KEPCO SC-FI Series User manual

Frequency to Current Signal Conditioner
SC-FI Series
99483 10/9/98
KESSLER-ELLIS PRODUCTS
10 Industrial Way East
Eatontown, NJ 07724
800-631-2165 • 732-935-1320
Fax [phone]
http://www.kep.com

THIS PAGE IS BLANK

INDEX
DESCRIPTION ..................................................................................1
SPECIFICATIONS.............................................................................1
TYPICAL WIRING HOOKUP.............................................................1
INPUT & OUTPUT SETTINGS..........................................................2
"L" OPTION SPECIFICATIONS ........................................................3
"L" OPTION TYPICAL WIRING.........................................................3
"L" OPTION INPUT & OUTPUT SETTINGS .....................................4
DIMENSIONS....................................................................................5
WARRANTY ......................................................................................5
DECODING PART NUMBER ............................................................5

THIS PAGE IS BLANK

SC-FI Signal Conditioner
1
Description:
The SC-FI is a two wire frequency to analog converter that
converts a pulse rate input into a 4-20 mA output signal
proportional to frequency or rate.
The input pulse rate is amplified and filtered by the input
signal conditioning circuitry. Two forms of input signal condi-
tioning are provided, one for magnetic pickups and the other
being an isolated pulse input.
The amplified frequency signal is then converted to an ana-
log signal using a precision frequency to analog converter.
The output stage derives it’s power from the output current
loop. The output stage converts the input signal into the
desired output range. Multi-turn potentiometers provide for
the necessary trimming of span and zero.
SPECIFICATIONS:
Operating Temperature
32°F (0°C) to 158°F (70°C)
High Level Pulse Input
Type: Opto-Isolated
Logic 1: 4-30 VDC
Logic 0: 0-1 VDC
Frequency Range: 0-10 kHz
Fault Protection: Reverse Polarity Protection
Over Voltage Protection
Isolation Voltage: 500 V
Fast Transient Immunity: 500 V
Maximum Rise Time: No Limit
Maximum Fall Time: No Limit
Magnetic Pickup Input
Differential Input
Input Impedance: 10 kΩ
Frequency Response: 0-3500 Hz
Trigger Sensitivity: 30 mV p-p
Over Voltage Protection: ±30 VDC
Frequency to Current Conversion
Range Selection: DIP Switch Selectable
Available Ranges: 150 Hz, 300 Hz, 600 Hz, 1200 Hz,
2500 Hz, 5000 Hz, 10,000 Hz
Factory Default: 1000 Hz
Analog Output
Accuracy: ±0.1% Span (@ 20°C)
Output Type: Two Wire, Loop Powered
Range: 4-20 mA (10 - 50 mA optional)
Compliance Voltage: 10 to 40 VDC
Loop Burden: < 10 VDC (less than 500 Ω)
Trim Controls: Zero & Span, non-interacting
Span (20 mA) Trim Range: 50% to 100% of full scale
Linearity: < ±0.1% Span
Output Voltage Effect: < ±0.002% Span/Volt
Temperature Effect: < 200 PPM/C°
Reverse Polarity Protected
Noise Content: < 0.2% Span
Response Time: 0.1 second (1 sec. jumper selectable)
Over-current Limiting: 35 mA
Output Loop Indicator: LED illuminates when output loop is
powered by proper polarity and blinks
proportionally to the input frequency.
Mounting Styles
DIN Rail Mount: Plastic enclosure with a snap fastener for
fitting to DIN 46 277 and DIN EN 50 022
assembly rails.
NEMA 4X: 4.92" x 4.92" NEMA 4X Enclosure for wall
mounting.
Explosion Proof: Aluminum enclosure for:
Class I, Division 1, Groups B, C & D
Class II, Division I, Groups E, F & G.
Simplified Block Diagram
F/V
V ref
Span
Zero
+
–
mV
I
nput
3
-30V
Input
Loop Powered
4-20mA Output
+
–
V/I
3.3kΩ
10kΩ 10kΩ
Typical Wiring Hookup
1• Magnetic pickup
2• Magnetic pickup
3• Shield (common)
4• Opto-isolator In +
5• Opto-isolator In –
6• Shield (common)
7• Output +
8• Output –
9• Do Not Use
REED
SWITCH
PULSER
DC
POWER
SUPPLY
ANALOG
4-20 mA
DEVICE
+
–
+–
1• Magnetic pickup
2• Magnetic pickup
3• Shield (common)
4• Opto-isolator In +
5• Opto-isolator In –
6• Shield (common)
7• Output +
8• Output –
9• Do Not Use
DC
POWER
SUPPLY
ANALOG
4-20 mA
DEVICE
+
–
+–
Turbine Meter with
Mag Pickup
Magnetic Pickup Hookup
High Level Pulse Hookup

