Kenwood TK-868G User manual

Document Copyrights
Copyright 2006 by Kenwood Corporation. All rights reserved.
No part of this manual may be reproduced, translated, distributed, or transmitted in any
form or by any means, electronic, mechanical, photocopying, recording, or otherwise, for
any purpose without the prior written permission of Kenwood.
Disclaimer
While every precaution has been taken in the preparation of this manual, Kenwood
assumes no responsibility for errors or omissions. Neither is any liability assumed for
damages resulting from the use of the information contained herein. Kenwood reserves
the right to make changes to any products herein at any time for improvement purposes.
文档版权信息
Kenwood Corporation 拥有版权 2006。保留所有权利。
未经 Kenwood 公司预先书面同意，无论出于何种目的，均不得以任何形式或任何方式包
括电子、机械、影印、录音或其他方式复制、翻译、分发或传播本手册的任何部分。
免责声明
Kenwood 公司在准备本文档时已采取所有必要的预防措施，恕不对错误或疏漏承担任何
责任，也不对因使用本文中所含的信息而导致的损害负责。Kenwood 公司保留出于改进
的需要而随时对文中的产品信息做出更改的权利。

Panel assy
(A62-0731-03)
Key top
(K29-5344-02)
© 2006-1 PRINTED IN JAPAN
B51-8754-00 (N)PDF
UHF FM TRANSCEIVER / UHF
TK-868G
8 channels / 8
SERVICE MANUAL /
 !
PARTS LIST ................................................ 2
PC BOARD
DISPLAY UNIT (X54-3280-10) ............. 10
PLL/VCO (X58-4670-17)....................... 11
TX-RX UNIT (X57-5963-02) (A/2) ........ 12
TX-RX UNIT (X57-5963-02) (B/2) ........ 16
SCHEMATIC DIAGRAM........................... 18
KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK O
m`
afpmi^v=EuRQJPOUMJNMF KKKKKKKKKKKKKKKKKKKK NM
miiLs`l=EuRUJQSTMJNTF KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKNN
quJou=EuRTJRVSPJMOFE^LOF KKKKKKKKKKKK NO
quJou=EuRTJRVSPJMOFE_LOF KKKKKKKKKKKK NS
KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK NU

CONTENTS
This supplement edition service manual provides revisions
(schematic, printed board figure, and bill of material) only
for the M type of the TK-868G M, M3 version manual (B51-
8502-00). Refer to the TK-868G manual (B51-8502-00) for
all other details. This is applicable for all models from se-
rial number 70600001 and onwards.
 !"#$%&'()*jqhJUSUd=jjP
E_RNJURMOJMMF= =E !"#$%&'(F !
 !qhJUSUd=E_RNJURMOJMMF !"#$%&
TMSMMMMN !"#$
SUPPLEMENT /

M version

TK-868G
2
PARTS LIST / 
✽New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L: Scandinavia K:USA P:Canada
Y: PX (Far East, Hawaii) T:England E:Europe
Y:AAFES (Europe) X:Australia M:Other Areas
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
TK-868G (M)
DISPLAY UNIT (X54-3280-10), TX-RX UNIT (X57-5963-02)
11B✽A01-2165-23 CABINET UPPER
22A✽A01-2166-23 CABINET LOWER
32AA62-0731-03 PANEL ASSY
62BB11-1230-03 ILLUMINATION GUIDE
72AB38-0825-05 LCD
82D✽B62-1259-20 INSTRUCTION MANUAL
91C✽B72-1698-24 MODEL NAME-PLATE
11 2B E29-1183-04 INTER CONNECTOR
12 1C E30-2145-15 ANTENNA CABLE
-E30-3404-05 TRUNK CABLE
14 1C E30-7562-05 DC CORD RADIO
16 1C E37-0790-25 LEAD WIRE WITH CONNECTOR (SP)
17 2B E37-0815-05 FLAT CABLE
-✽E37-0852-15 LEAD WIRE WITH CONNECTOR (15P)
-✽E37-0853-15 LEAD WIRE WITH CONNECTOR (10P)
-E37-0854-15 LEAD WIRE WITH CONNECTOR (8P)
-E37-0855-15 LEAD WIRE WITH CONNECTOR (3P)
18 2B F12-0435-04 CONDUCTIVE SHEET
-F51-0016-15 FUSE (6X30,10A)
21 1C G02-0791-04 FLAT SPRING AF, APC
22 1B,1C G10-1221-04 FIBROUS SHEET SIDE
23 1B G10-1222-14 FIBROUS SHEET UP,DOWN
24 1A,2C G10-1223-14 FIBROUS SHEET SHIELD
26 1C G13-1468-04 CUSHION DC COARD
26 1B G13-1759-04 CUSHION SP
27 2C G53-0796-04 PACKING PHONE JACK
28 2B G53-0889-04 PACKING DISPLAY UNIT
30 2D H10-6618-12 POLYSTYRENE FOAMED FIXTURE (F)
31 1E H10-6619-12 POLYSTYRENE FOAMED FIXTURE (R)
33 2E H25-0720-04 PROTECTION BAG (200X350)
34 3E H52-1520-02 ITEM CARTON CASE
37 2A J21-8382-03 HARDWARE FIXTURE
40 2A K29-5344-02 KEY TOP
A2A,1B N33-2606-45 OVAL HEAD MACHINE SCREW
B2CN67-3008-46 PAN HEAD SEMS SCREW
C2B,1C N87-2606-46 BRAZIER HEAD TAPTITE SCREW
D2BN87-2612-46 BRAZIER HEAD TAPTITE SCREW
44 1B T07-0368-15 SPEAKER
D801 B30-2204-05 LED (RED/YELLOW)
D803 B30-2220-05 LED (2P/YELLOW)
D804 B30-2204-05 LED (RED/YELLOW)
C801 CK73GB1H471K CHIP C 470PF K
C802-804 CC73GCH1H101J CHIP C 100PF J
C805 CK73GF1A105Z CHIP C 1.0UF Z
C806 CK73GB1H471K CHIP C 470PF K
C807 CK73GB1H102K CHIP C 1000PF K
C808 CK73GB1H471K CHIP C 470PF K
C812 CK73GB1H471K CHIP C 470PF K
CN801 E40-6020-05 PIN ASSY
L801 L92-0138-05 FERRITE CHIP
R801,802 RK73GB2A103J CHIP R 10K J 1/10W
R803 RK73FB2B123J CHIP R 12K J 1/8W
R804 RK73GB2A103J CHIP R 10K J 1/10W
R805 RK73FB2B332J CHIP R 3.3K J 1/8W
R806 RK73GB2A474J CHIP R 470K J 1/10W
R807 RK73GB2A000J CHIP R 0.0 J 1/10W
R808 RK73GB2A393J CHIP R 39K J 1/10W
R809 RK73FB2B123J CHIP R 12K J 1/8W
R810 RK73FB2B332J CHIP R 3.3K J 1/8W
R812 RK73FB2B561J CHIP R 560 J 1/8W
R813-816 RK73GB2A473J CHIP R 47K J 1/10W
D802 MA2S111 DIODE
IC801 LC75833W IC
Q801-803 DTA114EKA DIGITAL TRANSISTOR
Q804 KRA225S TRANSISTOR
Q805 DTA114EKA DIGITAL TRANSISTOR
Q806-809 2SK1824 FET
D509-514 B30-2050-05 LED
D521 B30-2151-05 LED (RED/GRN)
C1-11 CK73GB1H471K CHIP C 470PF K
C13-19 CK73GB1H471K CHIP C 470PF K
C20 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C21 CK73GB1H471K CHIP C 470PF K
C22 CK73GB1C104K CHIP C 0.10UF K
C23,24 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C25 CC73GCH1H060D CHIP C 6.0PF D
C26 CK73GB1H471K CHIP C 470PF K
C28 CC73GCH1H060D CHIP C 6.0PF D
C29 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C30 CC73GCH1H020B CHIP C 2.0PF B
C31 CK73GB1H102K CHIP C 1000PF K
C32 C92-0662-05 CHIP-TAN 15UF 6.3WV
C33 CC73GCH1H220J CHIP C 22PF J
C34 CK73GB1A105K CHIP C 1.0UF K
C35 CK73GB1C104K CHIP C 0.10UF K
C36 CK73GB1H102K CHIP C 1000PF K
C37 CK73FB1C334K CHIP C 0.33UF K
C39 CK73GB1C104K CHIP C 0.10UF K
C40 CK73GB1H102K CHIP C 1000PF K
C41 CK73GB1H103K CHIP C 0.010UF K
C43 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C44 CK73GB1H331K CHIP C 330PF K
C45 CC73GCH1H470J CHIP C 47PF J
C46 CK73GB1H103K CHIP C 0.010UF K
TK-868G
DISPLAY UNIT (X54-3280-10)
TX-RX UNIT (X57-5963-02)

