KEYDEX UG-AQ1401A User manual

Manual For Breeding Box
Please turn off the powerhead circulation pump before installing the
breeding box.
Attach the two support bolts on the bottom of the breeding box, then
install on the left side of the tank.
ln order to avoid losing the water stoppert, please take off the water
stopper from the distributary hole and put it on the water stopper stand.
Put the baffle into the breeding box.
Put the channel water pipe through the baffle and stable it into the hole.
Close the breeding box top cover. eanwhile, fix the channel water pipe to
the side of the cover. Then, attach the opposite end of the pipe on the
distributary hole.
Turn on the powerhead circulation pump. Water will cycle with the water
from breeding box.This increases the survival rate of the baby fish.
Positionthe breeding box on the side to observe fish growth while remain-
ing near the aquatic ecosystem. For suitable female rainbow fish, it
provides a safe place to breed and rest. The water in the tank and the
breeding box must be circulated well, which greatly increases the survival
rate of the baby fish.
Please control the water flow in the breeding box wellso that baby fish
grow in optiminal conditions.
Attention
Breeding Box
Top Cover
Draining Pipe
Breeding Box
Baffle
Breeding Box
Support Bolt
(×2)
Soft
Tube
water
stopper
Breeding Box Kit
Top Cover
Top cover is designed to prevent scared fish from jumping out of the tank.
There are two holes on the top cover for feeding.
Well-designed transparent top cover is a convenient and practi-
cal part for fish tank users.
Top Cover Kit
Filter Tube For
Breeding Box
Top Cover
Feeding
Hole
Installation Of LED light
LED light bulb can increase the effect when viewing and also benefit the
growth of water plants. The fish tank uses LED lights which are: light weight,
energy efficient, and even when the LED light is on, the water temperature
in the tank will not increase. Water plants will grow better. In order to clean
the aquarium easily, the LED light can rotate 180 degrees.
In order to avoid algae breeding and other maintainance issues, we
suggest keeping the light on for 6~8 hours a day.
Place the LED light into the light holder.
Flexible tube style allows you to adjust the brightness of the lighting.
Rotating lamp holder design allows you to adjust the position of the lighting.
Adjustable lamp design allows you to adjust the angle of the lighting.
Turn on the switch, it is ready for use.
Light
Holder
Bulb
Lighting Arm
switch
LED Light Kit
Attention
Product Manual And Instructions For Use
How To Install The Gravel Filter
Powerhead circulation pump is placed beneath gravel filter and connects
to the draining pipe. Once placed onthe bottom, the 4 corners of the filter
must fit into 4 positioning pillars which locate on the bottom of the tank.
Gravel filter completes the nitrobacteria system, providing stable
water quality. You can also adjust the volume of water.
We suggest you use slightly larger sand granules in order to prevent
powerhead circulation pump from becoming blocked. You can use sands
such as Quartz sand and Natural Sand. Do not use black sand.
Attention
Place bottom sand on the gravel filter until sand is 3.5cm in depth.
The water stopper is used to prevent leaks.
Add appropriate amount of nitrobacteria after water treatment is complete.
For convenience, when the filter is in use, it can rotate clockwise or
counter clockwise to the flow regulator. See (A).
Fill the tank, then turn on the powerhead circulation pump, cycling after 12
hours then it’s done for water treatment.
Distributary
Hole
Plug
Holder
Water Stopper
DistributaryHole
Flow Regulator
Short Tube
Connector
Gravel
Filter
Powerhead
Circulation Pump
Gravel Filter Package
（A）
min
max
To avoid the powerhead circulation pump from burning out, make sure
the water level is higher than the pump.
Sediment such as dirt and waste in the tank will decrease the flow of the
drain; turn counter clockwise of the flow regulator to increase the flow.
The Most Convenient Fish Aquarium In The World

Finish Plan
How To Change Tank Water
Please turn off the powerhead circulation pump before changing the water.
Remove the top cover.
Move the breeding box to the back of the fish tank.
First, turn the L shape pipe to the front, then attach the draining hose to the tube.
Pull the draining pipe lightly to drain off the dirty water. Meanwhile, use a spoon
to stir the sand from the bottom. Use spare container for the dirty water.
Drain off a quarter of the water each time when changing water. After
draining off the dirty water, stir only a quarter of the bottom sand area.
Move the draining pipe to its original position. Take off the draining hose and
turn the L shape pipe to 90゜, facing left.
Place the breeding box back in its original position. Add in the water that has
been resting for at least 24 hours into the fish tank, then turn on the power-
head circulation pump. Place the top cover back on the fish tank. We have
finished changing the water and cleaning the filter.
It only takes 3 minutes to change the water. By connecting the hose to the draining pipe
at the bottom, it’s easy to drain the dirty water and clean the filter at the same time.
Change water for tank at least once a month without water plants. You must
do this more often when you have more fish and shrimp. However, in order
to help water plants grow, change water once a week.
Add tap water that has been resting for at least 24 hours in order to
eliminate traces of chlorine.
To avoid the siphon effect when changing water, please pull off the tube
after draining. Make surethe tube connection is tight enough.
To avoid the siphon effect when changing water, please pull off the tube
after draining. Make surethe tube connection is tight enough.
Add appropriate amount of nitrobacteria after changing water.
Attention
Water Change Kit
（B）
L Tube (small)
Long Tube
L Tube (large)
Draining Pipe
Model：UG-AQ1401A
Dimension (Long x Wide x Depth)：
Tank: 322mm x 212mm x 210mm
Breeding box: 160mm x 110mm x 115mm
Material：Tank - PMMA Accessory - ABS、PC
、PP、PET、PVC
Weight : 1200g
Accessories: Tank x1, Powerhead circulation pump x1, 3W LED
light x1, Adaptor x2, gravel filter x1, draining pipe x1, beak shaped
water outlet x1, breeding box water tube x1, L-Shaped drainage
pipes x1, drainage tube x1, top cover x1, breeding box x1,
breeding box water tube x1
Product Manual And Instructions For Use
More About the product
www.keydex.com.tw/aqua/
Never put new fish
and shrimp all in the
tank at the same time.
Adjust the water quality
– use a cup to pour the
tank water into the bag.
Pour out some
water into the bag.
After a few minutes,
pour out some water
from the bag.
Adjust the water tempera-
ture – float the fish inside
the bag into the tank water,
so the water in the bag
acclimates to the tank
temperature.
To prevent bacteria
from entering – rinse
the fish bag first to
prevent bacteria
entering from the fish
bag at the store.
Adjust the water quality –
use a small bucket to pour
the tank water into the bag.
After few minutes, pour
out some water from
the bag.
After few times, open the
bag and let the fish swim
into the tank.
How To Put Fish And Shrimp In The Tank
The Most Convenient Fish Aquarium In The World
