Kia SOUL EV 2017 Parts list manual

GETTING TO KNOW YOUR SOUL EV
Congratulations on Your New Kia Purchase!
Your new Kia vehicle has been designed, engineered and manufactured to provide you with years of comfortable and dependable driving. Kia is
committed to quality, innovation, safety and — above all — your satisfaction.
Using This Guide
The information contained in this guide is a brief overview that will help you become familiar with the operation and features of your new Kia
vehicle. The flipbook format facilitates information access, while the detailed illustrations help to ensure the instructions are easy to follow.
This Features & Functions Guide, and the specific operational and safety information it provides, is not a substitute for your Owner’s Manual.
In the interest of your safety and that of your family, and to help you avoid risks that may result in death or serious injury, Kia reminds you to
carefully read your Owner’s Manual in order to fully familiarize yourself with the important information it contains.
While the information contained in this guide is accurate at the time of printing, Kia may change vehicle specifications without notice in
advance or after the fact, and assumes no liability in connection with such changes.
www.kia.com
Consumer - Roadside Assistance
1-800-333-4KIA (4542)
See Back Pages for Vehicle
Maintenance Schedule
Always check the Owner’s Manual for complete
operating information and safety warnings.
Available on the App Store, the Kia AR Owner’s Manual
App uses AR (Augmented Reality) technology to
provide tips and useful information about your vehicle.
To use the Kia AR Owner’s Manual App:
• Simply scan the interior or engine (motor) room of
your vehicle with your smart phone or tablet, select
feature/component and view the video guide.
• If you are unable to scan the vehicle, use the
AR Manual (without scan) menu, select feature/
component and view the video guide.

ESSENTIAL FEATURES
SOUL EV FEATURES & FUNCTIONS GUIDE
Air Conditioning / Climate Control . . . . . . . . . . . . 27
Audio Systems - UVO EV Services / Android Auto™/
Apple CarPlay®Setup* . . . . . . . . . . . . . . . . . . 25
Audio Systems - UVO EV Services /
Premium Navigation* . . . . . . . . . . . . . . . . . . . 26
Audio Systems - Standard Audio System* . . . . . . . . 24
Aux/USB/iPod®Port & Power Outlets . . . . . . . . . . . 28
Bluetooth®Wireless Technology . . . . . . . . . . . . . 22
Charging your Electric Vehicle. . . . . . . . . . . . . . . 10
Cruise Control. . . . . . . . . . . . . . . . . . . . . . . 21
Digital Clock. . . . . . . . . . . . . . . . . . . . . . . . 28
Active ECO System . . . . . . . . . . . . . . . . . . . . 09
Folding Rear Seatback . . . . . . . . . . . . . . . . . . 34
Passenger Airbag Off Indicator . . . . . . . . . . . . . . 41
Tire Mobility Kit . . . . . . . . . . . . . . . . . . . . . . 39
Tire Pressure Monitoring System (TPMS) . . . . . . . . . 06
Windshield/Rear Wipers & Washers. . . . . . . . . . . . 19
Driving while distracted can result in a loss of vehicle control
that may lead to an accident, severe personal injury and death.
The driver’s primary responsibility is in the safe and legal
operation of a vehicle, and use of any handheld devices, other
equipment or vehicle systems which take the driver’s eyes,
attention and focus away from the safe operation of a vehicle
or that are not permissible by law should never be used during
operation of the vehicle.
VIDEOS & QR CODES . . . . . . . . . . . . . . 02
INSTRUMENT CLUSTER
Instrument Cluster Overview . . . . . . . . . . . . . . 03
Indicators & Warning Lights . . . . . . . . . . . . . . 04
Electric Vehicle (EV) Indicators . . . . . . . . . . . . . 05
Energy Consumption . . . . . . . . . . . . . . . . . . 06
Tire Pressure Monitoring System (TPMS) . . . . . . . 06
LCD Instrument Cluster Modes. . . . . . . . . . . . . 07
Trip Computer / Tripmeter . . . . . . . . . . . . . . . 07
User Settings Mode . . . . . . . . . . . . . . . . . . 08
Service Mode. . . . . . . . . . . . . . . . . . . . . . 08
ELECTRIC VEHICLE (EV) FEATURES
Active ECO System . . . . . . . . . . . . . . . . . . . 09
Charging Your Electric Vehicle . . . . . . . . . . . . . 10
EV Information Modes - Instrument Cluster . . . . . . 13
EV System Information - UVO EV Services/
Premium Navigation*. . . . . . . . . . . . . . . . . . 14
DRIVER’S PANEL
Instrument Panel Dimmer . . . . . . . . . . . . . . . 16
Electronic Stability Control (ESC). . . . . . . . . . . . 16
Heated Steering Wheel Button . . . . . . . . . . . . . 16
Hill-Start Assist Control (HAC) . . . . . . . . . . . . . 16
Power Windows, Window Lock & Central Door Lock . . 17
Automatic Door Lock/Unlock . . . . . . . . . . . . . . 17
Heated Outside Mirrors* . . . . . . . . . . . . . . . . 17
Power Folding Outside Mirrors* . . . . . . . . . . . . 17
STEERING WHEEL CONTROLS
Tilt/Telescoping Steering Wheel . . . . . . . . . . . . 18
Headlights & High Beams . . . . . . . . . . . . . . . 18
Turn Signals & Fog Lights* . . . . . . . . . . . . . . . 18
Windshield Wipers & Washers . . . . . . . . . . . . . 19
Rear Wiper & Washer. . . . . . . . . . . . . . . . . . 19
FlexSteer™ Steering Wheel Mode . . . . . . . . . . . 20
Audio Controls . . . . . . . . . . . . . . . . . . . . . 21
Cruise Control . . . . . . . . . . . . . . . . . . . . . 21
Bluetooth®Wireless Technology . . . . . . . . . . . . 22
AUDIO SYSTEMS
Standard Audio System* . . . . . . . . . . . . . . . . 24
UVO EV Services / Android Auto™/ Apple CarPlay®Setup* 25
UVO EV Services with Premium Navigation* . . . . . . 26
CENTER PANEL
Automatic Climate Control . . . . . . . . . . . . . . . 27
Driver Only Ventilation . . . . . . . . . . . . . . . . . 28
Reserved Climate Control* . . . . . . . . . . . . . . . 28
Digital Clock . . . . . . . . . . . . . . . . . . . . . . 28
Aux/USB/iPod®Port & Power Outlets . . . . . . . . . 28
Power Button . . . . . . . . . . . . . . . . . . . . . 29
Electronic Parking Brake (EPB). . . . . . . . . . . . . 30
Automatic Gear Shift with Regenerative Brake Mode . 31
Seat Warmers / Ventilated Seats* . . . . . . . . . . . 32
SEATING
6-Way Adjustable Driver’s Seat . . . . . . . . . . . . 33
Front Seat Headrest Adjustment . . . . . . . . . . . . 33
Folding Rear Seatback . . . . . . . . . . . . . . . . . 34
OTHER KEY FEATURES
Smart Key . . . . . . . . . . . . . . . . . . . . . . . 35
Double-Turn Lock/Unlock All . . . . . . . . . . . . . . 35
Panoramic Sunroof Operation* . . . . . . . . . . . . . 36
Map/Room Lamps . . . . . . . . . . . . . . . . . . . 37
Sunvisor . . . . . . . . . . . . . . . . . . . . . . . . 37
Pedestrian Warning System . . . . . . . . . . . . . . 37
Rear-Camera Display. . . . . . . . . . . . . . . . . . 38
Parking Assist System*. . . . . . . . . . . . . . . . . 38
Hood Release Lever and Latch . . . . . . . . . . . . . 39
Tire Mobility Kit. . . . . . . . . . . . . . . . . . . . . 39
High-Voltage Areas . . . . . . . . . . . . . . . . . . . 40
Air Inlet . . . . . . . . . . . . . . . . . . . . . . . . . 40
Tailgate Release Button . . . . . . . . . . . . . . . . 40
Child-Protector Rear Door Locks . . . . . . . . . . . . 40
SAFETY FEATURES
Seat Belts . . . . . . . . . . . . . . . . . . . . . . . 41
Seat Belt Retractor Locks . . . . . . . . . . . . . . . 41
Occupant Detection System (ODS) /
Passenger Airbag Off Indicator. . . . . . . . . . . . . 41
NORMAL MAINTENANCE SCHEDULE. . . 42
LEGAL DISCLAIMERS (See Back Inside Cover Page)
*IF EQUIPPED

