Kilowatt Labs SIRIUS CAPACITOR MODULE User manual

SIRIUS CAPACITOR MODULE
User Manual
Model number: 3550-48-B-1.7C-M-SD-A-G
Version 1.0; Release Date: July 2019

Introduction
The Sirius Capacitor Module (“Sirius”) is supercapacitor-based storage that uses supercapacitors as
storage cells instead of chemical cells. Kilowatt Labs’ proprietary balancing, control and charge
retention algorithms control the operation of the supercapacitor-based modules, making Sirius a safe,
efficient and effective alternative to chemical batteries wherever chemical batteries are deployed.
Legal Provisions
No part of this User Manual (“Manual”) may be reproduced, or transmitted, in any form or by any
means, without the prior written permission of Kilowatt Labs, Inc. (“Kilowatt” or the “Company”).
Specifications in this Manual are subject to change without notice. While every attempt has been
made to make the Manual accurate and up-to-date, users are cautioned that product improvements
may cause the Company to make changes to specifications without advance notice. Users are
encouraged to consult the Company or its Resellers before using the Manual. Neither the Company
nor its Resellers shall be liable for any indirect, incidental, or consequential damages under any
circumstances caused by reliance on the material presented, including, but not limited to, omissions,
typographical errors, arithmetical errors or listing errors in the content material. The content of this
manual shall not be modified without the written authorization of the Company.
Trademarks
All trademarks are recognized, even if not explicitly identified as such. Kilowatt Labs® is a registered
trademark of the Company.

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
3
Contents
1. Safety Instructions: ......................................................................................................................... 5
1.1 Symbols Convention: ........................................................................................................ 5
1.2 Safety Precautions: ........................................................................................................... 5
1.3 Modules Connection Safety Precautions:......................................................................... 6
1.4 Shipping: ........................................................................................................................... 7
1.5 Qualified Installer:............................................................................................................. 7
2. Product Introduction:...................................................................................................................... 7
2.1 Product Part Number:............................................................................................................. 7
2.2 Product Overview: .................................................................................................................. 8
2.2.1 Appearance:....................................................................................................................... 8
2.2.3 Dimensions and Weight:.................................................................................................. 11
2.3 Product Description:............................................................................................................. 11
3. Module Installation:...................................................................................................................... 16
3.1 Inspection: ............................................................................................................................ 16
3.2 Safety Gear: .......................................................................................................................... 16
3.3 Unpacking and Contents Check:........................................................................................... 17
4. Operation Procedures:.................................................................................................................. 17
4.1 Module Configuration:.......................................................................................................... 17
4.2 Software Configuration:.................................................................................................. 19
5. Recovery Procedure:..................................................................................................................... 22
6. Connecting the Module in Parallel or in Series:............................................................................ 23
6.1 Parallel Connection of Sirius Modules:................................................................................. 23
6.2 Series Connection of Sirius Modules: ................................................................................... 24
7. Automatic Safety Shutdown: ........................................................................................................ 25
8. Trouble Shooting:.......................................................................................................................... 26
9. Features: ....................................................................................................................................... 27
9.1 Key Features: ...................................................................................................................... 27
9.2 Physical features:................................................................................................................ 27
9.3 Technical Features: ............................................................................................................. 28
10. Shelf Life:....................................................................................................................................... 29
11. Maintenance:................................................................................................................................ 29
12. Disposal:........................................................................................................................................ 29
13. Test Procedures: ........................................................................................................................... 29

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
4
13.1 Round Trip Efficiency Test: ................................................................................................. 29
13.2 Performance Data:............................................................................................................ 30
13.2 ESR, Terminal Resistance and Internal Resistance: ........................................................ 32
13.3 Test Method for Self-Discharge:..................................................................................... 34
14. FAQs:....................................................................................................................................... 34

