Keysight HeNe 5519A User manual

Keysight
5519A and 5519B
HeNe Laser with Built-in
Receiver and Power Supply
User’s Guide

Manual Part Number
05519-90012
First Keysight Edition
July, 2021
Printed in USA
Keysight Technologies
1400 Fountaingrove Parkway
Santa Rosa, CA 95403
Document Warranty
The material contained in this document is
provided “as is,” and is subject to being
changed, without notice, in future edi-
tions. Further, to the maximum extent
permitted by applicable law, Keysight dis-
claims all warranties, either express or
implied, with regard to this manual and
any information contained herein, includ-
ing but not limited to the implied warran-
ties of merchantability and fitness for a
particular purpose. Keysight shall not be
liable for errors or for incidental or conse-
quential damages in connection with the
furnishing, use, or performance of this
document or of any information contained
herein. Should Keysight and the user have
a separate written agreement with war-
ranty terms covering the material in this
document that conflict with these terms,
the warranty terms in the separate agree-
ment shall control.
Technology Licenses
The hardware and/or software described in
this document are furnished under a
license and may be used or copied only in
accordance with the terms of such license.
Restricted Rights Legend
U.S. Government Rights. The Software is
"commercial computer software," as
defined by Federal Acquisition Regulation
("FAR") 2.101. Pursuant to FAR 12.212
and 27.405-3 and Department of Defense
FAR Supplement ("DFARS") 227.7202, the
U.S. government acquires commercial
computer software under the same terms
by which the software is customarily pro-
vided to the public.
Accordingly, Keysight provides the Soft-
ware to U.S. government customers under
its standard commercial license, which is
embodied in its End User License Agree-
ment (EULA), a copy of which can be
found at http://www.keysight.com/find/
sweula. The license set forth in the EULA
represents the exclusive authority by
which the U.S. government may use,
modify, distribute, or disclose the Soft-
ware. The EULA and the license set forth
therein, does not require or permit, among
other things, that Keysight: (1) Furnish
technical information related to commer-
cial computer software or commercial
computer software documentation that is
not customarily provided to the public; or
(2) Relinquish to, or otherwise provide, the
government rights in excess of these
rights customarily provided to the public
to use, modify, reproduce, release, per-
form, display, or disclose commercial
computer software or commercial com-
puter software documentation.
(continued in Back Matter)
Safety Notices
CAUTION
A CAUTION notice denotes a hazard. It
calls attention to an operating
procedure, practice, or the like that, if
not correctly performed or adhered to,
could result in damage to the product
or loss of important data. Do not
proceed beyond a CAUTION notice until
the indicated conditions are fully
understood and met.
WARNING
A WARNING notice denotes a hazard. It
calls attention to an operating
procedure, practice, or the like that, if
not correctly performed or adhered to,
could result in personal injury or death.
Do not proceed beyond a WARNING
notice until the indicated conditions
are fully understood and met.
Keysight 5519A and 5519B User’s Guide
3
Notices
© Keysight Technologies, 2021
No part of this manual may be reproduced
in any form or by any means (including
electronic storage and retrieval or transla-
tion into a foreign language) without prior
agreement and written consent from Key-
sight Technologies as governed by United
States and international copyright laws.
dummy

Keysight Technologies
1400 Fountaingrove Parkway
Santa Rosa, CA 95403
Certification
and Warranty
Certification
Keysight Technologies certi-
fies that this product met its
published specification at the
time of shipment from the
factory. Keysight further cer-
tifies that its calibration mea-
surements are traceable to
the United States National
Institute of Standards and
Technology, to the extent
allowed by the Institute’s cali-
bration facility, and to the cal-
ibration facilities of other
International Standards
Organization members.
Product Warranty
Keysight warrants Keysight
hardware, accessories and
supplies against defects in
materials and workmanship
for a period specified by each
product from date of ship-
ment. If Keysight receives
notice of such defects during
the warranty period, Keysight
will, at its option, either repair
or replace products which
prove to be defective.
Replacement products may be
either new or like-new.
Keysight warrants that
Keysight software will not fail
to execute its programming
instructions, for the period
specified above, due to
defects in material and work-
manship when properly
installed and used. If Keysight
receives notice of such defects
during the warranty period,
Keysight will replace software
media which does not execute
its programming instructions
due to such defects.
(continued in Back Matter)
Safety Considerations
General
This product and related doc-
umentation must be reviewed
for familiarization with the
safety markings and instruc-
tions before operation.
This product is an electrical
safety Safety Class 1 instru-
ment (provided with a protec-
tive ground terminal).
Before Applying Power
Verify that the product is set
to match the available line
voltage and the correct fuse
is installed.
Before Cleaning
Disconnect the product from
operating power before
cleaning.
Safety Earth Ground
An uninterruptible safety
earth ground must be pro-
vided from the mains power
source to the product input
wiring terminals or supplied
power cable.
Safety Considerations
(contd.)
Warning Symbols That
May Be Used In This Book
Instruction manual symbol;
the product will be marked
with this symbol when it is
necessary for the user to refer
to the instruction manual.
Indicates hazardous voltages.
Indicates Alternating
current.
Indicates Direct current.
Indicates earth (ground) ter-
minal.
or
Indicates terminal is con-
nected to chassis when such
connection is not apparent.
Safety Considerations
(contd.)
These labels are required by
the United States Center for
Devices and Radiological
Health. Failure to follow their
instructions may result in
personal injury.
The starburst symbol
indicates laser radiation.
For additional safety
information, refer to the
chapter on Safety, and to
the back matter of this
manual.
WARNING
LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
PER IEC 60825-1:2007
Maximum Output: 1mW
ContinuousWave: = 633 nm
Laser Medium: Helium Neon
4
Keysight 5519A and 5519B User’s Guide