2*IF EQUIPPED
SOUL EV FEATURES & FUNCTIONS GUIDE
VIDEOS & QR CODES - SMARTPHONES, TABLETS AND COMPUTERS
1. If you’re having trouble scanning codes, check the following:
•The code should be centered and focused in your mobile device’s camera screen
•Consider moving your device closer to or farther away from the code
•The code should be well lit, without significant shadow
•Avoid scanning from a significant angle
•Confirm that the device’s app supports 2D QR Code scanning
•Try another QR Code Reader App; not all apps are created equal
2. After scanning, if a “connecting” message appears and then nothing happens or there’s a “connection error” message, this typically indicates that your device is having trouble
connecting to the Internet
3. When accessing videos on your mobile device, standard cellular data rates will apply
EV Overview Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
www.youtube.com/KiaFeatureVideos
QR CODE
Kia provides a number of video resources at your disposal to assist you with becoming familiar with the features and
functions found in your Kia vehicle. You can access these resources by snapping the QR Codes with your smartphone/tablet
(mobile devices) or by visiting the following website: www.youtube.com/KiaFeatureVideos. Continue reading for a more
in-depth look at QR Codes and for instructions on how to use them.
What are QR Codes?
A QR Code is a square, 2-dimensional barcode that can be
read by mobile devices loaded with an appropriate barcode
or QR Code Reader App. The app reads the barcode image
and then launches/uploads the specific information the
code contains, such as URLs, text, photos, videos and so
much more.
How to use QR Codes
If you have a mobile device with a QR Code Reader App, you
can snap the code with your phone and you’ll be provided
a video with additional information pertaining to the topic.
For example, in the Instrument Cluster Overview section,
if you would like additional information, just snap the code
with your mobile device to view the selected Kia Features &
Functions Video.
How to snap a QR Code
1. With your mobile device, download a QR Code Reader
App. With many devices, you can do this through an app
store or marketplace
2. Open the QR Code Reader App on your mobile device
3. The app will utilize your device’s camera. Center the code
in the camera viewing area:
•With some apps, as soon as the app recognizes the
code, it will launch the corresponding video
•With other apps, you will have to snap or take a
picture of the code. The app will then launch the
corresponding video
•For operation specifics, refer to the instructions that
come with the QR Code Reader App
QUICK TIPS
REMINDER: When accessing videos
on your mobile device, standard
cellular data rates may apply.

