Kenwood TK-3118 User manual

© 2001-10 PRINTED IN JAPAN
B51-8601-00 (S) 610
TK-3118
GENERAL.................................................................. 2
PARTS LIST............................................................... 3
EXPLODEDVIEW ................................................... 11
PACKING ................................................................. 12
ADJUSTMENT......................................................... 13
PC BOARD VIEWS
DISPLAY UNIT (X41-3583-00)............................ 19
TX-RX UNIT (X57-6243-XX) ............................... 21
SCHEMATIC DIAGRAM .......................................... 33
BLOCK DIAGRAM .................................................. 37
LEVEL DIAGRAM ................................................... 39
BC-20, PB-40, PB-41, BT-12 ................................... 40
SPECIFICATIONS ................................................... 41
Helical Antenna
(T90-0759-05):C
(T90-0760-05):C4
Knob(ENC)
(K29-5443-03)
TK-3118
CONTENTS
Knob
(VOL)
(K29-5442-03)
UHF FM TRANSCEIVER / UHF FM手持机
SERVICE MANUAL /
维修手册
Key top(DTMF)
(K29-9028-13)
Cabinet assy
(Front)
(A02-3559-13)
Key top
(DIAL, SCAN)
(K29-9026-13)
Panel assy
(A62-0932-03)
Knob
(PTT, MONI)
(K29-9027-03)
ThisTK-3118servicemanualcontainsanumberof sections which
differ from the service manual (B51-8576-00) for the TK-3118.
For items other than those in thisTK-3118 service manual please
refer to the service manual (B51-8576-00) for the TK-3118.
本TK-3118维修手册记述了不同于TK-3118用维修手册（B51-8576-
00）部分的内容。
对于本TK-3118维修手册中未予记载的项目，请参阅TK-3118的维
修手册（B51-8576-00）。
SUPPLEMENT / 追补版

2
TK-3118
TK-260 :K, K2
INTRODUCTION
SCOPE OF THIS MANUAL
This manual is intended for use by experienced technicians
familiar with similar types of commercial grade
communications equipment. It contains all required service
information for the equipment and is current as of the
publication date. Changes which may occur after publication
are covered by either Service Bulletins or Manual Revisions.
These are issued as required.
ORDERING REPLACEMENT PARTS
When ordering replacement parts or equipment
information, the full part identification number should be
included. This applies to all parts : components, kits, or
chassis. If the part number is not known, include the chassis or
kit number of which it is a part, and a sufficient description of
the required component for proper identification.
PERSONAL SAFETY
The following precautions are recommended for personal
safety :
•DO NOT transmit until all RF connectors are verified secure
and any open connectors are properly terminated.
•SHUT OFF and DO NOT operate this equipment near
electrical blasting caps or in an explosive atmosphere.
•This equipment should be serviced by a qualified
technician only.
SERVICE
This radio is designed for easy servicing. Refer to the
schematic diagrams, printed circuit board views, and
alignment procedures contained within.
GENERAL / 概述
目录目录
目录目录
目录
概述. ............................................................................ 2
零件表 ......................................................................... 3
部件分解图 ................................................................11
包装 ........................................................................... 12
调整 ........................................................................... 13
PC板视图
显示单元 (X41-3583-00) ....................................... 19
发射－接收单元 (X57-6243-XX) ............................ 21
原理图 ....................................................................... 33
方块图 ....................................................................... 37
电平图 ....................................................................... 39
BC-20, PB-40, PB-41, BT-12 ...................................... 40
规格 ........................................................................ 背面
Destnation Number of CH RF power output
C, C4 50 5W/2W
引言
本手册的范围
本手册是提供给熟悉通信专业并且具有维修经验的技术人员
使用的。它包括了维修该设备所需要的全部资料和现行出版日
期。在出版后可能发生变动，如果需要，可以使用《维修通
报》或《手册修订本》进行补充。
替换零件的订购
当订购替换零件或设备信息时，应注明完整的零件识别号
码。所有的零件均有识别号码：元件、组件或机壳。如果不知
道零件的号码，为了正确地识别，必须注明此元件所属的机壳
或组件的号码，并对元件进行充分的说明。
个人安全
为了个人的安全，请注意下列事项：
• 在没有认真核实所有射频插头之前或有任何一个打开的插头
没有连接到相应端子上的情况下，均不要发射。
• 在电爆管附近或在易燃性气体环境中，必须关掉电源，不要
操作本设备。
•本设备只应该由有资格的技术人员来维修。
维修服务
为了便于维修本设备，建立了完整的维修服务体系，提供了
包括原理图、印刷线路板图和调整步骤在内的资料供参考。
型式 信道号码 射频功率输出
C, C4 50 5W/2W

3
TK-3118
PARTS LIST / 零件表
Destination Parts No. Description Address New
parts
Destination
TK-3118
Ref. No. Parts No. Description
Address New
parts
∗New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
TK-3118
Ref. No.
TX-RX UNIT (X57-6243-XX)
!
DISPLAY UNIT (X41-3583-00)
13AA01-2173-11 CABINET(REAR)
21A∗A02-3559-13 CABINET ASSY(FORONT)
33AA62-0932-03 PANEL ASSY
43AB09-0599-03 CAP
51AB10-2652-13 FRONT GLASS
6- B62-1387-10 INSTRUCTION MANUAL
73A∗B72-1886-14 MODEL NAME PLATE C
73A∗B72-1890-14 MODEL NAME PLATE C4
83AE04-0430-05 RF COAXIAL RECEPTACLE(SMA)
92BE23-1148-04 BATT TERMINAL(-)
10 2B E23-1169-04 BATT TERMINAL(+)
11 2B E23-1186-04 GROUND TERMINAL
12 2B F07-1839-03 COVER(FPC)
13 3A G11-2664-24 RUBBER SHEET(RF PCB)
14 3A G11-4031-14 RUBBER SHEET(VOLL,ENC)
15 1A G53-1521-04 PACKING(SP/MIC)
16 - H12-3088-05 PACKING FIXTURE
17 - H25-0085-04 PROTECTION BAG
18 - H52-1720-02 ITEM CARTON CASE
19 2B J19-5391-02 HOLDER(BATT TERMINAL)
20 - J29-0465-04 BELT HOOK ACCESSORY
21 - J61-0429-05 BAND ACCESSORY
22 - J69-0352-05 HANDSTRAP ACCESSORY
23 3A K29-5442-03 KNOB(VOL)
24 3A K29-5443-03 KNOB(ENC)
25 1B K29-9026-13 KEY TOP(DIAL SCAN)
26 3B K29-9027-03 KNOB(PTT MONI)
27 1B K29-9028-13 KEY TOP(DTMF)
A2BN09-2282-05 TAPTITE SCREW(CABINET)
B3AN09-2377-05 SPECIAL SCREW(SMA)
C3AN14-0582-14 CIRCULAR NUT(SMA)
D3AN14-0590-04 CIRCULAR NUT(VOL,ENC)
E1AN38-2030-46 PAN HEAD MACHINE SCREW
F3A,3B N80-2016-45 PAN HEAD TAPTITE SCREW
G2AN83-2004-46 PAN HEAD TAPTITE SCREW
H- N99-2023-05 SCREW SET ACCESSORY
SP 1A T07-0362-05 SPEAKER
ANT - T90-0759-05 HELICAL ANTENNA C
ANT - ∗T90-0760-05 HELICAL ANTENNA C4
X41358B
D100-107 B30-2157-05 LED(YELLOW)
C600 CK73GB1H471K CHIP C 470PF K
28 2B E37-0865-05 SPEAKER CORD
J30-1267-04 SPACER(ECM)
30 2B J82-0082-05 FPC
R307-310 RK73GB1J102J CHIP R 1.0K J 1/16W
R600-603 RK73GB1J221J CHIP R 220 J 1/16W
R604-606 RK73GB1J680J CHIP R 68 J 1/16W
31 2B T91-0616-05 MIC ELEMENT
32 2A A13-1632-03 FRAME
33 1A B11-1268-04 FILTER(LCD)
34 1A B11-1269-03 ILLUMINATION GUIDE(LCD)
35 1A B38-0848-05 LCD
D300 B30-2156-05 LED(RED)
D304,305 B30-2143-05 LED(YG)
D313 B30-2157-05 LED(YELLOW)
C1 CK73HB1H471K CHIP C 470PF K
C2 C92-0576-05 CHIP-TAN 1.0UF 6.3WV
C3 CK73GB1H471K CHIP C 470PF K
C4 CK73GB1C473K CHIP C 0.047UF K
C5 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C6 CK73HB1H471K CHIP C 470PF K
C7 CC73HCH1H100D CHIP C 10PF D
C8 CK73GB1H102K CHIP C 1000PF K C4
C8 CK73GB1H472K CHIP C 4700PF K C
C9 CK73GB1C104K CHIP C 0.10UF K
C10 CK73HB1H471K CHIP C 470PF K
C11 CK73HB1H102K CHIP C 1000PF K
C12 CK73HB1A104K CHIP C 0.10UF K
C13 CC73HCH1H101J CHIP C 100PF J
C14 CC73HCH1H100D CHIP C 10PF D
C15 CK73GB1C104K CHIP C 0.10UF K C4
C15 CK73GB1C333K CHIP C 0.033UF K C
C16 CK73HB1H102K CHIP C 1000PF K
C18 CK73GB1H471K CHIP C 470PF K
C21 CC73HCH1H470J CHIP C 47PF J
C25 C92-0001-05 CHIP-C 0.1UF 35WV
C26 CK73HB1H331K CHIP C 330PF K
C27 CK73GB1H471K CHIP C 470PF K
C28 CK73HB1H471K CHIP C 470PF K
C29 C92-0512-05 CHIP-TAN 1.0UF 16WV
C30 CK73HB1H221K CHIP C 220PF K
C32 C92-0560-05 CHIP-TAN 10UF 6.3WV
C33 CC73HCH1H150J CHIP C 15PF J
C34 CC73HCH1H020C CHIP C 2.0PF C
C35 C92-0001-05 CHIP-C 0.1UF 35WV
C36 CK73HB1H471K CHIP C 470PF K
C40 CK73GB1H102K CHIP C 1000PF K
C41 CC73HCH1H680J CHIP C 68PF J
C42 C92-0560-05 CHIP-TAN 10UF 6.3WV
C43 CC73HCH1H330J CHIP C 33PF J
C44 CC73HCH1H121J CHIP C 120PF J
C45 CC73HCH1H030C CHIP C 3.0PF C
C46 CK73GB1H471K CHIP C 470PF K
C47 CC73HCH1H330J CHIP C 33PF J
C49 CC73HCH1H680J CHIP C 68PF J
TX-RX UNIT (X57-6243-XX) -00:C, -01:C4

