Kia CADENZA 2019 Parts list manual

GETTING TO KNOW YOUR CADENZA
Congratulations on Your New Kia Purchase!
Your new Kia vehicle has been designed, engineered and manufactured to provide you with years of comfortable and dependable
driving. Kia is committed to quality, innovation, safety and — above all — your satisfaction.
Using This Guide
The information contained in this guide is a brief overview that will help you become familiar with the operation and features of your
new Kia vehicle. The flipbook format facilitates information access, while the detailed illustrations help to ensure the instructions are
easy to follow.
This Features & Functions Guide, and the specific operational and safety information it provides, is not a substitute for your Owner’s
Manual. In the interest of your safety and that of your family, and to help you avoid risks that may result in death or serious injury,
Kia reminds you to carefully read your Owner’s Manual in order to fully familiarize yourself with the important information it contains.
While the information contained in this guide is accurate at the time of printing, Kia may change vehicle specifications without
notice in advance or after the fact, and assumes no liability in connection with such changes.
www.kia.com
Consumer - Roadside Assistance†18
1-800-333-4KIA (4542)
See Back Pages for Vehicle Maintenance Schedule
Always check the Owner’s Manual for complete operating information and safety warnings.

ESSENTIAL FEATURES
CADENZA FEATURES & FUNCTIONS GUIDE
Air Conditioning / Automatic Climate Control . . . . . . 29
Android Auto™/ Apple CarPlay®Setup . . . . . . . . . . 24
Audio System – UVO eServices System* . . . . . . . . . 25
Audio System – UVO eServices / Premium Navigation* . 26
Audio System – UVO eServices Activation . . . . . . . . 24
Aux/USB/iPod®* Port* & Power Outlets* . . . . . . . . . 28
Bluetooth®Wireless Technology . . . . . . . . . . . . .20
Cruise Control* . . . . . . . . . . . . . . . . . . . . . . 23
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . .28
ECO Mode (Active ECO) . . . . . . . . . . . . . . . . . 08
Passenger Airbag Off Indicator. . . . . . . . . . . . . . 46
Service Mode. . . . . . . . . . . . . . . . . . . . . . . 07
Smart Cruise Control (SCC) with Stop & Go* . . . . . . . 22
Smart Key . . . . . . . . . . . . . . . . . . . . . . . . 37
Tire Pressure Monitoring System (TPMS) . . . . . . . . 05
Trip Modes / Trip Computer . . . . . . . . . . . . . . . 06
User Settings . . . . . . . . . . . . . . . . . . . . . . . 07
Windshield Wipers & Washers . . . . . . . . . . . . . .19
Driving while distracted can result in a loss of vehicle control
that may lead to an accident, severe personal injury and death.
The driver’s primary responsibility is in the safe and legal
operation of a vehicle, and use of any handheld devices, other
equipment or vehicle systems which take the driver’s eyes,
attention and focus away from the safe operation of a vehicle
or that are not permissible by law should never be used during
operation of the vehicle.
LEGAL DISCLAIMERS . . . . . . . . Inside Back Cover
MAINTENANCE CHART . . . . . . . . . . Back Cover
VIDEOS & QR CODES . . . . . . . . . . . . . . . . 02
INSTRUMENT CLUSTER
Instrument Cluster Overview . . . . . . . . . . . . . . . . 03
Indicators & Warning Lights . . . . . . . . . . . . . . . . 04
Tire Pressure Monitoring System (TPMS) . . . . . . . . . 05
Fuel Economy. . . . . . . . . . . . . . . . . . . . . . . . 05
LCD Instrument Cluster Modes . . . . . . . . . . . . . . 06
Trip Modes / Trip Computer. . . . . . . . . . . . . . . . . 06
User Settings / Service Mode. . . . . . . . . . . . . . . . 07
Drive Mode Integrated Control System* . . . . . . . . . . 08
ECO Mode (Active ECO). . . . . . . . . . . . . . . . . . . 08
DRIVER’S PANEL
Head-Up Display (HUD)* . . . . . . . . . . . . . . . . . . 09
Electronic Stability Control (ESC) . . . . . . . . . . . . . . 10
Hill-Start Assist Control (HAC) . . . . . . . . . . . . . . . 10
Blind-Spot Collision-Avoidance Assist-Rear (BCA-R)* . . . 10
Blind-Spot Collision Warning (BCW) w/ RCCW* . . . . . . 11
Lane Keeping Assist (LKA)* . . . . . . . . . . . . . . . . 12
Forward Collision-Avoidance Assist (FCA) /
Forward Collision Warning (FCW) . . . . . . . . . . . . 13
Power Windows, Window Lock & Central Door Lock . . . . 13
Power Folding Outside Mirrors* . . . . . . . . . . . . . . 14
Power/Heated Outside Mirrors . . . . . . . . . . . . . . . 14
Automatic Door Lock/Unlock . . . . . . . . . . . . . . . . 14
Fuel Door Release Button . . . . . . . . . . . . . . . . . 14
Reverse Parking Aid Function* . . . . . . . . . . . . . . . 14
Trunk Release Button. . . . . . . . . . . . . . . . . . . . 15
Instrument Panel Dimmer . . . . . . . . . . . . . . . . . 15
Engine Start/Stop Button. . . . . . . . . . . . . . . . . . 15
STEERING WHEEL CONTROLS
Manual Tilt/Telescoping Steering Wheel* . . . . . . . . . 16
Power Tilt/Telescoping Steering Wheel* . . . . . . . . . . 16
Headlights & High Beams. . . . . . . . . . . . . . . . . . 17
Turn Signals & Fog Lights . . . . . . . . . . . . . . . . . 18
Windshield Wipers & Washers . . . . . . . . . . . . . . . 19
Bluetooth®Wireless Technology . . . . . . . . . . . . . . 20
Smart Cruise Control (SCC) with Stop & Go . . . . . . . . 22
Audio Controls . . . . . . . . . . . . . . . . . . . . . . . 23
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . 23
AUDIO SYSTEMS
UVO eServices Activation. . . . . . . . . . . . . . . . . . 24
Android Auto™/ Apple CarPlay®Setup* . . . . . . . . . . 24
UVO eServices*. . . . . . . . . . . . . . . . . . . . . . . 25
UVO eServices with Premium Navigation* . . . . . . . . . 26
CENTER PANEL
Surround View Monitoring (SVM) System* . . . . . . . . . 27
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Aux/USB/iPod®Port & Power Outlets . . . . . . . . . . . 28
Automatic Climate Control . . . . . . . . . . . . . . . . . 29
Automatic Gear Shift / Sportmatic®Shifting . . . . . . . . 30
Paddle Shifters* . . . . . . . . . . . . . . . . . . . . . . 30
Electric Parking Brake (EPB)* . . . . . . . . . . . . . . . 31
Auto Hold* . . . . . . . . . . . . . . . . . . . . . . . . . 31
Wireless Smartphone Charging System* . . . . . . . . . . 32
Heated Steering Wheel* . . . . . . . . . . . . . . . . . . 33
Power Rear Sunshade* . . . . . . . . . . . . . . . . . . . 33
Seat Warmers / Ventilated Seats* . . . . . . . . . . . . . 34
SEATING
Power Adjustable Driver’s Seat. . . . . . . . . . . . . . . 35
Front Seat Headrest Adjustment . . . . . . . . . . . . . . 36
Driver Position Memory System* . . . . . . . . . . . . . . 36
OTHER KEY FEATURES
Smart Key . . . . . . . . . . . . . . . . . . . . . . . . . 37
HomeLink®with Auto-Dimming Rearview Mirror* . . . . . 38
Map/Room Lamps . . . . . . . . . . . . . . . . . . . . . 39
Panoramic Sunroof Operation* . . . . . . . . . . . . . . . 40
Sunvisor . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Rear-Camera Display . . . . . . . . . . . . . . . . . . . . 41
Parking Distance Warning-Reverse* . . . . . . . . . . . . 41
Power Trunk / Smart Power Trunk*. . . . . . . . . . . . . 42
Trunk Release Button. . . . . . . . . . . . . . . . . . . . 43
Fuel Cap / Malfunction Indicator (Check Engine Light) . . . 43
Child-Protector Rear Door Locks . . . . . . . . . . . . . . 43
Hood Release Lever and Latch . . . . . . . . . . . . . . . 44
Driver Attention Warning (DAW)* . . . . . . . . . . . . . . 45
SAFETY FEATURES
Occupant Detection System (ODS) /
Passenger Airbag Off Indicator . . . . . . . . . . . . . . 46
Seat Belts. . . . . . . . . . . . . . . . . . . . . . . . . . 47
Seat Belt Retractor Locks . . . . . . . . . . . . . . . . . 47
*IF EQUIPPED

