104K CHIP C 0.10UF K
C402-404 CK73GB1H471K CHIP C 470PF K
C406 CK73GB1H471K CHIP C 470PF K
C407 CK73GB1H102K CHIP C 1000PF K
C408 CS77AA0J100M CHIP TNTL 10UF 6.3WV
C409 CC73GCH1H030B CHIP C 3.0PF B
C410,411 CK73GB1H471K CHIP C 470PF K
C412 CC73GCH1H100D CHIP C 10PF D
C413 CK73GB1H102K CHIP C 1000PF K
C414 CK73GB1H471K CHIP C 470PF K
C415 CC73GCH1H100D CHIP C 10PF D
C416 CK73GB1H471K CHIP C 470PF K
C417 CK73EF1C105Z CHIP C 1.0UF Z
C418 CK73GB1H103K CHIP C 0.010UF K
C420,421 CK73GB1H103K CHIP C 0.010UF K
C422 CK73HB1E103K CHIP C 0.010UF K
C423 CK73GB1C104K CHIP C 0.10UF K K2,M2
C423 CK73GB1C333K CHIP C 0.033UF K K,M
C424 CK73FB1A105K CHIP C 1.0UF K
C425 CK73HB1E103K CHIP C 0.010UF K
C427 CK73GB1H471K CHIP C 470PF K
C429,430 CK73FB1A105K CHIP C 1.0UF K
C500,501 CK73GB1C273K CHIP C 0.027UF K
C502 CK73GB1H392K CHIP C 3900PF K
C503 CK73GB1C333K CHIP C 0.033UF K
C504 CS77AA0J4R7M CHIP TNTL 4.7UF 6.3WV
C505 CK73FB1A105K CHIP C 1.0UF K
C506 CK73GB1H471K CHIP C 470PF K
C507 CS77CP0G2R2M CHIP TNTL 2.2UF 4WV
C508 CK73GB1H103K CHIP C 0.010UF K
C509 CK73GB1H332K CHIP C 3300PF K
C510 CC73GCH1E681J CHIP C 680PF J
C511 CK73GB1C473K CHIP C 0.047UF K
C512 CK73GB1H332K CHIP C 3300PF K
C513 CC73GCH1E681J CHIP C 680PF J
C514 CK73GB1C473K CHIP C 0.047UF K
C515 CK73GB1H103K CHIP C 0.010UF K
C516 CC73GCH1H100D CHIP C 10PF D
C517 CK73GB1H471K CHIP C 470PF K
C518 CK73GB1E223J CHIP C 0.022UF J
C519 CS77AA0J4R7M CHIP TNTL 4.7UF 6.3WV
C520 CK73GB1E223J CHIP C 0.022UF J
C521 CK73GB1H102K CHIP C 1000PF K
C522 CK73FB1E104K CHIP C 0.10UF K
C523 CS77CP0G2R2M CHIP TNTL 2.2UF 4WV
C524 CK73GB1C273K CHIP C 0.027UF K
C525 CK73GB1C104K CHIP C 0.10UF K
C526 CK73GB1H471K CHIP C 470PF K
C527 CS77AA0J100M CHIP TNTL 10UF 6.3WV
C528 CK73GB1H471K CHIP C 470PF K
C529 CK73FB1H471K CHIP C 470PF K
C530 CC73HCH1H221J CHIP C 220PF J
C531 CC73GCH1H221J CHIP C 220PF J
C532 CK73GB1H471K CHIP C 470PF K
TC1 C05-0383-05 CERAMIC TRIMMER CAPACITOR (6PF)
TC2 C05-0384-05
CERAMIC TRIMMER CAPACITOR (10PF)
TC201 C05-0383-05 CERAMIC TRIMMER CAPACITOR (6PF)
TC202,203 C05-0369-05 CERAMIC TRIMMER CAPACITOR (6PF)
101 2B E23-1182-04 RELAY TERMINAL (BATT+)
CN400 E40-5998-15 PIN ASSY
J500 E11-0703-05 PHONE JACK (2.5/3.5)
F500 F53-0130-05 FUSE (3A)
F500 F53-0392-05 FUSE (3A)
102 2B G13-1867-14 CUSHION (TERMINAL BATT+)
103 2B G53-0862-04 PACKING (TERMINAL BATT+)
104 2B J19-1571-04 HOLDER (TERMINAL BATT+)
105 2B J30-1249-04 SPACER (TERMINAL BATT+)
