Keysight N9010B EXA Installation and operation manual

Option YAS
Y-Axis Screen Video Out
Keysight N9010B EXA and
N9020B MXA Signal Analyzers
N9048B PXE EMI Receiver
Installation Note

Notices
© Copyright 2016 - 2018 Keysight Technologies, Inc.
The information contained in this document is subject to change without notice.
Keysight Technologies makes no warranty of any kind with regard to this material, including but
not limited to, the implied warranties of merchantability and fitness for a particular purpose.
Keysight Technologies shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance, or use of this material.
Manual Part Number
N9020-90272
Edition
Edition 1, October 2018
Supersedes February 2018
Printed in USA/Malaysia
Published by:
Keysight Technologies, Inc.
1400 Fountaingrove Parkway
Santa Rosa, CA 95403

Installation Note N9020-90272 3
Option YAS Installation Kit
Option YAS Installation Kit
Products Affected: N9010B EXA Signal Analyzer
N9020B MXA Signal Analyzer
N9048B PXE EMI Receiver
Serial Numbers: All
Options
To Be Performed By: (X) Keysight Service Center
(X) Personnel Qualified by Keysight
(X) Customer
Estimated Installation Time:
Estimated Adjustment and Verification Time:
0.5 Hours
0.5 Hours

4Installation Note N9020-90272
Option YAS Installation Kit
Introduction
This kit contains all of the instructions required to install Option YAS on Keysight EXA and MXA
signal analyzers and PXE EMI receivers. Option YAS enables the ANALOG OUT port to provide a
Y-Axis screen video output.
The rear panel ANALOG OUT port is present on all EXA and MXA signal analyzers and PXE EMI
receivers, however Option YAS must be enabled via a license file.
1. At the time of manufacture the hardware related to this option was fully
adjusted and the option performance was verified to be within its warranted
specifications. Within one year of the initial calibration date of the instrument
this option is fully calibrated with no further adjustment or verification testing.
To determine the initial calibration date, locate the original calibration
certificate that was shipped with the instrument at the time of purchase. The
Date of Calibration is printed on the original calibration certificate.
To ensure that this newly installed option has been installed properly, the
procedure that follows includes a functional check.
2. The latest revision of the X-Series signal analyzer software may be
downloaded from:
http://www.keysight.com/find/Xseries_software
3. This option is licensed for one instrument model/serial number combination.
The license key will only install on the designated instrument.

Installation Note N9020-90272 5
Option YAS Installation Kit
Contents
Tools Required for Installation
— Personal computer with internet access and USB port
— USB storage device with >2GB free memory
Tools Required for Manual Operation Verification
—Voltmeter
— Test cable, BNC (used to connect voltmeter to the analyzer rear panel ANALOG OUT)
— Banana plug to BNC adapter (used to connect voltmeter to BNC cable)
Installation Procedure over USB
1. Locate the Option Upgrade Entitlement Certificate (5964-5178) from the kit.
2. Redeem the Option Upgrade Entitlement Certificate by following the instructions on the
Certificate.
3. After redeeming your Option Upgrade Entitlement Certificate you will receive an email with an
attached License File.
4. Locate a USB storage device. Perform a virus scan on this device before use.
5. Save the License File to the root directory of the USB Storage Device.
6. Connect the USB Storage Device to the signal analyzer USB port. Windows will detect the new
hardware and may display the configuration menu shown in Figure 1. This menu may be
configured according to your preferences.
Quantity Description Keysight Part Number
1 Installation Note This note
1 Option Upgrade Entitlement Certificate 5964-5178

6Installation Note N9020-90272
Option YAS Installation Kit
Figure 1 USB Storage Device Configuration Menu
7. The signal analyzer will automatically consume the License File. (This may take a few minutes)
When the License File is consumed the Keysight License Manager will display a “Successful
License Installation” message similar to the one shown in Figure 2.
Figure 2 Successful License Installation
Alternate Installation Procedure
The License File can be manually installed over USB or LAN by placing the license file in the
following folder on the signal analyzer
C:\Program Files\Agilent\licensing
Verify the Installation
1. Cycle the power on the signal analyzer.
2. Press System, Show System to display a list of installed options.
3. Verify that the newly installed option appears on the list.

Installation Note N9020-90272 7
Option YAS Installation Kit
Manually Verify Operation
1. Preset X-Series analyzer. Assure mode is Spectrum Analyzer.
2. Display the 50 MHz calibrator signal. Press Input/Output, RF Calibrator, 50 MHz. Press FREQ,
Center Frequency, key in 50 MHz. Press Span, Zero Span. You should see a flat line across the
display at −25 dBm.
3. Press AMPTD, Ref Level, and key in −25 dBm. The displayed signal level should be at the top
graticule line.
4. Press Input/Output, Output, Analog Out, Screen Video.
5. Connect a voltmeter, set to measure DC volts, to the analyzer rear panel ANALOG OUT
connector.
6. The voltmeter should measure 1V.
7. Increase the Ref Level to −15 dBm. The signal should drop one graticule division on screen and
the voltmeter reading should be 0.9 V.
8. This test is sufficient to determine if the output circuitry is working properly for all Analog Out
signal selections.

8Installation Note N9020-90272
Option YAS Installation Kit
Utilities, Adjustments, and Performance Verification Tests
Calibration Software and specified test equipment is required to perform the adjustments, and can
be used to automate the performance verification testing. Information on how to obtain this
software can be found at
http://www.keysight.com/find/calibrationsoftware
Utilities Required
None
Adjustments Required
None
Performance Testing Required
None
A full calibration is required to assure the instrument meets all specifications
The end user must ultimately determine whether they want a full calibration to be performed after
the installation of this upgrade or not. If a full calibration is required, arrangements regarding the
level of calibration must be made between the end user and the calibration provider.
For assistance, contact your nearest Keysight Technologies Sales and Service Office. To find your
local Keysight office access the following URL, or if in the United States, call the following
telephone number:
http://www.keysight.com/find/assist
1-800-829-4444 (8 am - 8 pm ET, Monday - Friday)