TK-868G
3
PARTS LIST / 
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
C47 C92-0561-05 CHIP-ELE 22UF 16WV
C49 CK73GB1H102K CHIP C 1000PF K
C51 CK73GB1C104K CHIP C 0.10UF K
C52 CC73GCH1H680J CHIP C 68PF J
C53 CK73GB1C104K CHIP C 0.10UF K
C54 CK73GB1H103K CHIP C 0.010UF K
C55 CC73GCH1H010B CHIP C 1.0PF B
C56 CC73GCH1H220J CHIP C 22PF J
C58 CK73GB1E223K CHIP C 0.022UF K
C60 CK73GB1H102K CHIP C 1000PF K
C61 CC73GCH1H050C CHIP C 5.0PF C
C62 CC73GCH1H101J CHIP C 100PF J
C63 CK73GB1C104K CHIP C 0.10UF K
C64 CK73GB1H103K CHIP C 0.010UF K
C66 CK73GB1H102K CHIP C 1000PF K
C67 CK73GB1A105K CHIP C 1.0UF K
C68 CC73GCH1H101J CHIP C 100PF J
C69 CK73GB1C104K CHIP C 0.10UF K
C70 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C71 CC73GCH1H101J CHIP C 100PF J
C72 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C73 CC73GCH1H101J CHIP C 100PF J
C74,75 CK73GB1H471K CHIP C 470PF K
C77 C92-0610-05 ELECTRO 22UF 16WV
C78 CK73GB1C104K CHIP C 0.10UF K
C79,80 CK73GB1H102K CHIP C 1000PF K
C81 CK73GB1H471K CHIP C 470PF K
C82 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C83 CC73GCH1H270J CHIP C 27PF J
C84 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C86 C92-0662-05 CHIP-TAN 15UF 6.3WV
C87 CC73GCH1H330J CHIP C 33PF J
C88 CK73GB1H103K CHIP C 0.010UF K
C89 CK73GB1H471K CHIP C 470PF K
C91 CC73GCH1H020B CHIP C 2.0PF B
C93 C92-0555-05 CHIP-TAN 0.047UF 35WV
C95,96 CK73GB1H471K CHIP C 470PF K
C97 C92-0546-05 CHIP-TAN 68UF 6.3WV
C98 CK73GB1H103K CHIP C 0.010UF K
C99 C92-0008-05 CHIP-TAN 3.3UF 16WV
C100 CC73GCH1H020B CHIP C 2.0PF B
C101 CK73GB1H471K CHIP C 470PF K
C102 CC73GCH1H020B CHIP C 2.0PF B
C103 CK73GB1H471K CHIP C 470PF K
C104 C92-0555-05 CHIP-TAN 0.047UF 35WV
C105 CC73GCH1H100D CHIP C 10PF D
C106 CC73GCH1H180J CHIP C 18PF J
C107 CK73GB1H471K CHIP C 470PF K
C108 CC73GCH1H050B CHIP C 5.0PF B
C109 CK73GB1H471K CHIP C 470PF K
C111 CC73GCH1H030C CHIP C 3.0PF C
C112 CK73GB1H471K CHIP C 470PF K
C113 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C114 C92-0697-05 CHIP-TAN 3.3UF 16WV
C115 C92-0001-05 CHIP-TAN 0.1UF 35WV
C116 CK73GB1H103K CHIP C 0.010UF K
C117 CK73GB1H102K CHIP C 1000PF K
C118 CC73GCH1H040C CHIP C 4.0PF C
C119 CK73GB1H103K CHIP C 0.010UF K
C120 CC73GCH1H040C CHIP C 4.0PF C
C121 CK73GB1H471K CHIP C 470PF K
C122,123 CK73GB1C104K CHIP C 0.10UF K
C125 C92-0005-05 CHIP-TAN 2.2UF 6.3WV
C126 CC73GCH1H120J CHIP C 12PF J
C127 CK73GB1H103K CHIP C 0.010UF K
C128 C92-0543-05 CHIP-TAN 3.3UF 10WV
C129 CK73FF1C105Z CHIP C 1.0UF Z
C130 CK73GB1H103K CHIP C 0.010UF K
C131 CK73GB1H102K CHIP C 1000PF K
C133 CK73GB1H471K CHIP C 470PF K
C134 CK73FB1E104K CHIP C 0.10UF K
C135 CC73GCH1H180J CHIP C 18PF J
C138 CK73FB1E104K CHIP C 0.10UF K
C139,140 CK73GB1H471K CHIP C 470PF K
C141 C92-0719-05 ELECTRO 47UF 25WV
C142 CC73GCH1H010C CHIP C 1.0PF C
C143 CK73GB1H471K CHIP C 470PF K
C144 CK73GB1H102K CHIP C 1000PF K
C145 CC73GCH1H050C CHIP C 5.0PF C
C146 CK73GB1H471K CHIP C 470PF K
C148,149 CK73GB1H471K CHIP C 470PF K
C150 CK73FF1C105Z CHIP C 1.0UF Z
C152 CC73GCH1H060D CHIP C 6.0PF D
C153 CC73GCH1H040C CHIP C 4.0PF C
C154 CK73GB1H102K CHIP C 1000PF K
C155 CC73GCH1H060D CHIP C 6.0PF D
C156 CK73GB1H471K CHIP C 470PF K
C157 CK73GB1H102K CHIP C 1000PF K
C158 CK73GB1H471K CHIP C 470PF K
C160,161 C92-0719-05 ELECTRO 47UF 25WV
C162,163 CK73GB1H471K CHIP C 470PF K
C164 CK73GB1H102K CHIP C 1000PF K
C165 C92-0719-05 ELECTRO 47UF 25WV
C166 CE04EW1E471M ELECTRO 470UF 25WV
C167 CK73GB1H471K CHIP C 470PF K
C168 CC73GCH1H060D CHIP C 6.0PF D
C169 CK73GB1H471K CHIP C 470PF K
C172 CE04EW1E471M ELECTRO 470UF 25WV
C173 CK73GB1C104K CHIP C 0.10UF K
C174 CK73GB1H471K CHIP C 470PF K
C177 CC73FCH1H220J CHIP C 22PF J
C178 CC73GCH1H060D CHIP C 6.0PF D
C179 CK73GB1H471K CHIP C 470PF K
C181,182 CK73GB1H471K CHIP C 470PF K
C183 CK73GB1C104K CHIP C 0.10UF K
C185 CK73GB1C104K CHIP C 0.10UF K
C186 CK73GB1H471K CHIP C 470PF K
C187 CC73GCH1H060D CHIP C 6.0PF D
C189 CC73FCH1H040C CHIP C 4.0PF C
C190 CK73GB1H471K CHIP C 470PF K
C192 CK73GB1H103K CHIP C 0.010UF K
C196 CK73GB1H471K CHIP C 470PF K
C198 C92-0719-05 ELECTRO 47UF 25WV
C199 ✽CK73GB1E154K CHIP C 0.15UF K
C201 CK73GB1H471K CHIP C 470PF K
C202 CK73GB1C104K CHIP C 0.10UF K
C203 CK73GB1H471K CHIP C 470PF K
C204 C92-0004-05 CHIP-TAN 1.0UF 16WV
C206 CK73GB1H102K CHIP C 1000PF K
C207 CK73GB1H103K CHIP C 0.010UF K
TX-RX UNIT (X57-5963-02)

TK-868G
4
PARTS LIST / 
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
C208 CC73GCH1H050C CHIP C 5.0PF C
C209 CC73FCH1H050C CHIP C 5.0PF C
C210 CK73GB1H103K CHIP C 0.010UF K
C211 CC73GCH1H180J CHIP C 18PF J
C212 CK73GB1H471K CHIP C 470PF K
C213 C93-0550-05 CHIP C 1.0PF C
C215 CC73FCH1H060D CHIP C 6.0PF D
C216 CC73GCH1H0R5B CHIP C 0.5PF B
C217 CC73GCH1H020B CHIP C 2.0PF B
C218 CK73GB1C104K CHIP C 0.10UF K
C219 CC73FCH1H040C CHIP C 4.0PF C
C220 CK73GB1H471K CHIP C 470PF K
C221 C93-0550-05 CHIP C 1.0PF C
C222 CC73GCH1H0R5B CHIP C 0.5PF B
C223 CC73GCH1H020B CHIP C 2.0PF B
C224 CK73GB1H471K CHIP C 470PF K
C225 C93-0603-05 CHIP C 1000PF K
C226 C93-0556-05 CHIP C 6.0PF D
C227 C93-0558-05 CHIP C 8.0PF D
C229 C93-0556-05 CHIP C 6.0PF D
C230,231 CK73GB1C104K CHIP C 0.10UF K
C241 CK73GB1H471K CHIP C 470PF K
C248 C92-0585-05 CHIP-TAN 4.7UF 16WV
C251 CK73GB1H221K CHIP C 220PF K
C254 CK73GB1C104K CHIP C 0.10UF K
C257 CK73GB1C104K CHIP C 0.10UF K
C259 CK73GB1C104K CHIP C 0.10UF K
C265 CK73GB1H471K CHIP C 470PF K
C266 CK73GB1A105K CHIP C 1.0UF K
C270 CK73GB1H471K CHIP C 470PF K
C271 CK73GB1H681K CHIP C 680PF K
C275 CK73GB1H471K CHIP C 470PF K
C278 CK73GB1H221K CHIP C 220PF K
C285 CK73GB1H221K CHIP C 220PF K
C292-294 CK73GB1H471K CHIP C 470PF K
C298 CC73GCH1H680J CHIP C 68PF J
C299 CK73GB1H471K CHIP C 470PF K
C300 CK73GB1A105K CHIP C 1.0UF K
C501 CK73GB1H102K CHIP C 1000PF K
C502 CK73GB1C104K CHIP C 0.10UF K
C503 CK73GB1H471K CHIP C 470PF K
C504 CK73GB1H103K CHIP C 0.010UF K
C505 CK73GB1C104K CHIP C 0.10UF K
C506,507 CK73GB1H103K CHIP C 0.010UF K
C508 CK73GB1H472K CHIP C 4700PF K
C509 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C514 CC73GCH1H680J CHIP C 68PF J
C515 CK73HB1E103K CHIP C 0.010UF K
C516 CC73GCH1H300J CHIP C 30PF J
C517 CK73GB1E153K CHIP C 0.015UF K
C518 CC73GCH1H300J CHIP C 30PF J
C519 CK73GB1H102K CHIP C 1000PF K
C520 CK73GB1C104K CHIP C 0.10UF K
C521 CK73GB1H102K CHIP C 1000PF K
C522 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C523 CC73GCH1H121J CHIP C 120PF J
C524 CK73GB1H103K CHIP C 0.010UF K
C525 CK73GB1E123K CHIP C 0.012UF K
C526 CK73GB1C683K CHIP C 0.068UF K
C527 CK73GB1H222K CHIP C 2200PF K
C528 CK73GB1H103K CHIP C 0.010UF K
C529 CK73GB1H272K CHIP C 2700PF K
C530 CK73GB1H152K CHIP C 1500PF K
C531 CK73GB1H272K CHIP C 2700PF K
C532,533 CK73GB1C104K CHIP C 0.10UF K
C534,535 CK73GB1H103K CHIP C 0.010UF K
C536 CK73GB1C104K CHIP C 0.10UF K
C537 CK73GB0J105K CHIP C 1.0UF K
C538 C92-0560-05 CHIP-TAN 10UF 6.3WV
C539 CK73GB1H103K CHIP C 0.010UF K
C540,541 CK73GB1C104K CHIP C 0.10UF K
C542 CC73GCH1H331J CHIP C 330PF J
C543 CK73GB1H102K CHIP C 1000PF K
C544-546 CK73GB1H562K CHIP C 5600PF K
C548-550 CK73GB1H272K CHIP C 2700PF K
C551 CC73GCH1H151J CHIP C 150PF J
C553 CK73GB1H102K CHIP C 1000PF K
C554 CK73GB1H122K CHIP C 1200PF K
C555 C92-0560-05 CHIP-TAN 10UF 6.3WV
C556 CK73GB1C333K CHIP C 0.033UF K
C557 CK73GB1C104K CHIP C 0.10UF K
C558 CC73GCH1H101J CHIP C 100PF J
C559 CK73GB1H102K CHIP C 1000PF K
C560-563 CK73GB1C104K CHIP C 0.10UF K
C564 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C567 CC73GCH1H101J CHIP C 100PF J
C568 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C569 CK73GB1C333K CHIP C 0.033UF K
C570 CK73FF1C105Z CHIP C 1.0UF Z
C571,572 CK73GB1H102K CHIP C 1000PF K
C573 CK73FB1H563K CHIP C 0.056UF K
C574 CC73GCH1H470J CHIP C 47PF J
C575 CK73GB1H102K CHIP C 1000PF K
C576 CK73GB1C104K CHIP C 0.10UF K
C577,578 CK73GB1H103K CHIP C 0.010UF K
C579 CC73GCH1H101J CHIP C 100PF J
C580 CK73GB1C104K CHIP C 0.10UF K
C581 CK73GB1H102K CHIP C 1000PF K
C582 CK73GB1C473K CHIP C 0.047UF K
C583 C92-0560-05 CHIP-TAN 10UF 6.3WV
C584 CK73GB1H103K CHIP C 0.010UF K
C585 CC73GCH1H101J CHIP C 100PF J
C587 CK73GB1H103K CHIP C 0.010UF K
C589 C92-0606-05 CHIP-TAN 4.7UF 10WV
C590 CK73GB1H102K CHIP C 1000PF K
C594 CK73GB1H102K CHIP C 1000PF K
C596 CK73GB1H102K CHIP C 1000PF K
C597 CC73GCH1H101J CHIP C 100PF J
C598 CK73GB1H102K CHIP C 1000PF K
C599 CC73GCH1H101J CHIP C 100PF J
C600 CK73GB1H102K CHIP C 1000PF K
C601,602 CC73GCH1H101J CHIP C 100PF J
C603 CK73GB1H102K CHIP C 1000PF K
C604-606 CC73GCH1H101J CHIP C 100PF J
C608-610 CC73GCH1H101J CHIP C 100PF J
C611,612 CK73GB1H471K CHIP C 470PF K
C613 CC73GCH1H101J CHIP C 100PF J
C615 CK73GB1H471K CHIP C 470PF K
C616 CC73GCH1H101J CHIP C 100PF J
C618 CK73GB1H102K CHIP C 1000PF K
TX-RX UNIT (X57-5963-02)

