Kenwood TK-378G User manual

UHF FM TRANSCEIVER / UHF FM 手持机
TK-378G
©2002-10 PRINTED IN JAPAN
B51-8640-00 (S) 607
SERVICE MANUAL /
维修手册
PARTS LIST .......................................................... 2
EXPLODED VIEW ................................................. 9
PACKING ............................................................ 10
ADJUSTMENT ................................................... 11
PC BOARD VIEWS
TX-RX UNIT (X57-617X-XX) ........................ 23
SCHEMATIC DIAGRAM ..................................... 29
BLOCK DIAGRAM .............................................. 33
LEVEL DIAGRAM ............................................... 35
KNB-14/KNB-15A (Ni-Cd BATTERY) ................ 36
KMC-17/KMC-21 (SPEAKER MICROPHONE) .. 37
SPECIFICATIONS ............................ BACK COVER
M VERSIONS
Helical Antenna
(T90-0743-05): M
(T90-0744-05): M4
Knob
(CHANNEL SELECTOR)
(K29-5434-03)
Knob (VOLUME)
(K29-5332-03)
Cabinet assy
(A02-3508-33)
Button knob (PTT)
(K29-5334-23)
Button knob
(MONI/LAMP)
(K29-5333-13)
零件表 ................................................................... 2
部件分解图 ............................................................ 9
包装 ..................................................................... 10
调整 ..................................................................... 11
PC 板视图
TX-RX 单元 (X57-617X-XX) ........................... 23
原理图 ................................................................. 29
方块图 ................................................................. 33
电平图 ................................................................. 35
KNB-14/KNB-15A (镍－铬电池).......................... 36
KMC-17/KMC-21(扬声器话筒)............................ 37
规格 ..................................................................... 39
CONTENTS 目录目录
目录目录
目录
SUPPLEMENT/ 追补版
This service manual is aimed to revise and update the
information on the PC Board that is used in the TK-378G
transceiver having the serial number 4700201 and the
later serial numbers. Refer to the original TK-378G
(M,M4) service manual (B51-8517-00) for any
information which are not contained in this manual.
此维修手册的目的是修改和更新印刷电路板的资料，它
用于序号 4700201 以后的 TK-378G 对讲机。关于未包
含于此手册的资料请参照 TK-378G (M,M4) 初版维修手
册(B51-8517-00)。

2
TK-378G
PARTS LIST / 零件表
CAPACITORS
1 = Type ... ceramic, electrolytic, etc.
2 = Shape ... round, square, ect.
3 = Temp. coefficient
4 = Voltage rating
5 = Value
6 = Tolerance
Color*
CC45
Capacitor value
010 = 1pF
100 = 10pF
101 = 100pF
102 = 1000pF = 0.001µF
103 = 0.01µF
22
Multiplier
2nd number
1st number
0 = 22pF
CC 45 TH 1H J220
12346
5
Temperature coefficient
Tolerance (More than 10pF)
Voltage rating
Chip capacitors
1
1st Word
Color*
Code DG JKMX Z P No code
LCPRSTU
Black Red Orange Yellow Green Blue Violet
0 -80 -150 -220
+ 40
- 40
+ 80
- 20
+ 100
-0
-330 -470 -750
C
(%)
ppm/
0.25 0.5 2 5 10 20 More than 10µF-10 +50
Less than 4.7µF-10 +75
2nd Word HG
Example : CC45TH = -470
JKL
ppm/ 30 60
0.1 0.25 0.5 1 2
120 250 500
60ppm/
Gode CD FGB
(pF)
(Less than 10pF)
1st word
2nd word A
02.0 2.5 3.15
20 25 31.5
200 250 315
2000 2500 3150
1.0 1.25 1.6
112.5 16
100 125 160
1000 1250 1600
1
2
3
BCD EF
4.0
40
400
4000
G
5.0
50
500
5000
H
6.3
63
630
6300
J
8.0
80
800
8000
K
-
35
-
-
V
(EX) C C 7 3 F S L 1 H 000 J
Refer to the table above.