Keysight 5519A and 5519B User’s Guide
5
5519A
5519B
CURRENT NUMBER PREFIX
US5214
US5214
User's Guide
This User's Guide provides procedures for installing and
using the Keysight 5519A/B Laser Head, and instructs how
to calibrate and verify machine tool and CMM accuracy as a
component of the Keysight 5530 Laser Calibration System.
Products Covered By This Document

6
Keysight 5519A and 5519B User’s Guide

Keysight 5519A and 5519B User’s Guide 7
2. Laser Controls, Connectors, and Indicators 17
Laser Front Panel 18
Laser Rear Panel 20
3. Specifications 22
Specifications and Characteristics 23
Environmental Ratings 23
11. Safety 1111
In This Guide 9
Units Covered By This Manual 10
Description of Sections 10
Related Documents 10
Introduction 12
Laser Safety 12
Regulations 12
Safety Label 13
USA FCC Radio Frequency Interference Statement 13
Laser Permanent Magnet and Medical Hazard 14
General Safety Precautions 14
Using Components Safely 15
Contents

8
Keysight 5519A and 5519B User’s Guide
Contents
Service and Support 50
5.Using the CO1 Special Option for Long Range Linear Measurements 44
Introduction 45
Specifications 45
Components 45
Setup and Operation 46
4. Using Keysight 5519A/B Laser Head with the Keysight 5530 Laser Calibration System 25
Introduction 26
Assemble and Position the Optics 26
Set Up Software for Linear Measurement 29
Align the Optics 33
Make the Measurements 35
Save, Display and Recall the Data 38
Save the Data Files 38
Data Analysis Display 39
Recall the Data 41

5519A and 5519B User’s Guide
9
In This Guide
Units Covered By This Manual, 10
Description of Sections, 10
Related Documents, 10

In This Guide
10
Keysight 5519A and 5519B User’s Guide
Units Covered By This Manual
The contents of this manual apply to products with serial number prefixes listed
in “Products Covered by This Document” on page5. A unit’s serial number can be
found on a plate attached to the unit, in the form “xxxAyyyy” where
“xxxA” is the prefix, and “yyyy” is the suffix. A prefix is the same for all
instruments of the same revision. The suffix is assigned sequentially and is
unique to each individual instrument of the revision.
A unit manufactured after the printing of this manual may have a serial number
prefix that is not listed on the title page. This indicates that the unit is different
from those described in this manual. Contact the nearest Sales and Support
Office listed in “Service and Support” on page51 if information regarding the
changes is not provided with the new unit.
Description of Sections
Chapter1, Safety
Provides information about safety regulations regarding the Keysight 5519A/B
Laser Head.
Chapter2, Laser Controls, Connectors, and Indicators
Provides information about operating the Keysight 5519A/B Laser Head.
Chapter3, Specifications
Provides information about physical and laser beam characteristics regarding
the Keysight 5519A/B Laser Head.
Chapter4, Using the Keysight 5519A/B Laser Head with the 5530 Laser
Calibration System
Provide first time users with a short tutorial on setting up and using the
Keysight 5530 Laser Calibration system with the Keysight 5519A/B Laser Head
and E1733A software to make a linear measurement.
Chapter5, Using the C01 Special Option for Long Range Linear Measurements
Provides information on specifications and about using the C01 option with the
Keysight 5519A/B Laser Head to make long range measurements.
Related Documents
Keysight Laser and Optics User’s Manual, part number 05517-90086
Keysight 5530 Laser Calibrator Getting Started Guide, part number
E1733-90001

5519A and 5519B User’s Guide
11
1
Safety
Introduction, 12
Laser Safety, 12
Safety Label, 13
USA FCC Radio Frequency Interference Statement, 13
Laser Permanent Magnet and Medical Hazard, 14
General Safety Precautions, 14
Use Components Safely, 15
Regulations, 12