CF200 L72-0958-05 CERAMIC FILTER
L1 L92-0140-05 CHIP FERRITE
L2
✽L41-8295-39 SMALL FIXED INDUCTOR (8.2UH)
L4 L40-4781-86 SMALL FIXED INDUCTOR (0.47UH)
L5 L40-5681-86 SMALL FIXED INDUCTOR (0.56UH)
L6 L40-1875-92 SMALL FIXED INDUCTOR (18NH)
L7 L92-0140-05 CHIP FERRITE
L8 L40-1085-92 SMALL FIXED INDUCTOR (100NH)
L9 L40-3391-86 SMALL FIXED INDUCTOR (3.3UH)
L10 L92-0140-05 CHIP FERRITE
L11 L40-3391-86 SMALL FIXED INDUCTOR (3.3UH)
L12 L40-1085-92 SMALL FIXED INDUCTOR (100NH)
L13,14 L33-0744-05 SMALL FIXED INDUCTOR
L15 L40-1085-92 SMALL FIXED INDUCTOR (100NH)
L16,17 L40-2285-38 SMALL FIXED INDUCTOR (220NH)
L18 L40-4775-92 SMALL FIXED INDUCTOR (47NH) K,M
L19 L92-0140-05 CHIP FERRITE
L20 L40-3391-86 SMALL FIXED INDUCTOR (3.3UH)
L21 L40-2275-92 SMALL FIXED INDUCTOR (22NH)
L100 L40-2275-92 SMALL FIXED INDUCTOR (22NH)
L101 L40-1875-92 SMALL FIXED INDUCTOR (18NH)
L102 L40-1575-92 SMALL FIXED INDUCTOR (15NH)
L103 L92-0140-05 CHIP FERRITE
L104 L41-1098-40 SMALL FIXED INDUCTOR (1000NH)
L105 L92-0149-05 CHIP FERRITE

TK-3102G
16
Ref. No. Address Parts No. Description Desti-
nation
New
parts
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-6030-XX)
L106 L34-4551-05 AIR-CORE COIL
L107 L92-0149-05 CHIP FERRITE
L109 L40-2285-54 SMALL FIXED INDUCTOR (220NH)
L110 L34-4547-05 AIR-CORE COIL
L112,113 L34-4547-05 AIR-CORE COIL
L114 L34-4546-05 AIR-CORE COIL
L118 L41-1092-44 SMALL FIXED INDUCTOR (1UH)
L119 L40-2263-92 SMALL FIXED INDUCTOR (2.2NH)
L200 L41-1095-39 SMALL FIXED INDUCTOR (1.0UH) K,M
L200 L41-8285-39 SMALL FIXED INDUCTOR (0.82UH) K2,M2
L202 L40-1575-92 SMALL FIXED INDUCTOR (15NH)
L203,204 L34-4546-05 AIR-CORE COIL
L206 L40-1575-92 SMALL FIXED INDUCTOR (15NH) K,M
L206 L40-1875-92 SMALL FIXED INDUCTOR (18NH) K2,M2
L207 L40-2775-92 SMALL FIXED INDUCTOR (27NH) K,M
L207 L40-3375-92 SMALL FIXED INDUCTOR (33NH) K2,M2
L208 L41-1278-14 SMALL FIXED INDUCTOR (12NH)
L209,210 L34-4546-05 AIR-CORE COIL
L211 L41-1278-14 SMALL FIXED INDUCTOR (12NH)
L212 L34-4554-05 COIL
L212 ✽L34-4850-15 COIL
L214 L34-4546-05 AIR-CORE COIL
L400 L40-2281-86 SMALL FIXED INDUCTOR (0.22UH)
L401 L92-0140-05 CHIP FERRITE
L402,403 L40-2281-86 SMALL FIXED INDUCTOR (0.22UH)
L500 L92-0140-05 CHIP FERRITE
L501,502 L92-0149-05 CHIP FERRITE
X1 L77-1877-15 TCXO
X400 ✽L77-1761-15 CRYSTAL RESONATOR (7.3728MHZ)
XF201 L71-0522-05 MCF (38.85MHZ)
106 2B
✽N78-2640-48 PAN HEAD TAPTITE SCREW
CP1 RK75GB1J102J CHIP-COM 1.0K J 1/16W