1 = Type
2 = Shape
5 = Voltage rating
4 = Temp. coefficient
3 = Dimension
6 = Value
7 = Tolerance
7654321
(EX) C K 7 3 F F 1 H 000 Z
7654321
(Chip)(CH,RH<UJ,SL)
(Chip)(B,F)
Chip resistor (Carbon)
(EX) R K 7 3 E B 2 B 000 J
7654321
RESISTORS
(Chip)(B,F)
Carbon resistor (Nomal type)
(EX) R D 1 4 B B 2C 000 J
7654321
1 = Type
2 = Shape
5 = Rating wattage
4 = Temp. coefficient
3 = Dimension
6 = Value
7 = Tolerance
Dimension code L W T
Empty
A
B
C
D
E
F
G
H
L
W
T
0.5
5.0
0.4
3.2
0.3
2.0
0.2
1.25
0.2
1.6
0.2
1.25
0.2
0.8
0.05
0.5 0.05 0.5
0.3
2.5
0.5
5.6
0.5
4.5
0.5
4.5
0.5
4.5
0.2
3.0
0.3
2.0
0.2
1.6
0.05
1.0
0.4
3.2
Less than 2.0
Less than 2.0
Less than 2.0
Less than 1.25
Less than 1.5
Less than 1.25
Less than 1.25
Less than 1.0
Dimension (Chip capacitors)
Dimension (Chip resistor)
Rating wattage
Dimension
Dimension code L W T
E
F
G
H
0.2
1.6
0.2
1.25
0.2
0.8
0.05
0.5
0.1
0.5
0.05
0.35
0.2
3.2
0.3
2.0
0.2
1.6
0.05
1.0
1.0
1.0
Code
2C
2H
2E
Wattage
1/16W
1/2W
1/4W
Code
1J
2B
2A
Wattage
1/16W
1/8W
1/10W
Code
3A
3D
Wattage
1W
2W

TK-378G
3
Parts No. Description Address New
parts
Destination Destination Ref. No. Parts No. Description Address New
parts
Ref. No.
TK-378G
L: Scandinavia K: USA P: Canada
Y: PX (Far East, Hawaii) T: England E: Europe
Y: AAFES (Europe) X: Australia M: Other Areas
PARTS LIST / 零件表
∗New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
TK-378G (Y50-5390-XX)
TX-RX UNIT (X57-6170-XX)
11A∗A02-3508-33 CABINET ASSY
23BA82-0036-02 REAR PANEL
32CB09-0351-03 CAP(SP/MIC)
42DB62-1288-10 INSTRUCTION MANUAL
53A∗B72-1752-14 MODEL NAME PLATE M
53A∗B72-1753-14 MODEL NAME PLATE M4
63BE04-0413-05 RF COAXIAL RECEPTACLE(SMA)
73AE23-1183-04 RELAY TERMINAL(BATT -)
82BE23-1184-04 RELAY TERMINAL(BATT +)
92BE37-0829-05 SPEAKER LEAD ASSY
10 3A E37-0830-05 FLAT CABLE(PTT)
11 2A F10-2302-04 SHIELDING COVER(POWER MODULE)
12 2A F10-2304-03 SHIELDING COVER(TX-RX UNIT)
13 1A G01-0881-04 COIL SPRING(BATT RELEASE)
14 1B G10-1254-04 FIBROUS SHEET(SP)
15 1B ∗G10-1276-04 FIBROUS SHEET(MIC)
16 1A ∗G11-4028-04 SHEET(MONI/LAMP)
17 3A ∗G11-4252-14 SHEET(PTT)
18 2A G13-1783-04 CUSHION(POWER MODULE COVER)
19 3B ∗G13-1865-04 CUSHION(CHASSIS-BATT)
20 2B ∗G13-1866-04 CUSHION(SP)
21 2B,3A ∗G13-1867-14 CUSHION(BATT TERMINAL)
22 1B G53-0882-03 PACKING(SP)
23 3B G53-0883-04 PACKING(BATT TERMINAL +)
24 3B ∗G53-1528-04 PACKING(SMA)
25 1B ∗G53-1529-04 PACKING(VOL/CH)