1 Safety
12
Keysight 5519A and 5519B User’s Guide
Introduction
Laser Safety
Regulations
This chapter provides safety guidelines you must follow to help ensure your
protection and the protection of the equipment. Familiarize yourself with
all these guidelines before setting up or using the Keysight 5519A/B Laser
Head.
The Keysight 5519A/B Laser Head is a low power (less than 1 mW) helium-neon
laser, the Keysight 5519A/B Laser Head will not cut metal or even burn paper.
Therefore, it is not necessary to use special safety equipment such as tinted
glasses or shielding. To avoid possible injury from prolonged exposure, do not
stare directly at the laser beam or the beam reflected from a polished surface.
(It is safe to look at the dots of light reflected on an unpolished surface.)
The Keysight 5519A/B Laser Head is a Laser Class 2 product certified as
conforming to Bureau of Radiological Health Regulations 21 CFR1 1040.10 and
1040.11, and per IEC2 60825-1:2007. The instrument and this manual should be
inspected and reviewed for safety markings and instructions before operation.
Please refer to the summary of Safety Considerations in the front matter of this
document.
The above regulations may also apply to the end product into which the
Keysight 5519A/B Laser Head will be designed. Care must be taken to insure
that the end product complies with all applicable national and local laser safety
regulations.
The Keysight 5519A/B Laser Head is also a Safety Class 1 product, designed
and tested in accordance with international safety standards, including HD
3
194
and IEC 348.
1. CFR, Code of Federal Regulations (U.S.A.)
2. IEC, International Electrotechnical Commission
3. HD, Harmonization Document
For the latest conformity to Standards and Safety Regulations,
refer to Declarations of Conformity for the Keysight 5519A/B
Laser Head at https://www.keysight.com/go/conformity/.
NOTE
NOTE If the equipment is used in a manner not specified by this manual,
the protection provided by the equipment may be impaired.

1 Safety
Keysight 5519A and 5519B User’s Guide
13
Safety Label
Figure1 shows the safety label and its location on the rear panel of
the Keysight 5519A/B Laser Head.
Figure1. Safety Label
USA FCC Radio Frequency Interference Statement
0USE ONLYU S E O N L Y
WITH 250VW I T H 2 5 0 V
FUSES F U S E S
MSIP-REM-ATi-
455530
MADE IN U.S.A.OF DOMESTIC
AND FOREIGN COMPONENTS
LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
PER IEC 60825-1:2007
Maximum Output: 1mW
ContinuousWave: = 633 nm
Laser Medium: Helium Neon
CAUTION
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions in this manual, may cause interference to radio
communications. As temporarily permitted by regulation, it has not
been tested for compliance with the limits for Class A computing
devices pursuant to Subpart J of Part 15 of FCC Rules, which are
designed to provide reasonable protections against such interference.
Operation of this equipment in a residential area is likely to cause
interference, in which case the user, at his own expense, will be
required to take whatever measures may be required to correct the
interference.

1 Safety
14
Keysight 5519A and 5519B User’s Guide
Laser Permanent Magnet and Medical Hazard
General Safety Precautions
Before turning on the power to any component of the Keysight 5519A/B Laser
Head, make sure it is plugged into a protective grounded socket.
Tampering with a protective (grounding) conductor or disconnecting the
protective earth terminal causes a potential shock hazard. Grounding one
conductor of a two-conductor outlet is not sufficient protection.
If you think the electrical protection is impaired, make sure the component is
not used until a qualified service technician has checked it and, if necessary,
made the appropriate repairs.
If an autotransformer is used for voltage reduction, make sure the common
terminal is connected to the earth terminal of the power source.
Use only fuses with the correct rating and specified type. Do not use a repaired
fuse or a short-circuited fuse holder. This could cause a shock or fire hazard.
NOTE
Keysight lasers contain a permanent magnet. The field strength of the
Keysight laser magnet does not exceed 5.25 milligauss at a distance of
460 cm (15 ft) from any point on the surface of the packaged Laser as
specified in Standard: IATA Dangerous Goods:2011, and therefore meets the
IATA requirements for air shipment with “Magnetic Material” caution label.
WARNING
The field strength ofthe Keysight laser magnet may, in some
circumstances, pose a danger to individuals with cardiac
pacemakers or similarmedical devices. Such individualsmust take
precautions appropriate to their condition.
WARNING
Electrical supply: 100-240 Vac, 50/60 Hz, 65VA Max. Main
supply voltage fluctuations for the Keysight 5519A and 5519B
Lasers are not to exceed 10 percent of the normal supply.

