Ketra N4-1-TT-BK User manual

N4
TABLE TOP HUB
Instlltion Guide
Model
N41-TTBK  Ketra N4 Table Top Hub

Risk of electric shock. Use in dry locations only.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: ( 1 ) this device may not cause harmful interference, and ( 2 )
this device must accept any interference received, including interference that may cause
undesired operation.
Maintain at least 6 feet of spacing between any KetraNet Mesh product and Wi-Fi routers
and access points.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
• This device may not cause interference.
• This device must accept any interference, including interference that may cause
undesired operation of the device.
!Wrning
2|N4 INSTALLATION GUIDE
770-000027-01 r18
© 2019 Ketra, Inc. All rights reserved

Contents
Product Overview 4
Explanation of Indicator Lights 5
Included Components/Specs 6
Specifications 6
Dimension Drawings 7
Wiring Diagrams 8
Pre-Installation 9
N4 Placement 9
Network Configuration 9
Installation 10
Mount the Hub (optional) 10
Apply Power to the Hub 11
Connect the Hub to the LAN (Local Area Network) 12
Additional Tasks 13
Controlling with Design Studio 13
Controlling with the Ketra Mobile App 13
Warranty  Tech Support 14
3|N4 INSTALLATION GUIDE
770-000027-01 r18
© 2019 Ketra, Inc. All rights reserved

Product Overview
Ketra’s N4 Hub forms a bridge between Ketra products and Ketra digital
interfaces such as Design Studio, mobile app, and API commands.
With multiple N4s, a user can integrate KNets, allowing for seamless installations no
matter how large. Using an Internet connection, the Hub can connect to Ketra’s cloud
servers to enable backup and remote maintenance functions.
fig. 1
fig. 2
continued on next page
Ethernet
KetraNet Mesh
KetraNet Link
IEC C8 Power
Connnection
Reset Switch
Micro USB
Wi-Fi
RJ 45 Jacks
Power
4|N4 INSTALLATION GUIDE
770-000027-01 r18
© 2019 Ketra, Inc. All rights reserved

PRODUCT OVERVIEW
Explanation of Indicator Lights
The N4 indicates its status using the lights on the front.
Indicator Light Behavior
Symbol Name Expected Behavior
Power • Red briefly at startup
• White at all other times while N4 is on
Wi-Fi • For future use
Ethernet • Red briefly at connection to LAN (while N4 waits for an
IP address)
• White at all other times while network connection active
• Dark if no LAN connection is detected
• Blinking red if N4 detects a network wiring loopback
KetraNet Mesh • Blinks red when a “remote access” message is sent
or received
• Solid red when the hub is configured for remote access,
but the hub cannot connect to the remote access server
KetraNet Link • Blinking white when a message is sent or received
over KetraNet Link (wired communication with other
Ketra devices)
• Red when no Internet connection is detected
• Dark at all other times
5|N4 INSTALLATION GUIDE
770-000027-01 r18
© 2019 Ketra, Inc. All rights reserved

Included Components/Specs
Specifications
( 1 ) N4 Conduit-Mounted Hub ( 1 ) IEC C8 Power Cord
Environmental
Operating Temperature -20˚ to 40˚C
Storage Temperature -20˚ to 80 ˚C
Humidity 0  95%, Non-condensing
Certification UL, cUL, FCC Class B, RoHS
Location UL Damp Location, IP20
Mechanical
Weight 15 oz (0.43 kg)
Housing Material Polymer
Power
Voltage 120 V
Power Consumption 5 W
Current 0.041 A at 120 V
Enclosure  Connections
Connections (Class 1)
AC Power In IEC C8 Power Connection
Data Connections
Connectivity Technology Wireless, Wired
Data Link Protocol Ethernet, Fast Ethernet,
IEEE 802.11b, IEEE 802.11g
KetraNet Mesh™ Wireless
USB Port 1  Micro-B USB console port,
for firmware updates
6|N4 INSTALLATION GUIDE
770-000027-01 r18
© 2019 Ketra, Inc. All rights reserved

Dimension Drawings
fig. 3
fig. 4
1.3 in, 34.2 mm
3.9 in,
98.0 mm
5 in, 127 mm
2.91 in, 74 mm
2.6 in,
66 mm
Keyholes designed
for No. 6 English
Hardware
6.1 in, 154 mm
7|N4 INSTALLATION GUIDE
770-000027-01 r18
© 2019 Ketra, Inc. All rights reserved