4
TK-3118
Ref. No. Parts No. Description Address New
parts
Ref. No. Parts No. Description Address New
parts Destination Destination
TX-RX UNIT (X57-6243-XX)
400~420Hz : C5
450~470Hz : C6
PARTS LIST / 零件表
C50 CK73HB1H471K CHIP C 470PF K
C51 C92-0560-05 CHIP-TAN 10UF 6.3WV
C53 CK73GB1H103K CHIP C 0.010UF K
C54 CK73GB1C104K CHIP C 0.10UF K
C59 CK73HB1H182K CHIP C 1800PF K
C60 CK73HB1H102K CHIP C 1000PF K
C62,63 CK73HB1H471K CHIP C 470PF K
C64 CC73GCH1H080B CHIP C 8.0PF B C
C64 CC73GCH1H200J CHIP C 20PF J C4
C65 CC73GCH1H100C CHIP C 10PF C C4
C65 CC73GCH1H150J CHIP C 15PF J C
C66 CC73GCH1H100C CHIP C 10PF C C
C66 CC73GCH1H200J CHIP C 20PF J C4
C68 CC73GCH1H100C CHIP C 10PF C C4
C68 CC73GCH1H120G CHIP C 12PF G C
C69 CK73HB1H182K CHIP C 1800PF K
C70 CC73HCH1H270J CHIP C 27PF J
C71 CC73HCH1H0R5B CHIP C 0.5PF B
C72 CC73GCH1H050B CHIP C 5.0PF B C
C72,73 CC73GCH1H050B CHIP C 5.0PF B C4
C73 CC73GCH1H030B CHIP C 3.0PF B C
C74 CK73HB1H471K CHIP C 470PF K
C75 CC73GCH1H130J CHIP C 13PF J
C77 CC73HCH1H030B CHIP C 3.0PF B C4
C77 CK73HB1H471K CHIP C 470PF K C
C78 CK73GB1C104K CHIP C 0.10UF K C
C78 CK73GB1H561K CHIP C 560PF K C4
C79 CC73GCH1H0R5B CHIP C 0.5PF B
C80 CC73HCH1H080D CHIP C 8.0PF D
C81 CC73GCH1H100C CHIP C 10PF C
C82 CC73GCH1H0R5B CHIP C 0.5PF B
C83 CK73HB1H471K CHIP C 470PF K
C85-87 CK73HB1H471K CHIP C 470PF K
C88 CK73HB1C103K CHIP C 0.010UF K
C90 CC73HCH1H060B CHIP C 6.0PF B C
C90 CC73HCH1H080B CHIP C 8.0PF B C4
C91 CK73HB1H471K CHIP C 470PF K
C92 CC73GCH1H090D CHIP C 9.0PF D
C93 CC73HCH1H220J CHIP C 22PF J
C95 CK73HB1H471K CHIP C 470PF K
C96 CK73HB1C103K CHIP C 0.010UF K
C97 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C98-101 CK73HB1H471K CHIP C 470PF K
C102 CK73HB1H102K CHIP C 1000PF K
C103 CC73HCH1H030C CHIP C 3.0PF C C
C103 CC73HCH1H060B CHIP C 6.0PF B C4
C104 CK73HB1H471K CHIP C 470PF K
C105 CC73HCH1H150J CHIP C 15PF J C
C105 CC73HCH1H180J CHIP C 18PF J C4
C107 CK73HB1H471K CHIP C 470PF K
C109 CK73HB1C103K CHIP C 0.010UF K
C111 CK73HB1H471K CHIP C 470PF K
C112 CC73GCH1H100C CHIP C 10PF C
C116 CK73HB1H471K CHIP C 470PF K
C121 CK73HB1H471K CHIP C 470PF K
C122 CC73GCH1H050B CHIP C 5.0PF B C
C122 CC73GCH1H080D CHIP C 8.0PF D C4
C125 CC73GCH1H050B CHIP C 5.0PF B C
C125 CC73GCH1H060B CHIP C 6.0PF B C4
C126 CK73GB1H471K CHIP C 470PF K
C127 CC73GCH1H020B CHIP C 2.0PF B C
C127 CC73GCH1H040B CHIP C 4.0PF B C4
C129 CK73GB1H471K CHIP C 470PF K
C130 CC73GCH1HR75B CHIP C 0.75PF B
C131 CC73GCH1H050B CHIP C 5.0PF B C
C131 CC73GCH1H060B CHIP C 6.0PF B C4
C133 CK73GB1C104K CHIP C 0.10UF K
C134 CK73HB1H471K CHIP C 470PF K
C135 CC73GCH1H090B CHIP C 9.0PF B
C137 CK73GB1H471K CHIP C 470PF K
C138 CK73HB1H471K CHIP C 470PF K
C139 CC73GCH1HR75B CHIP C 0.75PF B
C140 CC73GCH1H040B CHIP C 4.0PF B
C141 CC73GCH1H050B CHIP C 5.0PF B C
C141 CC73GCH1H060B CHIP C 6.0PF B C4
C145 CC73GCH1H470J CHIP C 47PF J C4
C145 CC73GCH1H560J CHIP C 56PF J C
C146 CK73GB1H102K CHIP C 1000PF K C
C147 CC73GCH1H471J CHIP C 470PF J
C149 CK73HB1H471K CHIP C 470PF K
C150 CK73GB1H471K CHIP C 470PF K
C151 C92-0565-05 CHIP-TAN 6.8UF 10WV
C152 CK73HB1H471K CHIP C 470PF K
C154 CK73GB1H471K CHIP C 470PF K
C159 CK73HB1H471K CHIP C 470PF K
C162 CC73GCH1H390J CHIP C 39PF J C4
C163 CK73HB1H471K CHIP C 470PF K
C164 CK73GB1H471K CHIP C 470PF K
C166-168 CK73GB1H471K CHIP C 470PF K
C169 CC73GCH1H050B CHIP C 5.0PF B C
C169 CC73GCH1H060B CHIP C 6.0PF B C4
C170 CK73GB1H471K CHIP C 470PF K
C171 CK73FF1C105Z CHIP C 1.0UF Z C4
C172 CK73HB1H471K CHIP C 470PF K
C173 CC73GCH1HR75B CHIP C 0.75PF B
C174 CK73GB1H471K CHIP C 470PF K
C176 CK73GB1H103K CHIP C 0.010UF K
C177 CK73GB1H471K CHIP C 470PF K
C178 CC73GCH1H050B CHIP C 5.0PF B C
C178 CC73GCH1H060B CHIP C 6.0PF B C4
C179 CC73GCH1H150G CHIP C 15PF G C
C180 CK73GB1C104K CHIP C 0.10UF K
C182 CC73GCH1HR75B CHIP C 0.75PF B
C183 CC73GCH1H1R5B CHIP C 1.5PF B C4
C185 CC73GCH1H100D CHIP C 10PF D
C186 CC73GCH1H270G CHIP C 27PF G C
C186 CC73GCH1H430J CHIP C 43PF J C4
C187 CK73GB1H471K CHIP C 470PF K
C189 CC73HCH1H101J CHIP C 100PF J
C190 CK73GB1H471K CHIP C 470PF K
C192 CK73GB1H471K CHIP C 470PF K
C193 CC73GCH1H060B CHIP C 6.0PF B