TK-868G
5
PARTS LIST / 
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
C620 CK73GB1H471K CHIP C 470PF K
C621 CK73GB1H102K CHIP C 1000PF K
C623 CK73GB1H102K CHIP C 1000PF K
C626 CK73GB1C104K CHIP C 0.10UF K
C628 CK73GB1C104K CHIP C 0.10UF K
C629 CC73GCH1H470J CHIP C 47PF J
C630 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C631 CK73GB1H103K CHIP C 0.010UF K
C632 CK73FF1C105Z CHIP C 1.0UF Z
C633 CK73GB1C104K CHIP C 0.10UF K
C720 C92-0560-05 CHIP-TAN 10UF 6.3WV
CN1 E40-6047-05 PIN ASSY
CN2 E40-6021-05 FLAT CABLE CONNECTOR
CN3 E40-3247-05 PIN ASSY
CN4 E40-5737-05 PIN ASSY
CN5 E40-5738-05 PIN ASSY
CN6 E40-5751-05 PIN ASSY
CN7 E40-3247-05 PIN ASSY
CN8 E40-3246-05 PIN ASSY
CN501 E40-6021-05 FLAT CABLE CONNECTOR
J1 E11-0442-05 3.5D PHONE JACK (3P)
J501 E08-0877-05 MODULAR JACK
F1 F53-0108-05 FUSE
-J31-0543-05 COLLAR (LH-5-1.5)
CF1 L72-0999-05 CERAMIC FILTER
CF2 L72-0993-05 CERAMIC FILTER
L1 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L2-4 L40-3381-86 SMALL FIXED INDUCTOR (0.33UH)
L5 L34-4725-05 COIL
L6 L40-3975-77 SMALL FIXED INDUCTOR (39NH)
L7 L40-5685-85 SMALL FIXED INDUCTOR (0.56U)
L8 L40-8285-85 SMALL FIXED INDUCTOR (0.82UH)
L9 L40-1275-77 SMALL FIXED INDUCTOR (12NH)
L10 L40-2275-77 SMALL FIXED INDUCTOR (22NH)
L11 ✽L41-1075-33 SMALL FIXED INDUCTOR (0.01UH)
L13 L79-1585-05 HELICAL BLOCK
L14 L40-1875-77 SMALL FIXED INDUCTOR (18NH)
L15 L40-6875-77 SMALL FIXED INDUCTOR (68NH)
L16 ✽L41-3375-33 SMALL FIXED INDUCTOR (0.033UH)
L17 L40-1875-77 SMALL FIXED INDUCTOR (18NH)
L18 ✽L41-1875-33 SMALL FIXED INDUCTOR (0.018UH)
L19 L40-3375-77 SMALL FIXED INDUCTOR (33NH)
L20 L40-1875-77 SMALL FIXED INDUCTOR (18NH)
L21 L34-4478-05 AIR-CORE COIL
L22 L79-1585-05 HELICAL BLOCK
L26 ✽L41-3375-33 SMALL FIXED INDUCTOR (0.033UH)
L27 ✽L41-1575-33 SMALL FIXED INDUCTOR (0.015UH)
L29 L34-1185-05 AIR-CORE COIL
L30,31 L34-1039-05 AIR-CORE COIL
L32 L34-4478-05 AIR-CORE COIL
L33,34 L92-0179-05 CHIP FERRITE
L38,39 L40-1075-77 SMALL FIXED INDUCTOR (10NH)
L501 L92-0138-05 CHIP FERRITE
L503,504 L92-0138-05 CHIP FERRITE
L510 L92-0138-05 CHIP FERRITE
X1 ✽L77-1992-05 TCXO (16.8MHZ)
X501 L78-0479-05 RESONATOR (3.58MHZ)
X502 L78-1418-05 RESONATOR (9.8304M)
XF1 L71-0551-45 MCF (49.95MHZ)
CP501-505 R90-0741-05 MULTIPLE RESISTOR
CP508-514 R90-0741-05 MULTIPLE RESISTOR
CP516-524 R90-0741-05 MULTIPLE RESISTOR
CP526,527 R90-0741-05 MULTIPLE RESISTOR
CP529-536 R90-0741-05 MULTIPLE RESISTOR
CP538 R90-0741-05 MULTIPLE RESISTOR
CP539 RK75GB1J102J CHIP-COM 1.0K J 1/16W
R1 RK73GB2A000J CHIP R 0.0 J 1/10W
R2 RK73GB2A102J CHIP R 1.0K J 1/10W
R3 RK73GB2A000J CHIP R 0.0 J 1/10W
R4 RK73GB2A154J CHIP R 150K J 1/10W
R6 RK73GB2A000J CHIP R 0.0 J 1/10W
R7,8 RK73GB2A102J CHIP R 1.0K J 1/10W
R9,10 RK73GB2A000J CHIP R 0.0 J 1/10W
R11 RK73GB2A102J CHIP R 1.0K J 1/10W
R12 RK73GB2A104J CHIP R 100K J 1/10W
R13 RK73GB2A472J CHIP R 4.7K J 1/10W
R14 RK73GB2A474J CHIP R 470K J 1/10W
R15 RK73GB2A104J CHIP R 100K J 1/10W
R16 RK73GB2A220J CHIP R 22 J 1/10W
R17 RK73GB2A154J CHIP R 150K J 1/10W
R18 RK73GB2A103J CHIP R 10K J 1/10W
R19 RK73GB2A392J CHIP R 3.9K J 1/10W
R20 RK73GB2A124J CHIP R 120K J 1/10W
R21 RK73GB2A102J CHIP R 1.0K J 1/10W
R22 RK73GB2A474J CHIP R 470K J 1/10W
R23 RK73GB2A223J CHIP R 22K J 1/10W
R24 RK73GB2A103J CHIP R 10K J 1/10W
R25 RK73GB2A000J CHIP R 0.0 J 1/10W
R26 RK73GB2A104J CHIP R 100K J 1/10W
R29 RK73GB2A000J CHIP R 0.0 J 1/10W
R30 RK73GB2A103J CHIP R 10K J 1/10W
R31 RK73GB2A152J CHIP R 1.5K J 1/10W
R32 RK73GB2A103J CHIP R 10K J 1/10W
R33 RK73GB2A000J CHIP R 0.0 J 1/10W
R34 RK73GB2A104J CHIP R 100K J 1/10W
R35 RK73GB2A224J CHIP R 220K J 1/10W
R36 RK73GB2A223J CHIP R 22K J 1/10W
R37 RK73GB2A000J CHIP R 0.0 J 1/10W
R38-40 RK73GB2A103J CHIP R 10K J 1/10W
R41 RK73GB2A224J CHIP R 220K J 1/10W
R42 RK73GB2A473J CHIP R 47K J 1/10W
R43 RK73GB2A683J CHIP R 68K J 1/10W
R44 RK73GB2A153J CHIP R 15K J 1/10W
R46 RK73GB2A223J CHIP R 22K J 1/10W
R47 RK73GB2A101J CHIP R 100 J 1/10W
R48 RK73GB2A474J CHIP R 470K J 1/10W
R49 RK73GB2A152J CHIP R 1.5K J 1/10W
R50 RK73GB2A104J CHIP R 100K J 1/10W
R51-53 RK73GB2A102J CHIP R 1.0K J 1/10W
R54 RK73GB2A000J CHIP R 0.0 J 1/10W
R56 RK73GB2A100J CHIP R 10 J 1/10W
R57 RK73GB2A471J CHIP R 470 J 1/10W
R58 RK73GB2A682J CHIP R 6.8K J 1/10W
R59 RK73GB2A472J CHIP R 4.7K J 1/10W
R60 RK73GB2A154J CHIP R 150K J 1/10W
R61 RK73GB2A221J CHIP R 220 J 1/10W
TX-RX UNIT (X57-5963-02)