*IF EQUIPPED 3
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS.
INSTRUMENT CLUSTER
Your vehicle’s instrument cluster &
indicator light locations may differ
from those in the illustrations. For
more information on the instrument
cluster, the LCD Warning Messages
and the function of all indicator and
warning lights, please refer to the
Owner’s Manual.
EV Overview Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
www.youtube.com/KiaFeatureVideos
Energy Consumption
Hold : Reset
048
--.-mi./kwh
POWER
ECO
GUIDE
CHARGE
MAX
MIN
EPB
RANGE
mi.
MPH
POWER
ECO
GUIDE
CHARGE
MAX
MIN
EPB
RANGE
mi.
MPH
ECO electric
Energy Consumption
Hold : Reset
048
--.-mi./kwh
A
B
D
C C
F G
H
E
I
QR CODE
AMotor Operation Gauge
BRange Meter
CTurn Signal Indicators
DState-of-Charge Gauge
EIndicators & Warnings Lights
FGear Shift Position
GTrip Computer / Trip Meter
HOdometer
ISpeedometer
Instrument Cluster Overview

4*IF EQUIPPED
SOUL EV FEATURES & FUNCTIONS GUIDE
INSTRUMENT CLUSTER
Energy Consumption
Hold : Reset
048
--.-mi./kwh
POWER
ECO
GUIDE
CHARGE
MAX
MIN
EPB
RANGE
mi.
MPH
POWER
ECO
GUIDE
CHARGE
MAX
MIN
EPB
RANGE
mi.
MPH
ECO electric
Energy Consumption
Hold : Reset
048
--.-mi./kwh
EV Cluster Overview Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
www.youtube.com/KiaFeatureVideos
A B
QR CODE
Indicators & Warning Lights
Ready Indicator Light
Service Warning Light
Charging Indicator Light
Power Down Warning Light
High-Voltage Battery Level
Warning Light
Anti-lock Braking System (ABS)
Warning Light
Cruise ON/OFF Indicator
Cruise SET Indicator
Electronic Stability Control
(ESC) Indicator
Immobilizer Indicator Light*
Electronic Stability Control
(ESC) OFF Indicator
Low Tire Pressure Light / Tire
Pressure Monitoring System
(TPMS) Malfunction Indicator
Tailgate Open Warning Light
Seat Belt Warning Light
Door Ajar Warning Light
Regenerative Brake Warning
Light (red/yellow) (Two separate
indicators on Instrument Cluster
lit at same time)
High Beam Indicator
Light ON Indicator
Airbag Warning Light
Electric Parking Brake (EPB)
Parking Brake & Brake Fluid
Warning Light
Electronic Brake Force
Distribution (EBD) System
Warning Light (Two separate
indicators on Instrument Cluster
lit at same time)
Front Fog Light Indicator*
ECOMINDER®indicator
(Active ECO system)
Electronic Power Steering
Warning Light
Your vehicle’s instrument cluster &
indicator light locations may differ
from those in the illustrations. For
more information on the instrument
cluster, the LCD Warning Messages
and the function of all indicator and
warning lights, please refer to the
Owner’s Manual.

*IF EQUIPPED 5
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS.
INSTRUMENT CLUSTER
Electric Vehicle (EV) Indicators
AMotor operation gauge
Soul EV’s motor operation gauge provides information on the
energy consumption rate of the vehicle and the charge status of the
regenerative brakes.
•CHARGE – Shows the charging status of the battery when it is
being charged by the regenerative brakes. The more electric
energy charged, the lower the gauge level
•ECO GUIDE – Shows the energy consumption rate during normal
driving conditions
•POWER – Shows the energy consumption rate of the vehicle when
driving uphill or accelerating. The more electric energy used, the
higher the gauge level
BState of Charge gauge (SOC)
The State of Charge gauge displays the high-voltage battery
charge status.
•MIN position on the gauge indicates that the driving battery
energy is low
•MAX position on the gauge indicates that the driving battery is
fully charged
Ready indicator light – Illuminates when the vehicle is ready
to drive. When the ready indicator light is OFF or blinking, a
malfunction has occurred. Have an authorized Kia dealer address
the concern as soon as possible.
ECOMINDER®indicator – Indicates that the Active ECO System
is operational. This indicator light is always illuminated unless
the Active ECO System is turned OFF.
Service warning light – Illuminates when there is a malfunction
related to the electric vehicle control system. Have an authorized
Kia dealer address the concern as soon as possible.
Power down warning light – Illuminates when the power is
limited for the safety of the electric vehicle.
Charging indicator light – Shows the charging status of the
high-voltage battery. When charging, the red indicator turns on.
When charging is complete, the green indicator turns on.
High-voltage battery level warning light – Illuminates when
the high-voltage battery charge level is insufficient.
Regenerative brake warning lights (when both indicators
are lit) – Illuminates when the regenerative brake system is not
functioning correctly.

6*IF EQUIPPED
SOUL EV FEATURES & FUNCTIONS GUIDE
INSTRUMENT CLUSTER
Tire Pressure Monitoring
System Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to page 2 for more
information.
www.youtube.com/KiaFeatureVideos
QR CODE
Energy Consumption
There are several factors that contribute to your electric
vehicle’s energy consumption, including maintenance
of your vehicle, driving style, environmental conditions,
vehicle weight and vehicle aerodynamics.
Below are tips on how to help reduce
energy consumption:
•Keep your vehicle in good condition with
regular maintenance
•Don’t “ride” the brake pedal
•Drive at a moderate speed, accelerating smoothly
and at a moderate rate
•Keep tires inflated to the recommended pressure
•Travel lightly, without carrying unnecessary weight
in your vehicles
•Ensure wheels are aligned correctly
•Avoid placing large or heavy items on roof racks
•Avoid hilly, winding or poorly maintained roads
REMINDER: Do not turn the vehicle off by pushing the POWER button
while the vehicle is in motion. If the vehicle has been turned off the
power brake and power steering system cannot operate.
Tire Pressure Monitoring System (TPMS)
The indicator functions as both Low Tire Pressure
Light and TPMS Malfunction Indicator.
The TPMS indicator illuminates if one or more tires is
significantly underinflated, the vehicle has a spare tire
installed without TPMS or the outside temperature becomes
significantly lower.
Inflate tire(s) to specifications using an accurate digital tire
pressure gauge to turn off Low Tire Pressure Light . See
front driver’s door jamb for PSI specification.
When there is a problem with the TPMS, the TPMS
Malfunction Indicator will blink for approximately one
minute and then illuminate - see dealer for service.
REMINDER: Consult your dealer for service if Low Tire Pressure Light remains
illuminated after inflating your tire(s).
•
•Even with TPMS, tire pressure should be checked manually at
least once a month. Only adjust Tire Pressure on “cold tires”
•For proper maintenance and optimal fuel economy, maintain
recommended tire inflation pressures and stay within the load
limits and weight distribution recommended for your vehicle
•In winter or cold weather, the TPMS light may illuminate if the
tire pressure was adjusted to the recommended tire inflation
pressure during warm weather
QUICK TIPS

