Kestronics SC600 User manual

SC600 User’s Manual
WinCE. NET Rugged Portable Data Terminal
Jan/23/2006 Ver: 0.55

Table of Contents
Chapter 1. Introduction......................................................................1-1
1.1 About this Manual............................................................................1-1
1.2 User and Product Safety ..................................................................1-1
1.3 Radio Frequency Interference Information......................................1-3
1.3.1 FCC Radiation Exposure Statement.......................................1-3
1.4 Product Labeling..............................................................................1-5
1.5 System Specifications ......................................................................1-6
1.6 Environment Standard .....................................................................1-8
1.7 Warranty and after service...............................................................1-8
Chapter 2. Getting Started..................................................................2-1
2.1 Check the package ...........................................................................2-1
2.2 General View of the PDT.................................................................2-2
2.2.1 PDT front side view................................................................2-2
2.2.2 PDT back side view................................................................2-3
2.3 Charging the Battery Pack...............................................................2-5
2.3.1 Installing the battery pack.......................................................2-5
2.3.2 Charging the battery pack with Power Adapter......................2-7
2.3.3 Charging the battery pack with Single Dock..........................2-8
2.4. Handling the PDT.........................................................................2-10
2.4.1 Starting the PDT ...................................................................2-10
2.4.2 Power on / off .......................................................................2-10
2.4.3 Calibration of the touch Screen ............................................2-11
2.4.4 Adjusting the brightness........................................................2-11
2.4.5 To mute the Sound ................................................................2-12
2.4.6 Using the Stylus ....................................................................2-12
2.4.7 Using the Keypad..................................................................2-12
2.5 Navigating the Display..................................................................2-22
2.5.1 Setting Time and Date...........................................................2-22
2.5.2 Entering the Data ..................................................................2-22
2.5.3 The Command Bar................................................................2-23
2.5.4 The Task Bar.........................................................................2-23
2.5.5 The Soft Keypad ...................................................................2-24
2.5.6 Setting Up Wireless LAN RF ...............................................2-24
2.5.7 Scanning Barcode.................................................................2-25
2.5.8 Help.......................................................................................2-26

2.6 Power management........................................................................2-27
2.6.1 Suspend Mode.......................................................................2-27
2.6.2 Resuming..............................................................................2-28
2.7 Resetting the PDT..........................................................................2-28
2.7.1 Software (Warm) Reset.........................................................2-28
2.7.2 Cold Reset.............................................................................2-28
Chapter 3. Setting ..............................................................................3-1
3.1 Introduction......................................................................................3-1
3.2 Control Panel ...................................................................................3-1
3.2.1 BarCode Setting......................................................................3-2
3.2.2 Symbologies List....................................................................3-8
3.2.3 Bluetooth Device Properties.................................................3-24
3.2.4 Certificates............................................................................3-26
3.2.5 Control Center.......................................................................3-28
3.2.6 Date/Time .............................................................................3-32
3.2.7 Dialing Properties.................................................................3-32
3.2.8 Display Properties.................................................................3-34
3.2.9 Input Panel............................................................................3-36
3.2.10 Internet Options ..................................................................3-37
3.2.11 Keyboard.............................................................................3-39
3.2.12 Network and Dial-up Connections .....................................3-40
3.2.13 Owner..................................................................................3-44
3.2.14 Password.............................................................................3-45
3.2.15 PC Connection....................................................................3-46
3.2.16 Power..................................................................................3-47
3.2.17 Regional Settings ................................................................3-49
3.2.18 Remove Programs ...............................................................3-50
3.2.19 Storage Manager.................................................................3-51
3.2.20 Stylus ..................................................................................3-52
3.2.21 System.................................................................................3-53
3.2.22 Volume & Sounds Properties..............................................3-55
3.3 Taskbar and Start Menu.................................................................3-56
Chapter 4. Communication ................................................................4-1
4.1 Installing & Setting Up Microsoft ActiveSync................................4-1
4.1.1 Installing Microsoft ActiveSync on the Host PC....................4-1
4.1.2 Connecting PDT to Host PC...................................................4-1
4.2 Using ActiveSync ............................................................................4-1
4.2.1 Setting up a Partnership..........................................................4-1