SC-FI Signal Conditioner
2
INPUT & OUTPUT SETTINGS
REMOVING THE CASE:
The case must be removed to change switch settings. To
remove the case procede as follows:
Refer to FIGURE 1. Using finger tips, carefully pry the
case away from the terminal blocks (as shown with
dotted lines).
Pry far enough to release the restraining clips on both
sides of the case.
Press up on terminal block with thumbs. The assembly
will pop out allowing it to be removed from case.
FIGURE 1:
OUTPUT ADJUSTMENTS:
The unit has two potentiometers for adjustment. The upper
potentiometer controls the 20mA setpoint and the lower
potentiometer controls the 4mA setpoint (see Figure 2). The
4mA output range can be adjusted from 3mA to 5mA. The
20mA output range can be trimmed from 50% to 100% of
the selected range. To adjust the output, initially turn the
20ma adjust 20 turns CW for starting position. Input 0
frequency and adjust the 4 mA pot. Connect your maximum
frequency and adjust the 20 mA pot.
FIGURE 2:
1 2 3
4 5 6
7 8 9
INPUT FREQUENCY RANGE SETTINGS:
The appropriate range is selected by turning “ON” the corre-
sponding switch.
Range: Switch # “ON”
0-150Hz 1
0-300Hz 2
0-600Hz 3
0-1200Hz 4*
0-2500Hz 5
0-5000Hz 6
0-10000Hz 7
* Factory Default. The unit is setup at the factory for the
range 0-1000Hz.
RESPONSE TIME SETTING:
Switch #8 controls the output response time.
Switch #8 Response Time
OFF 0.1 second
ON 1 second
Turn switch #8 ON to provide damping of the output result-
ing in a 1 second response time.
LED INDICATOR:
The SC-FI has a LED which indicates the status of the unit.
The table below describes the 3 states for the LED.
LED STATUS: MEANING:
OFF The unit is off.
ON (constant) The unit is loop powered.
BLINKING The unit is receiving an input fre-
quency. The LED will blink at a rate
proportional to the input frequency.
(The LED may appear to be constant
at high input frequencies)
1 2 3
4 5 6
7 8 9
LED
INDICATOR
4 mA Adjust
(CCW-Down, CW-Up)
20 mA Adjust
(CCW-Up, CW-Down)

SC-FI Signal Conditioner
3
Description:
The SC-FI with option "L" is a two wire frequency to analog con-
verter that converts a pulse rate input into a 4-20 mA output signal
proportional to frequency or rate.
The SC-FI with option "L" is intended for use with lower full scale
input frequencies. Full scale frequencies of 15 Hz to 2000 Hz are
possible. The unit includes both a contact closure input and an
opto-isolated input. Output response time is selectable 1 or 10
seconds.
The amplified frequency signal is then converted to an analog
signal using a precision frequency to analog converter.
The output stage derives it’s power from the output current loop.
The output stage converts the input signal into the desired output
range. Multi-turn potentiometers provide for the necessary trim-
ming of span and zero.
SPECIFICATIONS:
Operating Temperature
32°F (0°C) to 158°F (70°C)
High Level Pulse Input
Type: Opto-Isolated
Logic 1: 4-30 VDC
Logic 0: 0-1 VDC
Frequency Range: 0-10 kHz
Fault Protection: Reverse Polarity Protection
Over Voltage Protection
Isolation Voltage: 500 V
Fast Transient Immunity: 500 V
Maximum Rise Time: No Limit
Maximum Fall Time: No Limit
Contact Closure Input
Sensor Compatibility- Requires an isolated, contact closure
Maximum Contact Voltage- 5 V
Maximum Contact Current- 0.12 mA
Nominal Pullup Resistance - 47 Kohm to 5 Vdc
Frequency Range - 0-100 Hz
Frequency to Current Conversion
Range Selection: DIP Switch Selectable
Available Ranges: 30 Hz, 60 Hz, 120 Hz, 240 Hz,
480 Hz, 960 Hz, 1920 Hz
Factory Default: 100 Hz
Analog Output
Accuracy: ±0.1% Span (@ 20°C)
Output Type: Two Wire, Loop Powered
Range: 4-20 mA (10 - 50 mA optional)
Compliance Voltage: 10 to 40 VDC
Loop Burden: < 10 VDC (less than 500 Ω)
Trim Controls: Zero & Span, non-interacting
Span (20 mA) Trim Range: 50% to 100% of full scale
Linearity: < ±0.1% Span
Output Voltage Effect: < ±0.002% Span/Volt
Temperature Effect: < 200 PPM/C°
Reverse Polarity Protected
Noise Content: < 0.2% Span
Response Time: 1 second (10 sec. jumper selectable)
Over-current Limiting: 35 mA
Output Loop Indicator: LED illuminates when output loop is
powered by proper polarity and blinks
proportionally to the input frequency.
Mounting Styles
DIN Rail Mount: Plastic enclosure with a snap fastener for
fitting to DIN 46 277 and DIN EN 50 022
assembly rails.
NEMA 4X: 4.92" x 4.92" NEMA 4X Enclosure for wall
mounting.
Explosion Proof: Aluminum enclosure for:
Class I, Division 1, Groups B, C & D
Class II, Division I, Groups E, F & G.
Simplified Block Diagram
Typical Wiring Hookup (option "L")
1• Magnetic pickup
2• Magnetic pickup
3• Shield (common)
4• Opto-isolator In +
5• Opto-isolator In –
6• Shield (common)
7• Output +
8• Output –
9• Do Not Use
REED
SWITCH
PULSER
DC
POWER
SUPPLY
ANALOG
4-20 mA
DEVICE
+
–
+–
Contact Closure Hookup
High Level Pulse Hookup
F/V
V ref
Span
Zero
–
+
Contact
Closure
Input
3-30V
Input
Loop Powered
4-20mA Output
+
–
V/I
3.3kΩ
47kΩ
+5V
1• Not Used
2• Contact Closure In
3• Shield (common)
4• Opto-isolator In +
5• Opto-isolator In –
6• Shield (common)
7• Output +
8• Output –
9• Do Not Use
DC
POWER
SUPPLY
ANALOG
4-20 mA
DEVICE
+
–
+–
Flowmeter with
Switch Closure Output
"L" Option SPECIFICATIONS