5
TK-3118
Ref. No. Parts No. Description Address New
parts
Ref. No. Parts No. Description Address New
parts Destination Destination
TX-RX UNIT (X57-6243-XX)
M:TK-2107
M2:TK-2107
PARTS LIST / 零件表
C194 CC73GCH1H101J CHIP C 100PF J C4
C194 CC73GCH1H270G CHIP C 27PF G C
C197 CK73GB1H471K CHIP C 470PF K
C198 CC73GCH1H090B CHIP C 9.0PF B C
C198 CC73GCH1H3R5B CHIP C 3.5PF B C4
C199 CC73GCH1H471J CHIP C 470PF J
C200 CK73HB1H102K CHIP C 1000PF K
C201 CC73GCH1H020B CHIP C 2.0PF B
C202 CK73HB1H102K CHIP C 1000PF K
C203 CC73GCH1H020B CHIP C 2.0PF B
C204 CC73GCH1H050B CHIP C 5.0PF B
C205 CC73GCH1H1R5B CHIP C 1.5PF B
C206 CK73HB1H471K CHIP C 470PF K
C207 CC73GCH1H040B CHIP C 4.0PF B
C208 CC73GCH1H3R5B CHIP C 3.5PF B C4
C212 CK73GB1H102K CHIP C 1000PF K C
C212 CK73GB1H471K CHIP C 470PF K C4
C213 CK73HB1H471K CHIP C 470PF K
C214 CK73HB1H102K CHIP C 1000PF K
C215 CC73HCH1H110J CHIP C 11PF J C
C215 CC73HCH1H130G CHIP C 13PF G C4
C216 CC73HCH1H070B CHIP C 7.0PF B C
C216 CC73HCH1H100C CHIP C 10PF C C4
C217 CK73HB1H102K CHIP C 1000PF K
C218 CK73FF1C105Z CHIP C 1.0UF Z
C219 CC73GCH1H010C CHIP C 1.0PF C
C221,222 CK73HB1H471K CHIP C 470PF K
C223 CC73GCH1H050B CHIP C 5.0PF B C
C223 CC73GCH1H060B CHIP C 6.0PF B C4
C224 CK73HB1H471K CHIP C 470PF K
C225 CC73GCH1H470J CHIP C 47PF J C
C226 CC73GCH1H070B CHIP C 7.0PF B
C230,231 CK73HB1H471K CHIP C 470PF K
C232 CK73GB1H471K CHIP C 470PF K
C234 CK73GB1H471K CHIP C 470PF K
C236 CC73GCH1H040B CHIP C 4.0PF B C4
C236 CC73GCH1H2R5B CHIP C 2.5PF B C
C237 CC73GCH1H0R5B CHIP C 0.5PF B
C238 CK73GB1H471K CHIP C 470PF K
C240 CC73GCH1H160G CHIP C 16PF G C
C240 CC73GCH1H240G CHIP C 24PF G C4
C242 CC73GCH1H330G CHIP C 33PF G C4
C243 CC73HCH1H150J CHIP C 15PF J C4
C244 CC73HCH1H101J CHIP C 100PF J
C300 CK73HB1H332K CHIP C 3300PF K
C301 CK73HB1A473K CHIP C 0.047UF K
C302 CC73HCH1H390J CHIP C 39PF J
C303-305 CK73HB1H471K CHIP C 470PF K
C306 CC73HCH1H390J CHIP C 39PF J
C307-309 CK73HB1C103K CHIP C 0.010UF K
C310 CC73HCH1H100D CHIP C 10PF D
C311,312 CK73HB1H471K CHIP C 470PF K
C313 CC73HCH1H030C CHIP C 3.0PF C
C314 CC73HCH1H100D CHIP C 10PF D
C316 CK73HB1H471K CHIP C 470PF K
C317 CK73HB1A104K CHIP C 0.10UF K
C318 C92-0560-05 CHIP-TAN 10UF 6.3WV
C319-321 CK73HB1H471K CHIP C 470PF K
C322 CK73GB1H471K CHIP C 470PF K
C323 CK73EF1C105Z CHIP C 1.0UF Z
C324 C92-0623-05 CHIP-TAN 22UF 4WV
C326 CK73HB1C223K CHIP C 0.022UF K
C327 CK73GB1C273K CHIP C 0.027UF K
C328 CK73HB1H471K CHIP C 470PF K
C329 CK73GB1C273K CHIP C 0.027UF K
C331 CK73HB1H471K CHIP C 470PF K
C332 CK73FB1A105K CHIP C 1.0UF K
C333 CK73HB1H102K CHIP C 1000PF K
C334 CK73FB1A105K CHIP C 1.0UF K
C335 CK73HB1A393K CHIP C 0.039UF K
C336 CK73GB1C104K CHIP C 0.10UF K
C337 CK73FB1A105K CHIP C 1.0UF K
C338 CK73FF1E104Z CHIP C 0.10UF Z
C339 CK73FF1C105Z CHIP C 1.0UF Z
C343,344 CK73FB1A105K CHIP C 1.0UF K
C347 CK73FB1A105K CHIP C 1.0UF K
C349,350 CK73HB1A104K CHIP C 0.10UF K
C352 CK73HB1H392K CHIP C 3900PF K
C353 CK73HB1C103K CHIP C 0.010UF K
C354 CK73HB1A683K CHIP C 0.068UF K
C356 CK73HB1A473K CHIP C 0.047UF K
C357 CK73HB1C103K CHIP C 0.010UF K
C358 CK73HB1E682K CHIP C 6800PF K
C359 C92-0587-05 CHIP-TAN 2.2UF 4WV
C360 CK73HB1A473K CHIP C 0.047UF K
C361 CK73HB1C103K CHIP C 0.010UF K
C362 CK73GB1H682K CHIP C 6800PF K
C363 CK73HB1A333K CHIP C 0.033UF K
C365 CK73HB1H392K CHIP C 3900PF K
C366 CK73GB1H472K CHIP C 4700PF K
C367 CK73HB1C103K CHIP C 0.010UF K
C369 CK73FB1A105K CHIP C 1.0UF K
C370 CK73HB1H392K CHIP C 3900PF K
C371 CK73HB1A104K CHIP C 0.10UF K
C374 CK73GB1C104K CHIP C 0.10UF K
C375 CK73HB1H471K CHIP C 470PF K
C376 C92-0560-05 CHIP-TAN 10UF 6.3WV
C377 CK73GB1H391K CHIP C 390PF K
C378 CK73HB1E682K CHIP C 6800PF K
C381 CK73HB1A473K CHIP C 0.047UF K
C382 CK73HB1H332K CHIP C 3300PF K
C383 CK73HB1A104K CHIP C 0.10UF K
C384 C92-0560-05 CHIP-TAN 10UF 6.3WV
C385 CC73HCH1H100D CHIP C 10PF D
C386 C92-0560-05 CHIP-TAN 10UF 6.3WV
C387 CK73HB1H471K CHIP C 470PF K
C388 CK73GB1H102K CHIP C 1000PF K
C389 CC73HCH1H560J CHIP C 56PF J
C390 CK73HB1A333K CHIP C 0.033UF K
C391 CK73HB1C223K CHIP C 0.022UF K
C392 CK73HB1A473K CHIP C 0.047UF K
C393 C92-0507-05 CHIP-TAN 4.7UF 6.3WV

6
TK-3118
Ref. No. Parts No. Description Address New
parts
Ref. No. Parts No. Description Address New
parts Destination Destination
TX-RX UNIT (X57-6243-XX)
400~420Hz : C5
450~470Hz : C6
PARTS LIST / 零件表
C394 CK73HB1A683K CHIP C 0.068UF K
C395 CK73HB1H102K CHIP C 1000PF K
C396 CK73HB1H221K CHIP C 220PF K
C397 CK73HB1H471K CHIP C 470PF K
C398 CK73HB1A104K CHIP C 0.10UF K
C399 CK73GB1E393J CHIP C 0.039UF J
C400,401 CK73GB1C104K CHIP C 0.10UF K
C402 CK73HB1H471K CHIP C 470PF K
C403 C92-0587-05 CHIP-TAN 2.2UF 4WV
C404 CK73GB1A474K CHIP C 0.47UF K
C405 CK73FB1C474K CHIP C 0.47UF K
C406 CC73GCH1H101J CHIP C 100PF J
C407 C92-0560-05 CHIP-TAN 10UF 6.3WV
C408 CK73GB1C104K CHIP C 0.10UF K
C409,410 CK73GB1H471K CHIP C 470PF K
C411 CK73GB1C473K CHIP C 0.047UF K
C412 C92-0560-05 CHIP-TAN 10UF 6.3WV
C413 CK73GB1H103K CHIP C 0.010UF K
C414 C92-0665-05 TANTAL 100UF 6.3WV
C416 CK73HB1H471K CHIP C 470PF K
C418 CC73GCH1H221J CHIP C 220PF J
C420 CK73HB1H102K CHIP C 1000PF K
C421 CK73HB1H471K CHIP C 470PF K
C422 CK73HB1H102K CHIP C 1000PF K
C423 CK73HB1A473K CHIP C 0.047UF K
C424 CK73GB1H561K CHIP C 560PF K
TC1 C05-0383-05 CERAMIC TRIMMER CAP(6PF) C
TC1,2 C05-0384-05 CERAMIC TRIMMER CAP(10PF) C4
TC2 C05-0384-05 CERAMIC TRIMMER CAP(10PF) C
TC3 C05-0383-05 CERAMIC TRIMMER CAP(6PF)
TC5 C05-0383-05 CERAMIC TRIMMER CAP(6PF) C4
TC5 C05-0384-05 CERAMIC TRIMMER CAP(10PF) C
36 1A E29-1190-04 INTER CONNECTOR(LCD)
37 2A ∗E37-0996-05 FLAT CABLE
CN1 E40-5651-05 FLAT CABLE CONNECTOR
CN2 E23-0603-05 RELAY TERMINAL(ANT)
CN3-6 ∗E23-1214-05 TERMINAL(FINAL FET)
CN100 E40-5630-05 PIN ASSY SOCKET
CN301 E40-5651-05 FLAT CABLE CONNECTOR
CN302 E40-5629-05 PIN ASSY
CN303 E40-6166-05 FLAT CABLE CONNECTOR
J300 E11-0457-05 PHONE JACK
W1 ∗E37-0860-05 PROCESSED LEAD WIRE C4
F1 F53-0217-05 FUSE
38 2A ∗G11-4126-04 SHEET
39 1A J21-8412-14 HARDWARE FIXTURE
CF1 L72-0958-05 CERAMIC FILTER
L1 L92-0140-05 FERRITE CHIP
L2-4 L92-0138-05 FERRITE CHIP
L5 L40-1005-85 SMALL FIXED INDUCTOR(10UH)
L6,7 L92-0138-05 FERRITE CHIP
L9 L40-5681-86 SMALL FIXED INDUCTOR(0.56UH)
L10 L40-4781-86 SMALL FIXED INDUCTOR(0.47UH)
L11 L40-1875-92 SMALL FIXED INDUCTOR(18NH)
L12,13 L40-2285-92 SMALL FIXED INDUCTOR(220NH)
L14-16 L92-0140-05 FERRITE CHIP
L17 L40-6891-86 SMALL FIXED INDUCTOR(6.8UH)
L18 L92-0140-05 FERRITE CHIP
L20 L40-2278-98 SMALL FIXED INDUCTOR(22NH) C4
L20,21 L40-2278-98 SMALL FIXED INDUCTOR(22NH) C
L21 L40-2778-98 SMALL FIXED INDUCTOR(27NH) C4
L22 L34-4554-05 COIL
L23 L40-6891-86 SMALL FIXED INDUCTOR(6.8UH)
L24 L92-0140-05 FERRITE CHIP
L25 L40-2775-92 SMALL FIXED INDUCTOR(27NH) C
L25 L40-3375-92 SMALL FIXED INDUCTOR(33NH) C4
L26 L40-4775-92 SMALL FIXED INDUCTOR(47NH)
L27 L92-0140-05 FERRITE CHIP
L28 L40-4785-85 SMALL FIXED INDUCTOR(0.47UH)
L29 L40-2775-92 SMALL FIXED INDUCTOR(27NH) C
L29 L40-3375-92 SMALL FIXED INDUCTOR(33NH) C4
L30 L40-3385-85 SMALL FIXED INDUCTOR(0.33UH)
L31 L40-6875-92 SMALL FIXED INDUCTOR(68NH)
L33 L40-1875-92 SMALL FIXED INDUCTOR(18NH) C
L33 L40-6865-92 SMALL FIXED INDUCTOR(6.8NH) C4
L34,35 L40-1278-60 SMALL FIXED INDUCTOR(12NH)
L36 L40-1275-92 SMALL FIXED INDUCTOR(12NH)
L37 L92-0140-05 FERRITE CHIP
L38 L41-4778-03 SMALL FIXED INDUCTOR C
L38 L41-5678-03 SMALL FIXED INDUCTOR C4
L39 L40-1278-60 SMALL FIXED INDUCTOR(12NH)
L40 L41-2278-03 SMALL FIXED INDUCTOR C
L40 L41-4778-03 SMALL FIXED INDUCTOR C4
L42 L40-1098-76 SMALL FIXED INDUCTOR(1UH) C
L42 L40-4788-76 SMALL FIXED INDUCTOR(0.47UH) C4
L43 L92-0149-05 FERRITE CHIP
L44 L40-1078-60 SMALL FIXED INDUCTOR(10NH) C
L44 L40-1278-60 SMALL FIXED INDUCTOR(12NH) C4
L45 L34-4568-05 AIR-CORE COIL
L46 L92-0149-05 FERRITE CHIP
L47 L40-1278-60 SMALL FIXED INDUCTOR(12NH)
L48 L41-1578-03 SMALL FIXED INDUCTOR C4
L48,49 L41-1578-03 SMALL FIXED INDUCTOR C
L49 L41-1078-03 SMALL FIXED INDUCTOR C4
L50 L40-2285-54 SMALL FIXED INDUCTOR(220NH)
L51 L34-4564-05 AIR-CORE COIL
L52 L34-4563-05 AIR-CORE COIL
L53 L34-4564-05 AIR-CORE COIL
L54 L34-4563-05 AIR-CORE COIL
L55 L40-1092-81 SMALL FIXED INDUCTOR
L57 L40-6865-92 SMALL FIXED INDUCTOR(6.8NH)
L58 L40-6891-86 SMALL FIXED INDUCTOR(6.8UH)
L59 L92-0140-05 FERRITE CHIP
L60 L40-6891-86 SMALL FIXED INDUCTOR(6.8UH)
L63 L40-2775-92 SMALL FIXED INDUCTOR(27NH) C
L64 L34-4563-05 AIR-CORE COIL C4
L300,301 L40-2281-86 SMALL FIXED INDUCTOR(0.22UH)
L302 L92-0138-05 FERRITE CHIP
L303 L40-2281-86 SMALL FIXED INDUCTOR(0.22UH)