TK-868G
6
PARTS LIST / 
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
R62 RK73GB2A224J CHIP R 220K J 1/10W
R63 RK73GB2A154J CHIP R 150K J 1/10W
R64 RK73GB2A682J CHIP R 6.8K J 1/10W
R65 RK73GB2A103J CHIP R 10K J 1/10W
R66 RK73GB2A101J CHIP R 100 J 1/10W
R67 RK73GB2A222J CHIP R 2.2K J 1/10W
R68 RK73GB2A221J CHIP R 220 J 1/10W
R69 RK73GB2A000J CHIP R 0.0 J 1/10W
R70 RK73GB2A183J CHIP R 18K J 1/10W
R71 RK73GB2A682J CHIP R 6.8K J 1/10W
R72 RK73GB2A000J CHIP R 0.0 J 1/10W
R75 RK73GB2A000J CHIP R 0.0 J 1/10W
R76 RK73GB2A223J CHIP R 22K J 1/10W
R77 RK73GB2A224J CHIP R 220K J 1/10W
R78 RK73GB2A124J CHIP R 120K J 1/10W
R79 RK73GB2A102J CHIP R 1.0K J 1/10W
R80 RK73GB2A471J CHIP R 470 J 1/10W
R81 RK73GB2A101J CHIP R 100 J 1/10W
R82 RK73GB2A000J CHIP R 0.0 J 1/10W
R83 RK73GB2A684J CHIP R 680K J 1/10W
R84 RK73GB2A000J CHIP R 0.0 J 1/10W
R86 RK73GB2A122J CHIP R 1.2K J 1/10W
R87 RK73GB2A102J CHIP R 1.0K J 1/10W
R88 RK73GB2A271J CHIP R 270 J 1/10W
R89 RK73GB2A102J CHIP R 1.0K J 1/10W
R90 RK73GB2A104J CHIP R 100K J 1/10W
R91 RK73GB2A823J CHIP R 82K J 1/10W
R92 RK73GB2A822J CHIP R 8.2K J 1/10W
R93 RK73GB2A102J CHIP R 1.0K J 1/10W
R94 RK73GB2A392J CHIP R 3.9K J 1/10W
R95,96 RK73GB2A103J CHIP R 10K J 1/10W
R97,98 RK73GB2A101J CHIP R 100 J 1/10W
R99 RK73GB2A271J CHIP R 270 J 1/10W
R100,101 RK73GB2A222J CHIP R 2.2K J 1/10W
R103 RK73GB2A472J CHIP R 4.7K J 1/10W
R104 RK73GB2A332J CHIP R 3.3K J 1/10W
R105 RK73GB2A101J CHIP R 100 J 1/10W
R106 RK73GB2A102J CHIP R 1.0K J 1/10W
R107 RK73GB2A473J CHIP R 47K J 1/10W
R108 RK73GB2A331J CHIP R 330 J 1/10W
R109 RK73GB2A103J CHIP R 10K J 1/10W
R110 RK73GB2A470J CHIP R 47 J 1/10W
R111 RK73GB2A101J CHIP R 100 J 1/10W
R112 RK73GB2A331J CHIP R 330 J 1/10W
R113 RK73GB2A332J CHIP R 3.3K J 1/10W
R114 RK73GB2A472J CHIP R 4.7K J 1/10W
R115 RK73GB2A563J CHIP R 56K J 1/10W
R116 RK73GB2A473J CHIP R 47K J 1/10W
R118 RK73GB2A681J CHIP R 680 J 1/10W
R120 RK73GB2A000J CHIP R 0.0 J 1/10W
R122 RK73RB2H471J CHIP R 470 J 1/2W
R123 RK73GB2A472J CHIP R 4.7K J 1/10W
R124 RK73GB2A103J CHIP R 10K J 1/10W
R125 RK73GB2A333J CHIP R 33K J 1/10W
R126 RK73GB2A471J CHIP R 470 J 1/10W
R127,128 RK73GB2A104J CHIP R 100K J 1/10W
R129 RK73GB2A331J CHIP R 330 J 1/10W
R130 RK73GB2A102J CHIP R 1.0K J 1/10W
R131 RK73GB2A681J CHIP R 680 J 1/10W
R132 RK73FB2B000J CHIP R 0.0 J 1/8W
R133-136 RK73GB2A000J CHIP R 0.0 J 1/10W
R138 RK73GB2A102J CHIP R 1.0K J 1/10W
R140 RK73FB2B2R2J CHIP R 2.2 J 1/8W
R141 RK73RB2H220J CHIP R 22 J 1/2W
R142 RK73GB2A473J CHIP R 47K J 1/10W
R143 RK73GB2A101J CHIP R 100 J 1/10W
R145,146 RK73GB2A473J CHIP R 47K J 1/10W
R147,148 RK73GB2A104J CHIP R 100K J 1/10W
R149 RK73GB2A151J CHIP R 150 J 1/10W
R150 RK73GB2A104J CHIP R 100K J 1/10W
R151 RK73FB2B331J CHIP R 330 J 1/8W
R152 RK73GB2A000J CHIP R 0.0 J 1/10W
R153 RK73FB2B000J CHIP R 0.0 J 1/8W
R154 RK73GB2A152J CHIP R 1.5K J 1/10W
R155 RK73GB2A104J CHIP R 100K J 1/10W
R156 RK73FB2B5R6J CHIP R 5.6 J 1/8W
R158 RK73FB2B221J CHIP R 220 J 1/8W
R159 RK73GB2A473J CHIP R 47K J 1/10W
R160 RK73FB2B331J CHIP R 330 J 1/8W
R161,162 RK73GB2A104J CHIP R 100K J 1/10W
R163 RK73FB2B000J CHIP R 0.0 J 1/8W
R166 RK73GB2A151J CHIP R 150 J 1/10W
R172 RK73GB2A474J CHIP R 470K J 1/10W
R173 RK73GB2A472J CHIP R 4.7K J 1/10W
R174 RK73GB2A103J CHIP R 10K J 1/10W
R175 RK73GB2A682J CHIP R 6.8K J 1/10W
R176 RK73GB2A103J CHIP R 10K J 1/10W
R177 RK73RB2H151J CHIP R 150 J 1/2W
R178 RK73GB2A822J CHIP R 8.2K J 1/10W
R179 RK73GB2A223J CHIP R 22K J 1/10W
R180,181 RK73GB2A562J CHIP R 5.6K J 1/10W
R182 RK73FB2B000J CHIP R 0.0 J 1/8W
R184 RK73GB2A000J CHIP R 0.0 J 1/10W
R185 RK73GB2A473J CHIP R 47K J 1/10W
R186 RK73GB2A000J CHIP R 0.0 J 1/10W
R187 RK73GB2A101J CHIP R 100 J 1/10W
R188 RK73GB2A102J CHIP R 1.0K J 1/10W
R189 RK73GB2A101J CHIP R 100 J 1/10W
R190 RK73GB2A473J CHIP R 47K J 1/10W
R192 RK73GB2A103J CHIP R 10K J 1/10W
R193 RK73GB2A104J CHIP R 100K J 1/10W
R196 RK73GB2A332J CHIP R 3.3K J 1/10W
R197 RK73GB2A000J CHIP R 0.0 J 1/10W
R198 RK73GB2A104J CHIP R 100K J 1/10W
R199-202 RK73GB2A000J CHIP R 0.0 J 1/10W
R207 RK73GB2A330J CHIP R 33 J 1/10W
R208 RK73GB2A100J CHIP R 10 J 1/10W
R210 RK73GB2A332J CHIP R 3.3K J 1/10W
R219 RK73GB2A000J CHIP R 0.0 J 1/10W
R221 RK73GB2A000J CHIP R 0.0 J 1/10W
R232 RK73GB2A000J CHIP R 0.0 J 1/10W
R233 RK73GB2A333J CHIP R 33K J 1/10W
R234,235 RK73GB2A104J CHIP R 100K J 1/10W
R236 RK73GB2A823J CHIP R 82K J 1/10W
R237 RK73GB2A104J CHIP R 100K J 1/10W
R242 RK73GB2A393J CHIP R 39K J 1/10W
R243 RK73GB2A000J CHIP R 0.0 J 1/10W
R501 RK73GB2A473J CHIP R 47K J 1/10W
R502 RK73GB2A472J CHIP R 4.7K J 1/10W
R503 RK73GB2A102J CHIP R 1.0K J 1/10W
TX-RX UNIT (X57-5963-02)