*IF EQUIPPED 7
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS.
INSTRUMENT CLUSTER
MODE
SET
CRUISE
RES
CANCEL
MODE
VOL
VOL
SET
CRUISE
RES
MODE
A
Energy Consumption
Hold : Reset
048
--.-mi./kwh
MODE
SET
CRUISE
RES
CANCEL
MODE
VOL
VOL
SET
CRUISE
RES
MODE
B
C
ENERGY CONSUMPTION
• Average Energy
Consumption
• Instant Energy
Consumption
TRIP A
• Tripmeter A
• Average Vehicle Speed
• Elapsed Time (E/T)
TRIP B
• Tripmeter B
• Average Vehicle Speed
• Elapsed Time (E/T)
(Buttons located on Steering Wheel)
(LCD Instrument Cluster mode buttons located on Steering Wheel)
LCD Instrument Cluster Modes
To cycle through the LCD Instrument Cluster modes, press
the Mode/Select button A
Trip Computer Mode: Displays driving information
for tripmeter, energy consumption, etc.
Master Warning / Service Modes: Informs on
upcoming service intervals, and warning messages
related to TPMS and others
User Settings Mode: Change settings of the doors,
lamps and other features
A/V Mode: Displays the state of the A/V System
EV Information: Displays EV System energy flow and
ECO level
Trip Computer / Tripmeter
The Trip Computer is a driver information system
that displays information related to driving —
such as Average and Instant Energy Consumption,
Tripmeter, Average Vehicle Speed and Driving
Time — on the display when the ignition switch is
in the ON position.
To cycle through the LCD Instrument Cluster
modes, press the Mode/Select button B.
When in the Trip Computer mode , press
the Move/Reset button Cto cycle through the
screens. When displaying Trip A or Trip B screens,
press and hold the Move/Reset button Cto reset
the Tripmeter to zero.
REMINDERS:
•Appearance of Tripmeter display may differ as equipped
•All stored driving information (except Odometer and Range) is reset if the battery is disconnected

8*IF EQUIPPED
SOUL EV FEATURES & FUNCTIONS GUIDE
INSTRUMENT CLUSTER
P
35000 mi 365days
Service Interval
Service Interval
OFF
P
P
Service Required
Service Interval
Back
On
Off
01000 mi
10 months
P
MODE
SET
CRUISE
RES
CANCEL
MODE
VOL
VOL
MODE
A
B
(Buttons located on Steering Wheel)
(Instrument Cluster LCD Screens)
User Settings Mode
To enter the User Settings mode in the LCD Instrument
Cluster Modes, press the Mode/Select button Awhen the
vehicle is at a standstill and with the POWER button in the
ON position and select User Settings .
You can navigate the selections on the display by pressing
the Move/Reset button B, and then selecting the item by
pressing the Mode/Select button A.
Door:
•Auto Door Lock
•Auto Door Unlock
•Two Press Unlock
•Horn Feedback
Lights:
•One-Touch Turn Lamp*
•Headlamp Delay*
Settings:
•Language
•Temperature Unit
•Welcome Sound*
•Energy Consumption Auto Reset
Service Interval:
•ON/OFF
•Set mileage/months
Service Mode
To enter Service Mode, press the Mode/Select button A, scroll to Service
Mode by pressing Move/Reset button B. Then press the Mode/Select
button Ato enter. System will display number of miles remaining until next
service is due, and type of service.
When service is required, the following will be displayed: Service Required.
To reset the Service Mode system, press and hold the Move/Reset button
Bfor more than 1 second.
To turn Service In mode OFF, go to User Settings in the
LCD Instrument Cluster Modes.
Service Interval Setting
To set the service interval when in User Settings mode:
•Press the Move/Reset button Band scroll to Service
Interval. Press the Mode/Select button Ato enter
•Press the Move/Reset button Band toggle to ON,
then press the Move/Select button A. Then press the
Move/Reset button Bto scroll and select the desired
miles or months for your next service
•Press the Mode/Select button Ato enter

*IF EQUIPPED 9
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS.
ELECTRIC VEHICLE (EV) FEATURES
EV Active ECO Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to page 2 for more
information.
www.youtube.com/KiaFeatureVideos
ACTIVE
ECO
ECO
OFF
ECO
OFF
Energy Consumption
Hold : Reset
048
--.-mi./kwh
POWER
ECO
GUIDE
CHARGE
MAX
MIN
EPB
RANGE
mi.
MPH
POWER
ECO
GUIDE
CHARGE
MAX
MIN
EPB
RANGE
mi.
MPH
ECO electric
Energy Consumption
Hold : Reset
048
--.-mi./kwh
A
B
(Shown in Instrument Cluster)(Button located below Gear Shift)
P
R
N
D
B
SHIFT
LOCK
RELEASE
POWER
C
QR CODE
Active ECO System
Soul EV is equipped with an ECO feature that improves energy
efficiency and helps extend battery life. The Active ECO System
helps reduce energy consumption by controlling several vehicle
components. When activated, it optimizes drivetrain operations
to help improve energy economy.
Active ECO System ON results in reduced torque, higher energy
efficiency, and enhanced regenerative braking.
Active ECO System OFF results in more torque, lower energy
efficiency, and reduced regenerative braking.
The Active ECO System is activated by pressing the ACTIVE ECO
button A(LED illuminated) and can be deactivated by pressing the
button again (LED not illuminated). The green ECO indicator light Bin
the instrument cluster will illuminate, indicating that ECO is operating.
Regenerative Brake Mode “B” – Move the
gear shift to the “B” position Cto enter the
maximum regenerative braking drive mode.
This mode helps to minimize energy loss and
increase the distance to empty.
To help reduce energy consumption:
•Drive at a moderate speed, accelerating smoothly and at a moderate rate
•Keep tires inflated to the recommended pressure and wheels aligned properly
•Be sure the wheels are properly aligned
QUICK TIPS
REMINDER: When Active ECO is activated and the Power button is cycled, the Active ECO system
remains ON.
For more information on the Active ECO System, refer to your Owner’s Manual or contact your
local dealership.