4.2.2 ActiveSync File Synchronization............................................4-3
4.3 Networking ......................................................................................4-3
Chapter 5. Software Applications.......................................................5-1
5.1 Introduction......................................................................................5-1
5.2 Software Applications......................................................................5-1
5.2.1 Inbox.......................................................................................5-1
5.2.2 Internet Explorer...................................................................5-10
5.2.3 Media Player.........................................................................5-13
5.2.4 Messenger.............................................................................5-13
5.2.5 Microsoft WordPad...............................................................5-14
5.2.6 Remote Connection...............................................................5-19
5.2.7 Windows Explorer................................................................5-20
5.3 DiskOnChip...................................................................................5-22
5.3.1 Saving to Flash......................................................................5-22
5.3.2 DiskOnChip Location...........................................................5-22
5.3.3 DiskOnChip Size ..................................................................5-23

1
-
1
Chapter 1.Introduction
Congratulations on purchasing the SC600 Portable Data Terminal (PDT), a Microsoft
Windows®CE .Net rugged PDT. Its special combination of features makesit perfect for
using in a wide range of applications. These features as:
λIntel® XScaleTM PXA255 400MHz 32 bits RISC Processor
λWindows® CE .NET 4.2 Operating System
λ64/128/256 MB SDRAM & 64/128 MB Flash ROM
λOpen Architecture: User Accessible SD/CF/PCMCIA Slot
λ240 x 320, 3.5” Color TFT Display with Touch Panel
λ1 Numeric Keyboardswith LED backlight
λ802.11b Radio Support (Bluetooth Optional)
λOptionally Built-in GSM/GPRS Module
λIntegrated 1D or 2D Barcode Scanner
1.1 About this Manual
The following chapters contained in this manual are:
Chapter 1: Introduction --- Present the general information about the PDT.
Chapter 2: Getting started --- Describe the basic use of the PDT.
Chapter 3: Setting –Provide basic instructions for customizing the PDTby adjusting
settings.
Chapter 4: Communication --- Describe how to use all kinds of communication of the
PDT.
Chapter 5: Software Application --- Offer the procedures of Software implement.
1.2 User and Product Safety
◆Do not stare into the laser beam directly or shine it into eyes.
◆Never use strong pressure onto the screen or subject it to severe impact, as the LCD
panel could become cracked and possibility cause personal injury. If the LCD panel
is broken, never touch the liquid inside, for such contact would irritate the skin.
◆Although the SC600 PDThas been passed the test of IP54 standard for water and
dust resistance, avoid prolonged exposure to rain or other concentrated moisture.
For these conditions exceed the IP54 standard, and could result in water or other

1
-
2
contaminants entering into the PDT.
◆Use only the approved AC Adapter with the PDT. Use of an unapproved AC Adapter
could result in electrical problems, or even cause a fire or electrical shock to the
user.
◆Be sure that only authorized supplier are allowed to disassemble and reassemble the
device. If the device or parts has been damaged due to any wrong handling, shall
void the product and parts warranty.
◆Always make back-up copies of all important data. Easy done by using a cable or
Single Cradle (sold by optional) to transfer data to the computer. Manufacturer is
not liable for any data damages or data loss caused by deletion or corruption by
using of this device, or due to the drained battery.
◆Lithium-ion battery packs might get hot, explode, ignite and/or cause serious injury
if exploded by abusive using. Please follow the safety warnings listed as below:
?Do not place the battery pack in fire or heat the battery.
?Do not install the batterypack backwards so the polarity is reserved.
?Do not connect the positive Battery pack with negative battery pack to each other with
any metal object (like wire).
?Do not carry or store battery pack together with metal objects.
?Do not pierce the battery pack with nails, strike the battery pack with a hammer,
step on the battery pack or otherwise put it to strong impacts or shocks.
?Do not solder directly onto the battery pack.
?Do not expose battery pack to liquid, or allow the battery contacts to get wet.
?Do not disassemble or modify the battery pack. The battery pack contains
safety and protection devices, which, if damaged, may cause the battery pack
to generate heat, explode or ignite.
?Do not discharge the battery pack using any device except for the specified device.
When it is used in devices other than the specified devices, the battery pack can
be damaged or its life expectancy reduced. If the device causes any abnormal
current to flow, it may cause the battery pack to become hot, explode or ignite
and cause serious injury.
?In the event the battery pack leaks and the fluid gets into one’s eye, do not rub the
eye. Rinse well with water and immediately seek medical care. If left untreated,
the battery fluid could cause damage to the eye.