TK-868G
7
PARTS LIST / 
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
R504-507 RK73GB2A473J CHIP R 47K J 1/10W
R508-510 RK73GB2A000J CHIP R 0.0 J 1/10W
R511 RK73GB2A473J CHIP R 47K J 1/10W
R512 RK73GB2A104J CHIP R 100K J 1/10W
R513 RK73GB2A683J CHIP R 68K J 1/10W
R514 RK73GB2A473J CHIP R 47K J 1/10W
R515,516 RK73GB2A153J CHIP R 15K J 1/10W
R517 RK73GB2A473J CHIP R 47K J 1/10W
R518 RK73GB2A472J CHIP R 4.7K J 1/10W
R519 RK73GB2A103J CHIP R 10K J 1/10W
R520-523 RK73GB2A102J CHIP R 1.0K J 1/10W
R526 RK73GB2A154J CHIP R 150K J 1/10W
R527 RK73GB2A000J CHIP R 0.0 J 1/10W
R528 RK73HB1J472J CHIP R 4.7K J 1/16W
R529 RK73GB2A154J CHIP R 150K J 1/10W
R530 RK73GB2A473J CHIP R 47K J 1/10W
R531 RK73GB2A564J CHIP R 560K J 1/10W
R532 RK73GB2A103J CHIP R 10K J 1/10W
R533 RK73GB2A564J CHIP R 560K J 1/10W
R534 RK73GB2A474J CHIP R 470K J 1/10W
R535 RK73GB2A103J CHIP R 10K J 1/10W
R536 RK73GB2A153J CHIP R 15K J 1/10W
R537 RK73GB2A105J CHIP R 1.0M J 1/10W
R538 RK73GB2A103J CHIP R 10K J 1/10W
R539 RK73GB2A000J CHIP R 0.0 J 1/10W
R540 RK73GB2A223J CHIP R 22K J 1/10W
R541 RK73GB2A184J CHIP R 180K J 1/10W
R542 RK73GB2A102J CHIP R 1.0K J 1/10W
R543 RK73GB2A184J CHIP R 180K J 1/10W
R544 RK73GB2A103J CHIP R 10K J 1/10W
R545 RK73GB2A472J CHIP R 4.7K J 1/10W
R546 RN73GH1J913D CHIP R 91K D 1/16W
R547 RK73GB2A103J CHIP R 10K J 1/10W
R548 RN73GH1J333D CHIP R 33K D 1/16W
R549 RN73GH1J913D CHIP R 91K D 1/16W
R550 RN73GH1J683D CHIP R 68K D 1/16W
R551,552 RK73GB2A223J CHIP R 22K J 1/10W
R553 RK73GB2A105J CHIP R 1.0M J 1/10W
R554 RN73GH1J913D CHIP R 91K D 1/16W
R555,556 RK73GB2A104J CHIP R 100K J 1/10W
R557 RN73GH1J274D CHIP R 270K D 1/16W
R558 RK73GB2A000J CHIP R 0.0 J 1/10W
R559 RK73GB2A333J CHIP R 33K J 1/10W
R560 RK73GB2A474J CHIP R 470K J 1/10W
R561 RK73GB2A273J CHIP R 27K J 1/10W
R562 RK73GB2A000J CHIP R 0.0 J 1/10W
R563 RK73GB2A473J CHIP R 47K J 1/10W
R564 RK73GB2A223J CHIP R 22K J 1/10W
R565 RK73GB2A000J CHIP R 0.0 J 1/10W
R566 RK73GB2A563J CHIP R 56K J 1/10W
R567 RK73GB2A334J CHIP R 330K J 1/10W
R568 RK73GB2A473J CHIP R 47K J 1/10W
R569 RK73GB2A102J CHIP R 1.0K J 1/10W
R570 RK73GB2A155J CHIP R 1.5M J 1/10W
R571 RN73GH1J682D CHIP R 6.8K D 1/16W
R572 RK73GB2A473J CHIP R 47K J 1/10W
R573 RK73GB2A474J CHIP R 470K J 1/10W
R574 RN73GH1J683D CHIP R 68K D 1/16W
R575 RK73GB2A101J CHIP R 100 J 1/10W
R576 RK73GB2A224J CHIP R 220K J 1/10W
R577 RK73GB2A103J CHIP R 10K J 1/10W
R578 RN73GH1J682D CHIP R 6.8K D 1/16W
R579 RK73GB2A223J CHIP R 22K J 1/10W
R580 RK73GB2A000J CHIP R 0.0 J 1/10W
R581 RK73GB2A104J CHIP R 100K J 1/10W
R583 RK73GB2A470J CHIP R 47 J 1/10W
R584 RK73GB2A220J CHIP R 22 J 1/10W
R585 RK73GB2A000J CHIP R 0.0 J 1/10W
R586 RK73GB2A473J CHIP R 47K J 1/10W
R587 RK73GB2A000J CHIP R 0.0 J 1/10W
R588 RK73GB2A103J CHIP R 10K J 1/10W
R590 RK73GB2A333J CHIP R 33K J 1/10W
R591 RK73GB2A000J CHIP R 0.0 J 1/10W
R592 RK73GB2A103J CHIP R 10K J 1/10W
R593 RK73GB2A181J CHIP R 180 J 1/10W
R594 RK73GB2A392J CHIP R 3.9K J 1/10W
R595 RK73GB2A181J CHIP R 180 J 1/10W
R598 RK73GB2A473J CHIP R 47K J 1/10W
R599,600 RK73GB2A102J CHIP R 1.0K J 1/10W
R602 RK73GB2A473J CHIP R 47K J 1/10W
R603 RK73GB2A101J CHIP R 100 J 1/10W
R604 RK73GB2A472J CHIP R 4.7K J 1/10W
R605 RK73GB2A332J CHIP R 3.3K J 1/10W
R606 RK73GB2A102J CHIP R 1.0K J 1/10W
R607 RK73GB2A101J CHIP R 100 J 1/10W
R608 RK73GB2A122J CHIP R 1.2K J 1/10W
R610,611 RK73GB2A473J CHIP R 47K J 1/10W
R612 RK73RB2H221J CHIP R 220 J 1/2W
R613 RK73GB2A103J CHIP R 10K J 1/10W
R614,615 RK73GB2A000J CHIP R 0.0 J 1/10W
R616 RK73GB2A474J CHIP R 470K J 1/10W
R617 RK73GB2A472J CHIP R 4.7K J 1/10W
R618 RK73GB2A683J CHIP R 68K J 1/10W
R619 RK73GB2A104J CHIP R 100K J 1/10W
R620,621 RK73GB2A103J CHIP R 10K J 1/10W
R622 RK73GB2A473J CHIP R 47K J 1/10W
R630 RK73GB2A000J CHIP R 0.0 J 1/10W
R641,642 RK73GB2A000J CHIP R 0.0 J 1/10W
R701 RK73GB2A683J CHIP R 68K J 1/10W
R704 RK73GB2A223J CHIP R 22K J 1/10W
R720 RK73GB2A000J CHIP R 0.0 J 1/10W
R722 RK73GB2A000J CHIP R 0.0 J 1/10W
R723 RK73GB2A273J CHIP R 27K J 1/10W
R724 RK73GB2A473J CHIP R 47K J 1/10W
R726 RK73GB2A000J CHIP R 0.0 J 1/10W
D1 ✽DA204U DIODE
D2 02DZ20(Y,Z) ZENER DIODE
D3-5 ✽DA204U DIODE
D8 DAN235E DIODE
D9 1SS355 DIODE
D10 DAN235E DIODE
D11 MA742 DIODE
D14 1SS355 DIODE
D15 DAN202K DIODE
D16 DAN235E DIODE
D17 ✽DA204U DIODE
D18 KV1848K VARIABLE CAPACITANCE DIODE
D19,20 1SS355 DIODE
D21 02DZ18F-X,Y ZENER DIODE
D23 KV1848K VARIABLE CAPACITANCE DIODE
TX-RX UNIT (X57-5963-02)