10 *IF EQUIPPED
SOUL EV FEATURES & FUNCTIONS GUIDE
ELECTRIC VEHICLE (EV) FEATURES
Zero Emission
POWER
CHARGE
FAULT
B
A
C
D
OFF
MUSIC
MOOD
E
(Buttons located left of steering column)
(Control box on charging cable)
Charging Your Electric Vehicle
Level 1 Charging – “Trickle” Charge
A Level 1 or “trickle” charger is the most common type of charging system for an electric vehicle. This type
of charger uses 110 volts of household electricity and takes up to 24 hours for a full charge.
Trickle Charger Indicators:
AICCB – In-Cable Control Box
BPower – Indicates that the charger is plugged in
and functioning.
CCharge – Indicates that the vehicle is charging.
DFault – Indicates charge failure.
REMINDER: Do not use an extension cord. Plug Trickle charger directly into wall socket.
Level 2 Charging – “Normal” Charge
A Level 2 or “normal” charger is the recommended charging system for your Soul EV. This type of charger
uses 240 volts of electricity and takes approximately 4-5 hours for a full charge (Based on Kia Motors
Corporation testing with SAE J1772 charger performed at 6.6kW). This charger can be installed at your home
or found at a public charging station.
REMINDER: Shape of charger and how to use the charger may be different for each manufacturer. Please see Owner’s Manual for
more information.
Level 3 Charging - “Quick” Charge
A Level 3 or “Quick” charger are usually found at public charging stations. This type of charge may charge
an electric vehicle in as little as 43 minutes to about an 83% charge.
For more information on Level 3 Charging, refer to the Owner’s Manual
A Level 2 or “normal” 240-volt charger is recommended for regular charging of the vehicle.
QUICK TIP
REMINDER: For more detail and/or subsequent steps in charging your vehicle, please see the Owner's Manual.

*IF EQUIPPED 11
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS.
ELECTRIC VEHICLE (EV) FEATURES
(Normal/trickle charge shown)
Zero Emission
POWER
CHARGE
FAULT
Zero Emission
POWER
CHARGE
FAULT
G
Zero Emission
POWER
CHARGE
FAULT
H
I
F
EV Charging, Charging
Station Search Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to page 2 for more
information.
www.youtube.com/KiaFeatureVideos
QR CODE
REMINDER: For more detail and/or subsequent steps in charging your vehicle, please see
the Owner’s Manual.
Charging Your Electric Vehicle (Continued)
To charge the Soul EV using a normal/trickle charger:
1. Connect the ICCB Aplug to an electrical outlet
2. Check if the power light (green) Bon the ICCB turns on
3. Press the brake pedal and engage the parking brake
4. Turn off all switches, put the shift lever in P (Park), and turn off
the vehicle
5. Release the charging door by pressing the charging door open button
Elocated to the left of the steering column
6. Open the charging door Fat the front of the vehicle and press the
trickle charging inlet release tab to open the inlet cover G
7. Open the protective cover Gof the trickle charger’s charging
connector
8. Hold the charging connector handle and connect it to the vehicle’s
trickle charging inlet Hby pushing the connector until you hear a
“clicking” sound
9. Charging begins automatically (Ensure the charge indicator light
is illuminated on your instrument cluster, indicating the vehicle is
charging)
Checking the Charging Status
The charging status can be checked by viewing the charging status
indicator Ion the dash panel. The lights will progressively become
lit as the vehicle approaches a full charge.

12 *IF EQUIPPED
SOUL EV FEATURES & FUNCTIONS GUIDE
ELECTRIC VEHICLE (EV) FEATURES
OFF
MUSIC
MOOD
A
(Buttons located left of steering column)
Charging Your Electric Vehicle (Continued)
Reserved Charging* - Charging times can be set using the UVO EV Services with
Premium Navigation* settings when in EV Mode. You can also use the Reserved Charging*
App on your smartphone.
Reserved Charging* with the UVO Eco* App:
The UVO Eco* App can help you find the nearest charging station, displays charging-status
information and the lists the Reserved Charging* schedule. On your Smartphone, go to an
app store or marketplace to download the UVO Eco* App.
REMINDER: When Reserved Charging* is set and the charger is plugged in, charging of the electric vehicle will not
begin until the time and date set.
For more information on UVO Eco* and using the app refer to the Car Multimedia System User’s Manual.
Deactivate reserved charging - Depress the Deactivate Reserved Charging button* Ato
disable the reserved charging feature when immediate charging is required.
When you press the Deactivate Reserved Charge button* for immediate charging, the reserved charge
setting is not completely deactivated. If you need to completely deactivate the reserved charge setting,
use the UVO EV Services with Premium Navigation* to finalize the deactivation.
QUICK TIP
REMINDER: For more detail and/or subsequent steps in charging your vehicle, please see the Owner’s Manual.