R1,2 RK73GB2A102J CHIP R 1.0K J 1/10W
R3 RK73GB2A100J CHIP R 10 J 1/10W
R4 RK73GB2A102J CHIP R 1.0K J 1/10W
R5 RK73GB2A561J CHIP R 560 J 1/10W
R6 RK73GB2A154J CHIP R 150K J 1/10W
R7 RK73GB2A561J CHIP R 560 J 1/10W
R8 RK73GB2A334J CHIP R 330K J 1/10W
R9 RK73GB2A272J CHIP R 2.7K J 1/10W
R10 RK73GB2A222J CHIP R 2.2K J 1/10W
R11 RK73GB2A473J CHIP R 47K J 1/10W
R12 RK73GB2A274J CHIP R 270K J 1/10W
R13 RK73GB2A000J CHIP R 0.0 J 1/10W K,M
R13 RK73GB2A221J CHIP R 220 J 1/10W K2,M2
R14 RK73GB2A101J CHIP R 100 J 1/10W
R15 RK73GB2A103J CHIP R 10K J 1/10W
R16 RK73GB2A473J CHIP R 47K J 1/10W
R18 RK73GB2A104J CHIP R 100K J 1/10W
R19 RK73GB2A101J CHIP R 100 J 1/10W
R20 RK73GB2A102J CHIP R 1.0K J 1/10W
R21 RK73GB2A104J CHIP R 100K J 1/10W
R22 RK73GB2A473J CHIP R 47K J 1/10W
R23 RK73GB2A682J CHIP R 6.8K J 1/10W
R24 RK73GB2A822J CHIP R 8.2K J 1/10W
R25 RK73GB2A151J CHIP R 150 J 1/10W K2,M2
R25,26 RK73GB2A101J CHIP R 100 J 1/10W K,M
R26 RK73GB2A221J CHIP R 220 J 1/10W K2,M2
R27 RK73GB2A331J CHIP R 330 J 1/10W K,M
R27 RK73GB2A471J CHIP R 470 J 1/10W K2,M2
R28 RK73GB2A220J CHIP R 22 J 1/10W K,M
R28 RK73GB2A820J CHIP R 82 J 1/10W K2,M2
R29 RK73GB2A000J CHIP R 0.0 J 1/10W
R30 RK73GB2A124J CHIP R 120K J 1/10W
R31 RK73GB2A101J CHIP R 100 J 1/10W
R32 RK73GB2A472J CHIP R 4.7K J 1/10W
R33 RK73GB2A102J CHIP R 1.0K J 1/10W
R34 RK73GB2A104J CHIP R 100K J 1/10W
R100 RK73GB2A332J CHIP R 3.3K J 1/10W
R101 RK73GB2A562J CHIP R 5.6K J 1/10W
R102 RK73GB2A271J CHIP R 270 J 1/10W
R103 RK73GB2A332J CHIP R 3.3K J 1/10W
R104 RK73GB2A100J CHIP R 10 J 1/10W
R105,106 RK73GB2A332J CHIP R 3.3K J 1/10W
R107 RK73GB2A473J CHIP R 47K J 1/10W
R108 RK73GB2A331J CHIP R 330 J 1/10W
R109 RK73GB2A220J CHIP R 22 J 1/10W
R110 RK73GB2A681J CHIP R 680 J 1/10W
R111 RK73GB2A220J CHIP R 22 J 1/10W
R112 RK73GB2A152J CHIP R 1.5K J 1/10W
R113 RK73GB2A331J CHIP R 330 J 1/10W
R115 RK73GB2A100J CHIP R 10 J 1/10W
R117 RK73GB2A124J CHIP R 120K J 1/10W
R118 RK73GB2A473J CHIP R 47K J 1/10W
R119 RK73GB2A472J CHIP R 4.7K J 1/10W
R120 RK73GB2A000J CHIP R 0.0 J 1/10W
R121 RK73GB2A470J CHIP R 47 J 1/10W
R122 RK73GB2A681J CHIP R 680 J 1/10W
R123 RK73FB2B000J CHIP R 0.0 J 1/8W
R124 RK73GB2A681J CHIP R 680 J 1/10W
R125,126 RK73GB2A473J CHIP R 47K J 1/10W
R127 RK73FB2B000J CHIP R 0.0 J 1/8W
R128 RK73GB2A470J CHIP R 47 J 1/10W
R130-132 RK73EB2ER39K CHIP R 0.39 K 1/4W
R133-138 RK73GH2A154D CHIP R 150K D 1/10W
R139 RK73GB2A271J CHIP R 270 J 1/10W