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
5
1. Safety Instructions:
This manual contains instructions for unpacking, mounting, installation and operation of a Sirius
Module. Please read this manual carefully before operating the system and follow all warnings and
safety instructions to prevent accidents. The Sirius Module must be installed by trained personnel.
1.1 Symbols Convention:
Safety instructions and general information that appears in this manual are described.
1.2 Safety Precautions:
The Sirius Modules are designed to provide years of trouble-free operation. Proper handling is
required to avoid damage to the Module. In particular the following precautions should be observed.
•Personal Safety:
→Always wear proper personal protective equipment (eyes protection, gloves and safety shoes).
→Always make sure charger is set as recommended.
→Always make sure chargers are disconnected while working on Modules.
•Module Safety:
→Do not subject the Module to strong impact.
→Do not crush or puncture the Module.
Caution!
‘’Caution” indicates hazardous situation which, if not avoided could
result in minor or moderate injury.
Warning!
‘’Warning” indicates hazardous situation which, if not avoided could
result in major injury or death.
Danger!
‘’Danger” indicates hazardous situation which, if not avoided could
result in serious injury or death.
Note!
‘Note” provides tip that are valuable for optimal operation of your
product.

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
6
→Do not dispose the Module in a fire.
→Do not charge the Module when the temperature is below -30oC.
→Do not charge the Module when temperature is above 80oC.
→Do not operate the Module above the specified voltage.
→Under no circumstances charge/discharge the Module at more than 125A.
→Under no circumstance must the charging voltage exceed 55 Vdc for more than 60 seconds.
→Do not expose the Module to temperatures in excess of 80°C.
→Do not place the Module near a heat source, such as a fireplace.
→Do not disassemble the Module under any circumstances.
→Do not touch the Module with wet hands.
→Do not expose the Module to moisture or liquids.
→Keep the Module away from children and animals.
→Ensure precautions to prevent short-circuit under all circumstances.
→Do not connect or disconnect terminals from the Module without first disconnecting the load.
→Do not touch the terminals with conductors while the Module is charged. Serious burns, shock, or
material fusing may occur.
→Protect surrounding electrical components from incidental contact.
→When connecting to external devices ensure that galvanic isolation does not exceed 1000V.
→Do not use the Module in open-environment, in rain or in a place exposed to water and other
liquids.
→Do not subject the Module to high pressure.
→It is not recommended to stack more than 2 Modules.
→Do not step on the Module.
→Do not drop the Module. Internal damage may occur that will not be visible.
→Do not stack Modules once they have been removed from the packaging, instead the Modules
should be placed on shelving.
→In case the Module is physically damaged due to any event, do not install and energize the Module
under any circumstances and immediately contact your Reseller.
1.3 Modules Connection Safety Precautions:
→All Modules must be at 100% SOC before connecting in Series or in Parallel.
→The maximum number of Modules that can be connected in series is 8 with Module Combiner.
→Do not connect more than 8 Modules in Series.
→Modules cannot be connected in Series-Parallel combination under any circumstance.

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
7
1.4 Shipping:
Sirius Capacitor Modules are shipped out via Air and Sea.
•If the Modules are shipped via Air, please follow the instructions given below:
•Carefully remove the nails from all the four sides of the wooden box and open it.
•Remove the foam and cling wrap and open the carton box and lift the Module manually.
•If the Modules are shipped via Sea, please follow the instructions below:
•Carefully remove the Module from the pallets after cutting the packing strip holding the
Modules to the shipping pallets.
•Open the carton box and lift the Module manually.
1.5 Qualified Installer:
Selling and installation of this Module is only through the Company’s Resellers who are trained on
installation, operation and maintenance of the Sirius Modules.
2. Product Introduction:
2.1 Product Part Number:
1) Capacity of Module in Wh
2) Nominal Voltage of the Module
3) Terminals are on the Front Side
4) Maximum Charge Rate of the Module
5) With Individual Cell Monitoring and Total Monitoring
6) With Safety
7) With Alarm
8) General Module
Note!
If you want to connect more than 8 Modules in Series, please contact your
Reseller.

