Kilews KTM-CSH User manual

KILEWS
KILEWS JAPAN CO., LTD.
□ KTM - CSH
数字扭力计操作手册
DIGITAL TORQUE METER INSTRUCTION MANUAL
OSH-Q04

®
Digital Torque Meter
KILEWS
操作前请阅读全部说明
一. 安全警告 !!
1. 工作场所要保持干净。
◎ 杂乱的工作区域及台面容易造成伤害。
2. 注意工作场所的环境。
◎ 勿将扭力计置放于雨中或潮湿处。
◎ 请在正常室温下(约24℃)使用扭力计。
◎ 工作场所应照明良好。
◎ 勿于有易燃液体或气体之处所使用扭力计。
3. 勿让孩童接近。
◎ 除操作人员以外应避免他人靠近工作场所。
4. 穿着适宜。
◎ 勿穿着太宽松的衣物或珠宝，以免操作工具时勾扯拉到。
5. 谨慎操作。
◎ 操作扭力计时应小心使用，注意操作方式及工作场所安全。
6. 稳固的固定机身主体。
◎ 当测量较大扭力时应使用夹子或虎头钳等工具来固定起子，如此会比较安全，同时可用双手操作起子。
7. 勿测试超过负荷量的扭力。
◎ 若测试超过负荷量会使仪器损坏甚至产生意外或伤害。
8. 勿拆卸、撞击或震动仪器。
◎ 自行拆卸仪器或仪器遭过度撞击、震动，可能导致仪器损坏。
9. 电击警告!!
◎ 勿以潮湿的手碰触电源插座以免电击。
10. 使用专用的充电器充电。
◎ 使用非专用的充电器可能会损坏仪器，更可能引起火灾意外。
11. 适当的充电。
◎ 请依指示电压充电。勿使用直流供电机或发电机充电，如此会产生高热引发火灾。
◎ 充电时间不要超过 8小时，过量充电会引起爆炸、过热和电池漏液，引起火灾。
12. 绝不可将电池(嵌装于扭力计内)丢弃火中。
◎ 如此会导致爆炸或释放有毒物质。(丢弃电池的程序应依当地法律规定妥善处理或送到专门的回收处)
13. 如有下列情况应关闭电源。
◎ 没有使用时或进行充电时。
◎ 进行修理时。
◎ 其它可能招致危险的情况时。
14. 细心保养扭力计。
◎ 请经常检查弹簧座，不要使用变形或坏掉的接头，以使操作正常安全。
◎ 定期检查电线和延长线，更换有损坏的线材。
2

®
Digital Torque Meter
KILEWS
15. 不可猛烈拉扯电线。
◎ 不可搬运悬挂着电线的仪器，也不要拉扯电线来拔开插头。
◎ 不可将电线放在高温、油腻和有锐利边缘的物品旁。
16. 检查有无因零件损坏所造成的功能损失。
◎ 在进一步使用仪器前，仔细检查有无损坏、能否正常运作。
◎ 检查任何有可能会影响运作的零件是否正常。
17. 请由专业的人员来修理仪器。
◎ 勿改装此产品。
◎ 应在购买的经销商处维修产品，若由非专业人员修理此产品，有可能会无法正常运作，甚至引起意外或伤
害。
18. 请使用专用的配件或附件。
◎ 勿使用本操作手册指示以外的配件或附件。
19. 不使用时请小心储放。
◎ 扭力计应储放在干燥且儿童无法接触之处、或是安全的地方。在运送时可利用此产品原有的包装盒。
3

®
Digital Torque Meter
KILEWS
二. 外观
①Torque Display Part 液晶显示器 ⑨UP Switch 上选键
②NG/LOBAT (low battery) lamp NG/LOBAT 显示灯 ⑩DOWN Switch 下选键
③ＧＯＯＤLamp GOOD 显示灯 ⑪Torque detection part 测试底座
④ON/OFF Key 电源开关 ⑫Measurement Mode change switch 测量模式选择开关
⑤AC/DC Adaptor Terminal 充电孔 ⑬SELECT Key 系统功能选择开关
⑥CLEAR Key 归零开关 ⑭Measurement Unit change switch 单位选择开关
⑦RS232C Output Connector 数据传输埠 ⑮Zero Adjusting Knob 归零调整器
⑧System Reset Switch 系统重置开关
4

