VEHICLE FEATURE TIPS
Many of the Tips presented below are covered in greater detail in the
Owner’s Manual, Multimedia System Manuals, Features and Functions
Guide, and Quick-Start Guide hangtag supplied with your new vehicle.
VOICE RECOGNITION1AND BLUETOOTH®2
Using Voice Recognition
Improve Bluetooth®Voice Recognition (VR) performance
by making a few simple changes to your phone contacts:
• Use full names (first and last names) vs. short
or single-syllable names (“John Smith” vs. “Dad,”
“Smith Residence” vs. “Home”).
• Avoid using special characters, emojis, and hyphenated
names (@, &, #, /, -, *, +, etc.).
• Avoid using acronyms (“Emergency” vs. “ICE” or “In
Case of Emergency”) or words with all capital letters.
• Spell words completely; system will not recognize
abbreviations (“Doctor Smith” vs. “Dr. Smith”).
• Always wait for the beep before speaking
any commands.
• When using VR to place a call, speak in a natural,
moderate tone, with clear pronunciation. The system
may have trouble recognizing commands if you speak
too softly or too loudly.
• Open windows, sunroof, weather (wind/rain), or an
A/C fan operating at higher speeds can interfere with
VR accuracy.
• Your VR system may have difficulty understanding
some accents or uncommon names.
• Press the talk button and say “Help” to get a list of
available commands.
Pairing or Connecting Your Phone with Bluetooth®
• Press the Phone hard key (if equipped) or “Call” button
on the steering wheel to begin the pairing process if
no phone has previously been paired.
• During the pairing process, please make sure you
accept all requests for phonebook download and
future auto-connection on your phone.
• To pair a second phone or subsequent phones, reference
the manuals and guides supplied with your Telluride
as steps vary by radio.
• If you experience any issues with auto-connection, try
the following:
• Reboot your phone (turn the phone off and then on).
• Update the phone operating system to the most
recently released version.
• Delete the phone from the list of Bluetooth®devices
on the UVO display1and delete UVO from the list of
Bluetooth®devices on your phone, and re-pair.
• Ensure the phone has the Bluetooth®feature
activated.
• If some contacts are not downloading to the UVO
display, check to confirm that the contact has been
entered correctly and that it has been stored under
the categories (HOME, MOBILE, WORK, iPhone®3)
that are supported by the UVO display. Some
contact categories (MAIN, PAGER, OTHER) may not
be supported. If the number of contacts exceeds
the maximum number allowed on the UVO display,
contacts will be partially downloaded. Ensure that
only the “phone contact list” is selected for contact
download on your phone (not social media or email
contact lists as these contacts may not download to
the UVO display).
• Phone operating systems change frequently and some
phones may have varying compatibility levels with the
Bluetooth®system. For any questions regarding the
features of your vehicle, please contact your preferred
Kia dealer or contact Kia Consumer Assistance at
1-800-333-4542.
Other Bluetooth®Tips
• Bluetooth®reception is affected by carrier coverage
and is dependent on the phone.
• If streaming audio through Bluetooth®from a device,
ensure the listening volume on the device is turned up.
FEATURE VIDEOS
To view a video on your mobile device, snap this QR Code or visit the listed website:
https://www.youtube.com/KiaFeatureVideos
SMARTPHONE CONNECTIVITY1
Apple CarPlay®3
Your vehicle offers you effortless command of your compatible iPhone®when you connect through Apple
CarPlay®on your UVO display. This will enable you to make calls, send hands-free texts, access your
favorite music and apps, and get navigation help with Siri®voice control.
To connect Apple CarPlay, visit https://youtu.be/N1FQ1VqDt4A.
Android AutoTM4
Your vehicle allows you to connect to your compatible AndroidTM phone via Android AutoTM on your UVO display.
Through this feature, you can access music, your phone’s dialer, navigation help, and more with an intuitive
interface and voice commands. You can even access your phone through your steering wheel controls.
To connect Android Auto, visit https://youtu.be/QPV7y06-RJ4.
2020

REAR OCCUPANT ALERT SYSTEM5
The Rear Occupant Alert can help alert the driver if the system detects a rear passenger
has been left in the vehicle. The 1st alert will be a message on the Instrument Cluster.
After the 1st alert, when the doors are locked and there is movement detected in the
rear seats, the horn will sound for about 25 seconds.
To turn the system on or off, go to User Settings, select Convenience, then Rear
Occupant Alert.
Check rear seats
:Alarm Off
OK
SAFE EXIT ASSIST (SEA) SYSTEM6
The Safe Exit Assist (SEA) system can help prevent passengers from opening their door
after your vehicle has stopped when it detects a vehicle approaching from behind by
displaying a warning message on the Instrument Cluster and sounding an audible warning.