1
-
3
1.3 Radio Frequency Interference Information
1.3.1 FCC Radiation Exposure Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.

1
-
4
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. To maintain compliance with FCC RF exposure compliance requirements,
please avoid direct contact to the transmitting antenna during transmitting.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Caution: Please also note that SC600 is limited in CH1~CH11 for 2.4GHz by
specified firmware controlled in U.S.A.
The FCC ID of SC600 is TQ2-SC600PDT-BW

1
-
5
1.4 Product Labeling
The PDThas several labels as showed in Figure 1-1 and 1-2.
Figure 1-1Product Labeling (Front side view)

1
-
6
Figure 1-2Product Labeling (Back side view)
1.5 System Specifications
The SC600 PDTdetailed specifications as follows. Unless otherwise noted, all the
specifications are subject to change without prior notification.
Table 1-1System Specification
SC600
Processor -400MHz Intel PXA255 32 bits RISC CPU
Memory -64 or 128MB Flash ROM
-64,128 or 256MB SDRAM
Display -240 x 320 3.5” TFT 256K Color LCD with LED
backlight
Audio -One mono speaker
-2.5mm DIA Stereo Earphone Jack with Microphone
input

1
-
7
SC600
Radio Support -Wireless LAN: 802.11b
-Bluetooth: Class II (optional)
-GSM/GPRS: (optional)
Communication Ports
-USB: Support USB v1.1 both host and client.
(PDT and Cradle)
-Serial: RS232 via optional cable or Cradle.
Scan Engine -Default: Opticon Laser (1D) Engine
-Optional: HHP 2D Imager.
Expansion Slot -One Compact Flash Type-II slot
-One SD Card slot (support SD memory only)
LED -One Triple-Color LED for Charger Indicator and
Alarm Notification
-One Dual-Color LED for Scanner Indicator
Power System
-Standard Li-Ion Battery Pack, 3.7VDC, 3150mAh
-Advanced Smart Battery with Gas-Gauge
-Built-in Battery Charger
-2.4VDC/15mAh rechargeable backup battery
-One Battery Cover Sensor Switch
-Power Adapter: 100~240V AC, 50/60Hz Input ;
5VDC/2.6A, 3A Output
Button/Key
-Power button
-4-way navigation button
-4 Application Keys
-3 Scanner Enable Keys
-SW Reset input button
-16 Alpha-numeric keyboard
Dimensions and
Weight
-Dimensions: 192.5mm (L) x 91.3mm / 78mm(W) x
42.2mm / 60.6mm (H)
-Weight: 560g with Standard Battery Pack
500g without Battery Pack
Color -Black

1
-
8
SC600
Peripherals and
Accessories
-Optional: RS232 Serial Cable for Terminal / USB
Host Cable for Terminal / High-Capacity Li-Ion
Battery Pack (3.7VDC, 4000 mAh) / RFID Card
Cover / Single Dock / Pistol Grip/ 4 Slot Battery
Charger / Car Adapter / Holster / Protect Film
Software -Microsoft Windows CE.NET 4.2 Professional
1.6 Environment Standard
Table 1-2 Environment Standard
Operating Temperature 14oF ~ 122oF( -10oC ~ 50oC)
Storage Temperature -4oF ~ 158oF (-20oC~ 70oC)
Humidity 5% ~ 80% (non-condensing)
Drop 5ft (1.5m) Drop to Concrete
Water & Dust proof IP54 Certificated & IP64 Compliant
Vibration MIL STD 810F
1.7 Warranty and after service
Should this PDTbe malfunctioned, please contact your original retailer providing
information about the product name, the serial number, and the details about the
problem.