*IF EQUIPPED 13
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS.
ELECTRIC VEHICLE (EV) FEATURES
ECO Level 4
P
Energy Flow
P
ECO Level 4
P
Energy Flow
P
MODE
SET
CRUISE
RES
CANCEL
MODE
VOL
VOL
MODE
(Buttons located on Steering Wheel)
A
B
EV Information Modes - Instrument Cluster
To access the EV Information Mode screen, use the control buttons
located on the steering wheel. Press the Mode/Select button Ato enter.
You can navigate the selections on the screen by pressing the
following buttons:
•Use the Mode/Select button Afor changing modes and setting a
selected item
•Use the Move button Bfor changing items
Soul EV’s instrument cluster LCD displays the following EV system screens
to inform the driver of the current energy flow and ECO level.
The EV Energy Flow screen notifies the driver of the EV system’s energy
flow in operating modes.
EV Propulsion – Energy
flows from high-voltage
battery to the wheel when
the vehicle is driven by motor
Regenerative Braking – Energy flows
from wheel to high-voltage battery when
the accelerator pedal is released or the
brake pedal is pressed.
The ECO Level screen displays the
current ECO driving level. If you drive
economically, the ECO level will increase.
If you do not drive economically, the ECO
level will decrease.

14 *IF EQUIPPED
SOUL EV FEATURES & FUNCTIONS GUIDE
ELECTRIC VEHICLE (EV) FEATURES
DRIVER
ONLY
PASSENGER
AIR BAG
EV
DRIVER
EV
ONLY
PASSENGER
AIR BAG
3:00PM
Electric Vehicle
ECO Driving Set timings for EV Settings
charging/climate
Available Range Nearby Stations Energy Information
124 2.50 80 km km %
3:00PM
Range
Anytown
Auto
10 mi
20 km
24 km 112
3
3:00PM
Nearby Stations (106)
1.2mi
4.5mi
9.8mi
1.0mi
0.6mi
Distance
3:00PM
ECO Driving Distance
Mar 18, 2014
Mar 12, 2014
Mar 10, 2014
Mar 08, 2014
Mar 06, 2014 1.86 mi
1.93 mi
14.52 mi
0.00 mi
10.56 mi 99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
ECO Level History
3:00PM
EV Settings
Warning
EV Route
Low Battery Warning
Frequency
Destination Unreachable
Warning
Off
The range warning is displaye if the
selected navigation destination is further
than the currently available vehicle range
3:00PM
Energy Information
72 mi
80 %
Battery Information Power Consumption
Range
Expected Charging Time
3h 40min
Normal
11:13Jun 2 AM
3:00PM
ECO Driving
ECO Level History
ECO Level 4
Energy
Consumption
--.-
mi/kWh
Cancel
Select Charging Option
Set Start Time + 100% Charge
Sets Charging Start Time for each day of the week. Charging
will be continued until maximum charge (100%) is reached
Set Start Time + Set End Time
Sets Charging Start Time and End Time for each day of the
week
3:00PM
Electric Vehicle
ECO Driving Set timings for EV Settings
charging/climate
Available Range Nearby Stations Energy Information
124 2.50 80 km km %
3:00PM
Range
Anytown
Auto
10 mi
20 km
24 km 112
3
3:00PM
Nearby Stations (106)
1.2mi
4.5mi
9.8mi
1.0mi
0.6mi
Distance
3:00PM
ECO Driving Distance
Mar 18, 2014
Mar 12, 2014
Mar 10, 2014
Mar 08, 2014
Mar 06, 2014 1.86 mi
1.93 mi
14.52 mi
0.00 mi
10.56 mi 99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
ECO Level History
3:00PM
EV Settings
Warning
EV Route
Low Battery Warning
Frequency
Destination Unreachable
Warning
Off
The range warning is displaye if the
selected navigation destination is further
than the currently available vehicle range
3:00PM
Energy Information
72 mi
80 %
Battery Information Power Consumption
Range
Expected Charging Time
3h 40min
Normal
11:13Jun 2 AM
3:00PM
ECO Driving
ECO Level History
ECO Level 4
Energy
Consumption
--.-
mi/kWh
Cancel
Select Charging Option
Set Start Time + 100% Charge
Sets Charging Start Time for each day of the week. Charging
will be continued until maximum charge (100%) is reached
Set Start Time + Set End Time
Sets Charging Start Time and End Time for each day of the
week
3:00PM
Electric Vehicle
ECO Driving Set timings for EV Settings
charging/climate
Available Range Nearby Stations Energy Information
124 2.50 80 km km %
3:00PM
Range
Anytown
Auto
10 mi
20 km
24 km 112
3
3:00PM
Nearby Stations (106)
1.2mi
4.5mi
9.8mi
1.0mi
0.6mi
Distance
3:00PM
ECO Driving Distance
Mar 18, 2014
Mar 12, 2014
Mar 10, 2014
Mar 08, 2014
Mar 06, 2014 1.86 mi
1.93 mi
14.52 mi
0.00 mi
10.56 mi 99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
ECO Level History
3:00PM
EV Settings
Warning
EV Route
Low Battery Warning
Frequency
Destination Unreachable
Warning
Off
The range warning is displaye if the
selected navigation destination is further
than the currently available vehicle range
3:00PM
Energy Information
72 mi
80 %
Battery Information Power Consumption
Range
Expected Charging Time
3h 40min
Normal
11:13Jun 2 AM
3:00PM
ECO Driving
ECO Level History
ECO Level 4
Energy
Consumption
--.-
mi/kWh
Cancel
Select Charging Option
Set Start Time + 100% Charge
Sets Charging Start Time for each day of the week. Charging
will be continued until maximum charge (100%) is reached
Set Start Time + Set End Time
Sets Charging Start Time and End Time for each day of the
week
(Button located
on Center Panel)
EV System Information - UVO EV Services with Premium Navigation*
EV mode on the UVO EV Services with Premium Navigation* screen allows you to navigate to a total of six menus that include
available driving range, nearby charging stations, energy usage, ECO driving, charging and climate settings, and EV settings.
EV button - Press the EV button to access the EV mode screen or
press the EV Mode button* on the touchscreen.
Available range - Displays the available driving distance
according to the vehicle’s current location and charge
amount. Reachable areas are displayed within a green
circle. Risky areas are displayed within a red circle.
Unreachable areas are displayed in a gray shaded area.
EV mode menu - The EV mode menu allows
you to access six EV menus.
Nearby stations - Displays charging stations near the
vehicle’s current location. The station locations are
categorized as reachable, risky or unreachable areas.