CADENZA FEATURES & FUNCTIONS GUIDE
2*IF EQUIPPED
VIDEOS & QR CODES - SMARTPHONES, TABLETS AND COMPUTERS
One-Click Fuel Cap Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
www.youtube.com/KiaFeatureVideos
QR CODE
Kia provides a number of video resources to assist you with becoming familiar with the features and functions found in your Kia
vehicle. You can access these resources by snapping the QR Codes with your smartphone/tablet (mobile devices) or by visiting
the following website: www.youtube.com/KiaFeatureVideos. Continue reading for a more in-depth look at QR Codes and for
instructions on how to use them.
What are QR Codes?
A QR Code is a square, 2-dimensional barcode that can be
read by mobile devices loaded with an appropriate barcode
or QR Code Reader App. The app reads the barcode image
and then launches/uploads the specific information the
code contains, such as URLs, text, photos, videos and so
much more.
How to Use QR Codes
If you have a mobile device with a QR Code Reader App, you
can snap the code with your phone and you’ll be provided a
video with additional information pertaining to the topic. For
example, in the Fuel Cap section, if you would like additional
information, just snap the code with your mobile device to
view the selected Kia Features & Functions Video.
How to snap a QR Code
1. With your mobile device, download a QR Code Reader
App. With many devices, you can do this through an app
store or marketplace
2. Open the QR Code Reader App on your mobile device
3. The app will utilize your device’s camera. Center the code
in the camera viewing area:
• With some apps, as soon as the app recognizes the
code, it will launch the corresponding video
• With other apps, you will have to snap or take a
picture of the code. The app will then launch the
corresponding video
• For operation specifics, refer to the instructions
that come with the QR Code Reader App
1. If you’re having trouble scanning codes, check the following:
•The code should be centered and focused in your mobile device’s camera screen
•Consider moving your device closer to or farther away from the code
•The code should be well lit, without significant shadow
2. After scanning, if a “connecting” message appears and then nothing happens or there’s a “connection error” message, this typically indicates that your device is having trouble
connecting to the Internet
3. When accessing videos on your mobile device, standard cellular data rates will apply
QUICK TIPS
•Avoid scanning from a significant angle
•Confirm that the device’s app supports 2D QR Code scanning.
•Try another QR Code Reader App; not all apps are created equal
REMINDER: When accessing videos
on your mobile device, standard
cellular data rates may apply.