26 3B G53-1530-02 PACKING(SIDE)
27 2B G53-1531-03 PACKING(SP/MIC)
28 1A G53-1537-04 PACKING(PTT KNOB)
29 1C,2D H12-1487-02 PACKING FIXTURE
30 1D H25-0085-04 PROTECTION BAG (100/200/0.07)
31 2C H25-2012-04 PROTECTION BAG (75/100/0.08)
32 3D H52-1557-02 ITEM CARTON CASE
33 1A J19-1572-04 HOLDER(BATT RELEASE)
34 2B ∗J19-5353-24 HOLDER(BATT TERMINAL +)
35 2B J19-5388-03 HOLDER(VOL/CH)
36 2C J21-4493-04 HARDWARE FIXTURE(SP/MIC)
37 2B J21-8378-04 HARDWARE FIXTURE(SP)
38 2C J21-8393-04 HARDWARE FIXTURE(HAND STRAP)
39 2C J21-8399-04
HARDWARE FIXTURE ASSY(HAND STRAP)
40 2C J29-0658-05 BELT HOOK
41 2A J32-0925-04 HEXAGON BOSS
42 2C J69-0339-05 HAND STRAP
43 2C J69-0349-04 RING(HAND STRAP)
44 1B K29-5332-03 KNOB(VOLUME)
45 1A K29-5333-13 BUTTON KNOB(MONI/LAMP)
46 1A ∗K29-5334-23 BUTTON KNOB(PTT)
47 1A K29-5337-03 LEVER KNOB(BATT RELEASE)
48 1B K29-5434-03 KNOB(16CH)
A3BN09-2319-05 BINDING HEAD SCREW(SMA)
B2A,3A N09-2331-05 SPECIAL SCREW(BATT TERMINAL +)
C1BN14-0582-14 CIRCULAR NUT(SMA)
D1B∗N14-0591-04 CIRCULAR NUT(VOL/CH)
E3AN30-2606-46
PAN HEAD MACHINE SCREW(CHASSIS)
G2AN67-2005-46 PAN HEAD SEMS SCREW W(POWER MODULE)
H 2A,3A,3B N78-2045-46 PAN HEAD TAPTITE SCREW(TX-RX B/2)
I3AN79-2030-46 PAN HEAD TAPTITE SCREW(BATT TERMINAL -)
J2BN83-2005-46 PAN HEAD TAPTITE SCREW(TX-RX A/2)
49 2C N99-2012-05 SCREW SET
VR2 R31-0628-15 VARIABLE RESISTOR(VOLUME)
S1 S60-0416-15 ROTARY SWITCH(16CH)
50 2B T07-0326-05 SPEAKER
51 2D T90-0743-05 HELICAL ANTENNA M
51 2D T90-0744-05 HELICAL ANTENNA M4
D18 B30-2019-05 LED(RED/GREEN)
C1 CK73GB1H471K CHIP C 470PF K
C2 CC73GCH1H020C CHIP C 2.0PF C
C3 CC73GCH1H010B CHIP C 1.0PF B M4
C4 CC73GCH1H0R5B CHIP C 0.5PF B M4
C4,5 CC73GCH1H010B CHIP C 1.0PF B M
C5 CC73GCH1H020B CHIP C 2.0PF B M4
C6 CK73GB1C104K CHIP C 0.10UF K
C8 CC73GCH1H030B CHIP C 3.0PF B
C9 CK73GB1H471K CHIP C 470PF K
C10 CC73GCH1H080B CHIP C 8.0PF B M
C10 CC73GCH1H270G CHIP C 27PF G M4
C11 CC73GCH1H080D CHIP C 8.0PF D M
C11 CC73GCH1H120J CHIP C 12PF J M4
C12 CC73GCH1H070D CHIP C 7.0PF D M
C12 CC73GCH1H110J CHIP C 11PF J M4
C13 CK73GB1H471K CHIP C 470PF K
C14 CC73GCH1H0R5B CHIP C 0.5PF B
C16 CC73GCH1H060B CHIP C 6.0PF B M
C16,17 CC73GCH1H040B CHIP C 4.0PF B M4
C17 CC73GCH1H040B CHIP C 4.0PF B M
C18 CC73GCH1H060B CHIP C 6.0PF B M
C18 CC73GCH1H270J CHIP C 27PF J M4
C20 CC73GCH1H030B CHIP C 3.0PF B M
C20 CC73GCH1H040B CHIP C 4.0PF B M4