TK-868G
8
PARTS LIST / 
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
D24 02DZ15(X,Y) ZENER DIODE
D25 ZSH5MA27 SURGE ABSORBER
D26 DSA3A1-FK DIODE
D27 1SS355 DIODE
D28 KV1848K VARIABLE CAPACITANCE DIODE
D30 MA4PH633 DIODE
D31 KV1848K VARIABLE CAPACITANCE DIODE
D33,34 XB15A709 DIODE
D35,36 MA742 DIODE
D39 UDZS4.7B ZENER DIODE
D40 RB706F-40 DIODE
D42 HZU5ALL DIODE
D54 MA2S111 DIODE
D56 HZU5CLL ZENER DIODE
D501-507 MA2S111 DIODE
D508 RB706F-40 DIODE
D523 DAN202U DIODE
D524,525 ✽DA204U DIODE
D526 1812L075PR VARISTOR
D527,528 ✽DA204U DIODE
D529 RB706F-40 DIODE
IC1,2 TA75S01F IC (OP AMP)
IC3 MB15A02 IC
IC4 NJM4558M IC (OP AMP X2)
IC5 TA31136FNG IC (FM IF DETECTOR)
IC6 M62363FP IC (8bit D/A CONVERTER)
IC7 NJM2904M IC (OP AMP X2)
IC9 BU4094BCF IC (8-STAGE SHIFT/STORE REGISTER)
IC10 NJM78L05UA IC (VOLTAGE REGULATOR/+5V)
IC11 AN8009M IC (REGULATOR)
IC12 TA7808S IC (REGULATOR)
IC13 LA4422 IC (AF POWER AMP/5.8W)
IC14 TC4013BF(N) IC (MEMORY)
IC15 TA75S01F IC (OP AMP)
IC400 2C RA30H4452M-31 IC (RF MODULE440-490MHz)
IC501 ✽AT29C02090TU IC
IC502 30622M4A-439GP MPU
IC503 RH5VL42C IC (REGULATOR)
IC505 AT24C08A10SU18 IC (8bit SERIAL EEPROM)
IC507 NJM2904V IC (APC)
IC508 TC35453F IC (AUDIO PROCESSOR)
IC509 BU4066BCFV IC (ANALOG SWITCHX4)
IC510 BU4094BCFV IC (8-STAGE SHIFT/STORE REGISTER)
IC511 LC73872M IC (DTMF RECEIVER)
IC512 NJM78L05UA IC (VOLTAGE REGULATOR)
IC513 TA75W558FU IC (OP AMP X2)
IC514 TC75W51FUF IC (OP AMP X2)
Q1 DTD114EK DIGITAL TRANSISTOR
Q2 KRA225S DIGITAL TRANSISTOR
Q3 DTA114EKA DIGITAL TRANSISTOR
Q4,5 DTC114EKA DIGITAL TRANSISTOR
Q6 DTC124EKA DIGITAL TRANSISTOR
Q7 2SC4649(N,P) TRANSISTOR
Q8 2SC2412K TRANSISTOR
Q9 2SC4226(R24) TRANSISTOR
Q10 2SC2412K TRANSISTOR
Q11 2SA1774(R) TRANSISTOR
Q12 2SC4617(R) TRANSISTOR
Q13 2SC4649(N,P) TRANSISTOR
Q14 2SC5110(O) TRANSISTOR
Q15 3SK255 FET
Q16 DTC114EKA DIGITAL TRANSISTOR
Q17 DTC363EU DIGITAL TRANSISTOR
Q18 2SA1745(6,7) TRANSISTOR
Q19 DTC114EKA DIGITAL TRANSISTOR
Q20 DTA114EKA DIGITAL TRANSISTOR
Q21 DTC114EKA DIGITAL TRANSISTOR
Q22 2SC4093 TRANSISTOR
Q23 2SA1641(S,T) TRANSISTOR
Q24 DTA114EKA DIGITAL TRANSISTOR
Q26 DTA114EKA DIGITAL TRANSISTOR
Q27 2SC2954 TRANSISTOR
Q28 2SB1132(Q,R) TRANSISTOR
Q29 DTC114EKA DIGITAL TRANSISTOR
Q33 DTC114EKA DIGITAL TRANSISTOR
Q34 3SK255 FET
Q35 DTC144EKA DIGITAL TRANSISTOR
Q36 2SC2412K TRANSISTOR
Q37,38 2SK1824 FET
Q501 2SC4649(N,P) TRANSISTOR
Q502,503 DTC114EE DIGITAL TRANSISTOR
Q504 2SC4617(S) TRANSISTOR
Q505 2SB1132(Q,R) TRANSISTOR
Q506 DTC114EE DIGITAL TRANSISTOR
Q508 2SC4617(S) TRANSISTOR
Q509 DTC363EU DIGITAL TRANSISTOR
TH1 157-153-65001 THERMISTOR
TH2 ✽B57331V2682J THERMISTOR
C102 CK73GB1H471K CHIP C 470PF K
C104 CC73GCH1H120J CHIP C 12PF J
C105 CC73GCH1H070D CHIP C 7.0PF D
C107 CC73GCH1H060D CHIP C 6.0PF D
C108 CC73GCH1HR75B CHIP C 0.75PF B
C110 CC73GCH1H030B CHIP C 3.0PF B
C111 CC73GCH1H050B CHIP C 5.0PF B
C112 CC73GCH1H1R5B CHIP C 1.5PF B
C113 CC73GCH1H010B CHIP C 1.0PF B
C114 CC73GCH1H040B CHIP C 4.0PF B
C115 CC73GCH1H060D CHIP C 6.0PF D
C116 CC73GCH1H050B CHIP C 5.0PF B
C117 CK73GB1H471K CHIP C 470PF K
C118 CC73GCH1H050B CHIP C 5.0PF B
C119,120 CK73GB1H471K CHIP C 470PF K
C121 CC73GCH1H050B CHIP C 5.0PF B
C122 CC73GCH1H0R5B CHIP C 0.5PF B
C123 CK73GB1H471K CHIP C 470PF K
C124 CC73GCH1H0R5B CHIP C 0.5PF B
C125 CK73GB1H102K CHIP C 1000PF K
C126 CK73GB1H471K CHIP C 470PF K
C127 CC73GCH1H050B CHIP C 5.0PF B
TC106 C05-0384-05 CERAMIC TRIMMER CAPACITOR (10P)
TC109 C05-0384-05 CERAMIC TRIMMER CAPACITOR (10P)
CN101 E40-6019-05 PIN ASSY
-F10-2279-04 SHIELDING CASE
PLL/VCO (X58-4670-17)
TX-RX UNIT (X57-5963-02)
PLL/VCO (X58-4670-17)

TK-868G
9
PARTS LIST / 
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
PLL/VCO (X58-4670-17)
L101-104 ✽L41-1595-33 SMALL FIXED INDUCTOR (1.5UH)
L105 ✽L41-3975-33 SMALL FIXED INDUCTOR (0.039UH)
L106 ✽L41-2775-33 SMALL FIXED INDUCTOR (0.027UH)
L107,108 L40-1098-76 SMALL FIXED INDUCTOR (1UH)
L109,110 ✽L41-1595-33 SMALL FIXED INDUCTOR (1.5UH)
L111 L34-4547-05 AIR-CORE COIL
L115 L34-4547-05 AIR-CORE COIL
R101,102 RK73GB2A101J CHIP R 100 J 1/10W
R103 RK73GB2A102J CHIP R 1.0K J 1/10W
R104 RK73GB2A101J CHIP R 100 J 1/10W
R105 RK73GB2A154J CHIP R 150K J 1/10W
R106 RK73GB2A470J CHIP R 47 J 1/10W
R107-110 RK73GB2A103J CHIP R 10K J 1/10W
R111 RK73GB2A331J CHIP R 330 J 1/10W
R112,113 RK73GB2A221J CHIP R 220 J 1/10W
R114 RK73GB2A470J CHIP R 47 J 1/10W
R115 RK73GB2A103J CHIP R 10K J 1/10W
R116 RK73GB2A392J CHIP R 3.9K J 1/10W
R117 RK73GB2A101J CHIP R 100 J 1/10W
D101-104 ✽1SV283F VARIABLE CAPACITANCE DIODE
D105 1SV214 VARIABLE CAPACITANCE DIODE
Q101 2SK508NV(52K) FET
Q102 DTC114EUA DIGITAL TRANSISTOR
Q103 2SK508NV(52K) FET
Q104,105 2SC4081 TRANSISTOR
Q106 2SC4226(R24) TRANSISTOR

10
JIHGFEDCBA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
CN801
1MBL
5C
LCDCS
CNTCK
E
E
SB
CNTDT
2
78
IC801
1
12
13 24
36
3748
25
R803 R805
Q801
Q802
Q803
Q805
R810
R809
C801
C806
C808
C812
R812
R804
C804
R802
C803
C802
R801
R808
C807
C805
R806
D802
R807
L801
Q804
Q806
Q807
G
SD
G
SD
G
S
D
G
S
D
Q808
Q809
R813
R814
R815
R816
D801 D804
D803
J72-0684-02 J72-0684-02
TK-868G PC BOARD / PC板
DISPLAY UNIT (X54-3280-10)
Component side view (J72-0684-02)
DISPLAY UNIT (X54-3280-10)
Foil side view (J72-0684-02)
Component side
Foil side
Layer 1
Layer 2
Component side
Foil side
Layer 1
Layer 2
Ref. No. Address
D801 3C
D803 10E
D804 5C
Ref. No. Address
IC801 11H
Q801 3G
Q802 4H
Q803 5G
Ref. No. Address
Q804 5G
Q805 5I
Q806 4G
Q807 4H
Ref. No. Address
Q808 5H
Q809 5I
D802 9G

11
ABCDE FGH I J
1
2
3
4
5
6
7
8
9
10
11
12
13
14
CN101
RX
(ST)
RX
(ST)
6
1
HT
HT
E
E
8CL
8CL
MD
MD
CV
CV
J72-0676-02
J72-0676-02
L103
L104
C102
C126
C120
C119
R110
C125
R107
C115
C104
C105
R103
R108
C116
L110
L109
C122
R115
R109
R114
R111
Q102
Q104
Q105
Q106
L106
C127
L115
L116
L112
C107
C114
C121
C118
C111
C123
C117
D105
R116
C110
C108
R101
R102
TC106
L101
TC109
R117
R106
R104
R105
C113
C124
R112 R113
L102
C112
D101
D102
D103
D104
L108
L107
Q101
G
S
D
G
S
D
Q103
L105
PC BOARD / PC板TK-868G
PLL/VCO (X58-4670-17) Component side view (J72-0676-02)
PLL/VCO (X58-4670-17) Foil side view (J72-0676-02)
Component side
Foil side
Layer 1
Layer 2
Component side
Foil side
Layer 1
Layer 2
Ref. No. Address
Q101 12C
Q102 11C
Q103 9C
Q104 11B
Q105 11B
Q106 11E
D101 13F
D102 9F
D103 13F
D104 9F
D105 10E

12
JIHGFEDCBA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
C30
C32
C34
C39
C47 +
C55C61
Q11
Q12
C67
C71
C225
C77
C91
C266
C270
C285
TH1
L5
D30
D33D34
L21
L27
IC3
1
1011
20
L29
IC5
1 89
16
C117
L30
CF1 (
G
L32
C131
R177
Q9
R197
R56
R62
R64
R65
R75
R79R82
C198
R93
R200
IC11
TV
8R
CV
+
+
++
XF1
+
A1: X58-4670-17
8CL
+
+
+
G
O
I
TP1
C35
C40
C45
R232
C203
C54
C206
C207
C208
C209
C210
C211
C212
C63
C64
C215
C68 C73
C75
C226
C81
C83
C86
C89
C93
C98
C99
D9
TH2
R112
R113
D42
L13
C104
C300
L22
L26
C114
C115
L31
L38
L39
Q8
R34
R37
R188
R49
R51 R52 R53
R57
R66
R70 R71
R76
R208
+
J72-0988-09 A/2
RX (ST)
HT
E
8CL
MD
CV
TK-868G PC BOARD / PC板
TX-RX UNIT (X57-5963-02) (A/2)
Component side view (J72-0988-09 A/2)

