KICK ASS KAVS12240V-LION User manual

KAVS12240V-LION
12/240V
RECHARGEABLE
WET/DRY
VACUUM SEALER
QUICK START GUIDE
V0.5

Keeping food fresh can be challenging while you are out camping or off the beaten
track. With the all new KickAss 12v Vacuum Sealer, you can do just that!
Now with a rechargeable lithium-ion battery with both 12v and 240v capabilities,
you can prep your food at home or out on the road!
Sealing your food at home is great for packing, saving room in your fridge or esky
and eliminating the need of bulky containers.
The 12v connection of the KickAss Vacuum Sealer means you can also use and
charge your sealer while you are travelling, perfect for storing leftovers or fresh
caught fish and game meats.
The KickAss Vacuum Sealer has settings for wet and dry foods, perfect for pre-
marinated meats or foods with a higher moisture content.
The new KickAss Vacuum Sealer is a vital part of any camping kitchen to help
keep your food fresh while on the road.
INTRODUCTION

FUNCTIONS AND FEATURES
Seal Only
Heat seals the bag without engaging the vacuuming function. This mode
can be used to make a bag from a bag roll.
Food: Dry/Wet/Container Setting
Dry: This mode is suitable for large bag vacuuming and products which
have a low moisture content.
Moist: This mode is suitable for products that have a high moisture content.
Canister: This mode is suitable for use with vacuum containers.
Vacuum Seal
This mode will engage the vacuum function and heat seal the bag on
completion.
Cancel
Stops the current vacuum operation.
1
2
3
4
Battery Charge Indicator
Displays the remaining charge of the battery.
5
Vacuum
Seal Cancel
Seal
Only Dry
Moist Canister
25%
100%
50% 75%
Food
1
3
5
2
4

SPECIFICATIONS DIAGRAM
Vacuum Seal Bar
Gasket
Vacuum Chamber
Nozzle
Heating Wire
Control Panel
On/Off
Switch
Charging
Socket
Vacuum
Canister Port
Locking Latch

1. Place item in vacuum canister.
2. Connect the canister to the vacuum tube and ensure both ends of the of vacuum
tube are secure.
3. Press the Vacuum Seal Button and observe the vacuum indicator of the canister.
When the canister indicates a vacuum, press the cancel button on the machine.
4. Gently pull out the vacuum tube.
Caution: Do not over vacuum.
How To Seal With Vacuum Canister
OPERATING INSTRUCTIONS
Take your desired size of plastic bag off
the roll and use the Seal Only function to
create a bag. Alternatively, use a pre-
made bag. Place items into your bag.
Make sure you leave some distance
around the items.
Open the top cover of the food sealer,
place the bag with the items inside into
the vacuum chamber but before the
vacuum nozzle.
Close the top cover engaging the lock.
Then press food mode. Then you will
need to choose either Wet Mode or
Dry Mode. When ready, press the
Vacuum Seal button and the operation
will begin.
After the indicator light goes out and
the machine stops, open the cover by
pressing in the lock button on both
ends of the cover and take your
vacuum sealed item.
● This appliance is not intended for use by persons (including children) with
reduced physical sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
● Children should be supervised to ensure that they do not play with the
appliance.
!

TECHNICAL SPECIFICATIONS
Model
Products Size
Battery
Motor rated voltage
Battery Run Time
Material
Vacuum Pressure
Sealing Length
Sealing Width
Charger
Battery charge time
Certification
Country of Origin
KAVS12240V-LION
356mm*141*68mm
14.8V 1500mAh
DC 12V
Approx. 50 Seals
ABS
75Kpa
28cm
2mm
12V-240V,50/60Hz
~1.5h
CE/ROHS/FCC
China

Warranty Period:
KickAss Products Pty Ltd (KickAss) of 2
Mallet Street, Kunda Park QLD 4556 offers
a 12 month warranty from date of purchase
against manufacturing defects in KickAss
Products.
Warranty Inclusions:
Under ordinary usage conditions, this
warranty covers any defect in design or
manufacture which results in our product
failing to perform substantially as described
in our advertising or literature (i.e. product
manuals).
Where we are at fault during the warranty
period, we will either repair or replace the
product (or part of the product) at our
discretion. When a product is repaired or
replaced under this warranty, the original
warranty period is not renewed or
extended.
This warranty is provided in addition to your
other rights and remedies under the
Australian Consumer Law and does not
exclude, restrict, modify, limit or override
your rights under the Australian Consumer
Law.
Warranty Exclusions:
Our warranty is non-transferable and is
only offered to the original purchaser of our
product.
Our warranty does not apply to:
1. Damage caused by any improper use of
our product(s);
2. Damage caused by faulty installation or
modification made during installation;
3. Damage caused by mould, insects,
animals, misuse, incorrect operation,
adverse weather, accidents and fair
wear and tear;
4. Damage caused by exposure to
excessive sunlight;
5. Costs, losses or charges:
- of removing and reinstalling the
product;
- directly or indirectly associated with the
product failing to operate.
6. Commercial use of KickAss Products by
government organisations or
commercial fleet applications;
7. KickAss Products that are on-sold by the
customer or exported for use outside of
Australia.
How to Claim:
To make a claim visit supportportal.kickassproducts.com.au, email
[email protected]. Please provide your proof of purchase (i.e. sales receipt) to
assist with your warranty claim.
Once we approve your warranty claim, we will arrange (at our cost) return shipping of the faulty
product to an assessment facility of our choice. Once we have determined the cause of the
defect, we will contact you with the outcome of our assessment and advise whether the faulty
product will be repaired or replaced.
Australian Consumer Law:
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does not amount to a major
failure.
WARRANTY

kickassproducts.com.au