R140 RK73GB2A103J CHIP R 10K J 1/10W
R141 RK73GB2A473J CHIP R 47K J 1/10W
R142 RK73GB2A105J CHIP R 1.0M J 1/10W
R143 RK73GB2A000J CHIP R 0.0 J 1/10W
R144 RK73GB2A222J CHIP R 2.2K J 1/10W
R145 RK73GB2A184J CHIP R 180K J 1/10W
R146 RK73GB2A104J CHIP R 100K J 1/10W
R147 RK73GB2A000J CHIP R 0.0 J 1/10W
R152 RK73GB2A331J CHIP R 330 J 1/10W K2,M2
R152 RK73GB2A391J CHIP R 390 J 1/10W K,M
R153 RK73GB2A332J CHIP R 3.3K J 1/10W
R154 RK73GB2A271J CHIP R 270 J 1/10W
R200 RK73GB2A100J CHIP R 10 J 1/10W
R201 RK73GB2A102J CHIP R 1.0K J 1/10W
R202 RK73GB2A394J CHIP R 390K J 1/10W
R203,204 RK73GB2A332J CHIP R 3.3K J 1/10W
R205 RK73GB2A153J CHIP R 15K J 1/10W
R206 RK73GB2A474J CHIP R 470K J 1/10W
R207 RK73GB2A104J CHIP R 100K J 1/10W
R208 RK73GB2A684J CHIP R 680K J 1/10W
R209 RK73GB2A272J CHIP R 2.7K J 1/10W
R210 RK73GB2A471J CHIP R 470 J 1/10W
R212 RK73HB1J470J CHIP R 47 J 1/16W

TK-3102G
17
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-6030-XX)
R213 RK73GB2A000J CHIP R 0.0 J 1/10W
R214 RK73GB2A103J CHIP R 10K J 1/10W
R215 RK73HB1J151J CHIP R 150 J 1/16W K,M
R215 RK73HB1J271J CHIP R 270 J 1/16W K2,M2
R216 RK73HB1J103J CHIP R 10K J 1/16W K2,M2
R216 RK73HB1J563J CHIP R 56K J 1/16W K,M
R218 RK73GB2A101J CHIP R 100 J 1/10W
R219 RK73GB2A222J CHIP R 2.2K J 1/10W K2,M2
R219 RK73GB2A332J CHIP R 3.3K J 1/10W K,M
R220 RK73GB2A221J CHIP R 220 J 1/10W
R221 RK73GB2A104J CHIP R 100K J 1/10W
R222 RK73GB2A102J CHIP R 1.0K J 1/10W
R225 RK73GB2A000J CHIP R 0.0 J 1/10W K2,M2
R225 RK73GB2A100J CHIP R 10 J 1/10W K,M
R226 RK73HB1J561J CHIP R 560 J 1/16W
R227 RK73GB2A000J CHIP R 0.0 J 1/10W
R228 RK73GB2A104J CHIP R 100K J 1/10W
R229 RK73HB1J683J CHIP R 68K J 1/16W
R230 RK73HB1J104J CHIP R 100K J 1/16W
R231,232 RK73GB2A104J CHIP R 100K J 1/10W
R234 RK73HB1J104J CHIP R 100K J 1/16W K2,M2
R234,235 RK73HB1J104J CHIP R 100K J 1/16W K,M
R235 RK73HB1J153J CHIP R 15K J 1/16W K2,M2
R236 RK73HB1J103J CHIP R 10K J 1/16W K2,M2
R236 RK73HB1J563J CHIP R 56K J 1/16W K,M
R237 RK73GB2A104J CHIP R 100K J 1/10W K,M
R237 RK73GB2A183J CHIP R 18K J 1/10W K2,M2
R238 RK73HB1J222J CHIP R 2.2K J 1/16W
R239 RK73HB1J271J CHIP R 270 J 1/16W
R240 RK73HB1J000J CHIP R 0.0 J 1/16W
R300 RK73GH2A913D CHIP R 91K D 1/10W
R301,302 RK73GB2A562J CHIP R 5.6K J 1/10W
R303 RK73GB2A332J CHIP R 3.3K J 1/10W
R304 RK73GB2A105J CHIP R 1.0M J 1/10W
R305 RK73GB2A183J CHIP R 18K J 1/10W
R306 RK73GB2A124J CHIP R 120K J 1/10W
