Kia K5 2021 Parts list manual

Delivery First
The priority that delivers more
Features & Functions Guide

WELCOME TO THE KIA FAMILY!
Your new Kia vehicle has been designed, engineered and manufactured to provide you with years of comfortable and dependable driving. Kia is committed
to quality, innovation, safety and – above all – your satisfaction.
USING THIS FEATURES & FUNCTIONS GUIDE
The information contained in this guide is a brief overview of the operation and features of your new Kia vehicle.
This Features & Functions Guide and the specific operational and safety information it provides are not a substitute for your Owner’s Manual. In the interest
of your safety and that of the vehicle’s occupants, and to help you avoid risks that may result in death or serious injury, Kia reminds you to carefully read the
Owner’s Manual in order to fully familiarize yourself with the important information and safety warnings it contains.
While Kia endeavors to ensure that the information contained in this guide is accurate at the time of printing, Kia may change vehicle specifications without
notice in advance of or after the fact and assumes no liability in connection with such changes.
1. If you’re having trouble scanning codes, check the following:
§The code should be centered and focused in your mobile device’s
camera screen
§Consider moving your device closer to or farther away from the code
§The code should be well lit, without significant shadow
§Avoid scanning from a significant angle
§Confirm that the device’s app supports 2D QR Code scanning
§Try another QR Code Reader app; not all apps are created equal
2. After scanning, you may experience a “connection error” message or a “connecting” message with no subsequent response. These messages typically
indicate that your device is having trouble connecting to the Internet
QUICK TIPS
VIDEOS AND QR CODES
Kia provides a number of video resources to assist you with becoming familiar with the features and functions found in your Kia
vehicle. You can access these resources by snapping the QR Codes with your mobile device using the built-in QR Code Reader
or a downloaded QR Code Reader App.
After opening the QR Code Reader App on your mobile device, the app will utilize your device’s camera. Center the code in the
camera viewing area - With some apps, as soon as the app recognizes the code, it will launch the corresponding video.
With other apps, you will have to snap or “take a picture” of the code. The app will then launch the corresponding video.
For operation specifics, refer to the instructions that come with the QR Code Reader app. You can also view the videos by
visiting the following website: www.youtube.com/KiaFeatureVideos.
One-Click Fuel
Cap Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website. Refer to this page
for more information.
www.youtube.com/KiaFeatureVideos
QR CODE

GETTING STARTED
As you get to know your new Kia, you can explore this booklet to better understand how to operate its many features and systems.
You can find the complete Table of Contents on the next two pages, but first, be sure to review the following to better understand
some of your Kia’s most used features:
1Smart Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
2Fuel Filler Door Release. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
3Power Adjustable Driver’s Seat* / Front Seat Headrest Adjustment . . . . . . 43-44
4Seat Warmers* / Ventilated Seats* . . . . . . . . . . . . . . . . . . . . . . . . 42
5Lifting Wipers (Wiper Service Mode) . . . . . . . . . . . . . . . . . . . . . . . 23
6Windshield Wipers & Washers . . . . . . . . . . . . . . . . . . . . . . . . . . 23
7Idle, Stop & Go (ISG) System . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
8Smart Cruise Control (SCC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
9Highway Driving Assist (HDA)* . . . . . . . . . . . . . . . . . . . . . . . . . . 16
10 Rear Occupant Alert (ROA) with Door Monitoring . . . . . . . . . . . . . . . . . 44
11 Smart Trunk with Auto Open* . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
12 Normal Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . Back Cover
13 User Settings – Instrument Cluster . . . . . . . . . . . . . . . . . . . . . . . . 09
14 Vehicle Settings* – Audio Head Unit Screen. . . . . . . . . . . . . . . . . . . . 10
15 Bluetooth®Wireless Technology . . . . . . . . . . . . . . . . . . . . . . . 28-29
16 Standard Audio System - Value* . . . . . . . . . . . . . . . . . . . . . . . . . 32
17 UVO link Activation* / UVO Assistance* . . . . . . . . . . . . . . . . . . . . . . 33
18 UVO link with Navigation*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
19 Android Auto™/ Apple CarPlay®Setup . . . . . . . . . . . . . . . . . . . . . . 31
Driving while distracted can result in a loss of vehicle
control that may lead to an accident, severe personal
injury and death. The driver’s primary responsibility
is in the safe and legal operation of a vehicle, and
handheld devices, other equipment or vehicle
systems which take the driver’s eyes, attention and
focus away from the safe operation of a vehicle or
that are not permissible by law should never be used
during operation of the vehicle.
www.kia.com
Consumer Affairs - Roadside Assistance†18:
1-800-333-4KIA (800-333-4542)
Always check the Owner’s Manual for complete
operating information and safety warnings.
*IF EQUIPPED
K5 FEATURES & FUNCTIONS GUIDE