®
Digital Torque Meter
KILEWS
三. 规格
型 号 KTM-CSH
30 ~ 174 Lbf.in
30 ~ 200 Kgf.cm
测 量 范 围 3 ~ 20 N.m
正 确 度 200 ~ 1000 数字显示为±0.5%
15 ~ 199 数字显示为±1%
显 示 器 三位元半 LCD 影像显示
测 试 方 向 正、反时钟方向
P-P(PEAK) 峰值模式 显示负荷力最高值
测量模式 TRACK 变值模式 显示负荷力值的变化
P-D(PEAK DOWN) 初值模式 显示负荷力最初峰值
数 据 输 出 RS232 序列输出 (速率 9600BPS)
数 据 记 忆 400 组
电 池 配 置 6VDC (Ni-Cd 1.2V x5 )
使用扭力单位 Lbf.in 、Kgf.cm 、N.m
充 电 时 间 少于 6小时
连续使用时间 约12 小时
电 池 寿 命 可充电 300 次以上，视操作情况而定
专 用 充 电 器 输入:AC 110V or 220V
输出:DC 7.25V(120mA)
机 体 尺 寸 180(长)x130(宽)x34(高)
重 量 约1.5Kg
四. 液晶显示器显示说明
名称 说明
高值 设定扭力显示值的最高范围
低值 设定扭力显示值的最低范围
PD 初始值 设定 PD 最低开始测量的数值
自动归零时间
若设定自动归零开始，测试完成后会在设定秒数
内自动清零。若设定 0.0C 则必须手动归零。
设置模式
设定完成 设定完毕后会显示，表示设定完成
清零 逐个或全部记忆值清除时显示
记忆功能
全部清零 所有记忆值全部清除
开头地址 选择欲输出的记忆值开头地址
结束地址 选择欲输出的记忆值结束地址
记忆值输出
数据输出 记忆值输出时会显示
5

®
Digital Torque Meter
KILEWS
五. 准备与测量方法
5.1 稳定机身
使用螺钉等固定机身。
5.2 测量单位的设定
测量扭力的单位由单位转换开关设定，当要改变单位时，需进行归零调整。
5.3 测量模式的设定
测量模式由模式转换开关设定。当改变单位时。需进行归零调整。
5.4 电源的开关
 打开电源开关（ON/OFF）
如果 LOBAT/NG 等亮起，请立即充电。
 当关闭电源时，请按下 ON/OFF 按钮约 1秒，仪器自动会关机。
归零调整
1. 将模式开关设为 TRACK
2. 左右调整归零调整开关，将显示器值设定为零【0.0】
3. 测量模式开关设定为使用时的模式【PD-TR-PP】
※如果 10 分钟之内没有完成按键动作，电源将自动关机。
5.5 功能键设定
1）设定最大值
按住 SELECT 键再按下 UP 键，绿灯发光，显示 。设定显示最大值。扭力的最大值是由 UP-DOWN 键
设定的。【设定欲显示的最大值，若显示器显示超过最大值，则 N.G 灯红灯会亮】
2）设定最小值
再次按下 SELECT 键，显示 ，设定显示最小值。扭力的最小值是由 UP-DOWN 键设定。如果设定的
最大值<最小值，GOOD-N.G 判断将不会被执行。【最大值>=最小值】
※设定完成后，若扭力低于最小值或扭力高于最大值，则 N.G 红灯会亮，反之若扭力在设定值范围之内，
GOOD 绿灯会亮。此功能可以设定扭力误差范围。
3）峰值的设定
再次按下 SELECT 键，显示 ，之后显示峰值。峰值由 UP-DOWN 开关设定。
（峰值超过设定值和扭力值 15 个数值， 当数值超过时，开始显示。）※此功能通常不用
4）自动清零设置
再次按下 SELECT 键，显示 AC ，设定显示自动清零时间。执行自动清零的时间由 UP-DOWN 开关设
定。（设定时间在 0.1～3.0 秒【时间间隔为 0.5】）
设定时间的选择
0.0C=>0.1C=>0.5C=>1.0C=>1.5=>2.0=>2.5=>3.0=>0.0C 循环
如果设定为 0..0C，为手动归零【按 CLEAR 手动归零】
5）结束设定
如果 SELECT 键再次被按下， 显示，设定结束。
6