7
TK-3118
Ref. No. Parts No. Description Address New
parts
Ref. No. Parts No. Description Address New
parts Destination Destination
TX-RX UNIT (X57-6243-XX)
M:TK-2107
M2:TK-2107
PARTS LIST / 零件表
L304,305 L92-0140-05 FERRITE CHIP
L306 L92-0149-05 FERRITE CHIP
L307-309 L92-0138-05 FERRITE CHIP
X1 L77-1792-05 TCXO (12.8MHZ)
X300 L77-1761-05 CRYSTAL RESONATOR(7.3728MHZ)
X301 L78-0326-05 RESONATOR (4.19MHZ)
XF1 L71-0586-05 MCF (38.85MHZ)
CP302 R90-0718-05 MULTI-COMP 4.7K X4
R1 RK73HB1J472J CHIP R 4.7K J 1/16W
R2 RK73HB1J273J CHIP R 27K J 1/16W
R3 R92-1252-05 CHIP R 0 OHM J 1/16W
R4 RK73HB1J563J CHIP R 56K J 1/16W
R5 RK73HB1J100J CHIP R 10 J 1/16W
R6 R92-1368-05 CHIP R 0 OHM
R7 RK73HB1J222J CHIP R 2.2K J 1/16W
R8 RK73HB1J470J CHIP R 47 J 1/16W
R9 RK73HB1J274J CHIP R 270K J 1/16W
R10 RK73HB1J222J CHIP R 2.2K J 1/16W
R11 RK73HB1J334J CHIP R 330K J 1/16W
R12,13 RK73HB1J561J CHIP R 560 J 1/16W
R14 RK73HB1J272J CHIP R 2.7K J 1/16W
R15 RK73HB1J222J CHIP R 2.2K J 1/16W
R16 RK73HB1J102J CHIP R 1.0K J 1/16W
R17 R92-1368-05 CHIP R 0 OHM
R18 RK73GB1J101J CHIP R 100 J 1/16W
R19 RK73HB1J104J CHIP R 100K J 1/16W
R20 RK73HB1J103J CHIP R 10K J 1/16W
R21 RK73HB1J101J CHIP R 100 J 1/16W
R22 RK73HB1J473J CHIP R 47K J 1/16W
R23 RK73HB1J103J CHIP R 10K J 1/16W
R25 RK73GB1J100J CHIP R 10 J 1/16W
R26 RK73HB1J104J CHIP R 100K J 1/16W
R28 RK73HB1J122J CHIP R 1.2K J 1/16W
R29 RK73GB1J103J CHIP R 10K J 1/16W
R30 RK73HB1J332J CHIP R 3.3K J 1/16W
R31 RK73HB1J472J CHIP R 4.7K J 1/16W
R32 RK73HB1J153J CHIP R 15K J 1/16W
R33 RK73HB1J473J CHIP R 47K J 1/16W
R34 RK73HB1J154J CHIP R 150K J 1/16W
R36 RK73HB1J102J CHIP R 1.0K J 1/16W C
R36,37 RK73HB1J102J CHIP R 1.0K J 1/16W C4
R37 RK73HB1J681J CHIP R 680 J 1/16W C
R38,39 RK73HB1J181J CHIP R 180 J 1/16W
R40 RK73HB1J102J CHIP R 1.0K J 1/16W
R41,42 RK73HB1J101J CHIP R 100 J 1/16W
R43 RK73HB1J124J CHIP R 120K J 1/16W
R44 RK73HB1J472J CHIP R 4.7K J 1/16W
R45 RK73HB1J124J CHIP R 120K J 1/16W
R46 RK73HB1J104J CHIP R 100K J 1/16W
R47 RK73GB1J561J CHIP R 560 J 1/16W
R48 RK73HB1J101J CHIP R 100 J 1/16W
R49 RK73HB1J102J CHIP R 1.0K J 1/16W
R50 RK73HB1J332J CHIP R 3.3K J 1/16W
R51 RK73HB1J562J CHIP R 5.6K J 1/16W
R52 RK73HB1J271J CHIP R 270 J 1/16W
R53 RK73HB1J103J CHIP R 10K J 1/16W
R54 RK73HB1J332J CHIP R 3.3K J 1/16W
R55 RK73GB1J561J CHIP R 560 J 1/16W
R56 RK73HB1J470J CHIP R 47 J 1/16W
R57 RK73HB1J100J CHIP R 10 J 1/16W
R58 RK73HB1J102J CHIP R 1.0K J 1/16W C
R58 RK73HB1J821J CHIP R 820 J 1/16W C4
R59 RK73HB1J332J CHIP R 3.3K J 1/16W
R60 RK73HB1J181J CHIP R 180 J 1/16W
R61 RK73HB1J102J CHIP R 1.0K J 1/16W
R62 R92-1368-05 CHIP R 0 OHM
R63 R92-1252-05 CHIP R 0 OHM J 1/16W
R64 RK73HB1J473J CHIP R 47K J 1/16W
R65 RK73HB1J562J CHIP R 5.6K J 1/16W
R67,68 RK73HB1J473J CHIP R 47K J 1/16W
R69 RK73HB1J181J CHIP R 180 J 1/16W
R70 RK73HB1J102J CHIP R 1.0K J 1/16W C
R72 RK73HB1J330J CHIP R 33 J 1/16W
R75 RK73HB1J152J CHIP R 1.5K J 1/16W C4
R77 RK73HB1J104J CHIP R 100K J 1/16W
R78 RK73HB1J332J CHIP R 3.3K J 1/16W C4
R78 RK73HB1J822J CHIP R 8.2K J 1/16W C
R79 RK73GB1J100J CHIP R 10 J 1/16W C4
R79 RK73GB1J220J CHIP R 22 J 1/16W C
R80 RK73GB1J102J CHIP R 1.0K J 1/16W
R81 RK73HB1J104J CHIP R 100K J 1/16W
R83 R92-1252-05 CHIP R 0 OHM J 1/16W
R84 R92-1368-05 CHIP R 0 OHM C
R85 RK73HB1J104J CHIP R 100K J 1/16W
R88 RK73GB1J122J CHIP R 1.2K J 1/16W
R89 RK73GB1J683J CHIP R 68K J 1/16W
R90 RK73HB1J101J CHIP R 100 J 1/16W
R91 RK73GB1J152J CHIP R 1.5K J 1/16W C
R91 RK73GB1J471J CHIP R 470 J 1/16W C4
R92 RK73HB1J562J CHIP R 5.6K J 1/16W C4
R92 RK73HB1J821J CHIP R 820 J 1/16W C
R96 R92-1368-05 CHIP R 0 OHM
R97 RK73HB1J121J CHIP R 120 J 1/16W
R98 RK73HB1J224J CHIP R 220K J 1/16W
R99 RK73GB1J273J CHIP R 27K J 1/16W C4
R99 RK73GB1J473J CHIP R 47K J 1/16W C
R101 RK73GB1J823J CHIP R 82K J 1/16W
R102 R92-1252-05 CHIP R 0 OHM J 1/16W
R103 RK73HB1J153J CHIP R 15K J 1/16W
R105 RK73HB1J104J CHIP R 100K J 1/16W
R106 RK73GB1J470J CHIP R 47 J 1/16W
R108 RK73GB1J102J CHIP R 1.0K J 1/16W
R110 RK73EB2ER39K CHIP R 0.39 K 1/4W
R112 RK73HB1J104J CHIP R 100K J 1/16W
R113,114 RK73EB2ER39K CHIP R 0.39 K 1/4W
R115 RK73HB1J104J CHIP R 100K J 1/16W
R116,117 RK73GH1J154D CHIP R 150K D 1/16W
R118 RK73HB1J104J CHIP R 100K J 1/16W
R119-122 RK73GH1J154D CHIP R 150K D 1/16W
R123 R92-0670-05 CHIP R 0 OHM C
R124,125 RK73GB1J271J CHIP R 270 J 1/16W
R126 RK73GB1J103J CHIP R 10K J 1/16W