C21 CC73GCH1H0R5B CHIP C 0.5PF B M4
C22 CC73GCH1H101J CHIP C 100PF J
C23 CC73GCH1H020B CHIP C 2.0PF B M
C23 CC73GCH1H050B CHIP C 5.0PF B M4
C24 CC73GCH1H030B CHIP C 3.0PF B M
C24,25 CC73GCH1H080B CHIP C 8.0PF B M4
C25 CC73GCH1H040B CHIP C 4.0PF B M
C26 CC73GCH1H020B CHIP C 2.0PF B M4
C26 CC73GCH1H1R5B CHIP C 1.5PF B M
C27 CC73GCH1H0R5B CHIP C 0.5PF B
C28 CC73GCH1H060D CHIP C 6.0PF D M
C28 CC73GCH1H070D CHIP C 7.0PF D M4
C29 CC73GCH1H220J CHIP C 22PF J
C30 CC73GCH1H060D CHIP C 6.0PF D M
TX-RX UNIT (X57-6170-XX) -20:M, -21:M4

TK-378G
4
Ref. No. Parts No. Description
Address New
parts
Ref. No. Parts No. Description
Address New
parts Destination Destination
TX-RX UNIT (X57-6170-XX)
PARTS LIST / 零件表
C30 CC73GCH1H080D CHIP C 8.0PF D M4
C31 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C32 CK73GB1C104K CHIP C 0.10UF K
C33 CC73GCH1H060B CHIP C 6.0PF B M
C33 CC73GCH1H080B CHIP C 8.0PF B M4
C35-41 CK73GB1H471K CHIP C 470PF K
C42-44 CC73GCH1H101J CHIP C 100PF J
C45 CK73GB1H471K CHIP C 470PF K
C48,49 C92-0001-05 CHIP-C 0.1UF 35WV
C51 C92-0004-05 CHIP-TAN 1.0UF 16WV M
C51 C92-0585-05 CHIP-TAN 4.7UF 16WV M4
C52 CC73GCH1H030B CHIP C 3.0PF B M4
C52 CC73GCH1H040B CHIP C 4.0PF B M
C53 CK73GB1H471K CHIP C 470PF K
C54 CK73FB1C474K CHIP C 0.47UF K
C55 CK73GB1H471K CHIP C 470PF K
C57 CK73FB1C474K CHIP C 0.47UF K
C58 CK73GB1H103K CHIP C 0.010UF K
C60 CK73GB1H103K CHIP C 0.010UF K
C62 CC73GCH1H560J CHIP C 56PF J
C63 CC73GCH1H070B CHIP C 7.0PF B
C64 CC73GCH1H010B CHIP C 1.0PF B
C68 C92-0565-05 CHIP-TAN 6.8UF 10WV
C70 CK73GB1H103K CHIP C 0.010UF K
C71 CC73GCH1H101J CHIP C 100PF J
C72 CC73GCH1H180J CHIP C 18PF J M4
C72 CC73GCH1H330G CHIP C 33PF G M
C73 CK73GB1H471K CHIP C 470PF K
C74 CK73FB1E104K CHIP C 0.10UF K
C75 CK73GB1H471K CHIP C 470PF K
C76 CK73GB1H102K CHIP C 1000PF K
C77 CC73GCH1H010B CHIP C 1.0PF B M4
C77 CC73GCH1H030B CHIP C 3.0PF B M
C78 CC73GCH1H470J CHIP C 47PF J
C81 CC73GCH1H010C CHIP C 1.0PF C
C82 CK73GB1H102K CHIP C 1000PF K M
C84,85 CK73GB1H471K CHIP C 470PF K
C86,87 CC73GCH1H100D CHIP C 10PF D
C88 CC73GCH1H040B CHIP C 4.0PF B
C89 CC73GCH1H070B CHIP C 7.0PF B
C90 C92-0560-05 CHIP-TAN 10UF 6.3WV
C94 C92-0560-05 CHIP-TAN 10UF 6.3WV
C95,96 CK73GB1H471K CHIP C 470PF K
C98 C92-0560-05 CHIP-TAN 10UF 6.3WV
C99 CK73GB1C104K CHIP C 0.10UF K
C100 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C101 CK73GB1H471K CHIP C 470PF K
C104 CK73GB1H471K CHIP C 470PF K
