KidKraft 14321A User manual

Customer Service
1-800-933-0771
www.kidkraft.com 1
USE AND MAINTENANCE:
-Use on level surfaces only
-Please check assembly at regular intervals, and frequently
tighten hardware if necessary. If maintenance is not carried out,
the product could cease to function properly
Please retain this information for future reference To order replacement parts, please visit www.kidkraft.com
CAUTION: Adult Assembly Required. Hardware
contains small screws with sharp points. Keep
unassembled parts out of reach of small children.
WARNING: CHOKING HAZARD
Small parts and sharp points, not
suitable for children under 3 years.
HARDWARE
Item# 14321A-14324A
Medium Locker
Assembly Instructions
Parts List:
Step 1 Step 2 Step 3
A. Hex Bolt x 12 pcs
(2 in / 50 mm)
B. Flat Screw x 4 pcs
(1 in / 25 mm)
C. Flat Screw x 4 pcs
(5/8 in / 15 mm)
D. Screw x 4 pcs
(5/16 in / 8 mm)
E. Cap Nut x 4 pcs
F. Latch x 2 pcs
G. Fabric Strip x 1 pc
H. Screw x 1 pc
(5/8 in / 15 mm)
I. Plastic anchor x 1 pc
J. Wood Screw x 1 pc
(1 9/16 in / 40 mm)
Wrench x 1 pc
Allen Wrench x 1 pc
The following tool
(not included) is
required for assembly:
Phillips®screwdriver
x 4
x 2x 2
F
F
Hole
predrilled
in product.
G
H
H
11

Item# 14321A-14324A
Medium Locker
Assembly Instructions
Customer Service
1-800-933-0771
www.kidkraft.com 2
USE AND MAINTENANCE:
-Use on level surfaces only
-Please check assembly at regular intervals, and frequently
tighten hardware if necessary. If maintenance is not carried out,
the product could cease to function properly
CAUTION: Adult Assembly Required. Hardware
contains small screws with sharp points. Keep
unassembled parts out of reach of small children.
WARNING: CHOKING HAZARD
Small parts and sharp points, not
suitable for children under 3 years.
Step 4
Step 8 Step 9 Step 10
Step 5 Step 6 Step 7
11
11
11
11

***For safe installation it is essential to use hardware appropriate for your wall type. This wall anchor is only for
Drywall surfaces where wood studs are not available. Mount to wood wall studs whenever possible.
Use a 1/8” drill bit for the pilot hole. If mounting to plaster, wood panels, brick or other surfaces than drywall
consult your local hardware store or a qualified professional.
The following tools (not included)
are required for assembly:
Electric
Drill
1/8” Drill Bit
J
G
I
Use 1/8” drill bit
to drill hole in wall.
Do not drill an oversized hole
or the wall anchor will not hold
tightly into the wall.
Tap wall anchor into hole.
Secure product to wall with
screw “J” through fabric strap
and into wall anchor.
HARDWARE
Medium Locker
Wall Anchor
Assembly Instructions Item# 14321A-14324A
Customer Service
1-800-933-0771
www.kidkraft.com 3
USE AND MAINTENANCE:
-Use on level surfaces only
-Please check assembly at regular intervals, and frequently
tighten hardware if necessary. If maintenance is not carried out,
the product could cease to function properly
CAUTION: Adult Assembly Required. Hardware
contains small screws with sharp points. Keep
unassembled parts out of reach of small children.
WARNING: CHOKING HAZARD
Small parts and sharp points, not
suitable for children under 3 years.
JI
G
Step 11