®
Digital Torque Meter
KILEWS
5.6 测量方法
1）请使用螺钉等固定机身。
2）请按下 ON/OFF 键并打开电源。当电量不足时，LOBAT/NG 灯会闪烁，此时请用原厂充电器充电。
3）设定各个功能的数值。
4）归零调整。当显示器的值大于零，请进行归零调整。
5）在工具扭力测试部分进行测量。当工具有负荷扭力时开始测量。
6）检查工具的操作正常完成，测量的扭力值显示并读取，测量结束。
7）测量结束后，按下 CLEAR 键，显示器清零。若设定自动清零功能，在设定时间之后，数值将自动清零。
（测量值会被存储在内部存储器内，同时数据会输出至 RS232C 输出连接器。此功能只在 PD-PP 被执行）
8）继续工作，从 5开始重复。
如果要结束工作，请按下 ON/OFF 键1秒，关闭电源。（如果维持一个状态不动，10 分钟后电源被关闭）
六. 充电
当显示器上出现＂LOBAT＂字样时表示扭力计电量不足，需进行充电。
请关闭扭力计电源，以随机配备的充电器，接妥正确电源与扭力计充电孔即可进行充电。
充电时间请勿超过 6小时，以免造成电池过热、漏液甚至燃烧等伤害。
七. 数据传输(只限 PEAK 模式)
数据传输(需搭配专用传输线与软件) : 在每次测量完毕按归零开关时(或机器自动归零时)，扭力计会自动将测得
的数据经传输装置输出到计算机上。
※ 搭配用的传输装置为选购产品;扭力测试仪必须切于 PEAK 模式。
7.1 数据的编辑（仅限 P-P 、P-D 模式）
数据的传输是以 RS-232C 为传输的依据。故需用适合于 RS-232C 的打印机或计算机等设备来配合数据的传输；在每次
测量完毕按归零开关时（或机器自动归零时），扭力计会自动将测得的数据经传输装置输出到计算机上。
※搭配用的传输装置为选购产品。
7.2 若测试完成后，数据会资动记录于内存内，不会传输至计算器。
7.3 欲调出存于内存的数据操作顺序如下：
○
1按住 SELECT 键再按下 CLEAR 键则会显示「FA」，再按 ”DOWN” ”UP” 键来选取希望输出数据地址开头。
○
2接着按压 SELECT 键则会显示「LA」，并选取希望输出数据地址结尾。
○
3再按压 SELECT 键，则会显示「--P--」，而 资料就会传输。
○
4要中止，按 清除键(Clear)。
7

®
Digital Torque Meter
KILEWS
八. 服务保证
本产品在购买后一年内若有因生产或运送过程瑕疵而产生的故障情况，本公司无条件提供修理服务；但下情况
则被排除在外:
◎ 不当使用、修理或重组仪器而导致故障者。
◎ 在购买后因摔落等事故而导致故障者。
◎ 因天然灾害、污染和不正常的电压所导致的故障。
九. 校正服务
本产品于出厂前皆已做过可靠且符合国际标准的准确度校正，但为维持扭力计的精确度，应将扭力计做定期的
校验。本公司另提供专业并符合标准的调修服务，唯保证期间外的校验服务得另收费用。
如有任何疑問 請與當地代理商聯繫 !
8

