Keystone Keystone F792 User manual

© Copyright by Tyco International Ltd. F792LPSB/11/98
Keystone reserves the right to change product designs and specifications without notice.
Controls – F792 Switchbox LP Series
The well proven design of the Keystone F792 Low
Profile Switchbox has been upgraded to simplify
switch setting, site wiring and weatherproof integrity.
Features
•Cams specially designed to operate
either V9 microswitches or
proximity sensors
•General purpose dustproof and
weatherproof enclosure to IP65
rating.
•Switches prewired to terminal strip.
•Cable entries: 2-off Pg 13.5.
•Suitable for direct mounting to
Keystone F790 actuators.
•Simple screw driver cam setting.
•Independently, top adjustable
cams, accessible at all degrees of
opening.
•Infinitely adjustable.
•Locking screw provides full face
friction of the cams ensuring
optimum repeatability, as cams
firmly lock after adjustment.
•Clearly visible position indicator.
•Anodised and ESPC* aluminium
enclosure provides full environmental
protection.
•Readily adaptable to suit all rotary
actuators.
•Terminal strip angled for easy
wiring.
* Electrostatic powder coating.
Options
•V9 microswitches.
•Inductive proximity sensors.
•Pneumatic switches.
•Direct mounted High Visibility
Indicator.
General Applications
For position sensing on manual or
automated valves in general industrial
environments.
Refer F792-K series Switchboxes for
hazardous applications.
A.C.N. 000922690
142
94
42 87
79 93
11
Ø16
2
1
7
6
4
5
9
8
Pg 13.5
Pg 13.5
© Copyright by Tyco International Ltd. F792LPSB/11/98
Keystone reserves the right to change product designs and specifications without notice.
Controls - F792 Switchbox LP Series
Operating Specifications
Temperature Rating:
Minus 25°C to 60°C for Micro and
Proximity switches.
Minus 15°C to 60°C for Pneumatic
switches.
Enclosure Protection:
IP65 dust and weatherproof.
Action:
360° rotary normally set for 90° action.
Parts List
No. Description Material
1Body Die cast aluminium LM24
(anodised and ESPC*coated)
2Cover Die cast aluminium LM24
(anodised and ESPC*coated)
3Cams (not shown) Acetal
4Shaft Acetal
5Position Indicator A.B.S. (acrylonitrile butadiene styrene)
6Fasteners Stainless Steel
7Fastener Seals Nylon
8Gasket Nitrile
9Dome Ektar (DN004 copolyester)
Note:
*Electrostatic powder coating.
© Copyright by Tyco International Ltd. F792LPSB/11/98
Keystone reserves the right to change product designs and specifications without notice.
Controls – F792 Switchbox LP Series
Option 1 Low profile switchbox with
two V9 single pole double
throw microswitches
Electrical Switch Plan Electrical Switch Wiring Diagram
Proximity Plan Proximity Wiring Diagram
Option 3 Low profile switchbox with
two pneumatic switches
Pneumatic Switch Plan Pneumatic Switch Wiring Diagram
(Shown in mid travel)
Top
switch
(open)
Bottom
switch
(closed)
Mains
Supply
Output
to lamp
Output
to lamp
Yellow
Black
Red
Brown
Blue
G/Y
Earth
NC
123456
NC
Top
switch
(open)
Bottom
switch
(closed)
Black (A)
Blue (-)
Brown (+)
Black (A)
Brown (+)
Earth
123456
NC NPN PROX
10 – 30V DC 200mA MAX
(Shown in mid travel)
Top
sensor
(open)
Bottom
sensor
(closed)
Blue (-)
Brown(+)
Blue (-)
Brown (+)
Earth
123456
NAMUR SENSOR
8V DC
(shown in closed position)
Top
switch
(open)
open
signal pressure
source close
signal
Bottom
switch
(closed)
Open signal
1/8" BSP.T
Shut signal
1/8" BSP.T
Air supply
1/8" BSP.T
Note:
2 Wire Schematic Illustrated. Note:
3 Wire Schematic Illustrated.
Caution:
Reverse air connections will
cause venting into enclosure.
