Keysight E8267D PSG Signal Generators
Upgrade Kit for Option 601 and 602
(Digital Bus Baseband Generator with 8
and 64 Msample Memory, respectively)
Kit Part Numbers E8267DK-601 and E8267DK-602
Installation Note
Part Number: E8251-90388
Printed in USA August 2014

Notice
The information contained in this document is subject to change without notice.
Keysight Technologies makes no warranty of any kind with regard to thismaterial, including but not limited to,
the implied warranties of merchantability and fitness for a particular purpose. Keysight Technologies shall not be
liable for errors contained herein or for incidental or consequential damages in connection with the furnishing,
performance, or use of this material.
© Copyright 2011-2014 Keysight Technologies Inc.

3
Digital Bus Baseband Generator Upgrade Kit
Introduction
This upgrade kit adds the Digital Bus Baseband Generator with 8 or 64 Msample memory to the E8267D.
NOTE This kit requires a PC or UNIX computer with LAN, GPIB, or RS232 access.
Installation includes the following major steps, starting on page 5:
1. Check signal generator functionality.
2. Initialize the signal generator memory.
3. Remove the outer and inner signal generator covers.
4. Install the A14 Digital Bus Baseband Generator board.
5. Verify proper installation of Option 601/602.
6. Re-assemble the signal generator.
7. Run the I/Q Calibration.
8. Verify signal generator calibration.
Product Affected: . . . . . . . . . . . . . . . . . . . . . . . . . E8267D
Serial Numbers: . . . . . . . . . . . . . . . . . . . . . . . . . . All
Options: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To Be Performed By: . . . . . . . . . . . . . . . . . . . . . . (X) Agilent Technologies Service Center
(X) Personnel Qualified by Agilent Technologies
(X) Customer
Estimated Installation Time: . . . . . . . . . . . . . . . 0.5 hours
Estimated Verification Time: . . . . . . . . . . . . . . . 1.0 hours

4
Installation Kit Parts List
Tools Required
•TORXT-10driver
•TORXT-15driver
•TORXT-20driver
• 9/16” nut driver
• 5 mm nut driver
• 9/16” socket
• 5 mm socket
• Torque Wrench Ratchet (9-21 in-lb)
• Small Phillips screw driver
• Needle-nose pliers
• Standard screw driver
Safety Considerations
WARNING Before you disassemble the signal generator, turn the power switch off and unplug the
power cord. Failure to unplug the signal generator can result in personal injury.
CAUTION Electrostatic discharge (ESD) can damage or destroy electronic components. All work on
electronic assemblies should be performed at a static-safe workstation.
Item Quantity Description Part Number
1 1 Installation Note E8251-90388
2 1 W64 Ribbon Cable Assembly 8121-1328
3 1 W90 Digital Bus Cable 8121-0690
4 1 Hex Nut 15/21-32 (AUX I/O) 2950-0035
5 1 Washer .4721D (BNC) 2190-0102
6 1 A14 Digital Bus Baseband Generator 8/64 Msample E4400-60765a
a. Requires firmware version C.06.00 or greater. Visit: http://www.agilent.com/find/upgradeassistant
7 1 W65 Cable A33/A04 400G 8121-0643
8 1 Entitlement Certificate 5964-5143
9 1 Entitlement Certificate Envelope 5010-7743

5
Check Signal Generator Functionality
Use the following procedure to confirm that the signal generator powers up and the internal check identifies no errors. The
internal check evaluates the operation of the signal generator and returns an error message if it detects a problem.
NOTE When the signal generator is first connected to ac line power, the error message
ERROR 514, Reference Oven Cold occurs, which causes both the OVEN COLD annunciator and the
ERR annunciator to turn on.
After approximately five minutes, the OVEN COLD annunciator automatically clears, but the ERR
annunciator remains on until all errors are cleared from the error queue.
1. Turn on the signal generator and let it warm up for at least five minutes.
2. Run the signal generator self-test by pressing Utility > Instrument Info/Help Mode > Self Test > Run Complete Self
Test. Upon completion, a summary of the self-test will be displayed. Use the E8257D/67D PSG Service Guide to
troubleshoot any failures detected by the test.
NOTE Some circuits may require up to 50 minutes to warm up before passing the self-test. If self-tests continue to
fail after 50 minutes of warm up, troubleshoot the instrument.
3. Check to see if the ERR annunciator is on.
•IftheERR annunciator is on, review the error messages in the error queue by pressing
Utility > Error Info. The first page of error messages in the error queue appears in the display text area. (Refer to the
signal generator error messages document for information about each error message.)
After resolving all problems causing errors, press Clear Error Queue(s).
•IftheERR annunciator is off, the signal generator functionality check has passed.

6
Remove the Outer and Inner Signal Generator Covers
Remove the Outer Cover
Refer to Figure 1.
1. Disconnect the power cord.
2. Using a T-20 driver, loosen the two screws (1) and remove the strap handle (2).
3. Using a T-15 driver, remove the center screws (3) on the four rear-panel feet (4).
4. Remove the four bottom feet (5) from the cover by lifting the tab and sliding the foot toward the tab.
5. Place the signal generator on its side.
6. Tilt the signal generator forward and slide the outer cover (6) back to remove it from the frame.
Remove the Inner Top Cover
Refer to Figure 2.
1. Using a T-10 driver, remove the eleven screws (1) from the inner-top cover (2).
2. Remove the inner-top cover.

7
Figure 1 Outer Cover Removal

8
Figure 2 Inner Top Cover Removal

9
Install the A14 Digital Bus Baseband Generator Board
Remove the A40 Compact Flash Drive Assembly
If the unit has a flash drive, remove the flash drive. Otherwise, proceed to “Install the Baseband Board”.
Refer to Figure 3 and Figure 4 for this procedure.
1. Disconnect the power cord.
2. Disconnect the W66 ribbon cable from A18P2.
3. Using the standard screwdriver, unlock the A41 door latch screw by rotating counter–clockwise.
4. Remove the flash card (if applicable).
5. Using the T–10 driver, remove the two upper screws (1) that attach the A40 PCA/CF drive assembly to the rear panel.
Figure 3 A40 Flash Drive Assembly
W66/A18P2A40

10
Figure 4 A41 Flash Drive Door Assembly
Install the Baseband Board
Refer to Figure 5, Figure 6, Figure 7, and Figure 8.
1. Remove the four screws from the baseband cover as shown in Figure 5.
2. Set the baseband cover aside.
3. Insert the new A14 Digital Bus Baseband Generator board into the card cage guides.
4. Connect the W64 ribbon cable to A17P2.
5. Connect the W90 cable end with foam attached to it, to A14J21.
6. Connect the W90 cable to A17P1.
7. Connect the W90 cable to A14J21.
8. Connect the W64 ribbon cable to A14J13.
9. Install the W65 cable to the rear panel slot labeled “BASEBAND GEN CLK IN.” Use a lock washer and a hex-nut to
secure one end of the cable to the rear panel. Torque the hex-nut to 21 in-lb.
10. Connect the loose end of the W65 cable to A14J801.
11. Reinstall the baseband cover.
11
Door Latch Screw