®
Digital Torque Meter
KILEWS
Operation Menul for Digital Torque Meter
Model: KTM-CSH
1.Caution for safety
1. Keep work area always clean.
Cluttered areas and benches may invite injuries.
2. Consider work area environment.
Do not use torque meter in the rain or in the damp or wet place.
Use the product at a place left at constant temperature(about 24℃).
Keep work place well lighted.
Do not use or charge the product in presence of flammable liquids or gases.
3. Keep children away.
Keep any person other than the operator(s) away from work area.
4. Dress properly.
Do not wear loose clothing or jewelry, which may be caught in moving parts.
5. Work with the most care.
When using the product, carefully work, with consideration to how to handle, how to work, work environment, etc.
6. Fix main body firmly.
When operated for measuring a large torque, use clamps or a vise, etc. ,It is not only more safe than holding by hand but also makes it possible to
grip the screwdriver by both hands.
7. Do not apply a torque exceeding the permissible load.
If applied beyond the permissible load, it may cause damage to the detector, resulting in accident or injury.
8. Do not disassembly, shock and vibrate this product.
Avoid disassembling the product that is a precise instrument. If the torque meter is damaged by excessive shock or vibration, the product may not
only show the full performance but also result in accident or injury.
9. Caution to electric shock
Do not touch power plug by wet hand. It may cause electricshock.
10. For charging the battery be sure to use only exclusive charger.
Using a charger other than specified may cause a fire or injury.
11. Charge properly.
Charge on the indicated voltage. Do not use DC power or engine generator. It may cause abnormal heat, resulting in a fire.
Keep the charging time not longer than 8 hours. Overcharge may bursting, overheat and liquid leakage, resulting in a fire or injury.
Charge in a well-ventilated place. While being charged, do not cover with cloth.
12. Never throw the battery(built-in the torque meter) into fire.
It may cause burst or give off toxic substance. (The procedure for scrapping the battery shall be followed in accordance with local or regional law
on waste disposal. If there is no local or regional law on waste disposal, be sure to dispose of the battery at a recycling shop.)
13. In the following cases, turn off the main switch and disconnect the plug from outlet.
When not used or charged;
When repaired;
When any other danger is expected.
14. Maintain torque meter with care.
For better and safer performance, check screw joints regularly and use ones whose tips are free from deformation and wear down.
For replacement of accessories follow the instruction manual.
Inspect cords and extension cords periodically and if damaged, replace them.
15. Do not handle cord violently.
Do not carry the product hanging by cord or draw out socket from outlet by pulling cord.
Do not put cord near to a hot, oily or edgy part.
16. Check for absence of damaged parts.
Before further use of the product, carefully check for no damage, normal operation, or intended functions.
Check whether or not any other components that may affect its operation are normal.
Replace parts according to the instruction manual.
9

®
Digital Torque Meter
KILEWS
17. Have the product repaired by the specialized dealer.
Do not modify this product.
Repair should be made always by the dealer where you purchased the product. If repaired by any person with no knowledge or skills of repair, it
may not only show the full performance but also may cause any accident or injury.
18. Use only the specified accessories and attachments.
Do not use any accessories and attachments other than ones specified in this instruction manual.
19. Store properly when not in use.
Store the torque meter in a dry place and in a height out of children＇s reach, or secured area.
To transport the product, reuse the packing case with which this product was delivered.
10

®
Digital Torque Meter
KILEWS
2. Designations and dimensions of the components
①Torque Display Part ⑨UP Switch
②NG/LOBAT (low battery) lamp ⑩DOWN Switch
③ＧＯＯＤLamp ⑪Torque detection part
④ON/OFF Key ⑫Measurement Mode change switch
⑤AC/DC Adaptor Terminal ⑬SELECT Key
⑥CLEAR Key ⑭Measurement Unit change switch
⑦RS232C Output Connector ⑮Zero Adjusting Knob
⑧System Reset Switch
11