3
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
[A] Tachometer
[B] Turn Signal Indicators
[C] Speedometer
[D] Engine Temperature Gauge
[E] Indicators and Warning Lights
[F] Gear Shift Position Indicator
[G] Odometer/Trip Computer/Tripmeter
[H] Fuel Gauge EPB
AUTO
0
1
C E FH
2
34
x1000 rpm 5
6
7
80
0
20
40
60
80 180
200
220
240
260
100 120
km/h
MPH
140 160
20
40
60 80 100
120
140
160
(Type A Cluster)
AC
B
B
F
D
E
H
G
A
B
C
D
E
F
G
H
Your vehicle’s instrument cluster & indicator
light locations may differ from those in the
illustrations. For more information on the
instrument cluster, the LCD Warning Messages
and the function of all indicator and warning
lights, please refer to the Owner’s Manual.
This illustration is for demonstration purposes
only. Some indicators and warning lights may not
appear in illustration. On the vehicle, they may
appear in the LCD.
Instrument Cluster Overview
INSTRUMENT CLUSTER

CADENZA FEATURES & FUNCTIONS GUIDE
4*IF EQUIPPED
ECO Mode Indicator*
SPORT Mode Indicator*
SMART Mode Indicator*
High Beam Assist Indicator*
High Beam Indicator
Light ON Indicator
Master Warning Indicator*
Forward Collision-Avoidance Assist (FCA) Indicator*
Engine Oil Pressure Warning Indicator
Charging System Warning Indicator
Seat Belt Warning Indicator
Malfunction Indicator
Low Tire Pressure Indicator / Tire Pressure Monitoring
System (TPMS) Malfunction Indicator
Electronic Stability Control (ESC) Indicator
Electronic Stability Control (ESC) OFF Indicator
Parking Brake & Brake Fluid Warning Indicator
Electronic Power Steering (EPS) Warning Indicator
Airbag Warning Indicator
Anti-Lock Braking System (ABS) Warning Indicator
Electric Parking Brake (EPB) Warning Indicator*
Electronic Brakeforce Distribution (EBD) System
Warning Indicator (Two separate indicators on
Instrument Cluster lit at same time)
Adaptive Front Lighting System Warning Indicator*
Lane Keeping Assist (LKA) Indicator*
Smart Cruise Control (SCC) with Stop & Go Radar
Warning*
Smart Cruise Control (SCC) with Stop & Go Warning
Indicator*
Front Fog Light Indicator*
Door Ajar Warning Indicator
Trunk Open Warning Indicator
Immobilizer Indicator*
Auto Hold Indicator*
CRUISE Cruise Indicator*
Cruise SET Indicator
Low Fuel Level Warning
Icy Road Warning*
LED Headlamp Warning*
Your vehicle’s instrument cluster & indicator
light locations may differ from those in the
illustrations. For more information on the
instrument cluster, the LCD Warning Messages
and the function of all indicator and warning
lights, please refer to the Owner’s Manual.
0
1
C E FH
2
34
x1000 rpm 5
6
7
80
0
20
40
60
80 180
200
220
240
260
100 120
km/h
MPH
140 160
20
40
60 80 100
120
140
160
(Type B Cluster)
Indicators and Warning Lights
This illustration is for demonstration purposes
only. Some indicators and warning lights may not
appear in illustration. On the vehicle, they may
appear in the LCD.
INSTRUMENT CLUSTER

5
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
To view these videos on
your mobile device, snap
these QR Codes or visit the
listed websites.
Refer to page 2 for more
information.
Tire Pressure Monitoring
System Video
Fuel Economy Video
QR CODES
www.youtube.com/KiaFeatureVideos
www.youtube.com/KiaFeatureVideos
Tire Pressure Monitoring System (TPMS)*†27
The TPMS indicator functions as both Low Tire Pressure Light
and TPMS Malfunction Indicator.
The indicator is designed to illuminate if it detects one or more
tires is significantly underinflated, the vehicle has a spare tire installed
without TPMS or the outside temperature becomes significantly lower.
The Low Tire Pressure Position Indicator Ais displayed on the LCD
screen in the Instrument Cluster when the tire(s) are underinflated.
Inflate tire(s) to specifications using an accurate digital tire pressure
gauge to turn off Low Tire Pressure Light A. See front driver’s door
jamb for PSI specification.
When there is a problem
with the TPMS, the TPMS
Malfunction Indicator will
blink for approximately one
minute then illuminate.
See dealer for service.
•Even with TPMS, tire pressure should be checked
manually at least once a month. Only adjust tire
pressure on “cold tires”
•For proper maintenance and optimal fuel
economy, maintain recommended tire inflation
pressures and stay within the load limits and
weight distribution recommended for your vehicle
•In winter or cold weather, the TPMS light may
illuminate if the tire pressure was adjusted to
the recommended tire inflation pressure during
warm weather
QUICK TIPS
REMINDERS:
• Check the recommended tire pressure label located on the
left side of driver's door jam, visible when the door is open.
• Consult your dealer for service if Low Tire Pressure Light
remains illuminated after inflating your tire(s).
Fuel Economy
There are several factors that contribute to your vehicle’s fuel economy, including maintenance of your vehicle, driving style,
environmental conditions, vehicle weight and vehicle aerodynamics. Below are tips on how to help improve fuel economy:
• Keep your vehicle in good condition with
regular maintenance
• Don’t let the engine idle longer than necessary
• Drive at a moderate speed, accelerating smoothly
and at a moderate rate
• Keep tires inflated to the recommended pressure
• Travel lightly, without carrying unnecessary weight
in your vehicles
• Avoid placing large or heavy items on roof racks
• Avoid hilly, winding or poorly maintained roads
For more information on Fuel Economy, you can snap the QR Code above to view a video or refer to the Owner's Manual.
25
32
32
32
A
INSTRUMENT CLUSTER