R307 RK73GB2A473J CHIP R 47K J 1/10W
R308 RK73GB2A103J CHIP R 10K J 1/10W
R309 RK73GB2A474J CHIP R 470K J 1/10W
R311 RK73FB2B000J CHIP R 0.0 J 1/8W
R312 RK73GB2A123J CHIP R 12K J 1/10W
R313 RK73GB2A104J CHIP R 100K J 1/10W
R314 RK73GH2A474D CHIP R 470K D 1/10W
R315 RK73GH2A394D CHIP R 390K D 1/10W
R316 RK73GB2A274J CHIP R 270K J 1/10W
R317 RK73GH2A274D CHIP R 270K D 1/10W
R318 RK73GB2A184J CHIP R 180K J 1/10W
R320 RK73GB2A473J CHIP R 47K J 1/10W
R321 RK73GB2A223J CHIP R 22K J 1/10W
R322 RK73GH2A224D CHIP R 220K D 1/10W
R323 RK73GB2A104J CHIP R 100K J 1/10W
R324 RK73GB2A562J CHIP R 5.6K J 1/10W
R325 RK73GB2A104J CHIP R 100K J 1/10W
R326 RK73GH2A562D CHIP R 5.6K D 1/10W
R327 RK73GB2A000J CHIP R 0.0 J 1/10W
R328 RK73GB2A102J CHIP R 1.0K J 1/10W
R329 RK73GB2A000J CHIP R 0.0 J 1/10W
R330 RK73GB2A473J CHIP R 47K J 1/10W
R331 RK73GB2A222J CHIP R 2.2K J 1/10W
R332 RK73GB2A151J CHIP R 150 J 1/10W
R333 RK73GB2A474J CHIP R 470K J 1/10W
R334 RK73GB2A100J CHIP R 10 J 1/10W K,M
R334 RK73GB2A150J CHIP R 15 J 1/10W K2,M2
R335 RK73GB2A563J CHIP R 56K J 1/10W
R336 RK73GB2A333J CHIP R 33K J 1/10W
R338 RK73GB2A473J CHIP R 47K J 1/10W
R339 RK73GB2A822J CHIP R 8.2K J 1/10W
R340 RK73GH2A124D CHIP R 120K D 1/10W
R341 RK73GB2A104J CHIP R 100K J 1/10W
R342 RK73GB2A472J CHIP R 4.7K J 1/10W
R400 RK73GB2A334J CHIP R 330K J 1/10W
R401 RK73GB2A104J CHIP R 100K J 1/10W
R402 RK73GB2A221J CHIP R 220 J 1/10W
R403 RK73GB2A181J CHIP R 180 J 1/10W
R404 RK73GB2A000J CHIP R 0.0 J 1/10W
R405 RK73GB2A102J CHIP R 1.0K J 1/10W
R406 RK73GB2A222J CHIP R 2.2K J 1/10W
R407 RK73GB2A102J CHIP R 1.0K J 1/10W
R408 RK73GB2A104J CHIP R 100K J 1/10W
R409 RK73GB2A102J CHIP R 1.0K J 1/10W
R410 RK73GB2A822J CHIP R 8.2K J 1/10W
R411 RK73GB2A224J CHIP R 220K J 1/10W
R412 RK73GB2A100J CHIP R 10 J 1/10W
R413 RK73GB2A102J CHIP R 1.0K J 1/10W
R414,415 RK73GB2A473J CHIP R 47K J 1/10W
R416 RK73GB2A472J CHIP R 4.7K J 1/10W
R417 RK73GB2A100J CHIP R 10 J 1/10W
R418 RK73GB2A222J CHIP R 2.2K J 1/10W
R419 RK73GB2A000J CHIP R 0.0 J 1/10W
R420 RK73GB2A102J CHIP R 1.0K J 1/10W
R421 RK73HB1J473J CHIP R 47K J 1/16W
R422 RK73GB2A272J CHIP R 2.7K J 1/10W
R423 RK73HB1J473J CHIP R 47K J 1/16W
R424,425 RK73GB2A332J CHIP R 3.3K J 1/10W
R426 RK73GB2A822J CHIP R 8.2K J 1/10W
R427 RK73GB2A102J CHIP R 1.0K J 1/10W
R428 RK73GB2A272J CHIP R 2.7K J 1/10W
R429 RK73GB2A821J CHIP R 820 J 1/10W
R430 RK73HB1J101J CHIP R 100 J 1/16W
R431 RK73HB1J000J CHIP R 0.0 J 1/16W