© Copyright by Tyco International Ltd. F792LPSB/11/98
Keystone reserves the right to change product designs and specifications without notice.
Controls - F792 Switchbox LP Series
Microswitch Specifications
Voltage Resistive load Tungsten lamp load (amps) Inductive load
(Volts) (Amps) NC NO (Amps)
AC 125 10 2 1 10
250 10 1.5 1 10
DC Up to 15 15 3 1.5 15
30 10 3 1.5 10
50 3 0.8 0.8 2.5
75 1 0.6 0.6 0.5
125 0.5 0.5 0.5 0.07
250 0.25 0.25 0.25 0.03
Proximity Sensor Specifications – 2 & 3 Wire Specification
Proximity Sensor- 2 wire specification
Type: Pepperl & Fuchs NJ2-V3-N or equivalent
Sensing Distance: 2mm maximum (metal face). NB separate amplifier
required
Supply: 8V DC (Ri approx. 1k0hm)
Output: •Sensor absent - 3mA or above
•Sensor present - 1mA or below
Proximity Switch - 3 wire specification
Type: Bailiff BES 5173
Supply Voltage: 10-30VDC
Current: ≤200mA
Frequency: ≤1500Hz
Pneumatic Switch Specifications
Signal connections: 4mm O.D. tube.
Switch details: •Telemecanique PXC–M111 or equivalent
•2 switches per box
•Switches normally non passing (NNP)
•Capacity – 60 L/min at 550 kPa to atmosphere
•pressure range 300 – 800 kPa
Temperature range: Minus 15°C to 60°C
© Copyright by Tyco International Ltd. F792LPSB/11/98
Keystone reserves the right to change product designs and specifications without notice.
Controls – F792 Switchbox LP Series
For Trimming Only DO NOT PRINT
© Copyright by Tyco International Ltd. F792LPSB/11/98
Keystone reserves the right to change product designs and specifications without notice.
Controls - F792 Switchbox LP Series
Typical Description – Electrical Switches
F792 LSB LP WP 2SPDT 240VAC
Figure No. Limit Switchbox Type Enclosure Rating Switch Type Voltage
(Low Profile) (weatherproof)
Typical Description – Proximity Sensors/Switches
F792 LSB LP WP Prox NO PNP
Figure No. Limit Switchbox Type Enclosure Rating Proximity Action Switch Style
(Low Profile) (weatherproof) Normally Open
Typical Description – Pneumatic Switches
F792 LSB LP WP Pneu NNP
Figure No. Limit Switchbox Type Enclosure Rating Pneumatic Action
(Low Profile) (weatherproof) Switch Normally Non Passing
Selection Guide
EDP Description Part No. Comments
F792 LSB LP WP 2SPDT 20-260VAC 422987 Weatherproof type with two 240 VAC electrical switches
F792 LSB LP WP PROX NAMUR 169555 Weatherproof type with two 8 VDC proximity sensors
F792 LSB LP WP PROX NO PNP 642884 Weatherproof type with two 10-30 VDC proximity switches
F792 LSB LP WP PROX NC PNP 764321 Weatherproof type with two 24 VDC proximity switches
F792 LSB LP WP PROX NO NPN 768482 Weatherproof type with two 24 VDC proximity switches
F792 LSB LP WP PROX NC NPN 252866 Weatherproof type with two 24 VDC proximity switches
F792 LSB LP WP PROX AC 116538 Weatherproof type with two 20-260 VAC proximity switches
F792 LSB LP WP 2 PNEU NNP 812791 Weatherproof type with two pneumatic switches
Note:
SPDT = Single Pole Double Throw
NO = Normally Open
NC = Normally Closed
NNP = Normally Non Passing