TABLE OF CONTENTS
VIDEOS & QR CODES.....Inside Front Cover
INSTRUMENT CLUSTER
Instrument Cluster Overview ...............03
Indicators & Warning Lights ................04
Tire Pressure Monitoring System (TPMS) ......05
Instant Fuel Economy / Fuel Economy .........06
Drive Mode Integrated Control System ........07
VEHICLE SETTINGS
LCD Instrument Cluster Modes ..............08
Trip Modes / Trip Computer.................08
User Settings – Instrument Cluster ...........09
Service Interval Mode .....................09
Vehicle Settings – Audio Head Unit ...........10
Vehicle Auto-Shut Off* ....................10
ADVANCED DRIVER ASSISTANCE
SYSTEMS (ADAS)
Blind-Spot Collision-Avoidance Assist (BCA)* ... 11
Rear Cross-Traffic Collision-Avoidance Assist
(RCCA)* .............................. 12
Forward Collision-Avoidance Assist (FCA)...... 13
Lane Keeping Assist (LKA) .................14
Lane Following Assist (LFA) ................ 15
Highway Driving Assist (HDA)* ..............16
Driver Attention Warning (DAW) ............. 17
Leading Vehicle Departure Alert (LVDA) ....... 18
Safe Exit Assist (SEA)* .................... 18
DRIVER’S PANEL
Instrument Cluster Control*................. 19
Electronic Stability Control (ESC) ............ 19
Hill-Start Assist Control (HAC)...............19
Engine Start/Stop Button*..................20
Power Windows, Window Lock
& Central Door Lock ....................21
Manual Folding Mirrors* ...................21
DRIVER’S PANEL CONTINUED
Auto Door Lock/Unlock ....................21
Power/Heated Outside Mirrors*..............21
Electronic Child Safety Lock System* .........21
Rear Door Locks .........................21
STEERING WHEEL CONTROLS
Headlights & High Beams ..................22
Windshield Wipers & Washers...............23
Lifting Wipers (Wiper Service Mode)..........23
Turn Signals & Fog Lights* .................23
Smart Cruise Control (SCC) .................24
Cruise Control (CC) .......................25
Navigation-based Smart Cruise Control (NSCC)* 26
Heated Steering Wheel Button*..............27
Tilt/Telescoping Steering Wheel .............27
AUDIO SYSTEMS
Bluetooth®Wireless Technology .............28
Audio Controls ..........................30
Android Auto™/ Apple CarPlay®Setup ........31
Standard Audio System - Value* .............32
UVO link Activation* ......................33
UVO Assistance* .........................33
Kia Access with UVO link App Download.......34
Kia Access with UVO link App Features Guide...34
UVO link with Navigation* ..................35
CENTER PANEL
Multimedia USB Port & Power Outlets.........36
Digital Clock ............................36
USB Charger Ports*.......................36
Idle, Stop & Go (ISG) System................37
Wireless Smartphone Charging System*.......38
Automatic Climate Control. . . . . . . . . . . . . . . . . . 39
Electronic Parking Brake (EPB) ..............40
Auto Hold ..............................40
Automatic Gear Shift with Sportmatic®Shifting . 41
CENTER PANEL CONTINUED
Paddle Shifters* .........................41
Dual Clutch Transmission (DCT) .............42
Seat Warmers* / Ventilated Seats* ...........42
SEATING
Driver Position Memory System*.............43
Power Adjustable Driver’s Seat* .............43
6-Way Manual Adjustable Driver’s Seat*.......44
Front Seat Headrest Adjustment .............44
Rear Occupant Alert (ROA) with Door Monitoring . 44
OTHER KEY FEATURES
Map/Room Lamps........................45
Panoramic Sunroof with Power Sunshade* .....45
Smart Key* .............................46
Remote Keyless Entry (Folding Key)*..........47
Double-Turn Lock/Unlock All................47
Fuel Cap / Malfunction Indicator (Check Engine
Light) ................................47
Fuel Filler Door Release. . . . . . . . . . . . . . . . . . . . 47
Trunk Release Buttons ....................48
Smart Trunk with Auto Open* ...............48
Reverse Parking Collision-Avoidance Assist (PCA)* 49
Reverse Parking Distance Warning (PDW)* .....49
Rear View Monitor (RVM) ..................50
Sunvisor ...............................50
Hood Release Lever and Latch .............. 51
SAFETY FEATURES
Child-Protector Rear Door Locks (Manual)*.....51
Occupant Detection System (ODS) /
Passenger Airbag Off Indicator ............52
Seat Belts ..............................52
NORMAL MAINTENANCE -
TURBO ....................... Back Cover
LEGAL DISCLAIMERS.... Inside Back Cover
2K5 FEATURES & FUNCTIONS GUIDE *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER

0
20
40
60
80
100 120 140 160
180
200
220
240
260
0
1
2
345
6
7
8
km/h
EPB
CH
x1000rpm
0
20
40
60 80 100
120
140
160
EF
MPH
(Type A cluster)
This illustration is for demonstration purposes only. Some indicators and warning lights
may not appear in illustration. On the vehicle, they may appear in the LCD.
Your vehicle’s instrument cluster & indicator light locations may differ from those in the
illustrations. See Section 4 in the Owner’s Manual for more information.
A
B B
C
D
E
E
F
G
Instrument Cluster Overview
ATachometer
BTurn Signal Indicators
CSpeedometer
DEngine Temperature Gauge
EIndicators & Warning Lights
FLCD – Gear Shift Position, Odometer,
Trip Modes / Trip Computer,
Driving Assist
GFuel Gauge
Arrow direction indicates the side of
the vehicle the fuel door is located
3
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
INSTRUMENT CLUSTER
INSTRUMENT
CLUSTER

