Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Assembly Instructions
Undermounted R8 Power Module
November 2018
tabletop
undermounted
R8 power module
marked for
drilling
Figure 1
marked for
drilling
undermounted
R8 power module cordless
power drill
Figure 2
tabletop
Required Tools
• Cordless Power Drill
• Screwdriver
Undermounted R8 Power Module
Installation
Note: The Undermounted R8 power
module can be mounted to the
underside of the Toggle tabletop at
one of two pre-drilled locations, and
can face the user, or non-user side of
the table. If pre-drilled holes will be
used to mount the module, proceed
to step 4 to mount the power module.
Note: If a mounting location is
desired where no pre-drilled holes
exist, beign with steps 1 through 3
below.
1. Position the Undermounted R8
power module to the underside of
the tabletop at the desired location.
Assure that the power cord can be
routed easily to a power source
(Figure 1).
2. Using the R8 power module as a
template underneath the tabletop,
align the unit straight, then mark the
four mounting hole locations and
move the unit away (Figure 1).
3. Carefully bore a 3/32” mounting hole
to a depth of 3/4” at the center of each
marked location, under the tabletop
using a cordless power drill. Take
care to not drill too deep, piercing
the tabletop (Figure 2).
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Undermounted R8 Power Module
Assembly Instructions
1330 Bellevue Street • P.O. Box 8100 • Green Bay, WI 54308-8100 • Tel 1-800-424-2432 • www.ki.com
© 2018 Krueger International, Inc. All Rights Reserved • Code KI-AI-000031/KI/PDF/1118
4. Align the mounting holes of the
R8 power module with the drilled/
pre-drilled mounting holes
underneath the tabletop. Secure
the R8 power module to the
tabletop using four #8 x 3/4” wood
screws. Take care to not over
tighten (Figure 3 or Detail A & B).
5. Route the power cord to an
approved power source if
optional mounting clamps are not
desired.
CAUTION: Risk of electrical
shock. Do not plug into another
relocatable power tap or an
extension cord.
Cable Clamp Installation
(optional)
1. Route the power cord for the
Undermounted R8 power module
along the underside of the
tabletop and mark the pilot hole
locations where the cable clamps
will be installed. Four cable
clamps are provided with each R8
power module, but depending on
your configuration not all clamps
may be required (Figure 4).
2. Position the power cord out of
the way. At each marked cable
clamp location, drill a pilot hole
to a depth of 3/4”, making sure to
not drill too deep, piercing the
tabletop (Figure 4).
3. Nest the power cord inside the
cable clamps. Position the cable
clamps over the pilot holes and
secure to the tabletop using
#8 x 3/4” wood screws (Figure 4).
4. Route the power cord to an
approved power source.
#8 x /”
wood screw
3
4undermounted
R8 power module
drilled
mounting
holes
Figure 3
tabletop
undermounted
R8 power module
#8 x /”
wood screw
3
4
cable
clamp
(optional)
power
cord
Figure 4
Detail A - T
oggle Table, Module Mounted
Between the Cross-Tube Assemblies
#8 x /”
wood screw
3
4undermounted
R8 power module
pre-drilled
mounting
holes
tabletop
Detail B - T
oggle Table, Module Mounted
Between the Cross-Tube Assemblies
#8 x /”
wood screw
3
4undermounted
R8 power module
pre-drilled
mounting
holes
tabletop