®
Digital Torque Meter
KILEWS
3. Specification
Model name KTM-CSH
Measuring range 30～174 lbf・in 30～200 kgf・cm 3～20 N･m ( at the time of Track)
Accuracy ±0.5% (or less 499±3digit)
display 4 figures digital display of LCD
The measurement direction CW-CCW (right and left)
Measurement mode Track, Peak (from 30 or more digits to a display),
Peak-Down (from 30 or more digits to a display)
A success or failure
judging function High and low value are measurement within the limits, and can be set up.
Data output RS232C conformity (baud rate 9600)
Data memory counts 400 data
Power supply Ni-Cd chargeable battery 1.2V×5cells 700mAh
Charging time From empty - 6 hours
Continuous working time About 12 hours
Exclusive charger (inputAC120V or 230V 50/60Hz output DC7.5V)
Accessories
(one piece each) Result of calibration document
Certification on calibration document / Traceability system figure
4. Explanation of the sign displayed on LCD
Name Representation
high value The high value of the success range is set up.
low value The low value of the success range is set up.
peak-down opening
value
The numerical value as which a peak-down begins to
function is set up.
auto clear time
If the set-up time comes, measurement value will be
automatically cleared in 0.0~3.0 seconds
(0.5s interval). *(0.0s is manually clearance)
Setting mode
setting closure It displays, when a setup is completed.
clearance It displays at the time of elimination of the each
or whole memory.
Memory
all (clearance) It displays, when eliminating all memory.
first address The serial number outputted to the beginning of
memory data is set up.
last address The serial number outputted to the last of memory data
is set up.
Memory data
output
data output It is displayed during the output of memory data.
12

®
Digital Torque Meter
KILEWS
5. Preparation and the method of measurement
5.1 Stabilize the body
Please use a bolt etc. and fix a body firmly.
5.2 Setup in Measurement Unit
The unit of the torque to measure is set up with a measurement unit change switch.
When you change a unit, please carry out zero adjustment.（5.4 zero adjustment）
5.3 Setup in Measurement Mode
The Mode of the torque to measure is set up with a measurement Mode change switch.
When you change a unit, please carry out zero adjustment.（5.4 zero adjustment）
mode contents
P-P peak to peak The highest value of load is hold-displayed.
(This mode is usually used.)
TRACK track A display also changes with load change.
P-D peak down
Load catches and displays the moment included in descent from a
rise. (when torque value falls by 15 or more digits exceeding of
setting value)
It is performed a additional tightening.
(*It may be unable to measure depending on a situation.)
5.4 ON OFF of Power Supply
* Turn on a power-supply switch (ON/OFF),
Supposing a LOBAT/NG lamp lights up, please charge promptly.
*When you turn off the power, please press the ON/OFF key for about 1 second.
* Check display zero. When the display more than zero has come out,
Please carry out zero adjustment.
zero adjustment
1.Set the Mode Switch at TRACK
2.Turn the Zero Adjusting Knob to the left and the right to set the displayed value to 0.
3. Set the Mode Switch at the mode to be used
* If key operation during 10 minutes is not performed, a power supply will be in OFF state automatically.
5.5 Setting Method of Each Functional Numerical Value
1) Change in Setting Mode, and Setup of Maximum Value
Press the UP Switch, Pressing the SELECT Key.
Green LED (GOOD lamp) sticks and it is displayed as . A maximum value is displayed after that.
The maximum value of torque measured value is set up by the UP-DOWN Switch.
13

®
Digital Torque Meter
KILEWS
2) Setup of a Minimum Value
SELECT key is pressed again. Displays. A minimum value is displayed after that.
The minimum value of torque measurement is set up by the UP-DOWN Switch.
If a maximum value < minimum value is set up, a yes-no decision will not be carried out.
(Maximum value ≧minimum value)
3) Setup of a peak down start value
SELECT key is pressed again. Display. A peak down start value is displayed after that.
A peak down start value is set up by the UP-DOWN Switch.
(A peak down exceeds this setting value and torque values are 15digit(s). When it falls above, it operates
(display))
4) Auto clear setup
The SELECT key is pressed again. Display. A time setup of an auto clearance is displayed
after that. Time to carry out the zero clearance of the display is set up by the UP-DOWN Switch.
(A setup is [the whole 0.5] possible in 0.1 - 3.0 seconds)
Setting time selection
0. 0C=>0.1C=>0.5C=>1.0C=>1.5C=>2.0C=>2.5C=>3.0C=>0.0C it returns.
0.0C if it comes out and sets up -- the zero in manual operation -- it becomes clear.
5) End of a setup
If the SELECT key is pressed again, it is displayed as and is a setting end.
Green LED (GOOD lamp) puts out the light.
(The inside of measurement mode has turned on green LED (GOOD lamp))
* Press the ON-OFF key to end a setup on the way.
It is displayed and measurement is started. Green LED (GOOD lamp) puts out the light.
5.6 Measuring Method
1) Please use a bolt etc. and fix a body firmly.
2) Please press the ON/OFF key and switch on a power supply.
Since power resource are insufficient when the LOBAT/NG lamp of a display part is blinking in that
case, please charge with the charger of exclusive use.
(Although measurement while charging is possible, use time should not exceed charge 6 hours.)
3) Set up the numerical value of each function. (Refer to above)
4) A display checks zero. When the display more than zero has come out, Please carry out zero adjustment.
（5.3）
5) Set a tool to measure in Torque detection part.
Measurement will be started if load torque is applied from a tool.
6) Check that operation of a tool has been completed normally.
The measurement torque value of a display part is read and it becomes a measurement end.
14