Forward Collision-Avoidance Assist Warning Light*
Lane Keeping Assist Indicator Light*
Low Fuel Level Warning Light
Electronic Brake force Distribution (EBD)
System Warning Light (Two separate indicators on
Instrument Cluster lit at same time)
CRUISE Cruise Indicator Light
Cruise SET Indicator Light*
AUTO HOLD Indicator Light*
Front Fog Light Indicator
Airbag Warning Light
Seat Belt Warning Light
Malfunction Indicator Lamp (MIL)
Low Tire Pressure Indicator / TPMS
Malfunction Indicator
Anti-lock Braking System (ABS) Warning Light
Electronic Stability Control (ESC) Indicator Light
Electronic Stability Control (ESC) OFF Indicator Light
Electronic Parking Brake (EPB) Warning Light*
LED Headlamp Warning Light*
Immobilizer Indicator Light*
SPORT SPORT Mode Indicator Light*
High Beam Assist Indicator*
High Beam Indicator
Low Beam Indicator Light*
Light ON Indicator Light
Parking Brake & Brake Fluid Warning Light
Engine Oil Pressure Warning Light
Electric Power Steering (EPS) Warning Light
Charging System Warning Light
!Master Warning Light*
Indicators & Warning Lights
Your vehicle’s instrument cluster & indicator light
locations may differ from those in the illustrations. See
Section 4 in the Owner’s Manual for more information.
This illustration is for demonstration purposes only.
Some indicators and warning lights may not appear in
illustration. On the vehicle, they may appear in the LCD.
0
20
40
60
80
100 120 140 160
180
200
220
240
260
0
1
2
345
6
7
8
km/h
EPB
CH
x1000rpm
0
20
40
60 80 100
120
140
160
EF
MPH
4K5 FEATURES & FUNCTIONS GUIDE *IF EQUIPPED
INSTRUMENT CLUSTER
INSTRUMENT
CLUSTER

0
20
40
60
80
100 120 140 160
180
200
220
240
260
0
1
2
3
45
6
7
8
km/h
EPB
CH
x1000rpm
0
20
40
60 80 100
120
140
160
EF
MPH
Tire Pressure Monitoring
System Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to inside front cover
information.
www.youtube.com/KiaFeatureVideos
QR CODE
(Indicator located on Instrument Cluster)
Tire Pressure Monitoring System (TPMS)†24
The TPMS indicator functions as both Low Tire Pressure Light
and TPMS Malfunction Indicator A. The indicator is designed
to illuminate if it detects one or more tires is significantly underinflated,
the vehicle has a spare tire installed without TPMS or the outside
temperature becomes significantly lower.
The Low Tire Pressure Position Indicator Bis displayed on the LCD
screen in the Instrument Cluster when the tire(s) is underinflated. Inflate
tire(s), using an accurate digital tire pressure gauge, to specifications to
turn off the Low Tire Pressure Position Indicator B; see the front driver’s
door jamb for PSI specification.
When there is a problem with the TPMS, the TPMS Malfunction Indicator
will blink for approximately one minute and then illuminate–see dealer
for service.
•Even with TPMS, tire pressure should be checked manually at least once a month. Only adjust tire pressure on “cold tires”
that have been sitting for 20 minutes, and tires that are not hot in temperature from direct sunlight or heat
•For proper maintenance and optimal fuel economy, maintain recommended tire inflation pressures and stay within the
load limits and weight distribution recommended for your vehicle
•In winter or cold weather, the TPMS light may illuminate if the tire pressure was adjusted to the recommended tire
inflation pressure during warm weather
QUICK TIPS
REMINDERS:
• Check the recommended tire pressure label located on the left side of driver's door jamb, which is visible when the door is open
• Consult your dealer for service if the Low Tire Pressure Light remains illuminated after inflating your tire(s)
• Personal electronic devices (such as laptops, wireless chargers, remote start systems, etc.) can interfere with the TPMS system,
which may cause the Malfunction Warning Indicator (Check Engine Light) to illuminate
For illustrative purposes only. Your actual display, buttons and/or features may vary. Refer to section 6 in the Owner’s Manual for more information.
5
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
A
INSTRUMENT CLUSTER
INSTRUMENT
CLUSTER
Tire Pressure
3525
35
psi
35
B

6*IF EQUIPPED
K5 FEATURES & FUNCTIONS GUIDE
INSTRUMENT CLUSTER
INSTRUMENT
CLUSTER
Fuel Economy Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to inside front cover
information.
www.youtube.com/KiaFeatureVideos
QR CODE
(Type A - Buttons located on Steering Wheel)
Instant Fuel Economy
Press the Mode button Ato cycle to the Trip Computer mode ,
then toggle up or down with the OK button Ato cycle to the Fuel
Economy screen. The bar at the bottom of the screen displays the
calculated Fuel Consumption during the past few seconds when the
vehicle speed is more than approximately 6 mph.
1. Keep your vehicle in good condition with regular maintenance
2. Travel lightly, without carrying unnecessary weight in your vehicle
3. Don’t let the engine idle longer than necessary
REMINDERS:
•Not to be used in calculating or as a reference for AVERAGE fuel economy
•If the vehicle speed exceeds 1 mph (1.6 km/h) after being refueled with more than
1.6 gallons (6 liters), the average fuel economy will be cleared to zero (----)
Your vehicle’s steering wheel buttons may differ from those in the illustrations.
Refer to section 4 in the Owner’s Manual for more information.
There are several factors that contribute
to your vehicle’s fuel economy, such as
maintenance of your vehicle, driving style,
environmental conditions, vehicle weight and
vehicle aerodynamics. Below are some tips on
how to help improve fuel economy:
•Keep your vehicle in good condition with
regular maintenance
•Don’t let the engine idle longer
than necessary
•Drive at a moderate speed, accelerating
smoothly and at a moderate rate
•Keep tires inflated to the recommended
pressure
•Travel lightly, without carrying
unnecessary weight in your vehicle
•Avoid placing large or heavy items on roof racks
•Avoid hilly, winding or poorly maintained roads
For more information on Fuel Economy, you can snap the QR Code above to view a video or
refer to section 4 in the Owner's Manual.
Fuel Economy
B
A