R432 RK73GB2A103J CHIP R 10K J 1/10W
R433,434 RK73GB2A153J CHIP R 15K J 1/10W
R435 RK73GB2A103J CHIP R 10K J 1/10W
R500,501 RK73GB2A472J CHIP R 4.7K J 1/10W
R502 RK73GB2A823J CHIP R 82K J 1/10W
R503 RK73GB2A183J CHIP R 18K J 1/10W K2,M2
R503 RK73GB2A683J CHIP R 68K J 1/10W K,M
R504 RK73GB2A333J CHIP R 33K J 1/10W
R505 RK73GB2A154J CHIP R 150K J 1/10W
R506 RK73GB2A223J CHIP R 22K J 1/10W
R507 RK73GB2A473J CHIP R 47K J 1/10W
R508 RK73GB2A222J CHIP R 2.2K J 1/10W K2,M2
R508 RK73GB2A562J CHIP R 5.6K J 1/10W K,M
R509 RK73GB2A124J CHIP R 120K J 1/10W
R510 RK73GB2A332J CHIP R 3.3K J 1/10W
R511 RK73GB2A103J CHIP R 10K J 1/10W
R512 RK73GB2A185J CHIP R 1.8M J 1/10W
R513-515 RK73GB2A333J CHIP R 33K J 1/10W
R516 RK73GB2A103J CHIP R 10K J 1/10W
R517 RK73GB2A185J CHIP R 1.8M J 1/10W

TK-3102G
18
Ref. No. Address Parts No. Description Desti-
nation
New
parts
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-6030-XX)
R518 RK73GB2A682J CHIP R 6.8K J 1/10W
R519,520 RK73GB2A333J CHIP R 33K J 1/10W
R521 RK73GB2A332J CHIP R 3.3K J 1/10W
R522 RK73GB2A182J CHIP R 1.8K J 1/10W
R523 RK73GB2A682J CHIP R 6.8K J 1/10W
R524 RK73GB2A513J CHIP R 51K J 1/10W
R525 RK73GB2A152J CHIP R 1.5K J 1/10W
R526,527 RK73GH2A153D CHIP R 15K D 1/10W
R528 RK73GB2A754J CHIP R 750K J 1/10W
R529 RK73GB2A183J CHIP R 18K J 1/10W
R530 RK73GB2A101J CHIP R 100 J 1/10W
R531 RK73GB2A000J CHIP R 0.0 J 1/10W
R532 RK73GB2A821J CHIP R 820 J 1/10W
R533 RK73GB2A104J CHIP R 100K J 1/10W
R534 RK73GB2A182J CHIP R 1.8K J 1/10W
R535 RK73GB2A471J CHIP R 470 J 1/10W
R536 RK73HB1J102J CHIP R 1.0K J 1/16W
R537 RK73HB1J101J CHIP R 100 J 1/16W
R538 RK73GB2A101J CHIP R 100 J 1/10W
R539 RK73HB1J000J CHIP R 0.0 J 1/16W
R540 RK73FB2B000J CHIP R 0.0 J 1/8W
R541 RK73GB2A472J CHIP R 4.7K J 1/10W
R542,543 RK73GB2A000J CHIP R 0.0 J 1/10W
R548 RK73GB2A332J CHIP R 3.3K J 1/10W
VR1 R32-0736-05 SEMI FIXED VARIABLE RESISTOR
VR500 R32-0739-05 SEMI FIXED VARIABLE RESISTOR
VR501 R32-0684-05 SEMI FIXED VARIABLE RESISTOR
S402,403 S70-0414-05 TACT SWITCH
MIC500 T91-0651-15 MIC ELEMENT
D1-4 MA2S376 VARIABLE CAPACITANCE DIODE
D5 MA360 VARIABLE CAPACITANCE DIODE K,M
D5 1SV214-F VARIABLE CAPACITANCE DIODE K2,M2
D6,7 MA2S111-F DIODE
D100 HSC277 DIODE
D101 HVU131-E DIODE
D102,103 HSC277 DIODE
D200 HSC277 DIODE
D201-204 HVC350B VARIABLE CAPACITANCE DIODE K,M
D201-204 HVC355B VARIABLE CAPACITANCE DIODE K2,M2
D300 DA221 DIODE
D500 1SS372F DIODE
D501 DAN222 DIODE