8
TK-3118
Ref. No. Parts No. Description Address New
parts
Ref. No. Parts No. Description Address New
parts Destination Destination
TX-RX UNIT (X57-6243-XX)
400~420Hz : C5
450~470Hz : C6
PARTS LIST / 零件表
R127 RK73HB1J273J CHIP R 27K J 1/16W
R128 RK73GB1J102J CHIP R 1.0K J 1/16W
R129 RK73HB1J563J CHIP R 56K J 1/16W
R130 RK73HB1J105J CHIP R 1.0M J 1/16W
R135 R92-1252-05 CHIP R 0 OHM J 1/16W
R137 RK73HB1J102J CHIP R 1.0K J 1/16W
R138 R92-1252-05 CHIP R 0 OHM J 1/16W C4
R144 RK73GB1J102J CHIP R 1.0K J 1/16W
R145,146 RK73HB1J104J CHIP R 100K J 1/16W
R151 RK73GB1J333J CHIP R 33K J 1/16W
R152 R92-0670-05 CHIP R 0 OHM
R153 RK73HB1J101J CHIP R 100 J 1/16W
R154 R92-1368-05 CHIP R 0 OHM
R155-158 RK73HB1J103J CHIP R 10K J 1/16W
R300 RK73GB1J103J CHIP R 10K J 1/16W
R301 RK73HB1J103J CHIP R 10K J 1/16W
R302 RK73HB1J473J CHIP R 47K J 1/16W
R303 RK73HB1J103J CHIP R 10K J 1/16W
R304 RK73HB1J102J CHIP R 1.0K J 1/16W
R305 RK73HB1J331J CHIP R 330 J 1/16W
R306 RK73HB1J100J CHIP R 10 J 1/16W
R307 RK73HB1J564J CHIP R 560K J 1/16W
R308 RK73HB1J472J CHIP R 4.7K J 1/16W
R309 RK73GB1J272J CHIP R 2.7K J 1/16W
R311 RK73HB1J103J CHIP R 10K J 1/16W
R312 R92-1368-05 CHIP R 0 OHM
R313 RK73HB1J104J CHIP R 100K J 1/16W
R314-317 RK73HB1J102J CHIP R 1.0K J 1/16W
R318 RK73HB1J104J CHIP R 100K J 1/16W
R319-321 RK73HB1J102J CHIP R 1.0K J 1/16W
R322 RK73HB1J104J CHIP R 100K J 1/16W
R323 RK73HB1J103J CHIP R 10K J 1/16W
R324 RK73GB1J272J CHIP R 2.7K J 1/16W
R325 RK73HB1J100J CHIP R 10 J 1/16W
R326 RK73HB1J103J CHIP R 10K J 1/16W
R327,328 RK73HB1J221J CHIP R 220 J 1/16W
R329 RK73HB1J223J CHIP R 22K J 1/16W
R330 RK73HB1J104J CHIP R 100K J 1/16W
R331 RK73HB1J222J CHIP R 2.2K J 1/16W
R332 RK73HB1J104J CHIP R 100K J 1/16W
R333 RK73HB1J473J CHIP R 47K J 1/16W
R334,335 RK73HB1J102J CHIP R 1.0K J 1/16W
R336 RK73HB1J473J CHIP R 47K J 1/16W
R337 RK73HB1J153J CHIP R 15K J 1/16W
R338 RK73HB1J334J CHIP R 330K J 1/16W
R339,340 RK73GB1J221J CHIP R 220 J 1/16W
R341 RK73HB1J102J CHIP R 1.0K J 1/16W
R342 RK73HB1J684J CHIP R 680K J 1/16W
R343 RK73HB1J473J CHIP R 47K J 1/16W
R344 RK73HB1J100J CHIP R 10 J 1/16W
R345 RK73HB1J333J CHIP R 33K J 1/16W
R346 RK73HB1J334J CHIP R 330K J 1/16W
R347 R92-1252-05 CHIP R 0 OHM J 1/16W
R348 RK73HB1J102J CHIP R 1.0K J 1/16W
R349 RK73HB1J331J CHIP R 330 J 1/16W
R350 R92-0670-05 CHIP R 0 OHM
R351 RK73HB1J224J CHIP R 220K J 1/16W
R352 RK73HB1J104J CHIP R 100K J 1/16W
R353 RK73HB1J472J CHIP R 4.7K J 1/16W
R354 RK73HB1J102J CHIP R 1.0K J 1/16W
R356 RK73HB1J103J CHIP R 10K J 1/16W
R357 RK73HB1J682J CHIP R 6.8K J 1/16W
R358 RK73HB1J472J CHIP R 4.7K J 1/16W
R359 RK73HB1J561J CHIP R 560 J 1/16W
R360 RK73HB1J823J CHIP R 82K J 1/16W
R361 RK73HB1J103J CHIP R 10K J 1/16W
R362 RK73HB1J333J CHIP R 33K J 1/16W
R363 RK73HB1J102J CHIP R 1.0K J 1/16W
R364 RK73HB1J272J CHIP R 2.7K J 1/16W
R365 RK73HB1J332J CHIP R 3.3K J 1/16W
R366 RK73HB1J103J CHIP R 10K J 1/16W
R367 RK73HB1J332J CHIP R 3.3K J 1/16W
R368 RK73HB1J103J CHIP R 10K J 1/16W
R369 R92-1368-05 CHIP R 0 OHM
R370 RK73HB1J102J CHIP R 1.0K J 1/16W
R371 RK73GB1J272J CHIP R 2.7K J 1/16W
R372 RK73HB1J471J CHIP R 470 J 1/16W
R373 RK73HB1J272J CHIP R 2.7K J 1/16W
R374 RK73GB1J821J CHIP R 820 J 1/16W
R375 R92-1368-05 CHIP R 0 OHM
R376 RK73GB1J333J CHIP R 33K J 1/16W
R377 RK73GB1J823J CHIP R 82K J 1/16W
R378 RK73HB1J473J CHIP R 47K J 1/16W
R379 RK73HB1J683J CHIP R 68K J 1/16W
R380 RK73GB1J821J CHIP R 820 J 1/16W
R381 RK73HB1J223J CHIP R 22K J 1/16W
R382 RK73HB1J332J CHIP R 3.3K J 1/16W
R383,384 R92-1368-05 CHIP R 0 OHM
R385 RK73HB1J105J CHIP R 1.0M J 1/16W
R386 RK73HB1J562J CHIP R 5.6K J 1/16W
R387 RK73HB1J392J CHIP R 3.9K J 1/16W
R388 RK73HB1J124J CHIP R 120K J 1/16W
R389 RK73HB1J102J CHIP R 1.0K J 1/16W
R390 RK73GH1J913D CHIP R 91K D 1/16W
R391 RK73HB1J393J CHIP R 39K J 1/16W
R392 RK73HB1J102J CHIP R 1.0K J 1/16W
R393 RK73HB1J222J CHIP R 2.2K J 1/16W
R394 RK73HB1J183J CHIP R 18K J 1/16W
R395 RK73HB1J274J CHIP R 270K J 1/16W
R396 RK73HB1J333J CHIP R 33K J 1/16W
R397,398 RK73HB1J474J CHIP R 470K J 1/16W
R399 RK73HB1J274J CHIP R 270K J 1/16W
R400 RK73HB1J332J CHIP R 3.3K J 1/16W
R401 RK73HB1J683J CHIP R 68K J 1/16W
R402,403 RK73HB1J563J CHIP R 56K J 1/16W
R404 RK73HB1J332J CHIP R 3.3K J 1/16W
R405 RK73HB1J153J CHIP R 15K J 1/16W
R406 R92-1368-05 CHIP R 0 OHM
R407 RK73HB1J124J CHIP R 120K J 1/16W
R408 RK73GB1J223J CHIP R 22K J 1/16W
R409 RK73HB1J563J CHIP R 56K J 1/16W
R410 RK73HB1J105J CHIP R 1.0M J 1/16W

9
TK-3118
Ref. No. Parts No. Description Address New
parts
Ref. No. Parts No. Description Address New
parts Destination Destination
TX-RX UNIT (X57-6243-XX)
M:TK-2107
M2:TK-2107
PARTS LIST / 零件表
R411 RK73HB1J103J CHIP R 10K J 1/16W
R412 RK73HB1J473J CHIP R 47K J 1/16W
R413 RK73HB1J562J CHIP R 5.6K J 1/16W
R414 RK73HB1J183J CHIP R 18K J 1/16W
R415 RK73GB1J474J CHIP R 470K J 1/16W
R416 RK73HB1J222J CHIP R 2.2K J 1/16W
R417 RK73GB1J183J CHIP R 18K J 1/16W
R418 RK73HB1J102J CHIP R 1.0K J 1/16W
R419 RK73HB1J272J CHIP R 2.7K J 1/16W
R420 RK73HB1J823J CHIP R 82K J 1/16W
R421 R92-0670-05 CHIP R 0 OHM
R422,423 RK73HB1J103J CHIP R 10K J 1/16W
R424 RK73HB1J563J CHIP R 56K J 1/16W
R425 RK73HB1J153J CHIP R 15K J 1/16W
R426 RK73HB1J184J CHIP R 180K J 1/16W
R427 RK73HB1J104J CHIP R 100K J 1/16W
R430 RK73HB1J182J CHIP R 1.8K J 1/16W
R431 RK73HB1J332J CHIP R 3.3K J 1/16W
R432 RK73GB1J682J CHIP R 6.8K J 1/16W
R433 RK73HB1J102J CHIP R 1.0K J 1/16W
R434 RK73GB1J333J CHIP R 33K J 1/16W
R436 RK73HB1J222J CHIP R 2.2K J 1/16W
R437 RK73HB1J124J CHIP R 120K J 1/16W
R438 RK73HB1J473J CHIP R 47K J 1/16W
R439 RK73HB1J104J CHIP R 100K J 1/16W
R440 R92-1368-05 CHIP R 0 OHM
R441 RK73HB1J563J CHIP R 56K J 1/16W
R442 RK73HB1J154J CHIP R 150K J 1/16W
R443 RK73HB1J823J CHIP R 82K J 1/16W
R444 RK73HB1J105J CHIP R 1.0M J 1/16W
R445 RK73HB1J103J CHIP R 10K J 1/16W
R446 RK73HB1J102J CHIP R 1.0K J 1/16W
R447 RK73GB1J683J CHIP R 68K J 1/16W
R448 RK73HB1J473J CHIP R 47K J 1/16W
R449 RK73HB1J222J CHIP R 2.2K J 1/16W
R450 RK73HB1J101J CHIP R 100 J 1/16W
R451 RK73HB1J392J CHIP R 3.9K J 1/16W
R452 R92-0670-05 CHIP R 0 OHM
R453 RK73GB1J101J CHIP R 100 J 1/16W
R454 RK73HB1J821J CHIP R 820 J 1/16W
R455 RK73GB1J474J CHIP R 470K J 1/16W
R456 RK73GB1J182J CHIP R 1.8K J 1/16W C4
R456 RK73GB1J392J CHIP R 3.9K J 1/16W C
R457 RK73GB1J100J CHIP R 10 J 1/16W
R458 RK73HB1J182J CHIP R 1.8K J 1/16W
R459 RK73HB1J471J CHIP R 470 J 1/16W
R460 RK73HB1J563J CHIP R 56K J 1/16W
R462 RK73HB1J333J CHIP R 33K J 1/16W
R464 RK73HB1J101J CHIP R 100 J 1/16W
R466 R92-1252-05 CHIP R 0 OHM J 1/16W
R467,468 RK73HB1J473J CHIP R 47K J 1/16W
R469 R92-1252-05 CHIP R 0 OHM J 1/16W
R470,471 RK73HB1J473J CHIP R 47K J 1/16W
R477 RK73HB1J103J CHIP R 10K J 1/16W
VR1 R12-7491-05 TRIMMING POT.(68K)
VR301 R12-7491-05 TRIMMING POT.(68K)
VR302 R32-0647-05 SEMI FIXED VARIABLE RESISTOR
VR303 R12-7487-05 TRIMMING POT.(15K)
S100 S40-1117-05 TACT SWITCH
S300 S60-0419-05 ROTARY SWITCH
D1 MA742 DIODE
D2 MA2S111 DIODE
D3 1SR154-400 DIODE
D6,7 MA2S376 VARIABLE CAPACITANCE DIODE
D9 MA2S376 VARIABLE CAPACITANCE DIODE
D11 MA2S376 VARIABLE CAPACITANCE DIODE
D12 MA360 VARIABLE CAPACITANCE DIODE
D13 MA2S111 DIODE
D14,15 HSC277 DIODE
D16-18 HVC350B VARIABLE CAPACITANCE DIODE
D19 HZU5ALL DIODE
D21,22 HVC350B VARIABLE CAPACITANCE DIODE
D23 HVC355B VARIABLE CAPACITANCE DIODE
D24 HVC131 DIODE
D25,26 HSC277 DIODE
D27 HVC131 DIODE
D28 MA2S111 DIODE
D301 MA742 DIODE
D302 KDZ4.7EV ZENER DIODE
D306 DA221 DIODE
D307 1SS372 DIODE
D308 DAN222 DIODE
D309 KDZ3.0V ZENER DIODE
IC1 MB15E03SL MOS IC
IC2 TA31136FN MOS IC
IC3 NJM2904V MOS IC
IC300 M38267M8L271G P MPU
IC301 LC73881M MOS IC
IC302 AT24C16N-10SI ROM IC
IC302 24LC16BT-I/SN ROM IC
IC303 PST9145NR MOS IC
IC304 PST9124NR MOS IC
IC305 XC62FP3502P MOS IC
IC306 NJM2902V MOS IC
IC307 NJM2904V MOS IC
IC308 NJM2902V MOS IC
IC309 KIA6278F BI-POLAR IC
Q1 2SC4738(GR) TRANSISTOR
Q2 KTC4082 TRANSISTOR
Q3 2SC5108(Y) TRANSISTOR
Q4,5 2SC5066(O) TRANSISTOR
Q6 KTC4082 TRANSISTOR
Q7 2SC5108(Y) TRANSISTOR
Q8 2SJ243 FET
Q9 KRX102U TRANSISTOR
Q10 2SC4617(S) TRANSISTOR
Q11 2SC5108(Y) TRANSISTOR
Q12 3SK320 FET
Q13 2SC5108(Y) TRANSISTOR
Q14 DTC114TE DIGITAL TRANSISTOR
Q15 2SC4988 TRANSISTOR