7
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
SNOW*
SPORT /
SPORT+*
COMFORT
CUSTOM*
SMART*
Blind-Spot Collision-
Avoidance Assist (BCA)
Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to inside front cover
information.
www.youtube.com/KiaFeatureVideos
QR CODE
A
INSTRUMENT CLUSTER
AUTO
HOLD
OFF
SHIFT
LOCK
RELEASE
P
R
N
D
+
_
DRIVE
MODE
INSTRUMENT
CLUSTER
For illustrative purposes only. Actual
vehicle operation or display may vary.
The drive modes may be changed according to the driver’s preferences or road
conditions. To cycle through the drive modes Aor deactivate a drive mode,
rotate the DRIVE MODE knob B.
When a drive mode is selected, the drive mode indicator will illuminate in the
Instrument Cluster or the audio head unit* (except for COMFORT). The system’s
default mode is COMFORT mode and when selected, the indicator will not be
illuminated.
• COMFORT Mode
• SPORT Mode
• SPORT+* Mode (2.5 Turbo)
• SNOW Mode* (All Wheel Drive)
• SMART Mode* – When the SMART mode is activated, the system automatically
selects the drive mode best suited to the current driving style (economic,
average, spirited). The color of the SMART mode indicator (green, white, red)
depends on the current driving style
• CUSTOM Mode* – When CUSTOM mode is selected, on the audio head unit the
driver can select separate modes with different combinations of drive modes
Drive Mode Integrated Control System
REMINDERS:
•Steering effort may be slightly increased in SPORT/SPORT+ mode
•When SPORT/SPORT+ mode is selected, fuel economy may decrease
For more information, refer to the Car Infotainment System Quick Reference Guide.
B

8*IF EQUIPPED
K5 FEATURES & FUNCTIONS GUIDE
VEHICLE SETTINGS
VEHICLE
SETTINGS
Driving while distracted is dangerous and should be avoided. Drivers
should remain attentive to driving and always exercise caution when
using the steering-wheel-mounted controls while driving.
Refer to section 4 in the Owner’s Manual for more information.
LCD Instrument Cluster Modes
(Type B; Buttons located on Steering Wheel)
Trip Computer Mode: Displays driving information for
Fuel Economy, Accumulated Info, Drive Info, Transmission
Temperature
Turn-by-Turn Mode*: Displays information on Route
Guidance, Destination Info
Driving Assist Mode: System settings for Smart Cruise
Control, Lane Keeping Assist, Lane Following Assist,
Driver Attention Warning, TPMS
User Settings Mode: Change settings for Driver Assistance,
Door, Lights, Convenience, Service Interval, Language,
Other Features, Reset
Master Warning Mode: Informs of warning messages related
to the vehicle when the systems are not operating normally
Press Mode button Ato scroll through different LCD Instrument
Cluster Modes.
Type B cluster:
Your vehicle’s steering wheel buttons may differ from those in the illustrations.
For illustrative purposes only. Your actual display, buttons and/or features may vary.
Refer to section 4 in the Owner’s Manual for more information.
Trip Modes / Trip Computer
The Trip Computer is a system to relay pertinent
driving information. It appears on the display
when the ignition switch or the Engine Start/
Stop button* is in the ON position.
To cycle through the Trip Modes, press the
Mode button A.
To select and enter Trip Computer mode ,
press the OK button Bup/down and then
press the OK button Bagain to enter. To cycle
through different screens (Fuel Economy, Trip
A, Trip B), press the OK button Bup/down and
press again to enter. When displaying TRIP A or
TRIP B screens, press and hold the OK button
Bto reset the Tripmeter to zero.
REMINDERS:
•Appearance of Tripmeter display may differ as equipped
•All stored driving information (except Odometer and
Range) is reset if the battery is disconnected
FUEL ECONOMY
•Average Fuel Economy
•Instant Fuel Economy
DRIVE INFO
•Tripmeter
•Fuel Economy
•Timer
SINCE REFUELING
•Tripmeter
•Fuel Economy
•Timer
ACCUMULATED INFO
•Tripmeter
•Fuel Economy
•Timer
DIGITAL SPEEDOMETER
Fuel Economy
27.4mpg
Average
0 10 20 30
(Type B Cluster)
A
B