*IF EQUIPPED 15
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS.
ELECTRIC VEHICLE (EV) FEATURES
3:00PM
Electric Vehicle
ECO Driving Set timings for EV Settings
charging/climate
Available Range Nearby Stations Energy Information
124 2.50 80 km km %
3:00PM
Range
Anytown
Auto
10 mi
20 km
24 km 112
3
3:00PM
Nearby Stations (106)
1.2mi
4.5mi
9.8mi
1.0mi
0.6mi
Distance
3:00PM
ECO Driving Distance
Mar 18, 2014
Mar 12, 2014
Mar 10, 2014
Mar 08, 2014
Mar 06, 2014 1.86 mi
1.93 mi
14.52 mi
0.00 mi
10.56 mi 99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
ECO Level History
3:00PM
EV Settings
Warning
EV Route
Low Battery Warning
Frequency
Destination Unreachable
Warning
Off
The range warning is displaye if the
selected navigation destination is further
than the currently available vehicle range
3:00PM
Energy Information
72 mi
80 %
Battery Information Power Consumption
Range
Expected Charging Time
3h 40min
Normal
11:13Jun 2 AM
3:00PM
ECO Driving
ECO Level History
ECO Level 4
Energy
Consumption
--.-
mi/kWh
Cancel
Select Charging Option
Set Start Time + 100% Charge
Sets Charging Start Time for each day of the week. Charging
will be continued until maximum charge (100%) is reached
Set Start Time + Set End Time
Sets Charging Start Time and End Time for each day of the
week
3:00PM
Electric Vehicle
ECO Driving Set timings for EV Settings
charging/climate
Available Range Nearby Stations Energy Information
124 2.50 80 km km %
3:00PM
Range
Anytown
Auto
10 mi
20 km
24 km 112
3
3:00PM
Nearby Stations (106)
1.2mi
4.5mi
9.8mi
1.0mi
0.6mi
Distance
3:00PM
ECO Driving Distance
Mar 18, 2014
Mar 12, 2014
Mar 10, 2014
Mar 08, 2014
Mar 06, 2014 1.86 mi
1.93 mi
14.52 mi
0.00 mi
10.56 mi 99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
ECO Level History
3:00PM
EV Settings
Warning
EV Route
Low Battery Warning
Frequency
Destination Unreachable
Warning
Off
The range warning is displaye if the
selected navigation destination is further
than the currently available vehicle range
3:00PM
Energy Information
72 mi
80 %
Battery Information Power Consumption
Range
Expected Charging Time
3h 40min
Normal
11:13Jun 2 AM
3:00PM
ECO Driving
ECO Level History
ECO Level 4
Energy
Consumption
--.-
mi/kWh
Cancel
Select Charging Option
Set Start Time + 100% Charge
Sets Charging Start Time for each day of the week. Charging
will be continued until maximum charge (100%) is reached
Set Start Time + Set End Time
Sets Charging Start Time and End Time for each day of the
week
3:00PM
Electric Vehicle
ECO Driving Set timings for EV Settings
charging/climate
Available Range Nearby Stations Energy Information
124 2.50 80 km km %
3:00PM
Range
Anytown
Auto
10 mi
20 km
24 km 112
3
3:00PM
Nearby Stations (106)
1.2mi
4.5mi
9.8mi
1.0mi
0.6mi
Distance
3:00PM
ECO Driving Distance
Mar 18, 2014
Mar 12, 2014
Mar 10, 2014
Mar 08, 2014
Mar 06, 2014 1.86 mi
1.93 mi
14.52 mi
0.00 mi
10.56 mi 99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
ECO Level History
3:00PM
EV Settings
Warning
EV Route
Low Battery Warning
Frequency
Destination Unreachable
Warning
Off
The range warning is displaye if the
selected navigation destination is further
than the currently available vehicle range
3:00PM
Energy Information
72 mi
80 %
Battery Information Power Consumption
Range
Expected Charging Time
3h 40min
Normal
11:13Jun 2 AM
3:00PM
ECO Driving
ECO Level History
ECO Level 4
Energy
Consumption
--.-
mi/kWh
Cancel
Select Charging Option
Set Start Time + 100% Charge
Sets Charging Start Time for each day of the week. Charging
will be continued until maximum charge (100%) is reached
Set Start Time + Set End Time
Sets Charging Start Time and End Time for each day of the
week
3:00PM
Electric Vehicle
ECO Driving Set timings for EV Settings
charging/climate
Available Range Nearby Stations Energy Information
124 2.50 80 km km %
3:00PM
Range
Anytown
Auto
10 mi
20 km
24 km 112
3
3:00PM
Nearby Stations (106)
1.2mi
4.5mi
9.8mi
1.0mi
0.6mi
Distance
3:00PM
ECO Driving Distance
Mar 18, 2014
Mar 12, 2014
Mar 10, 2014
Mar 08, 2014
Mar 06, 2014 1.86 mi
1.93 mi
14.52 mi
0.00 mi
10.56 mi 99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
ECO Level History
3:00PM
EV Settings
Warning
EV Route
Low Battery Warning
Frequency
Destination Unreachable
Warning
Off
The range warning is displaye if the
selected navigation destination is further
than the currently available vehicle range
3:00PM
Energy Information
72 mi
80 %
Battery Information Power Consumption
Range
Expected Charging Time
3h 40min
Normal
11:13Jun 2 AM
3:00PM
ECO Driving
ECO Level History
ECO Level 4
Energy
Consumption
--.-
mi/kWh
Cancel
Select Charging Option
Set Start Time + 100% Charge
Sets Charging Start Time for each day of the week. Charging
will be continued until maximum charge (100%) is reached
Set Start Time + Set End Time
Sets Charging Start Time and End Time for each day of the
week
EV Energy Information
AVN Screen Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to page 2 for more
information.
www.youtube.com/KiaFeatureVideos
QR CODE
EV System Information - UVO EV Services with Premium Navigation*
Energy information - Displays battery charge
information and electrical power consumption.
ECO driving - Displays ECO level information and
ECO driving history.
Set timings for charging/climate - Allows you
to select the time and date you wish to reserve for
automatic charging and automatic climate control.
EV Settings - Allows the user to change the EV
warning alarm settings.