CADENZA FEATURES & FUNCTIONS GUIDE
6*IF EQUIPPED
1754 mi
16.8 MPG
Average
0 10
Hold
OK : Reset
20 30
Instant 18.4 MPG
A
B
C
(Type A; Controls located on Steering Wheel)
Drive Info
• Tripmeter B
• Fuel Economy
• Timer
Accumulated Info
• Tripmeter A
• Fuel Economy
• Timer
TRIP
• Average Fuel Economy
• Instant Fuel Economy
Smart Shift
Digital Speedometer
LCD Instrument Cluster Modes*
Press Mode button Ato scroll through different LCD Instrument
Cluster Modes:
Trip Computer Mode: Displays driving information
for tripmeter, fuel economy, etc.
Turn-by-Turn Mode*: Displays the state of the
navigation system
Smart Cruise Control (SCC) w/ Stop and Go /
Lane Keeping Assist (LKA)*: Displays the state
of the SCC and LKA
User Settings Mode: Change settings of the doors,
lamps and other features
Master Warning Mode: Informs of warning
messages related to washer fluid or malfunction of
Blind-Spot Collision Warning (BCW), etc.
Your vehicle’s steering wheel buttons may differ from those in the illustrations.
Driving while distracted is dangerous and should be avoided. Drivers should
remain attentive to driving and always exercise caution when using the
steering wheel mounted controls while driving.
Trip Modes / Trip Computer
The Trip Computer is a driver information
system that displays information related
to driving on the display when the Engine
Start/Stop button is in the ON position.
To cycle through the LCD Instrument
Cluster modes, press the Mode button A.
When in the Trip Computer mode ,
press the Select/Reset button Bup/
down to cycle to the desired menu. When
displaying the Tripmeter screen, press and
hold the Select/Reset button Bto reset
the Tripmeter to zero. Press the Return
button Cto go back to the previous
mode/item (button only available with
Type A cluster).
REMINDERS:
•Appearance of Trip Computer display may differ
as equipped
•All stored driving information (except Odometer
and Range) is reset if the battery is disconnected
INSTRUMENT CLUSTER

7
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
To view these videos on
your mobile device, snap
these QR Codes or visit the
listed websites.
Refer to page 2 for more
information.
LCD Display Video
LCD Display:
Maintenance Video
QR CODES
www.youtube.com/KiaFeatureVideos
www.youtube.com/KiaFeatureVideos
User Settings
To enter the User Settings mode
in the LCD Instrument Cluster
Modes, press the Mode button A
when the vehicle is at a standstill
and with the Engine Start/Stop
button in the ON position and
select User Settings .
You can navigate the selections on the display by pressing the Select/
Reset button Bup or down, and then pressing again to enter.
A
B
(Type A; Buttons located on right side of
steering wheel)
C
Head-Up Display*:
• Display Height
• Rotation
• Brightness
• Contents Select
• Speedometer Size
• Speedometer Color
Sound:
• Park Assist System Volume*
• Cluster Voice Guide Volume*
• Welcome Sound*
Door:
• Two Press Unlock
• Auto Door Lock & Unlock
• Door Lock Sound*
• Smart Power Trunk*
Lights:
• One-Touch Turn Signal
• Headlamp Escort*
• Welcome Light*
Driving Assist:
• Smart Cruise Control Response*
• Forward Collision-Avoidance Assist
(FCA)*
• FCW (Forward Collision Warning)*
• Lane Keeping Assist (LKA)*
• Rear Cross-Traffic Collision
Warning (RCCW)*
• Blind-Spot Collision Warning
(BCW)*
Convenience:
• Seat Easy Access*
• Steering Easy Access*
• Wireless Smart Phone
Charging System*
• Wiper/Light Display*
• Gear Position Popup*
Service Interval:
• Service Interval
• Adjust Interval
• Reset
Service Mode
To enter Service Mode, press the Mode button A,
scroll to Service Interval by pressing Select/Reset
button Bup or down. Then press the OK button B
to enter. System will display number of miles
remaining until next service is due, and type
of service.
When service is required, the following will be
displayed: Service required.
To reset the Service Mode system, press and hold
the OK button Bfor more than 1 second.
To turn Service In OFF, go to User Settings.
Service Interval Setting
To set the service interval when in User Settings
mode:
• Press the Select/Reset button Bup/down and
scroll to Service Interval. Press again to enter
• Press the Select/Reset button Band toggle to
ON, then press again to set. Then press the
Select/Reset button Bto scroll and select the
desired miles or months for your next service
• Press the OK button Bto enter
Service in
-20 mi -5day
Service required
Service in
-20 mi -5day
Service required
INSTRUMENT CLUSTER