SC-FI Signal Conditioner
4
"L" Option INPUT & OUTPUT SETTINGS
REMOVING THE CASE:
The case must be removed to change switch settings. To
remove the case procede as follows:
Refer to FIGURE 1. Using finger tips, carefully pry the
case away from the terminal blocks (as shown with
dotted lines).
Pry far enough to release the restraining clips on both
sides of the case.
Press up on terminal block with thumbs. The assembly
will pop out allowing it to be removed from case.
FIGURE 1:
OUTPUT ADJUSTMENTS:
The unit has two potentiometers for adjustment. The upper
potentiometer controls the 20mA setpoint and the lower
potentiometer controls the 4mA setpoint (see Figure 2). The
4mA output range can be adjusted from 3mA to 5mA. The
20mA output range can be trimmed from 50% to 100% of
the selected range. To adjust the output, initially turn the
20ma adjust 20 turns CW for starting position. Input 0
frequency and adjust the 4 mA pot. Connect your maximum
frequency and adjust the 20 mA pot.
FIGURE 2:
1 2 3
4 5 6
7 8 9
INPUT FREQUENCY RANGE SETTINGS:
The appropriate range is selected by turning “ON” the corre-
sponding switch.
Range: Switch # “ON”
0-30Hz 1
0-60Hz 2
0-120Hz 3*
0-240Hz 4
0-480Hz 5
0-960Hz 6
0-1920Hz 7
* Factory Default. The unit is setup at the factory for the
range 0-100Hz.
RESPONSE TIME SETTING:
Switch #8 controls the output response time.
Switch #8 Response Time
OFF 1 second
ON 10 second
Turn switch #8 ON to provide damping of the output result-
ing in a 10 second response time.
LED INDICATOR:
The MS660 has a LED which indicates the status of the
unit. The table below describes the 3 states for the LED.
LED STATUS: MEANING:
OFF The unit is off.
ON (constant) The unit is loop powered.
BLINKING The unit is receiving an input fre-
quency. The LED will blink at a rate
proportional to the input frequency.
(The LED may appear to be constant
at high input frequencies)
1 2 3
4 5 6
7 8 9
LED
INDICATOR
4 mA Adjust
(CCW-Down, CW-Up)
20 mA Adjust
(CCW-Up, CW-Down)

SC-FI Signal Conditioner
5
Dimensions
3.88 (98.5)
2.95 (75)
1.40 (35.5)
.89
(22.5)
DIN Rail Mount
4.92
(125)
4.92
(125)
4.21
(107)
4.21
(107)
Mounting holes molded
directly under cover screws.
Max. screw head .29"
(Typ. 4 places)
TOP VIEW
PANEL INSTALLED
To access terminals, remove
cover and 4 panel screws.
2.95
(75)
1.93
(49)
.18 (5)
.43
(11)
SIDE VIEW
NEMA4X
Explosion Proof Enclosure
Decoding Part Number
Example SC-FI D ET
Series
FI= Frequency to Current
Mounting:
B= Nema 4X
C= Explosion Proof
D= DIN Rail
Options:
ET= Extended Temp (-20°to 85°C)
L = Low Count Speed for Contact Closure Inputs
50 = 10-50 mA output
Accessories: (add to end of part number)
DR-4= 4" DIN Rail
WARRANTY
This product is warranted against defects in
materialsandworkmanshipforaperiodoftwo
(2) years from the date of shipment to Buyer.
The Warranty is limited to repair or replace-
ment of the defective unit at the option of the
manufacturer.Thiswarrantyisvoidiftheprod-
ucthas beenaltered,misused, dismantled,or
otherwise abused.
ALL OTHER WARRANTIES, EXPRESSED
ORIMPLIED,AREEXCLUDED,INCLUDING
BUT NOT LIMITED TO THE IMPLIED WAR-
RANTIESOFMERCHANTABILITYANDFIT-
NESS FOR A PARTICULAR PURPOSE.
Kessler - Ellis Products Co.
10 Industrial Way East
Eatontown, NJ 07724
(732) 935 - 1320
Toll Free 800 - 631 - 2165
Fax (732) - 935 - 9344
http://www.kep.com
5.44
(138)
4.06
(103.2)
2 MTG LUGS
0.31 DIA.
5.06
(129)
7.125
(181)
3/4” NPT (2) HLS.
(feed thru hubs)