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
8
2.2 Product Overview:
2.2.1 Appearance:
The appearance of the Sirius Module is shown below:
2.2.2 Mechanical Drawings:

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
9
Front View
Side View

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
10
Top View
Isometric View

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
11
2.2.3 Dimensions and Weight:
Width
600 mm
Depth
534 mm
Height
200 mm
weight
75 kg
2.3 Product Description:
Object
Mark
Description
1
Circuit Breaker
C100A Circuit breaker for switch
ON/OFF Module.
2
Bypass Circuit Breaker
C100A Circuit breaker for bypassing
electronic switch.
3
Fault Reset
Fault Reset Button
4
Aux
Auxiliary USB
5
Comm Connector
Communication Connector USB
6
Comm Status
Communication Status LED
7
Terminal Status
Terminal Status LED
8
LCD
(16×2) LCD

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
12
9
F12 terminals
Terminals
1. Circuit Breaker:
Circuit breaker is used to power ON the Module. It also acts as a second line of protection, if the circuit
fails to protect the Module from over current, the circuit breaker will trip.
2. Bypass Circuit Breaker:
The Bypass Circuit breaker is used to bypass electronic switch. It is used for Series connection and
recovery of the Module.
3. Fault Reset:
Fault Reset is a push button which is used to turn ON the protected terminal manually after it turns
OFF due to any error.
The additional features of fault reset are as follows:
a) Hold fault reset for 5 seconds to toggle the protected terminal.
b) Hold fault reset for 3 seconds to reset fault if there is/are any.
c) We can set the Current reading to zero.
d) Press fault reset button to check the state of charge and instantaneous power.
e) Press the fault reset button to see the individual cell voltages.
•Checking for individual Cell Voltages:
When the fault reset button is pressed, the LCD after displaying the state of charge (SOC) and
instantaneous power, will display the cell voltages of the first four cells as shown below:
Whereas:
01=Voltage of 1st Cell
02=Voltage of 2nd Cell
03=Voltage of 3rd Cell
04=Voltage of 4th Cell
By continuously pressing, the cell voltages will be displayed for all the cells.
•Enabling/disabling Cell balancing:
After scrolling through the individual cell voltages, cell balancing can be enabled/disabled by the
following steps below:
Step 1: When current is zero, LCD will display the message as illustrated below.

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
13
Step 2: After this message appears, hold fault reset button for 5 seconds, then the LCD will display the
following message which means that the cell balancing has been enabled.
Step 3: To disable cell balancing, when current is zero, the LCD will display the following message.
Step 4: After this message appears, hold the fault reset button for 5 seconds, then when the LCD
displays the following message, it means that balancing has been disabled.
Step 5: To make the current zero, follow the steps below:
→When current is not zero, the LCD will display the following message.
Note!
To enable and disable balancing, the Current should always be zero.
Note!
Balancing is automatically disabled if there is a Current reading
greater than zero.

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
14
→To make the current zero, hold the fault reset button for 3 seconds and the LCD will display the
following message.
This means that the current is now zero.
To return back to the normal screen, press the fault reset button once more or leave the Module idle
for 5 seconds.
4. Auxiliary USB:
This is an auxiliary connector with isolated UART or Serial Communication for wireless monitoring,
Module Combiner and future functions.
5. COMM Connector USB:
This is a COMM connector to monitor the Module using the Sirius software. FTDi chip is used for this
USB.
6. COMM Status LED:
COMM Status LED indicates the communication status.
•LED Status Indication:
Color
Status
Indication
Red
Blinking
Control Module is communicating with SiriusVIEW Software.
Red
Steady
Control Module is not communicating with SiriusVIEW
Software.
Red
Dimming
Module is in power down state.
7. Terminal Status LED:
Note!
Make sure that there are no external loads or charger before setting
the current to zero.