9
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
VEHICLE SETTINGS
VEHICLE
SETTINGS
For illustrative purposes only. Your
actual display, buttons and/or
features may vary.
To view a video on your
mobile device, snap these
QR Codes or visit the listed
website.
Refer to inside front cover
information.
LCD Display Video
LCD Display:
Maintenance Video
www.youtube.com/KiaFeatureVideos
www.youtube.com/KiaFeatureVideos
QR CODES
Service Interval Mode
To enter Service Interval mode, press the Mode
button A, scroll using the OK button Bto User
Settings and press the OK button Bto enter.
Then scroll to Service Interval and press the OK
button again B. The System will display number
of miles remaining until the next service is due, as
well as type of service.
When service is required,
the following will be
displayed: Service
Required.
To reset the Service
Interval mode system,
press and hold the OK
button Bfor more than 1 second.
To turn Service In OFF, go to User Settings.
Service Interval Setting
To set the service interval when in User Settings
mode:
•Press the OK button Bup/down and scroll to
Service Interval. Press the OK button Bagain
to enter
•Press the OK button Band toggle to ON, then
press the OK button Bagain to set. Then press
the Move button Bup/down to scroll and select
the desired miles or months for your next service
•Press the OK button Bagain to enter
(Type B cluster)
Service required
0mi
0day
User Settings - Instrument Cluster
To enter the User Settings mode in
the Instrument Cluster, press the
Mode button Awhen the vehicle is
at a standstill, shift lever in Park and
with the ignition switch or the Engine
Start/Stop button* in the ON position,
and select User Settings .
You can navigate the selections on the display by pressing the Select/
Reset (OK) button Bup and down, and then selecting the item by
pressing the OK button Bagain.
(Type B; Located on Steering Wheel)
Driving Assistance*:
•Warning Time
•Warning Volume
•Driver Attention Warning
•Forward Safety
•Lane Safety
•Blind-Spot Safety
•Parking Safety
Door/Trunk:
•Automatically Lock
•Automatically Unlock
•Two-Press Unlock
•Smart Trunk with Auto Open*
Lights:
•Ambient Light
•One-Touch Turn Signal
•Headlamp Delay
•High Beam Assist
Convenience:
•Welcome Mirror/Light
•Wireless Charging System
Service Interval:
•Enable Service Interval
•Adjust Interval
•Reset
Other Features:
•Fuel Economy Auto Reset
•Speedometer Units
•Fuel Economy Units
•Temperature Units
•Tire Pressure Units
Reset:
•Reset User Setting menus
Language:
•Choose the language
A
B

10 *IF EQUIPPED
K5 FEATURES & FUNCTIONS GUIDE
Vehicle Auto-Shut Off*
The timer that appears on the Instrument Cluster’s LCD can be reset using
the OK button on the right side of the Steering Wheel.
QUICK TIP
REMINDERS:
•When the vehicle is turned off then on again, the system defaults to on
(30-minute pre-set time)
•The system will activate when the vehicle is on and these conditions are met:
– The vehicle is in (P) Park
– The driver’s seat belt is unfastened
– The driver’s door is opened
– The passenger seat is not occupied
VEHICLE SETTINGS
VEHICLE
SETTINGS
The Vehicle Auto-Shut Off, when certain conditions are met, will
turn the vehicle off automatically after a pre-set time (30 or 60
minutes) in the User Settings.
A warning on the Instrument Cluster LCD will appear stating the
“Vehicle will be turned off automatically in…” and a chime will
sound when the timer starts B.
When timer ends, a continuous beep sounds for one minute before
the vehicle shuts off.
Auto-Shut Off Settings –The system is on by default and timer is
pre-set to 30 minutes. To change the pre-set time settings, go to
User Settings* on the Instrument Cluster LCD or the audio head unit
Vehicle Settings* and select 30 minutes, 60 minutes or off C.
Vehicle Auto-Shut Off
Back
60 min.
30 min.
Off
Vehicle will be turned off
automatically in
59:01
:Reset
OK
Vehicle Settings - Audio Head Unit
To enter the Vehicle Settings mode in the audio head unit A, press the SETUP key
on the audio head unit. Then press the Vehicle icon, which will take you to Vehicle
Settings. Use the touchscreen to navigate through the menus.
Vehicle Settings:
Driver Assistance: Driving Convenience*, Warning Time*, Warning Volume*,
Driver Attention Warning*, Forward Safety*, Lane Safety*, Blind-Spot Safety*,
Parking Safety*
Drive Mode: Drive Mode Alert*
Climate*: Recirculate Air*, Automatic Ventilation*, Defog/Defrost Options*,
Climate Features*
Lights*: Ambient Light*, One Touch Turn Signal*, Headlight Display*,
High Beam Assist*
Door*: Auto Lock*, Auto Unlock*, Walk-Away Lock*, Two-Press Unlock*,
Smart Trunk*
Cluster*: Service Interval*, Energy Consumption Reset*, Content Selection*,
Cluster Voice Guidance Volume*, Welcome Sound*, Theme Selection*
Convenience*: Rear Occupant Alert*, Welcome Mirror Light*, Wireless
Charging System*, Vehicle Auto-Shut Off*
Seat*: Seat Position Change Alert*, Smart Posture Care*, Heated/Ventilated
Features, Seat East Access*, Rear Seat Heating Control*
Reset: Reset Vehicle Settings to Factory Defaults
12:00 AM Jan. 1
Menu
Vehicle Settings
Driving Convenience
Drive Mode
Climate
Lights
Driver
Assistance
Warning Timing
Late
Warning Volume
Off
Driver Attention Warning
A
B C

