Kettler 0393901-0200 User manual

Large Aluminium
Storage Box
0393901-0200
Assembly Instructions
Nov 2022
IMPORTANT
PLEASE KEEP THIS BOOKLET FOR FUTURE REFERENCE.
THIS IS IMPORTANT INFORMATION REGARDING THE USE AND
CARE OF YOUR GARDEN FURNITURE.

Parts List
Do not discard
any of the
packaging
until you have
checked that
you have all the
parts and the
pack of xings.
A1 Side
plate-
short
A2 Side
plate-
short
B1 Side
plate-long
B2 Side
plate-long
CBottom
shelf
DTop cover EWasher FBolt M6 x
15(mm)
GBolt M6 x
45(mm)
HBolt cap
IAllen Key JNut KNut Cover LWrench MBolt M6 x
20(mm)
NBolt M6 x
10(mm)
OHandle
holder
PHandle QSpring
washer
x1
x16
x2
x1
x8
x2
x1
x1
x2
x1
x2
x1
x18
x2
x1
x1
x1
x1
x4

Assembly
Helpful advice before you begin:
1. We suggest you spend a short time reading through this leaet and then follow the simple
step by step instructions.
2. Do not discard any of the packaging until you have checked that you have all the parts and
the pack of ttings.
3. Assemble this product on a soft surface.
4. To ensure an easier assembly, we strongly advise that all ttings are only nger tightened
during initial assembly. Only upon completion of the assembly should all xing points be
fully tightened.
5. We recommend a periodic check on all xing points to make sure they remain fully tightened.
6. Keep ttings out of children’s reach.
7. Do not use any other tools other than those recommended to build this product.
8. Please do not use substitute parts. Use only additional or replacement parts supplied by Kettler.
9. In the unlikely event that this product has missing or damaged parts, please visit our website
www.kettler.co.uk/shop.
A1
B1
A2
E N I H
E F I H
1

Assembly
H
IFE
B2
C
2
3

Assembly
HIFE
ENIH
ENIH
4
5

Assembly
O
O
PE
Q
M
I
H
D
H
G
I
E
E
J
K
L
6
7

Assembly
Finished
8

Maintenance and Care Instructions
Attention
Please be aware that painted/varnished surfaces can be damaged by sunscreens and
oil based products.If the surface of your Kettler leisure furniture comes into contact
with sunscreens, the surface is to be cleaned without delay as described above.
Only in this way can lasting discolouration of the surface by the ingredients of the
sunscreen be prevented.
• This product may only be used for its intended purpose for residential premises. Any other uses
may aect the warranty.
• Kettler furniture is designed to be left outdoors all year round.
• We recommend you clean your Kettler furniture at the beginning and end of the season.
• To clean your Kettler furniture, use warm soapy water only. Never use abrasive chemicals or
cleaning agents. To lengthen the life of your product we recommend the Kettler Multi-surface
cleaner from our after-care range available to purchase from our website. Tree sap and bird
droppings should be cleaned o immediately.
• Kettler furniture can be covered – we recommend that you use Kettler tailored covers (where
available) or universal breathable covers.
• Moving parts such as locking mechanisms, catches and joints need to be lubricated where
necessary.
• This product is 100% recyclable. At the end of the products life, please dispose of responsibly.
• Colours may vary slightly

• This product may only be used for its intended purpose as furniture for residential properties.
• Check all components regularly for correct function, damage and loose connections especially
at the start of the season and at 1-2 month intervals dependent on use.
• Damaged components may endanger your safety or shorten the life of the product. Replace all
damaged parts immediately. Use only spare parts manufactured by Kettler. Should you wish to
purchase spare parts, they can be ordered directly from: www.kettler.co.uk/shop
• Kettler will not be responsible for damaged caused by improper use.
For Your Safety
Attention
• Whilst assembling this product keep out of the reach of children. (Choking hazard –
contains small parts)
• Ensure that your working area is free of possible sources of danger, for example don’t
leave any tools lying around.
• Always dispose of packaging material in such a way that it may not cause any danger.
There is always a risk of suocation if children play with plastic bags!
• We reserve the right to make changes for technical reasons.
www.kettler.co.uk
Warranty For Home Use
This product is covered by a 3 year
warranty against manufacturing faults.
This warranty applies to domestic use
only. It does not cover commercial use,
mis-use or accidental damage.
To validate your warranty, register
at www.kettler.co.uk and quote
the product code from the front of
this booklet.