CADENZA FEATURES & FUNCTIONS GUIDE
8*IF EQUIPPED
Drive Mode Integrated
Control System Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to page 2 for more
information.
QR CODE
www.youtube.com/KiaFeatureVideos
Comfort
ECO SMART
Sport
DRIVE
MODE
AUTO
HOLD
DRIVE MODE
SMART
ECO
(Button located below Gear Shift)
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION
AND SAFETY WARNINGS.
For more information on ECO Mode, refer to your Owner’s Manual or contact your local dealership.
When the Engine Start/Stop button is
turned off, the system will default to
COMFORT mode if the vehicle was last
in Sport mode.
To help improve your fuel economy:
•Drive at a moderate speed,
accelerating smoothly and at a
moderate rate
•Keep tires inflated to the recommended
pressure
•Be sure the wheels are properly
aligned
QUICK TIPS
SMART, COMFORT, SPORT and ECO drive modes Amay be changed
according the driver’s preference or road conditions. To cycle through
drive modes, press the DRIVE MODE button B.
COMFORT Mode – The system’s default mode is COMFORT mode and may
not display on the instrument cluster nor the audio system’s screen.
ECO Mode – An ECO indicator will illuminate on the instrument cluster. To
deactivate, press the DRIVE MODE button Bagain to change the selection
to another setting.
SPORT Mode – A SPORT indicator will illuminate on the instrument cluster.
To deactivate, press the DRIVE MODE button Bagain to change the
selection to another setting.
SMART Mode* – When SMART mode is activated, the system automatically
selects the drive mode best suited to the current driving style (economic,
average, spirited). A SMART indicator will illuminate on the instrument cluster.
The color of the SMART indicator (blue, white, orange) depends on the current
driving style. To deactivate, press the DRIVE MODE button Bagain to change
the selection to another setting.
ECO Mode (Active ECO)*
The Active ECO system is designed to
improve fuel economy by controlling several
vehicle components. When activated, it
modifies drivetrain operations such as engine
power and transmission.
To turn ON, press the DRIVE MODE button
Band scroll through options until in the ECO
mode. The ECO mode indicator light in the
LCD cluster will illuminate, indicating that
the vehicle is in ECO mode and Active ECO is
operating. The Active ECO system will remain
on even when the ignition is cycled.
To turn the Active ECO system OFF, press the
DRIVE MODE button Bagain and change to
another mode.
Drive Mode Integrated Control System
REMINDERS:
•When ECO mode is selected,
the following may occur to help
improve fuel economy:
– Acceleration may be slightly
reduced even when the
accelerator is fully depressed
– Air conditioner performance
may be limited
– Shift pattern of the automatic
transmission may change
– Engine noise may increase
– System’s power will be limited
when driving uphill
•Steering effort may be slightly
increased in Sport mode
•When SPORT mode is selected,
fuel economy may decrease
A
B
C
INSTRUMENT CLUSTER

9
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
Head-Up Display (HUD)*†12
The Head-Up Display (HUD) is a transparent display that projects a snippet of information
from the instrument cluster and navigation system onto the windshield glass.
Drivers can turn the HUD display on or off in User Settings.
The HUD displays:
• Turn By Turn (TBT) navigation information
• Road signs*
• Speedometer
• Cruise setting speed
• Smart Cruise Control (SCC) with Stop & Go information*
• Blind-Spot Collision Warning (BCW) information*
• Warning lights (low fuel, BCW)
• AV Mode information
Head-Up Display (HUD) Display Settings
Drivers can adjust the HUD settings from the LCD Instrument Cluster modes in
User Settings. HUD settings include:
• Display Height: Adjust the height of the HUD image on the windshield glass
• Rotation: Adjust the degree of HUD rotation
• Brightness: Adjust the intensity of the HUD brightness
• Contents Select: Activate or deactivate HUD content (TBT, SCC, LDW, BCW)
• Speedometer Size: Choose the size of the HUD speedometer (Small, Medium, Large)
• Speedometer Color: Choose the color of the HUD speedometer (White, Orange, Green)
REMINDERS:
The HUD image on the windshield glass may not be visible when:
•The driver has poor sitting posture
•The driver is wearing polarized sunglasses
•There is an object covering the HUD
•Driving on a wet road
•Excessive lighting inside or outside the vehicle
•Modifications made to the windshield, such as tinting or other
aftermarket treatments, could affect the HUD. When replacing
the front windshield glass of vehicles equipped with the HUD,
owners must replace it with windshield glass designed for HUD
operation. Otherwise, duplicated images may be displayed on the
windshield glass.
•If Turn By Turn (TBT) navigation information is selected as HUD
content, TBT information will not be displayed on the LCD.
The Head-Up Display is a supplemental system. Do not solely rely
on the system, always drive safely, and pay attention to the driving
conditions on the road.
65
65
mi/h
0
1
C E FH
2
34
x1000 rpm 5
6
7
80
0
20
40
60
80 180
200
220
240
260
100 120
km/h
MPH
140 160
20
40
60 80 100
120
140
160
ECO
SPORT
DRIVER'S PANEL