11
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
Blind-Spot Collision-
Avoidance Assist (BCA)
Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to inside front cover
information.
www.youtube.com/KiaFeatureVideos
QR CODE
Blind-Spot Collision-Avoidance Assist (BCA)*†6a
BCA is designed to help alert the driver before changing lanes. BCA uses a front-view
camera on the front windshield and rear-corner radar sensors in the rear bumper to
help alert the driver and temporarily apply braking in certain situations if it detects an
approaching vehicle in the driver’s blind spot area.
To turn BCA on, go to User Settings by pressing the Mode button on the Steering Wheel
or the Vehicle Settings* on the audio head unit. Select Driver Assistance > Blind-Spot
Safety. Then select Active Assist, Warning Only or Off.
Warning Only – The Warning Only setting will activate the 1st and 2nd stage alerts:
1st-stage: When another vehicle is detected within the BCA system warning boundary
A, a yellow indicator will illuminate on the outside rearview mirrors B.
2nd-stage: When the 1st stage alert is on and the driver activates a turn signal, a
flashing yellow indicator will illuminate on the outside rearview mirrors and the system
will sound a warning.
To set the initial warning activation time, go to the settings > Driver Assistance
> Warning Timing. Then select the Normal or the Late option.
Active Assist – When Active Assist is selected in the settings, BCA may activate
the Electronic Stability Control (ESC) and temporarily apply braking power when an
approaching vehicle is detected within a certain distance next to or behind the vehicle.
A warning message may appear on the Instrument Cluster LCD.
BCA is a supplemental system. Do
not solely rely on this system and
always pay attention to the road and
its conditions.
See section 5 in the Owner’s Manual
for more detailed information,
limitations and conditions.
REMINDERS:
•BCA will not issue a warning if the vehicle is
passing at a high speed
•When BCA is ON and the ignition is cycled,
BCA returns to its previous state
The above images are for illustrative
purposes only and may not reflect
actual operation.
A
B
•The BCA Warning Volume can be adjusted in the User Settings or the Vehicle Settings* on
the audio head unit
•Conditions for the BCA to operate:
– Warnings: When the vehicle is traveling faster than 12 mph
– Active Assist: When the vehicle is traveling at least 40 mph
– Other vehicle detected on the side or the rear of the vehicle
QUICK TIPS
ADVANCED DRIVER ASSISTANCE SYSTEMS (ADAS)
ADAS

12 K5 FEATURES & FUNCTIONS GUIDE *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
ADVANCED DRIVER ASSISTANCE SYSTEMS (ADAS)
ADAS
The RCCA Warning Volume can be adjusted in the User Settings in the
Instrument Cluster or the Vehicle Settings* on the audio head unit
QUICK TIP
REMINDERS:
•The RCCA feature can be turned OFF/ON in User Settings, under Driver Assistance, Parking Safety
•When vehicle power is cycled, RCCA will remain in the previous state
•When a vehicle is approaching within the sensing range, and traveling 3 mph or faster, the RCCA
system will show a warning
•The RCCA system is a supplemental system. Do not solely rely on these systems and always pay
attention to the road and its conditions
Rear Cross-Traffic Collision-Avoidance Assist (RCCA)*†6a
If RCCA sensors detect approaching vehicles from the rear left or rear right side of the
vehicle A, the system will sound an audible warning, the warning indicators on the
outside rearview mirror will illuminate and a message will appear
on the Instrument Cluster screen B.
RCCA may activate the Electronic Stability Control (ESC) to help avoid an imminent
collision. RCCA may temporarily apply braking power when an approaching vehicle is
detected within a certain distance next to or behind the vehicle.
RCCA is designed to operate under the following conditions:
•When the gear shift is in Reverse
•When the vehicle is moving 5 mph or slower
A
(Warning to apply braking)
Images are for illustrative purposes
only and may not reflect actual
feature or operation.
See section 5 in the Owner’s Manual for more information.
B

ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER 13
Collision Warning
Forward Collision-
Avoidance Assist (FCA)
Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to inside front cover
information.
www.youtube.com/KiaFeatureVideos
QR CODE
Forward Collision-Avoidance Assist (FCA)†6a
FCA is designed to detect and monitor a vehicle ahead or detect a pedestrian in the roadway through front view camera
recognition and front radar signals to warn the driver that a collision is imminent, and if necessary, temporarily apply
emergency braking. Initially, FCA provides Forward Collision Warning (FCW) when it detects a potential collision with a vehicle
or pedestrian in front, emitting an audible warning and visual alert on the instrument cluster A.
If the system detects that the collision risk has increased, the FCA
automatically applies the brakes to reduce your speed, potentially
helping to reduce the effects of a possible collision.
FCA can be enabled by going to the User Settings > Driver Assistance >
Forward Safety and selecting Active Assist, Warning Only or Off.
The Warning Timing can be adjusted by going to User Settings >
Driver Assistance > Warning Time and Normal or Late.
FCA will become active when the:
• Engine Start/Stop button is ON
• Vehicle is traveling 6 mph or faster
• Electronic Stability Control (ESC) is ON
Forward Collision-Avoidance Assist
(FCA) is not a substitute for safe
and proper driving. Always drive
safely and use caution. FCA may
not always alert the driver when
the vehicle is approaching another
vehicle.
Images are for illustrative purposes
only and may not reflect actual feature
or operation.
See section 5 in the Owner’s Manual
for more information.
REMINDERS:
• FCA will be activated by default when vehicle power is cycled on, even when
previously set to off
• If FCA is operating and the ESC (Electronic Stability Control) is turned off, FCA is
automatically turned off
• When FCA is off, the FCA warning indicator is on in the Instrument Cluster
For illustrative purposes only. Your actual display, buttons and/or features may vary.
The FCA Warning Volume can be adjusted in the User Settings* or the Vehicle
Settings* on the audio head unit.
QUICK TIP
A
ADVANCED DRIVER ASSISTANCE SYSTEMS (ADAS)
ADAS