1 Safety
Keysight 5519A and 5519B User’s Guide
15
Using Components Safely
When using Keysight 5530 Laser Calibration System electronic
components—5519A/B Laser Head, E1735A USB Axis Module, E1736A
USB Sensor Hub, E1737A Material Sensor, and E1738A Air sensor—
observe the following guidelines:
•Before connecting a component, make sure the component and cable are in
good condition.
•If a sensor cable is cut, the cable must be replaced before use.
•Be sure the cables do not present a hazard to people working in the area.
Also, place all cables so they will not be damaged by equipment or people.
•Hold a cable by its connector (the plug, not the cord) when connecting or
disconnecting it.
•Never force a connector into a port. If they do not join easily, they do not
match. Make sure the connector and port match and that the connector is
properly aligned.
•After inserting a connector into a port, do not twist or turn it.
•Do not open the casings on the electronic components.

1 Safety
16
Keysight 5519A and 5519B User’s Guide

17
5519A and 5519B User’s Guide
2
Laser Controls, Connectors, and Indicators
Laser Front Panel, 18
Laser Rear Panel, 20

2 Laser Controls, Connectors, and Indicators
18
Keysight 5519A and 5519B User’s Guide
Laser Front Panel
Figure2 shows the front panel features.
Figure2. 5519A/B Front Panel Features
1LASER ON
The amber indicator alerts the operator when the 5519A/B Laser Head is
capable of emitting a laser beam.
2SIGNAL
The green indicator glows when a sufficient measurement signal is
returned to the measurement receiver assembly in the 5519A/B Laser
Head.
3 Exit (Upper) Aperture
The laser beam exits from this port.
When OTHER is selected (see the description of the Turret Ring below), the
laser beam is reflected back to the Exit Aperture.
LASER ON
AVOID EXPOSURE LASER RADIATION
IS EMITTED FROMTHIS APERTURE
EXPOSITION DANGEREUSE UN RAYONNEMENT
LASER EST EMIS PAR CETTE OUVERTURE
SIGNAL
OTHER
STRAIGHT
1
9
4
2
3
5
6
7
8
NOTE
Refer to Chapter 5: "Using the C01 Special Option for Long
Range Linear Measurements" for additional control.

2 Laser Controls, Connectors, and Indicators
Keysight 5519A and 5519B User’s Guide
19
4 Exit Aperture Control
The shutter is located behind the Upper Aperture. Three positions can be
selected:
Open − used during normal operation
Reduced Aperture − used during alignment of measurement axes
Closed − the shutter should be in the closed position whenever the
laser is not in use
5 Lower Aperture
For all non-straightness measurements, the laser beam is reflected back to
this port in the laser by the measurement optics, and then is directed to the
receiver assembly.
When OTHER is selected (see the description of the Turret Ring below), the
laser beam is reflected back to the Exit Aperture.
6 Lower Aperture Control
The lower aperture is normally open. When the measurement axes are being
aligned, a target can be rotated into the aperture to facilitate alignment.
7Turret Ring
The Turret Ring is used to select the type of measurement to be performed.
For all measurement types except straightness, the Turret Ring is set to
OTHER. The laser beam exits at its preset power through the Exit Aperture,
and the measurement beam is reflected back to the lower aperture.
When the Turret Ring is set to STRAIGHT, the laser beam both exits from
and returns to the 5519A/B Laser Head through the Exit Aperture. The beam
is reduced to approximately 30% of its preset power. The straightness
measurement optics reflect the return beam to the Exit Aperture.
8 OTHER position of the Turret Ring
9 STRAIGHT position of the Turret Ring

2 Laser Controls, Connectors, and Indicators
20
Keysight 5519A and 5519B User’s Guide
Laser Rear Panel
Figure3 shows the rear panel features.
Figure3. 5519A/B Rear Panel Features
1 Power Connector connects to the AC power input.
2Power Switc hactivates the 5519A/B Lase Head when set to the ‘I’
position, and begins the warm-up sequence that enables laser emission.
3Port for Keysight 10882B Laser Cable, which connects the laser to the
E1735A USB Axis Module of the Keysight 5530 Laser Calibrator System.
4Laser On (amber)
This LED indicator alerts the operator when the 5519A/B Laser Head is
capable of emitting a laser beam.
5Ready (green)
This LED indicator blinks on and off to indicate that the laser is in the process
of warming up, beginning about halfway through the laser warm-up period.
It glows steadily when the 5519A/B Laser Head is ready for use. Warm-up
typically takes about 10 minutes.
2
1
3
4
5
0USE ONLYUSE ONLY
WITH 250VWITH 250V
FUSES FUSES
MSIP-REM-ATi-
455530
MADE IN U.S.A.OF DOMESTIC
AND FOREIGN COMPONENTS