13
JKLMNOPQRS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
C46
R242
R243
C70
C84
Q37
G
D
S
C97
C1
C2
C3
C5
C6
C7
C8
C9
C298
R131
C103
IC4
1 45
8
CF1 (G)
R10
R11
Q2
C144
SB 3
E
HOR 1
R3
R4
1
8
R48
R50
C160
C161
R63
CN1
CN6
CN8
C10
C11
R201
+
+
+
+
+
+
5C
G
DS
C21 1
15
R221
C43
C60
C72
C74
C79 C80
Q35
Q38
C96
C257
C271
C278
D26
D40
C107
D54
C114
IC6
1
1
45
8
1213
24
IC7
CF2 (F)
R19
C134C138
C141
R40 R44
R193
C165
C166
R59
C172
R67 R68
R77 R78
R86
R87
R89
CN3
CN4
R90
CN5
R91
CN7
E2
1SP
R96
1
10
PSW
DTMFIO
8TC
PCO
UL
B
5C
CTO
GND
RSSI
C13
GND MIO MII AFI AFO ALT AUX2 AUX4 AUX1 AUX3 NC AUX6 AUX5 5S 8C
C14 C15 R202 C16 C17 C18 C19
IC12
OGI
IC13 10
1
D25
J1
EXT. SP
R1 R2
R7 R8
R9
E
B
+
+
+
+
+
+
PC
GND
GND
RSSI
SB
PA/LI1
SPO
SPI3
AM 1
3
MM
EMG/TXS
DEO
DTC
IGN
DI
ME
MI
PTT
SQ
TX-RX UNIT (X57-5963-02) (A/2)
Component side view (J72-0988-09 A/2)
PC BOARD / PC板TK-868G
Component side
Foil side
Layer 1
Layer 2
Layer 3
Layer 4
Ref. No. Address
IC3 10G
IC4 12L
IC5 12I
IC6 10L
IC7 9K
IC11 9I
IC12 6N
IC13 7R
Q2 12R
Q8 7F
Q9 10E
Q11 11F
Q12 10F
Q35 12L
Q37 11K
Q38 12Q
D9 9F
D25 4L
D26 4O
D30 5E
D33 7C
D34 7B
D40 11L
D42 11G
D54 11K

JKLMNOPQRSIHGFEDCBA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
2
3
4
5
6
7
8
9
10
11
12
13
14
C30
C32
C34
C39
C46
C47 +
C55
R242
R243
C61
Q11
Q12
C67
C70
C71
C225
C77
C84
Q37
G
D
S
C91
C97
C1
C2
C3
C5
C6
C7
C8
C9
C266
C270
C285
C298
TH1
L5
D30
D33D34
R131
C103
L21
L27
IC3
1
1011
20
IC4
1 45
8
L29
IC5
1 89
16
C117
L30
CF1 (G)
L32
R10
R11
C131
Q2
R177
Q9
C144
SB 3
E
HOR 1
R3
R4
1
8
R48
R197
R50
C160
C161
R56
R62
R63
R64
R65
R75
R79R82
C198
CN1
CN6
R93
CN8
C10
C11
R200
R201
IC11
TV
8R
CV
+
+
++
XF1
+
A1: X58-4670-17
8CL
+
+
+
+
+
G
O
I
TP1 +
+
+
5C
G
DS
C21 1
15
R221
C35
C40
C43
C45
R232
C203
C54
C206
C207
C208
C209
C210
C60
C211
C212
C63
C64
C215
C68
C72
C73
C74
C75
C226
C79 C80
C81
C83
C86
Q35
C89
Q38
C93
C96
C98
C99
C257
D9
C271
C278
TH2
R112
R113
D26
D40
D42
L13
C104
C107
C300
L22
D54
L26
C114
C115
IC6
1
1
45
8
1213
24
IC7
L31
CF2 (F)
L38
L39
R19
C134C138
Q8
C141
R34
R37
R188
R40 R44
R193
R49
R51 R52 R53
C165
C166
R57
R59
C172
R66
R67 R68
R70 R71
R76
R77 R78
R86
R87
R89
CN3
CN4
R90
CN5
R91
CN7
E2
1SP
R96
1
10
PSW
DTMFIO
8TC
PCO
UL
B
5C
CTO
GND
RSSI
C13
GND MIO MII AFI AFO ALT AUX2 AUX4 AUX1 AUX3 NC AUX6 AUX5 5S 8C
C14 C15 R202 C16 C17 C18 C19
IC12
OGI
IC13 10
1
R208
D25
J1
EXT. SP
R1 R2
R7 R8
R9
+
E
B
+
+
+
+
+
+
PC
GND
GND
RSSI
SB
PA/LI1
SPO
SPI3
AM 1
3
MM
EMG/TXS
DEO
DTC
IGN
DI
ME
MI
PTT
SQ
J72-0988-09 A/2
RX (ST)
HT
E
8CL
MD
CV
TK-868G PC BOARD / PC板
TX-RX UNIT (X57-5963-02) (A/2)
Component side view (J72-0988-09 A/2)
TX-RX UNIT (X57-5963-02) (A/2)
Component side view (J72-0988-09 A/2)
PC BOARD / PC板TK-868G
Component side
Foil side
Layer 1
Layer 2
Layer 3
Layer 4
Ref. No. Address
IC3 10G
IC4 12L
IC5 12I
IC6 10L
IC7 9K
IC11 9I
IC12 6N
IC13 7R
Q2 12R
Q8 7F
Q9 10E
Q11 11F
Q12 10F
Q35 12L
Q37 11K
Q38 12Q
D9 9F
D25 4L
D26 4O
D30 5E
D33 7C
D34 7B
D40 11L
D42 11G
D54 11K

14
JIHGFEDCBA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Q17
C248
C4
C259
F1
D15
D24 D27
R120
R122
R124
R125
R135
R136 R140
R145
R148
C113
R150
R152
R153
C122 R163
C128
Q1
Q5 Q6
C154 C164 C173
C179
C185
C186
IC10
I
G O
IC14
C24
Q23
E
B
C
Q26
IC1
1 34
5
R17
R18 C157
R154
R156
R158
R159
C140
C145
R182C177
C182
C192
C37
C58
D14
R22
R23
R25
R30 R32
R38
R43
R190
R46
R58
R60
Q10
D1
D3
D4
D5
R42
1
SFTDT
UL
PLST
PLDT
PCLK
RSSI
ASQ
TO
SFTST
DAST
CNTDT
CNTCK
W/N CTO
DTMFIO
MO
AFO
SB SB
PSW
AUX3 AUX1 AUX4 AUX2
EMG/TXS
8C
MM
MI
OE
ALT
DEO
MII
MIO
GND
34
SP
1
78
14
ASQ
++
5C
8C
SB
DB
+
8TC
+
+
1
34
5
B
B
C
C
E
E
C20
C22
R210
C29
C
C51
C
C53
C66
C69
Q19
Q20
Q21
Q24
C78
Q27
Q28
Q29
C230
C231
C241
D2
D8
R103
R107
D10
D11
D17
D19
R118
D20
D21
R123
R126
R129
R130
R132
R133
R134
R138
L16
L18
R141
R142
D56
12
IC2
R151
C116
IC9
1 89
16
R12 R13
C123
R14
R160
R15
C125
C129
R20
R21
R24
R26
Q3
Q4
R33
C143
R35
C148
R39
R186
R6
C150
C156
C158
R198
C162
R54
R61
R72
C189
C190
CN2
R146
RSSI
+
+
TP1
9C
8T
TK-868G PC BOARD / PC板
TX-RX UNIT (X57-5963-02) (A/2)
Foil side view (J72-0988-09 A/2)

15
JKLMNOPQRS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
+
J72-0988-09 A/2
C201 C202
L33 L34
C204
C218
Q22
1 23
4
C265
R104
R108
R109
R111 L11
C105
C108 C118
R166
R174
R175
R178
R180
R181
R187
R196
C196
C216
C221
C222
D35
R233
C293
D18
D23
R127
L15
R143
R161
R184
C152
C167
C168
C178
C187
C25
C28
R235
Q14
Q15
1 23
4
Q18
C275
C294 R100
R101
D16
R110
R115
R116
L6
C100
C102
L17
C106
C119
C120
C121 C126
C130
C133
C135
C142
R92
R95
R207
L8
C31
C33 C36
C41
C56
C62
C87 C88
L2
L4
R22
R23
R29
R31
R36
C146
R190
R192
R47
R80
X1
+
1
34
5
8R
C23
C26
R219
C44
R234
C49
R236 R237
C52
C53
C213
Q13
C217
C219
Q16
C220
C223
C224
C227
C229
C82
Q33
Q34
Q36
2
41
C95
C251
C254
C292
C299
R105
R106
D17
R114
D28
L1
L3
L7
R128
D31
L9
D36
D39
L10
L14
C101
L19
C109
R147
L20
R149
C111
IC400
34
C112
R155
R16
R162
C127
2
0
2
6
R172
R173
C139
R176
Q7
R179
C149
R185
R189
R41
C153
C155
R199 C163
C169
C174
R69
C181
C183
R81
R83
R84
R88
C199
R94
R97
R98
R99
IC15
+
ST
DT
CK UL
8RC
8CL
PC
TV
1
23
4
CV
ANT
RX (ST)
HT
E
8CL
MD
CV
TX-RX UNIT (X57-5963-02) (A/2)
Foil side view (J72-0988-09 A/2)
PC BOARD / PC板TK-868G
Component side
Foil side
Layer 1
Layer 2
Layer 3
Layer 4
Ref. No. Address
IC1 11D
IC2 9I
IC9 9F
IC10 8D
IC14 9C
IC15 6N
IC400 2J
Q1 11A
Q3 12G
Q4 12G
Q5 11B
Q6 10B
Q7 10K
Q10 12G
Q13 12K
Q14 10N
Q15 12N
Q16 13L
Q17 9B
Q18 13M
Q19 7B
Q20 8B
Q21 7B
Q22 6L
Q23 7D
Q24 8B
Q26 8C
Q27 6I
Q28 7I
Q29 7H
Q33 7N
Q34 10Q
Q36 8K
D1 13D
D2 11A
D3 13B
D4 13C
D5 13C
D8 11J
D10 12I
D11 11F
D14 10G
D15 9B
D16 11N
D17 7J
D18 12P
D19 8B
D20 7C
D21 7C
D23 11Q
D24 8D
D27 8C
D28 9P
D31 8Q
D35 6Q
D36 6Q
D39 8K
D56 4I