14 *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
K5 FEATURES & FUNCTIONS GUIDE
With the Engine Start/Stop button in the ON position, LKA is on by default. The instrument cluster indicator will illuminate
white. It will remain white when the vehicle is traveling slower than 40 mph and the system does not detect lane markers. When
LKA detects the lane markers and can assist steering, the LKA icon will illuminate green.
If LKA detects that you are moving outside of your lane, the system may give an audible warning and display a Lane Departure
Warning on the instrument cluster. If the vehicle continues to move outside of the lane, LKA will provide steering inputs, trying to
prevent the vehicle from moving outside its lane.
To turn LKA off, press the Lane Safety button A. To switch between modes (Active LKA, LKA and Lane Departure Warning),
go to User Settings in the Instrument Cluster, select Driver Assistance, then Lane Keeping Assist or the Vehicle Settings* in the
audio head unit.
The three available modes are:
Active LKA – Provides more frequent steering inputs than standard LKA
Lane Keeping Assist – Guides driver to keep vehicle within lanes and provides steering inputs
when vehicle is about to deviate from the lane
Lane Departure Warning – Alerts driver when the system detects the vehicle leaving the lane.
In this mode the system will not provide steering inputs
All systems will operate under the following conditions:
•The vehicle speed exceeds approximately 40 mph
•LKA recognizes the lane the vehicle is traveling in
•The vehicle is between the lane markers
Lane Keeping Assist
(LKA) Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website. Refer to inside
front cover information.
www.youtube.com/KiaFeatureVideos
QR CODE
(Located left of Steering Wheel)
Lane Keeping Assist
Lane Keeping Assist
Lane Keeping Assist Lane Keeping Assist
Lane Keeping Assist Lane Keeping Assist
Lane Keeping Assist
Lane Keeping Assist
Lane Keeping Assist Lane Keeping Assist
Lane Keeping Assist
Lane Keeping Assist
Lane Keeping Assist
Lane Keeping Assist
Lane Keeping Assist Lane Keeping Assist
When the LKA front-view
camera detects the lane
traveling in
When the LKA front-view
camera does not detect the
lane traveling in
When the LKA front-view camera detects the vehicle veering
outside of the lane traveling in, a yellow indicator will illuminate
Lane Keeping Assist (LKA)†6a
Lane Keeping Assist is not
a substitute for safe and
proper driving. Always drive
safely and use caution.
LKA may not always alert
the driver if the vehicle is
about to be driven outside
of its lane.
For illustrative purposes
only. Your actual display,
buttons and/or features
may vary.
See section 5 in the
Owner’s Manual for more
information.
REMINDERS:
• LKA will not issue a warning if the turn signal or hazard lights are activated
• If the Lane Safety button is not pressed and ignition is cycled, the system will
turn ON again. If the Lane Safety button is pressed, the system remains OFF
• LKA will return to its previous state when the ignition is cycled
• LKA may not always alert the driver if the vehicle is about to be driven
outside of its lane. Refer to the Owner’s Manual for more information
• When the vehicle changes lanes without a turn signal, LKA may sound an
audible warning. The warning sound can be adjusted in the User Settings
The LKA Warning
Volume can be
adjusted in the
User Settings or the
Vehicle Settings* on
the audio head unit.
QUICK TIP
A
ADVANCED DRIVER ASSISTANCE SYSTEMS (ADAS)
ADAS

15
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
Lane Following Assist (LFA)†6a
Lane Following Assist monitors lane lines and adjusts the steering to help
position the vehicle in the center of the lane.
To enable or disable LFA, go to the User Settings* on the Instrument Cluster
LCD or the Vehicle Settings* on the audio head unit. Go to Vehicle
> Driver Assistance > Driving Assist > Lane Following Assist.
To activate or deactivate the LFA system press the LFA button Aon the
Steering Wheel.
When LFA is activated and detects lane markers and/or a preceding vehicle,
the LFA indicator will illuminate green if the steering assist mode is on, or
white if the steering assist mode is off.
LFA will operate only when these conditions are met:
•When Smart Cruise Control is on and operating
•The vehicle is traveling slower than 110 mph
•LFA recognizes the lane the vehicle is traveling in
Image is for illustrative purposes only and may not
reflect actual feature or operation.
REMINDERS:
•If the ignition is cycled, the LFA returns to its previous state, on or off
•LFA is not a substitute for safe and proper driving. Always drive safely and use caution
See section 5 in the Owner’s Manual for more detailed information, limitations and conditions.
(Type B; Buttons located on Steering Wheel)
A
ADVANCED DRIVER ASSISTANCE SYSTEMS (ADAS)
ADAS