D502 GN1G DIODE
IC1 MB15A02PFV2E1 MOS-IC
IC100 NJM2904V-ZB MOS-IC
IC200 TA31136FNG MOS-IC
IC300 NJM2902V-ZB MOS-IC
IC301 NJM2904V-ZB MOS-IC
IC302 TA7368FG MOS-IC
IC400 PST9140NR MOS-IC
IC401 AT24C08A10SU18 ROM IC
IC401 CAT24WC08JI18 ROM IC
IC402 R3111N451C-F MOS-IC
IC403 ✽38268MCA060GU MICROPROCESSOR IC
IC404 XC6201P502PR MOS-IC
IC500 NJM2100V-ZB MOS-IC
Q1 2SC4649 (N,P) TRANSISTOR
Q2 2SC5108 (Y)F TRANSISTOR
Q3 2SK508NV (K52) FET
Q4 2SC4228 (R44) TRANSISTOR
Q5 2SJ243-A FET
Q6 2SC5108 (Y)F TRANSISTOR
Q7 UMC4N TRANSISTOR
Q8 2SC4617 (S) TRANSISTOR
Q100,101 2SC5108 (Y)F TRANSISTOR
Q102 ✽2SC4988-E TRANSISTOR
Q103 2SK1824-A FET
Q104 UFMMT717 TRANSISTOR
Q105 2SK2596-E FET
Q106 2SK1824-A FET
Q107 2SK2595-E FET
Q108 DTC114EE DIGITAL TRANSISTOR
Q109 DTA144EE DIGITAL TRANSISTOR
Q110 DTC114TE DIGITAL TRANSISTOR
Q200 DTA114EE DIGITAL TRANSISTOR
Q201 2SC4649 (N,P) TRANSISTOR
Q202,203 3SK318 FET
Q300 2SC4617 (S) TRANSISTOR
Q302 2SK1824-A FET
Q303 DTA144EE DIGITAL TRANSISTOR
Q304 DTC144EE DIGITAL TRANSISTOR
Q305 2SA1362-F (GR) TRANSISTOR
Q306 DTC144EE DIGITAL TRANSISTOR
Q307 2SK1588-AZ FET
Q400,401 DTC114EE DIGITAL TRANSISTOR
Q402 DTA114YE DIGITAL TRANSISTOR
Q403 DTC144EE DIGITAL TRANSISTOR
Q404 UMG3N TRANSISTOR
Q405 UPA672T-A FET
Q406 FP210 TRANSISTOR
Q407 UMG3N TRANSISTOR
Q408 DTA123JE DIGITAL TRANSISTOR
Q500 2SK1824-A FET
Q501,502 2SC4617 (S) TRANSISTOR
Q503 2SC4919 TRANSISTOR
Q504 DTA143ZE DIGITAL TRANSISTOR
TH102 157-503-65001 THERMISTOR
TH500,501 157-302-65801 THERMISTOR

TK-3102G
19
EXPLODED VIEW
Parts with the exploded numbers larger than 700 are not supplied.
3
2
1
BA
1
42
43 37
44
41
13
9
33
45
C
B
B
704
703
Fx2
TX-RX
unit
Fx3
Fx3
A
F
A
Dx2
E
702
701
700
Fx3
953
24
23
25 39
15
10
2
16
8
17
51
49
34
7
27
18
37
A : N09-2438-05
B : N14-0581-44
C : N14-0804-24
D M2.6 x 6 : N30-2606-48
E M2 x 3 : N79-2030-48
F M2 x 5 : N83-2005-48
19
21
22
12
X57
106
X57
101
X57
105
X57
102
X57
103
X57
104

TK-3102G
20
PACKING
3
2
1
DC
56 AC adapter (AC 120V)
(W08-0479-25):K,K2
58 AC adapter (AC 230V)
(W08-0558-35):M,M2
59 Charger
(W08-0598-15)
5 Instruction manual
(B62-2103-00)
4 Cap (SP/MIC)
(B09-0351-03)
47 Screw set
(N99-0396-15)
713
54 Whip antenna
(T90-1039-25)
36 Belt clip
(J29-0734-05)
715
30 Protection bag
(H25-0085-04)
711
712
714
35 SP/MIC holder
(J21-4493-04)
60 Battery assy
(W09-0940-25)
31 Protection bag
(H25-2012-04)
Parts with the exploded numbers larger than 700 are not supplied.