Wiring Diagrams
Key
Key
Wi-Fi Router
Receptacle
(by others)
KetraNet Mesh wireless network
KetraNet Mesh wireless network
CAT5E, 4 pair, unshielded
CAT5E, 4 pair, unshielded
KetraNet Mesh wireless network
KetraNet Mesh wireless network
E5EPC
Ketra N4
Example Installation Layout
KNet: N4 + 49 Ketra Wireless Devices
KETRA
N4
KETRA
NETWORK 1
KETRA
NETWORK 5
KETRA
N4
KETRA
NETWORK 2
KETRA
N4
KETRA
NETWORK 3
KETRA
N4
KETRA
N4
KETRA
N4
KETRA
NETWORK 6
KETRA
NETWORK 7
NETWORK
SWITCH
120 V , 60 Hz
MAINS SUPPLY
L1 KETRA
N4
KETRA
NETWORK 4
KETRA
N4
120 V , 60 Hz
MAINS SUPPLY
L1
KETRA
NETWORK 8
NOTE:
WHEN DAISY CHAINING,
LIMIT N4'S TO 10 UNITS
MAX PER DAISY CHAIN.
TO NETWORK
SWITCH / MODEM,
INTERNET
E5E
E5E
E5E
E5E
E5E
E5E
E5E
E5E
E5E
(BY OTHERS)
KEY
L1 12 AWG, 3 WIRE
KETRANET MESH
WIRELESS NETWORK
E5E CAT5E, 4 PAIR, UNSHIELDED
GENERAL NOTES:
1. KETRANET MESH IS KETRA'S
WIRELESS CONTROL PROTOCOL.
2. A NODE IS A KETRANET MESH
ENABLED WIRELESS DEVICE.
3. 50 KETRANET MESH NODES MAX.
PER INSTALLATION NETWORK.
4. ALL KETRANET MESH NODES TO
BE INSTALLED WITHIN 50'-0"
RANGE OF THE NEAREST NODE.
5. 10 N4'S MAX. PER DAISY CHAIN
SERIES.
SHEET
OF
SHEET NAME
SCALE:
CHECKED BY:
DRAWN BY:
DATE:
REVISION #:
DRAWING #:
DRAWING TYPE:
FOR REFERENCE ONLY
NOT FOR
CONSTRUCTION
6231 E. STASSNEY LANE
BUILDING 13, SUITE 400
AUSTIN, TX 78744
P: 512.872.4349
1 1
WD
00
06/01/2017
LEB
CEH
NTS
KETRA
MULTI-NETWORKS, N4,
STAR-TOPO, SWITCH
PC
L1
E5E
E5E
8|N4 INSTALLATION GUIDE
770-000027-01 r18
© 2019 Ketra, Inc. All rights reserved

Pre-Installation
N4 Placement
For ideal KetraNet Mesh wireless performance, position the N4 according to these guidelines:
• Keep within range: Place the N4 within 50 ft (15.24 m) of at least one of the devices it will control.
Ideally, place as close as possible to all devices it will control.
• Avoid obstructions: Avoid having metal obstructions or walls between the N4 and the nearest device it
will control.
• Avoid metal enclosures.
• Separate from Wi-Fi devices: Maintain at least 6 ft (1.83 m) of spacing between any KetraNet Mesh
product and Wi-Fi routers and access points.
The N4 is UL Damp Location-listed.
The N4 has a suggested clearance of 4 in (101.6 mm) to ensure visibility of indicator lights and access to all
ports (see fig. 5).
Network Configuration
The modem or router to which the N4 is connected must include a DHCP server from which the N4 can
obtain an IPv4 address. (For the vast majority of modems and routers, this is the default.)
All N4s that will be part of an installation together must be on the same LAN (Local Area Network) subnet.
fig. 5
4 in
(101.6 mm)
4 in
(101.6 mm)
9|N4 INSTALLATION GUIDE
770-000027-01 r18
© 2019 Ketra, Inc. All rights reserved

Installation
STEP 1
Mount the Hub (optional)
The hub can be placed on a flat surface, or it can be mounted vertically or horizontally. If you do not intend
to mount your hub, skip this section.
To mount the hub, use the two keyholes on the bottom. The keyholes are designed for #6 screws.
Use the distance measurements in the image below to determine where to place the screws.
fig. 6
2.91 in, 74 mm
2.6 in,
66 mm
Keyholes designed for
No. 6 English Hardware
10|N4 INSTALLATION GUIDE
770-000027-01 r18
© 2019 Ketra, Inc. All rights reserved

INSTALLATION
STEP 1
Apply Power to the Hub
Connect the N4 to power at the IEC C8 power connector. Use the provided IEC C8 power cord (see fig. 7).
fig. 7
Note: Once power is connected, the N4’s power indicator light will come on. It will be red while
the N4 boots up; afterward, it will turn white.
IEC C8 power
connection
IEC C8
power cord
11|N4 INSTALLATION GUIDE
770-000027-01 r18
© 2019 Ketra, Inc. All rights reserved

INSTALLATION
STEP 3
Connect the Hub to the LAN (Local Area Network)
Once a connection is detected, the N4’s Ethernet indicator, , will come on white.
DIRECT CONNECTION TO MODEM OR ROUTER
• Use a CAT5 or equivalent Ethernet cable
• Cable can be no more than 328 ft (100 m)
CAT5 or equivalent
Ethernet cable
Use either RJ45 port
Modem/Router
12|N4 INSTALLATION GUIDE
770-000027-01 r18
© 2019 Ketra, Inc. All rights reserved

Additional Tasks
Controlling with Design Studio
For simple instructions on establishing an N4 installation in Design Studio, refer to the N4 edition of our
Design Studio Quick Start Guide.
For more advanced instructions on establishing an N4 installation in Design Studio, refer to the following
portions of the Design Studio User Manual:
• Getting Started > Installation Management > Creating an Installation
• Operating an Installation > Organization
If you are unable to discover your N4s in Design Studio, confirm one of the following is true:
Option 1:
-Your computer is on the same subnet as all N4s
OR
Option 2:
-Your computer is on the same network as the N4s
-All N4s are on the same subnet
-The N4s have internet access
-Your computer has internet access
Controlling with the Ketra Mobile App
For instructions on using an N4 with the Ketra app, refer to our Mobile App Manual.
If you are unable to discover your N4s in the Ketra app, confirm one of the following is true:
Option 1:
-Your mobile device is on the same subnet as all N4s
OR
Option 2:
-Your mobile device is on the same network as the N4s
-All N4s are on the same subnet
-The N4s have internet access
-Your mobile device has internet access
13|N4 INSTALLATION GUIDE
770-000027-01 r18
© 2019 Ketra, Inc. All rights reserved

Warranty  Tech Support
Limited warranty terms can be found at:
www.ketra.com/warranty
For questions and technical support please contact:
(844) 5886445
k[email protected]