JKLMNOPQRSIHGFEDCBA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
2
3
4
5
6
7
8
9
10
11
12
13
14
+
J72-0988-09 A/2
Q17
C248
C4
C259
F1
D15
D24 D27
R120
R122
R124
R125
R135
R136 R140
R145
R148
C113
R150
R152
R153
C122 R163
C128
Q1
Q5 Q6
C154 C164 C173
C179
C185
C186
IC10
I
G O
IC14
C24
Q23
E
B
C
Q26
IC1
1 34
5
R17
R18 C157
C201 C202
R154
R156
R158
R159
L33 L34
C140
C145
R182C177
C182
C192
C204
C218
Q22
1 23
4
C265
R104
R108
R109
R111 L11
C105
C108 C118
R166
R174
R175
R178
R180
R181
R187
R196
C196
C216
C221
C222
D35
R233
C293
D18
D23
R127
L15
R143
R161
R184
C152
C167
C168
C178
C187
C25
C28
R235
Q14
Q15
1 23
4
Q18
C275
C294 R100
R101
D16
R110
R115
R116
L6
C100
C102
L17
C106
C119
C120
C121 C126
C130
C133
C135
C142
R92
R95
R207
L8
C31
C33 C36
C37
C41
C56
C58
C62
C87 C88
D14
L2
L4
R22
R23
R25
R29
R30
R31
R32
R36
C146
R38
R43
R190
R46
R192
R47
R58
R60
R80
X1
Q10
D1
D3
D4
D5
R42
1
SFTDT
UL
PLST
PLDT
PCLK
RSSI
ASQ
TO
SFTST
DAST
CNTDT
CNTCK
W/N CTO
DTMFIO
MO
AFO
SB SB
PSW
AUX3 AUX1 AUX4 AUX2
EMG/TXS
8C
MM
MI
OE
ALT
DEO
MII
MIO
GND
34
SP
1
78
14
ASQ
++
5C
8C
SB
DB
+
8TC
+
+
1
34
5
B
B
C
C
E
E
+
1
34
5
8R
C20
C22
C23
R210
C26
C29
R219
C44
R234
C49
R236 R237
C51
C52
C53
C213
C66
Q13
C217
C219
C69
Q16
Q19 C220
C223
Q20
C224
Q21
C227
Q24
C78
C229
Q27
Q28
Q29
C230
C231
C82
Q33
Q34
Q36
C241
C95
C251
C254
D2
D8
C292
C299
R103
R105
R106
R107
D10
D11
D17
D19
R114
R118
D20
D21
D28
L1
R123
L3
R126
L7
R128
R129
D31
L9
D36
R130
D39
R132
R133
R134
L10
R138
L14
C101
L16
L18
L19
R141
R142
C109
R147
L20
R149
C111
D56
IC400
12 3 4
C112
IC2
R151
C116
IC9
1 89
16
R155
R12 R13
C123
R14
R160
R15
C125
R16
R162
C127
C129
R20
R21
R24
R26
R172
Q3
R173
Q4
C139
R176
Q7
R179
R33
C143
R35
C148
R39
C149
R185
R186
R6
R189
C150
R41
C153
C155
C156
C158
R198
R199
C162
C163
R54
C169
R61
C174
R69
C181
R72
C183
C189
C190
R81
R83
R84
R88
C199
CN2
R94
R97
R98
R99
IC15
R146
RSSI
+
+
TP1
9C
8T
+
ST
DT
CK UL
8RC
8CL
PC
TV
1
23
4
CV
ANT
RX (ST)
HT
E
8CL
MD
CV
TK-868G PC BOARD / PC板
TX-RX UNIT (X57-5963-02) (A/2)
Foil side view (J72-0988-09 A/2)
TX-RX UNIT (X57-5963-02) (A/2)
Foil side view (J72-0988-09 A/2)
PC BOARD / PC板TK-868G
Component side
Foil side
Layer 1
Layer 2
Layer 3
Layer 4
Ref. No. Address
IC1 11D
IC2 9I
IC9 9F
IC10 8D
IC14 9C
IC15 6N
IC400 2J
Q1 11A
Q3 12G
Q4 12G
Q5 11B
Q6 10B
Q7 10K
Q10 12G
Q13 12K
Q14 10N
Q15 12N
Q16 13L
Q17 9B
Q18 13M
Q19 7B
Q20 8B
Q21 7B
Q22 6L
Q23 7D
Q24 8B
Q26 8C
Q27 6I
Q28 7I
Q29 7H
Q33 7N
Q34 10Q
Q36 8K
D1 13D
D2 11A
D3 13B
D4 13C
D5 13C
D8 11J
D10 12I
D11 11F
D14 10G
D15 9B
D16 11N
D17 7J
D18 12P
D19 8B
D20 7C
D21 7C
D23 11Q
D24 8D
D27 8C
D28 9P
D31 8Q
D35 6Q
D36 6Q
D39 8K
D56 4I

16
JIHGFEDCBA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
J72-0988-09 B/2
J72-0988-09 B/2
R616
R618
R619
R630
C626
C628
R514 R518 R519
R529
R536
R537
R538
R539 R540
R541
C507 C508
R551
R555
R556
R559
C520
C521
C523
C526
C532
R572
C538
R592C580
D521
PSW
IC507
D529
C599
R603
R604
R605
R606 R608
R615
CP539
C600 C602 C604 C606 C608 C610
34
C611
C612
C629
C633
Q503
Q505
B C
E
Q506
Q509
L510
R704
R720
R546
R549
X501
R557
R565
R568
R569
C533
R570
C535
R571
C536
R573
R574
C539
R577
R579
C540
C544
R580
C546
C548
R584
R586
R588
C551
C553
C554
R590
R591
C556
R594
C559
R598
C561
C562
C563
C564
C567
D508
C568
C569
C570
C571 C572
C573
C574
C579
C582
D523
C585
D526 D528
IC508
IC509
1
78
14
C594 C596 C598
++
+
1
11
1222
23
33
34 44
GND MIO MII DEO ALT OE MI MM 8C EMG/TXS AUX2 AUX4 AUX1 AUX3 PSW SB SB AFO MO DTMFIO
CTO
R600
R607
SPD R610
R612
R613
R614
R620
R621
C615
C620
Q502
Q504
Q508
R526
R722
R723
R72
6
R548 R550
R553
R554 R558
C530
C534
R575
R576
R578
C545
R581
R583
R585
C549
C550
C555
R593
C557 C558
R595
R599
C560
C576
C577
C581
D524
C584
D525
D527
C590
IC511
1 78
14
CN501
C632
R533
R
R543
R545
R547
R552
R560
C525
R561
R562R563 C527
R564
C528
C529
R566
R567
C531
C537
C541
C542
C543
D512
D513
D514
IC513
IC514
J501
CM MIC
ME GND MBL
PSB
PTT/
TXD
HOOK/
RXD
VOL
DN
VOL
UP
+
1
45
8
MON
1
45
8
1
45
8
PTT
TK-868G PC BOARD / PC板
TX-RX UNIT (X57-5963-02) (B/2) Component side view (J72-0988-09 B/2)
TX-RX UNIT (X57-5963-02) (B/2) Foil side view (J72-0988-09 B/2)
Ref. No. Address
IC501 3O
IC503 4L
IC507 3G
IC510 3L
Ref. No. Address
IC513 3J
IC514 4J
D506 4L
D509 5M
Ref. No. Address
D510 5Q
D511 2Q
D512 2E
D513 5E
Ref. No. Address
D514 5I
D521 3C
D529 3I
Ref. No. Address
IC502 10P
IC505 11N
IC508 11F
IC509 11J
Ref. No. Address
IC511 9E
IC512 10L
Q501 9R
Q502 10H
Ref. No. Address
Q503 11I
Q504 11C
Q505 11B
Q506 11B
Ref. No. Address
Q508 11C
Q509 11B
D501 11O
D502 11N
Ref. No. Address
D503 10N
D504 11O
D505 11N
D507 11N
Ref. No. Address
D508 9G
D523 10B
D524 9B
D525 10C
Ref. No. Address
D526 9D
D527 10B
D528 8D

17
JKLMNOPQRS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
R602
R622
C601 C603 C605 C609 C613
C630
C631
R510
R529
R724
R531R532
R534
R536
R537
R538
C503
R556
C520
C521
C523
C524
C532
IC501
1
1617
32
IC503
O
I
G
IC510
C599
CP518
CP519
CP520
CP521
CP522
CP523
CP524
CP526
CP527
CP529
CP530
CP531
CP532
CP533
CP534
CP535
R611
CP536
1
C616 C618 C621
L504
R502
R503
R504
R506
R507
R513 R516
R522
R528
R530
C506
C509
C515
C519
C720
R580
R587
D503
D505
D507
C575
C583
IC505
1
7
C589
IC512
O G
I
C594 C596 C597 C598
CP517
+
1
89
16
MBL
EESB
CNT
DT
EESB
CNT
DT
5C LCD
CS
CNT
CK
MBL 5C LCD
CS
CNT
CK
A
+
+
+
+
1
5
8
4
F.RESET
+
AUX1
AUX3 PSW SB SB AFO MO DTMFIO CTO W/N CNTCK CNTDT DAST SFTST TO ASQ RSSI PCLK PLDT PLST UL SFTDT
CP538
R617
R641
R642
C623
Q501
L503
R501
R508
R509
R701
R511
R515
R523
6
R527
R726
C502
C504
X502 C514
C516
C518
C522
D501
D502
D504
C578 C587
CP501 CP502 CP503 CP504 CP505
CP508
CP509 CP510 CP511 CP512 CP513
CP514
CP516
IC502
25 1
26
CN501
L501
R505
R512
R517
R520
R521
R535
C501
C505
R542 R544
C517
D506
D510
D511
5
13
5
14
D509
1
4
1
4
CH
DN
CH
UP
100
50
51 75
76
TX-RX UNIT (X57-5963-02) (B/2) Component side view (J72-0988-09 B/2)
PC BOARD / PC板TK-868G
Component side
Foil side
Layer 1
Layer 2
Layer 3
Layer 4
Component side
Foil side
Layer 1
Layer 2
Layer 3
Layer 4
TX-RX UNIT (X57-5963-02) (B/2) Foil side view (J72-0988-09 B/2)