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
15
Terminal status LED indicates the F12 terminal status.
Color
Status
Indication
Green
ON
The F12 terminal is active
Green
OFF
The F12 terminal is not active.
8. LCD Description:
→Once the power is switched ON from the circuit breaker, the Module gets power and the LCD
shows the following message after 3 seconds under normal operation:
→
→After 1 second, the following two LCD screens get switched with each other.

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
16
9. F12 Terminals:
These are the output terminals of the Module having electronic switch protection that is limited to
100VDC only. F12 terminals are used to connect the load or charger to the Module. There are also
positive and negative cables in the jumper cable set. The red one is positive (+), the black one is
negative (-).
3. Module Installation:
3.1 Inspection:
Inspect the shipping carton for visible damage including cracks, dents, deformation and other visible
abnormalities prior to unpacking the Module. Document (photograph) any damage and report this to
your Reseller as well as to the shipping agent immediately. Remove the Module from the shipping
carton and retain the shipping materials until the unit has been inspected and is determined to be
operational.
3.2 Safety Gear:
Installation must strictly follow the national safety regulations in compliance with the enclosure,
installation, creepage, clearance, casualty, markings and segregation requirements of the end-use
application. Installation must be performed by professional installers only. Switch OFF the system and
check for hazardous voltages before altering any connection! Sirius Modules must be handled only by
qualified and trained personnel. Installation should not exert bending or twisting torque to the Module
enclosure.
Never connect the red cable to the negative terminal of
the Module.

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
17
3.3 Unpacking and Contents Check:
Check the contents of the package.
1) Sirius Capacitor Module: 3.55KWh48VDC 3) USB Cable A-B
2) Screws × 2 4) Washers × 4
4. Operation Procedures:
4.1 Module Configuration:
Follow the steps below to switch ON the Module.
Step 1: Connecting the Load:
Connect the F12 terminals of the Module to the load. F12 terminals are shown in picture below:
Note!
Read the safety Instruction section before installation.
1
2
3
4

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
18
Step 2: Module Start-Up:
1. Turn ON the Circuit breaker by pushing the Blue button upwards as shown in the picture below:
2. The picture below shows that the Module is turned ON.
Note!
Use the Bypass circuit breaker button to connect the Modules in Series
and for recovery purpose.

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
19
3. Wait till the LCD screen on the Module displays initial values.
4. Be sure you are able to see the terminal status LED OFF.
5. Press and hold the fault reset button, after 3 seconds the terminal status LED will change to Green.
6. Release the fault reset button.
Step 3: Module Shut-Down:
1. Press and hold the fault reset button to turn OFF the terminal. After 3 seconds the terminal status
LED will go OFF.
2. Make sure every indicator on the Module is OFF.
3. Turn OFF the Module by moving the Circuit breaker button to the OFF position.
4.2 Software Configuration:
To configure SiriusVIEW application, please follow the steps below.
1. Install the SiriusVIEW application on your system.
2. Connect the USB cable to the COMM connector USB slot to start communication and monitoring.
3. Turn on the Sirius Module by pressing the fault reset button on front panel.
4. Wait till the LCD screen on the Module displays initial values.
5. Double click on the SiriusVIEW application to execute it.
6. When the Log-In appears, SiriusVIEW, enter the default username and password as shown below.
Default Username: admin
Note!
Always turn OFF the Module when not in use because it is Self-
Powered. If left ON, the self-discharge rate will increase.
Note!
Due to shipping laws and regulations, the Module may be shipped in
partial State of Charge.

Sirius Capacitor Module –User Manual Model Number - 3550-48-B-1.7C-M-SD-A-G
This manual is subject to change without notice and at the sole discretion of Kilowatt Labs, Inc.
Kilowatt Labs, Inc. | www.kilowattlabs.com
20
Default Password:123
7. Select SiriusVIEW as shown below and left click.
8. Enter Serial Port (COM) that Module is using at the beginning of application and select the type of
Module from drop down menu.