CADENZA FEATURES & FUNCTIONS GUIDE
10 *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
(Button panel located left of Steering Wheel)
A
Electronic Stability Control (ESC)*†7
The ESC system is designed to help stabilize the vehicle
during certain cornering maneuvers. It is a good idea to
keep the ESC turned on for daily driving whenever possible.
Press ESC button Ato disable Traction Control in ESC
(ESC OFF indicator will illuminate).
To turn OFF both the Traction Control and Stability
Control, press and hold for more than 3 seconds.
Press again to turn ON.
REMINDERS:
•ESC is active by default at vehicle start-up. When ignition is
cycled, ESC will turn ON again
•The ESC Indicator Light in the instrument cluster will
illuminate whenever the ESC is in operation
For more information on Electronic Stability Control (ESC)
and its specific features and operations, please refer to your
Owner’s Manual.
Hill-Start Assist Control (HAC)*†7
HAC is designed to prevent the vehicle from rolling backwards when accelerating from a stop
while on a steep incline. The HAC automatically activates whether the ESC is OFF or ON but
does NOT activate when the ESC has malfunctioned.
REMINDER: The HAC does not operate when the gear shift is in the P (Park) or the N (Neutral) position. HAC does not
replace the need to apply brakes while stopped on an incline.
When HAC is active (e.g., during initial acceleration from a stop on an incline), you may notice that the
brakes will momentarily remain engaged after you depress the accelerator.
QUICK TIP
Blind-Spot Collision-Avoidance Assist-Rear (BCA-R)*†6
The Blind-Spot Collision-Avoidance Assist-Rear (BCA-R) uses a camera on the upper
front windshield and radar sensors for the side and rear areas. The BCA-R may activate
the ESC light when detecting an approaching vehicle while changing lanes to help prevent
a possible collision.
The BCA-R is activated when BCA-R is in ON position and with the following conditions:
• Vehicle speed is above approximately 40 mph and both lanes are detected
• The system detects both of the lane lines
• An approaching vehicle is detected next to and/or behind the vehicle
When an approaching vehicle is detected within sensor areas next to or behind the vehicle,
the BCA-R may apply the brakes to help keep you within the lane markers. The ESC
instrument cluster indicator will illuminate to inform the driver of the system activation.
The Blind-Spot Collision-Avoidance Assist-Rear (BCA-R)* may apply braking power, when an
approaching vehicle is detected within a certain distance next to/behind your vehicle.
REMINDER: The BCA-R system are supplemental systems.
Do not solely rely on these systems and always pay
attention to drive safely.
For more information on when the BCA-R automatically
deactivates, see your Owner’s Manual.
DRIVER'S PANEL

11
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
Blind-Spot Collision
Warning w/ RCCW Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to page 2 for more
information.
QR CODE
www.youtube.com/KiaFeatureVideos
B
C
A
Blind-Spot Collision Warning (BCW) w/RCCW*†6
The BCW System uses radar sensors in the rear bumper to monitor and warn
the driver if it detects an approaching vehicle in the driver's blind spot area. It is
designed to help alert the driver before changing lanes. The BCW System is ON
when the button Ais pressed – the button light will illuminate. The outside
rearview mirror warning lights will also illuminate for 3 seconds.
The system will become active when the vehicle is traveling more than approximately
18 mph and will alert the driver if another vehicle is detected by the radar sensor.
1st-stage alert: When another vehicle is detected within the BCW system
boundary B, a yellow indicator will illuminate on the outside rearview mirrors.
2nd-stage alert: When 1st-stage alert is on and the driver activates a turn signal,
a flashing yellow indicator will illuminate on the outside rearview mirrors and the
system will sound an alert.
Rear Cross-Traffic Collision Warning (RCCW)*
If the RCCW system sensors detect approaching vehicles from the left or right
side C, the system will sound an audible alert, the warning indicators on the
outside rearview mirror will illuminate and a message will appear on the LCD
screen, when these conditions are met:
• When the gear shift is in moved into (R) Reverse
• When the vehicle is moving less than 6 mph
(Llocated left of Steering Wheel)
REMINDERS:
•When the BCW system is ON and the ignition is cycled to OFF then ON again, the BCW system returns to ON
•The RCCW feature can be turned OFF/ON in User Settings and will remain in OFF/ON as selected
•When vehicle power is cycled, the RCCW will remain in the previous state
•The RCCW system will show a warning if the approaching vehicle speed is between 2.5-22 mph within sensing
range. See owner's manual for other conditions.
•The BCW and RCCW systems are supplemental systems. Do not solely rely on these systems and always pay
attention to drive safely
For more information on the Blind-Spot Collision Warning (BCW), please refer to the Owner’s Manual.
DRIVER'S PANEL