C107,108 CK73GB1C104K CHIP C 0.10UF K
C109 C92-0560-05 CHIP-TAN 10UF 6.3WV
C110 CK73GB1H103K CHIP C 0.010UF K
C111 CK73GB1H471K CHIP C 470PF K
C112 CC73GCH1H050B CHIP C 5.0PF B
C113 CK73GB1H471K CHIP C 470PF K
C114 CK73GB1H391K CHIP C 390PF K
C115 CK73GB1C104K CHIP C 0.10UF K
C116 CK73GB1H471K CHIP C 470PF K M4
C118 CK73GB1H471K CHIP C 470PF K
C119 CK73FB1A105K CHIP C 1.0UF K
C120,121 CK73GB1H471K CHIP C 470PF K
C122 CK73FB1A105K CHIP C 1.0UF K
C123 CK73GB1H391K CHIP C 390PF K
C124 CC73GCH1H390J CHIP C 39PF J
C125,126 CK73GB1H103K CHIP C 0.010UF K
C128 CC73GCH1H040C CHIP C 4.0PF C
C130 CK73GB1H471K CHIP C 470PF K
C131 CC73GCH1H100D CHIP C 10PF D
C132 CK73GB1H103K CHIP C 0.010UF K
C133 CC73GCH1H820J CHIP C 82PF J
C135 CK73GB1H103K CHIP C 0.010UF K
C136 CC73GCH1H060B CHIP C 6.0PF B M4
C136 CC73GCH1H080B CHIP C 8.0PF B M
C137 CK73GB1H471K CHIP C 470PF K
C138 CK73GB1C104K CHIP C 0.10UF K
C139 CC73GCH1H181J CHIP C 180PF J
C140 CK73GB1H103K CHIP C 0.010UF K
C141 CK73GB1C104K CHIP C 0.10UF K
C142 CK73FB1A105K CHIP C 1.0UF K
C143,144 CK73GB1H471K CHIP C 470PF K
C146,147 CK73GB1C104K CHIP C 0.10UF K
C148 CK73GB1H103K CHIP C 0.010UF K
C150 CK73GB1H102K CHIP C 1000PF K
C151-153 CK73GB1H471K CHIP C 470PF K
C155 C92-0662-05 CHIP-TAN 15UF 6.3WV
C156,157 CK73GB1H471K CHIP C 470PF K
C158 CK73FB1A105K CHIP C 1.0UF K
C159 CK73GB1H471K CHIP C 470PF K
C161 CK73GB1H471K CHIP C 470PF K
C162 CK73GB1H103K CHIP C 0.010UF K
C163,164 CK73GB1H471K CHIP C 470PF K
C165 CK73GB1H103K CHIP C 0.010UF K
C166 CK73FF1E104Z CHIP C 0.10UF Z
C167 CK73GB1H471K CHIP C 470PF K
C170,171 CK73GB1H471K CHIP C 470PF K
C173 C92-0567-05 CHIP-TAN 68UF 6.3WV
C174 CK73GB1H471K CHIP C 470PF K
C176 CC73GCH1H101J CHIP C 100PF J
C177 CK73GB1C473K CHIP C 0.047UF K
C178 C92-0560-05 CHIP-TAN 10UF 6.3WV
C179 CK73GB1C104K CHIP C 0.10UF K
C180 CK73GB1H103K CHIP C 0.010UF K
C181 CK73GB1C393K CHIP C 0.039UF K
C182 CK73GB1H102K CHIP C 1000PF K
C183,184 CK73GB1C104K CHIP C 0.10UF K
C185 CC73GCH1H180J CHIP C 18PF J
C189 CK73GB1H103K CHIP C 0.010UF K
C190,191 CK73GB1C104K CHIP C 0.10UF K
C192,193 CC73GCH1H300J CHIP C 30PF J
C194 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C196 CC73GCH1H101J CHIP C 100PF J
C198,199 CK73GB1H103K CHIP C 0.010UF K
C200 CK73GB1A224K CHIP C 0.22UF K
C201 CK73GB1H103K CHIP C 0.010UF K
C202,203 CK73GB1C104K CHIP C 0.10UF K
C204 CK73FB1C474K CHIP C 0.47UF K