To turn on the SEA system, go to User Settings menu, select Driver Assistance, then
Blind-Spot,
7and select Safe Exit Assistance.
HIGHWAY DRIVING ASSIST (HDA) SYSTEM*8
The Highway Driving Assist (HDA) system is designed to automatically adjust the speed
of the vehicle to changing speed limits when driving on federal highways based on
available highway speed information.
To turn the HDA system on, go to User Settings in the Instrument Cluster. Go to Drive
Assistance > Driving Assist > Highway Driving Assist and press the OK button on the
Steering Wheel.
The HDA system will operate only when these conditions are met:
• The vehicle is traveling slower than 95 mph.
• When driving on federal highways.
• When the Smart Cruise Control (SCC)7is on and operating.
• When the SCC speed is set to current federal highway speed.
When the HDA system is activated and the conditions are met, the Instrument Cluster
indicator light will illuminate green. If the conditions are not met, the HDA system will
be in standby mode and the indicator light will illuminate white.
When in operation, and if both lanes are recognized, a display will show the lanes
illuminated white and the steering wheel indicator illuminated green.
If HDA is activated, conditions are met and the SCC speed is set by the driver (at the posted
highway speed limit or slower), the HDA system will enter the automatic speed setting
mode. The set speed and AUTO will be displayed in green and an audible alert will sound.
Reminders:
• If the driver changes the speed while in automatic speed setting mode, it
deactivates and enters a manual mode.
• When the ignition is cycled, the system returns to its previous state, on or off.
60 mph
BLIND-SPOT COLLISION AVOIDANCE-REAR (BCA-R)7/ BLIND-SPOT COLLISION WARNING (BCW)7
The BCA-R system uses radar sensors in the rear bumper to help monitor and warn the
driver if it detects an approaching vehicle in the driver’s blind spot area. It activates when
the vehicle is traveling faster than 20 mph and will alert the driver if another vehicle is
detected by the radar sensor.
To activate the BCA-R system, go to User Settings by pressing the Mode button on
the Steering Wheel. Select Driver Assistance > Blind Spot Safety and then press the OK
button. Select Active Assist, Warning Only, or Off.
To set the initial warning activation time, go to User Settings > Driver Assistance >
Warning Time and press the OK button. Select the Normal or the Later option.
With the Engine Start/Stop button in the ON position, press the BCA-R button to turn the
system ON. The button light will illuminate. The outside rearview mirror warning lights
will also illuminate for 3 seconds.
1st-stage alert: When another vehicle is detected within the BCA-R system warning
boundary, a yellow indicator will illuminate on the outside rearview mirrors.
2nd-stage alert: When 1st stage alert is on and the driver activates a turn signal, a
flashing yellow indicator will illuminate on the outside rearview mirrors and the system
will sound an alert.
Quick Tip:
• The BCA-R system will activate when:
• The system is turned on.
• The vehicle speed is above approximately 20 mph.
• Other vehicles are detected on the rear sides of the vehicle.
Reminders:
• The BCA-R system will not issue a warning if the vehicle speed is 6 mph or more
above the surrounding vehicles.
• When the BCA-R is ON and the ignition is cycled, the BCA-R system returns to its
previous state.
• The BCA-R and BCW systems are supplemental systems. Do not solely rely on
these systems. Always pay attention to the road and drive safely.
HIGH BEAM ASSIST (HBA)*9
HBA is designed to automatically adjust the headlight range by switching between high and low beams based on light
detected from other vehicles and road conditions.
To enable HBA, toggle the light switch to the AUTO Light position and turn on the high beams by pushing the lever away
from you. The High Beam Assist indicator will illuminate.
Reminders:
• HBA will operate when vehicle speed exceeds 25 mph.
• If the lever is pushed away from you while HBA is operational, HBA will turn off and the high beams will be on
continuously. If the lever is pulled toward you while HBA is operational, HBA will turn off.
• If the light switch is switched to the headlight position, HBA will turn off and the low beams will be on continuously.

BLIND-SPOT VIEW MONITOR (BVM) SYSTEM*7
The Blind-spot View Monitor (BVM) system is designed to display the passenger-side
rear blind spot areas in the Instrument Cluster LCD when the system is activated.
To turn the BVM system on, go to User Settings in the Instrument Cluster by pressing
the Mode button on the Steering Wheel. Select Driver Assistance > Blind-Spot Safety >
Blind-Spot View and press the OK button.
The BVM system will operate when the Engine Start/Stop button is on and the turn
signal is activated.
The BVM system will not operate when the Engine Start/Stop button is off, a turn signal
is deactivated, or another warning screen comes up on the Instrument Cluster LCD.
CANCEL
RES
OK SET
8
5
6
7
0
0
20
40
60
20
40
60
USB PORTS, POWER OUTLETS & USB CHARGER
Power Outlets A:Use the power outlets for mobile phones and other devices designed
to operate on a 12V (180W max.) power outlet.