16 *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
K5 FEATURES & FUNCTIONS GUIDE
Images are for illustrative purposes only and
may not reflect actual feature or operation.
See section 5 in the Owner’s Manual for more
information.
mph
60 mph
REMINDERS:
• Current highway speeds and controlled or limited access roads information may vary. Future navigation updates may change this
information. See owner’s manual for more information
• When the ignition is cycled, the system returns to its previous state, on or off
Highway Driving Assist is not a substitute for safe driving, may not detect all objects around the vehicle, and only functions on certain federal highways.
Always drive safely and use caution. See the Owner’s Manual for more detailed information, limitations and conditions.
Highway Driving Assist (HDA)*†6a
Highway Driving Assist (HDA) is designed to adjust the speed of the vehicle when driving on limited/controlled access
highways. The system can adjust the vehicle’s speed based on available highway speed information. The automatic speed
setting mode is designed to set the speed automatically by adjusting to the current speed limits of the highway vehicle is
travelling on.
To enable HDA, go to User Settings in the Instrument cluster or the Vehicle Settings* in the audio head unit. Go to Driver
Assistance > Driving Assist > Highway Driving Assist.
To activate HDA, turn Smart Cruise Control (SCC) on by pressing the Driving Assist (Cruise) button Aon the Steering
Wheel controls.
HDA will operate only when these conditions are met:
•When the SCC speed is set to current highway and controlled/limited access roads
•The vehicle is traveling slower than 110 mph
•When driving on limited access highways, such as, Interstate, Federal and State freeways
•When SCC is on and operating
When HDA is activated and the conditions are met, the Instrument Cluster indicator light Bwill illuminate green. If the
conditions are not met, HDA will be in standby mode and the indicator light Bwill illuminate white.
When in operation, and if both lanes are recognized, a display Cwill show the lanes illuminated white and the steering
wheel indicator illuminated green.
If HDA is activated, conditions are met and the SCC speed is set by the driver (at the posted highway speed limit), HDA
will enter the automatic speed setting mode. The set speed and AUTO will be displayed Din green and an audible alert
will sound.
ADVANCED DRIVER ASSISTANCE SYSTEMS (ADAS)
ADAS
(Type B Steering Wheel controls)
A
E
B
C
D

17
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
ADVANCED DRIVER ASSISTANCE SYSTEMS (ADAS)
ADAS
Driver Attention Warning (DAW)†6b
DAW is designed to detect inattentive driving practices and, in certain situations, can give a
warning signal to take a break from driving.
DAW is set to ON by default. To turn DAW OFF, turn the ignition on and then select User
Settings in the LCD Display on the Instrument Cluster or Vehicle Settings* in the audio head
unit. Go to Driver Assist and select Driver Attention Warning. Set Warning Timing to Normal or
Late Warning Timing.
Driver Attention Warning modes:
OFF: The Driver Attention Warning system is deactivated
Normal: The Driver Attention Warning system alerts the
driver of inattentive driving practices
Late: The Driver Attention Warning system alerts the driver of inattentive driving practices later
than in Normal mode
If the DAW System is activated, the DAW information will appear on the LCD Display Awhen
you select the Driving Assist mode .
A message, “Consider taking a break,” appears on the LCD display and a warning sounds to
advise the driver to take a break when the driver’s attention level is below one bar.
REMINDERS:
•The setup of the DAW system will be maintained, as selected, when the ignition is cycled
•When activated, the DAW system does not display the “Consider taking a break” message when the total trip driving
time is less than 10 minutes
Driver Attention Warning is not a substitute for safe driving and may not detect all instances of inattentive driving
practices. Failure to pay attention to travel conditions and vehicle operation could result in loss of vehicle control. Always
drive safely and use caution.
For illustrative purposes only. Your actual display, buttons and/or features may vary.
0
20
40
60
80
100 120 140 160
180
200
220
240
260
0
1
2
345
6
7
8
km/h
EPB
CH
x1000rpm
0
20
40
60 80 100
120
140
160
EF
MPH
P
Check Driver
Attention Warning
(DAW) System
59° F 10 mi
AUTO
HOLD
A

18 *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
K5 FEATURES & FUNCTIONS GUIDE
Safe Exit Assist (SEA)*†6a
Safe Exit Assist (SEA) can help prevent passengers from opening their
door by displaying a warning message on the Instrument Cluster and
sounding an audible warning when a vehicle is detected, approaching
from behind, and after your vehicle has stopped.
To turn on SEA, go to User Settings in the Instrument cluster or the
Vehicle Settings* in the audio head unit, select Driver Assistance, then
Blind-Spot Safety, and select Safe Exit Assist.
See section 4 in the Owner’s Manual for more information.
Image is for illustrative purposes only and may not reflect actual feature or operation.
Watch for traffic
Leading Vehicle Departure Alert (LVDA)†6b
When the vehicle detects that the leading vehicle is driving
away, LVDA sounds an warning to let you know you can start
driving.
If no action is taken after the vehicle in front drives away, then
a message Bwill appear on the Instrument Cluster.
To turn the system on, go to User Settings in the Instrument
Cluster. Press the MODE button on the Steering Wheel, go to
Driver Assistance > Leading Vehicle Departure Alert and press
the OK button on the Steering Wheel.
REMINDERS:
•When the ignition is cycled, the system returns to its previous state, on or off
•Always check the front of the vehicle and road conditions before departure
The Leading Vehicle Departure Alert system
is not a substitute for safe and proper driving.
Always drive safely and use caution.
Images are for illustrative purposes only and
may not reflect actual feature or operation.
Leading vehicle
is driving away
B
ADVANCED DRIVER ASSISTANCE SYSTEMS (ADAS)
ADAS