®
Digital Torque Meter
KILEWS
7) After a measurement end, if CLEAR key is pressed, a display will be cleared by zero.
If the auto clearance is set up by functional setup, a zero clearance will be automatically carried out after
setting time.
(In this case, measured value is saved in an internal memory and data is simultaneously outputted to
RS232C Output Connector.)
8) When continuing, repeat from 5).
9) If work is completed, please press the ON/OFF key for about 1 second, and turn OFF a power
supply.(Even when it remains as it is, a power supply is shut off after 10 minutes.)
The memory of the contents of each setting value is carried out.
6. Yes-no decision
The judgment of success or failure is performed only when measurement mode is PP (peak operation
mode). (30 or more digits of measured value)
At the time of PD (peak down mode), if the value of a peak down is detected, you will be told about by
green (GOOD) lamp lighting.
Yes-no decision below low value in high and low beyond high value over-torque
LED red Blink green lighting red Blink red lighting
Detection check peak down
LED green lighting -
7. Memory function and a data output
7.1 Usage of Memory
Data is always saved, whenever it presses the CLEAR key or an auto clearance starts.
We recommend you to carry out an all clearance (7.3 all clearance) before use.
The memory of data is begun from the data number 001.
When data is already memorized, it memorizes from the following memory number.
Preservation of a maximum of 400 data can be performed, and if it exceeds 400 data, it will be overwritten
from No. 001.
When required measured value exceeds 400, please save in a personal computer etc.
The data which carried out the memory can be searched with the UP Switch or the DOWN Switch.
If a memory number and a torque value are displayed by turns and button operation is left for 6 seconds, it
will move to measurement mode.
7.2 Output Method of Memory Data (RS232C Output)
1) If the CLEAR key is pressed, pressing the SELECT key – Display (the first number to
output) .A number is chosen by the UP Switch or the DOWN Switch.
2) Press the SELECT key. Display (the last number). A number is chosen by the UP Switch or the
DOWN Switch.
15

®
Digital Torque Meter
KILEWS
3) SELECT key is pressed again, it will be displayed as and data will be outputted.
After an output finishes, it returns to a measurement state.
4) Press the CLEAR key for 1 second to stop during an output.
7.3 Method of Memory Clearance
* It is, when eliminating all data at once and it continues pressing the CLEAR key for about 2 seconds.
to display. should press the DOWN Switch during blink.
* When clearing a memory individually, only one data will be eliminated, if a memory number to eliminate
by the UP Switch or the DOWN Switch is displayed and the CLEAR key is pressed during the display.
7.4 data output
Whenever data presses the CLEAR key or requires an auto clearance, as soon as a memory memorizes, it
outputs a signal also to a RS232C output and a printer output.
7.5 Data Format
The data output is RS-232C output conformity. Data can be outputted to the printer corresponding to
RS-232C, or a personal computer.
Data bit length Start bit 1+ Data bit 8+ Stop bit 2 + With no parity
Baud rate 9600bps
Connector form D-Sub-9pin
Connector specification No. 3 pin : Data output No. 5 pin : GND
１８ ○○○ ＯＥ ２０ ±○○○○
○２０ OF ○○○ ○○○ ０Ｄ
CAN ※ＳＯ Space Sign Measured
value Space ＳＩ Unit ＣＲ
7
All data 21
ＣＡＮ：Cancellation
※ ： In the case of a memory data output, it is a "data number." It becomes a "space" when outputted at the time of
"a clearance."
ＳＯ ： Double width expansion printing specification
± ： Measurement sign <+> A direction with a bundle <-> The Return Direction
Measured value: Adecimal point is also included. The last is a space when there is no decimal point.
１０. ００---- 10.00
ＳＩ ： Double width expansion printing release
Unit ：In N-m etc., the remainder is a space.
Ｎ・ｍ---- N･m （ｋｇｆ・ｃｍ---- kgf･cm ）
ＣＲ ：Carriage return
16