C205 CK73GB1H103K CHIP C 0.010UF K
C206-208 CK73GB1C104K CHIP C 0.10UF K
C209 CK73GB1H392K CHIP C 3900PF K
C210 CK73GB1H102K CHIP C 1000PF K
C211 C92-0507-05 CHIP-TAN 4.7UF 6.3WV

TK-378G
5
Ref. No. Parts No. Description
Address New
parts
Ref. No. Parts No. Description
Address New
parts Destination Destination
TX-RX UNIT (X57-6170-XX)
PARTS LIST / 零件表
C212 CK73GB1H122K CHIP C 1200PF K
C213 CK73GB1H103K CHIP C 0.010UF K
C215 CK73GB1C104K CHIP C 0.10UF K
C216 CK73GB1H392K CHIP C 3900PF K
C217 CK73GB1E153K CHIP C 0.015UF K
C218 CK73FB1H563K CHIP C 0.056UF K
C219,220 CK73GB1C104K CHIP C 0.10UF K
C221 CK73GB1H471K CHIP C 470PF K
C222 CK73GB1H103K CHIP C 0.010UF K
C223 C92-0560-05 CHIP-TAN 10UF 6.3WV
C224 CK73GB1H122K CHIP C 1200PF K
C225 CC73GCH1H101J CHIP C 100PF J
C226,227 CK73GB1H562J CHIP C 5600PF J
C229 CK73FB1H471K CHIP C 470PF K
C230 CK73GB1H562J CHIP C 5600PF J
C231 C92-0521-05 CHIP-TAN 0.47UF 20WV
C232 CK73GB1H471K CHIP C 470PF K
C233 CC73GCH1H151J CHIP C 150PF J
C234,235 CK73GB1H272J CHIP C 2700PF J
C236 CK73GB1C104K CHIP C 0.10UF K
C238 CK73GB1H392K CHIP C 3900PF K
C239 CK73GB1C683K CHIP C 0.068UF K
C240 CK73GB1H272J CHIP C 2700PF J
C241 CK73GB1H471K CHIP C 470PF K
C242 C92-0560-05 CHIP-TAN 10UF 6.3WV
C243 CK73FB1A105K CHIP C 1.0UF K
C244 C92-0560-05 CHIP-TAN 10UF 6.3WV
C245 CK73GB1H471K CHIP C 470PF K
C246 CK73FB1A105K CHIP C 1.0UF K
C247 CK73GB1E123K CHIP C 0.012UF K
C248 CK73GB1H103K CHIP C 0.010UF K
C249 CK73GB1H222K CHIP C 2200PF K
C250 CK73GB1C683K CHIP C 0.068UF K
C251 CK73GB1C104K CHIP C 0.10UF K
C252 CK73GB1C473K CHIP C 0.047UF K
C253,254 CK73GB1H103K CHIP C 0.010UF K
C255 CK73GB1H183K CHIP C 0.018UF K
C257 CK73GB1E153K CHIP C 0.015UF K
C258 CK73GB1C333K CHIP C 0.033UF K
C259 CC73GCH1H121J CHIP C 120PF J
C260 CK73GB1H183K CHIP C 0.018UF K
C261 CK73GB1E153K CHIP C 0.015UF K
C262 CK73GB1H102K CHIP C 1000PF K
C263 CK73GB1C104K CHIP C 0.10UF K
C265,266 CK73GB1C104K CHIP C 0.10UF K
C268 CK73GB1H102K CHIP C 1000PF K
C269 CK73GB1H152K CHIP C 1500PF K
C270 CK73GB1H222K CHIP C 2200PF K
C271 CK73GB1H102K CHIP C 1000PF K
C302 CC73GCH1H010B CHIP C 1.0PF B M
C302 CC73GCH1H020B CHIP C 2.0PF B M4
C303 CC73GCH1H020B CHIP C 2.0PF B M
C303 CC73GCH1H220G CHIP C 22PF G M4
C304 CC73GCH1H150G CHIP C 15PF G M
C304 CK73GB1H471K CHIP C 470PF K M4
C305,306 CC73GCH1HR75B CHIP C 0.75PF B M4
C305,306 CC73GCH1H0R5B CHIP C 0.5PF B M