USB Port B:Use the USB port to connect USB audio devices and smartphone devices.
USB Charger C:Devices can be recharged using a USB cable. The Engine Start/Stop
button needs to be in the ACC/ON/START position to operate the USB charger.
Reminders:
• Using the power outlets (accessory plugs) for prolonged periods of time with the Engine
Start/Stop button in the ACC position (Engine OFF) may cause the battery to discharge.
• Kia recommends that you only use USB cables made by your device’s manufacturer.
Third-party USB cables may cause damage to your device.
• The USB port Bin the center panel charges slower than the USB chargers C
throughout the vehicle.
Quick Tips:
• The power outlets are inactive when the ignition is in the OFF position.
• The USB data port is located next to the power outlets A. USB charger Cdoes not
support data transfer.
12V
180W
USB
BA C
IDLE, STOP & GO (ISG) SYSTEM
The ISG system is designed to help reduce fuel consumption by automatically shutting
down the engine when the vehicle is at a standstill.
When the ISG system is ON and the vehicle is at a standstill, the engine will stop and the
AUTO STOP indicator on the instrument cluster will illuminate green.
The engine will restart when the brake pedal is released or the shift lever is moved
from the D (Drive) to the R (Reverse) position or to Manual Shift mode. When the engine
restarts, the green AUTO STOP indicator on the instrument cluster will turn off.
To deactivate the ISG system, press the ISG OFF button A. If you press it again, the
system will be activated.
Reminders:
• ISG is active by default at vehicle startup. When ignition is cycled, ISG will turn ON again.
• Under certain conditions, the engine will restart automatically even if the brake
pedal is still depressed.
• If the AUTO STOP indicator is continuously blinking yellow and the ISG button LED is
on, please contact an authorized Kia dealer.
• If the ISG system does not meet the operating conditions outlined in the Owner’s
Manual, it will deactivate, the ISG OFF button will illuminate yellow.
OFF
OFF
A
FORWARD COLLISION-AVOIDANCE ASSIST-PEDESTRIAN (FCA-PED)7/ FORWARD COLLISION WARNING (FCW)7
Forward Collision-Avoidance Assist-Pedestrian (FCA-Ped) is designed to help alert the
driver and, under certain conditions, apply emergency braking when rapidly approaching
a vehicle that is slowing down, braking or stopped, or if it detects a pedestrian in front of
the vehicle. Initially, FCA-Ped provides Forward Collision Warning (FCW) when it detects a
potential collision with a vehicle or a pedestrian in front, emitting an audible warning and
visual alert on the instrument cluster. Adjust the alert settings (Active Assist, Warning
Only, Off) in the User Settings. To turn FCA-Ped/FCW off, go to User Settings again and
turn off.
If the system detects that the collision risk has increased, FCA-Ped can automatically
apply the brakes to reduce your speed, potentially helping to minimize the effects
of a possible collision. FCA-Ped can be turned ON in the User Settings menu on the
Instrument Cluster display.
FCA-Ped/FCW will become active when the:
• Engine Start/Stop button is ON.
• Vehicle is traveling faster than 5 mph.
• Electronic Stability Control (ESC) is ON.
Reminders:
• FCA-Ped/FCW will be activated by default when the ignition is cycled ON, even when
the previous setting was OFF.
• FCA-Ped/FCW will not operate when the vehicle is traveling faster than
approximately 45/50 mph, respectively.
• If FCA-Ped is operating and the ESC (Electronic Stability Control) is turned off,
FCA-Ped system is automatically turned off.
• When the FCA-Ped system is off, the FCA-Ped warning indicator is on in the
Instrument Cluster.
Warning: FCA-Ped and FCW are supplemental systems. Never intentionally attempt to activate
or test the operation of the systems. Do not solely rely on the systems and always drive safely.
Collision Warning
Emergency
Braking
ONE-TOUCH SLIDE AND FOLD SEATS
To get in and out of the 3rd-row seat, you can slide forward and fold down the 2nd row while
pressing the One-Touch Slide and Fold buttons. Buttons are located on the seat cushion A
and in the cargo area B. When stowing 3rd-row seats, it is best to use the One-Touch Slide
and Fold button in the cargo area Bto first stow the 2nd-row seats in order to prevent
damage to 3rd-row seats.
2ND
R
180W
2ND
R
L
2ND
R
180W
2ND
R
L
2ND
R
180W
2ND
R
L
B
A

WIPER SERVICE MODE
To inspect or replace the windshield wiper blades and to prevent damaging the hood, the
blades need to be moved to the service position A.
Have the ignition ON, then turn the ignition OFF, and within 20 seconds, move the wiper
switch up to the MIST position and hold the switch for more than 2 seconds until the
wiper blade is in the fully up position.