®
Digital Torque Meter
KILEWS
△Cautions: An interface cable is used for connection of a computer.
Please prepare a cable according to a computer. Please ask our company a cable.
8. about a system and a power supply
8.1 System Reset Operation
Even if it charges after a nickel-cadmium battery carries out full electric discharge (when not using it for a
long period of time), and it switches on a power supply, CPU in equipment may not start.
If it becomes such a situation, please push a system reset button once.
It will be in an initial state (all the contents of a memory are eliminated).
When you use system reset, please do not use it other than the following conditions.
* Even if it connects an AC/DC adaptor and turns on a power supply in the state where cross over a long
period of time, and it is not used, when a number does not display on LCD.
* When a measuring instrument stops operating in addition to this.
When system reset is performed, please perform zero adjustment (P7 5.6).
Moreover, since all the contents of a memory are eliminated, please redo a setup once again.
8.2 Power Supply
* If the LOBAT/NG lamp of a display machine blinks, please charge promptly.
* Charge should use theAC/DC adaptor of the exclusive use attached.
* Charge time should not exceed 6 hours by any means.
(It may become the cause of the fire by the burst of a battery, generation of heat, and liquid leak, or an
injury by fault charge.)
* If key operation is not performed for 10 minutes, a power supply will be in an OFF state automatically.
(Auto-power-off)
* When you turn off the power, please press the ON/OFF key lightly for about 1 second.
9. Calibration trust service
9.1 Periodical calibration
Proofreading is periodically required in order to manage the accuracy of torque meter.
By our company, the proofreading with the high reliability traced to the national standard is performed, and
in order to use it within accuracy, I recommend you one proofreading per year.
(Periodical calibration is a charge.)
An inspection report, a proofreading certificate, and traceability system figure attachment
17

®
Digital Torque Meter
KILEWS
9.2 Guarantee
Although manufactured under sufficient quality control, if the fault which originates in manufacture,
transportation, etc. of our company within one year after a purchase should occur, I will fix this machine
gratuitously.
In the following case, it becomes a charge within the term of a guarantee.
Failure and damage by the error, and unjust repair and reconstruction on use
Failure and damage by the natural disaster, pollution, unusual voltage, etc.
9.3 When Troubled
The checkpoint when being troubled. Before judging it as failure
When functional fault arises, please check based on the following table.
By the corresponding processing, when fault is not canceled, please tell repair to our company or a store.
In addition, I am allowed to make a torque tester's term of a guarantee into one year from a purchase.
(However, there may be onerous in the contents of repair.)
Checkpoint when being Troubled
condition checkpoint solution
A power supply is not
turned on. Is charge carried out? Please carry out regular time charge using the exclusive charger attached.
Even if it turns on a
power switch, a LOBAT
lamp blinks and a power
supply is shut off
immediately.
Charge is insufficient. Please carry out regular time charge
using the exclusive charger attached.
It does not display, even
if it switches on a power
supply after charge of
regulation time.
If it is not used over a long
period of time, an internal
battery will carry out full
electric discharge.
It will return, if a front system reset
button is pushed.
After a return, please push a clear button
and give an indication zero.
Is it the numerical value of
each function under setup? Please end a setup and return to measurement mode.
It cannot measure. When torque is applied, does a
numerical value change? The gauge may be damaged when not changing. Please request repair.
A display disappears
immediately.(It does not
hold by measurement
mode PP/PD)
It is used setting up an auto
clearance.
Please check the setting item of an auto
clear function again. (An auto clear
function will operate with the load
torque of 30 or more digits.)
When there is no necessity, please set it
as 0.0C.
18

®
Digital Torque Meter
KILEWS
如有疑问请与经销商联系
杉﨑計器株式会社
19