DRIVER'S PANEL
16 *IF EQUIPPED
SOUL EV FEATURES & FUNCTIONS GUIDE
OFF
MUSIC
MOOD
A
B
C
(Buttons located left of steering column)
Instrument Panel Dimmer
With parking lights / headlights ON, press button A+ or – to adjust
display brightness of the instrument panel illumination.
REMINDERS:
• Door Mood Lamp is a fixed brightness and cannot be adjusted (not to be confused with
Advanced Mood Lighting Speaker)
• The Instrument Panel Dimmer does not adjust brightness on the UVO EV Services with
Premium Navigation* screen; use UVO EV Services with Premium Navigation* settings menu
to adjust brightness on the screen.
Electronic Stability Control (ESC)
The ESC system is designed to help stabilize the vehicle during cornering
maneuvers. It is a good idea to keep the ESC turned ON for daily driving
whenever possible.
Press ESC button Bto turn ESC OFF/ON.
REMINDERS:
•ESC is turned ON by default at vehicle start-up. If vehicle power is cycled, ESC will turn
ON again
•The ESC Indicator Light in the instrument cluster will be lit momentarily whenever the ESC
is active
Heated Steering Wheel Button
Press button Cto turn ON/OFF steering wheel heater, while the Engine
Start/Stop Button is in the ON position. Steering wheel heater will turn off
automatically in 30 minutes, or when button is pressed again to deactivate.
If ignition is turned OFF, then ON again, within 30 minutes of steering wheel heater
being turned on, system will automatically be set ON again.
QUICK TIP
Hill-Start Assist Control (HAC)
HAC helps prevent the vehicle from rolling backward when accelerating
from a stop while on a steep incline. The HAC automatically activates
whether the ESC is OFF or ON but does NOT activate when the ESC has
malfunctioned.
REMINDER: The HAC does not operate when the gear shift is in the P (Park) or the N (Neutral)
position.
•
•HAC provides a 2-second delay before the vehicle may start rolling backwards
•When HAC is active (e.g., accelerating from a stop on an incline), you may
notice that the brakes will momentarily remain engaged after you depress the
accelerator
QUICK TIPS

DRIVER'S PANEL
*IF EQUIPPED 17
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS.
A
B
C
D
E
Power Windows, Window Lock & Central Door Lock
APull/Press to operate Driver’s and Front Passenger’s window Auto Up/Down
BPress to Unlock/Lock All Doors
CPress to disable Rear Passenger Windows
REMINDER: When button Cis pressed, window controls for the Rear Passenger Windows are disabled.
Button configuration may vary depending on vehicle model.
Automatic Door Lock/Unlock
Auto Door Lock/Unlock will engage when the gear shift is
moved in to or out of the P (Park) position. Refer to the User
Settings in the LCD Instrument Cluster modes on how to
turn Auto Door Lock/Unlock ON/OFF.
Heated Outside Mirrors*
Mirror heaters automatically turn ON/OFF at the same time
the Rear Window Defroster is turned ON/OFF. Rear Window
Defroster button* is located on climate control system panel.
Power Folding Outside Mirrors*
Toggle switch Dleft or right to select mirror. Then press
arrows to adjust mirror position.
Toggle button Eleft/right to unfold/fold the outside
rearview mirrors.
Toggle button Eto center to automatically fold/unfold
mirrors when:
• The Smart Key Lock/Unlock buttons are pressed
• The door outside handle button is pressed
REMINDERS:
•To automatically fold mirrors when exiting vehicle, press the LOCK button
on the Smart Key
•To lock position of mirrors, toggle switch to the neutral (center) position
The mirrors will automatically unfold when the Smart Key* is
within close proximity to the vehicle.
QUICK TIP

STEERING WHEEL CONTROLS
18 *IF EQUIPPED
SOUL EV FEATURES & FUNCTIONS GUIDE
AUTO Automatic Headlights position
Parking light position
Headlight position
OFF OFF position
One-Touch
Lane Change
Signal
B
C
A
Tilt/Telescoping Steering Wheel
To adjust the Steering Wheel, push down the lock-
release lever Aand adjust the desired angle B
and then the distance C.
When finished, pull up the lock-release lever Ato
lock Steering Wheel in place.
Headlights & High Beams
To operate:
•Rotate lever to change the Headlight function
•Push lever to turn High Beams ON
•Pull lever to flash Headlights / High Beams
AUTO Light function — When the light switch is in
the AUTO Light position, the tail lights and headlights
will turn ON/OFF automatically, depending on the
amount of light outside the vehicle.
Turn Signals & Fog Lights*
To operate:
•Turn Signals - Move lever
Up/Down for Right/Left Turn Signal
•Fog Lights - Rotate lever ring to
turn Fog Lights ON/OFF
One-Touch Lane Change Signal is activated by moving the Turn Signal Lever slightly for less
than 1 second and then releasing. The lane change signal will blink 3 times.
To change how many times (3/5/7) the Lane Change Signal blinks, go to User Settings Mode* in
the LCD Instrument Cluster modes (Type B cluster).
For more information on the User Settings Mode, please refer to your Owner’s Manual.
It may be helpful to pull/push bottom of Steering Wheel
towards/ away from you to adjust desired distance.
QUICK TIP