10
TK-3118
Ref. No. Parts No. Description Address New
parts
Ref. No. Parts No. Description Address New
parts Destination Destination
TX-RX UNIT (X57-6243-XX)
400~420Hz : C5
450~470Hz : C6
PARTS LIST / 零件表
Q17 2SK1824 FET
Q18 2SK3475 FET
Q20 3SK274 FET
Q22 2SK3476 FET
Q23 DTA144EE DIGITAL TRANSISTOR
Q24 DTC144EUA DIGITAL TRANSISTOR
Q300-302 DTC114EE DIGITAL TRANSISTOR
Q303 DTC114YE DIGITAL TRANSISTOR
Q304 DTA123JE DIGITAL TRANSISTOR
Q305 UMG3N TRANSISTOR
Q306 UPA672T FET
Q307 FP210 TRANSISTOR
Q308 UMG3N TRANSISTOR
Q309 DTA123JE DIGITAL TRANSISTOR
Q310 KTA1298(Y) TRANSISTOR
Q311 UMG3N TRANSISTOR
Q312 DTC144EE DIGITAL TRANSISTOR
Q313 2SK1824 FET
Q314 2SC4617(S) TRANSISTOR
Q315 DTC114EE DIGITAL TRANSISTOR
Q316 DTA144EE DIGITAL TRANSISTOR
Q317 2SC4738(GR) TRANSISTOR
Q318 2SK1824 FET
Q319 DTA144EE DIGITAL TRANSISTOR
Q320 DTC144EE DIGITAL TRANSISTOR
Q321 KTA1298(Y) TRANSISTOR
Q322 2SC4919 TRANSISTOR
Q323 DTC144EE DIGITAL TRANSISTOR
Q324 2SK1588 FET
Q325 DTA123JE DIGITAL TRANSISTOR
TH1 157-503-65001 THERMISTOR
TH301 157-303-65001 THERMISTOR
TH302 157-102-65001 THERMISTOR
S301 W02-3614-05 ENCODER

11
TK-3118
TK-260 :K, K2
TK-260/(N):NK, NK2 Partswithexplodednumberslargerthan700arenotsupplied.
AB
1
2
3
EXPLODED VIEW / 部件分解图
39
35
34
33
36
52
27
25
SP
15
E
30
12
28 31
TX-RX UNIT(C/3)
9
10
G
G
G
G
G
G
11
19
TX-RX UNIT(A/3)
26
1
7
F
F
B
B
8
4
3
14
14
C
23
24
D
TX-RX UNIT(B/3)
A
A
13
S/No. LABEL
37 32
38

12
TK-3118
TK-260 :K, K2
TK-260/(N):NK, NK2
22. HANDSTRAP
(J69-0352-05)
6. INSTRUCTION MANUAL
(B62-1387-10)
H. SCREW SET
(N99-2023-05)
20. BELT HOOK
(J29-0465-04)
21. BAND
(J61-0429-05)
ANT. HELICAL ANTENNA
(T90-0759-05):C
(T90-0760-05):C4
16. PACKING FIXTURE
(H12-3088-05)
17. PROTECTION BAG
(H25-0085-04)
18. ITEM CARTON CASE
(H52-1720-02)
PACKING / 包装

13
TK-3118
TK-260 :K, K2
Required Test Equipment
1. Stabilized Power supply
1. The supply voltage can be changed between 5V and 9V, and
the current is 3A or more.
2. The standard voltage is 7.5V.
2. DC Ammeter
1. Class 1 ammeter (17 ranges and other features).
2. The full scale can be set to either 300mA or 3A.
3. A cable of less internal loss must be used.
3. Frequency Counter (f. counter)
1. Frequencies of up to 1GHz or so can be measured.
2. The sensitivity can be changed to 500MHz or below, and
measurements are highly stable and accurate (0.2ppm or so).
4. Power Meter
1. Measurable frequency : Up to 500MHz
2. Impedance : 50 , unbalanced
3. Measuring range : Full scale of 10W or so
4. A standard cable (5D2W 1m) must be used.
5. RF Voltmeter(RF V.M)
1. Measurable frequency : Up to 500MHz or so.
6. Linear Detector
1. Measurable frequency : Up to 500MHz or so
2. Characteristics are flat, and CN is 60dB or more.
7. Digital Voltmeter
1. Voltage range : FS=18V or so
2. Input resistance : 1M or more
8. Oscilloscope
1. Measuring range : DC to 30MHz
2. Provides highly accurate measurements for 5 to 25MHz.
9. AF Voltmeter (AF V.M)
1. Measurable frequency : 50Hz to 1MHz
2. Maximum sensitivity : 1mV or more
10. Spectrum Analyzer
1. Measuring range : DC to 1GHz or more
11. Standard Signal Generator (SSG)
1. Maximum frequency : 500MHz or more
2. Output : -133dBm/0.05µV to 7dBm/501mV
3. Output impedance : 50
12. Tracking Generator
1. Center frequency : 50kHz to 500MHz
2. Frequency deviation : ±35MHz
3. Output voltage : 100mV or more
13. Dummy Load
1. 8 , 3W or more
14. AF Generator(AG)
1. Frequency range : 100Hz to 100kHz
2. Output : 0.5mV to 1V
15. Distortion Meter
1. Measurable frequency : 30Hz to 100kHz
2. Input level : 50mV to 10Vrms
ADJUSTMENT / 调整
所需的测试设备
1. 稳定电源
1. 输出电源在5V和9V之间可调，并且电流为3A或更大。
2. 标准电压为7.5V。
2. 电流表
1. 高级电流表 (17档和其他功能)。
2. 满刻度可设定为300mA也可设定为3A。
3. 必须使用低损耗电缆。
3. 频率计数器 (f.counter)
1. 可以测量到最大量程大约为1GHz的频率。
2. 灵敏度可调到500MHz或更低，测量为高稳定性和高准确度
(大约为0.2ppm)。
4. 功率仪
1. 可测量的频率：最高到500MHz
2. 阻抗：50Ω，不稳定
3. 测量范围：满刻度大约为10W。
4. 必须使用标准电缆 (5D2W 1m)。
5. 射频电压表 (RF V.M)
1. 频率范围：最高大约到500MHz。
6. 线性检测器
1. 频率范围：最高大约到500MHz。
2. 特征函数是平展的，CN为60dB或更大。
7. 数字电压表
1. 电压范围：大约FS＝18V。
2. 输入阻抗值：1MΩ或更大。
8. 示波器
1. 测量范围：直流到30MHz
2. 5到25MHz间提供高准确度测量。
9. 音频电压表 (AF V.M)
1. 频率范围：50Hz到1MHz
2. 最高灵敏度：1mV或更高
10.频谱分析仪
1. 测量范围：直流到1GHz或更大
11.标准信号发射器 (SSG)
1. 最高频率：500MHz或更高
2. 输出：－133dBm/0.05µV到7dBm/501mV
3. 输出阻抗：50Ω
12.轨迹发生器
1. 中心频率：50kHz到500MHz
2. 频偏：±35MHz
3. 输出电压：100mV或更高
13.假负载
1. 8Ω，3W或更高
14.音频发生器 (AG)
1. 频率范围：100Hz到100kHz
2. 输出：0.5mV到1V
15.失真测试仪
1. 频率范围：30Hz到100kHz
2. 输入电平：50mV到10Vrms