CADENZA FEATURES & FUNCTIONS GUIDE
12 *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
Lane Keeping Assist (LKA)*†6
With the Engine Start/Stop button
in the ON position, press the LKA
button Gto turn system ON. The
instrument cluster indicator
will initially illuminate white. It
will remain white when vehicle is
traveling less than 40 mph and the
system does not detect the lane
markers. When system detects the lane markers and can assist the
steering, the LKA icon will illuminate green.
If the LKA detects that you are moving outside of your lane, the system
may give an audible warning and display a LDW (Lane Departure
Warning) alert on the instrument cluster. If the vehicle continues to
move outside of the lane, the LKA will apply a slight adjustment to the
steering, trying to prevent the vehicle from moving outside its lane.
Standard LKA is the operating mode by default when the button
is depressed to ON. To switch between modes (Standard LKA, Active
LKA and Lane Departure), go to User Settings in the Instrument Cluster.
All systems will operate under the following conditions:
•The vehicle exceeds approximately 37 mph
•The LKA system recognizes both lane
markers the vehicle is traveling in
•The vehicle is between the lane markers
When the LKA sensor does not
detect the lane traveling in the
lanes are not illuminated
When the LKA sensor detects the vehicle moving outside of the lane
traveling in, a yellow indicator will illuminate either on the left or right
lane (shown in both images above)
Lane Keeping Assist
Lane Keeping Assist
Lane Keeping AssistLane Keeping Assist
Lane Keeping AssistLane Keeping Assist
Lane Keeping Assist
Lane Keeping Assist
Lane Keeping Assist
Lane Keeping Assist
Lane Keeping AssistLane Keeping Assist
Lane Keeping AssistLane Keeping Assist
Lane Keeping Assist
Lane Keeping Assist
When the LKA sensor detects
the lane traveling in, both lanes
are illuminated
REMINDERS:
•LKA will not issue a warning if the turn signal or hazard
signal is activated
•If the LKA button is ON and ignition is cycled, the
system will turn ON again. If the LKA button is OFF, the
system remains OFF
•The LKA/LDW are not substitutes for safe and proper
driving. Always drive safely and use caution.
•LKA/LDW may not always alert the driver if the vehicle
about to be driven outside of its lane. Refer to the
Owner’s Manual for more information.
Lane Keeping Assist
(LKA) Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website. Refer to page 2 for
more information.
QR CODE
www.youtube.com/KiaFeatureVideos
(Button panel located left of Steering Wheel)
G
DRIVER'S PANEL

13
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
Forward Collision-Avoidance Assist (FCA) / Forward Collision Warning (FCW)†9
The FCA is designed to alert the driver, and if necessary apply emergency braking, when rapidly approaching a vehicle that is
slowing down, braking or stopped.
Initially, the Forward Collision Warning (FCW) will provide a warning when it detects a potential collision with a vehicle in front
emitting an audible warning and visual alert on the instrument cluster. Adjust the alert settings (Early, Normal, Late) in the User
Settings. To turn the FCA/FCW off, go to User Settings again and turn off.
If the collision risk increases, the Forward Collision-Avoidance Assist (FCA) automatically applies the brakes to reduce your
speed, helping to minimize the effects of a possible collision.
FCA can be turned ON in the User Settings menu on the Instrument Cluster display. The FCA/FCW will become active when the:
• Engine Start/Stop button is ON • Vehicle is traveling more than 5 mph • Electronic Stability Control (ESC) is ON
Adjust the alert settings (Early, Normal, Late) in the User Settings. To turn the
FCA/FCW off, go to User Settings again and turn off.
REMINDERS:
• The FCA/FCW will be activated by default when the ignition is cycled ON, even when
previous setting to OFF
• The FCA/FCW will not operate when the vehicle is traveling more than approximately 50 mph
The Forward Collision-Avoidance Assist (FCA)* / Forward Collision Warning System (FCWS) are not substitutes for safe and proper driving. Always drive safely and
use caution. FCA and FCW may not always alert the driver when the vehicle is approaching another vehicle.
Power Windows, Window Lock & Central Door Lock
APull/Press to operate Driver’s & Passenger's Window Auto Up/Down*
BPress to Unlock/Lock All Doors
CPress to disable Rear Passenger Windows and Rear Sunroof
passenger controls
REMINDER: When pressed C, window controls for the Rear Passenger Windows are disabled.
Press button again to stop Auto Up/Down function.
QUICK TIP
(Button/switch panel located on Driver's Door )
A
BC
Forward Collision
Warning Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to page 2 for more
information.
QR CODE
www.youtube.com/KiaFeatureVideos
Button configuration
may vary depending on
vehicle model.
DRIVER'S PANEL

CADENZA FEATURES & FUNCTIONS GUIDE
14 *IF EQUIPPED
Power/Heated Outside Mirrors*
Mirror heaters automatically turn ON/OFF at the same time the Rear Window Defroster is
turned ON/OFF. Rear Window Defroster button* is located on climate control system panel.
Automatic Door Lock/Unlock
When the gear shift is moved into or out of P (PARK), all doors will Lock/Unlock. Refer to the
User Settings in the LCD Instrument Cluster modes on how to turn Auto Door Lock/Unlock
ON/OFF.
Fuel Door Release Button
Press the Fuel Door Release button D
to release the fuel door.
(Buttons panel located on Driver's Door )
E
F
Reverse Parking Aid Function*
When the gear shift lever is moved into R (Reverse)
and with the L or R mirror buttons depressed, the
outside rearview mirrors Ewill rotate downward to
aid in reverse parking.
To turn ON the Reverse Parking Aid Function, depress
either L or R mirror buttons F.
To turn OFF, depress the same buttons again.
The outside rearview mirrors will automatically return
to their original positions when:
• The Engine Start/Stop button is in the OFF position
• The gear shift lever is moved to any position except R
(Reverse)
• The L or R mirror buttons are not depressed.
REMINDER: When the outside rearview mirror buttons are not depressed,
the Reverse Parking Aid Function will not operate and the outside rearview
mirrors will not rotate downward.
Power Folding Outside Mirrors*
Press the L or R buttons Ato select the mirror to adjust.
Press button arrows Bleft/right or up/down to adjust
mirror position.
Toggle button Cleft/right to unfold/fold the outside
rearview mirrors.
•The Smart Key Lock/Unlock buttons are pressed
•The door outside handle button is pressed
•Driver approaches the vehicle with the Smart Key*
REMINDER: When mirror button Cis in the center, press the
Lock button on the Smart Key to automatically fold the mirrors
The mirrors will automatically unfold
when the Smart Key* is within close
proximity to the vehicle.
QUICK TIP
(Button/switch panel located on Driver's Door )
A
A
B
C
(Button located left of Steering Wheel)
D
Button configuration may vary
depending on vehicle model.
DRIVER'S PANEL