2
-
1
Chapter 2.Getting Started
2.1 Check the package
Open the package and check all the parts are inside without shortage and damage:
Figure 2-1Inside the package
1. SC600 Terminal
2. Stylus
3. USB Client Cable for Terminal
4. Earphone/ Microphone Set
5. Standard AC Adapter 5VDC/2.6A
6. AC Power Cord
7. Standard Battery Pack (3.7VDC, 3000 mAh)
8. CF Card Support Guide
9. Quick Guide (Not Shown)

2
-
2
2.2 General View of the PDT
2.2.1 PDT front side view
Figure 2-2PDT Front side view

2
-
3
2.2.2 PDTback side view
Figure 2-3PDTback side view

2
-
4
Table 2-1Description of PDT General View
“Red” color Reading barcode1 Scanner LED Indicator
“Green” color Successful reading
“Red” color Charging battery2 Charge LED Indicator
“Green” color Battery charged full
3 LCM / Touch Panel Do specific action through touch panel by stylus
4 Left Scan key
Right Scan key
Scan key
Start scanning the barcode by pressing any one of
these three scan keys
5 Power key Puts the terminal into and wakes the terminal from
suspend mode.
6 F1 ~ F4 key The four application keys, hot keys of application
program defined by end user.
7 Navigation key Navigation keys for left, right, up and down
directions
8 Alpha-Numeric keys Numeric keys, Change to Alpha keys after pressing
Alpha key.
9 Alpha key Toggle Alpha-mode for Alpha-Numeric keys
10 Fn key This key is used in combination with other keys to
type special characters and perform system functions.
11 Enter key This key confirms data entry
12 Earphone Jack
Connector
A connector to plug a earphone
13 USB / Serial /
Synchronization port
A connector to support USB Host/Client and serial
functions
14 Scan window A window for scanning of barcode reader
15 Stylus Use the stylus for selecting items and entering
information.
16 Battery Cover Protect Battery pack, keep the switch of battery cover
to leave system from suspend mode
17 Battery cover Latch To keep Battery Cover locked
18 Hand Strap This strap can be sealed tighter or looser
19 Speaker 1.5W speaker for audio sound
20 DC Power Jack A connector to support AC power.
21 End Cap Protect CF slot and SD slot from dust and water

2
-
5
2.3 Charging the Battery Pack
Before using the PDT, perform the basic procedure of charging the battery pack
through the following steps.
2.3.1 Installing the battery pack
1. On the PDTattached with a hand-strap, detach and loose the hand-strap.
Figure 2-4Release the Hand strap from PDT
2. Turn the locking screws (right and left) downwards and lift the battery cover away
from the PDT.
Figure 2-5Detach the battery cover from PDT

2
-
6
3. Insert the battery pack into the battery compartment with the label facing out, and
ensuring the battery snaps into place.
Figure 2-6Insert the battery pack
4. Replace the battery cover by inserting the top first, and then press the bottom in firmly.
Turn the locking screws (right and left) upwards to secure the cover to the PDT.
Figure 2-7Replace the battery cover

2
-
7
5. Charge time. For the first time to charge the battery pack needs approximately 6
hours. Subsequent charging time needs approximately 4hours.
◆.When charging the battery pack, the charge LED indicator on the PDTturns on
Red. After the battery pack is fully charged, the charge LED indicator turns to
Green.
2.3.2 Charging the battery pack with Power Adapter
1. Connect the Power cord to the Power adapter.
2. Plug in the connector of the power adapter.
3. Connect the power cord to a power source.
Figure 2-8Charging with power adapter
◆When charging the battery pack, the charge LED indicator on the PDTturns on
Red.
◆After the battery pack is fully charged, the charge LED indicator turns to Green.

2
-
8
2.3.3 Charging the battery pack with Single Dock
a) Leave the battery pack inside of the PDT
1. Connect the Power cord to the Power adapter
2. Connect the power cord to a power source
3. Plug in the connector of the power adapter with Single Dock
4. Insert the PDTinto the Single Dock
Figure 2-9Charging with Single Dock
◆When charging the battery pack, the charge LED indicator on the PDT turns on
Red.After the battery pack is fully charged, the charge LED indicator turns to
Green.
CAUTION: Single Cradle Adapter is 5Vdc/6.5A, which is different from PDT
Adapter (5Vdc/2.6A). Please use the Single Cradle Adapter only.
b) Place the spare battery pack into the Single Cradle’s spare Battery charging slot
1. Connect the power cord to the power adapter
2. Connect the power cord to a power source
3. Plug in the connector of the power adapter with Single Cradle
4. Insert the Battery pack into the Single Cradle’s spare Battery slot.