To return wipers to normal position, turn the ignition ON, then activate MIST.
A
2020 Telluride SX AWD with Prestige Package shown on cover. Quantities limited. Images or graphics are for illustrative purposes only and may not reflect actual feature
or operation. See the Owner’s Manual for more detailed information, limitations and conditions. *If equipped. 1Driving while distracted can result in a loss of vehicle control
that may lead to an accident, severe personal injury, and death. The driver’s primary responsibility is in the safe and legal operation of a vehicle, and use of any handheld
devices, other equipment, or vehicle systems which take the driver’s eyes, attention and focus away from the safe operation of a vehicle or which are not permissible by
law should never be used during operation of the vehicle. 2The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by Kia is under license. A Bluetooth®enabled cell phone is required to use Bluetooth®Wireless Technology. 3Apple CarPlay, iPhone, and Siri are registered trademarks of
Apple Inc. 4Android and Android Auto are trademarks of Google LLC. Apps may run on your smartphone cellular data service and normal data rates will apply. Requires a
compatible device sold separately. 5Rear Occupant Alert (ROA) is not a substitute for one’s attention and may not detect all movement within the vehicle. Always check
the vehicle interior when exiting the vehicle. 6Safe Exit Assist (SEA) is not a substitute for one’s attention and may not detect all objects surrounding the vehicle. Always
pay attention to traffic and to the area around your vehicle when exiting the vehicle. If necessary, SEA will override attempts to deactivate the Electronic Child Safety
Lock until it’s safe for your rear passengers to open and exit the vehicle. 7These features are not substitutes for safe driving, and may not detect all objects surrounding
vehicle. Always drive safely and use caution. 8Highway Driving Assist (HDA) is not a substitute for safe driving, may not detect all objects surrounding the vehicle, and
only functions on certain federal highways. Always drive safely and use caution. 9High Beam Assist does not operate below certain speeds, or in some lighting and driving
conditions. Please be aware of your surroundings and exercise proper road etiquette when operating a vehicle using the high beams.
©2020 Kia Motors America, Inc., 111 Peters Canyon Road, Irvine, CA 92606
SMART POWER LIFTGATE*
The Smart Power Liftgate can be operated from several controls to either open, close or
lock the Liftgate.
To turn the Smart Power Liftgate features ON, go to User Settings mode in the LCD
Instrument Cluster Modes and set to ON.
Opening from Inside the Vehicle:
Press and hold the Smart Power Liftgate Open/Close button Ato automatically open/
close the Liftgate.
Opening from Outside the Vehicle:
To open the Smart Power Liftgate automatically, press the Liftgate Release button B
on the exterior of the Liftgate.
Automatically close by pressing the Smart Power Liftgate Close button C.
Reminders:
• All doors are closed and locked after about 15 seconds.
• The Smart Power Liftgate feature will not operate when the following occurs:
• Doors are recently closed and locked.
• The Smart Key is still detected after 15 seconds near the vehicle or within
60" of the door handles.
• A door is not locked or closed.
• The Smart Key is in the vehicle.
• Pulling the Liftgate upward by the handle or pressing the button a second time will
interrupt the automatic opening of the Smart Power Liftgate.
Opening with no-touch activation:
When the Smart Key fob is on your person and you are near the back of the vehicle,
within close proximity, the hazard lights will blink and a chime will sound for about
3 seconds as an alert that the Smart Power Liftgate is about to open.
Then the alert system will blink and chime two additional times before opening the
Smart Power Liftgate.
The Smart Power Liftgate feature is OFF by default. To enable the Smart Power Liftgate,
go to User Settings in the LCD Instrument Cluster modes.
Quick Tip:
During the Smart Power Liftgate alert, the Smart Power Liftgate can be deactivated with
the Smart Key by pressing any button on the key fob.
Smart Key:
To open the Smart Power Liftgate, press and hold the Smart Key Liftgate button D
until the Liftgate begins opening. Press again and hold to close.
Power Liftgate Height Adjustment:
For your convenience, the Liftgate opening height is adjustable. To program the opening
height, perform the following:
1. Open the Liftgate and manually position the Liftgate to your preferred opening height.
2. Depress and hold the close button on the Liftgate for 3 seconds or more.
3. Once the system sounds the alert that the programming is complete, manually
close the Liftgate.
Power Liftgate Opening/Closing Speed Setting:
Go to the User Settings in the Instrument Cluster. Select Door, then Power Liftgate
Speed, and select Fast or Normal.
Reminders:
• The default speed is set to fast.
• The speed setting cannot be changed when the Power Liftgate function is turned
off or if the Liftgate is not completely closed.
A
B
C
HOLD
D
A
B
C
HOLD
D
