1. Introduction
keyestudio 4WD Bluetooth Multi-functional Car is a learning application development system based on microcontroller and with ATmega-328 as core. It has
functions of line tracking, obstacle avoidance, IR remote control , Bluetooth remote control and detecting distance. This kit contains plenty of interesting programs
and can extend an external circuit module to increase more functions of this car. The kit aims to disengage users from boring theories and obtain capacity of system
development when they are learningArduino.
2. Parameters
1.Motor: Voltage: 6-9V Reduction Ratio: 1:48
2.Choosing L298N driver module as control motor, separated from microcontrollor
3.Three line tracking modules, having higher precision when detecting white and black lines,able to realize anti-falling
4.IR remote control module making up a remote control system of the car
5.Using ultrasonic module to realize obstacle avoidance
6.Pairing mobile phone Bluetooth with Bluetooth remote control module to control the car
7.Able to connect with external voltage at 7~12V,and equip with various sensors to complete different functions as much as possible

keyestudio
www.keyestudio.com
2
3. Project List
Project 1:Line Tracking Sensor
Project 2:Ultrasonic Sensor
Project 3: Digital IR Receiver Module
Project 4: Servo Motor
Project 5: Bluetooth Module
Project 6: L298N Motor Driver
Project 7: I2C 1602 LCD
Project 8：Line Tracking of Smart Car
Project 9：ObstacleAvoidance of Smart Car
Project 10：IR Remote Control of Smart Car
Project 11：Distance Detecting of Smart Car
Project 12：Bluetooth Remote Control of Smart Car
Project 13：5 in 1 Multi-functional Car

keyestudio
www.keyestudio.com
3
4. BOM
No.
Product Name
Quantity
1
keyestudio UNO R3
1
2
keyestudio Shield V5
1
3
keyestudio L298N Motor Shield
1

keyestudio
www.keyestudio.com
4
4
keyestudio Bluetooh HC-06
1
5
I2C 1602 LCD
1
6
keyestudio Line Tracking Sensor
3
7
HC-SR04 Ultrasonic Sensor
1
8
keyestudio Digital IR Receiver Module
1

keyestudio
www.keyestudio.com
5
9
4WD Top PCB
1
10
4WD Bottom PCB
1
11
Servo Motor
1
12
Servo Plastic Platform
1
13
Remote Control of Chip
1

keyestudio
www.keyestudio.com
6
14
Toggle Switch
1
15
18650 Battery Case
1
16
Mental Motor
4
17
Motor Fixed Part
4
18
Plastic Tire
4

keyestudio
www.keyestudio.com
7
19
Copper Pillar 40MM
6
20
Copper Pillar 10MM
16
21
USB Cable
1
22
Dupont Line
30

keyestudio
www.keyestudio.com
8
23
M3*6MM Round Head Screw
60
24
M3*6MM Flat Head Screw
2
25
M3*30MM Round Head Screw
8
26
3MM Nut
16
27
Connector Wire (150mm, Black)
6

keyestudio
www.keyestudio.com
9
28
Connector Wire (150mm, Red)
6
29
Winding Wire (12CM)
1
5. Installation Method
1. Plug 4 10MM copper pillars into bottom PCB.

keyestudio
www.keyestudio.com
10
2. 4 M3*6MM round head screw is slotted into the pillars.
3. keyestudio L298N motor shield is bolted to the 4 pillars with 4 screws
4pcs
Copper Pillar
10MM
4pcs
M3*6MM
Round Head
Screw

keyestudio
www.keyestudio.com
11
4. Attach 3 line tracking sensors to bottom PCB using 3 screws.
5. Fix the line tracking sensors with 3 nuts on the back.
keyestudio
L298N Motor
Shield
4pcs
M3*6MM
Round Head
Screw
3 pcs
keyestudio
Line Tracking
Sensor
3pcs
M3*6MM
Round Head
Screw

keyestudio
www.keyestudio.com
12
6.Direct 4 motor fixed parts to the holes on bottom PCB.
3 pcs
3MM Nut
4 pcs
Motor Fixed Part

keyestudio
www.keyestudio.com
13
7. Bolt the motor fixed parts to bottom PCB with 8 screws.
8. Place 4 mental motors on PCB near the motor fixed parts.
8 pcs
M3*6MM
Round Head
Screw

keyestudio
www.keyestudio.com
14
9. Attach 4 motors to bottom PCB using 8 screws and 8 nuts.
4pcs
Mental Motor
8 pcs
3MM Nut
8 pcs
M3*30MM
Round Head
Screw

keyestudio
www.keyestudio.com
15
10. Plug 4 tires into the motors.
11. Insert 6 screws into 6 holes around bottom PCB.
12. Slot 6 pillars into the screws.
4pcs
Plastic Tire
6pcs
M3*6MM
Round Head
Screw

keyestudio
www.keyestudio.com
16
13. Attach IR receiver module to top PCB using a screw.
14. Twist a nut to the screw to fix IR receiver module.
6pcs
Copper Pillar
40MM
keyestudio
Digital
IR Receiver
Module
1pcs
M3*6MM
Round Head
Screw

keyestudio
www.keyestudio.com
17
15. Insert 4 screws into the holes of top PCB.
1 pcs
3MM Nut

keyestudio
www.keyestudio.com
18
16. 4 pillars are slotted into the screws.
4pcs
M3*6MM
Round Head
Screw
4pcs
Copper Pillar
10MM