14
TK-3118
TK-260 :K, K2
•Use a non-conductive rod such as a Ceramic rod for
adjustment (especially of trimmers and coils).
Kenwood order No. A-0910 (0.4X0.9mm)
Kenwood order No. A-1310 (0.4X1.3mm)
•To protect the SSG,do not send out signals while
adjusting the receiving unit.
•The indicated SSG output levels are for maximum
output.
Adjustment point
VR1: Frequency adjustment
TC3: Band-pass filter waveform adjustment
TC5: Band-pass filter waveform adjustment
L22: AF level adjustment
LV: Lock voltage adjustment terminal
1st IF: Band-pass filter test point
VR301: DQT waveform adjustment
VR302: Deviation adjustment
VR303: DTMF deviation adjustment
LCD
CPU
CN
CN
CF
ANT
TX-RX A/3 Component side TX-RX B/3
Component side
TX-RX A/3 Foil side
TC3
BATT
VR301
VR
302
VR1
L22 VR
303
TC1
TC2
BATT
TC5
LV
LV
1st IF
1st IF
ADJUSTMENT / 调整
注释:
•在短时间内调整发射压控微调电容器（大约10秒）。当收发
机处于发射模式，并且末级放大器晶体管长时间从机架拔出
时，则可能会对晶体管产生热损伤（无散热器）。
Notes:
•Adjust the TX VCO trimmer within a short period of time
(Appros. 10 seconds). When the transceiver is in TX mode
and the final amplifier transistor is detached from the
chassis for a long time, it may cause thermal damage to the
transistor (No heatsink).
•使用一个专用调整棒进行调整（特别是微调电容器和线
圈）。
建伍订货单号码 A-0910 (0.4X0.9mm)
建伍订货单号码 A-1310 (0.4X1.3mm)
•为了保护标准信号发生器，在调整接收部分时通信机不要发
射。
•显示的标准信号发生器输出电平为最大输出值。
Foil Side View
Componennt Side View
VR1: 频率调整
TC3: 带通滤波器波形调整
TC5: 带通滤波器波形调整
L22: 音频电平调整
LV: 锁定电压调整终端
1st: 带通滤波器测试点
VR301: DQT波形调整
VR302: DEV调整
VR303: DTMF DEV调整
TC1: Transmit lock voltage adjustment
TC2: Receive lock voltage adjustment
TC1: 发射锁定电压调整
TC2: 接收锁定电压调整
1Power / Volume switch 7FUNC key
2LED indicator 8SCAN key
3Channel switch 9LOW key
4PTT switch 0DTMF key
5MONI key -SP/MIC JAC
6DIAL key
1 电源／音量控制器 7 FUNC（功能）键
2 LED指示灯 8 SCAN（扫描）键
3 旋转编码器 9 LOW键
4 PTT（按下通话）开关 0 DTMF（双音多频）键盘
5 MONI（监听器）键 - MIC-SP插孔
6 DIAL（拨号）键
Speaker-
microphone
qe
w
Antenna
r
tu
y
o
i
!0
!1
123A
456B
789C
0D
DIAL
LOW
SCAN
FUNC
V
H
F
F
M
T
R
A
N
S
C
E
I
V
E
R
M
O
D
E
L
T
K
-
2
1
1
8
PTT
MONI
MIC SP

15
TK-3118
TK-260 :K, K2
ADJUSTMENT / 调整
Replacing Q22 (FET TX final)
1. Place Q22 in its location, upside down as shown in figure 1.
Make sure the location of each pin is correct. The bevelled
edge is located between pin 1 and 2. (See the figure below)
Replace the heat conductor sheet (G11-2664-x4) when
replacing Q22.
2. The bottom surface of Q22 must be firmly contacted to the
TX-RX PCB.
Solder each pin onto the top of the metal posts. Make sure
the solder is between the pin and the metal post (Refer to
figure 2).
Note:
•Make sure you are properly grounded while soldering the
Q22.
•Avoid adding excess solder to the metal post.
•Make sure the bottom surface of Q22 is firmly contacted to
the TX-RX PCB.
•The metal posts for the pins are also soldered to the PCB.
So, when you solder the Q22 pins to the metal posts, keep
the soldering time as short as possible so that the posts are
not moved.
重置Q22 (FET 发射终端)
1. 如图1所示，将Q22上下颠倒放在它的对应位置。
每个管脚的位置一定要正确。斜角位于管脚1与管脚2之间。
（如下图所示）
当置换Q22时，重置热导膜（G11-2664-x4）。
2. Q22的底部表面必须与发射-接收PCB紧密结合。
将每个管脚与金属杆的顶端焊接起来。焊剂必须位于管脚与
金属杆之间。（参见图2）
注释：
•当焊接Q22时一定要将焊剂碾磨恰当。
•避免向金属杆添加过多焊剂。
•Q22的底部表面一定要与发射-接收PCB紧密结合。
•管脚所对应的金属杆也要与PCB焊接在一起。
所以，将Q 2 2 管脚与金属杆焊接起来时，尽可能使焊接时间
越短越好，这样金属杆不易被移动。
Fig. 1 / 图1
Fig. 2 / 图2
Wrong! The bottom surface must be firmly contacted to the PCB.
错误！底部表面必须与PCB紧密结合。
Q22
Q22
Excessive soldering / 过度焊接 Good soldering / 焊接良好
Metal post / 金属杆
TC1 1st IF
TC2
LV
Q22
S
GD
1 2
4 3
Bevelled edge / 斜角
Metal post
金属杆
TX-RX UNIT A/3 Foil side
PCB

16
TK-3118
TK-260 :K, K2
Use the KPG-69D programming software for adjustment of the next item in PC MODE (see page 10).
Squelch Level, S meter Level, Lo Power, Hi Power, QT Deviation, DQT Deviation, and Battery warning.
ADJUSTMENT
Parts
TC1
TC2
Method
1.0V (C,C4)
1.0V (C,C4)
Specifications/
Remarks
±0.1V
±0.1V
less than 4.5V
Terminal
CV
Test equipment
Digital voltmeter
Condition
1)Power supply voltage
Battery teriminal:7.5V
1)CH:TX low
2)CH: RX low
3)CH:TX high
4)CH: RX high
Section common to the transmitter and receiver (VCO)
Item
1.Setting
2.VCO lock
voltage
Measurement Adjustment
Parts
TC3,TC5
L22
PC key
PC key
Method
Adjust the spectram waveform
shown Fig1
Adjust to the MAX AF level
Vol.knobposition at 12 o'clock
Check
Adjust to open the squelch.
Adjust to open the squelch.
Adjust to Full digit
Adjust to one digit
Specifications/
Remarks
SINAD: 12dB or
higher
Terminal
ANT
SP
ANT
Test equipment
Tra generator
Spectrum analyzer
SSG
Oscilloscope
AF.V. M
Distortion meter
SSG
Condition
1)CH: RX center
1)CH: RX center
SSG output: -53dBm(501µV)
MOD: 1kHz
DEV: ±3.0kHz
1)CH: RX center
CH: low
CH: high
SSG ouput: -116dBm(0.35µV)
MOD: 1kHz
DEV: ±3.0kHz
1)CH: RX center
2)Level 9
SSG output: -116dBm(0.35µV)
3)Level 1
SSG output: -123dBm(0.16µV)
1)CH: RX center
2)Full digit
SSG output: -110dBm(0.7µV)
3)one Digit
SSG output: -120dBm(0.2µV)
Receiver Section
Item
1.Band-
pass filter
2.AF level
3.Sensitivity
4.Squelch
Level
(PC Mode)
5.S meter
Level
(PC Mode)
Measurement Adjustment
Transmitter section
Item Condition Measurement Adjustment
Specifications/
Test equipment Terminal Parts Method Remark
1. Transmit 1) CH: TX center Frequency ANT VR1 Adjust to center frequency within ±100Hz
frequency PTT: ON counter
2. DQT/QT 1) CH: TX center Modulation analyzer VR301 Rectify the waveform to square
Balance wave
3. Lo Power 1) CH: TX center Power meter PC key Adjust it to 2W within ±0.1W
(PC Mode) CH: TX low Current meter
CH: TX high
4. Hi Power 1) CH: TX center Power meter PC key Adjust it to 5W within ±0.2W
(PC Mode) CH: TX low Current meter
CH: TX high
5. MAX DEV 1) CH: TX center Modulation VR302 Adjust it to ±4.2kHz (Wide) ±100Hz
AG: 1kHz/50mV analyzer 15kHz LPF
AG, AF. V. M Check (Narrow) ±1.9kHz~2.2kHz
6. MIC 1) CH: TX center Check (Wide) ±2.2kHz~3.8kHz
Sensitivity AG: 1kHz/5mV
7. QT 1) CH: TX center Modulation PC key Adjust it to 0.75kHz (Wide) ±0.05Hz
Deviation CH: TX low analyzer 3kHz LPF Adjust it to ±0.35kHz (Narrow) (Wide/Narrow)
(PC Mode) CH: TX high CH: TX Center
QT: 151.4Hz
8. DQT 1) CH: TX center Modulation PC key Adjust it to ±0.75kHz (Wide) ±0.05Hz
Deviation CH: TX low analyzer 3kHz LPF Adjust it to ±0.35kHz (Narrow) (Wide/Narrow)
(PC Mode) CH: TX high CH: TX Center
DQT:023N
9. DTMF 1) CH TX center using [9] key Modulation VR303 Adjust it to 2.5kHz (Wide) ±100Hz
Deviation analyzer 15kH LPF
10.VOX Level PC key Adjust it to [4]
(PC Mode)
11.Battery 1) Battery terminal: 5.5V PC key
Warning
(PC Mode)