C307 CC73GCH1H220J CHIP C 22PF J
C309 CK73GB1H471K CHIP C 470PF K
C311 CC73GCH1H020B CHIP C 2.0PF B M
C311 CC73GCH1H030B CHIP C 3.0PF B M4
C312 CC73GCH1H010B CHIP C 1.0PF B M4
C312 CC73GCH1H040B CHIP C 4.0PF B M
C314 CC73GCH1H030B CHIP C 3.0PF B M
C316,317 CK73GB1H471K CHIP C 470PF K
C319 CK73GB1H471K CHIP C 470PF K M4
C320 CC73GCH1H030B CHIP C 3.0PF B M4
C325,326 CK73GB1H471K CHIP C 470PF K
C327 CC73GCH1H080B CHIP C 8.0PF B M
C327 CC73GCH1H120G CHIP C 12PF G M4
C328,329 CK73GB1H471K CHIP C 470PF K M4
C330,331 CC73GCH1H050B CHIP C 5.0PF B M4
C332 CC73GCH1H040B CHIP C 4.0PF B M4
TC1,2 C05-0384-05 CERAMIC TRIMMER CAP(10PF)
TC301-303 C05-0383-05 CERAMIC TRIMMER CAP(6PF) M
TC301,302 C05-0383-05 CERAMIC TRIMMER CAP(6PF) M4
TC303 C05-0382-05 CERAMIC TRIMMER CAP(3PF) M4
CN1 E40-6067-05 PIN ASSY SOCKET
CN3 E40-5662-05 PIN ASSY SOCKET
CN5 E40-5932-05 PIN ASSY SOCKET
CN6 E23-0342-05 TEST TERMINAL
J1 E11-0457-05 PHONE JACK(2.5/3.5)
F1 F53-0130-05 FUSE(3A)
F1 F53-0217-05 FUSE(3A)
CD1 L79-1474-05 TUNING COIL
CF1 L72-0968-05 CERAMIC FILTER
CF2 L72-0969-05 CERAMIC FILTER
L1 L40-1875-92 SMALL FIXED INDUCTOR(18NH) M
L1 L40-2275-92 SMALL FIXED INDUCTOR(22NH) M4
L2 L92-0138-05 FERRITE CHIP
L3 L40-3391-86 SMALL FIXED INDUCTOR(3.3UH)
L4 L33-0744-05 SMALL FIXED INDUCTOR
L5-7 L34-4547-05 AIR-CORE COIL M
L5,6 L34-4547-05 AIR-CORE COIL M4
L7 L34-4546-05 AIR-CORE COIL M4
L8 L40-1575-92 SMALL FIXED INDUCTOR(15NH)
L9 L40-1075-92 SMALL FIXED INDUCTOR(10NH) M
L9 L40-1275-92 SMALL FIXED INDUCTOR(12NH) M4
L10 L40-1095-34 SMALL FIXED INDUCTOR(1UH)
L11 L40-1092-81 SMALL FIXED INDUCTOR
L12 L40-2702-86 SMALL FIXED INDUCTOR(27UH) M4
L12 L40-3391-86 SMALL FIXED INDUCTOR(3.3UH) M
L14 L40-1875-92 SMALL FIXED INDUCTOR(18NH)
L15 L40-2275-92 SMALL FIXED INDUCTOR(22NH) M
L15 L40-2775-92 SMALL FIXED INDUCTOR(27NH) M4
L17 L34-4547-05 AIR-CORE COIL
L18-20 L92-0138-05 FERRITE CHIP
L21 L40-1875-92 SMALL FIXED INDUCTOR(18NH)
L22 L40-1085-92 SMALL FIXED INDUCTOR(100NH) M
L22 L40-1885-92 SMALL FIXED INDUCTOR(180NH) M4
L23 L92-0138-05 FERRITE CHIP
L24 L40-5681-86 SMALL FIXED INDUCTOR(0.56UH)
L25 L40-1085-92 SMALL FIXED INDUCTOR(100NH) M
L25 L40-1885-92 SMALL FIXED INDUCTOR(180NH) M4
L26 L33-0744-05 SMALL FIXED INDUCTOR M
L26 L33-0745-05 SMALL FIXED INDUCTOR M4
L27 L92-0149-05 FERRITE CHIP
L30 L40-2702-86 SMALL FIXED INDUCTOR(27UH)
L31 L40-1085-92 SMALL FIXED INDUCTOR(100NH) M