15
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
Engine Start/Stop Button
& Smart Key Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to page 2 for more
information.
QR CODE
www.youtube.com/KiaFeatureVideos
(Button panel
located left of
Steering Wheel)
(Button panel
located left of
Steering Wheel)
E
C
REMINDERS:
•In an emergency situation while
the vehicle is in motion, you are
able to turn the engine off and to
the ACC position by pressing the
ENGINE START/STOP button for
more than 2 seconds or 3 times
successively within 3 seconds
•If Smart Key fob battery is dead,
with the lock button facing the
ENGINE START/STOP button,
hold the fob up against the
ENGINE START/STOP button
and press
Instrument Panel Dimmer
With parking lights/headlights ON, press button E(+) or (-)
to adjust the brightness of the instrument panel illumination.
REMINDER: Dimmer does not change brightness when lights are turned off.
Trunk Release Button
Press the Cbutton to open the trunk.
Engine Start/Stop Button*†8
To start the engine:
1. Depress the brake pedal
2. Press the ENGINE START/STOP button while in
(P) Park or (N) Neutral
To turn the engine OFF, press the ENGINE START/
STOP button.
To use the ENGINE
START/STOP button,
you must have the
Smart Key fob on
your person.
To use electrical accessories:
ACC position
•When in the OFF position and without depressing
the brake pedal, press the ENGINE START/STOP
button once (amber light)
ON position
•When already in the ACC position (amber light)
and without depressing the brake pedal, press
the ENGINE START/STOP button again (red light)
•When in the OFF position and without depressing
the brake pedal, press the ENGINE START/STOP
button twice (red light)
Keeping the vehicle in ACC or the ON position for
extended periods of time without turning engine on
may discharge the vehicle’s battery.
QUICK TIPS
ENGINE
START
STOP
DRIVER'S PANEL

CADENZA FEATURES & FUNCTIONS GUIDE
16 *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
A
C
BD
F
E
Manual Tilt/Telescoping Steering Wheel*†26
To adjust the Steering Wheel, press the Lock-Release Lever Adown and
adjust the desired angle Band then distance C.
When finished, pull the Lock-Release Lever Aup to lock Steering Wheel
in place.
Power Tilt/Telescoping Steering Wheel*†26
To adjust the Steering Wheel angle D, move the switch Eup or down.
To adjust the Steering Wheel distance F, move the switch Eforward
or backward.
It may be helpful to pull/push bottom of Steering Wheel towards/away from you to
adjust desired distance.
QUICK TIP
STEERING WHEEL CONTROLS

17
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
Headlight position
Parking light position
AUTO Auto Light / AFS-R /
High Beam Assist*
OFF OFF position
REMINDERS:
• HBA will operate when vehicle speed exceeds 25 mph
• If the lever is pushed away from you while HBA is operational, HBA will
turn off and the high beams will be on continuously. If the lever is pulled
toward you while HBA is operational, HBA will turn off
• If the light switch is switched to the headlight position, HBA will turn off
low beams will be on continuously
Headlights & High Beams
To operate:
• Rotate switch to change the Headlight function
• Push lever to turn High Beams ON
• Pull lever to flash Headlights/High Beams
AUTO Light position — When the light switch
is in the AUTO Light position, the tail lights and
headlights will turn ON/OFF automatically depending
on the amount of light outside the vehicle.
Adaptive Front-Lighting System-Height (AFS-H)*
The Adaptive Front-Lighting System-Height (AFS-H) can help improve
visibility during nighttime driving by aiming the low beam headlights toward
the direction the vehicle is moving. AFS-H controls the aiming direction
based on steering angle and speed.
When the light switch is in the AUTO Light position, the AFS-H will activate.
REMINDER: When the AFS-H indicator illuminates on the Instrument Cluster, the AFS-H is not
working properly. See authorized Kia dealer for service.
High Beam Assist (HBA)*
High Beam Assist is designed to automatically adjust the headlight range by
switching between high and low beams based on light from other vehicles
and road conditions.
To enable HBA, toggle the light switch to the AUTO Light position and turn on
the high beams by pushing the lever away from you. The High Beam Assist
indicator will illuminate.
STEERING WHEEL CONTROLS

CADENZA FEATURES & FUNCTIONS GUIDE
18 *IF EQUIPPED
A
One-Touch
Lane Change
Signal
Turn Signals & Fog Lights
To operate:
• Turn Signals - Move lever Up/Down for Right/Left Turn Signal
• Fog Lights - Push toggle switch Ato turn Fog Lights ON/OFF
REMINDER: Headlights must be ON for Fog Light operation.
One-Touch Lane Change Signal is activated by moving the Turn
Signal Lever slightly for less than 1 second and then releasing. The
lane change signal will blink 3 times.
To change how many times (3/5/7) the Lane Change Signal blinks,
go to User Settings Mode in the LCD Instrument Cluster modes.
For more information on the User Settings Mode, please refer to your Owner’s Manual.
STEERING WHEEL CONTROLS