SRC POWER
–40.00 dBm
REF –30.0 dBm #AT 0 dB
MKR 470.0 MHz
–60.00 dBm
SPAN 100.0 MHz
#SWP 200msec
#VBW 300 kHz
CENTER 460.0 MHz
#RES BW 10 kHz
PEAK
LOG
10
dB/
18
17
TK-3118 TK-3118
BPF-Wave
调整 ADJUSTMENT / 调整
Fig. 1 / 图1
在计算机模式下使用KPG-69D编程软件调整下记项目 (参见第10页)
噪音抑制电路电平、S计电平、低功率、高功率、QT偏差、DQT偏差、电池警告
发射部和接收部公用部分 (压控振荡器）
部件
TC1
TC2
方法
1.0V
1.0V
规格/备注
±0.1V
±0.1V
低于 4.5V
终端
CV
测试设备
数字电压表
条件
1) 电源电压电池终端：7.5V
1) CH: 发射低端频点
2) CH: 接收低端频点
3) CH: 发射高端频点
4) CH: 接收高端频点
项目
1. 设定
2. 压控振荡
器
测量 调整
部件
TC3,TC5
L22
PC机键
PC机键
方法
调整频谱波形
调整到最大音频电平
音量旋钮位置位于12点
检查
经调整打开静噪
经调整打开静噪
调节成全数字
调节成单数字
规格/备注
SINAD: 12dB或更高
终端
天线
扬声器
天线
测试设备
Tra 发生器
频谱分析仪
标准信号发射器
示波器
音频电压表
失真测试仪
SSG
条件
1) CH: 接收中心频点
1) CH: 接收中心频点
SSG 输出: -53dBm (501µV)
MOD: 1kHz
DEV: ±3.0kHz
1) CH: 接收中心频点
CH: low
CH: high
SSG 输出: -116dBm (0.35µV)
MOD: 1kHz
DEV: ±3.0kHz
1) CH: 接收中心频点
2) 第 9 级
SSG 输出: -116dBm (0.35µV)
3) 第 11 级
SSG 输出: -123dBm (0.16µV)
1) CH: 接收中心频点
2) Full digit
SSG 输出: -110dBm (0.7µV)
3) one Digit
SSG 输出: -120dBm (0.2µV)
接收部
项目
1. 带电滤波
器
2. 音频电平
3. 灵敏度
4. 噪音抑制
电路电平
(计算机模式)
5. S 计电平
(计算机模式)
测量 调整 • TK-3118 (C type)
注释:
•在短时间内调整发射压控微调电容器（大约10秒）。当
收发机处于发射模式，并且末级放大器晶体管长时间从
机架拔出时，则可能会对晶体管产生热损伤（无散热
器）。
Notes:
•Adjust the TX VCO trimmer within a short period of time
(Appros. 10 seconds). When the transceiver is in TX
mode and the final amplifier transistor is detached from
the chassis for a long time, it may cause thermal
damage to the transistor (No heatsink).
ADJUSTMENT FREQUENCY LIST 调整频率请单
发射部
项目 条件 测量 调整 规格/备注
测试设备 终端 部件 方法
1. 发射频率 1) CH: 发射中心频点 频率计数器 天线 VR1 调整频率 ±100Hz以内
PTT: 开启
2. DQT/QT 1) CH: 发射中心频点 频谱分析仪 VR301 将波形整流为方形波
平衡
3. 低功率 1) CH: 发射中心频点 功率表 PC机键 调整到 2W ±0.1W以内
(计算机模式) CH: 发射低频点 电流表
CH: 发射高频点
4. 高功率 1) CH: 发射中心频点 功率表 PC机键 调整到 5W ±0.2W以内
(计算机模式) CH: 发射低频点 电流表
CH: 发射高频点
5. 最大DEV 1) CH: 发射中心频点 频谱分析仪 15kHz LPF VR302 调整到 4.2kHz (宽) ±100Hz
AG: 1kHz/50mV AG, AF. V. M
检查 (窄) ±1.9kHz~2.2kHz
6. 调制 1) CH: 发射中心频点 检查 (宽) ±2.2kHz~3.8kHz
灵敏度 AG: 1kHz/5mV
7. QT
DEV 1) CH: 发射中心频点 频谱分析仪 3kHz LPF PC机键 调整到 0.75kHz (宽) ±0.05Hz
(计算机模式) CH: 发射低频点 调整到 ±0.35kHz (窄) (宽/窄)
CH: 发射高频点 CH: 发射中心频点
QT: 151.4Hz
8. DQT
DEV 1) CH: 发射中心频点 频谱分析仪 3kHz LPF PC机键 调整到 ±0.75kHz (宽) ±0.05Hz
(计算机模式) CH: 发射低频点 调整到 ±0.35kHz (窄) (宽/窄)
CH: 发射高频点 CH: 发射中心频点
DQT:023N
9. DTMF DEV 1) CH TX 中心，使用 [9] 键 频谱分析仪 15kHz LPF VR303 调整到 2.5kHz (宽) ±100Hz
10.VOX 电平 PC机键 调整到 [4]
(计算机模式)
11.电池警告 1) 电池终端: 5.5V PC机键
(计算机模式)
SRC POWER
–40.00 dBm
REF –30.0 dBm #AT 0 dB
MKR 420.0 MHz
–54.86 dBm
MEAS UNCAL
SPAN 100.0 MHz
#SWP 200msec
#VBW 300 kHz
CENTER 410.0 MHz
#RES BW 10 kHz
PEAK
LOG
10
dB/
• TK-3118 (C4 type)
Destination CC4
CH TX f (MHz) RX f (MHz) TX f (MHz) RX f (MHz)
Center 460.00 460.05 410.00 410.05
Low 450.00 450.05 400.00 400.05
Hi 470.00 469.95 420.00 419.95
型式 C C4
信道 发射频率 (MHz) 接收频率 (MHz) 发射频率 (MHz) 接收频率 (MHz)
中心 460.00 460.05 410.00 410.05
低450.00 450.05 400.00 400.05
高470.00 469.95 420.00 419.95

ABCDE FGH I J KLMNOPQRS
1
3
4
5
6
7
8
9
10
11
12
13
14
2
TK-3118 PC BOARD VIEW / PC 板视图
19 20
DISPLAY UNIT (X41-3583-00) Component side view
C600
D101
R310 R309 R308 R307
MIC+
MIC–
D106 D103 D102
D107 D105 D104
R604
R605
R606
R603 R601 R602 R600 D100
SP–
SP+
16
V1 V3
H1 H3 H5
LED
E
SP
V2 V4
H2 H4
SB
MIC
E
SP 1
.oN.feRsserddA
001DH6
101DC6
201DG01
301DE01
401DG21
501DE21
601DD01
701DD21
DISPLAY UNIT (X41-3583-00)
Component side view
DISPLAY UNIT (X41-3583-00) Foil side view
Component side
Foil side

ABCDE FGH I J KLMNOPQRS
1
3
4
5
6
7
8
9
10
11
12
13
14
2
TK-3118
PC BOARD VIEW / PC 板视图
22
21
C159
C149
C141 C139 C130
C138
R135
C152
C140 C237
C131
TC5
L35
R96
R103
R112
R105 R144
R116
R117
R128
R146
R55
R65
R79
R68
R80
IC3 R130
R121
R119
C219
C185
C147
D21
C151
C135
BPF
C145
C133
C189
C200
C137
C126
C116
C202
C80
C54
C129
C163
R92
R85
R81
D18
D17
D16
R90
C172
C169
C174
C173
C218
C223
C206
D26
D25
C182
C226
C201
C199
C205
C51
C32
W1
C197
C187
VR1
C27
C40
C53
C70
C86
C92
C96
C88
C62
C63
L3
L48
L2
L6
R1
R122
R120
R129
R47
R127
D28 R126
L4
L53
C8 C4
Q1
R3
R9
R28
R7
R151
L51
C232
L57
C122
R70or
C243
C121
C125 C134
C127
C18
L63orR138
R98
R83
R77
R78
R72
R75
D3
R59
R115
R118
D19
Q24
R145
L40
L39
L37
L36
R97
Q20
14
23
L44
+
TC3
L47
CN1
C178
C231
C221
C183
C203
C204
C2
C46
C10
D1
C15
C16
C69 C74
L22
C60
C59
C207
CN2
ANT C208
C192
C198
L49 L7
L52
L54
D22
D23
R8
R84
R69
R40
R45
R25
R29 R30
R31
R34
LV
R32
CF1
+
+
C42
+
1 APC/TUNE
UL
CK
DT
EP
TO
3.5C
E
RX
MOD
3.5R
AF
B
E
PABC
E
E
PS
5R
5T
5C
BUSY
SM
23
1
45
8
Q23
Q14 Q6
Q17
S
G
D
IC2
1
89
16
XF1
D15
Q15
E
C
B
L34
F1
BATT+
S100
PTT
MONI
J72-0777-22 A/3 J72-0777-22 C/3
L38
C236
L33 Q13
TX-RX UNIT (X57-6243-XX) -00:C -01:C4 Component side view
.oN.feRsserddA
2CIH11
3CIH8
1QE01
6QJ01
31QJ6
41QH01
51QI5
71QH9
02QE3
12QG5
32QH9
42QF5
1DE01
3DK5
51DJ7
61DK3
71DJ3
81DG3
91DE5
12DC5
22DC7
32DC7
52DC8
62DB8
82DH9
TX-RX UNIT (X57-6243-XX) (A/3)
Component side view DTA144EE
DTC114TE
KTC4082
2SC4738
2SC5108
E
C
B
2SC4988
3
1
4
DTC144EUA
IN
GND
OUT
NJM2904V
8
1
4
5
TA31136FN
1
8
9
16
MA742
3
21
3SK274
D
S
G1
G2
Component side
Foil side
Pattern 1
Pattern 2
Pattern 3
Pattern 4
R70 R84 R138 C243 L63 W1
CYES YES NO NO YES NO
C4 NO NO YES YES NO YES

ABCDE FGH I J KLMNOPQRS
1
3
4
5
6
7
8
9
10
11
12
13
14
2
TK-3118 PC BOARD VIEW / PC 板视图
24
23
C167
C224 C100
C111
C109
C154
C177
C176
C212
C186
R60
R64
R58
R56
R63
R110
R113
R114
R101
L43
L42
L30
R53
R44
R57
R43
R37
R23
R26
R33
R153 C71
C215 C216
C230
R38
R42
L18
L58
L13
L1
R48
R49
Q8
Q7
Q9
Q5
DS
G
1
23
5
C222
C112
C105
C104
C168
C162
C234
C170
C150
C146
C240
C164
C225
C166
C180
C171
L46
C107
D13
C95
C90
C79
C77
C73
C82
C78
C81
C72
L21
R17
R15
R11
C21
R124
R125
Q2
R5
R14
C35
C36 C30
C213
C194
C190
IC1
R123
L50
D24
D27
1
89
16
C7
C33
C44
C47
C26
C14
C25
C68
C217
L59
L23
D9
D7
C66
C91
C11
C12
R158
R157 R156 R155
D2
C6
R6
R154
C1
C45
L31
L28
R62
R61
D14
Q12
1
23
4
C97 +
Q10
Q11
R19
R16
L11
C34
C28
Q3
R2
C102
C101
C103
C99
C87
C50
C43 C41
C49
L20
C75
C65
C98
C93
C85
C83
R50
R51
R46
R41
R21 R22
R52
R39
R36
R137
R108
R54
L25
L26
L24
C64
L60
L17
L10
L12
L5
C9
C5
+
L9
L14
L16
L15
L29 L27
D12
D11
D6
TC1
TC2
Q4
R20
R18
+
+
+C29
C3
C238
L55
R13
R12
R10
C214
X1
R67
C13
C193
C179
C242
R4
L45
Q18
G
S
D
R88 R99
R91
R89
R102
R106
TH1
R152
CN100
1
2
65
E
MONI
NC
E
E
PTT
J72-0777-22 A/3
J72-0777-22 C/3
Q22
G
CN3
CN6 CN5
CN4
D
SS
TX-RX UNIT (X57-6243-XX) -00:C -01:C4 Foil side view
.oN.feRsserddA
1CIO8
2QN01
3QL7
4QJ11
5QJ01
7QI9
8QJ8
9QK8
01QJ7
11QI8
21QK5
81QM3
22QQ4
2DN7
6DK01
7DK31
9DL01
11DK21
21DJ8
31DJ7
41DJ6
42DQ9
72DQ9
TX-RX UNIT (X57-6243-XX) (A/3)
Foil side view
MB15E03SL
1
8
9
16
2SK3476
S
S
D
G
2SK3475
GSD
KTC4082
2SC4617
2SC5066
2SC5108
E
C
B
3SK320
D
S
G1
G2
2SJ243
S
G
D
KRX102U
1
2
3
45
Component side
Foil side
Pattern 1
Pattern 2
Pattern 3
Pattern 4
